Oriental motor BLV Series User manual

1
Introduction
Before using the product
Only qualied personnel of electrical and mechanical engineering should work with the
product. Use the product correctly after thoroughly reading the "Safety precautions." In
addition, be sure to observe the contents described in warning, caution, and note in this
manual.
The product described in this document has been designed and manufactured to be
incorporated in general industrial equipment. Do not use for any other purpose. For
the power supply, use a DC power supply with reinforced insulation on its primary and
secondary sides. Oriental Motor Co., Ltd. is not responsible for any damage caused through
failure to observe this warning.
Related operating manuals
For operating manuals not included with the product, contact your nearest Oriental Motor
sales oce or download from Oriental Motor Website Download Page.
Operating manual name Operating
manual number
Included or not
included with product
OPERATING MANUAL (This document) HM-5112 Included
USER MANUAL (Basic Function) HM-5113 Not included
USER MANUAL (RS-485 Communication Mode) HM-5114 Not included
Data setter OPX-2A HP-5049 Not included
Network Converter Slave Edition HP-5065 Not included
Safety precautions
The precautions described below are intended to prevent danger or injury to the user
and other personnel through safe, correct use of the product. Use the product only after
carefully reading and fully understanding these instructions.
WARNING
Handling the product without observing the instructions that
accompany a "WARNING" symbol may result in serious injury
or death.
CAUTION
Handling the product without observing the instructions
that accompany a "CAUTION" symbol may result in injury or
property damage.
Note
The items under this heading contain important handling
instructions that the user should observe to ensure safe use
of the product.
Description
of graphic
symbols
: Indicates "prohibited" actions that must not be performed.
: Indicates "compulsory" actions that must be performed.
WARNING
Do not use the product in explosive or corrosive environments, in the
presence of ammable gases, locations subjected to splashing water, or near
combustibles. Doing so may result in re, electric shock or injury.
Do not transport, install the product, perform connections or inspections
when the power is on. Always turn the power o before carrying out these
operations. Doing so may result in electric shock or damage to equipment.
Do not use a standard type product in vertical drive such as elevating
equipment. If the driver’s protection function is activated, the motor will stop
and the moving part may drop, thereby causing injury or equipment damage.
Do not use the brake mechanism of the motor with electromagnetic brake as a
safety brake. It is intended to hold the movable parts and motor position. This
caution is to avoid personal injury or damage to the equipment.
Do not forcibly bend, pull or pinch the cable. Doing so may result in re,
electric shock or damage to equipment.
Do not machine or modify the motor cable or connection cable. Doing so may
result in re, electric shock or damage to equipment.
Do not touch the motor or driver when conducting the insulation resistance
measurement or dielectric strength test. Accidental contact may result in
electric shock.
Do not disassemble or modify the motor, gearhead and driver. Doing so may
result in injury or damage to equipment. Refer all such internal inspections and
repairs to the branch or sales oce from which you purchased the product.
WARNING
Only qualied and educated personnel should be allowed to perform
installation, connection, operation and inspection/troubleshooting of the
product. Handling by unqualied and uneducated personnel may result in re,
electric shock, injury or equipment damage.
When the driver's protection function is triggered, rst remove the cause and
then clear the protection function. Continuing the operation without removing
the cause of the problem may cause malfunction of the motor and driver,
leading to injury or damage to equipment.
Install the motor, gearhead and driver in an enclosure. Failure to do so may
result in electric shock or injury.
Keep the driver's input-power voltage within the specied range to avoid re
or electric shock.
For the power supply, use a DC power supply with reinforced insulation on its
primary and secondary sides. Failure to do so may cause electric shock.
Securely connect the cables in accordance with the connection examples.
Failure to do so may result in re or electric shock.
Be sure to observe the specied cable sizes. Use of unspecied cable sizes may
result in re or electric shock.
Observe the specied screw tightening torque when connecting terminals to
the connector. Failure to do so may result in re or equipment damage.
Use a motor, gearhead, and driver only in the specied combination. Failure to
do so may result in re, electric shock or damage to equipment.
When the electromagnetic brake motor is used in an application of vertical
drive such as elevating equipment, operate it after checking the condition of a
load suciently so that a load in excess of the rated torque is not applied or a
small value is not set in the torque limiting value. Failure to do so may result in
injury or damage to equipment.
Always turn o the power before performing maintenance/inspection. Failure
to do so may result in injury.
Regularly check the openings in the driver for accumulated dust. Accumulated
dust may cause re.
CAUTION
Do not use the motor, gearhead and driver beyond the specications. Doing so
may result in electric shock, injury or damage to equipment.
Keep your ngers and objects out of the openings in the driver, or re, electric
shock or injury may result.
Do not touch the motor, gearhead or driver while operating or immediately
after stopping. The surface of the motor, gearhead or driver may be hot and
cause a skin burn(s).
To prevent the risk of damage to equipment, leave nothing around the motor
and driver that would obstruct ventilation.
Do not hold the output shaft of the motor and gearhead, as well as any of the
cables. Doing so may result in injury.
Do not touch the motor output shaft (key groove or pinion) with bare hands.
Doing so may result in injury.
When assembling the motor with the gearhead, exercise caution not to pinch
your ngers or other parts of your body between the motor and gearhead.
