1 Foreword
INFORMATION
Date of last update: 2020-03-19
►Please read this document carefully before using the product and observe the safety notices.
►Obtain instruction from the qualified personnel in the safe use of the product.
►Please contact the qualified personnel if you have questions about the product or in case of problems.
►Report each serious incident in connection with the product, in particular a worsening of the state of health, to
the manufacturer and to the relevant authority in your country.
►Please keep this document for your records.
INFORMATION
►New information regarding product safety and product recalls as well as the declaration of conformity can be
obtained at [email protected] or from the manufacturer’s service department (see inside or outside of back
cover for addresses).
►You can request this document as a PDF file at [email protected] or from the manufacturer’s service depart
ment (see inside or outside of back cover for addresses). The PDF file can also be displayed in a larger size.
You have received a product that is very versatile for everyday use at home and outdoors.
In order to exclude injuries of any type, familiarise yourself with the handling, functions and intended use of the
product before using it. These instructions for use provide you with the related necessary information.
Please note the following in particular:
• All users and/or their attendants must be trained by qualified personnel in the use of the product. In particular,
users and/or attendants must be informed of the residual risks with the aid of the safety notices in the instruc
tions for use (user).
• The product was adapted to the needs of the user. Subsequent changes may be made only by qualified per
sonnel. We recommend checking the product settings onceper year to ensure optimal treatment over the long
term. Especially for users with a changing anatomy (forexample body dimensions, weight), an adjustment at
least onceevery six months is recommended.
• Your product may differ from the models shown. In particular, not all the options described in these instruc
tions for use will be installed on your product.
• The manufacturer reserves the right to make technical changes to the model described in these instructions for
use.
5Ventus
Foreword

2 Product description
2.1 Function
The wheelchair is intended exclusively for transporting one person on the seat.
The wheelchair can be used on solid ground both indoors and outdoors.
2.2 Product overview
1
Ventus
Max. load: 100kg (effective seat width: 280–440mm); 140kg (effective seat width: 460–500mm)
The lightweight Ventus wheelchair is a modular rigid-frame wheelchair for active use in open frame design. The
one-piece light metal frame, combined with a single-panel foot plate or a tube foot support, offers high stability with
a low net weight.
The frame design allows the seat height and angle, centre of gravity and lower leg length to be adjusted. Two
frame angles as well as straight and inwardly offset versions are available.
1 Seat with seat pad 9 Tip-assist (option)
2 Side panel 10 Anti-tipper (option)
3 Back support, back support upholstery 11 Caster wheel
4 Push handle 12 Caster fork
5 Back support tube 13 Leg support (here: angle-adjustable)
6 Slider (drive wheel attachment device) 14 Caster attachment device
7 Drive wheel with handrim 15 Frame
8 Release button for quick-release axle 16 Wheel lock
6
Product description
Ventus

3 Intended use
The safe use of the product can only be ensured in case of intended use in accordance with the information con
tained in these instructions for use. The user is ultimately responsible for accident-free operation.
3.1 Indications for use
The wheelchair is intended for everyday indoor and outdoor use, by the user or an attendant, of people with tem
porary or permanent limitations of the ability to walk, inability to walk or difficulty standing up.
The product is suitable for users with intact skin whose anatomy (suchas body dimensions and weight) permits the
intended use of the product.
The wheelchair may only be used with the options listed on the product order form.
Ottobock assumes no liability for combinations with medical devices and/or accessories from other manufacturers
outside the modular system.
Combinations based on a combination agreement that have been evaluated for effectiveness and safety are an
exception to this.
3.1.1 Special features of the CLT version
In the CLT version, the wheelchair features permanently welded side supports for mounting the drive wheel attach
ment devices, a permanently welded back support and permanently welded caster attachment devices. In this
weight-saving version, the back support height and back support angle, for example, cannot be subsequently
adjusted. Furthermore, installation of certain options is not possible with this version.
For these reasons, this wheelchair version is intended only for experienced users with sporting ambitions who,
thanks to their physiological capabilities, are able to handle the wheelchair proficiently. Before fitting with this ver
sion, the user should be examined intensively for suitability (adequate physiological capabilities).
3.2 Indications
• Minor to pronounced or complete restrictions of mobility
3.3 Contraindications
3.3.1 Absolute Contraindications
• None known
3.3.2 Relative Contraindications
• Failure to meet physical or mental requirements
4 Safety
4.1 Explanation of warning symbols
WARNING Warning regarding possible serious risks of accident or injury.
CAUTION Warning regarding possible risks of accident or injury.
NOTICE Warning regarding possible technical damage.
4.2 Safety instructions for use
Hazards during preparation for use
WARNING
Independent modification of settings
Serious injuries to the user due to improper changes to the product
►Do not modify the settings established by the qualified personnel. Only the settings described in the section
“Use” in these instructions for use may be adjusted independently.
►In case of problems with the settings, please contact the qualified personnel who adjusted your product.
7Ventus
Intended use

