Omron S8VK-X Use and care manual

T213-E1-01
Switch-mode Power Supplies
Communications Manual
S8VK-X
IP Address Setting
and Resetting
Product
Overview
Monitoring and
Setting with the
Modbus TCP
Monitoring and
Setting with the
EtherNet/IP
1
2
3
4

Copyrights
Microsoft product screen shots reprinted with permission from Microsoft Corporation.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior
written permission of OMRON.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because
OMRON is constantly striving to improve its high-quality products, the information contained in this manual is
subject to change without notice. Every precaution has been taken in the preparation of this manual. Neverthe-
less, OMRON assumes no responsibility for errors or omissions. Neither is any liability assumed for damages
resulting from the use of the information contained in this publication.
NOTE
• Microsoft, Windows is either registered trademarks or trademarks of Microsoft Corporation in the United States
and other countries.
• ODVA, CIP, CompoNet, DeviceNet, and EtherNet/IP are trademarks of ODVA.
• Modbus is a registered trademark of Schneider Electric.
Other company names and product names in this document are the trademarks or registered trademarks of their
respective companies.
Trademarks

1
Preface
Switch-mode Power Supplies Communications Manual (T213)
Preface
Thank you for purchasing S8VK-X Switch-mode Power Supplies.
This communications manual describes how to use the communications functions of the S8VK-X. Read
this manual thoroughly and be sure you understand it before attempting to use the S8VK-X correctly
according to the information provided. Keep this manual in a safe place for easy reference.
PDF version of this manual can be downloaded from the OMRON website.
(http://www.omron.co.jp)
For details on how to use functions other than the S8VK-X communications function, refer to the data
sheet of the S8VK-X and the instruction manual (attached to the product).

Terms and Conditions Agreement
2Switch-mode Power Supplies Communications Manual (T213)
Terms and Conditions Agreement
Exclusive Warranty
Omron’s exclusive warranty is that the Products will be free from defects in materials and workman-
ship for a period of twelve months from the date of sale by Omron (or such other period expressed in
writing by Omron). Omron disclaims all other warranties, express or implied.
Limitations
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT
NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OF
THE PRODUCTS. BUYER ACKNOWLEDGES THAT IT ALONE HAS DETERMINED THAT THE
PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE.
Omron further disclaims all warranties and responsibility of any type for claims or expenses based
on infringement by the Products or otherwise of any intellectual property right.
Buyer Remedy
Omron’s sole obligation hereunder shall be, at Omron’s election, to (i) replace (in the form originally
shipped with Buyer responsible for labor charges for removal or replacement thereof) the non-com-
plying Product, (ii) repair the non-complying Product, or (iii) repay or credit Buyer an amount equal
to the purchase price of the non-complying Product; provided that in no event shall Omron be
responsible for warranty, repair, indemnity or any other claims or expenses regarding the Products
unless Omron’s analysis confirms that the Products were properly handled, stored, installed and
maintained and not subject to contamination, abuse, misuse or inappropriate modification. Return of
any Products by Buyer must be approved in writing by Omron before shipment. Omron Companies
shall not be liable for the suitability or unsuitability or the results from the use of Products in combi-
nation with any electrical or electronic components, circuits, system assemblies or any other materi-
als or substances or environments. Any advice, recommendations or information given orally or in
writing, are not to be construed as an amendment or addition to the above warranty.
See http://www.omron.com/global/ or contact your Omron representative for published information.
OMRON COMPANIES SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL, OR CON-
SEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY
WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED IN CONTRACT,
WARRANTY, NEGLIGENCE OR STRICT LIABILITY.
Further, in no event shall liability of Omron Companies exceed the individual price of the Product on
which liability is asserted.
Warranty, Limitations of Liability
Warranties
Limitation on Liability; Etc

