Enclosed Switch D4C F-9
Limit
Switches
Enclosed Switch
D4C
Sealed, Compact, and Slim-bodied Switch
Offers Choice of Many Actuators
• Liquid- and dust-resistance conforms to IEC IP67 standard.
• Triple-sealed construction:
Plunger section sealed via nitrile rubber packing seal and dia-
phragm; switch section sealed via nitrile rubber cap; cable en-
trance sealed via encapsulating material.
• Standard cable (S-FLEX VCTF) in 2-, 3-, or 5-meter lengths of-
fers high flexibility with outstanding oil and extreme temperature
resistance.
• Low temperature models are available.
Model Number Structure
■Model Number Legend
Standard Models
1. Rated Current
1: 5 A at 250 VAC, 4 A at 30 VDC
2: 5 A at 125 VAC (with LED indicator)
3: 4 A 30 VDC (with LED indicator)
4: 0.1 A at 125 VAC, 0.1 A at 30 VDC
5: 0.1 A at 125 VAC (with LED indicator)
6: 0.1 A at 30 VDC (with LED indicator)
2. Cable Specifications
2: VCTF oil-resistant cable (3 m)
3: VCTF oil-resistant cable (5 m)
4: VCTF (3 m)
5: VCTF (5 m)
6: SJT(O) (3 m)
7: SJT(O) (5 m)
8: VCTF oil-resistant cable (2 m)
9: VCTF (2 m)
3. Actuator
01: Pin plunger
02: Roller plunger
03: Crossroller plunger
10: Bevel plunger
20: Roller lever
24: Roller lever (high-sensitivity model)
31: Sealed pin plunger
32: Sealed roller plunger
33: Sealed crossroller
41: Panel mount pin plunger
42: Panel mount roller plunger
43: Panel mount crossroller plunger
50: Plastic rod
60: Center roller lever plunger
Note 1: Some combinations of the above may not be supported.
2: With standard models, the operation indicator turns OFF
when the switch operates. If models with operation indicators
that turn ON when the switch operates are required, add "-B”
to the end of the model number.
1 2 3
D4C-@@@

F-10 Enclosed Switch D4C
Pre-wired Models (Use VCTF Oil-resistant Cable)
1. Operation Indicator Lamp
1: Without operation indicator
2: 1 A at 125 VAC (with operation indicator)
3: 1 A at 30 VDC (with operation indicator)
2. Actuator
01: Pin plunger
02: Roller plunger
31: Sealed plunger
32: Sealed roller plunger
24: Roller lever (high-sensitivity model)
3. Wiring Specifications
DK1EJ: Pre-wired models
(3 conductors: DC specification, NC wiring)
AK1EJ: Pre-wired models
(3 conductors: AC specification, NC wiring)
M1J: Connector models for ASI devices
(2 conductors: NO wiring)
4. Cable length
03: 0.3 m
05: 0.5 m
10: 1 m
Wiring Specifications
Note: Since the above wiring specifications are different from those
for the D4CC, be careful not to mistake them.
Weather-resistant Models
1. Rated Current
1: 5 A at 250 VAC, 4 A at 30 VDC
2: 5 A at 125 VAC (with LED indicator)
3: 4 A at 30 VDC (with LED indicator)
4: 0.1 A at 125 VAC, 0.1 A at 30 VDC
5: 0.1 A at 125 VAC (with LED indicator)
6: 0.1 A at 30 VDC (with LED indicator)
2. Cable Specifications
2: VCTF oil-resistant cable (3 m)
3: VCTF oil-resistant cable (5 m)
3. Actuator
20: Roller lever
24: Roller lever (high-sensitivity model)
27: Variable roller lever
29: Variable rod lever
1 2 3 4
D4C-@0@@-@@@@@@
Internal switch Connector
COM 3
NC 2
NO 4
1 2 3
D4C-@@@-P

