Oriental motor BLE Series User manual

HM-5081-5
Brushless Motor
BLE Series CC-Link
Operation
OPERATING MANUAL
Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety precautions.
•Please read it thoroughly to ensure safe operation.
•Always keep the manual where it is readily available.
Table of contents
1 Related operating manuals........................... 2
2 Remote I/O .......................................................... 3
2.1 Remote I/O list..........................................................3
2.2 RY signals (master to driver)................................4
2.3 RX signals (driver to master)................................7
3 Remote register ................................................. 9
3.1 Remote register list.................................................9
3.2 RWw register.............................................................9
3.3 RWr register............................................................ 10
4 Codes...................................................................11
4.1 Code list................................................................... 11
4.2 Operation data read/write code..................... 13
4.3 Parameter read/write code............................... 13
4.4 Read-only code..................................................... 18
4.5 Special code........................................................... 19
5 Data write and read........................................21
5.1 Data save area ....................................................... 21
5.2 Writing data via the command code
(RWwn2) .................................................................. 21
5.3 Reading data via the command code
(RWwn2) .................................................................. 22
5.4 Writing the rotating speed via the set
rotating speed (RWwn1).................................... 23
6 Operation...........................................................24
6.1 Setting the switches............................................ 24
6.2 Turning on the power......................................... 25
6.3 Operating the motor........................................... 25
6.4 Checking the data................................................ 26
7 Monitor function.............................................27
7.1 Monitoring method............................................. 27
7.2 Monitor code list .................................................. 27
8 Extended functions........................................31
8.1 User I/O .................................................................... 31
8.2 Data setter .............................................................. 31
9 Remedial actions.............................................32
9.1 Driver alarm............................................................ 32
9.2 Driver warning ...................................................... 34
9.3 CC-Link communication error ......................... 34
10 Appendix ...........................................................35
10.1 CC-Link communication specications........ 35
10.2 Remote I/O list....................................................... 35
10.3 Remote register list.............................................. 36
10.4 Response code list ............................................... 36
10.5 Command code list ............................................. 36
10.6 Monitor code list .................................................. 38

Related operating manuals
–2–
1 Related operating manuals
Two operating manuals are provided for the BLE series CC-Link, as listed below.
•Operation (this document)
This manual explains the functions and usage of CC-Link. It also talks about the types of operations and functions of
each operation.
•Installation/Connection
This manual explains the names and functions of motor/driver components, installation method and connection
method.
Read the Installation/Connection Manual carefully to install and connect the product before use.

Remote I/O
–3–
2 Remote I/O
This section describes the driver’s remote I/Os.
“n” indicates the address assigned to the master station via station-number setting.
Note
•Do not turn ON/OFF the remote I/Os indicated by“Cannot be used”in the list. If these remote I/Os are
turned ON/OFF, a correct driver operation cannot be guaranteed.
•If a data setter is connected, the remote I/Os will become eective in modes other than the test mode.
2.1 Remote I/O list
•RY signals (master to driver) •RX signals (driver to master)
Device No. Signal name Description Device No. Signal name Description
RYn0 FWD Forward input RXn0 FWD Forward mode output
RYn1 REV Reverse input RXn1 REV Reverse mode output
RYn2 M0 Data selection 0 input RXn2 MOVE Motor running output
RYn3 M1 Data selection 1 input RXn3 VA Speed attained output
RYn4 M2 Data selection 2 input RXn4 ALARM-OUT2 Alarm output 2
(normally closed)
RYn5 − Cannot be used RXn5 MPS Main power supply
status output
RYn6 STOP-MODE Stop mode selection
input RXn6 WNG Warning output
RYn7 ALARM-RESET Alarm reset input RXn7 ALARM-OUT1 Alarm output 1
(normally closed)
RYn8 − Cannot be used RXn8 − Cannot be used
RYn9 − Cannot be used RXn9 − Cannot be used
RYnA − Cannot be used RXnA − Cannot be used
RYnB − Cannot be used RXnB S-BSY During the internal
processing
RYnC M-REQ Monitor performance
request RXnC M-BSY Monitoring
RYnD VW-REQ Rotating speed setting
request (RAM) RXnD VW-END Rotating speed setting
complete (RAM)
RYnE − Cannot be used RXnE − Cannot be used
RYnF CW-REQ Command code
execution request RXnF CW-END Command code
execution complete
RY (n+1) 0 RX (n+1) 0
to
RX (n+1) A
− Cannot be used
to − Cannot be used RX (n+1) B CRD Remote station
communication ready
RY (n+1) F
RX (n+1) C
to
RX (n+1) F
− Cannot be used

