OPTICOM DIGITAL VIDEO RECORDER 2 - V 1.3 User manual

DIGITAL VIDEO RECORDER
OPERATION MANUAL (REV.1.3)

2
Safety precautions
Install this equipment avoiding a direct ray of light, heats and moistures.
-Doing not, can result in lowering efficiency, electric shock or fire.
Do not pull electric wire or do not touch power plug with wet hands.
-Can result in electric shock or fire.
Do not bend the power cable forcedly or do not press it with heavy materials.
-Can result in electric shock or fire.
Do not use damaged power cord or loose outlet plug.
-Can result in electric shock or fire.
Do not use the outlet fully.
-Can result in electronic shock or fire.
Do not disassemble, repair or convert this product without permission.
-Can result in electric shock or fire. When repair is required, contact the service center.
Do not open the cover of the product at your convenience or do not insert inductive stick
into the ventilation hole.
-Especially, SMPS is open, so only professional technicians are allowed to work on.
Failure to follow these instructions could result in serious personal
injury or death.
Failure to follow these instructions could result in personal injury or
property damage.
Notifies user of references to use conveniently.
Do not place equipment on the inclined or uneven plane.
-Can cause lowering of efficiency or malfunction.
Do not vibrate or shock in operation.
-Can cause out of order with equipment and hard disk (HDD).
be caution that do not cover the ventilation hole of HDD or put liquid into the equipment.
-may cause out of order of equipment and hard disk drive (HDD)
Battery Caution : “Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.”

3
Contents
DVR Mainframe
Remote Controller (option)
Power Cord Set
USB Mouse (option)
Software CD Operation Manual
Open the box at the clean and even place. And read operation manual thoroughly before you install.
Check the items supplied with your DVR system. Refer to the picture above
and contact your dealer if you find anything is missing or damaged.
The specification and appearance may be changed without prior notice.
DC Power Adapter

4
Index
Chapter I. System overview
System Specification--------------------------------------------------------------------------------7
System Characteristics-----------------------------------------------------------------------------8
Chapter II. H/W description
System Appearance-------------------------------------------------------------------------------10
DVR Rear Panel------------------------------------------------------------------------------11,12
System Rear Connection detail----------------------------------------------------------------13
System Front Description----------------------------------------------------------------------16
Remote Control Description---------------------------------------------------------------------17
Installation Guide for HDD & ODD devices --------------------------------------------18,19
System on / shutdown----------------------------------------------------------------------------20
Chapter III. Monitoring Screen
Monitoring Screen---------------------------------------------------------------------------------22
Screen split, login----------------------------------------------------------------------------------23
Menu – Display-------------------------------------------------------------------------------------24
Menu – Spot, PTZ, Alarm------------------------------------------------------------------------25
Menu – Status--------------------------------------------------------------------------------------26
Menu – Record, Camera, Color, OSD-------------------------------------------------------27
Menu – Backup-------------------------------------------------------------------------------------28
Menu – Mute, Logout-----------------------------------------------------------------------------29
Chapter IV. Setup
System------------------------------------------------------------------------------------------------31
System – Information----------------------------------------------------------------------------32
System – Date/Time-----------------------------------------------------------------------------33
System – Disk-------------------------------------------------------------------------------------34
System – User------------------------------------------------------------------------------------35
System – Log, Logout, Shutdown-----------------------------------------------------------36
Network-----------------------------------------------------------------------------------------------37
Network – LAN------------------------------------------------------------------------------------38
Network – DDNS---------------------------------------------------------------------------------39
Network – Email----------------------------------------------------------------------------------40
Network – Callback------------------------------------------------------------------------------41
Device-------------------------------------------------------------------------------------------------42
Device – Camera---------------------------------------------------------------------------------43
Device – Alarm / Main Monitor----------------------------------------------------------------44
Device– Display / Spot Monitor---------------------------------------------------------------45
Device – Miscellaneous------------------------------------------------------------------------46
Record------------------------------------------------------------------------------------------------47
Record – Record policy / Record------------------------------------------------------------48
Event--------------------------------------------------------------------------------------------------49
Event – Motion------------------------------------------------------------------------------------50
Event – Sensor------------------------------------------------------------------------------------51
Event – Video loss-------------------------------------------------------------------------------52
Event – System-----------------------------------------------------------------------------------53

