Orion OLMU-K4940 User manual

Infinitely Expandable MLCD
OLMU-K4940 | OLMU-K4970 | OLME-K4950 | OLME-K4970
User’s Manual
ORION DISPLAY CO.,LTD.
www.oriondisplay.net
Address: 217, 1gongdan-ro, Gumi-si, Gyeongsangbuk-do, Korea
Tel : [phone], Fax: [phone]
A revolutionary MLCD
Infinitely Expandable MLCD
A revolutionary MLCD
Please read through this user’s manual for safely before installing this product
2019. 12.19

Features
▶Enjoy a wide flat screen with high brightness and high quality.
▶Easy to install and move due to its thin design
▶Enjoy your favorite programs with various split-screen features simultaneously presenting
several programs.
To prevent electric shock, Do not remove cover.
No user serviceable part inside.
Refer servicing to qualified service personnel.
Warning
Thank you for purchasing our monitor.
This manual describes how to use the product and notes in use.
Please read the manual carefully before using it.
After reading this manual, please retain for future reference.
If you have any questions or a problem occurs, please contact either the company you
purchased this product from or an authorized service center.
※Displaying static picture for an extended period of time may cause an burn-in effect.
※Burn-in effect and the faults in brightness and picture elements caused by fixed images are not
subject to the warranty coverage.
If you fail to comply with the regulations for safety and proper use,
fire or injury may be caused.
Warning
Notice to users
Class A digital device
It is a device designed for business purpose with a safety certificate for electromagnetic interfere
nce, which user should be mindful of.
" Important Safety Instructions"
1)Read these instructions.
2)Keep these instructions.
3)Heed all warnings.
4)Follow all instructions.
5)Do not use this apparatus near water.
6)Clean only with dry cloth.
7)Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8)Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9)Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10)Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11)Only use attachments/accessories specified by the manufacturer.
12)Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from
tip-over.
13)Unplug this apparatus during lightning storms or when unused for long periods of time.
14)Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
The symbol in figure 21 shall be shown adjacent to the text of item 12 above.
Optional Accessories
MAIN FRAME
FCC Verified : Class "A"
This device complies with the Part 15 of the FCC Rules.Operation is subject to the following two c
onditions :
1) This device may not cause harmful interference, and 2) This device must accept any interf
erence received, including interference that may cause undesired operation.
- 1 -
DP Cable
Power Cable
Supplied Accessories
User's manual CD
RS-232C Cable Remote ControllerBattery (AAA X2)IR Receiver
Guide Pin(4pcs)