3
Terms and Conditions Agreement
Switch-mode Power Supplies Communications Manual (T213)
Omron Companies shall not be responsible for conformity with any standards, codes or regulations
which apply to the combination of the Product in the Buyer’s application or use of the Product. At
Buyer’s request, Omron will provide applicable third party certification documents identifying ratings
and limitations of use which apply to the Product. This information by itself is not sufficient for a com-
plete determination of the suitability of the Product in combination with the end product, machine, sys-
tem, or other application or use. Buyer shall be solely responsible for determining appropriateness of
the particular Product with respect to Buyer’s application, product or system. Buyer shall take applica-
tion responsibility in all cases.
NEVER USE THE PRODUCT FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO
ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT(S) IS PROPERLY RATED AND
INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
Omron Companies shall not be responsible for the user’s programming of a programmable Product, or
any consequence thereof.
Data presented in Omron Company websites, catalogs and other materials is provided as a guide for
the user in determining suitability and does not constitute a warranty. It may represent the result of
Omron’s test conditions, and the user must correlate it to actual application requirements. Actual perfor-
mance is subject to the Omron’s Warranty and Limitations of Liability.
Product specifications and accessories may be changed at any time based on improvements and other
reasons. It is our practice to change part numbers when published ratings or features are changed, or
when significant construction changes are made. However, some specifications of the Product may be
changed without any notice. When in doubt, special part numbers may be assigned to fix or establish
key specifications for your application. Please consult with your Omron’s representative at any time to
confirm actual specifications of purchased Product.
Information presented by Omron Companies has been checked and is believed to be accurate; how-
ever, no responsibility is assumed for clerical, typographical or proofreading errors or omissions.
Application Considerations
Suitability of Use
Programmable Products
Disclaimers
Performance Data
Change in Specifications
Errors and Omissions

Precautions for Correct Use
4Switch-mode Power Supplies Communications Manual (T213)
Precautions for Correct Use
Be sure to observe the following precautions.
Communications
• Communications setup is necessary for installation and replacement. Make communication set-
tings according to this manual.
• Follow the instructions in this manual for connection method and cables to be used with the Ether-
Net/IP or the Modbus TCP. Otherwise, communication failure may occur.
• Do not exceed the communications distance that is given in the specifications.
• If EtherNet/IP tag data links (cyclic communications) are used with a repeating hub, the communi-
cations load on the network will increase. This will increase collisions and may prevent stable
communications.
Communications Cables
• Do not pull on the communications cables or bend the cables beyond their natural limit. Do not
place heavy objects on top of the communications cables or other wiring lines. Doing so may
cause the wire to break.
• To avoid inductive noise, keep the communications cables away from power cables carry high
voltages or large currents. Also, do not wire power lines together with or parallel to product wiring.
• If no communication cable is connected, attach a dust cover.
• Depending on the ambient temperature or the load ratio, the product itself may have a high tem-
perature. In that case, do not insert or remove the communications cable. Otherwise, minor burns
may occasionally occur.

5
Revision History
Switch-mode Power Supplies Communications Manual (T213)
Revision History
A manual revision code appears as a suffix to the catalog number on the front cover of the manual.
Revision code Date Revised content
01 December 2017 Original production
T213-E1-01
Revision code

Revision History
6Switch-mode Power Supplies Communications Manual (T213)

1
2
3
4
4
Product Overview
IP Address Setting and Resetting
Monitoring and Setting with the Modbus TCP
Monitoring and Setting with the EtherNet/IP
3
2
1
7
Sections in this Manual
Switch-mode Power Supplies Communications Manual (T213)
Sections in this Manual

CONTENTS
8Switch-mode Power Supplies Communications Manual (T213)
CONTENTS
Preface ......................................................................................................................1
Terms and Conditions Agreement ..........................................................................2
Warranty, Limitations of Liability .................................................................................................................. 2
Application Considerations .......................................................................................................................... 3
Disclaimers .................................................................................................................................................. 3
Precautions for Correct Use.................................................................................... 4
Revision History .......................................................................................................5
Sections in this Manual ...........................................................................................7
CONTENTS................................................................................................................8
Section 1 Product Overview
1-1 List of Models ........................................................................................................................ 1-2
1-2 Nomenclature and Functions ............................................................................................... 1-3
1-3 Communications Specifications .......................................................................................... 1-5
1-4 Communications Methods and Types of Data To Be Communicated ............................. 1-6
1-5 Measurement and Calculation Data ..................................................................................... 1-7
1-6 Self-Diagnosis Information...................................................................................................1-8
1-7 Product Information and Communications Setting Data................................................... 1-9
1-8 Communications Wiring ..................................................................................................... 1-10
1-9 Procedure............................................................................................................................. 1-12
Section 2 IP Address Setting and Resetting
2-1 IP Address Settings............................................................................................................... 2-2
2-2 Communications Reset Function ........................................................................................ 2-5
Section 3 Monitoring and Setting with the EtherNet/IP
3-1 Overview................................................................................................................................. 3-2
3-1-1 What is Monitoring Using EtherNet/IP?....................................................................................... 3-2
3-1-2 Tag Data Link .............................................................................................................................. 3-3
3-1-3 CIP Message Communications................................................................................................... 3-5
3-2 List of Monitoring Contents Using the Tag Data Link Communications .......................... 3-6
3-2-1 Connection setting ...................................................................................................................... 3-6
3-2-2 Data to be Tag Data Link Target in the S8VK-X .......................................................................... 3-6
3-3 List of Monitoring and Setting Contents Using the CIP Message Communications ...... 3-8
3-3-1 Services Supported by Objects in the S8VK-X ........................................................................... 3-8
3-3-2 Monitor Object of the S8VK-X (Class ID: 372 hex) ..................................................................... 3-8
3-3-3 Setting Object of the S8VK-X (Class ID: 373 hex) .................................................................... 3-10
3-3-4 Identity Object (Class ID: 01 hex) ............................................................................................. 3-11
3-3-5 TCP/IP Interface Object (Class ID: F5 hex) ..............................................................................3-13
3-3-6 Example of the CIP Message Communications Instruction ...................................................... 3-15