Injury may result.
When installing the motor or gearhead in the equipment, exercise caution not
to pinch your ngers or other parts of your body between the equipment and
motor or gearhead. Injury may result.
Do not shut o the negative side of the power supply during operation. Also,
note that the wiring for the power supply does not disconnect. Doing so may
cause damage to equipment.
Do not touch the rotating part (output shaft) during operation. This may cause
injury.
Securely install the motor, gearhead and driver to their respective mounting
plates. Inappropriate installation may cause the motor, gearhead or driver to
detach and fall, resulting in injury or equipment damage.
Provide a cover over the rotating part (output shaft) of the motor or gearhead.
Failure to do so may result in injury.
Securely install the load on the output shaft of the motor or gearhead.
Inappropriate installation may result in injury.
Provide an emergency stop device or emergency stop circuit external to the
equipment so that the entire equipment will operate safely in the event of a
system failure or malfunction. Failure to do so may result in injury.
Immediately when trouble has occurred, stop operation and turn o the driver
power. Failure to do so may result in re, electric shock or injury.
The motor surface temperature may exceed 70 °C (158 °F) even
under normal operating conditions. If the operator is allowed
to approach the motor in operation, attach a warning label in
a conspicuous position as shown in the gure. Failure to do so
may result in a skin burn(s). Warning label
Dispose the product correctly in accordance with laws and regulations, or
instructions of local governments.
HM-5112-7
OPERATING MANUAL Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety precautions.
Please read it thoroughly to ensure safe operation.
Always keep the manual where it is readily available.
Brushless Motor and Driver Package
BLV Series

2
Precautions for use
zRegeneration energy
When using the motor in operation such as vertical drive (gravitational operation) or
sudden starting/stopping of an inertial load, regeneration energy may generate. Since
the driver has no function to consume regeneration energy, if the output capacity or
overvoltage allowance of the DC power supply is small, the protective function for
the power supply or driver may activate, and the motor may stop. When performing
these operations, use a DC power supply or battery that has a large output capacity or
overvoltage allowance.
Also, use an electromagnetic brake motor not to drop the moving part in vertical drive
(gravitational operation).
If the protective function for the power supply or driver is activated, contact your nearest
Oriental Motor sales oce.
zDo not conduct the insulation resistance measurement or dielectric
strength test with the motor and driver connected
Conducting the insulation resistance measurement or dielectric strength test with the
motor and driver connected may result in damage to the product.
zDo not use a solid-state relay (SSR) to turn on/o the power
A circuit that turns on/o the power via a solid-state relay (SSR) may damage the motor
and driver.
zNotes for power ON/OFF using a mechanical contact
When turning on or o the power supply using a mechanical contact (breaker,
electromagnetic switch, relay, etc.), do so only the positive side (+) of the power supply
using the mechanical contact. Turning on or o the positive side (+) and the negative side (-)
of the power supply simultaneously using a mechanical contact may cause damage to the
control circuit or peripheral equipment.
Refer to USER MANUAL (Basic Function) for details.
zNote on connecting a power supply whose positive terminal is grounded
The driver's main power supply input terminal (CN1), I/O signal connector (CN4),
communication connector (CN5/CN6/CN7) and control power supply input terminal (TB1)
are not electrically insulated.
When grounding the positive terminal of the power supply, do not connect any equipment
(PC, etc.) whose negative terminal is grounded. Doing so may cause the driver and these
equipment to short, damaging both.
zPreventing electrical noise
Refer to USER MANUAL (Basic Function) for measures with regard to noise.
zGrease measures
On rare occasions, grease may ooze out from the gearhead. If there is concern over
possible environmental damage resulting from the leakage of grease, check for grease
stains during regular inspections.
Alternatively, install an oil pan or other device to prevent leakage from causing further
damage. Oil leakage may lead to problems in the customer’s equipment or products.
zNote on using in low temperature environment
When an ambient temperature is low, a load torque may increase due to the oil seal
or viscosity of grease used in the gearhead, and the output torque may decrease or an
overload alarm may generate. However, as time passes, the oil seal or grease is warmed up,
and the motor can be operated without generating the overload alarm.
zApply grease to the output shaft of a hollow shaft at gearhead
If you are using a hollow shaft at gearhead, apply grease (molybdenum disulde grease,
etc.) on the surface of the load shaft and inner walls of the hollow output shaft to prevent
seizure.
zThe driver uses semiconductor elements. Handle the driver with care
The driver uses parts that are sensitive to electrostatic charge. Before touching the driver,
turn o the power to prevent electrostatic charge from generating. If an electrostatic
charge is impressed on the driver, the driver may be damaged.
zConnecting the motor and driver
For the BLV510 product, be sure to use the included connection cable to connect the motor
and driver.
For the BLV620 and BLV640 products, use the included connection cable to extend the
wiring distance between the motor and driver.
zSliding noise of electromagnetic brake
An electromagnetic brake motor may cause a sliding noise of the brake disk during
operation. There is no functional problem.
Preparation
Checking the product
Verify that the items listed below are included. Report any missing or damaged items to
the branch or sales oce from which you purchased the product.
Motor (with a gearhead, only for combination type)..........1 unit
Driver ....................................................................................................1 unit
Connection cable .............................................................................1 pc.
