Otto Bock A200 User manual

A200
Instructions for use ............................................................................................... 3

2 A200

Foreword1 6..............................................................................................................................................................
Product description2 6............................................................................................................................................
Function2.1 6..............................................................................................................................................
Product overview2.2 7..................................................................................................................................
Intended use3 8........................................................................................................................................................
Indications for use3.1 8................................................................................................................................
Indications3.2 8...........................................................................................................................................
Contraindications3.3 8.................................................................................................................................
Absolute Contraindications3.3.1 8....................................................................................................................
Relative Contraindications3.3.2 8.....................................................................................................................
Qualification3.4 8.........................................................................................................................................
Safety4 9....................................................................................................................................................................
Explanation of warning symbols4.1 9..............................................................................................................
Safety instructions for assembly and adjustments4.2 9......................................................................................
Safety instructions for use4.3 9......................................................................................................................
Side effects4.4 10........................................................................................................................................
Effects of electromagnetic interference on the product and on the user4.5 10......................................................
Further information4.6 11..............................................................................................................................
Nameplate and warning labels4.7 11..............................................................................................................
Signage on the product4.7.1 11.......................................................................................................................
Nameplate4.7.2 11..........................................................................................................................................
Warning labels4.7.3 12...................................................................................................................................
Delivery5 12...............................................................................................................................................................
Scope of delivery5.1 12................................................................................................................................
Storage5.2 13..............................................................................................................................................
Storage during daily use5.2.1 13......................................................................................................................
Storage during extended disuse5.2.2 13............................................................................................................
Preparing the product for use6 13.........................................................................................................................
Safety instructions6.1 13...............................................................................................................................
Initial operation6.2 14...................................................................................................................................
Settings6.3 14.............................................................................................................................................
Adjustments by qualified personnel6.3.1 14.......................................................................................................
Safety instructions6.3.1.1 15...............................................................................................................................
Adjusting the standard seat6.3.1.2 15..................................................................................................................
Adjusting the back support upholstery6.3.1.2.1 15...................................................................................................
Inserting foam elements6.3.1.2.2 16.......................................................................................................................
Adjusting the belt length6.3.1.3 16......................................................................................................................
Adjusting the control device6.3.1.4 17.................................................................................................................
Wheelchair control options6.3.1.4.1 17...................................................................................................................
Attendant control6.3.1.4.2 17.................................................................................................................................
Adjustments by the user6.3.2 17.......................................................................................................................
Adjusting the control device6.3.2.1 18.................................................................................................................
Delivery7 18...............................................................................................................................................................
Final inspection7.1 18..................................................................................................................................
Transport to the customer7.2 18....................................................................................................................
Handing over the product7.3 18.....................................................................................................................
Use8 18......................................................................................................................................................................
Circuit breaker8.1 18...................................................................................................................................
Side panels8.2 19........................................................................................................................................
Removing/installing the side panels8.2.1 19.......................................................................................................
Adjusting the side panels8.2.2 19.....................................................................................................................
Table of contents
3A200
Table of contents

