Omron SYSMAC CS Series User manual

Cat. No. W372-E1-07
CX-Process Tool
SYSMAC CS/CJ Series
WS02-LCTC1-EV4
(Ver. 4.0)

WS02-LCTC1-EV4
CX-Process Tool (Ver. 4.0)
Operation Manual
Revised August 2004

iv

!
!
!
v
Notice:
OMRON products are manufactured for use according to proper procedures by a qualified operator
and only for the purposes described in this manual.
The following conventions are used to indicate and classify precautions in this manual. Always heed
the information provided with them. Failure to heed precautions can result in injury to people or dam-
age to property.
DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
Caution Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury, or property damage.
OMRON Product References
All OMRON products are capitalized in this manual. The word “Unit” is also capitalized when it refers
to an OMRON product, regardless of whether or not it appears in the proper name of the product.
The abbreviation “Ch,” which appears in some displays and on some OMRON products, often means
“word” and is abbreviated “Wd” in documentation in this sense.
The abbreviation “PLC” means Programmable Controller. “PC” is used, however, in some Program-
ming Device displays to mean Programmable Controller.
Visual Aids
The following headings appear in the left column of the manual to help you locate different types of
information.
Note Indicates information of particular interest for efficient and convenient operation
of the product.
1, 2, 3... 1. Indicates lists of one sort or another, such as procedures, checklists, etc.
Copyrights and Trademarks
Windows is a registered trademark of the Microsoft Corporation.
Other system and product names that appear in this manual are the trademarks or registered trade-
marks of the respective company.
OMRON, 2000
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any
form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permis-
sion of OMRON.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is
constantly striving to improve its high-quality products, the information contained in this manual is subject to change
without notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no
responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the informa-
tion contained in this publication.

vi
About Loop Controllers
Loop Control Types, Functional Elements, and Versions
Loop Controller Types
There are two types of CS/CJ-series Loop Controller: Separate Loop Control-
lers and Loop Controllers Pre-installed in CPU Units
Loop Controller
type
Type name Product name Model PLC series and Unit type
Separate Separate Loop
Controller
Loop Control Unit CS1W-LC001 CS-series CPU Bus Unit Loop
Controller
Co o e
Loop Control
Board
CS1W-LCB01/05 CS-series Inner Board Loop Controller
Pre-installed in
CPU Unit
CPU Unit with
Pre-installed
Loop
Ctll
Process-control
CPU Unit
CS1D-CPUjjPA one-Unit Loop Controller consisting of
an Inner Board pre-installed in a
CS-series CS1D-H CPU Unit
p
Controller Loop-control CPU
Unit
CJ1G-CPUjjPA one-Unit Loop Controller consisting of
an Inner Board pre-installed in a
CJ-series CJ1-H CPU Unit
Loop Controller Functional Elements
•Separate Loop Controllers consist of only the Loop Controller functional ele-
ment (i.e., the Loop Controller element).
•CPU Units with Pre-installed Loop Controller consists of a CPU Unit functional
element (i.e., the CPU Unit element) and the Loop Controller functional ele-
ment (i.e., the Loop Controller element).
Versions
The functional elements (i.e., the CPU Unit element and Loop Controller ele-
ment) have versions.
Model Numbers and Functional Elements
The following table lists the Loop Controller product model numbers, the func-
tional element names for the CPU Unit elements and Loop Controller elements,
and the versions of the functional elements.
Product name Product model
b
Unit version
fth d t
Configuration
number of the product
model
CPU unit element Loop Controller element
mo
d
e
l
(See note.) CPU Unit
model with
same
functionality
Functional
element unit
version
Functional
element
name
Functional
element
Loop Control
Unit
CS1W-LC001 Pre-Ver. 2.0 --- LC001 Ver. 2.5
Loop Control
Bd
CS1W-LCB01 Ver. 2.0 --- LCB01 Ver. 2.0
p
Board CS1W-LCB05 LCB05 Ver. 2.0
Process-control
CPU U i
CS1D-CPU65P --- CS1D-CPU65H Ver. 1.0 or higher LCB05D Ver. 1.0
CPU Unit CS1D-CPU67P CS1D-CPU67H Ver. 1.0 or higher LCB05D Ver. 1.0
Loop-control
CPU U i
CJ1G-CPU42P --- CJ1G-CPU42H Ver. 3.0 or higher LCB01 Ver. 2.0
p
CPU Unit CJ1G-CPU43P CJ1G-CPU43H Ver. 3.0 or higher LCB03 Ver. 2.0
CJ1G-CPU44P CJ1G-CPU44H Ver. 3.0 or higher LCB03 Ver. 2.0
CJ1G-CPU45P CJ1G-CPU45H Ver. 3.0 or higher LCB03 Ver. 2.0
Note Only Separate Loop Controllers have a unit version for the product model. CPU
Units with Pre-installed Loop Controllers do not have a unit version for the prod-
uct model.

