Omron INTELLI-SENSE HEM-780 User manual

INSTRUCTION MANUAL
R
AUTOMATIC BLOOD PRESSURE MONITOR
MODEL HEM-780
SYSTOLIC
DIASTOLIC
START
ON/OFF
MEMORY
PULSE
/min.
M
DATE / TIME
SET
Automatic Blood Pressure Monitor
with ComFitTM Cuff
Model HEM-780

32
TABLE OF CONTENTS
Introduction …………………………………………………………… 3
Important Safety Notes ……………………………………………… 4
Know Your Unit ……………………………………………………… 5
Suggestions Before Taking A Measurement ………………………… 6
How To Install The Batteries ………………………………………… 7
How To Set The Date and Time …………………………………… 8-9
How To Apply The Arm Cuff …………………………………… 10-11
How To How To Take A Measurement ………………………… 12-13
How To Use The Memory Function ………………………………… 14
How to Use The AC Adapter ……………………………………… 15
Care And Maintenance …………………………………………… 16
Error Indicators ……………………………………………………… 17
FCC Statement ……………………………………………………… 18
Warranty Information ………………………………………… 19-20
Specifications………………………………………………………… 21
Notes …………………………………………………………… 22-23
INTRODUCTION
Thank you for purchasing the Omron HEM-780 IntelliSenseTM
AutomaticBlood Pressure Monitor with ComFitTM Cuff.
Fill-in for future reference
DATE PURCHASED: ______________
SERIAL NUMBER: ________________
Staple your purchase receipt here.
This completely automatic instrument quickly measures your blood
pressure and pulse rate. The measurement reading is clearly displayed
on a large digital panel.
Your new digital blood pressure monitor uses the oscillometric method
of blood pressure measurement. This means the monitor detects
your blood’s movement through your brachial artery and converts the
movements into a digital reading. An oscillometric monitor does not
need a stethoscope so the monitor is simple to use.
The Omron HEM-780 IntelliSenseTM AutomaticBlood Pressure Monitor
is intended for home use.
SAVE THESE INSTRUCTIONS

54
KNOW YOUR UNIT
IMPORTANT SAFETY NOTES
To assure the correct use of the product basic safety measures should
always be followed including the precautions listed below:
þRead all information in the instruction book and any other literature
included in the box before using the unit.
þContact your physician for specific information about your blood
pressure. Follow the instructions of your healthcare provider.
þOperate the unit only as intended. Do not use for any other purpose.
þThe unit is intended for use in measuring blood pressure and pulse
rate in adult patient population. Do not use on infants.
þDo not use a cellular phone near the unit. It may result in
operational failure.
þChanges or modifications not approved by Omron Healthcare will
void the user warranty. Do not disassemble or attempt to repair the
unit or components.
ON/OFF
START
MEMORY
DATE / TIME
SET
AUTOMATIC BLOOD PRESSURE MONITOR
MODEL HEM-780
SYSTOLIC
DIASTOLIC
PULSE
/min. M
AUTOMATIC BLOOD PRESSURE MONITOR
MODEL HEM-780
SYSTOLIC
DIASTOLIC
PULSE
/min.
MEMORY
DATE / TIME
SET
ON/OFF
START
Systolic Blood
Pressure Display
Heart Symbol
Date/Time
Setting Button
Date/Time Display
Pulse Display
Diastolic Blood
Pressure Display
Air Jack
START
Button
Main Unit:
ON/OFF
Button
MEMORY
Button
AC Adapter Jack
Air Tube
Green Mark
Air Plug (Connects to Air Jack)
Components:
Arm Cuff
AC Adapter

7
6
HOW TO INSTALL THE BATTERIES
1. Slide the battery cover off in the direction
of the arrow.
2. Install 4 “AA” size batteries so the
+ (positive) and – (negative) polarities
match the polarities of the battery
compartment as indicated.
3. Replace the battery cover.
NOTES: If the Low Battery Indicator appears on the
display, replace all four batteries.
Long-life alkaline batteries are recommended.
Remove the batteries if the monitor will
not be used for an extended period of time.
If the batteries are removed for a long period
of time, Date / Time display setting will need
to be reset. Refer to “How to Set the
Date and the Time”.
SUGGESTIONS BEFORE TAKING
A MEASUREMENT
1. Avoid eating, smoking, and exercising for 30 minutes before
taking a measurement. Rest for at least 15 minutes before
taking the measurement.
2. Stress raises blood pressure. Avoid taking measurements
during stressful times.
3. Remove tight-fitting clothing from your left arm.
4. Measurements should be taken in a quiet place.
5. Sit in a chair with your feet flat on the floor. Rest your left arm
on a table so that the cuff is at the same level as your heart.
6. Remain still and do not talk during the measurement.
7. Keep a record of your blood pressure and pulse readings for your
physician. A single measurement does not provide an accurate
indication of your true blood pressure. You need to take and record
several readings over a period of time. Try to measure your blood
pressure at the same time each day for consistency.
8. Wait 2-3 minutes between measurements. The wait time allows the
arteries to return to the condition prior to taking the blood pressure
measurement. You may need to increase the wait time depending on
your individual physical characteristics.