WARNING
Settings outside the safety limits
Tipping over, falling due to adjustment errors because of failure to observe the physical/psychological require
ments of the user
►In certain versions and with certain settings, the product tends to tip backwards due to its design. This is an
intentional feature designed to enable users with the corresponding physical prerequisites to manoeuvre
quickly and nimbly.
►Users with the necessary physical and psychological preconditions can be supplied with such versions/set
tings. If the physical/psychological preconditions change, the product may no longer be used with these set
tings. Inform the responsible qualified personnel immediately in this case.
WARNING
Improper handling of packaging materials
Risk of suffocation due to neglect of the duty to supervise
►Packaging materials must be kept out of the reach of children.
Risk of hand injuries
CAUTION
Pinching on components
Pinching, crushing due to lack of caution in danger areas
►Do not reach between the drive wheel and wheel lock or drive wheel and side panel when driving the wheel
chair.
►Do not reach into the spokes of the rotating drive wheel.
►Pay attention not to pinch parts of your body at the wheel lock lever or between the side or frame parts.
CAUTION
Heat development when braking with handrims
Burns due to insufficient hand protection
►Wear wheelchair gloves when travelling at high speeds.
Hazards while driving
WARNING
Improper use of the wheel lock
Falling due to abrupt braking, rolling away of the wheelchair, damage to the wheel lock
►Do not use the wheel lock as a driving brake.
►Apply the wheel lock to prevent the wheelchair from moving on uneven ground or during transfers (e.g.into a
car).
CAUTION
Lack of driving experience
Tipping over, falling due to errors in handling the product
►Practise on level, open ground first.
►Learn with the support of an assistant how the product reacts to changes in centre of gravity, e.g.downward
or upward slopes, inclines or when overcoming obstacles.
CAUTION
Leaning forward in the wheelchair
Tipping over, overturning due to incorrect centre of gravity
►Do not lean too far out of the wheelchair when trying to pick up objects.
►Lean well forward with your upper body when climbing gradients, overcoming obstacles on gradients or on
ramps. If users cannot lean their upper body forward, accompanying persons must support the wheelchair
from behind.
8
Safety
Ventus

CAUTION
Risky operation
Falling, tipping over backwards due to approaching obstacles incorrectly
►Push slowly when crossing obstacles (e.g. steps, curbs) and negotiating uphill or downhill slopes and
inclines.
►Never cross obstacles at an angle. Always approach obstacles head on (at an angle of 90°).
►Raise the front wheels before crossing obstacles.
►Avoid collisions with obstacles and dropping off curbs/ledges.
►Avoid riding cross-country.
CAUTION
Lack of tipping resistance on public transport
Tipping over, user falls, damage to the product due to incorrect positioning
►When using public transit, always observe the currently applicable legal requirements and the safety notices
of the public transit operator.
►Use the permanently installed seats in the vehicle. If you depend on using your wheelchair as a seat, please
use the designated wheelchair spaces and safety securing equipment provided. Always ensure that you are
held in place securely.
CAUTION
Incorrect handling at level crossings
User may fall or tip over due to driving error
►Only cross railway systems and railway tracks in the designated areas.
►Negotiate level crossings so the caster wheels of the product cannot get caught in the gap between the rail
and the road surface.
CAUTION
Driving in the dark
Risk of collisions with other traffic participants due to lack of lighting
►Wear bright clothing or clothing with reflectors.
►Install active lighting on your product.
►Ensure that the reflectors on the product are clearly visible.
Hazards when overcoming obstacles
WARNING
Overcoming steps and obstacles without assistance
Tipping over, falling of the user due to failure to observe transportation instructions
►Always have accompanying persons help you negotiate steps and other obstacles.
►Use available facilities (e.g. access ramps or lifts).
►If such facilities are not available, have 2 assistants carry you over the obstacle.
WARNING
Improper lifting by attendants
Tipping over, falling of the user due to lifting by removable components
►Only lift the product by firmly mounted components (e.g. main frame, push handles).
►Be sure that the clamping levers of the height-adjustable push handles are firmly tightened.
9Ventus
Safety