vii
Notation in this Manual
This manual uses the following notation.
•“Loop Controller” is used as a generic term to refer to the Loop Controllers in
general.
•“LCBjj” is used to refer to specific Loop Controller functional elements. For
example, the Loop Controller function element in a CS1W-LCB05 Loop Con-
trol Board is the LCB05, so “LCB05” is used to refer to the Loop Controller func-
tional element. The Loop Controller function element in a CJ1G-CPU44P
Loop-control CPU Unit is the LCB03, so “LCB03” is used to refer to the Loop
Controller functional element.
•Model numbers are used to refer to specific Loop Controller models.
In the CX-Process Tool Operation Manual for version 3.2 or lower, functional ele-
ment names (LCBjj) are given as “Loop Control Board.” In the CX-Process
Tool Operation Manual for version 4.0 or higher, simply “LCBjj” is used.

viii
Unit Version Notation on Products
Loop Control Boards
A “unit version” has been introduced to manage CPU Units, Special I/O Units,
and Inner Boards in the CS/CJ Series according to differences in functionality
accompanying upgrades. This system applies to Units manufactured since Oc-
tober 1, 2003. The unit version code is provided on the nameplate of the product
for which unit versions are being managed, as shown below for the Loop Control
Board.
Product nameplate
Unit version
Example for unit version 1.5
Loop Control Board
The CX-Process Tool can be used to confirm the unit versions of Loop Control
Boards in the Monitor Run Status Window. After connecting the CX-Process
Tool online, select Operation – Monitor Run Status from the Execute Menu.
Confirm the unit version in ITEM099 (MPU/FROM version display) under from
the System Common Block (Block Model 000) in the Monitor Run Status Win-
dow.
ITEM Data name Data
099 MPU/FROM version indication V1.50
Functional Element Name and Version Code for Process-control CPU Units and
Loop-control CPU Units
The functional element name and functional element version code for Process-
control CPU Units and Loop-control CPU Units are provided on the nameplate
as shown in the following diagrams.
Version V1.50 and onwards must be indicated.

ix
Process-control CPU Units
Note CPU Unit elements for which no version code is provided are pre-Ver. 2.0 CPU
Units.
Process-control CPU Unit
Product nameplate
Functional element name for
CPU Unit element
Nameplate on
left side of Unit
Functional element name for
Loop Controller element
Functional element version code for
Loop Controller element
Functional element version code for CPU Unit element
CPU Unit elements for which no version code is provided
are pre-Ver. 2.0 CPU Units.
Loop-control CPU Units
Loop-control CPU Unit Unit model number
Product nameplate
Lot No.
Functional element
version code for
CPU unit element
Product model and functional
element name
Recommended location for
attaching version label
Functional element
version code for
Loop Controller
element
Confirming CPU Unit Element Versions with Support Software
CX-Programmer version 4.0 can be used to confirm the unit version using either
of the following two methods.
•Using the PLC Information
•Using the Unit Manufacturing Information (This method can also be used for
Special I/O Units and CPU Bus Units.)
Note CX-Programmer version 3.3 or lower cannot be used to confirm unit versions.
PLC Information
1, 2, 3... 1. If you know the device type and CPU type, select them in the Change PLC
dialog box, go online, and select PLC – Edit – Information from the menus.
If you do not know the device type and CPU type, but are connected directly
to the CPU Unit on a serial line, select PLC – Auto Online to go online, and
then select PLC – Edit – Information from the menus.
2. In either case, the following PLC Information Dialog Box will be displayed.

x
Functional element name
for CPU Unit element
Functional element version
code for CPU Unit element
Use the above display to confirm the unit version of the CPU Unit that is con-
nected online.
Unit Manufacturing Information
1, 2, 3... 1. In the I/O Table Window, right-click and select Unit Manufacturing In-
formation – CPU Unit.
2. The following Unit Manufacturing Information Dialog Box will be displayed.