Legrests8.3 20............................................................................................................................................
Removing/installing the leg supports8.3.1 20.....................................................................................................
Adjusting the leg supports8.3.2 20....................................................................................................................
Backrest8.4 21............................................................................................................................................
Folding the back support up/down8.4.1 21........................................................................................................
Adjusting the back support angle8.4.2 22..........................................................................................................
Getting in and transferring8.5 22...................................................................................................................
Control unit8.6 23........................................................................................................................................
Control panel8.6.1 23.....................................................................................................................................
Buttons and display functions8.6.2 23...............................................................................................................
Driving functions8.7 24.................................................................................................................................
Safety instructions8.7.1 24...............................................................................................................................
Driving notes8.7.2 26......................................................................................................................................
Switching on and off8.7.3 27............................................................................................................................
Selecting the speed levels8.7.4 28....................................................................................................................
Driving8.7.5 28...............................................................................................................................................
Range8.7.6 29................................................................................................................................................
Anti-tipper8.7.7 29..........................................................................................................................................
Drive-away lock8.7.8 29...................................................................................................................................
Adapting the driving characteristics8.7.9 30.......................................................................................................
Enabling/disabling the brakes8.8 30...............................................................................................................
Batteries/charging process8.9 31..................................................................................................................
Safety instructions8.9.1 31...............................................................................................................................
General8.9.2 31.............................................................................................................................................
Installing/removing the battery pack8.9.3 31......................................................................................................
Battery charging information8.9.4 32.................................................................................................................
Battery charger8.9.5 33...................................................................................................................................
Charging the batteries8.9.6 33.........................................................................................................................
Seat8.10 34..................................................................................................................................................
Safety instructions8.10.1 34...............................................................................................................................
Contoured pads8.10.2 35..................................................................................................................................
Detaching/attaching the covers8.10.2.1 35.............................................................................................................
Cleaning the covers8.10.2.2 36............................................................................................................................
Seat cushion8.10.3 36......................................................................................................................................
Adjusting the seat angle8.10.4 36.......................................................................................................................
Headrest8.10.5 37............................................................................................................................................
Manual seat functions8.11 37..........................................................................................................................
Safety instructions8.11.1 37...............................................................................................................................
Manual back angle adjustment8.11.2 37..............................................................................................................
Manually elevating legrests8.11.3 38...................................................................................................................
Lap belt8.12 38.............................................................................................................................................
Adaptation8.12.1 38.........................................................................................................................................
Use8.12.2 39...................................................................................................................................................
Control unit accessories8.13 40......................................................................................................................
Attendant control8.13.1 40.................................................................................................................................
Additional options8.14 41...............................................................................................................................
Control panel holder8.14.1 41............................................................................................................................
Adjusting the control panel position8.14.1.1 42.......................................................................................................
Overview of other options8.14.2 43.....................................................................................................................
Disassembly and transport8.15 43...................................................................................................................
Safety instructions8.15.1 43...............................................................................................................................
Reducing the transportation size8.15.2 43...........................................................................................................
Preparing for transport8.15.3 45.........................................................................................................................
Assembly8.15.4 45...........................................................................................................................................
Use in vehicles for transporting persons with reduced mobility8.16 46..................................................................
Required accessories8.16.1 46..........................................................................................................................
Using the product in a vehicle8.16.2 47...............................................................................................................
4 A200
Table of contents

Restrictions for use8.16.3 49.............................................................................................................................
Care8.17 49..................................................................................................................................................
Safety instructions8.17.1 49...............................................................................................................................
Cleaning8.17.2 49............................................................................................................................................
Disinfection8.17.3 49........................................................................................................................................
Maintenance and repair9 50...................................................................................................................................
Maintenance9.1 50.......................................................................................................................................
Maintenance intervals9.1.1 50..........................................................................................................................
Repair9.2 51...............................................................................................................................................
Replacing a defective fuse9.2.1 51....................................................................................................................
Wheel replacement9.2.2 52.............................................................................................................................
Replacing the inner tube and tyre9.2.3 52..........................................................................................................
Replacing the battery9.2.4 52...........................................................................................................................
Troubleshooting9.3 53..................................................................................................................................
Types of notifications9.3.1 53...........................................................................................................................
Procedure for warnings and error messages9.3.2 53..........................................................................................
Wheelchair control unit error overview9.3.3 53...................................................................................................
Attendant control error overview9.3.4 54............................................................................................................
Behaviour in case of breakdowns9.4 54..........................................................................................................
Disposal10 55.............................................................................................................................................................
Safety instructions10.1 55...............................................................................................................................
Disposal information10.2 55............................................................................................................................
Information on re-use10.3 55...........................................................................................................................
Legal information11 55..............................................................................................................................................
Liability11.1 55..............................................................................................................................................
Warranty11.2 55............................................................................................................................................
Privacy notice11.3 55.....................................................................................................................................
Service life11.4 55.........................................................................................................................................
Technical data12 56...................................................................................................................................................
Appendices13 58........................................................................................................................................................
Threshold values for wheelchairs transportable by train13.1 58...........................................................................
Required tools13.2 58....................................................................................................................................
Torque values of the screw connections13.3 58.................................................................................................
Sound emission information13.4 58.................................................................................................................
5A200
Table of contents