Hazard in case of broken skin
CAUTION
Skin damage
Skin damage or pressure points due to overloading
►Check your skin for intactness before and during use of the product.
►Pay attention to diligent skin care and pressure redistribution during interruptions in using the product.
►If skin damage or other problems occur during use, stop using the product. Consult the qualified personnel.
Hazards due to fire, heat and cold
CAUTION
Extreme temperatures
Hypothermia or burns due to contact with components, failure of components
►Do not expose the product to any extreme temperatures (e.g.direct sunlight, sauna, extreme cold).
►Do not leave the product in the immediate vicinity of heaters.
Hazards due to improper use of the product
WARNING
Overloading
Severe injuries if the product tips over due to overloading, damage to the product
►Do not exceed the maximum load capacity (see the nameplate and section "Technical data").
►Please note that certain accessories and add-on components will reduce the remaining load capacity.
WARNING
Exceeding the service life
Serious injuries due to failure to observe the manufacturer’s requirements
►Using the product beyond the specified expected service life leads to increased residual risk.
►Observe the specified service life.
WARNING
Incorrect pushing or pulling of the wheelchair
Risk of falling, tipping over due to user error
►Only the push handles may be used for pushing or overcoming obstacles. The tip-assist should be used in
addition.
►If a stabiliser bar is installed, it must not be used for pulling or pushing.
►The attendant should make sure that he/she has a secure stance and firm grip (on both sides).
►In case of damage, have the push handles repaired promptly.
CAUTION
Use of the product during diagnostic examinations and therapeutic treatment
Impairment of the examination results or the effectiveness of treatment due to interactions of the product with
devices that are used
►Make sure that examinations and treatments are carried out exclusively under the prescribed conditions.
CAUTION
Uncontrolled driving behaviour, unexpected sounds or odours
Falling, tipping, collision with persons or nearby objects due to defects
►If any faults, defects or other hazards that can lead to personal injury are detected, the product must be taken
out of service immediately. This includes uncontrolled movements as well as sounds that are unexpected or
previously not noted or odours that deviate significantly from the state of the product at the time of delivery.
►Contact the qualified personnel.
10
Safety
Ventus

NOTICE
Use under incorrect environmental conditions
Damage to product due to corrosion or abrasion
►Do not use the product in salt water.
►Make sure that the wheel bearings are not damaged by sand or other particles.
4.3 Side effects
The following side effects may occur during use of the product:
• Neck, muscle and joint pain
• Circulatory disorders, risk of pressure sores
Contact a doctor or therapist in case of problems.
4.4 Further information
INFORMATION
The serial number required for enquiries and orders can be found on the nameplate. For explanations of the
nameplate, see the section "Nameplate" (Nameplate).
INFORMATION
Even in the event of compliance with all applicable guidelines and standards, alarm systems (e.g. in department
stores) may respond to your product. Should this happen, remove your product from the area where the alarm
was triggered.
4.5 Nameplate and warning labels
The nameplates are found on the frame.
Label Meaning
AManufacturer’s product name
BCE marking
CMaximum load (see section “Technical data”)
DManufacturer information/address
ESerial number1)
FManufacturing date2)
GSymbol for medical device
HWARNING! Read the instructions for use before using the
product. Observe important safety-related information
(e.g.warnings, precautions).
IThe product has not been approved by the manufacturer for use
as a seat in vehicles for transporting persons with reduced
mobility
JManufacturer’s reference number for the product variant
KSerial number (PI)3),1)
LGlobal Trade Item Number (DI)4)
1)YYYY = year of manufacture; WW = week of manufacture; PP = production site; XXXX = sequential production
number
2)YYYY = year of manufacture; MM = month of manufacture; DD = day of manufacture
3)UDI-PI to GS1 standard; UDI = Unique Device Identifier, PI = Product Identifier
4)UDI-DI to GS1 standard; UDI = Unique Device Identifier, DI = Device Identifier
Label Meaning
(Safety loop on the wheelchair)
Caution!
The rear wheels have been pre-positioned according to your
indications. Before using the wheelchair, this pre-adjusted
position must be checked by the wheelchair user for function
11Ventus
Safety