5
Index
Chapter V. Search
Search screen--------------------------------------------------------------------------------------55
Menu – Display / Calendar search------------------------------------------------------------56
Menu – Event search / Date / Time search------- ----------------------------------------57
Menu – First, Last, Bookmark------------------------------------------------------------------58
Menu – Local device / Backup device-------------------------------------------------------59
Chapter VI. Client program
REMOTE---------------------------------------------------------------------------------------------61
Connection Info / Button-------------------------------------------------------------------------62
Program Info & Setup-----------------------------------------------------------------------------63
Icon Adjustment------------------------------------------------------------------------------------64
Remote search execute & setup--------------------------------------------------------------65
Menu – Remote setup (Camera)--------------------------------------------------------------66
Menu – Remote setup (Alarm)-----------------------------------------------------------------67
Menu – Remote setup (Record)---------------------------------------------------------------68
Menu – Remote setup (Record table)--------------------------------------------------------69
Menu – Remote setup (Record policy)-------------------------------------------------------70
Menu – Remote setup (Motion)----------------------------------------------------------------71
Menu – Remote setup (Motion link)----------------------------------------------------------72
Menu – Remote setup (Sensor)---------------------------------------------------------------73
Menu – Remote setup (Sensor link)----------------------------------------------------------74
Menu – Remote setup (Video loss)-----------------------------------------------------------75
Menu – Remote setup (Video loss link)------------------------------------------------------76
Menu – Remote setup (System)---------------------------------------------------------------77
Menu – Remote setup (Disk error/S.M.A.R.T)---------------------------------------------78
Menu – Remote setup (Disk error/S.M.A.R.T link)----------------------------------------79
Play & Pause / Audio transmission / Mouse click to right------------------------------80
Channel button/Layout change button-------------------------------------------------------81
PTZ operation---------------------------------------------------------------------------------------82
Remote search (Image playback screen / Section)--------------------------------------83
Remote search (Hotkey & Event search)---------------------------------------------------84
Remote search (Connection info / button / playback button)--------------------------85
Remote search (Split screen change / Audio / Image control button)---------------86
Remote search (Saving related button)-----------------------------------------------------87
Remote search (Preview)------------------------------------------------------------------------88
Remote search (Mouse click to right)--------------------------------------------------------89
Remote search (Time table)--------------------------------------------------------------------90
Backup playback-----------------------------------------------------------------------------------91
PLAYER----------------------------------------------------------------------------------------------92
Chapter VII. APPENDIX
Front Key---------------------------------------------------------------------------------------------96
Hot Key-----------------------------------------------------------------------------------------------97
Product Warranty----------------------------------------------------------------------------------98

6
Chapter-I. System Overview

7
Chapter I
System Specification
LX-400 LX-900 LX-1600
Video IN / Loop Out 4 9 16
Video Display 1, 4 1, 4, 9 1, 4, 9, 16
Monitor Out 1c Composition
VGA Out 1c
Spot Out 1c
Audio In/Out 4 in / 1 out
Audio Compression G.723
Display Resolution 720x480
Recording Resolution 720x480, 720x240, 360x240
Video Compression Mpeg4 Level 1,2,3
Display
Frame
NTSC 120fps 270fps 480fps
PAL 100fps 225fps 400fps
Record
Frame
NTSC D1 120fps CIF 240fps CIF 240fps
PAL D1 100fps CIF 200fps CIF 200fps
Playback
Frame
NTSC D1 120fps CIF 240fps CIF 240fps
PAL D1 100fps CIF 200fps CIF 200fps
OS Embedded Linux
Network 10/100 BaseT(1EA)
USB USB2.0 (Front 1EA, Rear 1EA)
EIDE 2c (Max 3EA HDD)
SATA 4C (Max 3EA HDD)
Console RS232C
PTZ RS485
Alarm Function (In/Out) 4/1
Front Key 33 Key
Remote controller ID Remote controller
Watc dog / Power monitor Yes
LCD None
Front LED Power, Network, HDD
Dimension 395(W) x 390(D) x 70(H) mm
Operation temp. 0~45℃
Operation umidity 5~70%
Weig t 3.5kg (Wit out CDRW, HDD)
Power Adapter DC 12V, 50/60Hz ,
5A
Adapter DC 12V, 50/60Hz, 7A