9
CONTENTS
Switch-mode Power Supplies Communications Manual (T213)
Section 4 Monitoring and Setting with the Modbus TCP
4-1 Overview................................................................................................................................. 4-2
4-2 Function Codes ..................................................................................................................... 4-3
4-2-1 Function Code List...................................................................................................................... 4-3
4-2-2 03 hex: Reading of multiple registers ......................................................................................... 4-3
4-2-3 06 hex: Operation command (Resets the peak hold current) ..................................................... 4-5
4-2-4 10 hex: Writing of multiple registers............................................................................................ 4-6
4-2-5 Exception Code List.................................................................................................................... 4-7
4-3 Register Address Lists ......................................................................................................... 4-8
4-3-1 Measurement/calculation data and Self-diagnostic information ................................................. 4-8
4-3-2 Product Information and Communications Setting Data............................................................. 4-9

CONTENTS
10 Switch-mode Power Supplies Communications Manual (T213)

1 - 1
1
Switch-mode Power Supplies Communications Manual (T213)
This section describes the overview of the S8VK-X.
1-1 List of Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1-2 Nomenclature and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1-3 Communications Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1-4 Communications Methods and Types of Data To Be Communicated . . . . 1-6
1-5 Measurement and Calculation Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
1-6 Self-Diagnosis Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
1-7 Product Information and Communications Setting Data . . . . . . . . . . . . . . 1-9
1-8 Communications Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
1-9 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Product Overview

1 Product Overview
1 - 2 Switch-mode Power Supplies Communications Manual (T213)
1-1 List of Models
This section shows the model list of the S8VK-X.
The S8VK-X has a type with display monitor and a type without display monitor.
With Indication Monitor
Without Indication Monitor
Power
rating Rated input voltage Rated output voltage (DC)
Rated output
current
Maximum
boost current Model number
90 W 100 to 240 VAC
(allowable range: 85
to 264 VAC, 90 to 350
VDC)
24 V 3.75 A --- S8VK-X09024A-EIP
120 W 24 V 5 A 6 A S8VK-X12024A-EIP
240 W 24 V 10 A 15 A S8VK-X24024A-EIP
480 W 24 V 20 A 30 A S8VK-X48024A-EIP
Power
rating Rated input voltage Rated output voltage (DC)
Rated output
current
Maximum
boost current Model number
30 W 100 to 240 VAC
(allowable range: 85
to 264 VAC, 90 to 350
VDC)
5 V 5 A *1
*1. Output power is 25 W at rated output current.
6 A S8VK-X03005-EIP
60 W 12 V 4.5 A *2
*2. Output power is 54 W at rated output current.
5.4 A S8VK-X06012-EIP
24 V 2.5 A 3 A S8VK-X06024-EIP
90 W 24 V 3.75 A --- S8VK-X09024-EIP
120 W 24 V 5 A 6 A S8VK-X12024-EIP
240 W 24 V 10 A 15 A S8VK-X24024-EIP
480 W 24 V 20 A 30 A S8VK-X48024-EIP

