Oriental motor PKP223 User manual

1
Introduction
Before use
Only qualied personnel of electrical and mechanical engineering should work with the
product.
Use the product correctly after thoroughly reading the“Safety precautions”. In addition,
be sure to observe the contents described in warning, caution, and note in this manual.
The product described in this manual has been designed and manufactured to be
incorporated in general industrial equipment. Do not use for any other purpose. Oriental
Motor Co., Ltd. is not responsible for any damage caused through failure to observe this
warning.
Safety precautions
The precautions described below are intended to prevent danger or injury to the user
and other personnel through safe, correct use of the product. Use the product only after
carefully reading and fully understanding these instructions.
Description of signs
Handling the product without observing the instructions that
accompany a "Warning" symbol may result in serious injury
or death.
Handling the product without observing the instructions
that accompany a“Caution”symbol may result in injury or
property damage.
The items under this heading contain important handling
instructions that the user should observe to ensure the safe
use of the product.
Description of graphic symbols
Indicates "prohibited" actions that must not be performed.
Indicates "compulsory" actions that must be performed.
yDo not use the product in explosive or corrosive environments, in the
presence of ammable gases, locations subjected to splashing water, or
near combustibles.
This may cause re or injury.
yDo not forcibly bend, pull or pinch the motor lead wire or cable.
This may cause re.
yDo not disassemble or modify the product.
This may cause injury.
yAssign qualied personnel the task of installing, wiring, operating/
controlling, inspecting and troubleshooting the product.
Failure to do so my result in re or injury.
yIf this product is used in a vertical application, be sure to provide a
measure for the position retention of moving parts.
Failure to do so may result in injury or damage to equipment.
yInstall the product in an enclosure.
Failure to do so may result in injury.
yConnect the cables securely according to the wiring diagram.
Failure to do so may result in re.
yFor the power supply, use a DC power supply with reinforced insulation
on its primary and secondary sides.
Failure to do so may cause electric shock.
HM-7448-3
OPERATING MANUAL Thank you for purchasing an Oriental Motor product. This Operating Manual describes
product handling procedures and safety precautions.
yPlease read it thoroughly to ensure safe operation.
yAlways keep the manual where it is readily available.
2-Phase Stepping Motor
PKP Series SH Geared Type
yDo not use the product beyond its specications.
This may cause injury or damage to equipment.
yKeep your ngers and objects out of the openings in the product.
Failure to do so may result in re or injury.
yDo not touch the product while operating or immediately after
stopping.
This may cause a skin burn(s).
yDo not carry the motor by holding the motor output shaft, motor lead
wire or cable.
Doing so may cause injury.
yKeep the area around the product free of combustible materials.
Failure to do so may result in re or a skin burn(s).
yLeave nothing around the product that would obstruct ventilation.
Failure to do so may result in damage to equipment.
yDo not touch the rotating part (output shaft) while operating the motor.
Doing so may result in injury.
yProvide a cover over the rotating part (output shaft) of the motor.
Failure to do so may result in injury.
yUse a motor and driver only in the specied combination.
Failure to do so may result in re.
yProvide an emergency stop device or emergency stop circuit so that the
entire equipment will operate safely in the event of a system failure or
malfunction.
Failure to do so may result in injury.
yWhen an abnormal condition has occurred, immediately stop operation
and turn o the driver power.
Failure to do so may result in re or injury.
yThe motor surface temperature may exceed 70 °C (158 °F)
even under normal operating conditions. If the operator
is allowed to approach the running motor, attach a
warning label as shown below in a conspicuous position.
Failure to do so may result in a skin burn(s).
Warning
label
Precautions for use
•When conducting the insulation resistance measurement and the
dielectric strength test, be sure to separate the connection between the
motor and the driver.
Conducting the insulation resistance measurement or withstand voltage test with the
motor and driver connected may result in injury or damage to equipment.
•Do not apply a radial load and axial load in excess of the specied
permissible limit
Operating the motor under an excessive radial load or axial load may damage the motor
bearings (ball bearings). Be sure to operate the motor within the specied permissible
limit of radial load and axial load.
•Motor surface temperature
The surface temperature on the motor case may exceed 100 °C (212 °F) depending on
operating conditions such as ambient temperature, operating speed, duty cycle and
others. To prevent the motor bearings (ball bearings) from reaching its usable life quickly,
use the motor in conditions where the surface temperature will not exceed 100 °C
(212 °F).
Use the geared motor in a condition where the gear case temperature does not exceed
70 °C (158 °F), in order to prevent deterioration of grease and parts in the gear part.
