Oriental motor AlphaStep AZ Series User manual

Thank you for purchasing an Oriental Motor product.
This Manual describes product handling procedures and safety precautions.
•Please read it thoroughly to ensure safe operation.
•Always keep the manual where it is readily available.
HM-60451
AZ Series / Motorized Actuator
equipped with AZ Series
mini Driver
PROFINET Compatible
USER MANUAL
Introduction
Hardware
PROFINET
communication
Parameter ID lists
Troubleshooting
Reference materials

2
1 Introduction
1 Before using the product............................................................................................................................................ 6
2 Operating manuals ...................................................................................................................................................... 7
2-1 Related operating manuals..................................................................................................................................................................7
2-2 How to use operating manuals...........................................................................................................................................................7
3 Overview of the product............................................................................................................................................. 9
4 Safety precautions .....................................................................................................................................................10
5 Precautions for use ....................................................................................................................................................12
2 Hardware
1 System conguration ................................................................................................................................................16
2 Preparation..................................................................................................................................................................17
2-1 Checking the product ......................................................................................................................................................................... 17
2-2 How to identify the product model ............................................................................................................................................... 17
2-3 Products possible to combine ......................................................................................................................................................... 17
2-4 Information about nameplate ......................................................................................................................................................... 18
2-5 Names and functions of parts.......................................................................................................................................................... 18
2-6 Indication of LEDs................................................................................................................................................................................. 19
3 Installation...................................................................................................................................................................21
3-1 Installation location ............................................................................................................................................................................. 21
3-2 Installation method.............................................................................................................................................................................. 21
4 Connection ..................................................................................................................................................................23
4-1 Connection example ........................................................................................................................................................................... 23
4-2 Connecting the main power supply and the control power supply (CN1)...................................................................... 24
4-3 Connecting the PROFINET cable (CN3/CN4)............................................................................................................................... 26
4-4 Connecting the USB cable................................................................................................................................................................. 26
4-5 Connecting input signals (CN5)....................................................................................................................................................... 26
4-6 Noise elimination measures.............................................................................................................................................................. 27
4-7 Conformity to EMC............................................................................................................................................................................... 28
5 Inspection and maintenance ...................................................................................................................................30
5-1 Inspection................................................................................................................................................................................................ 30
5-2 Warranty................................................................................................................................................................................................... 30
5-3 Disposal.................................................................................................................................................................................................... 30
6 Cables ...........................................................................................................................................................................31
6-1 Connection cables................................................................................................................................................................................ 31
6-2 Power supply cable.............................................................................................................................................................................. 33

3
3 PROFINET communication
1 Flow of setting of PROFINET communication.......................................................................................................36
2 Guidance......................................................................................................................................................................37
3 Communication specications ................................................................................................................................39
4 IO data ..........................................................................................................................................................................40
4-1 IO data format........................................................................................................................................................................................ 40
4-2 Input data ................................................................................................................................................................................................ 41
4-3 Output data ............................................................................................................................................................................................ 46
4-4 Processing order of IO data............................................................................................................................................................... 50
4-5 Data writing ............................................................................................................................................................................................ 51
4-6 Data reading........................................................................................................................................................................................... 52
5 Example of execution for operation.......................................................................................................................54
5-1 Positioning operation.......................................................................................................................................................................... 54
5-2 Continuous operation......................................................................................................................................................................... 55
6 Direct data operation ................................................................................................................................................56
6-1 Overview of direct data operation ................................................................................................................................................. 56
6-2 Output data and parameters required for direct data operation........................................................................................ 57
6-3 Operation example .............................................................................................................................................................................. 60
4 Parameter ID lists
1 Timing for parameter to update..............................................................................................................................64
2 Maintenance commands ..........................................................................................................................................65
3 Monitor commands ...................................................................................................................................................67
4 Operation data R/W commands ..............................................................................................................................73
4-1 Base address of each operation data number............................................................................................................................ 73
4-2 Parameter ID........................................................................................................................................................................................... 75
4-3 Setting example .................................................................................................................................................................................... 76
5 Operation I/O event R/W commands......................................................................................................................77
5-1 Base address of operation I/O event.............................................................................................................................................. 77
5-2 Parameter ID for operation I/O event R/W command............................................................................................................. 77
6 Protect release commands.......................................................................................................................................78
7 Extended operation data setting R/W command ................................................................................................79
8 Parameter R/W commands.......................................................................................................................................80
8-1 Driver action simulation setting parameter................................................................................................................................ 80
8-2 Base setting parameter....................................................................................................................................................................... 80
8-3 Coordinate parameters....................................................................................................................................................................... 81
8-4 Operation parameters......................................................................................................................................................................... 81
8-5 Direct data operation parameters .................................................................................................................................................. 81
8-6 ABZO sensor setting parameters .................................................................................................................................................... 82
8-7 Mechanism settings parameters..................................................................................................................................................... 82
8-8 Initial coordinate generation & wrap coordinate parameters.............................................................................................. 82