Remote I/O
–4–
2.2 RY signals (master to driver)
The following explains the RY signals (driver input signal) sent from the master to the driver.
The timing chart provided below assumes the following settings:
•When the FWD input is turned ON, the motor will turn in the CW direction.
•When the STOP-MODE input is turned ON, the motor will decelerate to a stop.
 FWD/REV (forward/reverse input)
When the FWD input or REV input is turned ON, the motor will run. When the FWD/REV input is turned OFF, the motor
will stop.
The motor decelerates to a stop if it is stopped while the STOP-MODE input is ON. The motor stops instantaneously if
the STOP-MODE input is OFF.
Turning the FWD input and REV input ON at the same time will cause the motor to stop instantaneously.
Whether the motor should turn in the CW direction or CCW direction when the FWD input is turned ON can be set
using the “motor direction selection”parameter (p.13).
FWD input ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
REV input
MOVE output
FWD output
REV output
Deceleration
stop
Instantaneous
stop
CW
Mot
or movementStop
CCW
Deceleration stop
10 ms
or less
200 ms
or less
Master to driver
Driver to master

Remote I/O
–5–
 M0/M1/M2 (data selection input)
Desired operation data can be selected by a combination of ON/OFF statuses of M0 to M2 inputs. Up to eight sets of
operation data can be set, and the rotating speed, acceleration time and deceleration time can be set for each data
set.
If the operation data is changed using the M0 to M2 inputs while the motor is operating, the motor will accelerate or
decelerate according to the acceleration or deceleration time set for the new operation data.
Note The STOP-MODE input is ignored when using the M0 to M2 inputs.
M2 input M1 input M0 input Operating data
OFF OFF OFF Data 0
OFF OFF ON Data 1
OFF ON OFF Data 2
OFF ON ON Data 3
ON OFF OFF Data 4
ON OFF ON Data 5
ON ON OFF Data 6
ON ON ON Data 7
M0 input ON
OFF
ON
OFF
ON
OFF
ON
OFF
M1 input
M2 input
FWD input
Speed 1
Speed 3
Speed 0 Deceleration time
7
Acceleration time 0Speed 7
Mot
or movement
Deceleration time 3
Acceleration time 1
Stop
CW
Master to driver
 STOP-MODE (stop mode selection input)
This input is used to select how to stop the motor when the FWD input or REV input is turned OFF.
If the STOP-MODE input is ON, the motor will stop according to the deceleration time that has been set.
If the STOP-MODE input is OFF, the motor will stop instantaneously.
FWD input ON
OFF
ON
OFF
STOP-MODE input
Deceleration stop
Motor movement
Stop
CW
Master to driver
Immediate stop

Remote I/O
–6–
 ALARM-RESET (alarm reset input)
When an alarm generates and the driver’s protective function is actuated, the ALARM-OUT1 output will turn OFF and
the motor will stop spontaneously. To reset the alarm, remove the cause of the alarm, and then turn the ALARM-RESET
input from ON to OFF or cycle the control power supply. The alarm will be reset and the ALARM-OUT1 output will
return to the ON status.
If the driver’s protective function is actuated due to an overload, the ALARM-OUT2 output will also turn OFF. In this
case, reset the alarm in the same method as explained above. Both the ALARM-OUT1 output and ALARM-OUT2
output will return to the ON status.
See “9.1 Driver alarm”on p.32 for details.
Note
•Alarms cannot be reset if the FWD input or REV input is ON or the motor is running.
Be sure to stop the motor before resetting any alarm.
•The ALARM-OUT1 output and ALARM-OUT2 output are normally closed signals, meaning that both
outputs are normally ON.
FWD input ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
FWD input OFF
REV input REV input OFF
ALARM-RESET input
ALARM-OUT1 output
Overload protection operation
ALARM-OUT2 output
Motor movement
Motor stop
Master to driver
Driver to master
Stop
CW
Natural stop
 M-REQ (monitor performance request)
This signal is used to request monitoring by remote registers.
See “7 Monitor function”on p.27 for details on monitor function.
 VW-REQ (rotating speed setting request)
This signal requests setting (writing) of the rotating speed data via a remote register.
Set the rotating speed of the operation data selected by the M0 to M2 inputs.
For the method to write data, see “5.4 Writing the rotating speed via the set rotating speed (RWwn1)”on p.23.
 CW-REQ (command code execution request)
This signal requests execution of a command code via a remote register.
Command codes can be used to set (write) and check (read) data.
For the writing and reading using command codes, see “5.2 Writing data via the command code (RWwn2)” on p.21
and “5.3 Reading data via the command code (RWwn2)” on p.22.
See “4 Codes”on p.11 for details on the codes.

