Oriental motor KIIS Series User manual

1
Introduction
 Before using the motor
Only qualied and educated personnel should work with the product.
Use the product correctly after thoroughly reading the section "Safety
precautions." Should you require the inspection or repair of internal parts,
contact the Oriental Motor ofce where you purchased the product.
The product described in this manual has been designed and manufactured
to be incorporated in general industrial equipment. Do not use for any other
purpose. Oriental Motor Co., Ltd. is not responsible for any damage caused
through failure to observe this warning.
 Standard and CE Marking
 This product is recognized by UL under the UL and CSA standards.
Also, it conforms to the China Compulsory Certication System (CCC System).
The motor model name is the recognized product name.
 The motor is afxed the CE Marking under the Low Voltage Directive.
Refer to p.4 for details.
 Hazardous substances
The products do not contain the substances exceeding the restriction values of
RoHS Directive (2011/65/EU).
Safety precautions
The precautions described below are intended to prevent danger or injury to
the user and other personnel through safe, correct use of the product. Use the
product only after carefully reading and fully understanding these instructions.
Warning
Handling the product without observing the instructions that accompany a
"Warning" symbol may result in serious injury or death.
 Do not use the product in explosive or corrosive environments, in the presence
of ammable gases, or near combustibles. Doing so may result in re, electric
shock or injury.
 Only qualied and educated personnel should be allowed to perform
installation, connection, operation and inspection/troubleshooting of the
product. Handling by unqualied and uneducated personnel may result in re,
electric shock, injury or equipment damage.
 Do not transport, install the product, perform connections or inspections
when the power is on. Always turn the power off before carrying out these
operations. Failure to do so may result in electric shock.
 The motor is Class І equipment. Install the motor so as to avoid contact with
hands, or ground it to prevent the risk of electric shock.
 Keep the input power voltage within the specied range. Failure to do so may
result in re or electric shock.
 Securely connect the cables in accordance with the connection examples.
Failure to do so may result in re or electric shock.
 Do not forcibly bend, pull or pinch the read wire (cable). Doing so may result in
re and electric shock.
 Turn off the power in the event of a power failure. Or the motor may suddenly
start when the power is restored and may cause injury or damage to
equipment.
 Do not disassemble or modify the motor. This may cause electric shock or
injury.
Caution
Handling the product without observing the instructions that accompany a
"Caution" symbol may result in injury or property damage.
 Do not use the motor beyond its specications. Doing so may result in electric
shock, injury or damage to equipment.
 Do not touch the motor during operation or immediately after stopping. The
surface is hot and may cause a skin burn(s).
 Do not lift the motor by holding the motor output shaft or motor lead wires.
Doing so may result in injury.
 Keep the area around the motor free of combustible materials. Failure to do so
may result in re or a skin burn(s).
 Do not leave anything around the motor that would obstruct ventilation. Doing so
may result in damage to equipment.
 The motor does not have a built-in overheat protection device. Provide an
overload protection device externally.
 Do not touch the rotating part (output shaft) while operating the motor. Doing
so may result in injury.
 When an abnormality is noted, turn off the power immediately. Failure to do so
may result in re, electrical shock or injury.
 The motor surface temperature may exceed 70 °C (158 °F)
even under normal operating conditions. If the operator is
allowed to approach the running motor, attach a warning
label as shown in the gure in a conspicuous position.
Failure to do so may result in a skin burn(s). Warning label
 To dispose of the motor, disassemble it into parts and components as much as
possible and dispose of individual parts/components as industrial waste.
Preparation
 Checking the product
Verify that the items listed below are included. Report any missing or damaged
items to the branch or sales ofce from which you purchased the product.
 Motor ................................................. 1 unit
This product comes with the motor and its dedicated gearhead pre-assembled.
 Hexagonal socket head screw set ..... 1 set
Hexagonal socket head screws, washers, spring washers 4 pieces each,
parallel key 1 piece
 OPERATING MANUAL ...................... 1 copy (this document)
 Checking the model name
Check the model number against the number indicated on the product.
Enter the gear ratio in the box () within the model name.