1 Foreword
INFORMATION
Date of last update: 2020-03-13
►Please read this document carefully before using the product and observe the safety notices.
►Obtain instruction from the qualified personnel in the safe use of the product.
►Please contact the qualified personnel if you have questions about the product or in case of problems.
►Report each serious incident in connection with the product, in particular a worsening of the state of health, to
the manufacturer and to the relevant authority in your country.
►Please keep this document for your records.
INFORMATION
►New information regarding product safety and product recalls as well as the declaration of conformity can be
obtained at [email protected] or from the manufacturer’s service department (see inside or outside of back
cover for addresses).
►You can request this document as a PDF file at [email protected] or from the manufacturer’s service depart
ment (see inside or outside of back cover for addresses). The PDF file can also be displayed in a larger size.
You have received a product that is very versatile for everyday use at home and outdoors.
In order to exclude injuries of any type, familiarise yourself with the handling, functions and intended use of the
product before using it. These instructions for use provide you with the related necessary information.
Please note the following in particular:
• All users and/or their attendants must be trained by qualified personnel in the use of the product. In particular,
users and/or attendants must be informed of the residual risks with the aid of the safety notices in these instruc
tions for use.
• The product was adapted to the needs of the user. Subsequent changes may be made only by qualified per
sonnel. We recommend checking the product settings onceper year to ensure optimal treatment over the long
term. Especially for users with a changing anatomy (forexample body dimensions, weight), an adjustment at
least onceevery six months is recommended.
• Note the address and telephone number of the responsible qualified personnel and keep this information with
you, especially when using the product outdoors. Inform the qualified personnel immediately in case of a mal
function. Provide all relevant details to make quick assistance possible.
• Your product may differ from the models shown. In particular, not all the options described in these instruc
tions for use will be installed on your product.
• The manufacturer reserves the right to make technical changes to the model described in these instructions for
use.
2 Product description
2.1 Function
The wheelchair is intended exclusively for transporting one person on the seat.
The wheelchair can be used indoors on solid surfaces (Category A according to EN 12184).
It is designed to be compact and manoeuvrable indoors.
Two 12-V batteries power the drive system and ensure safe operating performance.
The power wheelchair is controlled by the VR2 wheelchair control device (see Page23). The latter includes a con
trol panel to enter driving commands and display the current status as well as a controller that operates the drive
motors and other electrical functions based on the inputs.
The special features of the power wheelchair include:
• Compact design and ease of use.
• Frame that can be disassembled, making transportation easier.
• Serviceability due to easy, straightforward access to all components.
6 A200
Foreword

2.2 Product overview
1
1 Push bar 8 Caster wheel
2 Back support 9 Drive wheel
3 Arm support (side panel) 10 Battery (2 battery packs)
4 Control panel with joystick 11 Mechanical back support angle adjustment
(option)
5 Seat cushion 12 Plug with battery cable
6 Quick-release lever for seat inclination adjust
ment
13 Anti-tipper
7 Leg support
7A200
Product description

3 Intended use
The safe use of the product can only be ensured in case of intended use in accordance with the information con
tained in these instructions for use. The user is ultimately responsible for accident-free operation.
3.1 Indications for use
The wheelchair is intended for indoor transportation, by the user, of people with temporary or permanent limitations
of the ability to walk, inability to walk or difficulty standing up. Optionally, the power wheelchair can be controlled
by an attendant with the help of an attendant control device.
The product is suitable for users with intact skin whose anatomy (suchas body dimensions and weight) permits the
intended use of the product.
The wheelchair may only be used with the options listed on the order form.
The manufacturer assumes no liability for combinations with third-party medical devices and/or accessories not
included in the modular system.
3.2 Indications
• Minor to pronounced or complete restrictions of mobility
3.3 Contraindications
3.3.1 Absolute Contraindications
• None known
3.3.2 Relative Contraindications
• Failure to meet physical or mental requirements
3.4 Qualification
The installation and adjustment tasks described in the section "Adjustments by qualified personnel" (see Page14
ff.) may only be carried out by qualified personnel. Compliance with all manufacturer specifications and all applic
able legal provisions is required. Please contact the manufacturer’s service department for further information (see
inside or outside of rear cover for addresses).
8
Intended use
A200

4 Safety
4.1 Explanation of warning symbols
WARNING Warning regarding possible serious risks of accident or injury.
CAUTION Warning regarding possible risks of accident or injury.
NOTICE Warning regarding possible technical damage.
4.2 Safety instructions for assembly and adjustments
WARNING
Making incorrect adjustments
Risk of falling, tipping over or malposition of the user due to incorrect settings
►Settings may only be changed by qualified personnel unless otherwise prescribed.
►Before testing setting changes with the user seated, all screw connections must be firmly tightened.
►Check the product for safety and functionality after changing the settings.
4.3 Safety instructions for use
WARNING
Improper product operation
Falling, tipping over, collision due to user error
►The product may only be used by a qualified user.
►As a user or attendant, you must be trained in the use of the product by qualified personnel.
►Read the entire instructions for use.
►The product may not be used in case of exhaustion or under the influence of alcohol, medications or drugs.
►The product may not be used by users who have any mental limitations which can temporarily or permanently
limit attentiveness and judgement.
►Observe road traffic regulations during operation in public road traffic.
WARNING
Impermissible use
Risk of pinching, crushing, being pulled in, tipping, falling due to improper handling
►Only use this product for its original intended purpose.
►Only one person may be transported with the product at any one time.
WARNING
Overloading
Severe injuries if the product tips over due to overloading, damage to the product
►Do not exceed the maximum load capacity (see the nameplate and section "Technical data").
►Please note that certain accessories and add-on components will reduce the remaining load capacity.
WARNING
Exceeding the service life
Serious injuries due to failure to observe the manufacturer’s requirements
►Using the product beyond the specified expected service life leads to increased residual risk.
►Observe the specified service life.
CAUTION
Skin damage
Skin damage or pressure points due to overloading
►Check your skin for intactness before and during use of the product.
►Pay attention to diligent skin care and pressure redistribution during interruptions in using the product.
►If skin damage or other problems occur during use, stop using the product. Consult the qualified personnel.
9A200
Safety