NOTICE
1. To disconnect the apparatus from the mains, the plug must be pulled out from the mainssocket,
therefore the mains plug shall be readily operable
2. WARNING- To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Appliance To
Rain Or Moisture.
3. Apparatus shall not be exposed to dripping or splashing and no objects filledwith liquids, such
as vases,shall be placed on the apparatus.
4. Useonly aproperly grounded plug and receptacle
5. "Warning" CAUTION –These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that contained in the
operating instructions unless you are qualified to do so.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
This symbol is intended to alert the user to the presence of important operating and
maintenance(servicing) instructions in the literature accompanying the appliance.
- 2-
Contents
- 3-
※European Union Disposal Information ............................................................................................
※Cautions for consisting ...................................................................................................................
※Clearance for Ventilation ................................................................................................................
※Cleaning and Maintenance..............................................................................................................
※Please keep following instruction for panel protection without exception........................................
※Handle with Caution ........................................................................................................................
※How to carry.....................................................................................................................................
※Application information ....................................................................................................................
※Attention for Installing .....................................................................................................................
1. Safety Precautions...........................................................................................................
2. Names................................................................................................................................
3. How to Connect Cables...................................................................................................
3.1. Connection of Single.................................................................................................................
3.2. Connection of Multiple (for daisy chain)....................................................................................
3.3. Connection of Multiple (for 1:1 connection)...............................................................................
3.4. Connection of Control Cable.....................................................................................................
4. ID Setting..........................................................................................................................
4.1. Sequential Connection.............................................................................................................
4.2. Random Connection.................................................................................................................
4.3. Using Auto Setting…................................................................................................................
5. OSD Menu.........................................................................................................................
5.1. Picture Menu.............................................................................................................................
5.2. Input Menu................................................................................................................................
5.3. Multi-Display Menu...................................................................................................................
5.4. Other Menu...............................................................................................................................
5.5. Information Menu.......................................................................................................................
5.6. How To Use Remote Controller.................................................................................................
6. Setting and operation of OSW …………….....................................................................
6.1. Installation.................................................................................................................................
6.2. Start OSW...............................................................................................................................
6.3. Communication Configuration..................................................................................................
6.4. Screen Configuration................................................................................................................
6.5. Explanation of the command transmission method..................................................................
6.6. Basic Control ……………………………………………..............................................................
6.7. Control......................................................................................................................................
7. PROTOCOL.......................................................................................................................
7.1. Communication Setting.............................................................................................................
7.2. Protocol Format.........................................................................................................................
7.3. Command.................................................................................................................................
8. Before calling for service................................................................................................
9. Applicable signals............................................................................................................
10. Specification…...............................................................................................................
11. Regulatory Information.................................................................................................
12. Dimension.......................................................................................................................
12.1. OLMU-K4940/OLMU-K4970....................................................................................................
12.2. OLME-K4950/OLME-K4970....................................................................................................
…4
…5
…6
…7
…8
…9
..10
..11
..12
.14
.16
.18
.18
.20
..21
..22
.24
..24
..26
..31
.34
..34
..35
..36
..37
..38
..39
.42
..42
..43
..46
..53
..54
..54
..60
.68
..68
..69
..70
.76
.77
.78
.79
.80
..80
..81

- Whenyouinstall monitormakesurethereis at least20cmclearanceforeffective
ventilation and do not sealoff monitorsets.
If monitorsets areinstalledat thelocationsof bad ventilation, theinner
temperaturecanbe raisedrapidlyand it cancausefrequentmalfunctions and
rapidreductionoftheproduct life.
* Ventilationspacein front of monitormust be furnishedforheat dispersion.If the
front space of monitorhas to be sealed,theremust be considerationfortheheat
dispersion in therear side of monitor.
- Regularlycleanoff theventholesin theback of monitorsets.
If the ventholesand thefanairholesarecloggedwithdust,it preventsthe air
flow inside of monitorsets.
It cancause rapidincreaseof theinnertemperatureand maycausemalfunctions.
Cleanoff theventholesand thefanair holeswith avacuumcleanerregularly.
※Clearance for Ventilation ※Cleaning and Maintenance
VacuumCleaner
WARNING
WARNING
- 6 -- 7-

WarningWarning
※Handle with Caution.
-Shock/Impact on the set's sides will result in internal
circuit damages.
-The edge/bottom of the panel are fragile.
Use shock-absorbing pads or rugs for laying down the
product.
※Please keep following instructi
on for panel protection without
exception.
- This product can be damaged even with minor impact
for its nature.
Please keep following instruction to carry or store the
products.
PANEL PANEL PANEL
PANEL CUSHION
PANEL
- 8- - 9-
•
If you need to stand LCD, •If you need to lay down •If you need to lay down LCD
•
Please do not stand LCD •Please do not lean over •Please do not lean over the
you must lean over the LCD as face down as face up position, please be alone. It may fall or slip off the LCD. It may damage LCD toward the edge part. It
LCD to avoid panel touches position, please use cautious for falling objects and Panel can be broken or the bottom part of the may damage the edge part
ground or floor . shock-absorbing pads on the surface of the LCD. damaged. LCD. of the LCD.
under the LCD.
WARNING
WARNING