Remote I/O
–7–
2.3 RX signals (driver to master)
The following explains the RX signals (driver output signal) sent from the driver to the master.
The timing chart provided below assumes the following settings:
•When the FWD input is turned ON, the motor will turn in the CW direction.
•When the STOP-MODE input is turned ON, the motor will decelerate to a stop.
 FWD (forward mode output)
When the FWD input is turned ON, an operation command will be output and the driver will excite the motor. As a
result, the FWD output will turn ON.
Refer to the timing chart shown in “FWD/REV (forward/reverse input)” on p.4.
 REV (reverse mode output)
When the REV input is turned ON, an operation command will be output and the driver will excite the motor. As a
result, the REV output will turn ON.
Refer to the timing chart shown in “FWD/REV (forward/reverse input)” on p.4.
 MOVE (motor running output)
This output remains ON while a motor operation command is output.
To detect a stopping of the motor, use the output rotating speed (RWwn1) or “output rotating speed” under the
monitor function.
See “7 Monitor function”on p.27 for details on monitor function.
Refer to the timing chart shown in “FWD/REV (forward/reverse input)” on p.4.
 VA (speed attained output)
This signal is output when the motor rotating speed reaches the set value.
The detection band from the set value can be set using the“rotating speed attainment band”parameter (p.13).
(Master to driver) FWD input ON
OFF
ON
OFF
(Driver to master)
VA output
Rotating speed attainment band
Motor movement
Stop
CW
 ALARM-OUT2 (alarm output 2)
The ALARM-OUT2 output is a normally closed signal, meaning that it is normally ON.
When the overload detection level is exceeded, the ALARM-OUT2 output will turn OFF. Once the load drops to below
the detection level, the output will return to the ON status. The detection level can be set using the “overload warning
level” parameter (p.16). Whether or not to use this overload warning function is set using the “overload warning
function” parameter (p.16).
Regardless of whether or not the warning function is used, once the overload protection function is actuated the
ALARM-OUT2 output will always turn OFF. For the method to reset the overload protection function, see “9.1 Driver
alarm” on p.32.
 MPS (main power supply status output)
This output signal stays ON while the main power supply is turned ON.
 WNG (warning output)
If a warning generates, the WNG output will turn ON. Once the warning is reset, the output will return to the OFF
status. For the types of warnings, see“9.2 Driver warning”on p.34.
For your information, whether or not to use the overload warning can be set using the “overload warning function”
parameter (“Overload warning function” on p.16).

Remote I/O
–8–
 ALARM- OUT1 (alarm output 1)
The ALARM-OUT1 output is a normally closed signal, meaning that it is normally ON.
The ALARM-OUT1 output will turn OFF when the driver’s protective function has actuated due to an alarm.
For the method to reset the protective function, see “9.1 Driver alarm”on p.32.
Driver status ALARM-OUT1 output ALARM-OUT2 output WNG output
Normal ON ON OFF
Overload protection function has actuated OFF OFF OFF
Other protective function has actuated OFF ON OFF
Overload warning function has actuated ON OFF ON
 S-BSY (during the internal processing)
The signal will remain ON while the following internal processes are performed:
While the S-BSY output is ON, any request that uses the CW-REQ input or VW-REQ input is ignored.
•When the power supply is turned on
•While the EEPROM is being read
•While the EEPROM is being written
•While data is being written
•While data is being read
 M-BSY (monitoring)
This signal remains ON while the driver or motor status is being checked using the monitor function.
See “7 Monitor function”on p.27 for details on monitor function.
 VW-END (rotating speed setting complete)
This signal will turn ON when the VW-REQ input command is completed successfully. When the VW-REQ input is
turned OFF, the VW-END output will also turn OFF.
 CW-END (command code execution complete)
This signal will turn ON when the CW-REQ input command is completed successfully. When the CW-REQ input is
turned OFF, the CW-END output will also turn OFF.
 CRD (remote station communication ready)
This signal will turn ON when the initialization of the driver is completed. The CRD signal continues to be output while
the control power supply is input.

