Omron F3EM2-005 Series User manual

ZX-T Series
Cat. No. E77E-EN-01
Measuring Light Curtain
OPERATION MANUAL
Cat. No. E77E-EN-01 Note: Specifications subject to change without notice.
Authorized Distributor:
Printed in Europe
Cat. No. E77E-EN-01 F3EM2 Measuring Light Curtain OPERATION MANUAL
F3EM2

Manufacturer: OMRON Europe B.V.
Wegalaan 67-69
2132 JD Hoofddorp, THE NETHERLANDS
WWW www.industrial.omron.eu
User‘s Manual: Version 0.2 dated 18-10-2011

1
Precautions
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
Precautions
WARNING
The F3EM2 multi-beam photoelectric sensor with beam evaluation function is not a safety
component for ensuring the safety of people which is defined in EC directive (2006/42/EC) or
by any other regulations or standards.
GENERAL INFORMATION
The instructions in this manual must be followed in order to safeguard correct installation. The
barrier does not contain any parts that are subject to maintenance; do not remove any
electronic parts from the housing for any reason. In case of malfunction, please contact your
sales representative with a description of the failure found and its period of operation. Do not
touch the front protective cover with your hands as dust and/or grease may decrease
performance.
OPERATING ENVIRONMENT
Do not use the light curtain in locations with explosive or flammable gas. Make sure that the
product is operated in accordance with IP65 standards. Do not subject the light curtain to
excessive shock when mounting. When using the light curtain in the vicinity of an inverter
motor, be sure to connect the protective earth ground wire of the motor to earth. Failure to
ground the motor may result in malfunction of the light curtain. Further it is recommended to
use shielded cables and to connect the shield to the ground in such cases.
CLEANING
When cleaning the front covers please do not use woollen cloths or organic solvents. The
interval between cleaning depends on conditions in the environment (dust, fog).
POWER SUPPLY VOLTAGE AND OUTPUT LOAD
Do not connect an AC power supply to the Sensor. If AC power (100 VAC or more) is supplied
to the Sensor, it may explode or burn. Make sure that the power supply to the Sensor is within
the rated voltage range. If a voltage exceeding the rated voltage range is supplied to the
Sensor, it may explode or burn.

Table Of Contents
3
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
Precautions ........................................................................................... 1
Chapter 1 Overview
1-1 Applications ............................................................................................1-2
1-2 Model line up ..........................................................................................1-3
Chapter 2 Installation
2-1 General...................................................................................................2-2
2-2 Mechanical installation ...........................................................................2-3
2-3 Operating environment ...........................................................................2-4
2-4 Operating distances................................................................................2-4
2-5 Wiring & output circuit.............................................................................2-5
2-6 Setting the internal selector-switches .....................................................2-7
Chapter 3 Operation - General aspects and definitions
3-1 Beam order.............................................................................................3-2
3-2 Output modes .........................................................................................3-3
Chapter 4 Operation - Analog models
4-1 DIP switch setting ...................................................................................4-2
4-2 Analog output value................................................................................4-3
Chapter 5 Operating serial output models (RS-232C)
5-1 DIP switch setting - Overview.................................................................5-2
5-2 Transmission speed (baud rate).............................................................5-4
5-3 Beam aquisition and data aquisition.......................................................5-4
5-4 Communication protocol for serial output ...............................................5-5
Chapter 6 Order codes
Chapter 7 Technical specifications
7-1 Ratings ...................................................................................................7-2
Chapter 8 LED indicators and error indication
8-1 LED indication on receiver unit...............................................................8-2
8-2 LED indication on emitter unit.................................................................8-3
8-3 Troubleshooting for error indication........................................................8-4
Chapter 9 Dimensions
Chapter 10 Accessories
10-1 Mounting bracket ..................................................................................10-2
10-2 Cables ..................................................................................................10-2
Manual Revision History .............................................................................. 1

4

F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
1
1-1 Applications ..................................................................1-2
1-2 Model line up.................................................................1-3
Overview

1-2
1-1 Applications
1
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
Overview
1-1 Applications
F3EM2 is a multi-beam measuring light curtain designed for easy height and profile
measurement for various applications. Programming via dip switches makes it easy to set up
F3EM2 everywhere without external controller or Remote PC. Due to its robust housing
F3EM2 is also suitable for hash environments in industry.
Volume measurement Position control
Profile scan Hole detection
Wood industry