1 - 3
1 Product Overview
Switch-mode Power Supplies Communications Manual (T213)
1-2 Nomenclature and Func-
tions
1
1-2 Nomenclature and Functions
This section describes the nomenclature and functions of the S8VK-X.
In the following, the position of each part is indicated by number, and its contents are shown in a list.
Nomenclature and Functions
No. Terminal
name Name Function
(1) L1 Input terminals Connect the input lines to these terminals. *1
(2) L2
(3) N1
(4) N2
(5) PE Protective Earth terminal (PE) Connect the ground line to this terminal. *2
(6) +V1 DC Output terminals Connect the load lines to these terminals.
(7) +V2
(8) -V1
(9) -V2
(10) -V3
(11) --- Output indicator (DC ON: Green) The green indicator indicates when a DC voltage is
being output.
(12) --- Alarm indicator (ALM: Red) Lights up in red when a Power Supply abnormality
occurs. Refer to 1-6 Self-Diagnosis Information on
page 1-8 for details.
(13) --- Output voltage adjuster (V. ADJ) Use to adjust the output voltage.
(14) --- Main display (white) Displays measured values.
(11)
(12)
(13)
(17)
(19)
(16)
(18)
(6)(7)(8)(9)(10)
(1)(2)(3)(4)(5)
Without Indication MonitorWith Indication Monitor
(11)
(12)
(13)
(17)
(19)
(16)
(18)
(14)
(15)
(6)(7)(8)(9)(10)
(1)(2)(3)(4)(5)
* The above figure shows S8VK-X48024A-EIP. * The above figure shows S8VK-X48024-EIP.

1 Product Overview
1 - 4 Switch-mode Power Supplies Communications Manual (T213)
(15) --- Operation indicator
(white)
V Lights up when the output voltage is indicated.
--- A Lights up during indication of output current.
--- Apk Lights up during indication of peak hold current.
--- Yrs Lights up during replacement time calculation year
indication.
--- % Lights up during years until replacement time indica-
tion.
--- kh Lights up during percentage until replacement time
indication.
(16) --- Indication switching/reset key
(types with indication monitor)
Reset key (types without indica-
tion monitor)
Used to change the indicated parameter.
Used to reset the peak hold current or communication
settings.
For reset methods, refer to 2-2 Communications Reset
Function on page 2-5.
(17) --- EtherNet/IP port Connects to EtherNet cables.
(18) --- Module status indicator (MS) Refer to Module Status and Network Status Indicators
on page 1-4 for details.
(19) --- Network status indicator (NS)
*1. The fuse is located on the (L) side. For a DC input, connect the positive voltage to the L terminal.
*2. This is the protective
Module Status and Network Status Indicators
Name Color Status Operating status
Module status Indicator (MS) Green Lit Normal
Flashing ---
Red Lit RAM abnormality, EEPROM abnormality
Flashing Voltage measurement abnormality, current mea-
surement abnormality
--- Not lit No power supply
Green/Red Flashing When power is turned ON
Network status Indicator
(NS)
Green Lit Connection established
Flashing Connection not established
Red Lit Multiple IP addresses
Flashing Connection timeout
BOOTP server connection abnormality
--- Not lit No power supply
Green/Red Flashing When power is turned ON
No. Terminal
name Name Function

1 - 5
1 Product Overview
Switch-mode Power Supplies Communications Manual (T213)
1-3 Communications Specifica-
tions
1
1-3 Communications Specifications
This section shows the communications specifications of the S8VK-X.
Item Specification
Communications protocol EtherNet/IP, Modbus TCP
Physical layer 100 BASE-TX
Media access method CSMA/CD
Modulation system Baseband
Topology Star configuration
Transmission speed 100 Mbps
Transmission medium Twisted pair cable (with shield: STP): Category 5,
5e or above
Maximum transmission distance
(distance between hub and node)
100 m
Tag data Link
Class1 Possible
Connection source 1
No. of connected nodes 1
No. of tag sets 1
Packet interval (RPI) 100 to 10,000 ms
Time-out value Multiple of RPI
Connection type Point To Point Connection (fixed)
Explicit Message
Class3 Possible
UCMM Possible
Connection source 2 (Class3 server)
No. of clients for which simultane-
ous UCMM communication is pos-
sible
2
Modbus TCP Number of clients that can be con-
nected simultaneously
2
Factory default val-
ues
IP address 192.168.250.20
Subnet mask 255.255.255.0
Default gateway 0.0.0.0
IP address setting method Static IP address