Label Meaning
and stability against tipping with the assistance of qualified
personnel.
5 Delivery
5.1 Scope of delivery
• Wheelchair ready for use
• Instructions for use (user)
• Instructions for use for accessories (depending on equipment)
5.2 Options
The standard model can be fitted to the user's personal requirements thanks to a large range of options. For use of
these options: see Page13 ff.
5.3 Storage
5.3.1 Storage during daily use
The product should always be stored so it is protected against external influences.
5.3.2 Storage during extended disuse
The product must be stored in a dry place. Specific information for extended storage: see Page35.
It is not necessary to disassemble the product.
Maintain sufficient clearance from sources of heat. If the product is parked for an extended period of time or the
tyres overheat (e.g.in the vicinity of radiators or in case of exposure to strong sunlight behind glass), the tyres may
become permanently deformed.
During extended storage, the knee lever wheel lock on wheelchairs with PU tyres (=tubeless tyres) must be
released since tyre deformation may otherwise result.
6 Preparing the product for use
6.1 Assembly
CAUTION
Exposed pinch points
Crushing, pinching due to incorrect handling
►When folding out the backrest, only grip by the specified components.
CAUTION
Failure to verify readiness for use before putting into operation
Tipping, falling due to incorrect adjustment or installation
►Before you start using the wheelchair for the first time, check the chosen wheelchair settings with the support
of qualified personnel.
►After every assembly, check for proper mounting of the drive wheels. The quick-release axles must be
securely locked in the receiver bushings.
►Pay particular attention to the stability against tipping, free running of the drive wheels and correct function of
the wheel locks.
►Check the tyre pressure. The correct tyre pressure is printed on the sidewall. Ensure that the pressure is the
same in both tyres.
INFORMATION
On the topic of disassembly/transport: see Page28.
A few simple steps are sufficient for preparing the wheelchair for use:
1) Fold up the backrest (see fig.2):
→Pull the backrest cable until the locking mechanism releases the backrest.
→Fold the backrest rearwards until the locking bolts lock in on both sides.
2) Fold out the folded-in side panels:
12
Delivery
Ventus

→Fold the side panels outwards by 90° (see fig.3).
→Fold the side panels downwards into the guides of the side panel supports (see fig.4).
3) Attach the drive wheels to the quick-release axle housings:
→Press in the button on the quick-release axle (see fig.5).
→Attach the drive wheel to the quick-release axle housing and release the button on the quick-release axle.
→The quick-release axles must not be able to be removed after the push-button has been released.
→INFORMATION: For the "lock-release assist" option, see the section "Drive wheels".
4) If necessary: Fit the seat cushion. The seat cushion is secured against sliding by being pressed on to the
hook-and-loop fastener (see Page15).
5) If necessary: Fasten the calf strap to the frame tube above the caster attachment device (see Page14).
2 3
4 5
7 Use
7.1 Instructions for use
• Attaching loads (e.g.backpacks) can adversely affect stability. Therefore, suspending additional loads on the
wheelchair is not permitted.
• The recommended overall width for manual wheelchairs in an operational state is 700mm. This specification
should ensure unhindered use of escape routes,for example. Please note that the product dimensions can
exceed the recommended value in versions with very large seat widths (for more information see see Page35
ff.).
• The wheelchairs in this series fully satisfy the minimum technical requirements for wheelchairs transportable by
train. However, please note that it is possible that not every individual wheelchair will fulfil the minimum require
ments due to the variation in designs (please see see Page36 for further details).
13Ventus
Use

7.2 Getting in and transferring
CAUTION
Incorrect handling when getting in
Risk of falling, tipping or rolling away due to incorrect handling
►Activate the wheel lock each time before you get into or out of or transfer to or from the wheelchair.
►Always get into the wheelchair from the side, where possible.
►Never step on the foot plates when getting in and out.
►Do not support yourself on the wheel lock when getting in/out.
Users can choose the method for getting into and out of the wheelchair which is most suitable for them. The
respective procedure should be discussed and practised with a therapist.
As a rule, the frame tubes, seat bottom or side panels can be used as supports for getting into the wheelchair.
If getting in independently is not possible, transferring or getting in always has to be performed with the help of an
assistant. The manufacturer also offers transfer aids for getting in, such as transfer boards.
7.3 Legrests
CAUTION
Improper use of the legrests
Tipping over, falling due to errors in handling the product
►Fold up the footplates before getting in.
The legrests support the user's legs.
The height of the legrest has been adjusted by qualified personnel to the length of the user's lower legs.
The angle of the footrest has been set by the qualified personnel so that it allows the ankles to rest in a comfortable
position.
7.3.1 Adjusting the leg supports
The height or angle of the “angle-adjustable” leg support (see fig.6) and leg support for short lower leg lengths
(not pictured) can be adjusted by the qualified personnel. It is also possible to install heel blocks on the sides to
stop the feet from sliding into the area around the caster wheels.
The “fixed” tube foot support (see fig.7) can be adjusted in height by qualified personnel.
Subsequent adjustments may be made only by qualified personnel.
6 7
7.3.2 Removing and fastening the calf strap
The calf strap offers additional support for the user's legs. It can be removed for cleaning.
Fastening the calf strap
1) Guide the calf strap around the frame tube above the caster attachment device (see fig.8, item1).
2) +Close the hook-and-loop closure (see fig.8, item2).
Removing the calf strap
1) Unfasten the hook-and-loop closure.
2) Remove the calf strap from the frame tube.
14
Use
Ventus