Enclosed Switch D4C F-11
Limit
Switches
Ordering Information
■List of Models
Standard Models
Note 1. Cold-resistant models are also available. Order these models with reference to the following example.
D4C-1201 →D4C-1201-C
2. Models with viscosity-resistant oil specification (with an oil drain hole) are also available. Order these models with reference to the following
example. Applicable only to the plunger models.
D4C-1202 →D4C-1202-M
3. Variable roller lever models are also available.
* Oil-resistant vinyl cabtire cables.
** Ordinary vinyl cabtire cables.
*** Models with SJT(O) Cables (approved by UL and CSA standards) conform to UL and CSA standards.
Actuator Standard cable models UL/CSA-approved cable models
S-FLEX VCTF Cable* VCTF Cable** 5 A at 250 VAC without
LED indicator 5 A at 125 VAC with LED indicator (100 VAC)
SJT(O) Cable***
EN60947-5-1 approved UL/CSA approved
2m3m5m2m3m5m3m5m3m 5m
D4C-@801 D4C-@201 D4C-@301 D4C-@901 D4C-@401 D4C-@501 D4C-1601 D4C-1701 D4C-2601 D4C-2701
D4C-@831 D4C-@231 D4C-@331 D4C-@931 D4C-@431 D4C-@531 D4C-1631 D4C-1731 D4C-2631 D4C-2731
D4C-@802 D4C-@202 D4C-@302 D4C-@902 D4C-@402 D4C-@502 D4C-1602 D4C-1702 D4C-2602 D4C-2702
D4C-@832 D4C-@232 D4C-@332 D4C-@932 D4C-@432 D4C-@532 D4C-1632 D4C-1732 D4C-2632 D4C-2732
D4C-@803 D4C-@203 D4C-@303 D4C-@903 D4C-@403 D4C-@503 D4C-1603 D4C-1703 D4C-2603 D4C-2703
D4C-@833 D4C-@233 D4C-@333 D4C-@933 D4C-@433 D4C-@533 D4C-1633 D4C-1733 D4C-2633 D4C-2733
D4C-@810 D4C-@210 D4C-@310 D4C-@910 D4C-@410 D4C-@510 D4C-1610 D4C-1710 D4C-2610 D4C-2710
D4C-@850 D4C-@250 D4C-@350 D4C-@950 D4C-@450 D4C-@550 D4C-1650 D4C-1750 D4C-2650 D4C-2750
D4C-@820 D4C-@220 D4C-@320 D4C-@920 D4C-@420 D4C-@520 D4C-1620 D4C-1720 D4C-2620 D4C-2720
D4C-@824 D4C-@224 D4C-@324 D4C-@924 D4C-@424 D4C-@524 D4C-1624 D4C-1724 D4C-2624 D4C-2724
D4C-@841 D4C-@241 D4C-@341 D4C-@941 D4C-@441 D4C-@541 D4C-1641 D4C-1741 D4C-2641 D4C-2741
D4C-@842 D4C-@242 D4C-@342 D4C-@942 D4C-@442 D4C-@542 D4C-1642 D4C-1742 D4C-2642 D4C-2742
D4C-@843 D4C-@243 D4C-@343 D4C-@943 D4C-@443 D4C-@543 D4C-1643 D4C-1743 D4C-2643 D4C-2743
D4C-@860 D4C-@260 D4C-@360 D4C-@960 D4C-@460 D4C-@560 D4C-1660 D4C-1760 D4C-2660 D4C-2760
Pin
plunger
Sealed
plunger
Roller
plunger
Sealed roller
plunger
Crossroller
plunger
Sealed
crossroller
plunger
Bevel
plunger
Coil
spring
Roller
lever
Roller lever
(high-sensitivity
model)
Panel mount
pin plunger
Panel mount
roller plunger
Panel mount
crossroller
plunger
Center roller
lever plunger

F-12 Enclosed Switch D4C
Standard Models (Continued)
Pre-wired Models (Use VCTF Oil-resistant Cable)
Note 1. The @contains the length of the cable.
For example: 30 cm →D4C-1001-AK1EJ03
2. M1 models are also available. Contact your OMRON sales representative for further information.
Actuator CENELEC cable models
EN60947-5-1 approved
1m2m3m5m
D4C-1G01 1 M D4C-1G01 2 M D4C-1G01 3 M D4C-1G01 5 M
D4C-1G31 1 M D4C-1G31 2 M D4C-1G31 3 M D4C-1G31 5 M
D4C-1G02 1 M D4C-1G02 2 M D4C-1G02 3 M D4C-1G02 5 M
D4C-1G32 1 M D4C-1G32 2 M D4C-1G32 3 M D4C-1G32 5 M
D4C-1G03 1 M D4C-1G03 2 M D4C-1G03 3 M D4C-1G03 5 M
D4C-1G33 1 M D4C-1G33 2 M D4C-1G33 3 M D4C-1G33 5 M
D4C-1G10 1 M D4C-1G10 2 M D4C-1G10 3 M D4C-1G10 5 M
D4C-1G50 1 M D4C-1G50 2 M D4C-1G50 3 M D4C-1G50 5 M
D4C-1G20 1M D4C-1G20 2 M D4C-1G20 3 M D4C-1G20 5 M
D4C-1G24 1 M D4C-1G24 2 M D4C-1G24 3 M D4C-1G24 5 M
D4C-1G41 1 M D4C-1G41 2 M D4C-1G41 3 M D4C-1G41 5 M
D4C-1G42 1 M D4C-1G42 2 M D4C-1G42 3 M D4C-1G42 5 M
D4C-1G43 1 M D4C-1G43 2 M D4C-1G43 3 M D4C-1G43 5 M
Actuator 1 A at 125 VAC without
operation indicator 1 A at 125 VAC with operation indicator 1 A at 30 VDC without operation indicator 1 A at 30 VDC with operation indicator
D4C-1001-AK1EJ@D4C-2001-AK1EJ@D4C-1001-DK1EJ@D4C-3001-DK1EJ@
D4C-1002-AK1EJ@D4C-2002-AK1EJ@D4C-1002-DK1EJ@D4C-3002-DK1EJ@
D4C-1031-AK1EJ@D4C-2031-AK1EJ@D4C-1031-DK1EJ@D4C-3031-DK1EJ@
D4C-1032-AK1EJ@D4C-2032-AK1EJ@D4C-1032-DK1EJ@D4C-3032-DK1EJ@
D4C-1024-AK1EJ@D4C-2024-AK1EJ@D4C-1024-DK1EJ@D4C-3024-DK1EJ@
Pin
plunger
Sealed
plunger
Roller
plunger
Sealed roller
plunger
Crossroller
plunger
Sealed
crossroller
plunger
Bevel
plunger
Coil
spring
Roller
lever
Roller lever
(high-sensitivity
model)
Panel mount
pin plunger
Panel mount
roller plunger
Panel mount
crossroller
plunger
Pin
plunger
Roller
plunger
Sealed
plunger
Sealed roller
plunger
Roller lever
(high-sensitivity
model)