※How to carry ※Application information
It always needstwopersonsto carry or install
monitor.
Whenyoucarry monitor with up straight
manner, pleaseholdhandleson thebackand
bottompart of the paneltogether.
Pleasebe carefulnot to touchthebottompart
of thepanelwhenyou put down the panel.
Don't carry monitorin Horizontal Status.
ÅÆ
- Changetheimagesof little luminance differencebetweenthebackground and characters,periodically.
Æ Æ Æ
-It is not recommendedto displaytheimagesof hugeluminancedifferencebetweenthebackground
and charactersor theimagesof greytone.
Whentwo operatorsuphold monitor, Panelis
twistedby unbalancedhandling.
Please do not touch the panel with your hand.
If static images aredisplayed on the screen for along time, it causes burn-in image.
Please keep the following instruction to optimize the lifetime and functions of the
product.
1. Operatingcondition
- Temperature: 20 ±15˚C
- Humidity:55 ±20 %
- Displaypattern: movingpictureor regularswitchover display
- Environmentalcondition: Wellventilatedplaceis recommended.
- Poweroffand screen saver: Periodicalpower-offor screen saveris needed afterlong-termstatic
display.
※Note: Moving pictureor blackpatternis stronglyrecommendedfor screen saver.
2. Operatingmethodsto minimize burn-in imagedue to long-term static information
display
-For optimalperformance,we suggestturningofftheLEDpoweron themonitorforfourhoursper day
- Periodicaldisplaycontentschangefromstaticimageto movingpicture.
- Periodicalbackground colorand character(image)colorchange
(X) (X)
-Scrollthecharactersperiodically.
ÆÆ
(WholeScreen Scroll)
UA 012
DEPARTURE
Flight
No.
Time Gate
UA 012 11:20 A02
KE 732 12:10 K17
AN 291 12:45 F11
DEPARTURE
Flight
No.
Time Gate
UA 012 11:20 A02
KE 732 12:10 K17
AN 291 12:45 F11
DEPARTURE
Flight
N
o.
Time
Gate
UA
012
11:20 A02
DEPARTURE
Flight
N
o.
Time
Gate
UA
012
11:20 A02
DEPARTURE
Flight
N
o.
Time
Gate
UA
012
11:20 A02
DEPARTURE
Flight
N
o.
Time
Gate
UA
012
11:20 A02
ARRIVAL
Flight
No.
Time Gate Delay
AA 213 9:20 K11 On time
OZ 621 11:25 G21 10 min.
JA 032 12:05 A19 On time
ARRIVAL
Flight
No.
Time
Embark
Delay
AA 213 9:20 NewY
ork
On time
OZ 621 11:25 Seoul 10 min.
JA 032 12:05 Beijing On time
DEPARTURE
Flight
No.
Time Gate
UA 012 11:20 A02
KE 732 12:10 K17
AN 291 12:45 F11
DEPARTURE
Flight
No.
Time Gate
UA 012 11:20 A02
13:40 K17
UA 012 17:03 A02
DEPARTURE
Flight
No.
Time Gate
UA 012 11:20 A02
KE 732 12:10 K17
AN 291 12:45 F11
WARNING
WARNING
- 10 - - 11 -

※Attention for Installing
Warning
•Avoid giving a shock or damage at LCD
corner or other parts during setting
Multi-Vision.
•Avoid that LCD is twisted.•Keep all LCDs balanced in vertical or
horizontal force after setting
•Multi-Vision. Avoid LCD is set up tilted so
it can give a damage to down LCD.
•Avoid that LCD outside is shocked or
damaged by sharp thing.
Fixed
- 12 - - 13 -
WARNING
WARNING
•Guide for peeling off side tape caution.
•Please, Peel off side tape slowly.