CAUTION
Use of the product during diagnostic examinations and therapeutic treatment
Impairment of the examination results or the effectiveness of treatment due to interactions of the product with
devices that are used
►Make sure that examinations and treatments are carried out exclusively under the prescribed conditions.
CAUTION
Extreme temperatures
Hypothermia or burns due to contact with components, failure of components
►Do not expose the product to any extreme temperatures (e.g.direct sunlight, sauna, extreme cold).
►Do not leave the product in the immediate vicinity of heaters.
NOTICE
Use under incorrect environmental conditions
Damage to the product due to excessively high or low temperatures
►Only use the product within a temperature range of -15°C to +40°C (5°F to +104°F).
WARNING
Neglecting the duty to supervise
Risk of suffocation due to small loose parts
►Note that the product includes small parts that can be loosened and removed without tools.
►Ensure that small children, forexample, do not swallow them.
4.4 Side effects
The following side effects may occur during use of the product:
• Neck, muscle and joint pain
• Circulatory disorders, risk of pressure sores
Contact a doctor or therapist in case of problems.
4.5 Effects of electromagnetic interference on the product and on the user
CAUTION
Use of mobile devices with electromagnetic emissions (e.g., mobile phones)
Falling, collision with persons or objects due to interference with the control signals
►Turn all mobile devices off while driving, since the driving characteristics of the product are affected by elec
tromagnetic fields.
►Turn the control unit off when it is not required, since the product may generate electromagnetic fields that
can cause interference with other devices. The product has been tested according to EMC regulations.
►Notwithstanding compliance with all applicable EMC directives and standards, the product can be affected by
interference from other electric devices (e.g., department store EAS systems) or cause interference with such
devices. If this occurs, move your product outside the interference range.
• Powered wheelchairs may be susceptible to electromagnetic interference (EMI), which is interfering electro
magnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmit
ters, two-way radios, and cellular phones.
• The interference (from radio wave sources) can cause the powered wheelchair to release its brakes, move by
itself, or move in unintended directions.
• It can also permanently damage the powered wheelchairs control system.
• Because EM energy rapidly becomes more intense as one move closer to the transmitting antenna (source),
the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to uninten
tionally bring high levels of EM energy very close to the powered wheelchair's control system while using these
devices. This can affect powered wheelchair movement and braking.
• Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD
players, and cassette players, and small appliances, such as electric shavers and hair dryers, so far as we
know, are not likely to cause EMI problems to your powered wheelchair.
10
Safety
A200

4.6 Further information
INFORMATION
The serial number required for enquiries and orders can be found on the nameplate. For explanations of the
nameplate, see the section "Nameplate" (see Page11).
4.7 Nameplate and warning labels
4.7.1 Signage on the product
The warning signs and nameplates are attached at the following mounting points to the power wheelchair:
CLOSE
CS:
DA:
DE:
EN:
ES:
FI:
FR:
Třída A
Klasse A
Klasse A
Class A
Categoria A
Luokka A
Classe A
HR:
HU:
IT:
NL:
NO:
PL:
PT:
Razred A
Osztály A
Classe A
Klasse A
Klasse A
Klasa A
Classe A
2
Warning signs and nameplates on the power wheelchair
4.7.2 Nameplate
The nameplates are found on the side of the frame under the seat.
Label Meaning
AManufacturer’s product name
BCE marking
CMaximum load (see section “Technical data”)
DMaximum climbing ability (see section “Technical data”)
EMaximum speed (see section “Technical data”)
FAllowable axle load, front
GAllowable axle load, rear
HAllowable overall weight
IManufacturer information/address
JSerial number1)
KManufacturing date2)
LSymbol for medical device
M WARNING! Read the instructions for use before using the
product. Observe important safety-related information
(e.g.warnings, precautions).
11A200
Safety