Enclosed Switch D4C F-13
Limit
Switches
Weather-resistant Models
Individual Parts (Head/Actuator)
Note 1: The model numbers for heads are of the form D4C-00@@,
with the numbers in the squares indicating the type of actua-
tor.
2: Actuators for plunger models, plastic rod models, and center
roller lever models cannot be ordered individually. They must
be ordered together with the head.
3: Consult your OMRON representative for details on cold-re-
sistant specifications.
Mounting Plates
The WL model incorporated by equipment can be replaced with the
D4C together with the Mounting Plate without changing the position
of the dog or cam.
List of Replaceable Models
Contact your OMRON representative for the period required for deliv-
ery.
Note: The WL01@is for micro loads.
Application Example
Note: The position of the dog remains unchanged.
Actuator 5 A at 250 VAC
4 A at 30 VDC
without
operation
indicator
0.1 A at 125 VAC
0.1 A at 30 VDC
without operation
indicator
5 A at 125 VAC
with operation
indicator
4 A at 30 VDC
with operation
indicator
0.1 A at 125 VAC
with operation
indicator
0.1 A at 30 VDC
with operation
indicator
3 m D4C-1220-P D4C-4220-P D4C-2220-P D4C-3220-P D4C-5220-P D4C-6220-P
5 m D4C-1320-P D4C-4320-P D4C-2320-P D4C-3320-P D4C-5320-P D4C-6320-P
3 m D4C-1224-P D4C-4224-P D4C-2224-P D4C-3224-P D4C-5224-P D4C-6224-P
5 m D4C-1324-P D4C-4324-P D4C-2324-P D4C-3324-P D4C-5324-P D4C-6324-P
3 m D4C-1227-P D4C-4227-P D4C-2227-P D4C-3227-P D4C-5227-P D4C-6227-P
5 m D4C-1327-P D4C-4327-P D4C-2327-P D4C-3327-P D4C-5327-P D4C-6327-P
3 m D4C-1229-P D4C-4229-P D4C-2229-P D4C-3229-P D4C-5229-P D4C-6229-P
5 m D4C-1329-P D4C-4329-P D4C-2329-P D4C-3329-P D4C-5329-P D4C-6329-P
Roller lever
Roller lever
(high-sensitivity
model)
Variable
roller lever
Variable rod
lever
Actuator type Head (with
actuator) Actuator
Pin plunger D4C-0001 -
Roller plunger D4C-0002 -
Crossroller plunger D4C-0003 -
Bevel plunger D4C-0010 -
Roller lever D4C-0020 WL-1A100
Roller lever D4C-0024 WL-1A100
Variable roller lever D4C-0027 HL-1HPA320
Variable rod lever D4C-0029 HL-1HPA500
Sealed pin plunger D4C-0031 -
Sealed roller plunger D4C-0032 -
Sealed crossroller plunger D4C-0033 -
Panel mount pin plunger D4C-0041 -
Panel mount roller plunger D4C-0042 -
Panel mount crossroller plunger D4C-0043 -
Plastic rod D4C-0050 -
Center roller lever D4C-0060 -
WL model (Actuator) D4C model (Actuator) Plate
WLD/WL01D (Top
plunger) →D4C-@@01 (Plunger) D4C-P001
WLD2/WL01D2 (Top-
roller plunger) →D4C-@@02 (Roller plunger)
D4C-P002
WLCA2/WL01CA2
(Roller lever) →D4C-@@20 (Roller le- ver)
D4C-P020
Dog
Mounting Plate
Dog