01. Safety Precautions
•If it operatesabnormally,stopusingit
immediately.
•Pleasereferto aspecializedconstruction
company for installingstand or wall
mountunit. Otherwise, damageor injury
maybecaused.
•Avoid any actionto damagethe power
cord or power plug. It maycausefireor
electricshock.
•Donot alter (ordisassemble) the
product. It maycauseelectricshock
sincehighvoltageisflowinginside.
•Donot placeanyliquid-containing
containeronit. If theinsideiswet, it
maycauseelectric shockor fire.
•Donot touchthe devicewhen lightning
strikes.
•Donot pull out thepower plugwith a wet
hand. It maycauseelectricshock.
•Donot installtheproduct where it may
beexposed to direct sunlightor near
anyheatingdevice. It mayshorten the
product's life spanor causefailure.
•Donot put any foreign materialinto
the product. It maycauseafailureor
shortenthelife span.
•Donot installinan unstablelocation
It maycauseinjury.
•Donot exceed ratings ofAC outlet
or extensioncords.It maycausefailure.
•Makesuretheproduct isnot covered
with any object. If theventilationhole is
blocked, the insidetemperaturemayrise
to causeoverheatingresultinginfire.
•Do not touchproduct’sfrontsurfacewith •Donot poke the frontscreenwith sharp
material.It maydamagethescreenand
maycausemalfunction of the product.
•Donot leanagainst theproduct or keep
it leaned. It maycauseinjuryor failure. •Donot put it at any placewith much
humidity, dust, oil, smoke or steam. It
maycausefailure.
•If you do not want to use the product
for a long time, keep the power plug
unpluggedto saveelectricity.
•Thesocket-outletshouldbe installed
neartheequipment and be easily
accessible.
•Donot put any heavyobject onit.
It maycausefailure.
•Donot pull out or hangdownthe
connectioncable. It maydamagethe
cordto causefire or electricshock.
•Pullout the power plugby holding the
plug. Otherwise,it maydamagethe
power cord to causefire or electric
shock.
•Donot ride or step ontheproduct It may
causebreakage whenfallendown. •Whenmovingit, disconnect the connectingcable. Otherwise, it may
damagethe cableto causefire or
electricshock.
•Installtheproduct onsafeand flat
surface.
•Donot put candleson theproduct. If the
liquidflowsinsidetheproduct. It may
cause electricshockor fire. hand. Otherwise, theimage qualitycan belowered.
- 14 - - 15 -

▶Input Ports ▶Front
▶Rear
02. Names
❶
❻
❷
❼
❸
❽
❹
❾
❺
❿
1. AC IN
AC 100V ~ 240V, 50/60Hz
2. A/S
Only for Firmware upgrade.
3. LAN
Display control via Ethernet (RJ45)
4. IR
Remote controller input port
5. RS232C IN
Display control via COM port
(D-Sub 9pin, FEMALE)
6. RS232C OUT
Display control via COM port
(D-Sub 9pin, MALE)
7. DVI IN
To input Display Port signals
8. HDMI IN
To input HDMI video signal.
9. DP IN
To input DisplayPort video signal.
10. DP OUT
For loop through video with other
monitors for sharing video signal through
DisplayPort.
- 16 - - 17 -

•Do not connect/disconnect cables while monitor or other external equipments are turned on.
•First turn off the power all the attached equipment and make connections.
•Make sure the power cord is inserted properly into the power inlet to prevent unexpected pullout of
the cord.
3.1. Connection of Single
ㆍMonitor and PC should be connected; a Com Port in a PC and RS-232C IN port in a monitor is
connected with supplied RS-232C cable.
ㆍIf you do not have Com Port, you need to use an USB converter for RS-232C. Depending on
manufacturers or models, converters may cause malfunction.
03. How to Connect Cables
ControlPC
DPCable
DVICab;e
HUB or Router
LANCable(Directcable)
LANCable(Directcable)
LANCable(CrossCableor DirectCable)
RS-232C
DPCable
HDMICable
DVDplayer
DVDplayer
DVDplayer
- 18 - - 19 -
LOOP OUT