Label Meaning
NSymbol for separate collection of electrical and electronic
devices. Components of the power wheelchair and batteries
may not be disposed of in household waste.
OManufacturer’s reference number for the product variant
PSerial number (PI)3),1)
QGlobal Trade Item Number (DI)4)
1)MMM = model/model variant; S = speed code; YY = year of manufacture; WW = week of manufacture; PP = pro
duction site; XXX = sequential production number
2)YYYY = year of manufacture; MM = month of manufacture; DD = day of manufacture
3)UDI-PI to GS1 standard; UDI = Unique Device Identifier, PI = Product Identifier
4)UDI-DI to GS1 standard; UDI = Unique Device Identifier, DI = Device Identifier
4.7.3 Warning labels
Label Meaning
CLOSE
Engage the locking bar before use. Observe the information in
the instructions for use.
APower driving mode: lock motor brake
BManual driving mode: unlock motor brake
CS:
DA:
DE:
EN:
ES:
FI:
FR:
Třída A
Klasse A
Klasse A
Class A
Categoria A
Luokka A
Classe A
HR:
HU:
IT:
NL:
NO:
PL:
PT:
Razred A
Osztály A
Classe A
Klasse A
Klasse A
Klasa A
Classe A
Application class A (according to DIN EN 12184)
(Only in case of installation of ISO sets according to ISO
7176)
Fixation point/eyebolt to attach the product in vehicles for trans
porting persons with reduced mobility
5 Delivery
5.1 Scope of delivery
The power wheelchair is normally shipped fully assembled and fitted to the personal requirements of the respective
user.
The scope of delivery includes:
• Fitted power wheelchair with main components
• Installed options
• Battery charger
• Instructions for use
• Instructions for use for accessories (depending on equipment)
12
Delivery
A200

5.2 Storage
5.2.1 Storage during daily use
The power wheelchair should always be protected against external influences.
The control unit must be turned off.
5.2.2 Storage during extended disuse
NOTICE
Deep discharge
Battery damage due to standby current
►Remove the fuse if the wheelchair is not used for more than 3 days.
Please observe the following if the power wheelchair is not used for more than 3days:
Storage conditions
• Store the power wheelchair in a dry, enclosed room with sufficient air circulation and protection from external
influences. Specific information about storage conditions: see Page56.
• Protect the wheels against ground frost, forexample by taking all weight off them using an assembly stand or
by setting them onto wooden blocks.
• Maintain sufficient clearance from sources of heat. If the product is parked for an extended period of time or
the tyres overheat (e.g.in the vicinity of radiators or in case of exposure to strong sunlight behind glass), the
tyres may become permanently deformed.
• Fill pneumatic tyres with slight overpressure.
• Rotate the wheels weekly to prevent flat tyres from extended standing.
• For extended storage, store the power wheelchair so the wheels are not in contact with the ground.
Note regarding the tyres
• If the power wheelchair is not moved for several days, permanent colour changes may develop where it comes
into contact with the ground. A suitable base should therefore be used when parking it for extended periods of
time.
• Black tyres contain carbon black particles. They may leave black friction marks where they come into contact
with the ground. Therefore, the manufacturer recommends grey tyres if the product is primarily used indoors.
• Avoid unnecessary parking outdoors. Direct exposure to sunlight/UV radiation causes the tyres to age more
quickly. As a result, the tread surface hardens and corner pieces break out of the tread.
• The tyres must be changed when the tread is less than 1mm (0.04") to ensure safe driving behaviour.
• The tyres should be replaced every 2years regardless of wear and tear.
• When power wheelchairs with PU tyres are parked for longer periods, the tyres may become deformed (flat
spots). This deformation will go away on its own over time while driving.
6 Preparing the product for use
6.1 Safety instructions
General hazards while putting into operation
WARNING
Improper handling of packaging materials
Risk of suffocation due to neglect of the duty to supervise
►Packaging materials must be kept out of the reach of children.
WARNING
Uncontrolled movement of components when making adjustments
Crushing, pinching, blows due to non-observance of the maintenance and repair instructions
►Ensure that body parts, such as hands or head, are never in the danger zone.
►Perform the work with the aid of a helper for support.
13A200
Preparing the product for use