F-14 Enclosed Switch D4C
Remarks
There is no difference in mounting pitch between the Mounting Plate
and the WL. The mounting depth of the D4C with the Mounting Plate
attached is, however, shorter than that of the panel-mounted WL.
Specifications
■Approved Standards
Note 1: Models with VCTF oil-resistant cables only.
2: Pre-wired models only.
3: SJT(0)-cable models only.
■Approved Standard Ratings
General Ratings
Plate
WL D4C
Agency Standard File No.
TÜV Rheinland EN60947-5-1 R9451333 (see note 1)
J9950970 (see note 2)
UL UL508 E76675 (see note 3)
CSA CSA C22.2 No. 14 LR45746 (see note 3)
Model Rated voltage Non-inductive load Inductive load Inrush current
Resistive load Lamp load Inductive load Motor load
NC NO NC NO NC NO NC NO NC NO
D4C-1@@@ 125 VAC 5 A 5 A 1.5 A 0.7 A 3 A 3 A 2.5 A 1.3 A 20 A
max.
10 A
max.
250 VAC 5 A 5 A 1 A 0.5 A 2 A 2 A 1.5 A 0.8 A
8 VDC 5 A 5 A 2 A 2 A 5 A 4 A 3 A 3 A
14 VDC 5 A 5 A 2 A 2 A 4 A 4 A 3 A 3 A
30 VDC 4 A 4 A 2 A 2 A 3 A 3 A 3 A 3 A
125 VDC 0.4 A 0.4 A 0.05 A 0.05 A 0.4 A 0.4 A 0.05 A 0.05 A
250 VDC 0.2 A 0.2 A 0.03 A 0.03 A 0.2 A 0.2 A 0.03 A 0.03 A
D4C-2@@@ 125 VAC 5 A 5 A 1.5 A 0.7 A 3 A 3 A 2.5 A 1.3 A
125 VDC 0.4 A 0.4 A 0.05 A 0.05 A 0.4 A 0.4 A 0.05 A 0.05 A
D4C-3@@@ 30 VDC 4 A 4 A 2 A 2 A 3 A 3 A 3 A 3 A
D4C-4@@@ 125 VAC 0.1 A 0.1 A --- ---
8 VDC 0.1 A 0.1 A
14 VDC 0.1 A 0.1 A
30 VDC 0.1 A 0.1 A
D4C-5@@@ 125 VAC 0.1 A 0.1 A --- ---
D4C-6@@@ 30 VDC 0.1 A 0.1 A --- ---

Enclosed Switch D4C F-15
Limit
Switches
Ratings for Pre-wired Models
Note 1. Inductive loads have a power factor of 0.4 min. (AC) and a time constant of 7 ms max. (DC).
2. Lamp loads have an inrush current of 10 times the steady-state current.
3. Motor loads have an inrush current of 6 times the steady-state current.
UL/CSA Approved Ratings
B300 (D4C-16@@, -17@@), B150 (D4C-26@@, -27@@)
NEMA B300 (D4C-16@@, -17@@) NEMA B150 (D4C-26@@, -27@@)
TÜV Rheinland Approved Ratings (EN60947-5-1)
Applicable Load Range
Rated
voltage Non-inductive load Inductive load Inrush current
Resistive load Lamp load Inductive load Motor load
NC NO NC NO NC NO NC NO NC NO
125 VAC 1 1 1 0.7 1 1 1 1 20 A max. 10 A max.
30VDC11111111
Rated
voltage Carry current Current Volt-amperes
Make Break Make Break
120 VAC 5 A 30 A 3 A 3,600 VA 360 VA
240 VAC 15 A 1.5 A
Rated
voltage Carry current Current Volt-amperes
Make Break Make Break
120 VAC 5 A 30 A 3 A 3,600 VA 360 VA
Model Category and rating I the
D4C-1@@@ AC-15 2 A/250 VAC
DC-12 2 A/30 VDC
5 A
4 A
D4C-2@@@ AC-15 2 A/125 VAC 5 A
D4C-3@@@ DC-12 2 A/30 VDC 4 A
D4C-4@@@ AC-14 0.1 A/125 VAC
DC-12 0.1 A/30 VDC
0.5 A
0.5 A
D4C-5@@@ AC-14 0.1 A/125 VAC 0.5 A
D4C-6@@@ DC-12 0.1 A/30 VDC 0.5 A
D4C-6@@@
D4C-5@@@
D4C-4@@@
5 mW 0.8 W
Current I (mA)
D4C-1@@@
D4C-2@@@
D4C-3@@@
Voltage (VDC)