8
7.4 Seat cushion and back upholstery
WARNING
Seat cushions and back support pads may ignite
Burns due to user error
►The seat and back support upholstery as well as seat cushions, padding and covers fulfil the normative
requirements for flame resistance. However, they may still ignite if fire is handled improperly or negligently.
►Keep away from all ignition sources, especially lit cigarettes.
CAUTION
Wear of the seat and back upholstery
Loss of functionality due to prohibited continued use
►Have the seat and back upholstery replaced immediately in case of damage.
The product is equipped with seat and back upholstery. Hook-and-loop fasteners on the seat upholstery are used
to attach the seat cushion. The seat cushion ensures pressure relief during use of the wheelchair. It was chosen by
qualified personnel according to the needs of the user.
7.4.1 Removing and fastening the seat cushion
If the seat upholstery is "adaptable", the seat cushion and seat pad can be removed from the wheelchair for clean
ing.
7.4.2 Removing and fastening the back support pad
The backrest pad (adjustable) can be removed for cleaning.
1) Remove the seat cushion.
2) Fold the seat pad forwards away from the hook-and-loop fastener (see fig.9, item1).
3) Pull the flap of the backrest pad off the hook-and-loop fastener (see fig.9, item2) and let it hang down.
4) Remove the backrest pad.
5) After cleaning:
→Put the backrest pad back on. Place the kink in the backrest pad at the top. The "V" in the pad (see fig.10,
item1) shows exactly where the kink is.
→Pull the backrest pad flap tightly downwards (see fig.11).
→Pull the part of the flap that can be fastened forwards and fasten tightly to the seat upholstery (see fig.9,
item2).
INFORMATION: The part of the flap that can be fastened prevents sliding or falling through the
gaps between the straps and protects against draughts.
6) Fasten the seat pad (see fig.9, item1) and the seat cushion.
15Ventus
Use

9 10
11
7.5 Side panels
CAUTION
Pinching at the side panels
Pinching, crushing due to lack of caution in danger areas
►Pay attention not to pinch parts of your body between the side panel or frame parts.
The side panels protect the user and his/her clothing from getting dirty.
If armrests have been installed on the wheelchair, they offer the user additional support for the forearms.
7.5.1 Adjusting the height of the forearm support
"Height-adjustable" side panel
The "height-adjustable" side panels (see fig.12) can be set to different height positions without the use of tools.
1) Press in the release button on the inner side of the side panel (see fig.13, item1).
2) Slide the armrest to the desired position (see fig.13, item2).
3) Let go of the release button.
→The armrest locks into place automatically.
16
Use
Ventus

12 13
"Standard" side panel and "clothing protector" side panel
The "standard" side panel (not pictured) and the "clothing protector" side panel (see fig.14) cannot be adjusted in
height.
Both side panels can be combined with padded armrests.
"Padded" armrest
This armrest (see fig.15) can have its height adjusted by qualified personnel to match the user's requirements.
Subsequent adjustments may be made only by qualified personnel.
14 15
7.5.2 Folding down the side panels
Folding away for getting in (example: "clothing protector" side panel)
To make getting into the wheelchair easier, the side panels can be folded up.
1) Pull the side panels up out of the guides of the side panel supports (see fig.16).
2) Fold the side panels up by 90° (see fig.17).
3) After getting in, fold the side panels down again into the guides of the side panel supports.
16 17
17Ventus
Use