•Grease leakage
On rare occasions, a small amount of grease may ooze out from the geared motor. If
there is concern over possible environmental damage resulting from the leakage of
grease, check for grease stains during regular inspections. Alternatively, install an oil pan
or other device to prevent leakage from causing further damage. Oil leakage may lead to
problems in the customer’s equipment or products.

2
•Holding torque at standstill
The motor holding torque is reduced by the current cutback function of the driver at
motor standstill. When operating the motor, take account of the motor torque drop at
the time of stopping.
•Allowable torque
When operating the motor at a constant speed, use so that the torque does not exceed
the allowable torque in the specications. Operating the motor in excess of the allowable
torque may cause damage to the gear part.
•Speed range
Operate the motor at speeds within the speed range. Operating the motor at a speed
outside the speed range may result in a shorter gear life.
•Backlash
The gear output shaft is subject to backlash. To reduce the eect of backlash, perform
positioning operations from one direction only-either from the CW direction or the CCW
direction.
•Rotating direction of the gear output shaft
The relationship between the rotating direction of the motor shaft and that of the gear
output shaft changes as follows, depending on the gear type and gear ratio.
Model Gear ratio Rotation direction of the gear output shaft
PKP223 7.2, 36 Same as the motor output shaft
9, 10, 18 Opposite to the motor output shaft
PKP243
PKP264
3.6, 7.2, 9, 10 Same as the motor output shaft
18, 36 Opposite to the motor output shaft
Preparation
Checking the product
Verify that the items listed below are included. Report any missing or damaged items to
the branch or sales oce from which you purchased the product.
yMotor ..................................................................1 unit
yConnection cable [0.6 m (2 ft.)] .................1 pc. (PKP-L only)
yOPERATING MANUAL ....................................1 copy (this document)
How to identify the product name
Check the model number of the motor against the number shown on the nameplate.
PKP2   D   -SG - L
1 2 3 4 5 6 7 8 9
1 Motor frame size
2: 28 mm (1.10 in.)
4: 42 mm (1.65 in.)
6: 60 mm (2.36 in.)
2 Motor length
3 Number of lead wire D: 4 pcs.
U: 5 pcs. or 6 pcs.
4 Motor winding specication
Representative example
09: Rated current 0.95 A/phase
28: Rated current 2.8 A/phase
5 Shape A: Singnle shaft
B: Double shaft
6 Motor identication 2: Model A
None: Model B
7 Gear type SG: SH geared type
8 Gear ratio
9 Connection cable -L: Supplied with a connection cable
None: Without connection cable
Names of parts
The pin numbers as well as the colors of lead wires are shown in the gures.
The connection diagrams show the supplied or accessory connection cable.
zMotors of Model A
Pilot
Output shaft
Mounting holes
(4 places)
Connector
Pin No.1
Pin No.5
Connector
Connector locks
Motor lead wires
Pin No.5
Red
Pin No.1
Black
• Connection cable
Wiring connection diagram
1/Black
2/Green
4/Blue5/Red
• Unipolar 5 lead wires type • Bipolar 4 lead wires type *
1/Black
2/Green
AA
5/Red 4/Blue
B
3/White
AA
BBB
* The pin No.3 is not used for the 4 lead wires type.
Applicable connector/lead wire
Type Model
Connector housing MDF97-5S-3.5C (HIROSE ELECTRIC CO., LTD.)
Contact MDF97-22SC (HIROSE ELECTRIC CO., LTD.)
Designated crimping tool HT801/MDF97-22S (HIROSE ELECTRIC CO., LTD.)
Applicable lead wire
− AWG22 (0.3 mm2)
− Outer sheath diameter:
ø1.2 to 1.5 mm (ø0.047 to 0.059 in.)
− Strip length of the insulation cover:
1.8 to 2.3 mm (0.071 to 0.091 in.)
zMotors of Model B
Pilot
Output shaft
Mounting holes
(4 places)
Connector
Connector lock *
Connector
* Except for PKP223.
Pin No.1
Blue
Pin No.6
Green
Motor lead wires
Pin No.1
Pin No.6
• Connection cable
Wiring connection diagram
4/Black
5/Yellow
6/Green
AA
3/
Red
2/
White
1/
Blue
BB
• Unipolar 6 lead wires type
4/Black
6/Green
• Bipolar 4 lead wires type *
3/Red 1/Blue
AA
B B
* The pin Nos.2 and 5 are not used for the 4 lead wires type.

3
Applicable connector/lead wire
Motor
model Type Model
PKP223
Connector housing 51065-0600 (Molex)
Contact 50212-8XXX (Molex)
Designated crimping
tool 63819-0500 (Molex)
Applicable lead wire
yWhen the current value is less than
1 A/phase: AWG28 to 24 (0.08 to 0.2 mm2)
yWhen the current value is 1 A/phase or more:
AWG26 to 24 (0.14 to 0.2 mm2)
yWhen the current value is 1.5 A/phase or more:
AWG24 (0.2 mm2)
− Outer sheath diameter:
ø0.8 to 1.4 mm (ø0.031 to 0.055 in.)