F-16 Enclosed Switch D4C
■Characteristics
Note 1. The above figures are initial values.
2. The values are calculated at an operating temperature of 5°C to 35°C, and an operating humidity of 40% to 70%. Contact your OMRON
sales representative for more detailed information on other operating environments.
■Operating Characteristics
Degree of protection IP67
Durability (see note 2) Mechanical: 10,000,000 operations min.
Electrical: 200,000 operations min. (5A at 250 VAC, resistive load)
Operating speed 0.1 mm to 0.5 m/s (in case of plunger)
1 mm to 1 m/s (in case of roller lever)
Operating frequency Mechanical: 120 operations/min
Electrical: 30 operations/min
Rated frequency 50/60 Hz
Insulation resistance 100 MΩmin. (at 500 VDC)
Contact resistance (initial) 250 mΩmax. (initial value with 2-m VCTF cable)
300 mΩmax. (initial value with 3-m VCTF cable)
400 mΩmax. (initial value with 5-m VCTF cable)
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min between terminals of the same polarity
1,500 VAC, 50/60 Hz for 1 min between current-carrying metal part and ground, and between each
terminal and non-current-carrying metal part, Uimp: 2.5 kV (EN60947-5-1)
Rated insulation voltage (Ui)300 V (EN60947-5-1)
Switching overvoltage 1,000 VAC, 300 VDC max. (EN60947-5-1)
Pollution degree
(operating environment) 3 (IEC60947-5-1)
Short-circuit protective device (SCPD) 10 A fuse type gG (IEC269)
Conditional short-circuit current 100 A (EN60947-5-1)
Conventional enclosed thermal current
(Ithe)5 A, 4 A, 0.5 A (EN60947-5-1)
Protection against electric shock Class I (with grounding wire)
Vibration resistance Malfunction: 10 to 55 Hz, 1.5-mm double amplitude
Shock resistance Destruction: Approx. 1,000 m/s2min.
Malfunction: Approx. 500 m/s2min.
Ambient temperature (see note) Operating: –10°C to 70°C (with no icing)
Ambient humidity Operating: 95% max.
Weight With 3-m VCTF cable: 360 g; With 5-m VCTF cable: 540 g
Model D4C-@@01
D4C-@001-@K1EJ@D4C-@@31 D4C-@031-@K1EJ@D4C-@@02 D4C-@002-@K1EJ@D4C-@@32 D4C-@032-@K1EJ@D4C-@@03
OF max. 11.77 N 17.65 N 11.77 N 17.65 N 11.77 N
RF min. 4.41 N 4.41 N 4.41 N 4.41 N 4.41 N
PT max. 1.8 mm 1.8 mm 1.8 mm 1.8 mm 1.8 mm
OT min. 3 mm 3 mm 3 mm 3 mm 3 mm
MD max. 0.2 mm 0.2 mm 0.2 mm 0.2 mm 0.2 mm
OP 15.7±1 mm 24.9±1 mm 28.5±1 mm 34.3±1 mm 28.5±1 mm
TT (5) mm (5) mm (5) mm (5) mm (5) mm
Model D4C-@@33 D4C-@@10 D4C-@@50 D4C-@@20
D4C-@@27-P
(see note 1)
D4C-@@29-P
(see note 1)
D4C-@@24
D4C-@@24-P
D4C-@024-@K1EJ@
OF max. 17.65 N 11.77 N 1.47 N 5.69 N 5.69 N
RF min. 4.41 N 4.41 N --- 1.47 N 1.47 N
PT max. 1.8 mm 1.8 mm 15°25°10±3°
OT min. 3 mm 3 mm --- 40°50°
MD max. 0.2 mm 0.2 mm --- 3°3°
OP 34.3±1 mm 28.5±1 mm --- --- ---
TT (5) mm (5) mm --- (70°)(70°)

Enclosed Switch D4C F-17
Limit
Switches
Note 1. The values given for D4C-@@27-P and D4C-@@29-P are for when the length of the lever is 38 mm.
2. The operating characteristics for M1J@models are the same as those for @K1EJ@models.
■Contact Form
Standard Models / Weather-resistant Models
Note 1. "Lights when operated" means that when the actuator is turned or pushed and the Limit Switch contact leaves the NC side, the indicator
lights.
2. "Lights when not in operation" means that when the actuator is in the free position, the indicator is lit, and when the actuator is turned or
pushed and the contact comes into contact with the NO side, the indicator turns OFF.
Wire Color
Model D4C-@@41 D4C-@@42 D4C-@@43 D4C-@@60
OF max. 11.77 N 11.77 N 11.77 N 6.67 N
RF min. 4.41 N 4.41 N 4.41 N 1.47 N
PT max. 1.8 mm 1.8 mm 1.8 mm 10±3°
OT min. 3 mm 3 mm 3 mm 50°
MD max. 0.2 mm 0.2 mm 0.2 mm 3°
OP 31.2±1 mm 36.8±1 mm 36.8 mm ---
TT (5) mm (5) mm (5) mm ---
Without LED Indicator
(S-FLEX VCTF Cable) With LED Indicator
(S-FLEX VCTF Cable)
LED Indicator Circuits
100 VAC
COM NO COM NO
24 VDC
COM
(Black) NO (White) NC (Red) E (Yellow and
green striped)
COM
(Black) NO (White) NC (Red) E (Yellow and
green striped)
With LED Indicator
(lights when operated)
COM
(Black) NO (White)NC (Red) E (Yellow and
green striped)
Yellow/green: VCTF resin cable
Green: VCTF
UL/CSA-approved cable SJT(0)
Cable Without LED With LED
COM NO NC E COM NO NC E
VCTF Black White Red Green Black White Red Green
S-FLEX VCTF Black White Red Yellow/
Green
Black White Red Yellow/
Green
SJT (O) Black Blue Red Green Black Blue Red Green
CENELEC CABLE Blue Black Brown Yellow/
Green
Blue Black Brown Yellow/
Green