Folding for transport (example: "standard" side panel)
The side panels can be folded in for transport.
1) Fold the side panels up out of the side panel supports (see fig.18).
2) Fold the side panels inwards by 90° (see fig.19).
3) After assembling the wheelchair, fold the side panels down again into the guides of the side panel supports.
18 19
7.5.3 Removing the "padded" armrest
To make getting in and transporting the wheelchair easier, the armrests can be folded away or removed.
1) Pull the armrests up out of the holders (see fig.20).
2) Fold the armrests away by 90° (see fig.21) or remove them.
3) After getting in, slide the armrests down into the holders again.
20 21
7.5.4 Adjusting an arm support with swivel unit
INFORMATION
After adjusting the swivel unit, please always make sure that the lock pins have safely snapped in place.
The swivel unit allows the support angle and the rotation setting of an arm support to be adjusted individually.
Adjusting the support angle
1) Pull the release button outwards (see fig.22, item1).
2) Lift up the arm support at the front end and adjust it to the desired angle (see fig.22, item2).
3) Let go of the release button. The arm support will be secured in its position.
Adjusting the rotation setting in 15° increments
1) Pull the release button downwards (see fig.23, item1).
2) Move the arm support to the desired rotation setting (see fig.23, item2).
3) Let go of the release button. The arm support will be secured in its position.
Continuously adjusting the rotation setting
1) Pull the release button downwards (see fig.23, item1).
18
Use
Ventus

2) Turn the release button 90° (not pictured). The arm support can be rotated freely in this position.
3) Move the arm support to the desired rotation setting (see fig.23, item2).
4) Let go of the release button. The arm support will be secured in its position.
Adjusting the depth of the arm support
1) Loosen the Allen head screws under the arm support (not pictured).
2) Slide the arm support to the desired depth.
3) Re-tighten the Allen head screws under the arm support.
22 23
7.6 Push handles
The push handles make pushing the wheelchair easier for the attendant.
Some of the push handle designs allow the height to be adjusted to suit the needs of the attendant.
7.6.1 Adjusting the push handles
The "standard" push handle (see fig.24) and the "folding" push handle (not pictured) cannot be adjusted in
height.
The height of the "height-adjustable" (see fig.25) and "height-adjustable/removable" push handles (not pictured)
can be adjusted for easier pushing by an attendant.
1) Release the clamping lever.
2) Adjust the height of the push handle.
3) Close the clamping lever tightly.
INFORMATION: Both push handles must be adjusted to the same height.
24 25
7.7 Drive wheels
WARNING
Improper assembly of removable wheels
Tipping, falling over of the user due to wheels coming off
►After each assembly, verify the proper fit of the removable wheels. The quick-release axles must be firmly
locked in the wheel attachment.
19Ventus
Use

WARNING
Defective tyres
Accidents/falling due to poor traction, reduced braking force or lack of manoeuvrability
►Maintain sufficient tyre pressure. Note the information in the section "Technical data" or on the tyre sidewall.
►Ensure that the pressure is the same in both tyres.
►Ensure that the tyres have sufficient tread depth.
CAUTION
Reaching into exposed drive parts
Crushing, pinching due to incorrect handling
►Do not reach between the drive wheel and wheel lock or drive wheel and side panel when driving the product.
►Do not reach into the spokes of the rotating drive wheel while riding in the product.
CAUTION
Heat development when braking with handrims
Burns due to insufficient hand protection
►Wear wheelchair gloves when travelling at high speeds.
The wheelchair is moved, steered, braked and stopped with the help of the handrims on the drive wheels.
To make transport easier, drive wheels with quick-release axle can be taken off the wheelchair.
7.7.1 Removing and mounting the drive wheels
CAUTION
Incorrect removal/attachment of the wheels
Tipping, falling due to incorrect installation
►The user is not permitted to sit in the wheelchair during wheel replacement.
►For changing wheels, set the wheelchair onto a solid surface.
►To change the wheels, secure the wheelchair against tipping over or rolling away.
►If the drive wheel does not lock securely or has too much sideways play, contact the qualified personnel
promptly.
Rear wheels with quick-release axle
1) Release the wheel lock.
2) Grip the area between the spokes near the hub with your fingers.
3) Use your thumb to press in the push-button on the quick-release axle.
4) Remove or mount the drive wheel.
After mounting: The drive wheels must not be removable after releasing the push-button on the quick-release
axle.
26
Drive wheels with lock-release assist
The quick-release axle with lock-release assist for people with quadriplegia makes it possible to install the drive
wheels even in case of severely limited mobility of the arms and hands.
20
Use
Ventus