Remote register
–9–
3 Remote register
This section describes the driver’s remote registers.
“n” indicates the address assigned to the master station via station-number setting.
3.1 Remote register list
•RWw register (master to driver) •RWr register (driver to master)
Device No. Name Device No. Name
RWwn0 Monitor code RWrn0 Monitor value
RWwn1 Set rotating speed RWrn1 Output rotating speed
RWwn2 Command code RWrn2 Response code
RWwn3 Write data RWrn3 Read data
3.2 RWw register
 Monitor code (RWwn0)
This register stores the code used under the monitor function. See “7 Monitor function”on p.27 for details on
monitor function.
 Set rotating speed (RWwn1)
This register stores the rotating speed to be set for the operation data selected by the M0 to M2 inputs.
The stored rotating speed will be written when the VW-REQ input is turned ON.
See “5.4 Writing the rotating speed via the set rotating speed (RWwn1)” on p.23 for details.
 Command code (RWwn2)
This register stores the code for setting (writing) and checking (reading) data.
You can set/check data by storing a read command code or write command code and then turning ON the CW-REQ
input.
For data write and read using command codes, see “5.2 Writing data via the command code (RWwn2)” on p.21 and
“5.3 Reading data via the command code (RWwn2)” on p.22.
See “4 Codes”on p.11 for details on the codes.
 Write data (RWwn3)
This register stores the data written by a command code.
For data write using a command code, see “5.2 Writing data via the command code (RWwn2)” on p.21.
See “4 Codes”on p.11 for details on the codes.

Remote register
–10–
3.3 RWr register
 Monitor value (RWrn0)
This register stores the data obtained via the monitor function. See “7 Monitor function”on p.27 for details on
monitor function.
 Output rotating speed (RWrn1)
This register always stores the rotating speed of the motor output shaft.
The output is based on the following logic: a positive value indicates the direction achieved by the FWD input, while a
negative value indicates the direction achieved by the REV input.
Whether the motor should turn in the CW direction or CCW direction when the FWD input is turned ON can be set
using the “motor direction selection”parameter (p.13).
 Response code (RWrn2)
This register stores the processing result of each execution request eected by the CW-REQ input or
VW-REQ input. Every time a new processing result is obtained, the response code is overwritten and refreshed.
Response code Name Description
0000h Normal The processing was successful.
0001h Runtime error
•An attempt was made to execute a command when an internal
processing was still in progress.
•An attempt was made to execute a prohibited command during
operation (when the MOVE output is ON).
0002h Parameter selection error A command code not dened in the specication was specied.
0003h Out of range error The data to be written is outside the specication range.
 Read data (RWrn3)
This register stores the data that has been read via a command code.
For data read using a command code, see “5.3 Reading data via the command code (RWwn2)” on p.22.
See “4 Codes”on p.11 for details on the codes.

Codes
–11–
4 Codes
The following four types of codes are used by the CC-Link driver of the BLE series.
Type Description
Operation data read/write code Set the rotating speed, acceleration time and deceleration time.
Parameter read/write code Set the motor operating environment.
Read-only code Read the alarm and warning history. Read data relating to the speed display.
Special code Write/read the RAM and EEPROM. Clear the alarm history and initialize the parameters.
4.1 Code list
 Operation data read/write code
Read command code Write command code Description
3000h 4000h
Rotating speed
Data 0
3001h 4001h Data 1
3002h 4002h Data 2
3003h 4003h Data 3
3004h 4004h Data 4
3005h 4005h Data 5
3006h 4006h Data 6
3007h 4007h Data 7
3100h 4100h
Acceleration time
Data 0
3101h 4101h Data 1
3102h 4102h Data 2
3103h 4103h Data 3
3104h 4104h Data 4
3105h 4105h Data 5
3106h 4106h Data 6
3107h 4107h Data 7
3200h 4200h
Deceleration time
Data 0
3201h 4201h Data 1
3202h 4202h Data 2
3203h 4203h Data 3
3204h 4204h Data 4
3205h 4205h Data 5
3206h 4206h Data 6
3207h 4207h Data 7