− Strip length of the insulation cover:
1.3 to 1.8 mm (0.051 to 0.071 in.)
PKP243
Connector housing 51103-0600 (Molex)
Contact 50351-8XXX (Molex)
Designated crimping
tool 63811-8100 (Molex)
Applicable lead wire
yWhen the current value is less than
1.5 A/phase: AWG28 to 22 (0.08 to 0.3 mm2)
yWhen the current value is 1.5 A/phase or more:
AWG26 to 22 (0.14 to 0.3 mm2)
yWhen the current value is 2 A/phase or more:
AWG24 to 22 (0.2 to 0.3 mm2)
− Outer sheath diameter:
ø1.15 to 1.8 mm (ø0.045 to 0.071 in.)
− Strip length of the insulation cover:
2.3 to 2.8 mm (0.091 to 0.11 in.)
PKP264
Connector housing 51067-0600 (Molex)
Contact 50217-9XXX (Molex)
Designated crimping
tool 63811-8300 (Molex)
Applicable lead wire
− AWG24 to 18 (0.2 to 0.75 mm2)
− Outer sheath diameter:
ø1.4 to 3 mm (ø0.055 to 0.118 in.)
− Strip length of the insulation cover:
3 to 3.5 mm (0.118 to 0.138 in.)
Connection
•When inserting the connector
Hold the connector main body, and insert it in straight securely. Inserting the connector
in an inclined state may result in damage to connector or a connection failure.
•When pulling out the connector
Pull out the connector in straight while releasing the lock part of the connector. Having
the motor lead wires or pulling out the connector in a state of being locked may damage
the connector.
Secure the lead wires at the connection part to prevent the connection
part from receiving stress due to the exing of the lead wires or the lead
wires’own mass. Also, do not excessively bend the lead wires near the
connection part of the connector. Applying stress on the motor lead wires
may cause poor contact or disconnection, leading to malfunction or heat
generation.
Bend excessively
Have length allowances
More than 4 times
of the diameter of
the lead wires.
Connection with the drivers of Oriental Motor
Refer to the following table when connecting with the drivers of Oriental Motor.
“Color” in the table represents the colors of lead wires of the connection cable (supplied
or accessory).
The motors of the model A and model B are dierent in pin assignments.
Wrong connection will not cause the motor to operate properly.
•Connection with the CVD driver
Driver
CN2 Pin No.
Model A Model B
Pin No. Color Pin No. Color
1 4 Blue 1 Blue
2 5 Red 3 Red
3 − −
4 2 Green 6 Green
5 1 Black 4 Black
•Connection with the CMD driver
Driver
CN3 Pin No.
Model A Model B
Pin No. Color Pin No. Color
1 4 Blue 1 Blue
2 3 White 2 White
3 5 Red 3 Red
4 1 Black 4 Black
5 − 5 Yellow
6 2 Green 6 Green
Installation
Location for installation
The motor is designed and manufactured for installation in equipment.
Install it in a well-ventilated location that provides easy access for inspection. The
location must also satisfy the following conditions:
yInside an enclosure that is installed indoors (provide vent holes)
yOperating ambient temperature −10 to +50 °C (+14 to +122 °F) (non-freezing)
yOperating ambient humidity 85% or less (non-condensing)
yArea that is free of explosive atmosphere or toxic gas (such as sulfuric gas) or liquid
yArea not exposed to direct sun
yArea free of excessive amount of dust, iron particles or the like
yArea not subject to splashing water (rains, water droplets), oil (oil droplets) or other
liquids
yArea free of excessive salt
yArea not subject to continuous vibration or excessive shocks
yArea free of excessive electromagnetic noise (from welders, power machinery, etc.)
yArea free of radioactive materials, magnetic elds or vacuum
y1,000 m (3,300 ft.) or lower above sea level

4
yUnauthorized reproduction or copying of all or part of this manual is prohibited.
yOriental Motor shall not be liable whatsoever for any problems relating to industrial
property rights arising from use of any information, circuit, equipment or device
provided or referenced in this manual.
yCharacteristics, specications and dimensions are subject to change without notice.
yWhile we make every eort to oer accurate information in the manual, we welcome
your input. Should you nd unclear descriptions, errors or omissions, please contact the
nearest oce.
yis a registered trademark or trademark of Oriental Motor Co., Ltd.,
in Japan and other countries.