CN1 connector...................................................................................1 pc.
OPERATING MANUAL (this document).....................................1 copy
Included with combination type-parallel shaft gearhead
Mounting screw set........................1 set
Hexagonal socket head screws, washers, spring washers, nuts 4 pieces each
Parallel key ......................................... 1 pc.
(For the BLV620 and BLV640 products, the parallel key is xed to the gearhead output shaft.)
Included with combination type-hollow shaft at gearhead
Mounting screw set........................1 set
Hexagonal socket head screws, washers, spring washers, nuts4 pieces each
Parallel key ......................................... 1 pc.
Safety cover .......................................1 pc.
Safety cover mounting screw .....2 pcs.
For the BLV620 and BLV640 products, hexagonal nuts are not included.
Combinations of motors and drivers
Verify the model number of the purchased unit against the number shown on the package
label. Check the model number of the motor and driver against the number shown on the
nameplate.
in the model names indicates a number representing the gear ratio.
indicates a number representing the length of the included connection cable.
The combination types come with the motor and gearhead pre-assembled.
zStandard type
 Combination type-parallel shaft gearhead
Output power Model Motor model Gearhead model Driver model
100 W BLV510KS-BLVM510K-GFS GFS5GBLVD10KM
200 W BLV620KS-BLVM620K-GFS GFS6GBLVD20KM
400 W BLV640NS-BLVM640N-GFS BLVD40NM
 Combination type-hollow shaft at gearhead
Output power Model Motor model Gearhead model Driver model
100 W BLV510KF-BLVM510K-GFS GFS5GFR BLVD10KM
200 W BLV620KF-BLVM620K-GFS GFS6GFR BLVD20KM
400 W BLV640NF-BLVM640N-GFS BLVD40NM
 Round shaft type
Output power Model Motor model Driver model
200 W BLV620KA-BLVM620K-A BLVD20KM
400 W BLV640NA-BLVM640N-A BLVD40NM
zElectromagnetic brake type
 Combination type-parallel shaft gearhead
Output
power Model Motor model Gearhead model Driver model
100 W BLV510KMS-BLVM510KM-GFS GFS5GBLVD10KM
200 W BLV620KMS-BLVM620KM-GFS GFS6GBLVD20KM
400 W BLV640NMS-BLVM640NM-GFS BLVD40NM
 Combination type-hollow shaft at gearhead
Output
power Model Motor model Gearhead model Driver model
100 W BLV510KMF-BLVM510KM-GFS GFS5GFR BLVD10KM
200 W BLV620KMF-BLVM620KM-GFS GFS6GFR BLVD20KM
400 W BLV640NMF-BLVM640NM-GFS BLVD40NM
 Round shaft type
Output power Model Motor model Driver model
200 W BLV620KMA-BLVM620KM-A BLVD20KM
400 W BLV640NMA-BLVM640NM-A BLVD40NM
Names and functions of parts
zMotor
The gure shows the electromagnetic brake type of 200 W.
Motor cable
Motor power connector
Motor signal connecto
r
Electromagnetic brake
connector
Pilot section
Motor
Electromagnetic brake
Output shaft
Mounting hole
(4 places)

3
zDriver
Basic function switch
(SW1)
I/O signal connector [CN4]
POWER LED (Green)
ALARM LED (Red)
C-DAT LED (Green)
C-ERR LED (Red)
Internal potentiometer (
VR1)
Acceleration/deceleration
time potentiometer (VR2)
Motor signal connector
[CN3]
Motor power connector
[CN2]
Main power supply input
terminal [CN1]
Electromagnetic brake
connector [CN8]
Communication
connector [CN7]
RS-485 communication
connector [CN5/CN6]
Control power supply
input terminal (TB1)
Address number setting
switch (SW3)
C
ommunication function
switch (SW2)
Mounting hole
(4 places)
Torque limiting
potentiometer (VR3)
Name Description
POWER LED (Green) This LED is lit while the main power or control power is
input.
ALARM LED (Red)
This LED will blink when an alarm generates (a protective
function is triggered). You can check the generated alarm
by counting the number of times the LED blinks.
Internal potentiometer (VR1) Set the motor rotation speed.
Acceleration/deceleration
time potentiometer (VR2)
The acceleration time and deceleration time for starting
and stopping can be set.
Torque limiting
potentiometer (VR3) Set the torque limiting value of the motor.
Main power supply input
terminal [CN1]
Connect the main power supply.
BLV510, BLV620: +24 V, BLV640: +48 V
Motor power connector [CN2] Connect the motor power connector.
Motor signal connector [CN3] Connect the motor signal connector.
Electromagnetic brake
connector [CN8] Connect the electromagnetic brake connector.
I/O signal connector [CN4]
Use this connector when using an external control device
(programmable controller) or inputting a operation
command.
Basic function switch (SW1) Select the setting of the speed response, external DC
voltage and sink logic/source logic.
Communication connector
[CN7] Connect the MEXE02 or OPX-2A.
Control power supply input
terminal(TB1) Connect the driver control power supply.
RS-485 communication
connector[CN5/CN6] Connect the RS-485 communication cable.
C-DAT LED (Green)This LED will illuminate when the driver is communicating
with the master station properly via RS-485 communication.