4
8-9 JOG/HOME/ZHOME operation information setting parameters......................................................................................... 83
8-10 Alarm setting parameters.................................................................................................................................................................. 84
8-11 Information setting parameters ...................................................................................................................................................... 84
8-12 I/O parameters....................................................................................................................................................................................... 86
8-13 Direct I/O setting parameters........................................................................................................................................................... 89
8-14 Remote I/O setting parameters ....................................................................................................................................................... 89
8-15 Virtual input parameters .................................................................................................................................................................... 90
8-16 User output setting parameters...................................................................................................................................................... 91
8-17 Driver mode setting parameters..................................................................................................................................................... 91
8-18 Assignable monitor setting parameters....................................................................................................................................... 91
9 I/O signals assignment list........................................................................................................................................92
9-1 Input signals ........................................................................................................................................................................................... 92
9-2 Output signals........................................................................................................................................................................................ 93
5 Troubleshooting
1 Detection of communication errors .......................................................................................................................96
1-1 Communication timeout ................................................................................................................................................................... 96
1-2 Error of communication settings .................................................................................................................................................... 96
2 Alarms...........................................................................................................................................................................97
2-1 Alarm reset.............................................................................................................................................................................................. 97
2-2 Alarm history .......................................................................................................................................................................................... 97
2-3 Generation condition of alarms....................................................................................................................................................... 97
2-4 Alarm list .................................................................................................................................................................................................. 98
2-5 Timing chart..........................................................................................................................................................................................103
3 Information ...............................................................................................................................................................105
3-1 Information history ............................................................................................................................................................................108
3-2 Information list ....................................................................................................................................................................................108
4 Troubleshooting and remedial actions................................................................................................................111
6 Reference materials
1 Timing chart ..............................................................................................................................................................114
2 Specications............................................................................................................................................................116
2-1 Product specications.......................................................................................................................................................................116
2-2 General specications.......................................................................................................................................................................116
3 Regulations and standards.....................................................................................................................................117

1 Introduction
This part explains the product overview and safety precautions in addition to the types and descriptions about
operating manuals.
Table of contents
1 Before using the product ....................... 6
2 Operating manuals ................................. 7
2-1 Related operating manuals............................7
2-2 How to use operating manuals ....................7
3 Overview of the product........................ 9
4 Safety precautions ................................ 10
5 Precautions for use................................ 12

Before using the product
1 Introduction
6
1 Before using the product
Only qualied personnel of electrical and mechanical engineering should work with the product.
Use the product correctly after thoroughly reading the section “4 Safety precautions”on p.10. In addition, be sure to
observe the contents described in warning, caution, and note in this manual.
The product described in this document has been designed and manufactured to be incorporated in general
industrial equipment. Do not use for any other purpose. Oriental Motor Co., Ltd. is not responsible for any
compensation for damage caused through failure to observe this warning.