3.2. Connection of Multiple (for daisy chain)
•Image quality can be affected by cable or signal quality.
•Please use DisplayPort cable with DisplayPort certified logo.
•Select DisplayPort cables feature a locking function. When removing this cable, hold down the top
button to release the lock.
•Recommended maximum set connection for Multi setting is shown in table below.
If you need to connect more than described in the table, you have to use distributors.
3.3. Connection of Multiple (for 1:1 connection)
•It is recommended you purchase certified cables. Otherwise, the screen may appear blank
or a connection error may occur.
•Image quality can be affected by cable or signal quality.
DP IN DP OUTHDMI-IINDVIIN DP IN DPOUTHDMI-IINDVIIN DP IN DP OUTHDMI-IINDVIIN
DP IN DPOUTHDMI-IINDVIIN DP IN DP OUTHDMI-IINDVIIN DP IN DP OUTHDMI-IINDVIIN
DP IN DP OUTHDMI-IINDVIIN DP IN DP OUTHDMI-IINDVIIN DP IN DP OUTHDMI-IINDVIIN
※Caution for Signal Distributor
If you want to display HDCP (High-bandwidth Digital Content P
rotection) applied contents, you must use the distributor that su
pports HDCP function.
INPUT SOURCE Resolution Output Port Connection Remark
DP / HDMI 3840 x 2160 x 60Hz DP OUT 6 sets HDCP Available
DVI 1920 x 1080 x 60Hz DP OUT 6 sets HDCP Available
DP IN DP OUTHDMI-IINDVIIN DP IN DP INHDMI-IINDVIIN DP IN DP OUTHDMI-IINDVIIN
DP IN DPOUTHDMI-IINDVIIN DP IN DP OUTHDMI-IINDVIIN DP IN DP OUTHDMI-IINDVI IN
DP IN DP OUTHDMI-IINDVI IN DP IN DP OUTHDMI-IINDVIIN DP IN DP OUTHDMI-IINDVIIN
Video Signal Distributor
VideoSource
- 20 - - 21 -
VideoSource
DPHDMI
DVI
DVI

3.4. Connection of Control Cable
•Control signal transmission can be connected by 3 different methods.(RS-232C or Ethernet
or IR)
•RS-232C and Ethernet connection cannot be used simultaneously.
•All control signals are output to the RS-232OUT after conversion to RS-232C signal.
3.4.1. Connection of RS-232C Cable
•Maximum use of RS-232C with Daisy Chain connection is 30 sets or less, if you need
additional connection, use RS-232C distributor.
RS-232CcontrolPC
RS-232C Cable
LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT
LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT
LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT
- 22 - - 23 -
3.4.2. Connection of Ethernet Cable
•In case of Ethernet connection, the control PC should be connected to one of monitor sets
with Ethernet cable.For the connection between the monitor sets, they should be
connected with RS-232C cables.
LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT
LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT
LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT LAN IR RS232CIN RS232COUT
EthernetcontrolPC
HUB or Router
(Wireless&Cable)
LANCable
LANCable
LAN

4. ID Setting
•Refer to the next chapter for OSW use.
•Before ID Setting Using OSW, Make sure that all of the connected MLCD sets are turned on by
clicking “POWER ON” button in Broadcast.
4.1. Sequential Connection
ㆍIt is the sequential RS-232C cable connection according to the order of ID numbers.
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LAN
I
R
RS232
C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
ID 1 ID 2 ID 3
ID 4 ID 5 ID 6
ID 7 ID 8 ID 9
RS-232C
control PC
RS-
232C
1.Click “MULTI → ID”
2.Click "AUTO ID SET" button in "ID" tab to complete ID setting.
3. After that, ID setting status in OSW Screen Configuration is as follows. It's same as
physical RS-232C cable connection. Because "AUTO ID SET" sets the order of ID
numbers according to the sequential RS-232C cable connection.
ID 7
ID 4
ID 1
ID 8
ID 5
ID 2 ID 3
ID 6
ID 9
- 24 - - 25 -

4.2. Random Connection
ㆍIt is the random RS-232C cable connection regardless of the order of ID numbers.
RS-232C
control PC
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
LA
NI RRS232 C IN RS232C OUT
RS-
232C
1.Click “MULTI → ID”.
2.Select another number, which is not in use, for “AUTO GROUP ID" and click "AUTO ID SET" in
“ID” menu
3. After that, ID setting status in OSW Screen Configuration is as follows. It's same as
physical RS-232C cable connection. Because "AUTO ID" sets the order of ID numbers
according to the sequential RS-232C cable connection.
* Group ID = GID, Monitor ID = MID
GID 2
MID 1
GID 2
MID 2
GID 2
MID 3
GID 2
MID 6
GID 2
MID 5
GID 2
MID 4
GID 2
MID 9
GID 2
MID 8
GID 2
MID 7
ID 2
ID 1
ID 3ID 4
ID 5
ID 6
ID 9
ID 8
ID 7
- 26 - - 27 -