C-ERR LED (Red)This LED will illuminate when a RS-485 communication
error occurs with the master station.
Communication function
switch(SW2)
Set the transmission rate, communication protocol and
termination resistor of RS-485 communication.
Address number setting
switch(SW3)
Set the address number (slave address) of RS-485
communication.
Mounting hole (4 places) 4 places on the back surface and side surface
Uses when controlling the system via RS-485 communication.
Installation
Location for installation
The motor and driver are designed and manufactured to be incorporated in equipment.
Install them in a well-ventilated location that provides easy access for inspection. The
location must also satisfy the following conditions:
Inside an enclosure that is installed indoors (provide vent holes)
Operating ambient temperature 0 to +40 °C [+32 to 104 °F] (non-freezing)
Operating ambient humidity 85% or less (non-condensing)
Area that is free of explosive atmosphere or toxic gas (such as sulfuric gas) or liquid
Area not exposed to direct sun
Area free of excessive amount of dust, iron particles or the like
Area not subject to splashing water (rain, water droplets), oil (oil droplets) or other liquids
Area free of excessive salt
Area not subject to continuous vibration or excessive shocks
Area free of excessive electromagnetic noise (from welders, power machinery, etc.)
Area free of radioactive materials, magnetic elds or vacuum
Altitude Up to 1000 m (3300 ft.) above sea level
Installing the combination type
Note
Do not forcibly assemble the motor and gearhead. Also, do not let metal
objects or other foreign matters enter the gearhead. The pinion of the motor
output shaft or gear may be damaged, resulting in noise or shorter service
life.
Do not allow dust to attach to the pilot sections of the motor and gearhead.
Also, assemble the motor and gearhead carefully by not pinching the O-ring
at the motor pilot section. If the O-ring is crushed or severed, grease may
leak from the gearhead.
zCombination type-parallel shaft gearhead
Secure the motor and gearhead through four
mounting holes using the included mounting
screw set.
Do not leave a gap between the motor and
mounting plate.
Hexagonal socket
head screw
Screw
size
Tightening
torque
[N·m (lb-in)]
Maximum applicable
plate thickness
[mm (in.)]
M8 15.5 (137) 12 (0.47)
When the included mounting screw set is used.
Removing/assembling the gearhead
See the following steps to replace the gearhead or to change the cable outlet position.
Removing the gearhead from the motor
Remove the hexagonal socket head screws (2 places)
assembling the motor and gearhead, and detach the gearhead
from the motor.
Hexagonal socket
head screw
Assembling the gearhead to the motor
1. Keep the pilot sections of the motor and
gearhead in parallel, and assemble the
gearhead with the motor while slowly
rotating it clockwise/counterclockwise.
At this time, note so that the pinion of the
motor output shaft does not hit the side
panel or gears of the gearhead strongly.
Assemble the gearhead to the motor
in a condition where the motor output
shaft is in an upward direction.
Side panel
Pilot section
Pinion of
the motor
output shaft
2. Check no gaps remain between the motor and gearhead, and tighten them with
hexagonal socket head screws (2 pieces).
Screw size Tightening torque
[N·m (lb-in)]
M3 0.6 (5.3)

4
zCombination type-hollow shaft at gearhead
A combination type-hollow shaft at gearhead can be installed by using either its front
or rear side as the mounting surface. (Illustration shows when installing the gearhead by
using its front side as the mounting surface.)
Secure the gearhead through four mounting holes using the included mounting screw set.
Do not leave a gap between the gearhead and mounting plate.
Hexagonal nuts are not included with the BLV620 and BLV640 products, so provide them
separately or drill tapped holes in the mounting plate.
Attach the included safety cover to the hollow output shaft on the end opposite from the
one where the load shaft is installed. [Tightening torque: 0.45 N·m (3.9 lb-in)]
Safety cover
Hexagonal socket
head screw
Front
Rear
Safety cover
mounting scre
w
Mounting plate
Screw size Tightening torque
[N·m (lb-in)]
Maximum applicable plate thickness
[mm (in.)]
M8 15.5 (137) 12 (0.47)
When the included mounting screw set is used.
Removing/assembling the gearhead
See the following steps to replace the gearhead or to change the cable outlet position.
Note that the motor cable cannot be positioned in the direction where it faces to the
gearhead output shaft side.
Removing the gearhead from the motor
Remove the hexagonal socket head screws
(4 places) assembling the motor and
gearhead, and detach the gearhead from
the motor.
Hexagonal socket
head screw
Assembling the gearhead to the motor
1. Keep the pilot sections of the motor and
gearhead in parallel, and assemble the
gearhead with the motor while slowly
rotating it clockwise/counterclockwise.
At this time, note so that the pinion of the
motor output shaft does not hit the side
panel or gears of the gearhead strongly.
Change the position to a
desired 90° direction.
2. Check no gaps remain between the motor and gearhead, and tighten them with
hexagonal socket head screws (4 pieces).
Screw size Tightening torque
[N·m (lb-in)]
M8 15.5 (137)
Installing the round shaft type
Secure the motor with hexagonal socket head screws
through the four mounting holes provided. Do not leave a
gap between the motor and mounting plate.
Since hexagonal socket head screws are not included with
the product. They must be provided by the customer.