1-3
1-2 Model line up
1
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
Overview
1-2 Model line up
F3EM2 is provided with 3 output versions:
Analogue 0-10 V
RS-232C + analogue 0-10 V
RS485 + analogue 0-10 V (on request)
F3EM2 is available in two resolutions:
Models with 7.5mm resolution are available upon request.
Due to its modular design F3EM2 can be provided in various sizes. For standard sizes please
refer to model list in chapter 6.
Model Sensing distance Pitch resolution Min. detectable object
F3EM2-005-[…] 0 to 3 m 5 mm 10 mm
F3EM2-018-[…] 0 to 15 m 18 mm 30 mm

F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
2
2-1 General ..........................................................................2-2
2-2 Mechanical installation ................................................2-3
Mounting accessories ..................................................................... 2-3
Additional mounting rigidity ............................................................. 2-3
Mechanical Mounting ...................................................................... 2-4
2-3 Operating environment ................................................2-4
2-4 Operating distances .....................................................2-4
Analogue models ............................................................................ 2-5
Models with serial & analogue output ............................................. 2-6
2-5 Wiring & output circuit .................................................2-5
2-6 Setting the internal selector-switches ........................2-7
Installation

2-2
2-1 General
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
2
Installation
2-1 General
The light curtain consists of one bar with light emitting optical elements and of one with
receiving optical elements. The photosensitive elements are scanned in sequence, thus
broken rays are detected.
F3EM2 features optical synchronisation and does not require synchronization wire between
transmitter and receiver. The sync-function is provided by the upper beam located on the
opposite side of the connector (see illustration below). During operation this beam must always
be kept free. Otherwise it will result a loss of synchronism between the transmitter and
receiver.
For applications where also the upper beam is needed for measurement synchronization by
wire can be activated (see ’4-1 DIP switch setting’ on page 4-2). In this case transmitter and
receiver must be connected by a sync-wire (see ’2-5 Wiring & output circuit’ on page 2-5).
1st BEAM
X: measuring direction
L: Maximum measurement area
D: System resolution
D
L
x
X: measuring direction
L: Maximum measurement area
D: System resolution
D
L
x

2-3
2-2 Mechanical installation
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
2
Installation
2-2 Mechanical installation
Mounting accessories
The F3EM2 system is mechanically installed by using the T-slots on the two sides or the back-
side of the housing.
Use the movable bolts, washers, growers and nuts to fix the mounting brackets as shown in
the picture
Note: Shipment contains different quantity of brackets, depending on the length of the SLC. Longer SLC
contains a higher number of brackets, following the rule of every 400 mm one bracket.
Additional mounting rigidity
It is recommended that the distance between the mounting brackets is 400 mm or less for
optimum performance of the F3EM2 system.
ID Description
1 movable M6 bolt
2 fixing braket
3 M6 washer
4 M6 Grower
5M6nut

2-4
2-3 Operating environment
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
2
Installation
Mechanical Mounting
Please mount the light curtains in proper alignment as shown in the pictures below by using
the brackets provided with the light curtains.
For serial output models the STROBE input can be used for easier alignment. Please follow
this procedure:
• Turn on the light curtain with the STROBE input connected to +24 VDC
• Move the light curtain to reach the alignment using the led indication on receiver (see led
table 5-1)
• Turn off the light curtain and remove the +24 VDC strobe input connection
If F3EM2 is installed at long distances the laser alignment aid F39-TGR-LLK2-CL provides a
visible laser spot for simplified installation.
If several light curtains are installed close to each other, interference of the light curtains must
be avoided. In this case the assembly should be carried out as follows:
2-3 Operating environment
The area for the installation of the light curtain must be suitable according to the technical
specifications. The temperature of the environment, interference caused by electromagnetic
disturbance and ambient light must be considered. Please contact the manufacturer for any
information not contained in this manual.
2-4 Operating distances
The operating distances, which are given in the technical specifications, are guaranteed values
for reliable operation. Operating F3EM above the specified sensing distance may cause
greater sensitivity to vibration and possible electro magnetic disturbances.
If the F3EM2 is operated in a distance <1m, the sensitivity can be set to NEAR operation by
dip-switch setting at transmitter (see ’4-1 DIP switch setting’ on page 4-2).
This should be considered for following application conditions:
a) Multiple light curtains are installed close to each other (avoiding mutual interference)
b) Detection of small or semi-transparent objects
If none of above mentioned cases applies, FAR setting should be kept in order to provide
maximum detection reliability.
OK NG NG
TX TXRXRX