xi
Functional element version
code for CPU Unit element
Use the above display to confirm the unit version of the CPU Unit connected
online.
Functional Element Versions and Programming Devices
The Programming Device that supports the functional element version code
must be used to enable all the functions in the corresponding functional element.
Note Upgrading versions is not necessary if only the basic functions of the CPU Unit
element are required.
CPU Unit Element
Loop Controller Programming Device
Functional
element name
Functional
element version
CX-Process Tool CX-Programmer
(See note.)
CS1G/H-CPUjjHPre-Ver. 2.0 --- ---
jj
Ver. 2.0 Ver. 4.0 or higher
Ver. 3.0 Ver. 5.0 or higher
CS1D-CPUjjHVer. 1.1 Ver. 4.0 or higher
CJ1G-CPUjjHVer. 3.0 Ver. 5.0 or higher
Loop Controller Element
Loop Controller Programming Device
Functional
element name
Functional
element version
CX-Process Tool CX-Programmer
(See note.)
LCB01 Ver. 1.0 Not specific ---
Ver. 1.5 Ver. 3.2 or higher
Ver. 2.0 Ver. 4.0 or higher
LCB05 Ver. 1.0 Not specific
Ver. 1.5 Ver. 3.2 or higher
Ver. 2.0 Ver. 4.0 or higher
LCB05D Ver. 1.0 Ver. 3.2 or higher
LCB03 Ver. 2.0 Ver. 4.0 or higher

TABLE OF CONTENTS
xiii
PRECAUTIONS xvii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Intended Audience xviii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 General Precautions xviii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Safety Precautions xviii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Application Precautions xx. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1
Introduction 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-1 CX-Process Tool 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 Relationship with CX-Process Monitor 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3 CX-Process Tool Specifications 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4 Version Improvements 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-5 Function Blocks/ITEMs Incompatible with Earlier Versions 23. . . . . . . . . . . . . . . . . . . . . .
1-6 Connecting to the PLC 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-7 Basic Operating Procedures 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-8 Operations 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 2
Preparations to Create Function Blocks 45. . . . . . . . . . . . .
2-1 Installation 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Overview of User Interface 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3
Creating Function Blocks 87. . . . . . . . . . . . . . . . . . . . . . . . .
3-1 Creating Function Block 89. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 Using the CX-Process Monitor 121. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-3 Using the CX-Process Monitor Plus 127. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-4 Preparations for Using SCADA Software 129. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-5 User Link Tables 146. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-6 Creating User-defined Blocks 155. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-7 Creating Step Ladder Program Instructions 162. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-8 Creating Sequence Tables 176. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-9 Displaying Loop Controller Memory Maps 185. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-10 Printing 189. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-11 Setting Options 198. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 4
Online Operation 209. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-1 Overview of Online Functions 210. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-2 Initial Settings for Online Connections 211. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-3 Downloading, Uploading and Comparing Data 223. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-4 Run/Stop Command 236. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-5 Monitor Run Status 237. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-6 Operation Check 241. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-7 Tuning 265.................................................................
4-8 Backup and Recovery 276. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-9 Backup/Recovery of Project Comments, Annotations, Tags, and Connection Data
(CX-Process Tool Ver.4.0 or Higher) 278. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-10 Clear All 281. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-11 Controlling the CPU Unit 281. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-12 Password Protection 282. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 5
Troubleshooting 285. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-1 Troubleshooting 286. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-2 Error Codes 286. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TABLE OF CONTENTS
xiv
Appendix
Sequence Table Design Sheet 289. . . . . . . . . . . . . . . . . . . . . .
Revision History 291. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