8 9
HOW TO SET THE DATE AND TIME
8. Press the Date / Time Setting button.
The date is set and the hour blinks.
9. In the same manner, set the hour and the minute.
Set the hour and the minute by using the Memory (▼/▲)button
and the Date / Time Setting button following the previously
mentioned procedure.
10. After setting, check the time.
If you set the minute and press the Date /Time Setting
button, the unit starts to display the time.
11. Press the ON / Off button.
The power is turned off.
4. Press the Date / Time Setting button.
The year is set, then the month blinks.
5. Press the Memory (▼/▲) button and set the month
to the current month.
Each time you press the Memory (▲) button, the month advances by one
month. Each time you press the Memory (▼) button, the month moves
back one month.
6. Press the Date / Time Setting button.
The month is set and the day blinks.
7. Press the Memory (▼/▲) button and set the day
to the current date.
Each time you press the Memory (▲) button, the date advances by one
day. Each time you press the Memory (▼) button, the date moves back
one day. If you keep pressing the Memory (▼/▲)button, you can
fast advance the date.
When the unit starts
to display the time,
a colon (:) blinks.
HOW TO SET THE DATE AND TIME
The Blood Pressure Monitor automatically stores up to 90 measurements
values. The memory function stores the date and time with
measurements values.
• Set the monitor to the correct date and time before taking
a measurement for the first time.
• If the correct date and time is not set, the measurement values will
not be stored in the memory.
ON/OFF
START
AUTOMATIC BLOOD PRESSURE MONITOR
MODEL HEM-780
SYSTOLIC
DIASTOLIC
PULSE
/min.
MEMORY
MEMORY
DATE / TIME
SET
DATE / TIME
SET
1. Press the ON / OFF button
The Power is turned on.
When you turn on the power for the first time, all the items
on the display illuminate, and then “AM 12:00” blinks.
2. Press the Date / Time Setting button for more than 1 Second
The year blinks.
3. Press the Memory (▼ /▲) button and set the year
to the current year.
Each time you press the Memory (▲)button, the year advances by one
year. When you press the Memory (▼)button, the year moves
back by one year.
• The range to set the year is 2003 to 2030.
If the year reaches 2030, it will return to 2003
Memory (▼/▲)
Button
Date / Time
Setting Button
ON/OFF
Button
Date / Time Set Buttons

1110
HOW TO APPLY THE ARM CUFF
ON YOUR LEFT ARM
6. Align the Green Marker on the
cuff over the brachial artery on
the inside of the arm.
The cuff tube should run down
the center of the arm even with
the middle finger.
The bottom of the cuff should be
approximately 1/2'' - 1'' above
your elbow.
7. Secure the cuff around your arm
using the cloth velcro.
8. Make sure the cuff is wrapped
firmly in place.
9. Relax your arm and place your
elbow on the table.
Bottom Edge
1/2 -1inch (24.5-12.7 mm)
Green
Marker Cuff
Tube
PULSE
/min.
Air Plug
HOW TO APPLY THE ARM CUFF
ON YOUR LEFT ARM
1. Make sure the air plug is
securely inserted in the main unit.
2. Remove tight-fitting clothing
from your upper arm.
3. Sit in a chair with your feet flat
on the floor and place your arm
on a table so that the cuff will be
at the same level as your heart.
4. Hold the cloth velcro on the cuff
with your other hand.
5. Turn the palm of your hand
upward. Apply the cuff on your
upper arm.
Velcro