 Terminal box type
Model Motor model Gearhead model
5IK60VEST2-A5IK60VGVH-EST2 5GVHA
5IK100VEST2-A5IK100VGVR-EST2 5GVRA
 Lead wire type
Model Motor model Gearhead model
5IK60VES-A5IK60VGVH-ES 5GVHA
5IK100VES-A5IK100VGVR-ES 5GVRA
Installation
 Location for installation
Install it in a well-ventilated location that provides easy access for inspection.
[ Common conditions ]
 Operating ambient temperature −10 to +40 °C (+14 to +104 °F) (non-freezing)
 Operating ambient humidity 85%, maximum (non-condensing)
 Area that is free from an explosive atmosphere or toxic gas (such as sulfuric
gas) or liquid
 Area not exposed to direct sun
 Area free of excessive amount dust, iron particles or the like
 Area free of excessive salt
 Area not subject to continuous vibration or excessive shocks
 Area free of excessive electromagnetic noise (from welders, power machinery,
etc.)
 Area free of radioactive materials, magnetic elds or vacuum
 Altitude Up to 1000 m (3300 ft.) above sea level
HM-9343-3
O P E R AT I N G M A N U A L Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety
precautions.
 Please read it thoroughly to ensure safe operation.
 Always keep the manual where it is readily available.
KⅡS Series Induction Motor
Three-phase 220/230 V type

2
[ Terminal box type ]
 Indoors
 Not exposed to oil (oil droplets) or chemicals.
The motor can be used in an environment that is splashed with water.
Not available for use under high pressure jets of water or immersion in water.
[ Lead wire type ]
 Inside an enclosure that is installed indoors (provide vent holes)
 Area not subject to splashing water (storms, water droplets), oil (oil droplets) or
other liquids
Note On rare occasions, a small amount of grease may ooze out from the
gearhead. If there is a concern over possible environmental damage
resulting from the leakage of grease, provide an oil tray or similar
oil catching mechanism in order not to cause a secondary damage.
Oil leakage may lead to problems in the customer’s equipment or
products.
 How to install the motor
Secure the motor with hexagonal socket head screws (supplied) through the four
mounting holes provided. Do not leave a gap between the motor and mounting
plate.
Hexagonal
socket head
screw
Supplied
Motor
Gearhead
Mounting plate
Spring
washer
Washer L2
MotorGearhead
L1
Hexagonal socket head screw set (supplied)
Gearhead
model Gear ratio
Hexagonal socket head screws
Material: Stainless steel Tightening
torque
Screw size L1
[mm (in.)]
L2
[mm (in.)]
5GVHA
5 to 18
5/16-
18UNC
69.9 (2.75) 14 (0.55)
12 N·m
(106 lb-in)
25 to 100 82.6 (3.25) 13 (0.51)
120 to 300 88.9 (3.5) 14 (0.55)
5GVRA
5 to 15 69.9 (2.75) 14 (0.55)
18 to 36 82.6 (3.25) 13 (0.51)
50 to 180 95.3 (3.75) 14 (0.55)
 Installing a load
The gearhead shaft is provided with a key slot
for connecting the transmission parts. When
connecting the transmission parts, ensure that
the shaft and parts have a clearance t, and
always x the parallel key to the output shaft
with a screw to prevent the parts from rattling
or spinning.
Screw
Parallel key
Gearhead
output shaft
Note Do not apply excessive force onto the output shaft of the gearhead
using a hammer or other tools. Doing so may cause damage to the
output shaft or bearings.
When using the output shaft end tapped hole of a gearhead
Use a tapped hole provided at the end of
the output shaft as an auxiliary means for
preventing the transfer mechanism from
disengaging.
Output shaft end tapped hole: No.12-24 UNC,
Effective depth 12 mm (0.47 in.)
Fixed screw
Screw
Spacer
Transmission
parts
 Removing/Installing the gearhead
 Removing the gearhead from the motor
Remove the gearhead by unscrewing the hexagonal socket head screws holding
the gearhead to the motor (2 locations).
Hexagonal socket head screw
(2 locations)
Screw size: M3
Tightening torque: 0.6 N·m (5.3 lb-in)
Illustration shows the view from motor case side.
 Installing a gearhead to a motor
Using the pilot sections of the motor and gearhead as guides, slowly rotate it
clockwise/counterclockwise to prevent the pinion of the motor output shaft from
contacting the side panel or gear of the gearhead.