Codes
–12–
 Parameter read/write code
Read command code Write command code Description
1200h 2200h
Operation
Motor direction selection
1201h 2201h Rotating speed attainment band
1202h 2202h Input selection
1301h 2301h
Speed display
Gear ratio
1302h 2302h Gear ratio digit specication
1303h 2303h Speed increasing ratio
1305h 2305h Conveyor gear ratio
1306h 2306h Conveyor gear ratio digit specication
1307h 2307h Conveyor speed increasing ratio
1110h 2110h Overload warning Overload warning level
1111h 2111h Overload warning function
3500h 4500h
General I/O (user I/O)
General input 0
3501h 4501h General input 1
3502h 4502h General input 2
3503h 4503h General input 3
3600h 4600h General output 0
3601h 4601h General output 1
 Read-only code
Read command code Description
0074h
Protection
Alarm history 0, 1 read
0075h Alarm history 2, 3 read
0076h Alarm history 4, 5 read
0077h Alarm history 6, 7 read
0078h Alarm history 8, 9 read
1100h Warning history 0, 1 read
1101h Warning history 2, 3 read
1102h Warning history 4, 5 read
1103h Warning history 6, 7 read
1104h Warning history 8, 9 read
1300h Speed display Decimal position in operating speed
1304h Decimal position in conveyor transfer speed
 Special code
Command code Description
006Dh Read the main rotating speed (RAM)
006Eh Read the main rotating speed (EEPROM)
00EDh Write the main rotating speed (RAM)
00EEh Write the main rotating speed (EEPROM)
00F4h Clear the alarm history
00FCh Initializing the parameters
2F00h Read the EEPROM all at once
2F01h Write the EEPROM all at once

Codes
–13–
4.2 Operation data read/write code
 Rotating speed
Description Set the rotating speed to operating data 0 to 7.
Setting (write) 4000h to 4007h
Check (read) 3000h to 3007h
Setting range 0 r/min and 80 to 4000 r/min (setting unit: 1 r/min)
Initial value 0 r/min
 Acceleration time
Description Set the acceleration time until the target speed is reached, to operation data 0 to 7.
Setting (write) 4100h to 4107h
Check (read) 3100h to 3107h
Setting range 0.2 to 15 s (setting unit: 0.1 s)
In the processing of data, 0.1 s is equal to a value of 1.
Initial value 0.5 s
 Deceleration time
Description Set the deceleration time until the target speed is reached, to operation data 0 to 7.
Setting (write) 4200h to 4207h
Check (read) 3200h to 3207h
Setting range 0.2 to 15 s (setting unit: 0.1 s)
In the processing of data, 0.1 s is equal to 1.
Initial value 0.5 s
4.3 Parameter read/write code
 Motor direction selection
Description Set the motor direction to be applied when the FWD input is turned ON.
Setting (write) 2200h
Check (read) 1200h
Setting range 0 (CCW)
1 (CW)
Initial value 1 (CW)
Note When an attempt is made to set up during operation (when the MOVE output is ON), a response code
(RWrn2) will cause a runtime error (0001h), disabling setup.
 Rotating speed attainment band
Description Set the band within which the rotating speed of the motor is deemed to have reached the set value.
Setting (write) 2201h
Check (read) 1201h
Setting range 0 to 400 r/min (setting unit: 1 r/min)
Initial value 200 r/min