1312
HOW TO TAKE A MEASUREMENT
HOW TO TAKE A MEASUREMENT
1. Press the ON/OFF button.
a) All display symbols appear for approximately
one second.
b) When the monitor becomes ready to measure,
the Heart Symbol ( ) appears on the display.
2. Press the START button and remain still.
As the cuff begins to inflate, the monitor automatically determines
your ideal inflation level. Because this monitor detects the pulse
even during inflation, do not move your arm and remain still until
the entire measurement completes.
NOTE:
If you want to stop the inflation or measurement, press the
ON/OFF button. The monitor will stop inflating and start
deflating rapidly, and the monitor will turn off.
3. Inflation stops automatically and measurement is started.
As the cuff slowly deflates,
decreasing numbers appear on the
display and the Heart Symbol ( )
flashes at every heartbeat.
In rare circumstances, a higher
inflation may be necessary.
In those cases, the monitor reinflates the cuff up to 30 mmHg
higher than initial inflation and restarts the measurement.
Inflation Deflation
4. When the measurement is complete, the arm cuff
completely deflates and your blood pressure and
pulse rate are displayed.
NOTE:
The monitor automatically stores blood
pressure and pulse rate into the memory.
5. Press the ON/OFF button to turn the monitor off.
NOTE:
If you forget to turn the monitor off, it will automatically
shut itself off after five minutes.
• If your systolic pressure is known to be more than
220 mmHg, press and hold the START button until
the monitor inflates 30 to 40 mmHg higher than
your suspected systolic pressure.
NOTE: Do not apply more pressure than necessary.
The monitor will not inflate above 280 mmHg.
Instructions for special conditions:
START
Continue to
press button
NOTE: Wait 2-3 minutes before taking another blood pressure
measurement. Waiting between readings allows the
arteries to return to the condition prior to taking
the blood pressure measurement.

1514
HOW TO USE THE AC ADAPTER
Use only the authorized Omron AC Adapter, Model Number
HEM-ADPT1, with this monitor. Use of any other adapter may
cause damage to the monitor and will void the user warranty.
Insert the AC Adapter Plug into the AC Adapter Jack on the back
side of the monitor as illustrated.
Plug the AC Adapter into a 120V AC outlet (50-60 cycles).
To disconnect the AC Adapter remove the AC Adapter from the
electrical outlet first and then remove the AC Adapter Plug
from the monitor.
NOTE:
The monitor is designed not to draw power from the batteries when
the AC Adapter is used.
To store the AC Adapter
Place the AC Adapter in the AC Adapter
storage area in the AC Adapter
storage case.
HOW TO USE THE MEMORY FUNCTION
The Blood Pressure Monitor stores up to 90 measurement values with
the date and time. When 90 sets of measurement values are stored
in the memory, the oldest record is deleted to save the most recent
measurement values.
If the date and time is not set, the measurement values will not be stored
in the memory.
1. Press the ON/OFF Button to turn the power on. Wait
for the Heart ( ) Symbol to appear on the display.
2. Press the MEMORY (▲) Button to display the most
recent measurement values. The time and date alternate
on the display for each measurement.
3. Press the MEMORY (▼) Button again to display previous
measurement values.
4. Press the START/STOP button to turn the power off.
HOW TO DELETE ALL MEASUREMENT VALUES
Press and hold the START Button and MEMORY (▼) Button
simultaneously for more than 2 seconds. All records will be deleted.
NOTE:
You cannot partially delete the stored records.
1
2
AC Adapter Jack
AC Adapter
Plug
To connect the AC Adapter
Press the Start Button and the
Memory ( ) Button simultaneously
for more than 2 seconds.
START
Memory (▼ /▲)

17
ERROR INDICATORS
Error Symbol Correction
Cause
Cuff under-inflated.
Movement during
Measurement
No pulse or blood pressure
reading due to very weak
artery pulse.
Cuff over-inflated (more
than 300 mmHg).
Batteries have run down.
Carefully read and repeat
steps listed under “How
To Take A Measurement.”
Replace all four
“AA” batteries.
Remove arm cuff. Wait 2-3
minutes and take another
measurement. Repeat steps
listed under “How To Take
A Measurement”.
Inflate the cuff
40 mmHg higher
than the previous
inflation value.
This trouble is caused
by abnormal
memory function.
Contact Omron
Customer Service Toll
Free: 1-800-634-4350
An Er mark is displayed.
16
CARE AND MAINTENANCE
To keep your digital blood pressure monitor in the best condition and
protect the unit from damage follow the directions listed below:
Clean the monitor with a soft dry cloth. Do not use any abrasive or
volatile cleaners. Do not attempt to clean the cuff. Never immerse the
monitor or any components in water.
Store the monitor in a safe and dry location. Do not fold the cuff
and tubing tightly. Do not subject the monitor to extreme hot or cold
temperatures, humidity and direct sunlight.
Avoid subjecting the monitor to strong shocks, such as dropping the
unit on the floor.
Remove the batteries if the unit will not be used for three months or
longer. Always replace all the batteries with new ones at the same time.
Use the unit consistent with the instruction provided in this manual.
Use only authorized parts and accessories.