F-18 Enclosed Switch D4C
Pre-wired Models
Note 1. "Lights when operated" means that when the actuator is turned or pushed and the Limit Switch contact leaves the NC side, the indicator
lights.
2. "Lights when not in operation" means that when the actuator is in the free position, the indicator is lit, and when the actuator is turned or
pushed and the contact comes into contact with the NO side, the indicator turns OFF.
Connector Models for ASI Devices
Note 1. "Lights when operated" means that when the actuator is turned or pushed and the Limit Switch contact leaves the NC side, the indicator
lights.
2. "Lights when not in operation" means that when the actuator is in the free position, the indicator is lit, and when the actuator is turned or
pushed and the contact comes into contact with the NO side, the indicator turns OFF.
342
Without LED Indicator
AC
DC
With LED Indicator
(lights when not in operation)
Note: Not connected to the ground.
Pin No. Pin No.
With LED Indicator
(lights when operated)
COM
(Black) NO (White) NC (Red) E (Yellow and
green striped)
Yellow/green: VCTF resin cable
Green: VCTF
UL/CSA-approved cable SJT(0)
COM NO NC E (See note.)
342
COM NO NC E (See note.)
COM NO NC
3 4
E (See note.)
A
COM NO NC
3 4
E (See note.)
A
Without LED Indicator
Pin No.
Note: Not connected to the ground.
Pin No.
DC
With LED Indicator
(lights when not in operation)
With LED Indicator
(lights when operated)
COM
(Black) NO (White) NC (Red)E
(Yellow and
green striped)
Yellow/green: VCTF resin cable
Green: VCTF
UL/CSA-approved cable SJT(0)

Enclosed Switch D4C F-19
Limit
Switches
Engineering Data
■Electrical Durability
■Leakage Current for LED-indicator Models
Model Voltage Leakage current Resistance
D4C-2@@@ 125 VAC 1.7 mA 68 kΩ
D4C-3@@@ 30 VDC 1.7 mA 15 kΩ
D4C-5@@@ 125 VAC 1.7 mA 68 kΩ
D4C-6@@@ 30 VDC 1.7 mA 15 kΩ
0
10
50
100
300
500
1,000
3,000
5,000
30
50
100
300
500
1,000
3,000
10,000
5,000
7,000
30
0 20 40 60 80 100 120
1234567
Operating frequency: 30 operations/min
(cosφ= 1, L/R = 0)
Operating temperature: 5°C to 35°C
Operating humidity: 40% to 70%
Operating frequency: 30 operations/min
(cosφ=1, L/R = 0)
Switching current (mA) Switching current (mA)
Durability (x 103operations)
Durability (x 103operations)
D4C-4@@@, -5@@@, -6@@@
30 VDC
125 VAC
125 VAC
250 VAC
D4C-1@@@, -2@@@, -3@@@

F-20 Enclosed Switch D4C
Nomenclature
Standard Models
Roller Lever Models Without Indicator
Weather-resistant Models
Roller Lever Models Without Indicator
O ring
(NBR)
O ring
(NBR)
Roller
Lever
Diaphragm (NBR)
Protective cap (NBR)
Ground terminal
Molded resin
Built-in switch
Cable
Roller
The roller is made of self-lubricating sintered
stainless steel and boasts high resistance to
wear.
Lever
The lever forged of anti-corrosive aluminium
alloy features high corrosion resistances
and outstanding ruggedness.
Roller Lever Setscrew
This screw is made of stainless steel and has high
corrosion resistance.
Built-in Switch
Both standard load and microload models available.
Rotary Shaft
The shaft is made of stainless steel
decreasing the likelihood of rusting.
Diaphragm
The diaphragm is made of silicone rubber
and is resistant to temperature changes
and adverse weather conditions.
Cable
Vinyl cabtire cable and is resistant
to adverse weather conditions.
Head-mounting
Screw
Shaft Section Seal
By fitting an O-ring to the rotary shaft and with
an appropriate interference of the screws,
high-sealing properties are maintained. The
O-ring is made of silicone rubber and is resis-
tant to temperature changes and adverse
weather conditions.