Hazards while putting into operation by qualified personnel
WARNING
Incorrect charging or use of the battery
Injuries due to fire or explosion, damage to the battery, short circuit
►Observe the safety notices in the section "Use" > "Batteries/charging process" (see Page31).
Hazards while putting into operation by the user
WARNING
Independent modification of settings
Serious injuries to the user due to improper changes to the product
►Do not modify the settings established by the qualified personnel. Only the settings described in the section
“Use” in these instructions for use may be adjusted independently.
►In case of problems with the settings, please contact the qualified personnel who adjusted your product.
CAUTION
Screw connections not tightened
Pinching, crushing, tipping over, falling of user due to assembly errors
►After all adjusting/readjusting work authorised by the manufacturer, retighten the mounting screws/nuts firmly.
Observe any torque settings which may be specified.
6.2 Initial operation
The qualified personnel delivers the power wheelchair fully assembled and in operational condition.
The following additional tasks may be required:
•Only if needed: Assembling the frame and drive unit bracket (see Page45)
• Adjusting the settings (see next section)
• Installing the fuse (see Page18)
• Installing the battery pack (see Page31)
• Charging the battery (see Page33)
• Folding up the backrest (see Page21)
• Installing the side panels (see Page19)
• Installing the leg supports (see Page20)
6.3 Settings
6.3.1 Adjustments by qualified personnel
The seat height, seat width and seat angle have been preset in accordance with the customer order.
Changes to these basic settings may only be made by qualified personnel. Please see the service manual for fur
ther information.
All parts of the product should be cleaned thoroughly before adjustments are made.
The tools required for adjustments and maintenance tasks as well as the torque values for screw connections are
listed in the section "Appendices" (see Page58).
14
Preparing the product for use
A200

6.3.1.1 Safety instructions
WARNING
Making incorrect adjustments
Risk of falling, tipping over or malposition of the user due to incorrect settings
►The tasks described below may only be carried out by qualified personnel.
►Settings may only be changed within the allowable adjustment ranges; otherwise, the stability of the product
may be impaired (see this section and the “Technical data” section). If you have questions, contact the manu
facturer's service (see back cover for addresses).
►Only conduct tests in the presence of an assistant.
►Unless expressly described, you may not change any settings with a person sitting in the product.
►Secure the user against falling out during all tests.
►Before testing setting changes with the user seated, firmly tighten all screw connections.
►Check for safe function before delivering the product.
CAUTION
Unsecured screw connections
Pinching, crushing, tipping over, falling of user due to assembly errors
►Always firmly re-tighten the mounting screws and nuts after changing settings. Observe the specified torques
in doing so.
►Any time you loosen a screw connection with thread lock, replace it with a new screw connection with thread
lock or secure the old screw connection with medium strength thread locker (e.g.Loctite241).
►Always replace self-locking screws and nuts with new self-locking screws and nuts after disassembly.
CAUTION
Improper lifting
Crushing, pinching, blows due to failure to observe safety instructions
►Some parts of the power wheelchair, such as the batteries, frame, seat, and motors, are very heavy. Ensure
ergonomically correct lifting of these parts. Use sufficiently large hoisting devices or perform this work with a
helper.
►If it is necessary to work underneath raised parts or equipment, make sure these are secured by suitable
means so that they cannot come loose, shift, or fall down.
►When using lifting platforms, ensure that the power wheelchair is centred on the platform and that no parts
protrude into the danger zone.
NOTICE
Improper preparation before making adjustments
Damage to the product due to falling down and failure to follow setting instructions
►When you work on the product, secure it so that it cannot tip over or fall over.
►Turn the power wheelchair off and remove the fuse before making any adjustments. Functional tests of the
electrical components are excepted from this rule.
►Before performing any work on the seat, ensure that the cushion is sufficiently protected against mechanical,
chemical, and thermal effects.
NOTICE
Use of unsuitable packaging
Damage to the product caused by transportation using incorrect packaging
►Use only the original packaging for delivery of the product.
6.3.1.2 Adjusting the standard seat
6.3.1.2.1 Adjusting the back support upholstery
INFORMATION
A well-adjusted back support provides lasting comfort for the wheelchair user and reduces the risk of secondary
damage and pressure zones.
15A200
Preparing the product for use