8
System Characteristics
Up to D1(720*480) recording
High level specification with elegance design and jog/shuttle, easy UI with LCD
Control recording resolution, quality, frame rate by each camera
USB mouse supported
LIVE screen editing, Digital zoom, SPOT monitor supported
Event / Panic / Schedule record, optimized record mode supported
Diversified search by Time, Calendar, Event supported
Diversified backup by USB2.0 and DVD-RW supported
Convenient backup by AVI , Mini viewer etc
10/100 Base-T network
DDNS, NTP, E-MAIL, CALLBACK functions
DISK ID, S.M.A.R.T functions, real-time disk health check
Multi-language supported
Intensive security function by chosen AUTHORITY
Diversified network program by LIVE, SEARCH, CMS, AGENT
Chapter I

9
Chapter-II. H/W Description

10
1) Front View
2) Side View
3) Top View
Chapter II
System appearance

11
DVR rear panel
Chapter II
Video Input
(4CH)
Video
Output
Power Input
DC12V
Alarm
In/Out
Network Port
USB Port
RS232
Port
VGA
Port
FAN
NT/PAL
switch
Audio In/Out
RS485
Power
switch
1) 4CH Rear Panel
2) 9CH Rear Panel
FAN
Power
switch
Video
Output Video Input
(9CH)
Audio In/Out
Power Input
DC12V
NT/PAL
switch
VGA
Port
Spot
Output
USB Port
Network Port
RS232
Port
Alarm
In/Out
RS485

12
DVR rear panel
Chapter II
3) 16CH Rear Panel
FAN
Power
switch
Video
Output Video Input
(9CH)
Audio In/Out
Power Input
DC12V
NT/PAL
switch
VGA
Port
Spot
Output
USB Port
Network Port
RS232
Port
Alarm
In/Out
RS485

13
Chapter II
System rear connection detail
2) Monitor Connection
1)Video Source Connection
It connects video sources (camera image) to BNC connector via cable.
CVBS/ SPOT OUT : It connects normal CCTV CRT monitor.
VGA : It connects PC monitor or LCD monitor (not supporting DVI)
3) Audio Connection 4) Network Connection
It connects audio source (mic) to audio
input (4CH) of RCA and connects
speaker to audio output.
It supports 10/100 BaseT, connects
Cat5 cable with RJ-45

14
Chapter II
* Alarm Input 1~4CH
When an event happens DVR operates by using external device.
Sensor, Switch signal (Signal GND) are connected terminal block.
Ref : Spec. Max 6V/50mA
* Alarm Output 1CH
It can be on/off external device as buzzer, headlamp etc.
Alarm input mode consists of NORMAL OPEN and NORMAL CLOSE.
Ref : Spec. Max24V/2A
* RS485
Through Half-duplex serial communication, remote controlling is available using control system
as external device, control keyboard.
In addition, it is available to control PTZ (Pan/Tilt/Zoom) camera.
it is connected RS485 +,- of DVR.
5) RS232 port Connection.
RS232 port is connected to PC and other devices for specific function and After Sales purpose.
It consists of 1 USB (Front), 1 USB (Rear), its supported devices are such as USB mouse, USB
external HDD and USB memory stick
6) USB port Connection
7) ALARM IN/OUT(SENSOR) Connection

15
Chapter II
Adaptor is DC12V /5A input and Main Power can turn on/off DVR on Switch.
8) NTSC/PAL Shift Switch
NTSC/PAL Shift Switch
9)Power Connection
The factory reset switch located at the left side of NTSC/PAL switch is used to return to factory
default setup values.
When you need to shift NTSC/PAL mode, turn off the DVR before shift switch, then restart the DVR.

16
System Front Description
Chapter II
REMOVABLE HDD RACK
CD_RW,DVD_RW Direction
IR sensor
Operating Number
Menu
Menu Button : it shows menu in live, search display (same function as right click of mouse)
Direction Button : It is used for movement, changing set-up, PTZ move, etc in menu.
(Basic function- left, right : Movement / up, down : Changing set-up / Enter : confirmation
Number Button : It is used for Changing to 1CH screen, direct input in set-up.
Operating Button : It is used for operating function as Setup, Backup etc in DVR.
ESC Button : It is used for exit from menu/mode, withdrawing from execution.
LED : It shows status of Power, HDD, Network.
IR sensor : it receives a signal of remote controller (remote controller is optional)
Playback Button : It is used for when search, playback, Pause, FF, REW.
(It comes to live screen out of playback screen when stop button is pressed)
Power, HDD,
Network LED
USB2.0
Playback
ESC