xv
About this Manual:
This manual describes the installation and operation of the WS02-LCTC1-EV4 CX-Process Tool software
package and includes the sections described below. The CX-Process Tool is used to create and test func-
tion blocks for the CS1W-LC001 Loop Control Unit, the CS1W-LCB01 and CS1W-LCB05 Loop Control
Boards, the CS1D-CPUjjP Process-control CPU Units, and the CJ1G-CPUjjP Loop-control CPU
Units.
Please read this manual carefully and be sure you understand the information provided before attempting
to install and operate the CX-Process Tool. Please read the following manuals carefully and be sure you
understand the information provided before setting up or using an application for a Loop Control Unit/
Board.
Product Manual name Cat. No. Contents
WS02-LCTC1-EV4
CX-Process Tool
CX-Process Tool
Operation Manual
W372
(this manual)
Installation and operation
procedures for the CX-Process
Tool.
WS02-LCTC1-E
CX-Process Monitor
CX-Process Monitor
Operation Manual
W373 Installation and operation
procedures for the CX-Process
Monitor.
WS02-LCMC1-E
CX-Process Monitor
Plus
CX-Process Monitor
Plus Operation
Manual
W428 Installation and operation
procedures for the CX-Process
Monitor Plus.
CS1W-LC001
Loop Control Unit
Loop Control Unit
Operation Manual
W374 Installation and operation
procedures for the Loop Control
Unit (except for function blocks).
CS1W-LCB01/05
Loop Control Boards,
CS1D-CPUjjP
Process-control CPU
Units, and
CJ1G-CPUjjP
Loop-control CPU
Units
Loop Control Board
Operation Manual
W406 Installation and operation
procedures for the Loop Control
Boards (except for function
blocks).
CS1W-LC001
Loop Control Unit
Loop Control Unit
Function Block
Reference Manual
W375 Detailed information on function
blocks for Loop Control Units.
CS1W-LCB01/05
Loop Control Boards,
CS1D-CPUjjP
Process-control CPU
Units, and
CJ1G-CPUjjP
Loop-control CPU
Units
Loop Control Board
Function Block
Reference Manual
W407 Detailed information on function
blocks for Loop Control Boards
Section 1 introduces the operations of the CX-Process Tool and connections to the PLC.
Section 2 describes installing the CX-Process and provides an overview of the user interface.
Section 3 describes how to create and manipulate function blocks.
Section 4 describes online operations for uploading, downloading, and testing function block data.
Section 5 describes errors that can occur while using the CX-Process Tool.
WARNING Failure to read and understand the information provided in this manual may result in
personal injury or death, damage to the product, or product failure. Please read each
section in its entirety and be sure you understand the information provided in the section
and related sections before attempting any of the procedures or operations given.
!

xvii
PRECAUTIONS
This section provides general precautions for using the CS-series Programmable Controllers (PLCs) and related devices.
The information contained in this section is important for the safe and reliable application of Programmable Control-
lers. You must read this section and understand the information contained before attempting to set up or operate a
PLC system.
1 Intended Audience xviii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 General Precautions xviii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Safety Precautions xviii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Application Precautions xx. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

!
!
4Safety Precautions
xviii
1 Intended Audience
This manual is intended for the following personnel, who must also have knowl-
edge of electrical systems (an electrical engineer or the equivalent) and instru-
mentation systems.
•Personnel in charge of installing FA systems.
•Personnel in charge of designing FA systems.
•Personnel in charge of managing FA systems and facilities.
2 General Precautions
The user must operate the product according to the performance specifications
described in the operation manuals.
Before using the product under conditions which are not described in the manual
or applying the product to nuclear control systems, railroad systems, aviation
systems, vehicles, combustion systems, medical equipment, amusement ma-
chines, safety equipment, petrochemical plants, and other systems, machines,
and equipment that may have a serious influence on lives and property if used
improperly, consult your OMRON representative.
Make sure that the ratings and performance characteristics of the product are
sufficient for the systems, machines, and equipment, and be sure to provide the
systems, machines, and equipment with double safety mechanisms.
This manual provides information for programming and operating the Loop Con-
troller. Be sure to read this manual before attempting to use the Loop Controller
and keep this manual close at hand for reference during operation.
WARNING It is extremely important that a PLC and all PLC Units/Boards be used for the
specified purpose and under the specified conditions, especially in applications
that can directly or indirectly affect human life. You must consult with your
OMRON representative before applying a PLC System to the above-mentioned
applications.
3 Safety Precautions
WARNING Check the following items before starting to run the LCBjj:
•Do not allow the bank of the EM Area with the number specified for allocation to
the HMI (human-machine interface) data to be used by the CPU Unit or other
Units for any other purpose. The block allocated for the HMI is specified in
ITEM 050 (EM Area Bank Allocated for HMI Memory = 0 to 12) of the System
Common block. If areas overlap, the system may operate in an unexpected
fashion, which may result in injury.
•Do not allow the area to which user link table data is written to be used by the
CPU Unit or other Units for any other purpose. If areas overlap, the system
may operate in an unexpected fashion, which may result in injury.
•Analog Input/Output Units used in combination with the LCBjj must be
mounted correctly, and the unit number set on the front panel of the Analog
Input/Output Unit must match the unit number set on the Field Terminal block.
If the unit numbers do not match, input/output (read/write) is performed on the
data of another Special I/O Unit (i.e., the one whose unit number is set on the
Field Terminal block).
•The defaults of the System Common block on the LCBjj must be set correct-
ly.

