Omega Altise OP40B User manual

OP40B
40CM BLACK
PEDESTAL FAN

OMEGA ALTISE
OMEGA ALTISE
Important Safety Instructions. ........................................................................................1
Technical Details and Parts...........................................................................................2
Getting Started.............................................................................................................. 2
Appliance Components................................................................................................. 3
Assembly. ..................................................................................................................... 4-7
How To Use. ..................................................................................................................8
Cleaning and Maintenance. ...........................................................................................8
TABLE OF CONTENTS

OMEGA ALTISE
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT: Read the safety precautions of this booklet carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety
information.Failuretocomplywithinstructionscouldresultinpersonalinjuryand/orpropertydamage.Ifyou
areunsureabout anything regarding your pedestal fan or these instructions, please contact Omega Altise
on1300795572inAustraliaor(09)4156000inNewZealandbeforeoperatingyourappliance.
Read all instructions carefully before using the pedestal fan.
Use this pedestal fan only as described in this manual. Any other use not recommended by the manufacturer may
cause fire, electrical shock, or injury to persons. Do not modify this appliance. Do not try to repair this appliance –
there are no user serviceable parts within.
Remove the packaging and ensure that the appliance is undamaged. In case of doubt do not use the appliance and
contact Omega Altise Service. Do not let children play with any parts of the packaging.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance. Extreme caution is necessary when the pedestal fan is used by or near children or
individuals with decreased mental and physical capacity and whenever the pedestal fan is left operating unattended.
Before you use the appliance, check if the voltage marked on the rating label corresponds to the mains in your
home. The appliance must be connected to a grounded power supply.
Do not use this appliance with a programmer, timer or any other device that switches the appliance on
automatically, since a fire risk exists if the appliance is covered or positioned incorrectly.
Do not pull the power cord to disconnect with the power source. Always grasp the plug to pull it out.
Do not run power cords under rugs or other combustible materials. Do not place power cords in areas where they
can be a tripping hazard. Do not operate directly below a power outlet.
Do not insert any objects into the appliance as it may cause an electric shock or fire or damage to the appliance. Do not
block or tamper with the appliance in any manner while it is in operation. To prevent a possible fire, do not cover the
appliance in any manner. Do not place on soft surfaces, like a bed, where openings may become blocked.
Do not leave the appliance unattended. Always unplug the appliance when not in use. Take care that it is not
obstructed whenoscillating.
Keep materials such as hair, net curtains, tablecloths & clothes away from the openings of the pedestal fan, as
material may be sucked into the appliance causing injury, damage to property or the appliance.
The appliance has hot and arcing or sparking parts inside. It must NOT be used in potentially dangerous locations
such as flammable, explosive, chemical-laden, corrosive, salty or wet atmospheres. This appliance is intended for
general indoor domestic useONLY.
This appliance is not intended for use in wet or damp locations. Never locate it where it may fall into a bathtub or other water
container.
Do not use the pedestal fan outdoors. Do not use close to windows or in direct sunlight.
Always place the appliance on flat, stable surfaces before use. Always place the appliance vertically on its base.
Itisimportant thatyou retaintheseinstructions,proof ofpurchase aswell as otherimportant
documents about this product for future reference. Due tocontinualproduct development,
Omega Altise reserves the right to alterspecificationsorappearanceswithoutnotice.
Disposeof packaging responsibly –recycle where facilities are available.
1
The Function Switch should not be used as the sole means of disconnecting power.
Always unplug the power cord before cleaning or moving the appliance.
WARNING: To avoid danger of electric shock, unplug from outlet when not in use and before cleaning.
If the supply cord is damaged, it must be replaced by the manufacturer, its Service Agent or
similarly qualified persons in order to avoid a hazard. In order to avoid overheating, do
not cover the appliance. Do not use the appliance in the immediate surrounding of a bath,
shower or swimming pool.