Codes
–14–
 Input selection
Description Select whether to operate the input signals using remote I/Os or user I/Os.
Setting (write) 2202h
Check (read) 1202h
Setting range 0 (remote I/O)
1 (user I/O)
Initial value 0 (remote I/O)
Note
•When an attempt is made to set up during operation (when the MOVE output is ON), a response code
(RWrn2) will cause a runtime error (0001h), disabling setup.
•If the FWD input or REV input of the I/O at the switched destination is ON when the
“input selection”parameter is changed, an operation prohibited warning is generated. See“9.2 Driver
warning”on p.34 for details on the warnings.
 Gear ratio
Description
Set the numerical part of the gear ratio relative to the rotating speed of the motor output shaft.
The gear ratio is used for“operating speed” under the monitor function. Also set the “gear ratio digit
specication” parameter.
Setting (write) 2301h
Check (read) 1301h
Setting range 100 to 9999 (setting unit: 1)
Initial value 100
Note
•The default value of the “gear ratio”parameter is 100, while the default value of the “gear ratio digit
specication” parameter is 2. Accordingly, the actual default gear ratio becomes 1.00.
•If both the gear ratio (speed reducing ratio) and speed increasing ratio are set, the speed increasing ratio
will be given priority. If the speed increasing ratio is 1, the speed does not increase and consequently the
speed increasing ratio will be ignored. In this case, the operating speed output by the monitor function
corresponds to the output data calculated by the set value of the“gear ratio”parameter. See “7 Monitor
function”on p.27 for details on monitor function.
 Gear ratio digit specication
Description Set the position of the decimal point in the set value of the “gear ratio”parameter.
Setting (write) 2302h
Check (read) 1302h
Setting range
0 (No decimal point)
1 (1 decimal place)
2 (2 decimal places)
Initial value 2 (2 decimal places)
Note The default value of the “gear ratio”parameter is 100, while the default value of the “gear ratio digit
specication” parameter is 2. Accordingly, the actual default gear ratio becomes 1.00.

Codes
–15–
 Speed increasing ratio
Description Set the speed increasing ratio relative to the rotating speed of the motor output shaft. The speed
increasing ratio is used for “operating speed” under the monitor function.
Setting (write) 2303h
Check (read) 1303h
Setting range 1 to 5 (setting unit: 1)
Initial value 1
Note If both the gear ratio (speed reducing ratio) and speed increasing ratio are set, the speed increasing ratio
will be given priority. If the speed increasing ratio is 1, the speed does not increase and consequently the
speed increasing ratio will be ignored. In this case, the operating speed output by the monitor function
corresponds to the output data calculated by the set value of the“gear ratio”parameter. See “7 Monitor
function”on p.27 for details on monitor function.
 Conveyor gear ratio
Description
Set the numerical part of the conveyor gear ratio relative to the rotating speed of the motor output
shaft. The conveyor gear ratio is used for“conveyor transfer speed” under the monitor function. Also
set the “conveyor gear ratio digit specication” parameter.
Setting (write) 2305h
Check (read) 1305h
Setting range 100 to 9999 (setting unit: 1)
Initial value 100
Note
•The default value of the “conveyor gear ratio” parameter is 100, while the default value of the“conveyor
gear ratio digit specication”parameter is 2. Accordingly, the actual default conveyor gear ratio becomes
1.00.
•If both the conveyor gear ratio (conveyor speed reducing ratio) and conveyor speed increasing ratio are
set, the conveyor speed increasing ratio will be given priority. If the conveyor speed increasing ratio is 1,
the speed does not increase and consequently the conveyor speed increasing ratio will be ignored. In
this case, the conveyor transfer speed output by the monitor function corresponds to the output data
calculated by the set value of the“conveyor gear ratio”parameter. See “7 Monitor function”on p.27 for
details on monitor function.
 Conveyor gear ratio digit specication
Description Set the position of the decimal point in the set value of the “conveyor gear ratio”parameter.
Setting (write) 2306h
Check (read) 1306h
Setting range
0 (No decimal point)
1 (1 decimal place)
2 (2 decimal places)
Initial value 2 (2 decimal places)
Note The default value of the “conveyor gear ratio” parameter is 100, while the default value of the“conveyor
gear ratio digit specication”parameter is 2. Accordingly, the actual default conveyor gear ratio becomes
1.00.