© Copyright ORIENTAL MOTOR CO., LTD. 2016
Published in February 2018
T
echnical Support Tel:[phone]
8:30
A.M. to 5:00 P.M., P.S.T. (M-F)
7:30
A.M. to 5:00 P.M., C.S.T. (M-F)
www
.orientalmotor.com
Schiessstraße 44, 40549 Düsseldor
f, Germany
T
echnical Support Tel:[phone]
www
.orientalmotor.de
T
el:01256-347090
www
.oriental-motor.co.uk
T
el:01 47 86 97 50
www
.orientalmotor.fr
T
el:02-93906346
www
.orientalmotor.it
T
el:[phone]
www
.orientalmotor.com.br
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno
,Taito-ku,Tokyo 110-8536
Japan
T
el:03-6744-0361
www
.orientalmotor.co.jp
Tel:[phone]
www.orientalmotor.com.tw
Singapore
Tel:[phone]
www.orientalmotor.com.sg
Tel:[phone]
www.orientalmotor.com.my
Korea
Tel:[phone]
www.inaom.co.kr
Tel:[phone]
www.orientalmotor.co.th
Tel:[phone]
www.orientalmotor.com.cn
Tel:[phone]
www.orientalmotor.co.in
Hong Kong Branch
Tel:[phone]
Installation method
Install the motor onto an appropriate at
metal plate having excellent vibration
resistance and heat conductivity.
When installing the motor, secure it with four
screws (not supplied) through the four screw
holes provided. Leave no gap between the
motor and plate.
Metal plate
Scr
ew holes
P
ilot holder
Model Nominal size Tightening torque
[N·m (oz-in)]
Eective depth of screw
thread [mm (in.)]
PKP223 M2.5 P0.45 0.5 (71) 4 (0.157)
PKP243 M3 P0.5 1 (142) 7 (0.278)
PKP264 M4 P0.7 2 (280) 8 (0.315)
Do not loosen the gearhead-attaching screws (four pcs.).
Installing a load
When connecting a load to the motor, align the centers of the motor’s output shaft and
load shaft. Be careful not to damage the output shaft or the bearings when installing a
coupling or pulley to the motor’s output shaft.
Permissible radial load and permissible axial load
The radial load and axial load on the motor output shaft must be kept under the
permissible values listed below.
zPermissible radial load
Model
Permissible radial load [N (lb.)]
Distance from the tip of motor output shaft [mm (in.)]
0 (0) 5 (0.2) 10 (0.39) 15 (0.59) 20 (0.79)
PKP223 15 (3.3) 17 (3.8) 20 (4.5) 23 (5.1) −
PKP243 10 (2.2) 15 (3.3) 20 (4.5) 30 (6.7) −
PKP264
(gear ratio: 3.6 to 10) 30 (6.7) 40 (9) 50 (11.2) 60 (13.5) 70 (15.7)
PKP264
(gear ratio: 18 to 36) 80 (18) 100 (22) 120 (27) 140 (31) 160 (36)
zPermissible axial load
Model Permissible axial load
[N (lb.)]
PKP223 10 (2.2)
PKP243 15 (3.3)
PKP264 30 (6.7)
Maintenance/inspection
Inspection
It is recommended that periodic inspections be conducted for the items listed below
after each operation of the motor. If an abnormal condition is noted, discontinue any use
and contact your nearest oce.
During inspection
yAre any of motor mounting screws loose?
yAre there any abnormal noises in the motor bearings (ball bearings) or other moving
parts?
yAre there any scratches, signs of stress in the motor lead wires?
yAre there any loose connections on the connector or driver?
yAre the motor’s output shaft and load shaft out of alignment?
Warranty
Check on the Oriental Motor Website or General Catalog for the product warranty.
Disposal
Dispose the product correctly in accordance with laws and regulations, or instructions of
local governments.
Specications
Check on the Oriental Motor Website for the product specications.
General specications
Degree of protection IP20
Operation
environment
Ambient
temperature −10 to +50 °C (+14 to +122 °F) (non-freezing)
Humidity 85% or less (non-condensing)
Altitude Up to 1,000 m (3,300 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Storage
environment,
Shipping
environment
Ambient
temperature −20 to +60 °C (−4 to +140 °F) (non-freezing)
Humidity 85% or less (non-condensing)
Altitude Up to 3,000 m (10,000 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Insulation
resistance
100 MΩ or more when 500 VDC megger is applied between the
case and motor windings.
Dielectric
strength
Sucient to withstand the following conditions applied between
the winding and the case for 1 minute:
• PKP23, PKP24: 0.5 kVAC 50/60 Hz
• PKP26: 1.0 kVAC 50/60 Hz
Regulations and standards
RoHS Directive
The products do not contain the substances exceeding the restriction values of RoHS
Directive (2011/65/EU).