INFORMATION
Ensure that the user's pelvis is positioned as far back in the seat as possible, i.e.between the back support
tubes.
The adjustable back support upholstery can be adjusted in segments to the needs of the user. In order to properly
adjust the upholstery, the user must be sitting in the wheelchair during the adjustment process.
3Adjusting the back support upholstery
1) Pull the fabric of the back support pad off the hook-
and-loop straps of the back support upholstery and
fold it up.
2) Open and loosen the hook-and-loop straps one
after the other (see fig.3).
3) From the bottom to the top, adjust the tension of the
hook-and-loop straps to the weight and anatomical
condition of the user and fasten the straps one after
the other.
INFORMATION: The two ends of the hook-and-
loop strap have to overlap by at least 100mm in
each case.
INFORMATION: Adjust the respective lower
hook-and-loop straps somewhat tighter. Deviat
ing adjustments may be required in specific
cases; this is the responsibility of the attending
therapist.
4) Fold the fabric of the back support pad over the
hook-and-loop straps and press it into place.
6.3.1.2.2 Inserting foam elements
INFORMATION
Please note that the correction pads are not included in the scope of delivery and cannot be ordered from
Ottobock. Please use corresponding foam elements from your inventory.
The sitting position can be fine-tuned by using various correction pads in the backrest.
4Fine-tuning the backrest
1) Open the side of the back pad. In order to do so,
loosen the hook-and-loop closures of the side open
ings.
2) Select the correction pads as required. These can
be positioned by turning/sliding to offer additional
lateral guidance for the user.
3) Insert the correction pads as required.
4) Fasten the hook-and-loop closures on the side
openings again.
6.3.1.3 Adjusting the belt length
CAUTION
Incorrect approach to the adjustment process
Injuries, malpositions, user discomfort due to adjustment errors
►The qualified personnel is responsible for the individual positioning and fitting of the belt system.
►Adjusting the belt system too tightly may lead to unnecessary pain or user discomfort.
►Adjusting the belt system too loosely can cause the user to slide into a dangerous position. In addition, the
fastening snaps could open unintentionally if they slide against hard parts of clothing (e.g.buttons).
16
Preparing the product for use
A200

CAUTION
Lack of instruction
Injuries, malpositions, illness of the user due to incorrect information
►The qualified personnel is responsible for making sure that the user and/or attendant/nursing staff has under
stood the proper adjustment, use, maintenance and care of the belt system.
►In particular, ensure that the user and/or attendant/care staff knows how to quickly loosen and open the
product to avoid delays in case of emergency.
Notes on correctly applying and adjusting the lap belt: see Page38.
6.3.1.4 Adjusting the control device
WARNING
Incorrect configuration settings
Falling, tipping over, collision due to programming errors
►Programming the control device may only be performed by qualified personnel. The manufacturer of the
product and the control device manufacturer are not liable in case of damage caused by programming which
was not performed properly and/or which was not adjusted properly according to the user’s abilities.
►Note that modified parameter settings in the configuration can lead to changes in driving characteristics. In
particular, changes to the speed, acceleration, braking or joystick settings can lead to unexpected and there
fore uncontrollable driving characteristics and cause an accident.
►After configuration/programming is complete, the user must test the driving characteristics of the product
under the supervision of the qualified personnel.
6.3.1.4.1 Wheelchair control options
If necessary, the programming of the wheelchair control unit can be adjusted to the specific user requirements.
Information on using the wheelchair control unit: see Page23.
Troubleshooting information: see Page53.
Further information on programming can be found in the service manual or the supplied instructions for use from
the control device manufacturer Curtiss-Wright.
6.3.1.4.2 Attendant control
The power wheelchair can be ordered and equipped with an attendant control. It may be necessary to fit the
already installed attendant control to the actual body size of the attendant.
Information on operating the attendant control: see Page.
Troubleshooting information: see Page54.
6.3.2 Adjustments by the user
CAUTION
Screw connections not tightened
Pinching, crushing, tipping over, falling of user due to assembly errors
►After all adjusting/readjusting work authorised by the manufacturer, retighten the mounting screws/nuts firmly.
Observe any torque settings which may be specified.
The user or attendant may only perform the fine-tuning adjustments described in the following. The user should be
sitting upright in the power wheelchair while making adjustments.
• Adjusting the armrests (see Page19)
• Adjusting the lower leg length and foot support angle (see Page20)
• Adjusting the back angle (see Page22)
• Adjusting the position of the control panel (see Page42)
• Adjusting the lap belt (see Page38)
All parts of the product should be cleaned thoroughly before adjustments are made.
17A200
Preparing the product for use

6.3.2.1 Adjusting the control device
WARNING
Incorrect configuration settings
Falling, tipping over, collision due to programming errors
►Programming may only be performed by qualified personnel. The manufacturer of the product and the control
device manufacturer are not liable in case of damage caused by programming which was not performed prop
erly and/or which was not adjusted properly according to the user’s abilities.
If necessary, the qualified personnel can adapt the preprogrammed wheelchair control unit and options to the con
crete requirements of the user.
7 Delivery
7.1 Final inspection
A final inspection must be performed before delivery of the power wheelchair:
• Was the product fitted optimally to the physical and mental condition of the user (e.g.seat, arm support/side
panel, leg supports, control panel)?
• Are the batteries charged?
• Is the tyre pressure correct (see tyre sidewall and the section "Technical data" for information)?
• Do all manual and power functions work properly?
• Do all control functions work properly?
• Do the brakes work?
7.2 Transport to the customer
Instructions for disassembly and transport: see Page43.
7.3 Handing over the product
WARNING
Lack of instruction
Tipping over, falling of the user due to lack of knowledge
►Instruct the user or the attendant in the proper use of the product when handing it over.
The following steps must be performed for the safe handover of the product:
• Have the user get into the product and perform a trial seat fitting. Pay special attention to proper positioning
according to medical considerations.
• The user and any attendants must be instructed in the safe use of the product. The instructions for use in par
ticular have to be used.
• The instructions for use must be given to the user or an attendant upon delivery of the wheelchair.
• The user or attendant should acknowledge that they have been instructed in how to use the product and were
informed of the residual risks.
•Depending on equipment: The supplied instructions for use for accessories have to be handed over in addi
tion.
8 Use
8.1 Circuit breaker
INFORMATION
►Should the fuse burn out repeatedly after a short time for no discernible reason, contact the qualified person
nel.
►For shipping or when the power wheelchair is not being used for an extended period of time, the fuse should
be removed.
Note: The fuse typically comes installed in the dedicated fuse holder when the wheelchair is handed over to the
user.
Before the power wheelchair can be switched on, the fuses may have to be inserted into the fuse holders provided
for the purpose.
18
Delivery
A200