Codes
–16–
 Conveyor speed increasing ratio
Description Set the conveyor speed increasing ratio relative to the rotating speed of the motor output shaft. The
conveyor speed increasing ratio is used for “operating speed”under the monitor function.
Setting (write) 2307h
Check (read) 1307h
Setting range 1 to 5 (setting unit: 1)
Initial value 1
Note If both the conveyor gear ratio (conveyor speed reducing ratio) and conveyor speed increasing ratio are
set, the conveyor speed increasing ratio will be given priority. If the conveyor speed increasing ratio is 1,
the speed does not increase and consequently the conveyor speed increasing ratio will be ignored. In
this case, the conveyor transfer speed output by the monitor function corresponds to the output data
calculated by the set value of the“conveyor gear ratio”parameter. See “7 Monitor function”on p.27 for
details on monitor function.
 Overload warning level
Description Set the detection level (load factor) of the overload warning function. See “Load factor” on p.29 for
details on the load factor.
Setting (write) 2110h
Check (read) 1110h
Setting range 50 to 100% (setting unit:1%)
Initial value 100%
 Overload warning function
Description Enable/disable the overload warning function.
Setting (write) 2111h
Check (read) 1111h
Setting range 0 (disable)
1 (enable)
Initial value 0 (disable)

Codes
–17–
 General input
Description Set the function to assign to each of user I/Os X0 to X3 inputs.
Setting (write) 4500h to 4503h
Check (read) 3500h to 3503h
Setting range 0 to 8 (See the correspondence table below.)
Initial value
General input 0 (X0 input): 1 (FWD)
General input 1 (X1 input): 2 (REV)
General input 2 (X2 input): 6 (STOP-MODE)
General input 3 (X3 input): 7 (ALARM-RESET)
•Correspondence table of general inputs
Setting value Function Name Reference page
0 None − −
1 FWD Forward input P. 4
2 REV Reverse input P. 4
3 M0 Data selection input 0 P. 5
4 M1 Data selection input 1 P. 5
5 M2 Data selection input 2 P. 5
6 STOP-MODE Stop mode selection input P. 5
7 ALARM-RESET Alarm reset input P. 6
8 EXT-ERROR External error signal input (normally closed) See below.
Note
•When an attempt is made to set up during operation (when the MOVE output is ON), a response code
(RWrn2) will cause a runtime error (0001h), disabling setup.
•If the input signal at the assigned destination is ON when the FWD input or REV input is assigned, an
operation prohibited warning will be generated. See“9.2 Driver warning”on p.34 for details on the
warnings.
•If duplicate functions are assigned, priority will be given in the order of X0>X1>X2>X3, and others will
be ignored.
•EXT-ERROR
The EXT-ERROR input is an input signal that can be used only as a user I/O.
Since the EXT-ERROR input is a normally closed signal, it should normally remain ON. An external stop alarm can be
generated by turning the EXT-ERROR input OFF. When this input turns OFF, the motor will stop instantaneously.
EXT-ERROR input
ON
OFF
ON
OFF
(Driver to master) ALARM-
OUT1 output
Instantaneous stop
Motor movement
Stop
Note If the EXT-ERROR input is assigned to a user I/O, the EXT-ERROR input can be used even when the remote I/
O mode is selected by the “input selection” parameter (p.14).

Codes
–18–
 General output
Description Set the function to assign to each of user I/Os Y0 and Y1 outputs.
Setting (write) 4600h to 4601h
Check (read) 3600h to 3601h
Setting range 0 to 5 (See the correspondence table below.)
Initial value General output 0 (Y0 output): 1 (MOVE)
General output 1 (Y1 output): 5 (ALARM-OUT1)
•Correspondence table of general outputs
Setting value Function Name Reference page
0 None − −
1 MOVE Motor running output P. 7
2VA Speed attained output P. 7
3 ALARM-OUT2 Alarm output 2 P. 7
4 WNG Warning output P. 7
5 ALARM-OUT1 Alarm output 1 P. 8
4.4 Read-only code
 Alarm history
Description
Up to 10 recent alarms can be checked. Alarms are output as alarm codes.
Two alarms can be checked at a time. The upper byte indicates the newer alarm, while the lower byte
indicates the older alarm.
Upper 1 byte
Alarm history 0Alarm history 1
Lower 1 byte
Read command code: 0074h