Also conrm that no gaps remain
between the motor and gearhead.
An O-ring is attached to the ange of
the motor. Do not pinch the O-ring when
assembling the motor and gearhead.
Pinching the O-ring causes a grease leak
from the gearhead.
Pinion of the motor
output shaft
Pilot section
Flange
Gearhead
Motor
Note Do not forcibly assemble the motor and gearhead. Also, do not let
metal objects or other foreign matters enter the gearhead. The pinion
or gear of the motor output shaft may be damaged, resulting in noise
or shorter service life.
Connection and operation
 Insulate the connecting part of the motor lead wires and power supply.
 Ground the motor using a Protective Earth Terminal.
Note Make sure that the motor case temperature does not exceed 90 °C
(194 °F) when operating the motor. Operation exceeding case
temperature 90 °C (194 °F) may signicantly deteriorate the coils
and ball bearings of the motor and shorten the motor's life span.
Motor case temperature can be measured by xing a thermometer
on the motor surface. It can also be measured using thermo tape or a
thermocouple.
 Terminal box type

zConnection method to a terminal box
Connection procedure
1.
Loosen the terminal cover mounting screws, and remove the terminal cover
from the terminal box.
2.
Insert the cable through the cable gland, and connect the lead wires to the
terminal block.
Connect the grounding lead wire to the Protective Earth Terminal.
3.
Install the terminal cover on the terminal box.
Terminal cover
Terminal cover mounting screw
(M4-4 pcs.)
Tightening torque:
1.0 to 1.5 N·m (8.8 to 13.2 lb-in)
Terminal box
Cable gland
Insert the cable through the cable gland
When inserting the cable
through the cable gland, loosen
the tightening nut.
After connecting to the terminal
block, turn the tightening nut to
secure the cable. Nipple
[2.0 to 2.5 N·m (17.7 to 22 lb-in)]
Tightening nut
[2.0 to 2.5 N·m (17.7 to 22 lb-in)]
[ ] indicates the value of the tightening torque.
Connection method to a terminal block
 When connecting to the terminal block, use the following crimp terminal.
Round terminal with insulated coating
[Unit: mm (in.)]
Ø4.3 (0.17) or more
18 (0.71) or less
8 (0.31)
or less
 To ensure safety, ground the motor using the Protective Earth Terminal
inside the terminal box.
 Layout of terminals
U, V and W are indicated on the side face of the terminal block.
U V WNC NC
[ ] indicates the value of the tightening torque.
Terminal block (M4)
[1.0 to 1.2 N·m (8.8 to 10.6 lb-in)]
Protective Earth Terminal (M4)
[1.0 to 1.5 N·m (8.8 to 13.2 lb-in)]

3
 Use a cable of the following specications.
Applicable cable diameter: Ø7 to Ø13 mm (Ø0.28 to Ø0.51 in.)
Applicable lead wire: AWG18 (0.75 mm2) or thicker
Connection cables are available as accessories. Refer to the product catalog
for details.
 Although the O-ring that is set to the matching surface of the terminal cover
is a structure not to fall off easily, install it in the groove portion of the terminal
cover securely if it fell off.
Note  To make shielding function fully effective, use a cable of an appropriate
diameter and observe the specied tightening torque of screws.
 Secure the cable drawn from the motor terminal box so that it does not
receive stress.

zChanging the cable outlet position
The cable outlet position can be changed to the left or right 90-degree direction,
or the 180-degree direction by changing the mounting direction of the terminal
box.
When changing the mounting direction of the terminal box, specify the cable
outlet position based on the equipment to be installed.
Change procedure
1.
Loosen the terminal cover mounting screws, and remove the terminal cover
from the terminal box.
2.
Loosen the terminal box mounting screws, and remove the terminal box from
the terminal block base.
Terminal box mounting screw
(M4-4 pcs.)
Tightening torque:
1.0 to 1.5 N·m (8.8 to 13.2 lb-in)
3.
Change the cable outlet position of the terminal box from the mounting
position at the time of shipment by turning the terminal box itself to the left or
right 90-degree direction, or the 180-degree direction.