1 Product Overview
1 - 6 Switch-mode Power Supplies Communications Manual (T213)
1-4 Communications Methods and
Types of Data To Be Communicated
This section shows the communications methods of the S8VK-X and the types of data to be communi-
cated.
You can read or write the communications target data of the S8VK-X using one of the following meth-
ods.
For details on the communications methods and target data, refer to the sections shown in the table
below.
Communica-
tions protocol
Communica-
tions methods
Types of data to be communicated
Reference
• Measurement and
calculation data *1
• Self-diagnosis Infor-
mation *2
*1. Refer to 1-5 Measurement and Calculation Data on page 1-7 below.
*2. Refer to 1-6 Self-Diagnosis Information on page 1-8 below.
• Product information
and communica-
tions setting data *3
*3. Refer to 1-7 Product Information and Communications Setting Data on page 1-9 below.
EtherNet/IP Tag data links Can read Can not write 3-2 List of Monitor-
ing Contents Using
the Tag Data Link
Communications on
page 3-6
CIP message
communications
Can write and can read 3-3 List of Monitor-
ing and Setting Con-
tents Using the CIP
Message Communi-
cations on page 3-8
Modbus TCP Modbus TCP
message com-
munications
Section 4 Monitoring
and Setting with the
Modbus TCP

1 - 7
1 Product Overview
Switch-mode Power Supplies Communications Manual (T213)
1-5 Measurement and Calcula-
tion Data
1
1-5 Measurement and Calculation Data
This section shows measurement and calculation data that can be read using communications with the
S8VK-X.
The following measurement and calculation data can be read using the EtherNet/IP or the Modbus
TCP.
Measurement and
calculation data
Measurement EtherNet/IP Modbus
TCP
Resolution Data update
cycle Details Tag data link
CIP
message
Output voltage mea-
sured
0.1 V 5 ms Measurement accuracy: ±2%
(percentage of output voltage
value) ±1 digit
Read Read Read
Output current mea-
sured
0.1 A 5 ms Measurement accuracy: ±5%
(percentage of rated output
current) ±1 digit
Read Read Read
Peak hold current
measured *1
*1. Peak hold current measured can be reset. It can be reset by operating the "Peak hold current reset" bit.
0.1 A 5 ms Measurement accuracy: ±5%
(percentage of rated output
current) ±1 digit
Read Read Read
Years until replace-
ment
0.1 years 1 min Range: 0.0 to 15.0 years Read Read Read
FUL *2
*2. It can be checked with "S8VK-X status".
--- 1 min 1: FUL ( displayed at the
main display.)
0: other than FUL
Read Read Read
HLF *2 --- 1 min 1: HLF ( displayed at the
main display.)
0: other than FUL
Read Read Read
Percentage until
replacement
0.1% 1 min Range: 0.0 to 100% Read Read Read
Total run time 1 h 1 min Range: 0 to 262,800 h Read Read Read
Continuous run time 1 min 1 min Range: 0 to 15,768,000 min Read Read Read

1 Product Overview
1 - 8 Switch-mode Power Supplies Communications Manual (T213)
1-6 Self-Diagnosis Information
This section shows status information that can be confirmed by the self-diagnosis of the S8VK-X.
The following self-diagnosis status can be checked with the "S8VK-X status" using the EtherNet/IP or
the Modbus TCP.
Note 1. The cause of the " " and " " display may be the noise from outside.
2. When " " is displayed, the display can not be switched.
3. The causes of " " and " " display may include use in conditions exceeding the derating curve,
ventilation error, or an error in the installation direction.
4. When you press the Indication switching/reset key with " " or " " displayed, the display will
return to the normal display.
5. When " " is displayed, the display of the number of years and percentages until the replacement
time will be years and %, respectively.
Status name Details Restoration
method
Main
display
Alarm
indicator
EtherNet/IP Modbus
TCP
Tag data
link
CIP
message
Measure-
ment
abnor-
mality
Current
measure-
ment error
Output voltage,
output current, etc.,
cannot be mea-
sured normally due
to noise.
Automatic resto-
ration
Lit Read Read Read
Voltage
measure-
ment error
Read Read Read
Overheating alarm Overheated status
has continued for 1
to 180 minutes.
Automatic resto-
ration
Lit Read Read Read
Product overheat
abnormality
Overheated status
has continued for
more than 180
minutes.
Replace the
S8VK-X, as inter-
nal parts may be
deteriorated.
Lit Read Read Read
Memory error An error has
occurred in the
internal memory
and data damage
has occurred.
Turn the AC input
OFF then ON
again.
If the S8VK-X is
not reset, contact
the dealer.
Lit Read Read Read
(Flashing)
(Flashing)