Operating manuals
1 Introduction
7
2 Operating manuals
2-1 Related operating manuals
Download the operating manuals from Oriental Motor Website Download Page or contact your nearest Oriental
Motor sales oce.
•AZ Series / Motorized Actuator equipped with AZ Series
mini Driver PROFINET Compatible USER MANUAL (this document)
•AZ Series / Motorized Actuator equipped with AZ Series OPERATING MANUAL Function Edition
Read the following operating manuals for motors and motorized actuators.
•OPERATING MANUAL Motor Edition
•OPERATING MANUAL Actuator Edition
•Motorized Actuator OPERATING MANUAL Function Setting Edition
2-2 How to use operating manuals
To use the product, read this manual together with the AZ Series OPERATING MANUAL Function Edition.
This manual describes contents specic to the mini Driver PROFINET compatible, and the AZ Series OPERATING
MANUAL Function Edition describes contents common to the AZ Series products. Refer to the AZ Series OPERATING
MANUAL Function Edition for the contents not included in this manual.
Reference destinations are indicated according to the ow of use.
How to read reference destinations
The title name of the operating manual is described in the reference destination.
The title number in the reference destination may be changed. Use the title name when checking the
reference destination.
Reference destination in this manual
Reference destination in AZ Series
OPERATING MANUAL Function Editio
n
Procedure
3 PROFINET communication
4 Parameter ID lists
Setting of parameters
4 Parameters
7 Address/code lists

Operating manuals
1 Introduction
8
2 Hardware
Installation and connection
Make the communication settings
for the driver using the conguration
tool of a host controller.
Refer to the operating manual of the
conguration tool for how to set.
Communication settings of PROFINET
3 PROFINET communication
4 Parameter ID lists
Setting of parameters
3 PROFINET communication
Operation
1 Before starting operation *1
4 Parameters
7 Address/code lists
2 Operation
3 I/O signals
8 Measures for various cases
11 Appendix *2
Before starting operation
*1 When a motorized actuator is used, the following contents cannot be operated via PROFINET. Use the support
software MEXE02.
• Copying the xed value (parameter) of the ABZO sensor to driver
• Creation of recovery data le and method of recovery
*2 Refer to this manual for “LEDs of the driver.” (_p.19)
Description of power supplies
This manual describes contents when a main power supply and a control power supply are used.
The mini Driver can also be used with a main power supply only. When using it with only the main power supply,
replace "main power supply and control power supply" or "control power supply" with "main power supply” to read
this manual.

Overview of the product
1 Introduction
9
3 Overview of the product
The AZ Series mini Driver PROFINET compatible is the dedicated driver for the AZ Series products.
Compact and light weight
Compact and lightweight are achieved, oering the dimensions of 69 mm×56 mm×30 mm (2.72 in.×2.2 in.×1.18 in.)
and the mass of 0.11 kg (0.24 lb.).
Compatible with PROFINET
Operation data and parameters can be set via PROFINET or using the MEXE02 software.
This manual describes how to set operation data and parameters via PROFINET.
Equipped with direct data operation function
Direct data operation is a function to start operation at the same time as rewriting of the data. It can be used when
the setting of the operation data is changed frequently, such as changing the speed or travel amount according to a
load.
Providing the GSD File
The GSD le (General Station Description le) is a le that describes the specic information of the PROFINET
compatible products. Importing the GSD le to the Conguration tool of the host controller can perform the settings
of PROFINET before the driver is delivered to you.
For details, contact your nearest Oriental Motor sales oce.

Safety precautions
1 Introduction
10
4 Safety precautions
The precautions described below are intended to ensure the safe and correct use of the product, and to prevent the
user and other personnel from exposure to the risk of injury. Use the product only after carefully reading and fully
understanding these instructions.
Handling the product without observing the instructions that accompany a "WARNING"
symbol may result in serious injury or death.
Handling the product without observing the instructions that accompany a "CAUTION"
symbol may result in injury or property damage.
The items under this heading contain important handling instructions that the user
should observe to ensure safe use of the product.
The items under this heading contain related information and contents to gain a further
understanding of the text in this manual.
General
•Do not use the product in explosive or corrosive environments, in the presence of ammable gases, in places
subjected to splashing water, or near combustibles. Doing so may result in re, electric shock, or injury.
•Assign qualied personnel to the task of installing, wiring, operating/controlling, inspecting and troubleshooting
the product. Handling by unqualied personnel may result in re, electric shock, injury, or damage to equipment.
•Do not transport, install, connect or inspect the product while the power is supplied. Doing so may result in electric
shock.
•Do not touch the driver while the power is supplied. Doing so may result in re or electric shock.
•When an alarm of the driver is generated (any of the driver's protective functions is triggered), remove the cause
before resetting the alarm (protective function). Continuing the operation without removing the cause of the
problem may cause malfunction of the motor and the driver, leading to injury or damage to equipment.
Installation
•Install the driver in an enclosure. Failure to do so may result in electric shock or injury.
Connection
•Observe the product specications for the power supply voltage of the driver. Failure to do so may result in re or
electric shock.
•Connect the product securely according to the connection diagram. Failure to do so may result in re or electric
shock.
•Do not forcibly bend, pull, or pinch the connection cable. Doing so may result in re or electric shock.
Operation
•Turn o the main power supply and the control power supply in the event of a power failure. Failure to do so may
result in injury or damage to equipment.
•Do not remove the motor excitation during operation. Doing so may cause the motor to stop and lose the holding
force, resulting in injury or damage to equipment.
Repair, disassembly, and modication
•Do not disassemble or modify the driver. Doing so may result in injury or damage to equipment.