Hexagonal socket
head screw
Applicable
screw size Tightening torque [N·m (lb-in)]
M8 15.5 (137)
Install the motor to a mounting plate of the following size or larger, so that the motor case
temperature will not exceed 90 °C (194 °F).
Model Size of mounting plate [mm (in.)] Thickness [mm (in.)] Material
BLV620 200×200 (7.87×7.87) 5 (0.2) Aluminum
BLV640 250×250 (9.84×9.84) 6 (0.24)
Installing a load of the combination type-parallel gearhead or
round shaft type
When installing a load on the motor or the gearhead, align the center of the motor output
shaft or the gearhead output shaft with the center of the load shaft.
Note
When coupling the motor or the gearhead with a load, pay attention to
centering, belt tension, parallelism of pulleys, etc. Also, rmly secure the
tightening screws of the coupling or pulleys.
When installing a load, do not damage the motor output shaft, the gearhead
output shaft, or bearings. Installing the load forcibly with a hammer or the
like may break the bearings. Do not apply any excessive force to the output
shaft.
Do not modify or machine the output shaft of the motor or gearhead. Doing
so may damage the bearings, leading to damage to the motor or gearhead.
zOutput shaft shape
Combination type-parallel gearhead
A key slot is provided on the output shaft of the gearhead. Form a key slot on the load side,
and secure the load using the included parallel key.
[Parallel key dimension: 6 mm (0.236 in.)]
Round shaft type
A at section is provided on the motor output shaft of each round shaft type.
Apply a double-point screw, etc., at the at section to rmly secure the load and prevent it
from spinning.
zHow to install a load
Using a coupling
Align the centerline of the output shaft of the motor or gearhead with the centerline of the
load shaft.
Using a belt drive
Adjust the output shaft of the motor or gearhead to lie parallel with the load shaft, and
form right angles between the output shaft/load shaft and the line connecting the centers
of both pulleys.
Using a gear drive
Adjust the output shaft of the motor or gearhead to lie parallel with the gear shaft, and
allow the output shaft to mesh correctly with the centers of the gear teeth.
When using the output shaft end tapped hole of a gearhead
Use a screw hole [M6; Eective depth 12 mm
(0.47 in)] provided at the end of the output shaft
as an auxiliary means for preventing the transfer
mechanism from disengaging.
Fixed screw
Screw
Spacer
Transmission parts

5
Installing a load of the combination type-hollow shaft at
gearhead
If a large impact occurs at instantaneous stop or a large radial load is applied, use a
stepped load shaft.
Note Apply grease (molybdenum disulde grease, etc.) on the surface of the load
shaft and inner walls of the hollow output shaft to prevent seizure.
zRecommended load shaft installation dimensions [Unit: mm (in.)]
Model BLV510 BLV620, BLV640
Inner diameter of hollow shaft (H8) Ø20
+0.033
0
(Ø0.7874
+0.0013
0
)
Ø25
+0.033
0
(Ø0.9843
+0.0013
0
)
Recommended diameter of load shaft (h7) Ø20
0
- 0.021
(Ø0.7874
0
- 0.0008
)
Ø25
0
- 0.021
(Ø0.9843
0
- 0.0008
)
Nominal diameter of retaining ring Ø20 (Ø0.79) Ø25 (Ø0.98)
Applicable screw M6 M8
Spacer thickness 5 (0.20) 6 (0.24) [3 (0.12)]
Outer diameter of stepped shaft (ØD) 30 (1.18) 40 (1.57)
The value in [ ] is the thickness when installing the gearhead by using its rear side as the
mounting surface.
zStepped load shaft
Secure the retaining ring to the load shaft by tightening the hexagonal socket head screw
over a spacer, at washer and spring washer.
Flat washer
Spacer
Retaining ring
Stepped load shaft
Pa
rallel key
Spring washer
Hexagonal socket
head screw
Retaining ring
Hollow output shaft
Hexagonal
socket
head screw
Spring washer
Flat washer
Spacer
Parallel key
Load shaft
ØD
zNon-stepped load shaft
Install a spacer on the load shaft side and secure the retaining ring to the load shaft by
tightening the hexagonal socket head screw over a spacer, at washer and spring washer.
Flat washer
Spacer
Retaining ring
Load shaft
Pa
rallel key
Spring washer
Hexagonal socket
head screw
Retaining ring
Hollow output shaft
Hexagonal
socket
head screw
Spring washer
Flat washer
SpacerSpacer
Parallel key
Load shaft
Spacer
Permissible radial load and permissible axial load
Note Failure due to fatigue may occur when the bearings and output shaft of the
motor or gearhead are subject to repeated loading by a radial or axial load
that is in excess of the permissible limit.
zCombination type-parallel gearhead
Model Gear ratio
Distance from tip of gearhead output shaft
and permissible radial load[N (lb.)] Permissible axial
load [N (lb.)]
10 mm (0.39 in.) 20 mm (0.79 in.)
BLV510
5 300 (67) 400 (90)
150 (33)10 to 20 400 (90) 500 (112)
30 to 200 500 (112) 650 (146)
BLV620
BLV640
5 to 20 550 (123)
<500 (112)>
800 (180)
<700 (157)> 200 (45)
30, 50 1000 (220)
<900 (200)>
1250 (280)
<1100 (240)> 300 (67)
100, 200 1400 (310)
<1200 (270)>
1700 (380)
<1400 (310)> 400 (90)
The values assume a rated speed of 3000 r/min or below.