17
○
○○
○How to change remote controller ID
A) Enter 'ID' button for 3seconds
B) Power LED is lightened.
C) Enter 2 letters of digit. (00 ~ 99) – In case 00, means no ID function
- ID set is available from 01 to 99.
D) Save setting value, then LED is off.
E) It enables to communicate the same ID DVR
F) LED is ON every time data is transferred.
Remote controller Description (Optional)
Chapter II
ICON HOT KEY
LATEST SEARCH
TO LIVE
FIRST SEARCH
LAST SEARCH
CALENDAR SEARCH
EVENT SEARCH
RECORD
SETUP
BACKUP
COLOR
STATUS
ENTER
DIRECTION
MENU
ESCAPE
DISPLAY
SEQUENCE
FREEZE
ZOOM
REWIND
FAST FORWORD
STEP REVERSE
STEP FORWORD
FUNCTION
POWER ON/OFF
PLAYBACK & PAUSE
STOP
||▶
||▶||▶
||▶
■
■■
■
◀◀
◀◀◀◀
◀◀
▶▶
▶▶▶▶
▶▶
◀|
◀|◀|
◀|
|▶
|▶|▶
|▶
▲
▲▲
▲ ◀
◀◀
◀ ▶
▶▶
▶
▼
▼▼
▼
◀
◀◀
◀
▶

18
Chapter II
Installation Guide for HDD & ODD devices (E-IDE Type)
Description
JF 1 : PRIMARY
JF 4 : SECONDARY
MASTER : HDD#1
SLAVE : HDD#2
SLAVE : ODD(CD/DVD)
Installed HDD HDD System
ODD(CD-RW/DVD-RW)
Device
IDE Connector IDE Connector
HDD x 1 HDD#1 PRIMARY
MASTER JF1 SYSTEM
SECONDARY
SLAVE
JF 4
HDD x 2 HDD#1 PRIMARY
MASTER JF 1 SYSTEM
HDD#2 PRIMARY
SLAVE JF 1
ODD
MAIN
BOARD
HDD
1. ODD(CD-RW/DVD-RW) devices should be installed as “Secondary Slave”.
2. HDD for system needs to be installed as “Primary”.
Guide Chart for installing several HDDs

19
Chapter II
Installation Guide for HDD & ODD devices (SATA Type)
Description
Installed HDD HDD Position System ODD(CD-RW/DVD-RW)
Device
HDD x 1 HDD#1 SATA 1 SYSTEM
SATA 4
HDD x 2 HDD#1 SATA 1 SYSTEM
HDD#2 SATA 2
1. ODD(CD-RW/DVD-RW) devices should be installed as “SATA 4”.
2. HDD for system needs to be installed as “SATA 1”.
Guide Chart for installing several HDDs
SATA1 : HDD#1
SATA2 : HDD#2
SATA3 or SATA4 : ODD(CD/DVD)
ODD
MAIN
BOARD
HDD

20
Chapter II
System On
• Put the power to the DVR.
• Turn on the power switch at the rear power button .
• It takes about 2minutes to boot (It may take more when network cable isn’t connected)
System Shutdown
•Select [SETUP > SYSTEM > SYSTEM SHUTDOWN] to shutdown system at login status
• Press “OK” button to confirm “Power off the system”, then turn off power switch in the rear.
This manual suits for next models
6
Table of contents
Other OPTICOM DVR manuals

OPTICOM
OPTICOM SVD-2416 User manual

OPTICOM
OPTICOM OWB-1605 User manual

OPTICOM
OPTICOM 4 CHANNELS MPEG-4 DIGITAL VIDEO RECORDER - V... User manual

OPTICOM
OPTICOM OWL - REV1.3 User manual

OPTICOM
OPTICOM OWE-900 - User manual

OPTICOM
OPTICOM OWM-402 User manual

OPTICOM
OPTICOM OWL-900 - User manual

OPTICOM
OPTICOM OWE-1600 - User manual

OPTICOM
OPTICOM OWL-400 - User manual

OPTICOM
OPTICOM EV4250 Installation and maintenance instructions