!
!
!
!
!
3Safety Precautions
xix
WARNING Check the following items before starting Loop Controller operation:
Do not allow the area to which user link table data is written to overlap with any
other area used by the CPU Unit or other Units. If areas overlap, the system may
operate in an unexpected manner, which may result in injury.
When using a user link table to write bit data to I/O memory in the CPU Unit.
Never allow ladder programming or communications processes in the CPU Unit
to write to any bits in the words in which bits are written from a user link table.
Depending on the timing, any attempts to write to these words from ladder pro-
gramming or communications processes may be ignored. Example: If tag A in a
user link table writes to bit 00 of W000 and an OUT instruction in the ladder pro-
gram in the CPU Unit write to bit 01 of W000, the write from the ladder program
may be ignored.
Analog I/O Units used in combination with the Loop Controller must be mounted
correctly.
The unit number set on the front panel of the Analog I/O Unit must be the same
as the unit number set on the Field Terminal Function Block. If the unit numbers
are not the same, I/O (read/write) will be performed on the data for another Spe-
cial I/O Unit (i.e., the one whose unit number is set in the Field Terminal Function
Block).
The initial settings of the System Common Block in the Loop Controller must be
set correctly. In particular, make sure that words in the Data Memory used for the
Node Terminals in the CPU Unit controlling the Loop Controller are not used for
other applications on the PC.
When writing data to the I/O memory in the CPU Unit with function blocks (e.g.,
using Send All Blocks, Expanded DO/AO Terminal to CPU Unit, or DO/AO Ter-
minal to CPU Unit), be sure that the words written to in I/O memory are not being
used for any other purpose. If I/O memory words are allocated to more than one
purpose, the PC system may act unexpectedly and cause injury.
WARNING Always stop the operation of the LCBjj before converting any of the EM Area
to file memory. If any part of the EM Area that is being used by the LCBjj for
the HMI is converted to file memory during Board operation, the system may
operate in an unexpected fashion, which may result in injury.
WARNING Do not perform processing in such a way that the Loop Controller and CPU Unit
write to identical I/O memory words allocated to a contact output or analog
output of an external Unit. If the same words are written to, the externally
connected loads may act unexpectedly and cause injury.
Caution Before transferring function block data (initial setting data or operation data) to
the Loop Controller, confirm that the destination for the data is correct and also
confirm the overall safety of the system (including the Loop Controller). Not do-
ing so may result in unexpected operation.
Caution Before performing Validate Action, be sure to perform Compare on currently
opened function files and the Loop Controller’s function block data. If there are
inconsistencies in the registered function blocks (block address vs. block mod-
el), it will not be possible to perform Validate Action correctly.
Before forcing changes of analog signals or contact signals using Validate Ac-
tion, confirm the safety of the instrumentation system as a whole. Not doing so
may result in unexpected operation.