Enclosed Switch D4C F-21
Limit
Switches
Dimensions
Note 1. All units are in millimeters unless otherwise indicated.
2. Unless otherwise specified, a tolerance of ±0.4 mm applies to all dimensions.
Standard Models
OP
23
34
2
2
8
7.5
7
16
1.4 1.5
2.8
25±0.1
OP
PT 25±0.1
34
2
223
4.5
7.5
8
16
1.4 1.5
PT
OP
23
34
2
2
8
7.5
4.5
PT 16
1.4 1.5
2.8
25±0.1
12 dia. x 5 stainless steel roller
Correct setting
position
51.5 max.
67 max.
40 max.
Rubber cap
49 max.
40 max.
49 max.
54.2 max.
40 max.
Pin Plunger
D4C-@@01
Sealed Plunger
D4C-@@31
Roller Plunger
D4C-@@02
10 dia. stainless
steel plunger
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
Correct setting
position
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6
10 dia. stainless
steel plunger
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia. Depth: 6
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6

F-22 Enclosed Switch D4C
OP
23
34
2
2
8
7.5
7
PT 16
1.4 1.5
2.8
25±0.1
34
2
23
2
8
7.5
4.5
OP
PT 25±0.1 16
1.4 1.5
34
2
OP
PT
23
8
7.5
4.5
16
1.4 1.5
25±0.1
2
51.5 max.
67 max.
40 max.
Rubber cap
49 max.
40 max.
Crossroller Plunger
D4C-@@03
Sealed Crossroller Plunger
D4C-@@33
Sealed Roller Plunger
D4C-@@32
Rubber cap
49 max.
40 max.
12 dia. x 5 stainless
steel roller 0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6
12 dia. x 5 stainless
steel roller
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6 Correct setting
position
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6
12 dia. x 5 stainless
steel roller
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
VCTF cable, 0.75 mm2,
4 conductor
Finishing O.D.: 7.6

Enclosed Switch D4C F-23
Limit
Switches
34
2
25±0.1
7
2
8
7.5
11.4
16
1.4 1.5
44±0.8
30.2±0.8
31.5±0.8
38R
34
2
104±2.5
42
38
25±0.1
23
2
8
7.5
4.5
16
1.4 1.5
OP
25±0.1
34
223
7
7.5
8
16
2.8
1.4 1.5
2
PT
23
102.7 max.
40 max.
65 max.
50 max.
Rubber cap
Nylon rod
51.5 max.
40 max.
3.2 dia.
6.6 dia.
(see note 2)
(see note 1)
67 max.
51.5 max.
40 max.
Roller Lever
Bevel Plunger
D4C-@@10
Coil Spring
D4C-@@50
D4C-@@20
D4C-@@20-P
10 dia. stainless
steel plunger 0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
Correct setting
position
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6
Note: 1. Operation is possible in
any direction except in par-
allel to the axis ↓.
2. The ideal range for opera-
tion is between the tip of
the rod and 1/3 of the
length of the actuator.
VCTF cable, 0.75 mm2,
4 conductor
Finishing O.D.: 7.6 0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia. Depth: 6
17.5 dia. x 7 stainless
sintered roller
M5 (length: 12)
Allen-head bolt
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6 (see note)
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
Note: S-FLEX VCTF Cables are used for weather-
resistant models (D4C-P).

F-24 Enclosed Switch D4C
Roller Lever (High-Sensitivity Model)
65 max.
102.7 max.
40 max.
50 max.
Center Roller Lever Plunger
D4C-@@60
102.7 max.
40 max.
D4C-@@24
D4C-@@24-P
17.5 dia. x 7 stainless
sintered roller
M5 (length: 12)
Allen-head bolt
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6 (see note)
Note: S-FLEX VCTF Cables are used for weather-
resistant models (D4C-P).
17.5 dia. x 7 stainless
sintered roller
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6
38R
38R

Enclosed Switch D4C F-25
Limit
Switches
Note: Two nuts (thickness: 2.5; distance across: 17) are included with the D4C-@@41, D4C-@@42 and D4C-@@43.
34
OP
PT
25±0.1
2
7.5
4.5
16
2.8
1.4 1.5
23
8
M14 x 1
2
34
2
23
2
8
7.5
4.5
OP
PT
25±0.1
16
2.8
M14 x 1
1.4 1.5
34
2
OP
PT
25±0.1
23
2
8
7.5
4.5
2.8
M14 x 1
1.4 1.5
16
Correct setting
position
49 max.
40 max.
49 max.
40 max.
Panel Mount Pin Plunger
D4C-@@41
Panel Mount Roller Plunger
D4C-@@42
Panel Mount Crossroller Plunger
D4C-@@43
49 max.
40 max.
10 dia. stainless
steel plunger 0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6 Correct setting
position
VCTF cable, 0.75 mm2, 4 conductor
Finishing O.D.: 7.6
12 dia. x 5 stainless
steel roller
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
VCTF cable, 0.75 mm2,
4 conductor
Finishing O.D.: 7.6
12 dia. x 5 stainless
steel roller 0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
Correct setting
position
VCTF cable, 0.75 mm2,
4 conductor
Finishing O.D.: 7.6