Safety precautions
1 Introduction
11
General
•Do not use the driver beyond the specications. Doing so may result in electric shock, injury, or damage to
equipment.
•Keep your ngers and objects out of the openings in the driver. Failure to do so may result in re, electrical shock,
or injury.
•Do not touch the driver while operating or immediately after stopping. Doing so may result in a skin burn(s).
•Do not forcibly bend or pull the cable that is connected to the driver. Doing so may cause damage to the product.
Installation
•Keep the area around the driver free of combustible materials. Failure to do so may result in re or a skin burn(s).
•Do not leave anything around the driver that would obstruct ventilation. Doing so may result in damage to
equipment.
Operation
•Use a motor and a driver only in the specied combination. An incorrect combination may cause a re.
•Take measures against static electricity when operating the switches of the driver. Failure to do so may result in the
driver malfunction or damage to equipment.
•Provide an emergency-stop device or emergency-stop circuit external to the equipment so that the entire
equipment will operate safely in the event of a system failure or malfunction. Failure to do so may result in injury.
•When moving the moving part manually, put the motor into a non-excitation state. Continuing the work while the
motor is in an excitation state may result in injury.
•For the main power supply and the control power supply, use a DC power supply with reinforced insulation on its
primary and secondary sides. Failure to do so may result in electric shock.
•When an abnormal condition has occurred, immediately stop operation to turn o the main power supply and
control power supply. Failure to do so may result in re, electrical shock, or injury.

Precautions for use
1 Introduction
12
5 Precautions for use
This chapter explains restrictions and requirements the user should consider when using the product.
zAlways use Oriental Motor cables to connect a motor and a driver.
Refer to the cable models on p.31.
zWhen conducting the insulation resistance measurement or the dielectric strength test, be sure to
separate the connection between the motor and the driver.
Conducting the insulation resistance measurement or the dielectric strength test with the motor and driver
connected may result in damage to the product.
zNote when connecting a main power supply and a control power supply in a state of grounding the
positive side
The USB connector on the driver is not electrically insulated. When grounding the positive terminals of a main power
supply and a control power supply, do not connect any equipment (PC, etc.) whose negative terminal is grounded.
Doing so may cause the driver and this equipment to short, damaging both. When connecting, do not ground
equipment.
zSaving data to the non-volatile memory
Do not turn o the control power supply while writing the data to the non-volatile memory, and also do not turn o
for ve seconds after the completion of writing the data. Doing so may abort writing the data and cause an alarm of
EEPROM error to generate. The non-volatile memory can be rewritten approximately 100,000 times.
zNoise elimination measures
Refer to p.27 for noise elimination measures.
zRegeneration
When operating a large load inertia at a high speed, the regenerative energy generated may increase the voltage of
the main power supply, causing an alarm of Overvoltage to generate. To prevent damage to the driver, reconsider the
operating conditions so that regenerative voltage does not generate.
Notes when the connection cable is used
Note the following points when an Oriental Motor cable is used.
zWhen inserting the connector
Hold the connector main body, and insert it in straight securely. Inserting the connector in an inclined state may result
in damage to terminals or a connection failure.
zWhen pulling out the connector
Pull out the connector in straight while releasing the lock part of the connector. Pulling out the connector with
holding the cable may result in damage to the connector.
zBending radius of cable
Use the cable in a state where the bending radius of the cable is more
than six times of the cable diameter.
Do not bend the lead wires part or secure with a clamp, etc. Doing so
may result in damage to the connector.
More than 6 times
of cable diameter
Do not bend the lead wires part