3
4
Terminal block base
Cable gland
Terminal block
Terminal box
Gasket
Cutout in the gasket
4.
Remove the gasket being installed under the terminal box.
Change the direction of the gasket, and install it under the terminal box.
Direction of gasket
There is a cutout in the gasket.
Install the gasket with facing the cutout to the motor side (opposite the output
shaft side) as shown in the gure.
Assemble not to enter any foreign object between the terminal box and
terminal block base.
 Lead wire type

zConnecting Protective Earth Terminal
Ground the motor using the Protective Earth Terminal on the motor.
Applicable crimp terminal:
Insulated round crimp terminal
Terminal screw size: M4
Tightening torque:
1.0 to 1.3 N·m (8.8 to 11.5 lb-in)
Applicable lead wire:
AWG18 (0.75 mm2) or thicker
Ø4.1 (0.16) or more
4.8 (0.19) or less
9.5 (0.37)
or less
[ Unit: mm (in.) ]
Note Do not use screws other than the Protective Earth Terminal screw
attached on the product.
 Wiring diagram
Note In order to prevent the motor from burning out for when the
output shaft is locked or in the case of an overload state, use an
electromagnetic switch.
 See the p.4 for the electromagnetic switches.
 Check the output power and gear ratio of the motor before connecting.
The rotation direction of the output shaft varies depending on the gear ratio of
the gearhead. When connecting as the "Wiring diagram," the motor rotates in
the direction as shown below.
60 W Gear ratio 5 to 18
 120 to 300 60 W Gear ratio 25 to 100
100 W Gear ratio 5 to 15
 75 to 180 100 W Gear ratio 18 to 60
[Clockwise]
CW
[Counterclockwise]
CCW
The gure represents the rotation direction viewed from the output shaft.
The rotation in the clockwise direction represents "CW" and the rotation in the
counterclockwise direction represents "CCW."
Wiring diagram
Terminal box type
U
V
W
PE
Motor
R0C0
R0C0
R0C0
L2(S)
L3(T)
L1(R)
To change the direction of rotation, change any two connections
between R, S and T.
Lead wire type
Red
White
Black PE
Motor
R0C0
R0C0
R0C0
L2(S)
L3(T)
L1(R)
To change the direction of rotation, change any two connections
between R, S and T.
[ Electromagnetic switch ]
Thermal
relay
Electromagnetic
contactor
[ Surge voltage measures ]
Connect the CR circuit for surge
suppression ( ).
R0=5 to 200 
C0=0.1 to 0.2 μF 250 WV
It is provided as an accessory
(sold separately).

4
 Unauthorized reproduction or copying of all or part of this manual is
prohibited.
 Oriental Motor shall not be liable whatsoever for any problems relating
to industrial property rights arising from use of any information, circuit,
equipment or device provided or referenced in this manual.
 Characteristics, specications and dimensions are subject to change without
notice.
 is a registered trademark or trademark of Oriental Motor
Co.,Ltd., in Japan and other countries.
© Copyright ORIENTAL MOTOR CO., LTD. 2014
Technical Support Tel:[phone]
8:30 A.M. to 5:00 P.M., P.S.T. (M-F)
7:30 A.M. to 5:00 P.M., C.S.T. (M-F)
www.orientalmotor.com
Schiessstraße 74, 40549 Düsseldorf, Germany
Technical Support Tel:[phone]
www.orientalmotor.de
Tel:[phone]
www.oriental-motor.co.uk
Tel:[phone]
www.orientalmotor.fr
Tel:[phone]
www.orientalmotor.it
Tel:[phone]
www.orientalmotor.com.br
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno,Taito-ku,Tokyo 110-8536
Japan
Tel:[phone]
www.orientalmotor.co.jp
Tel:[phone]
www.orientalmotor.com.tw
Singapore
Tel:[phone]
www.orientalmotor.com.sg
Tel:[phone]
www.orientalmotor.com.my
Korea
Tel:[phone]
www.inaom.co.kr
Tel:[phone]
www.orientalmotor.co.th
Tel:[phone]
www.orientalmotor.com.cn
Tel:[phone]
www.orientalmotor.co.in
Hong Kong Branch
Tel:[phone]
Burnout protection for overload/locked-rotor state
Note In order to prevent the motor from burning out for when the
output shaft is locked or in the case of an overload state, use an
electromagnetic switch.