Alarm history 2Alarm history 3
Read command code: 0075h

Alarm history 4Alarm history 5
Read command code: 0076h

Alarm history 6Alarm history 7
Read command code: 0077h

Alarm history 8Alarm history 9
Read command code: 0078h

+
+
+
+
+
00h 00h
Check (read) 0074h to 0078h
 Warning history
Description
Up to 10 recent warnings can be checked. Warnings are output as warning codes.
Two warnings can be checked at a time. The upper byte indicates the newer warning, while the lower
byte indicates the older warning.
Upper 1 byte
Warning history 0Warning history 1
Lower 1 byte
Read command code: 1100h

Warning history 2Warning history 3
Read command code: 1101h

Warning history 4Warning history 5
Read command code: 1102h

Warning history 6Warning history 7
Read command code: 1103h

Warning history 8Warning history 9
Read command code: 1104h

+
+
+
+
+
00h 00h
Check (read) 1100h to 1104h

Codes
–19–
 Decimal position in operating speed
Description
Check the decimal position in the data output as “operating speed”under the monitor function. The
decimal position changes automatically according to the setting of the “gear ratio”parameter and “gear
ratio digit specication”parameter.
Check (read) 1300h
Output range
0: No decimal point
1: 1 decimal place
2: 2 decimal places
3: 3 decimal places
 Decimal position in conveyor transfer speed
Description
Check the decimal position in the data output as “conveyor transfer speed” under the monitor
function. The decimal position changes automatically according to the setting of the “conveyor gear
ratio” parameter and “conveyor gear ratio digit specication” parameter.
Check (read) 1304h
Output range
0: No decimal point
1: 1 decimal place
2: 2 decimal places
3: 3 decimal places
4.5 Special code
The special codes are used to handle the data saved in the EEPROM. See “5.1 Data save area”on p.21 for the
EEPROM.
Note The EEPROM can be rewritten approx. 100,000 times. Avoid situations where the EEPROM will be written
frequently.
 Read/Write the main rotating speed
Set the rotating speed for the operation data selected by the M0 to M2 inputs.
While the operation data read/write code “rotating speed” directly sets the rotating speed of the specied operation
data, the special code sets the rotating speed of the operation data selected by the M0 to M2 inputs.
Also, either the RAM or EEPROM can be specied as the area to save the rotating speed.
•Saving to the RAM
Setting (write) 00EDh
Check (read) 006Dh
Setting range 0 r/min and 80 to 4000 r/min (setting unit: 1 r/min)
Initial value 0 r/min
•Saving to the EEPROM
Setting (write) 00EEh
Check (read) 006Eh
Setting range 0 r/min and 80 to 4000 r/min (setting unit: 1 r/min)
Initial value 0 r/min
Note To prevent inconsistency between the EEPROM data and RAM data, the data read from the EEPROM is also
overwritten to the RAM.
 Clear the alarm history
When the alarm history clear data is stored in the “write data” remote register (RWwn3) and a command code is
executed, the alarm history can be cleared.
Description Clear the entire alarm history.
Clear the history 00F4h
Data 9696h

Codes
–20–
 Initializing the parameters
When the parameter initialization data is stored in the “write data”remote register (RWwn3) and a command code is
executed, the parameters can be initialized.
Description Revert all writable parameters to their default values.
Initializing the parameters 00FCh
Data 9696h
Note If an attempt is made to initialize during operation (when the MOVE output is ON), a response code (RWrn2)
will cause a runtime error (0001h), disabling initialization.
 Read the EEPROM all at once
When the EEPROM all read data is stored in the “write data” remote register (RWwn3) and a command code is
executed, the parameters will be read from the EEPROM.
Description Read all writable parameters at once from the EEPROM to the RAM. The parameters in the
RAM are overwritten by the corresponding parameters read from the EEPROM.
Read the EEPROM all at once 2F00h
Data 1
Note If an attempt is made to read during operation (when the MOVE output is ON), a response code (RWrn2)
will cause a runtime error (0001h), disabling reading.
 Write the EEPROM all at once
When the EEPROM all write data is stored in the“write data”remote register (RWwn3) and a command code is
executed, the parameters will be written to the EEPROM.
Description Write all writable parameters at once from the RAM to the EEPROM.
Write the EEPROM all at once 2F01h
Data 1