1918
WARRANTY INFORMATION
Your HEM-780 IntelliSenseTM Automatic Blood Pressure Monitor , excluding the monitor cuff,
is warranted to be free from defects in materials and workmanship appearing within 5 years,
when used in accordance with the instructions provided with the monitor. The monitor cuff is
warranted to be free from defects in materials and workmanship appearing within one year,
when the monitor is used in accordance with the instructions provided with the monitor. The
above warranties extend only to the original retail purchaser.
We will, at our option, repair or replace without charge any monitor or monitor cuff covered
by the above warranties. Repair or replacement is our only responsibility and your only
remedy under the above warranties.
To obtain warranty service, ship the monitor and all of the components, together with proof
of purchase and a note explaining the problem with $5.00 for return shipping and insurance to:
Omron Healthcare, Inc.
Attn: Repair Department
300 Lakeview Parkway
Vernon Hills, IL 60061
Be sure to include the model number, your name and your phone number on the enclosed
note and any other correspondence.
ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR
PURPOSE, ARE LIMITED TO THE DURATION OF THE APPLICABLE WRITTEN
WARRANTY ABOVE. Some states do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
OMRON SHALL NOT BE LIABLE FOR LOSS OF USE OR ANY OTHER INCIDENTAL,
CONSEQUENTIAL OR INDIRECT COSTS, EXPENSES OR DAMAGES. Some states do
not allow the exclusion or limitation of incidental or consequential damages, so the above
exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which may
vary from state to state.
FOR CUSTOMER SERVICE
Visit our web site at: http://quickmedical.com/omron/
Call toll free: 1-888-345-4858 (US and Canada)
Limited Warranties
FCC STATEMENT
NOTE:
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only)
This product has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. The product generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If the product does cause harmful interference to radio or television
reception, which can be determined by turning the product on and off, the
user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE
(for Canada only)
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the interference-causing
equipment standard entitled “ Digital Apparatus”, ICES-003 of the Canadian
Department of Communications. Cet appareil numérique respecte les limites
de bruits radioeléctriques applicables aux appareils numériques de Clase B
prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques”,
ICES-003 édictée par le minister des communications.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

2120
SPECIFICATIONS
Model: HEM-780
Display: LCD Digital Display
Measurement Range: Pressure: 0 to 280 mmHg
Pulse: 40-180/min.
Accuracy/Calibration: Pressure: ±3mmHg or 2% of reading
Pulse: ±5% of reading
Inflation: Automatic by electric pump
Deflation: Automatic pressure release valve
Rapid Air Release: Automatic exhaust valve
Pressure Detection: Capacitive pressure sensor
Measurement Method: Oscillometric method
Pulse Wave Detection: Capacitance type pressure sensor
Power Source: 4 "AA" batteries, AC Adapter HEM-ADPT1
Battery Life: Approx. 300 uses when used once
a day for 2 minutes
Operating Temperature/ 50°F to 104°F (10°C to 40°C)
Humidity: 30 to 85% RH maximum
Storage Temperature/ -4°F to 140°F (-20°C to 60°C)
Humidity: 10 to 95% RH maximum
Main Unit Weight: Approximately 14 oz. (400g)
not including batteries
Main Unit Dimensions: Approx. 6 1/2" (l) x 4" (w) x 2 7/8" (h)
(165mm x 102mm x 73mm)
Cuff Size: Approximately 6" (w) (152 mm)
Cuff tube 23 5/8'' (l) (600 mm)
Cuff Circumference: Fits arm circumferences 9'' to 17''
(228 mm to 432 mm)
Contents: Main Unit, ComFitTM Cuff, AC Adapter,
4 “AA” Batteries, Instruction Manual,
and, Storage Case.
UPC Code: 0 73796 78000 5
NOTE: These specifications, to improve performance, are subject to change without notice.
WARRANTY INFORMATION
Limited Warranties (Outside of the USA and Canada)
Your HEM-780 IntelliSenseTM Automatic Blood Pressure Monitor, excluding the monitor
cuff, is warranted to be free from defects in materials and workmanship appearing within
5 years, when used in accordance with the instructions provided with the monitor.
The monitor cuff is warranted to be free from defects in materials and workmanship
appearing within one year, when the monitor is used in accordance with the instructions
provided with the monitor. The above warranties extend only to the original retail purchaser.
Should repair be needed during the warranty period, please contact the authorized
distributor in your country.
The above warranty is complete and exclusive. The warrantor expressly disclaims liability
for incidental, special, or consequential damages of any nature. (Some countries do not
allow the exclusion or limitation of incidental or consequential damages, so the above
warranty may not apply to you.)
Any implied warranties arising by the operation of law shall be limited in duration to the
term of this warranty. (Some countries do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.)
This warranty gives you specific legal rights and you may have other rights
which vary country to country.

2322
NOTES NOTES

Made in China
Manufactured by:
OMRON HEALTHCARE, INC.
300 Lakeview Parkway
Vernon Hills, Illinois 60061
www.omronhealthcare.com
Copyright © 2003 Omron Healthcare, Inc.
HEM-780INST Rev