4.Identify the IDs of all connected MLCD sets by clicking "INFO" button in Broadcast.
5.First, Identify the IDs of upper left corner MLCD set.
6.Set the IDs identified through the above 4,5) procedure for “CURRENT GROUP/MONITOR
ID” in “NEW ID” Menu. And then, set “NEW GROUP ID" as 1 and “NEW MONITOR ID" as 1 in
“NEW ID" Menu. And click "NEW ID SET" button in “NEW ID” menu.
7.Identify the IDs on the right MLCD set of upper left corner MLCD set in the same way as the
above 4) procedure.
8.Set the IDs identified through the above 7) procedure for “CURRENT GROUP/MULTI ID” in
“NEW ID” Menu. And then, Increase the number by 1 for “NEW MONITOR ID" in “NEW ID”
Menu to set the ID order. and click "NEW ID SET" button in “NEW ID” menu.
ID 1
ID 2
ID 3
ID 6
ID 5
ID 4 ID 9
ID 8
ID 7 ID 7
ID 4
ID 1
ID 8
ID 5
ID 2 ID 3
ID 6
ID 9 ID 1
ID 2
ID 1
ID 6
ID 5
ID 4 ID 9
ID 8
ID 7 ID 7
ID 4
ID 1
ID 8
ID 5
ID 2 ID 3
ID 6
ID 9
Group ID 2, Multi ID 3 Group ID 1, Multi ID 1 Group ID 2, Multi ID 4 Group ID 1, Multi ID 2
- 28 - - 29 -

9.Repeat the above 7) and 8) procedures for the rest of displays in the same order as the
number of the 10) procedure's capture view.
10.After setting last MLCD set, ID setting status in OSW Screen Configuration is as follows.
It's different from physical RS-232C cable connection.
ID 7
ID 4
ID 1
ID 8
ID 5
ID 2 ID 3
ID 6
ID 9
4.3. Using Auto Setting
ㆍThis feature is a way to automatically set the ID by entering a cable connection order
※ NOTE : This function is supported on OSW 2.1.3 and later versions.
1. Monitor Configuration
ㆍEnter the horizontal and vertical numbers in the X / Y fields. Click the SET button.
- 30 - - 31 -

2. Type in the panel
•Type the number in panel as physical RS-232 cable connection sequence.
▶Example
RS-232C
control PC
L
A
N
I
RRS23 2C IN RS232 C OUT
L
A
N
I
RRS23 2C IN RS232 C OUT
L
A
N
I
RRS23 2C IN RS232 C OUT
L
A
N
I
RRS23 2C IN RS232 C OUT
L
A
N
I
RRS23 2C IN RS232 C OUT
L
A
N
I
RRS23 2C IN RS232 C OUT
L
A
N
I
RRS23 2C IN RS232 C OUT
L
A
N
I
RRS23 2C IN RS232 C OUT
L
A
N
I
RRS23 2C IN RS232 C OUT
RS-
232C
•If the physical connection is above, type the number in auto setting panel as connection
sequence.
3. Auto Setting Start
• After typing the numbers in auto setting panel, then click the START button.
ID 1 ID 2 ID 3
ID 4 ID 5 ID 6
ID 7 ID 8 ID 9
• Setting is done, you can see IDs set as below.
- 32- - 33-