The values in < > are based on a rated speed of 4000 r/min.
zCombination type-hollow shaft at gearhead
Model Gear ratio
Distance from gearhead mounting surface
and permissible radial load[N (lb.)] Permissible axial
load [N (lb.)]
10 mm (0.39 in.) 20 mm (0.79 in.)
BLV510
5, 10 900 (200) 770 (173)
500 (112)15, 20 1300 (290) 1110 (240)
30 to 200 1500 (330) 1280 (280)
BLV640 51230 (270)
<1130 (250)>
1070 (240)
<990 (220)>
800 (180)
BLV620
BLV640
10
15, 20 1680 (370)
<1550 (340)>
1470 (330)
<1360 (300)>
30 to 100 2040 (450)
<1900 (420)>
1780 (400)
<1660 (370)>
The values assume a rated speed of 3000 r/min or below.
The values in < > are based on a rated speed of 4000 r/min.
zRound shaft type
Model
Distance from tip of motor output shaft and
permissible radial load [N (lb.)] Permissible axial load
[N (lb.)]
10 mm (0.39 in.) 20 mm (0.79 in.)
BLV620
BLV640 197 (44) 221 (49) 25 (5.6)
Installing the driver
The driver is designed so that heat is dissipated via air convection and conduction through
the enclosure. Install the driver to a at metal plate oering excellent vibration resistance.
When two or more drivers are to be installed side by side, provide at least 20 mm (0.79 in.)
and 25 mm (0.98 in.) clearances in the horizontal and vertical directions, respectively.
Note
Install the driver in an enclosure whose pollution degree is 2 or better
environment, or whose degree of protection is IP54 minimum.
Do not cover the radiation vent of the driver.
Do not install any equipment that generates a large amount of heat or noise
near the driver.
If the ambient temperature of the driver exceeds 40 °C (104 °F), revise the
ventilation condition or force-cool the area around the driver using a fan.
zInstalling with screws
Install the driver through the mounting holes using two screws (M4: not included).
When mounting in vertical direction [Unit: mm (in.)]
147 (5.79) 147 (5.79)
Ø4.5 (Ø0.177) 2×Ø4.5 (Ø0.177)
•When using side surface A •When using side surface B
B
A

6
When mounting in horizontal direction [Unit: mm (in.)]
147 (5.79)
147 (5.79)
Ø4.5 (Ø0.177)
2×Ø4.5 (Ø0.177)
•When using side surface A
•When using side surface B
A
B
zMounting to DIN rail
Use the DIN rail mounting plate PADP03 (sold separately), and install it to a 35 mm (1.38in.)
wide DIN rail. After installation, x the both sides of the driver with the end plate (not
included).
DIN rail
DIN lever
Hook
DIN rail
mounting plate
Mounting screw (included)
Tightening torque: 0.3 to 0.4 N·m (2.6 to 3.5 lb-in)
Mounting hole
(M3-4 places)
Note
Do not use the mounting holes (M3, four places) for the DIN rail mounting
plate for any purpose other than securing the DIN rail mounting plate.
Be sure to use the included screws when securing the DIN rail mounting
plate. The use of screws that would penetrate 3 mm (0.12 in.) or more
through the surface of the driver may cause damage to the driver.
Setting
Basic function switch
(SW1)
Address number
setting switch (SW3)
Communication
function switch (SW2)
Basic function (SW1)
SW1 Description Setting range
1 Speed response ON: High response mode
OFF: Regenerative power suppression mode (Factory setting)
2 External DC voltage ON: 0 to 10 V
OFF: 0 to 5 V (Factory setting)
3 Sink logic/Source logic ON: Source logic
OFF: Sink logic (Factory setting)
Communication function (SW2)
Set when controlling the system via RS-485 communication.
SW2 Description Factory setting
1
Transmission rate
OFF
2
3
4 Not used
5 Communication protocol selection
6 Not used
7 Termination resistor
8 Extending the address number
Address number setting (SW3)
Set when controlling the system via RS-485 communication.
Set the address number using this switch in combination with No. 8 of the SW2.
Factory setting: 0
Connection
This section explains how to connect the driver and motor, I/O signals, and power supply.
zBLV510
Be sure to use the connection cable (included) for the exclusive use of the BLV510 product
to connect the motor and driver.
The motor cable cannot be connected to the driver directly. It is required to convert the
connector of the motor cable using the connection cable (included) for the exclusive use
of the BLV510 product.
Maximum extension distance between the motor and driver :
1.5 m (4.9 ft.) [including 0.5 m (1.6 ft.) of the motor cable]
Required
Driver
DC power supply
Motor cable
Motor
RS-485
communication cable
MEXE02
or
OPX-2A
I/O signals cable
Grounding
+
-
24 VDC±10%
Connection cable
[0.2 m (0.66 ft.)
or 1 m(3.3 ft.)]
zBLV620, BLV640
Maximum extension distance between the motor and driver :
3.5 m (11.5 ft.) [including 0.5 m (1.6 ft.) of the motor cable]
Driver
DC power supply
MEXE02
or
OPX-2A
+
-
BLV620：
24 VDC±10%
BLV640：
48 VDC±10%
Motor cable
Motor
Grounding
Connection cable
[1 m (3.3 ft.), 2 m (6.6 ft.),
3 m (9.8 ft.)]