OMEGA ALTISE
Model: OP40B Black Pedestal fan
Power: 220-240V 50Hz,
60W.
Gross Weight: 14.5kg.
Dimensions 130–170
H(max)x45.5W x45.5D
cm
1. Carefully remove the parts of the appliance from the plastic
bags and the carton, and unwind the cord to its full length.
2. Place the weight of the base under the base and insert the lower tube through the holes of them. Fix the parts together by
using the nut provided.
3. Connect the middle tube to the lower tube by screwing them together.
4. Insert the power cord through the base, the bottom tube, the middle tube and the
upper tube. The connector of the power cord should come out a little bit from the
upper tube.
5. Link the connector coming out from the upper tube to the connector coming out from the head of the fan and fix them by
rotating the plastic nut.
6. Fix the head of the fan to the upper tube by using the 2 screws provided.
7. Fix the power cord under the base by using the cable holder and the 2 screws provided.
2
TECHNICAL DETAILS AND PARTS

OMEGA ALTISE
6
8
10
1. Grid
2. Blades
3. Upper tube
4. Middle tube
5. Lower tube
6. Motor
7. Off/Speed control knob
8. Blue LED rotary controller
9. Base
10. Weight for the base
11. Power cord
3
APPLIANCE COMPONENTS
1
2
3
4
5
7
9
11

OMEGA ALTISE
Unpack the fan and make sure all the parts are available before you proceed with the installation.
1
Place the weight of the base (10) under the base
(9) and insert the lower tube (5) through the holes
of them. Fix the parts together by using the nut
provided.
2
Connect the middle tube (4) to the lower tube
(5) by screwing them together.
3
Connect the upper tube (3) to the middle tube
(4) by screwing them together.
The upper tube has 2 holes on the top.
4
ASSEMBLY

OMEGA ALTISE
4
Insert the power cord (11) through the base (9), the
bottom tube, the middle tube and the upper tube.
The connector of the power cord should come of
the upper tube.
5
Link the connector coming out from the upper tube
(3)to the connector coming out from the head (6) of
the fan and fix them by rotating the plastic nut.
5

6
Fix the head (6) of the fan to the upper tube (3) by
using the 2 screws provided.
7
Fix the power cord (11) under the base (9) by
using the cable holder and the 2 screws provided.
6

OMEGA ALTISE
N.B:
The fan can be installed at two heights depending on whether or not the middle tube is used.
If the smaller size is needed please avoid the steps 2 and 3 of assembly and proceed to connect the upper tube to the
lower tube by screwing them together.
ATTENTION: do not connect the fan to electrical supply until the unit is fully assembled.
7
170
cm
130
cm

Adivision of Shriro Australia Pty Ltd
104VanessaStKingsgroveNSW2208
In Australia: 1300 795 572
In New Zealand: [phone]
www.omegaaltise.com
OMEGAALTISE
Place the fan in a flat and stable surface. Make sure the Off/Speed knob is in
Off position (“0”) then plug it into a correct socket.
To select the desired speed rotate the Off/Speed knob; the desired speed
must be aligned at the reference dot place on the motor.
0 = off
1 =low speed
2 = medium speed
3 = high speed
① = low speed with vertical oscillation
② = medium speed with vertical oscillation
③ = high speed with vertical oscillation
If the fan is working the blue LED light ring will be on; if the fan is off, the blue
LED light ring will be off.
When the fan is not used disconnect it from the electrical supply.
WARNING: ALWAYS UNPLUG THE CORD BEFORE MOVING OR CLEANING, DO
NOT
The fan should be cleaned periodically (at least once a month depending on the build-up of dust).
Clean the body of the pedestal fan with a soft damp cloth. Always make sure that the appliance is completely
dry before connecting back to the mains supply.
CAUTION: Do not use gasoline, benzene, thinner, harsh cleaners, etc. asthey willdamagethepedestal fan.
NEVERuse ALCOHOLORSOLVENTS.
Remove the front guard and take out the fan blades. Wash under water, rinse & dry. Replace fan blades
and frontguard. Donot disassemble the faninany othermanner.
STORAGE: Store the pedestal fan with these instructions, in a cool, dry place with a cover over it. 8
HOW TO USE
Reference dot
CLEANING & MAINTENANCE