!
!
!
!
!
!
!
4Application Precautions
xx
Caution When downloading a sequence table for the LCBjj (version 1.5 or higher) that
has been edited online with the CX-Process Tool version 3.2 or higher, confirm
that the system will operate normally with the edited sequence. If the sequence
is not suitable for operation, unexpected operation may result.
Caution Confirm in advance the conditions at any node for which the sequence table is
being edited over a Controller Link or Ethernet network. Not doing so may result
in unexpected operation.
4 Application Precautions
Observe the following precautions when using CX-Process Tool and Loop Con-
troller.
Caution If the power supply is turned OFF while function block data is being backed up
from RAM to flash memory, the backup will not be completed normally. If the
power supply is turned back ON within 24 hours, however, the super capacitor
will have held the RAM data. The backup operation will restart when power is
turned ON and operation will start when the backup has been completed. If the
power supply is turned OFF for more than 24 hours, however, RAM data will be
lost and operation will be started with the data that was previously saved to flash
memory. If this happens, the Cold Start Auto-execution Flag (A35807) will turn
ON to show that the previous data has been used. Use this bit in programming to
take whatever steps are necessary, such as downloading the most recent func-
tion block data. (For LCBjj only)
Caution Loop Control Unit data is monitored and operated using CX-Process Monitor
based on the monitor tag files created using CX-Process Tool. CX-Process Tool
can be used on Microsoft Windows 95, 98, Me, 2000, XP, or NT (Service Pack 4
or later). When creating monitor tag files using CX-Process Tool, CX-Process
Monitor must be installed on the same computer.
Caution Before using function block data in actual operation, confirm operation by moni-
toring run status (to check the load rate; select Execute/Operation/Monitor
Run Status) and validating actions (select Validate Action/Start) with CX-Pro-
cess Tool. In particular, be sure to confirm that the load rate will be less than 60%.
(For details on the load rate, refer to the Operation Manual for the Loop Control-
ler.)
Caution When uploading the Loop Controller’s function block data, observe the following
precautions.
When performing Upload New for Loop Control Units of version 1.5 or earlier,
data on the Edit Block Diagram Screen (function block information) will be lost,
and the block diagram showing the connections between function blocks will not
be displayed.
When performing Upload Previous, if the data in the source file currently
opened using the CX-Process Tool and the Loop Controller’s function block data
does not match the registered function blocks or the data on the Edit Block Dia-
gram Screen, the data currently opened may change to illegal data.
Caution The Loop Controller can read and write I/O memory in the CPU Unit using the
Field Terminal Function Blocks or CPU Terminal Blocks independent of the user
program (Step Ladder Program) in the CPU Unit. Do not write to the same I/O
memory words from both the Loop Controller and the CPU Unit.

!
!
!
!
!
!
!
!
4Application Precautions
xxi
Caution To hold an analog output or contact output at a specific value (for example, the
maximum value or minimum value) when the Loop Controller stops running,
create a Step Ladder Program in the CPU Unit so that the corresponding output
bit allocated to Analog Output Unit or Contact Output Unit is set to the desired
value using an NC condition of the Loop Controller Running Flag (bit 00 in allo-
cated CIO word “n”) as an input condition.
Caution If a fatal error occurs in the CPU Unit (including fatal errors created by execution
of a FALS instruction), the Loop Controller will also stop running. To hold analog
outputs to the previous values before the stop occurred, and to set analog out-
puts to either the minimum value or maximum value, use the output hold function
of the Analog Output Unit or Analog I/O Unit.
Caution Before turning ON the power to the PLC, make sure that the facilities are safe.
The analog output values and contact outputs from the Loop Controller are up-
dated when the power to the PLC is turned ON regardless of the operating mode
of the CPU Unit (including in the PROGRAM mode). (Internally, the analog out-
put values and contact outputs are sent from the CPU Unit to Basic I/O Units and
Analog Output Units.)
Caution Fail-safe measures must be taken by the customer to ensure safety in the event
of incorrect, missing, or abnormal signals caused by broken signal lines, mo-
mentary power interruptions, or other causes.
Caution Confirm that no adverse effect will occur in the system before attempting any of
the following:
•Changing the operating mode of the PLC
•Force-setting/force-resetting any bit in memory
•Changing the present value or any set value in memory
Caution Be sure that all mounting screws, terminal screws, and cable connector screws
are tightened to the torque specified in the user manuals. Incorrect tightening
torque may result in malfunction.
Caution In the event of system or power failure, CX-Process function files (extension
“.ist”) may not be saved. It is recommended that function files are saved regular-
ly.
Caution Do not connect pin 6 (+5 V power supply line) of the RS-232C port on the CPU
Unit to any external device except the CJ1W-CIF11 RS-422A Adapter or NT-
AL001 RS-232C/RS-422A Adapter. Doing so may damage the external device
or CPU Unit.