I/O signals cable
RS-485
communication cable
The motor cable can be connected to the driver directly.

7
Connection example (Sink logic)
This section describes the connection example of sink logic.
Refer to the USER MANUAL (Basic Function) for the connection example of source logic and switching between sink logic and source logic.
FWD 1
CN4
CN2
CN3
CN8
3.3 kΩ
2
+
CN1
−
+
−
3
4
9
10
5
13
12
11
6
CN4
5
14
7
15
8
2
1
3
REV
STOP-MODE
M0
ALARM-RESET
MB-FREE
IN-COM
IN-COM
SPEED-OUT
∗2
∗1
∗2
WNG (+)
WNG (−)
ALARM-OUT1 (+)
ALARM-OUT1 (−)
VH
+15 V
0 V
0 V
0 V
VM
VL
VM
VL
Motor power connector
Driver
Motor signal connector
Electromagnetic brake connector
BLV510, BLV620 : 30 VDC or less
10 mA or less
BLV640 : 53 VDC or less
10 mA or less
BLV510, BLV620 : 30
VDC or less
100 mA or less
BLV640 : 53 VDC or less
100 mA or less
External potentiometer
PAVR-20KZ
(sold separately)
Ex
ternal DC voltage
(Not to ex
ceed the
voltage selec
ted by
SW1-No
.2)
BLV510, BLV620 : 24 VDC±10%
BLV640 : 48 VDC±10%
DC power supply
 Be sure to suppress the current value to 10 mA or less. Connect a current-limiting resistor if the current exceeds this specied value.
 Be sure to suppress the current value to 100 mA or less. Connect a current-limiting resistor if the current exceeds this specied value.
Connecting the power supply
zConnecting method
1. Strip the insulation cover of the lead wire by 10 mm
(0.39 in.).
Applicable lead wire: AWG16 to 10 (1.25 to 6 mm2)
10 mm
(0.39 in.)
2. Insert each lead wire into the CN1 connector and
tighten the screw.
Tightening torque: 0.7 to 0.8 N·m (6.1 to 7.0 lb-in)
CN1
connecto
r
Lead wire
3. Insert the CN1 connector into CN1.
Hold the green part of the CN1 connector, and insert it into the CN1on the driver.
Push the lever (orange) into the CN1 on the driver before pulling out the CN1 connector.
Lever
Supplying the power in a state where the
lever (orange) is pushed in may cause
damage to the driver due to connection
failure.
Note
When connecting, check the indication of the driver case and pay attention
to the polarity of the power supply. Reverse-polarity connection may cause
damage to the driver.
Do not wire the power supply cable of the driver in the same cable duct
with other power lines or motor cable. Doing so may cause malfunction due
to noise.
When turning on the power again or inserting/pulling out the connector,
turn o the power and wait for the POWER LED to turn o.
When turning on or o the power supply using a mechanical contact
(breaker, electromagnetic switch, relay, etc.), do so only the positive side
(+) of the power supply using the mechanical contact. Turning on or
o the positive side (+) and the negative side (-) of the power supply
simultaneously using a mechanical contact may cause damage to the
control circuit or peripheral equipment.
zApplicable crimp terminal
If crimp terminals are used, select the following terminals.
Manufacturer Model Applicable lead wire
PHOENIX CONTACT GmbH & Co. KG
AI 1,5-10 AWG16 (1.25 mm2)
AI 2,5-10 AWG14 (2 mm2)
AI 4-10 AWG12 (3.5 mm2)
Recommended power supply capacity
Model Input power supply voltage Power supply capacity
BLV510 24 VDC±10% 400 W or more
BLV620 24 VDC±10% 800 W or more
BLV640 48 VDC±10% 1 kW or more
Connecting the motor
Motor power connector
Connect to CN2
Motor signal connector
Connect to CN3
Electromagnetic brake connector
Connect to CN8∗
∗ Electromagnetic brake type only
Connect the motor power connector to the CN2, and the motor signal connector to the
CN3 on the driver.
When using an electromagnetic brake type product, connect the electromagnetic brake
connector to the CN8.
For the BLV510 product, the connection cable (included) is required to connect the motor
and driver.
Note Make sure the connector is inserted securely. Insecure connection may cause
malfunction or damage to the motor or driver.

8
Unauthorized reproduction or copying of all or part of this manual is prohibited.
Oriental Motor shall not be liable whatsoever for any problems relating to industrial
property rights arising from use of any information, circuit, equipment or device
provided or referenced in this manual.
Characteristics, specications and dimensions are subject to change without notice.
While we make every eort to oer accurate information in the manual, we welcome
your input. Should you nd unclear descriptions, errors or omissions, please contact the
nearest oce.
is a registered trademark or trademark of Oriental Motor Co., Ltd., in
Japan and other countries.
Modbus is a registered trademark of the Schneider Automation Inc.
CC-Link is a registered trademark of the CC-Link Partner Association.
MECHATROLINK is a registered trademark of the MECHATROLINK Members Association.