When connecting to an inverter, use the electronic thermal relay
function of the inverter.
 When connecting to the power supply
 Always connect an electromagnetic switch.
Connect the electromagnetic switch according to the operating manual of the
electromagnetic switch.
 Set the motor rated current for the thermal relay.
The motor rated current is described on the motor nameplate.
 For electromagnetic switches, use the products as shown in the chart, or an
equivalent.
[ Fuji Electric FA Components & Systems Co., Ltd. ]
 For motor output power 60 W Model: SC11AAN-10TF
 For motor output power 100 W Model: SC11AAN-10TH
(: Coil code)
Coil code 50 Hz 60 Hz
2 200 V 200-220 V
M 200-220 V 220-240 V
P 220-240 V 240-260 V
Use the product which satises the motor rated voltage by selecting the coil
code.
[ Mitsubishi Electric Corporation ]
 For motor output power 60 W Model: MSO-T10 0.35A 200V AC200V
 For motor output power 100 W Model: MSO-T10 0.5A 200V AC200V
 When connecting to the inverter
Be sure to set the electronic thermal relay according to the operating manual of
the inverter. Unless the electronic thermal relay is set, a burnout may result.
When using the motor with an inverter
When the motor is used with connecting an inverter, perform the following
settings to the inverter.
When driving the inverter, use it at the setting frequency 120 Hz or lower.
 Setting for motor
Electronic thermal relay function
Set the rated current listed on the motor
nameplate based on the base frequency
and the voltage applied to the motor.
Applicable motor setting Constant-torque motor or inverter motor
Motor capacity
Motor rated output power
If the setting value in the inverter does not
exist, set the closest value.
Number of motor poles 4 poles
 Notes about when using the motor with an inverter
The inverter which input voltage exceeds 240 VAC cannot be used.
The insulation of the motor winding may deteriorate, causing damage to the
motor.
Time rating
Continuous operation is possible (continuous rating).
Troubleshooting
When the motor cannot be operated correctly, refer to the contents provided in
this section and take appropriate action. If the problem persists, contact your
nearest ofce.
Phenomena Check items
Motor does not rotate.
Motor sometimes
rotates and stops.
 Check the power supply voltage.
 Connect the power supply and the motor correctly.
 If terminal blocks or crimp terminals are used, check
them for poor connection.
 Keep the load at or below the allowable value.
The motor rotates in
the direction opposite
to the specied
direction.
 The connection varies depending on the gear ratio of
the gearhead.
 The rotation direction is as viewed from the output
shaft end. Check the reference direction.
Motor temperature
abnormally high.
[Motor case
temperature exceeds
90 °C (194 °F)]
 Check the power supply voltage.
 Review the ventilation condition.
Noisy operation. Check whether the combination of the motor and
gearhead is correct. (Refer to p.1 for the combinations)
Standard and CE Marking
 This product is recognized by UL under the UL and CSA standards.
Also, it conforms to the China Compulsory Certication System (CCC System).
The motor model name is the recognized product name.
 The motor is afxed the CE Marking under the Low Voltage Directive.
 UL Standards, CSA Standards, CCC System
Applications standards Certication Body / File No.
UL 1004-1 UL /
UL File No.E62327
CSA C22.2 No.100
GB 12350 CQC
 Thermal Class: 130 (B)
 CE Marking
 Applications standards
EN 60034-1, EN 60034-5, EN 60664-1
 Installation conditions (For EN standard)
Terminal box type: Overvoltage category ІІ, Pollution degree 3, Class І equipment
Lead wire type: Overvoltage category ІІ, Pollution degree 2, Class І equipment
When the machinery to which the motor is mounted requires overvoltage
category ІІІ specications, install the motor in a cabinet that connect to power
supply via an isolation transformer.
Temperature rise tests required by the above standards are performed in a
state that has been attached a heat radiation plate instead of a gearhead.
The size and material for the heat radiation plates are as follows.
Size: 200×200 mm (7.87×7.87 in.)
Thickness: 5 mm (0.20 in.) Material: Aluminum alloy