Precautions for use
1 Introduction
13
zHow to x the cable
Fix the cable at two places near the connectors as shown in the gure or x it with a wide clamp to take measures to
prevent stress from being applied to the connectors.
Motor
Driver
In the case of a exible cable,
this area is a movable range.
Fixing at two places
Fixing at two places
Do not bend the lead wires
part or x with a clamp

1 Introduction
14

2 Hardware
This part explains names and functions of each part of the driver, installation and connection methods, and so
on.
Table of contents
1 System conguration............................ 16
2 Preparation............................................. 17
2-1 Checking the product ................................... 17
2-2 How to identify the product model ......... 17
2-3 Products possible to combine ................... 17
2-4 Information about nameplate ................... 18
2-5 Names and functions of parts.................... 18
2-6 Indication of LEDs........................................... 19
3 Installation.............................................. 21
3-1 Installation location ....................................... 21
3-2 Installation method ....................................... 21
4 Connection ............................................. 23
4-1 Connection example..................................... 23
4-2 Connecting the main power supply
and the control power supply (CN1) ....... 24
4-3 Connecting the PROFINET cable
(CN3/CN4).......................................................... 26
4-4 Connecting the USB cable........................... 26
4-5 Connecting input signals (CN5)................. 26
4-6 Noise elimination measures ....................... 27
4-7 Conformity to EMC......................................... 28
5 Inspection and maintenance .............. 30
5-1 Inspection.......................................................... 30
5-2 Warranty............................................................. 30
5-3 Disposal.............................................................. 30
6 Cables ...................................................... 31
6-1 Connection cables.......................................... 31
6-2 Power supply cable........................................ 33

System conguration
2 Hardware
16
1 System conguration
Control
power supply *1 Circuit
breaker *2
Circuit
breaker *2
*3
Noise
lter
AC
power supply
Noise
lter
AC
power supply
Host controller
PROFINET
PROFINET
compatible
product
PROFINET
compatible
product
PC in which the MEXE02
has been installed
Driver
Motor
Main
power supply
*1 Connecting the control power supply allows you to continue monitoring even if the main power supply is shut o.
Connect it as necessary.
*2 It is recommended that a circuit breaker or a circuit protector is connected because incorrect wiring of the power
supply may cause the internal input circuit to short-circuit.
*3 Connect when using direct inputs or sensors.

Preparation
2 Hardware
17
2 Preparation
This chapter explains the items you should check, as well as names and functions of each part.
2-1 Checking the product
Verify that the items listed below are included. Report any missing or damaged items to the Oriental Motor sales
oce from which you purchased the product.
•Driver ............................................................................... 1 unit
•Instructions and Precautions for Safe Use.......... 1 copy
2-2 How to identify the product model
Check the driver model against the model shown on the
nameplate. Refer to “2-4 Information about nameplate”
on p.18 for how to identify the nameplate.
AZD - K R PN
1 2 3 4
1 Series AZD: AZ Series driver
2 Power supply input K: DC power input
3 Driver gure R: Compact
4 Type PN: PROFINET
2-3 Products possible to combine
Products with which the driver can be combined are listed below. Check the model name of the product with the
nameplate.
Power supply
type Product type Applicable Series
Model name
representing
Series name *1
Example of model name
DC power
input
Stepping motor AZ Series AZM AZM46AK
Motorized actuator
EAC Series *2 EACM EACM2E05AZAK
EAS Series *2 EASM EASM4NXD005AZAK
EZS Series *2 EZSM EZSM6D005AZAK
DR Series DR DR28G2.5B03-AZAKU
DRS2 Series DRSM DRSM60-05A4AZAK
DGII Series *2 DGM
DGB
DGM85R-AZAK
DGB85R12-AZAKR
EH Series *2 EH EH4-AZAKH
LSeries *2 LM LM4F150AZAK-1
*1 The driver described in this manual can be combined with products that begin with these model names.
*2 For these motorized actuators, the equipped motors have been evaluated to ax the CE Marking. The model name
of the equipped motor can be checked as follows..
EAC Series, EAS Series, EZS Series: Check with the motor nameplate.
DGII Series, EH Series, LSeries: Check with “P/N (Motor P/N)” described on the actuator nameplate.