They are located on the underside of the battery packs (see fig.5).
5Installing the fuse
1) Remove the battery packs (see Page31).
2) Remove the fuse from the supplied protective cover.
3) Insert the fuse into the slot provided (see fig.5).
4) Reinstall the battery packs (see Page31).
Removing the fuse
>Prerequisite: The control unit is switched off.
1) Remove the battery packs (see Page31).
2) Take the fuse out of the slot (see fig.5).
3) Reinstall the battery packs (see Page31).
8.2 Side panels
INFORMATION
Additional information for adjusting the control panel position: see Page42.
The side panels protect the user and his/her clothing from getting dirty.
The installed armrests offer the user additional support for the forearms.
8.2.1 Removing/installing the side panels
To make getting in from the side easier or for transportation, the side panels can be removed if needed.
6Removing the side panel
1) Loosen the thumb screw on the side panel holder
(see fig.6, item1).
2) Pull the side panel out from the side panel holder
and set it aside.
3) Only for side panel with control panel:
→Carefully let the side panel with the control pan
el hang down while getting in.
→For transporting the power wheelchair, place
the side panel on the seat.
Installing the side panel
1) Insert the side panel into the side panel holder.
2) Re-tighten the thumb screw on the side panel hold
er (see fig.6, item1).
8.2.2 Adjusting the side panels
The height of the armrests, the forearm length and the clothing protector can be subsequently adapted.
7Adjusting the armrest height
1) Loosen the Allen head screw on the side panel
mounting (see fig.7, item1).
2) Slide the armrests up or down to the desired posi
tion.
3) Re-tighten the Allen head screw.
Adjusting the armrest to the forearm length
1) Loosen the 2 Allen head screws on the underside of
the armrest (see fig.7, item2).
2) Push the armrest to the front or back into the
desired position.
3) Tighten the 2 Allen head screws.
19A200
Use

8.3 Legrests
The legrests support the user's feet.
The height of the legrests has been adjusted by qualified personnel to the length of the user's lower leg.
The angle of the footrest has been set by the qualified personnel so that it allows the ankles to rest in a comfortable
position.
8.3.1 Removing/installing the leg supports
CAUTION
Incorrect handling when getting in
Crushing, pinching, impacts due to incorrect handling
►Do not reach into the danger area with your fingers when folding the legrest or footplates up or down.
►Never step on the footplates when getting in and out.
►Note projecting edges.
INFORMATION
For detaching/attaching the mechanically elevating leg supports: see Page38.
8Removing the leg supports
1) Unhook the calf band (not illustrated).
2) Flip the foot support up.
3) Release the leg support locking mechanism (see
fig.8, item1).
4) Swing out the leg support.
5) Pull the leg support up and remove it.
Installing the leg support
1) Hook the leg support into the holder from the side.
2) Swing the leg support forward until the leg support
lock engages (see fig.8, item1).
3) Fold down the foot support.
4) Hook the calf band into the holder.
8.3.2 Adjusting the leg supports
CAUTION
Exposed pinch points
Crushing, pinching due to incorrect handling
►Do not reach into the danger area with your fingers when folding the legrest or footplates up or down.
CAUTION
Improper adjustment of the leg supports and foot plates
Risk of injuries due to uncontrolled driving characteristics, damage to the product
►Make sure that the clearance between the foot plates and ground is sufficient even under load.
►Make sure that the leg supports and foot plates do not come into contact with the caster wheels under load.
The legrests can be subsequently adjusted to the user's lower leg length.
For some legrests, the angle of the foot plate can also be adjusted.
20
Use
A200