F-26 Enclosed Switch D4C
Pre-wired Models
49 max.
40 max.
Rubber cap
XS2H-D421
49 max.
XS2H-D421
Rubber cap
40 max.
40 max.
67 max.
51.5 max.
XS2H-D421
12 dia. x 5 stainless steel roller
10 dia. stainless steel plunger
40 max.
54.2 max. 49 max.
XS2H-D421
Pin Plunger Roller Plunger
Sealed Roller PlungerSealed Pin Plunger
D4C-@001-@K1EJ@
D4C-@001-M1J@D4C-@002-@K1EJ@ D4C-@002-M1J@
D4C-@031-@K1EJ@
D4C-@031-M1J@D4C-@032-@K1EJ@ D4C-@032-M1J@
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
Correct setting
position 0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
Correct setting
position
10 dia. stainless
steel plunger
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
12 dia. x 5 stainless
steel roller
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6

Enclosed Switch D4C F-27
Limit
Switches
Weather-resistant Models
Models with LED Indicator
The dimensions of the LED indicator for models equipped with one are shown below.
38R
102.7 max.
40 max.
65 max.
50 max.
XS2H-D421
Roller Lever
D4C-@024-@K1EJ@17.5 dia. x 7 stainless
sintered roller
M5 (length: 12)
Allen-head bolt
0
Two, 5.1+0.2 dia. holes
Spot facing 10.2 dia.
Depth: 6
Adjustable Roller Lever
D4C-@@27-P
Adjustable Rod Lever
D4C-@@29-P
40 max.
30R to 75R (variable)
40 max.
65 max.
65 max.
57.7 max. 55 max.
17.5 dia. x 7 stainless
steel roller
M5 (length: 16)
Allen-head bolt
M5 (length: 12)
Allen-head bolt
0
Two, 5.1
+0.2
dia. holes
Spot facing 10.2 dia. Depth: 6
VCTF cable, 0.75 mm
2
, 4 conductor
Finishing O.D.: 7.6
3 dia. x 160 stainless
steel lever
0
Two, 5.1
+0.2
dia. holes
Spot facing 10.2 dia.
Depth: 6
M5 (length: 16)
Allen-head bolt
M5 (length: 12)
Allen-head bolt
VCTF cable, 0.75 mm
2
, 4 conductor
Finishing O.D.: 7.6
(4)
LED

F-28 Enclosed Switch D4C
Special Mounting Plates (Plates are not provided with Limit Switches.)
Note: Each dimension has a tolerance of ±0.4 mm unless otherwise specified.
OP of WLD
Spring pins
OP of WLD2
Four, 5.2
+0.2
dia. holes (see note 1)
−0
11 dia.
11 dia.
11 dia.
D4C-P001
D4C-P002
D4C-P020
Two, M5 x 0.8 tapped hole
(see note 2)
Note: Four, M5 x 0.8 hexagon pan-head bolts and
two M5 x 0.8 Allen-head bolts are provided.
−0
Note: 1. Tighten the 5.2+0.2 dia. holes with the M5
x 10 hexagon pan-head screws.
2. Insert the M5 Allen-head bolts into the
M5 tapping holes to tighten the Mount-
ing Plate securely.
Note: Four, M5 x 0.8 hexagon pan-head bolts and
two M5 x 0.8 Allen-head bolts are provided.
−0
Note: 1. Tighten the 5.2+0.2 dia. holes with the M5
x 10 hexagon pan-head screws.
2. Insert the M5 Allen-head bolts into the
M5 tapping holes to tighten the Mount-
ing Plate securely.
Two, M5 x 0.8 tapped hole
(see note 2)
Four, 5.2
+0.2
dia. holes (see note 1)
−0
−0
Two, 4.2
+0.12
dia. positioning holes
(Press-fit the spring pins.)
Two, M5 x 0.8 tapped hole
(see note 2)
−0
Two, 5.2
+0.2
dia. holes (see note 1)
Note: Four, M5 x 0.8 hexagon pan-head bolts and
two M5 x 0.8 Allen-head bolts are provided.
−0
Note: 1. Tighten the 5.2+0.2 dia. holes with the M5
x 10 hexagon pan-head screws.
Four, M5 x 0.8 hexagon pan-head bolts,
two M5 x 0.8 Allen-head bolts are pro-
vided, and two 4 x 14 spring pins are
provided.
2. Insert the M5 Allen-head bolts into the
M5 tapping holes to tighten the Mount-
ing Plate securely.