1
SECTION 1
Introduction
This section introduces the operations of the CX-Process Tool and connections to the PLC.
1-1 CX-Process Tool 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-1-1 Overview 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-1-2 Function Block Navigation and Multi-node Folder 3. . . . . . . . . . . . . . . . . . . . . . . .
1-1-3 Files Created with CX-Process Tool 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-1-4 Relationships between Tag Files 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-1-5 Operating Conditions of CX-Process Tool 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 Relationship with CX-Process Monitor 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2-1 Overview of the CX-Process Monitor and CX-Process Monitor Plus 9. . . . . . . . .
1-2-2 Settings Required on the CX-Process Tool 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3 CX-Process Tool Specifications 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4 Version Improvements 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4-1 Version 1.20 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4-2 Version 1.50 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4-3 Version 2.00 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4-4 Version 2.50 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4-5 Version 3.00 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4-6 Version 3.1 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4-7 Version 3.2 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4-8 Version 4.0 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-5 Function Blocks/ITEMs Incompatible with Earlier Versions 23. . . . . . . . . . . . . . . . . . . . . . .
1-5-1 Incompatibility with Versions Earlier than Version 1.20 23. . . . . . . . . . . . . . . . . . . .
1-5-2 Incompatibility with Versions Earlier than Version 1.50 23. . . . . . . . . . . . . . . . . . . .
1-5-3 Incompatibility with Versions Earlier than Version 2.00 24. . . . . . . . . . . . . . . . . . . .
1-5-4 Incompatibility with Versions Earlier than Version 2.50 26. . . . . . . . . . . . . . . . . . . .
1-5-5 Incompatibility with Versions Earlier than Version 3.2 28. . . . . . . . . . . . . . . . . . . . .
1-5-6 Incompatibility with Versions Earlier than Version 4.0 28. . . . . . . . . . . . . . . . . . . . .
1-6 Connecting to the PLC 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-6-1 Features of FinsGateway and CX-Server 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-6-2 Selecting the Communications Driver 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-6-3 Using FinsGateway 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-6-4 Connecting Cables 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-7 Basic Operating Procedures 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-8 Operations 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-8-1 Creating Function Blocks 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-8-2 Online Operations 42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1SectionCX-Process Tool
2
1-1 CX-Process Tool
1-1-1 Overview
The CX-Process Tool supports the following functions for Loop Controllers. The
CX-Process Tool runs on Windows NT 4.0 (with Service Pack 4 or higher), Win-
dows 95, Windows 98, Windows ME, Windows 2000, or Windows XP.
The CX-Process Tool (version 2.50 or higher) can communicate with a PLC
equipped with a Loop Controller using the CX-Server communications driver as
well as the FinsGateway communications driver.
•Creating function blocks, including the following functions
•Setting the Step Ladder Program Block (block 000), including the follow-
ing: System common operation cycle, Loop Control Unit number (Loop
Control Unit only), start mode at power ON, first address of data memory of
node terminal (Loop Control Unit only)
•Registering function blocks (allocating block addresses)
•Connecting function blocks with analog and accumulator signals
•Setting ITEMs in function blocks
•Editing sequence tables (Block 302) and the Step Ladder Program Block
(Block 302) (See note.)
Note Editing sequence tables is supported only by the CS1W-LCB05 Loop
Control Board (00-LCB05) and CS1D-LCB05D Loop Control Board
(00-LCB05D).
•Settings tags for CX-Process Monitor (Loop Control Unit only) or CX-Pro-
cess Monitor Plus software or setting CSV tags for SCADA software (Tag
Names and Analog Signals) and creating monitor tag files (Loop Control
Unit only, CX-Process Monitor must be already installed), or CSV tag files.
•Downloading function block data to Loop Controllers
•Uploading data from Loop Controllers
•Comparing function block data with data in a Loop Controller or Function Block
File
•Sending Run/Stop Commands to Loop Controller
•Monitoring status (including System Common Block Settings, Load Rate per
Operation Cycle Group, and Execution Errors)
•Monitoring actions of Loop Controllers (including operation checks on function
block diagrams and ladder diagrams)
•Tuning parameters such as PID constants in function blocks (Control Blocks)
•Backing up function block data from the Loop Controller’s RAM to flash
memory and restoring that function block data from flash memory back to RAM
•Initializing function block data in Loop Controllers
Note To create monitor tag files using the CX-Process Tool with the CX-Process Moni-
tor or CX-Process Monitor Plus software, both the CX-Process Tool, and CX-
Process Monitor or CX-Process Monitor Plus, must be installed on the same
computer.