5.1. Picture Menu
ㆍUse this menu to activate Brightness/Contrast/sharpness and the luminance of the
backlight adjustment.
5. OSD Menu
[Input Menu Table]
[Picture Menu Table]
5.2. Input Menu
ㆍUse the Input Source menu to select between different video inputs that are be connected to the
monitor.
Picture Multi-DisplayInput
Backlight Brightness Contrast Sharpness
MUL
TI
Other
DP HDMI DVI
Picture Input Multi-Display
MUL
TI
Other
Menu Sub Menu Description Range
Input
DP
Select DP input when you are using the DP (DisplayPort) connector.
-
HDMI
Select
the HDMI input when you are using the HDMI connector.
Use
to select the HDMI input source. -
DVI
Select DVI input when you are using the DVI connector.
-
Menu Sub Menu Description Range
Backlight
Backllight
adjusts the luminance of the backlight 0 ~ 100
Brightness
Brightness
adjusts the brightness of the monitor. 0 ~ 100
Contrast
Contrast
adjusts the difference between darkness and lightness
on
the monitor. Adjust the Brightness first, and then adjust
Contrast
only if further adjustment is necessary. 0 ~ 100
Sharpness
Sharpness
adjusts the sharpness of the monitor 0~4
GAMMA
Select
a display gamma for best picture quality. 1.8/2.0/
2.2/2.4
TEMPERATURE
Adjust
the color temperature of the screen. If Color Temperature
needs
further adjustment, the individual R/G/B levels of the white
point
can be adjusted. Can be used only in User mode of Color
Temperature
.
10000/
9300/
6500/
USER
Studio Mode
Select
Studio Mode. The color temperature of Studio Mode is
about
3200K. ON/OFF
HUE
Adjustment
the hue value of the screen. 0 ~ 100
SAT
Adjustment
the saturation value of the screen. 0 ~ 100
Menu Sub Menu Description Range
Picture Color Range
Select
Color Range for input signal Only applied to HDMI, DVI).
The
color range of DP is detected Automatically Limit/Full
- 34 - - 35 -

- 36 - - 37 -
5.3. Multi-Display Menu
ㆍControl multi-scaling functions in this menu.
[Multi-Display Menu Table]
Picture Input Multi-Display
MUL
TI
Other
ID2ID1
ID4ID3
ON?OFF
1
2
•
1
2
•
1
2
•
Vertical
Numbers
1
1
2
2
3
3
Horizontal
Numbers
Multi On/Off Monitor ID H-Monitor V-Monitor
Multi-DisplayInput
MUL
TI
Picture Other
Reset Menu Time OSD H Position OSD V Position
Reset OSD OSD
5.4. Other Menu
ㆍReset of the OSD settings, menu time, transparency, position and rotation of the OSD can be
adjusted in other menu.
[Other Menu Table]
Menu Sub Menu Description Range
Multi
Display
Multi On/Off Activate the multi-scaling screen or Deactivate ON/OFF
Monitor ID Assign the ID to the monitor individually 1~254
H-Monitor set the number of horizontal monitor in multi-screen. 1~16
V-Monitor set the number of vertical monitor in multi-screen. 1~16
Multi Position set the position number of the segnent image in multi screen 240
B-Comp. Set Activate Bezel compensation ON/OFF
B-Comp. Value Set bezel compensation numerically 1~10
※The multiplies of H-monitor value and V-monitor value cannot exceed 240.
If the value of H-monitor is set to 16, the max value of V-monitor is 15.
Menu Sub Menu Description Range
Other
Reset
Initialize
all the setting value and options. ON/OFF
Menu Time
OSD
operation Time 3 ~ 60
OSD H Position
OSD
horizontal position adjustment . 0 ~ 100
OSD V Position
OSD
vertical position adjustment 0 ~ 100
Language
Select
the Language.
EN/DE/FR/ES
/NL/PL/RU/IT
Transparency
OSD
transparency ratio adjustment. 0 ~ 10
Rotate(OSD)
OSD
ROTATION.
0°/90°/270
°
Fan On/OFF
Turn
On/Off the fan operation. ON/OFF
Model Info
View
Model name, Ip address, Subnet Mask ,Gateway -
LAN
Tun
On or Off the Lan operation. ON/OFF
Auto Power On
Turn
On or Off the Auto Power On operation. ON/OFF