Preparation
2 Hardware
18
2-4 Information about nameplate
The gure shows an example.
Driver model
Serial number
Manufacturing date
2-5 Names and functions of parts
Not used
PWR/ALM LED (Green/red/blue)
MS LED (Green/red)
L/A LED (Green)
Mounting hole
USB connector
Input signal connec
tor (CN5)
Power supply connector (CN1)
Motor/encoder/electromagnetic
brake connector (CN2)
PROFINET connectors
(CN3, CN4)
NS LED (Green/red)
Cutout for mounting
Type Name Sign Description
LED
PWR/ALM LED (Green/Red/Blue) PWR/ALM This LED indicates the status of the driver.
MS LED (Green/Red) MS These LEDs indicate the communication status
of PROFINET.
NS LED (Green/Red) NS
L/A LED (Green) L/A This LED indicates the LINK/ACT status of
PROFINET.
Connector
Power supply connector (CN1) +, − Connects a main power supply and a control
power supply.
Motor/encoder/electromagnetic
brake connector (CN2) −Connects the motor, the encoder, and the electromagnetic brake.
USB connector Connects a PC in which the MEXE02 software
has been installed. (USB2.0 mini-B port)
PROFINET connectors (CN3, CN4) − Connects the PROFINET cable.
Input signal connector (CN5) − Connects when using direct inputs or sensors.

Preparation
2 Hardware
19
2-6 Indication of LEDs
PWR/ALM LED indication
This LED indicates the status of the driver.
LED status Description
No light The main power supply and the control power supply are not turned on.
Green light The main power supply and/or the control power supply are turned on.
Blinking red
An alarm is being generated. The alarm message generated can be checked
by counting the number of times the LED blinks.
The LED is lit in green when the alarm is reset.
Blinking blue
•Information is being generated. The LED is lit in green when the information
is cleared.
•Remote operation is being executed with the MEXE02 software. The LED is
lit in green when remote operation is completed.
Repeating "Green →Red →
Simultaneously lit * →No light" This is the driver simulation mode.
* Green and red colors may overlap and it may be visible to orange.
MS LED, NS LED
These LEDs indicate the communication status of PROFINET.
LED
name
LED status Description
Green Red
MS LED
No light No light The main power supply and the control power supply of the driver are not turned
on.
Blinking No light
•The communication settings of PROFINET have not been made in the driver.
Make the communication settings using the Conguration tool of the host
controller.
•Blinking the LED was requested by the Conguration tool of the host controller.
(When it is blinking simultaneously with the NS LED)
Light No light The driver operates properly.
No light Blinking
The data for the communication settings of PROFINET stored in the driver was
damaged. Execute either of the following, and turn o the main power supply
and the control power supply and on again. After that, make the communication
settings again using the Conguration tool of the host controller.
•Initialize the communication settings using the Conguration tool of the host
controller. (Only the communication settings can be initialized.)
•Execute [Restore to factory settings (including communication settings)] under
the [Communication] menu with the MEXE02 software. (All parameters
including the communication settings are initialized.)
No light Light An error inside the driver was detected. Turn on the main power supply and the
control power supply again.
NS LED
No light No light
•The main power supply and the control power supply are not turned on.
•PROFINET communication is not being made.
Blinking No light
•The communication settings of PROFINET are being made.
•Blinking the LED was requested by the Conguration tool of the host controller.
(When it is blinking simultaneously with the MS LED)
Light No light PROFINET communication is being made.
No light Blinking
The communication timeout was detected during PROFINET communication.
Check the following.
•Is the PROFINET cable disconnected?
•Is the power supply for the host controller turned on?

Preparation
2 Hardware
20
L/A LED
This LED indicates the LINK/ACT status of PROFINET.
LED status Description
No light
•This is in an oine state.
•The frame of PROFINET is not sent and received.
Blinking
•This is in an online state.
•The frame of PROFINET is sent and received.
Light
•This is in an online state.
•The frame of PROFINET is not sent and received.