2-5
2-5 Wiring & output circuit
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
2
Installation
2-5 Wiring & output circuit
The F3EM2 can be operated with analogue output or serial output. Please connect the light
curtain as described below:
Analogue models
For synchronization by wire please connect white wires of transmitter and receiver.
Variable
Power Supply
RECEIVER F3EM2
analogue out only
EMITTER F3EM2
Br Wh Bl Bk
Br Wh Bl Bk
Analogue
Gr
Earth
Ground +24 VDC 0 VDC
Connector PIN assignment - Receiver
Type Internal wiring Pin Colour Signal name
M12 n5 pole
1Brown +Vs
2 White Wire sync
3Blue 0V
4 Black Analogue +
5 Gray Analogue reference
Connector PIN assignment - Transmitter
Type Internal wiring Pin Colour Signal name
M12 n4 pole
1Brown+Vs
2 White Wire sync
3Blue 0V
4 Black Not used

2-6
2-5 Wiring & output circuit
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
2
Installation
Models with serial & analogue output
For synchronization by wire please connect the red wire of receiver with white wire of
transmitter.
Safety Points
We recommend protecting the control unit with an external fuse, whose rated breaking current
must be 1A, even if the appliance is provided with its own internal, self-resetting fuse.
Variable
Power Supply
RECEIVER F3EM2
Earth
Ground +24 VDC 0 VDC Wh Br Gn Ye Gr Pk Bl Rd
Analogue
RSout
EMITTER F3EM2
SYNC.
Br Wh Bl Bk
S1
Connector PIN assignment - receiver
Type Internal wiring Pin Colour Signal name
M12 n8 pole
1White Strobe input/alignment
(normally open)
2Brown +Vs
3 Green RS+ or RS TX
4 Yellow RS- or RS RX
5 Gray Analogue +
6 Pink Analogue reference
7Blue 0V
8 Red Wire synch
Connector PIN assignment - transmitter
Type Internal wiring Pin Colour Signal name
M12 n4 pole
1Brown +Vs
2 White Wire sync
3Blue 0V
4 Black Not used

2-7
2-6 Setting the internal selector-switches
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
2
Installation
2-6 Setting the internal selector-
switches
Precautions for Correct Use
All the operations listed below must only be carried out when the receiver is disconnected to
the power supply.
Settings like operation mode, baud rate and distance can be changed by selector switches.
To access the selector switches unscrew the end cap of the receiver and transmitter unit:
There are two lines of dip switches in each transmitter and receiver. The settings must
be done for both lines. Change the setting of the dip-switch and close the cap again. The light
curtain can now be reconnected to the power supply.
The functions of dip-switches are explained in chapter 4-1 ’DIP switch setting’ on page 4-2.
1 2 34 5 6 7 8
OFF
ON
1 2 34 5 6 7 8
OFF
ON

F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
3
F3EM2 is not a safety device. The usage of F3EM2 as Safety protection
equipment is dangerous and prohibited and expose personnel to serious injury.
3-1 Beam order....................................................................3-2
3-2 Output modes ...............................................................3-3
Operation - General aspects and definitions

3-2
3-1 Beam order
F3EM2 MEASURING LIGHT CURTAINS OPERATION MANUAL
3
Operation - General aspects and
Safety Points
F3EM2 is not a safety device. The usage of F3EM2 as Safety protection equipment is
dangerous and prohibited and expose personnel to serious injury.
The light curtain consists of an array of beams that can be obscured by an object between
transmitter and receiver. The status of each beam (open or blocked) is controlled every scan
cycle and the output reflects the current status accordingly. Thus size and position of objects
can be detected.
Different output modes are available to adapt F3EM2 operation to the given application and to
simplify installation into the machine.
3-1 Beam order
Beams are numbered in the way as shown in the picture; starting from beam 1
opposite to connector to the last beam at the connector side of the light curtain.
Beam status in the protocol is defined as follows:
Beam open = 0
Beam blocked = 1