EtherCAT® is registered trademark and patented technology, licensed by Beckho
Automation GmbH, Germany.
© Copyright ORIENTAL MOTOR CO., LTD. 2011
Published in December 2019
T
echnical Support Tel:[phone]
8:30
A.M. to 5:00 P.M., P.S.T. (M-F)
7:30
A.M. to 5:00 P.M., C.S.T. (M-F)
www
.orientalmotor.com
Schiessstraße 44, 40549 Düsseldor
f, Germany
T
echnical Support Tel:[phone]
www
.orientalmotor.de
T
el:01256-347090
www
.oriental-motor.co.uk
T
el:01 47 86 97 50
www
.orientalmotor.fr
T
el:02-93906346
www
.orientalmotor.it
T
el:[phone]
www
.orientalmotor.com.br
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno
,Taito-ku,Tokyo 110-8536
Japan
T
el:03-6744-0361
www
.orientalmotor.co.jp
Tel:[phone]
www.orientalmotor.com.tw
Singapore
Tel:[phone]
www.orientalmotor.com.sg
Tel:[phone]
www.orientalmotor.com.my
Korea
Tel:[phone]
www.inaom.co.kr
Tel:[phone]
www.orientalmotor.co.th
Tel:[phone]
www.orientalmotor.com.cn
Tel:[phone]
www.orientalmotor.co.in
Hong Kong Branch
Tel:[phone]
Connecting the I/O signals
Connect the I/O signals to the I/O signal connector (CN4) on the driver. Keep the wiring
distance as short as possible [less than 2 m (6.6 ft.)] to suppress the eect of noise.
Note
The connector for connecting the I/O signals is not included. Provide the
following products.
D-Sub connector (15-pin), Hood (screw: No.4-40UNC)
Wire the I/O signal cable at a distance of 100 mm (3.94 in) or more apart
from the inductive load (electromagnetic relay etc.), power supply, or power
cable (motor cable etc.).
zConnector function table
1827
915 1014
This gure is the CN4 connector viewed
from the driver front side.
Pin
No.
Signal
type
Terminal
name Signal name Description
1
Input
X0 FWD The motor rotates in the clockwise direction.
2 X1 REV The motor rotates in the counter clockwise
direction.
3 X2 STOP-MODE Select instantaneous stop or deceleration
stop.
4 X3 M0 Select the internal potentiometer or external
potentiometer (external DC voltage).
5 GND C0 IN-COM −
6
Output
Y2 SPEED-OUT 30 pulses are output with each revolution
of the motor output shaft.
7 Y1−WNG (−) −
8 Y0−ALARM-OUT1 (−) −
9
Input
X4 ALARM-RESET Reset the alarm.
10 X5 MB-FREESelect how the electromagnetic brake
would operate when the motor stops.
11
Analog
input
VL VL External speed setting input. Set the speed
by the external potentiometer or external
DC voltage.
12 VM VM
13 VH VH
14 Output Y1+ WNG (+) This signal is output when a warning generates.
15 Y0+ ALARM-OUT1 (+) This signal is output when an alarm generates.
For the electromagnetic brake type
Operation overview
Basic operation
With the BLV Series, the following operations can be performed. Refer to the USER
MANUAL (Basic Function) for details.
 Speed setting
Internal potentiometer, external potentiometer, external DC voltage
 Operation and stop
Operates or stops the motor.
 Setting the acceleration time and deceleration time
The acceleration time and deceleration time for starting and stopping can be set.
 Two-speed operation
Operation can be performed at two speeds through use of both the internal potentiometer
and external potentiometer (external DC voltage).
 Multi-motor control
A single external potentiometer (external DC voltage) can be used to set the same speed for
multiple motors.
Using the support software MEXE02 or the data setter OPX-2A (sold separately) can
extend functions such as the digital setting of the rotation speed and torque limiting value,
the setting of parameters, and various monitors.
Operation via communication
zRS-485 communication
Operation data and parameters can be set and operation commands can be input from
the host controller via RS-485 communication. The protocol for the RS-485 communication
is the Modbus protocol. Refer to the USER MANUAL (RS-485 Communication Mode) for
details.
zNetwork converter
This product can be used via various network when connecting to a network converter (sold
separately). Refer to the operating manual of the network converter for details.
Network converter model Supported network
NETC01-CC CC-Link
NETC01-M2/M3 MECHATROLINK
NETC01-ECT EtherCAT
Refer to the USER MANUAL for details on the product.
For the USER MANUAL, contact your nearest Oriental Motor sales oce or
download from Oriental Motor Website Download Page.
Regulations and standards
CE Marking
This product is axed the CE Marking (EMC Directive) based on the EN Standard. The
input power supply voltage of this product is 24 VDC/48 VDC. Therefore this product is not
subject to the Low Voltage Directive, but install and connect it as follows.
 Installation conditions
For incorporating in equipment
Overvoltage category: I
Pollution degree: 2
 EMC Directive
Refer to USER MANUAL (Basic Function) for installation method.
Republic of Korea, Radio Waves Act.
KC Mark is axed to this product under the Radio Waves Act, the republic of Korea.
RoHS Directive
The products do not contain the substances exceeding the restriction values of RoHS
Directive (2011/65/EU).
