Otto Bock Zenit User manual

Zenit
Instructions for use (user) ..................................................................................... 3

2 Zenit

Foreword1 5..............................................................................................................................................................
Product description2 6............................................................................................................................................
Function2.1 6..............................................................................................................................................
Product overview2.2 6..................................................................................................................................
Intended use3 10......................................................................................................................................................
Indications for use3.1 10...............................................................................................................................
Special features of the CLT version3.1.1 10.......................................................................................................
Indications3.2 10.........................................................................................................................................
Contraindications3.3 10................................................................................................................................
Absolute Contraindications3.3.1 10..................................................................................................................
Relative Contraindications3.3.2 10....................................................................................................................
Safety4 10..................................................................................................................................................................
Explanation of warning symbols4.1 10............................................................................................................
Safety instructions for use4.2 10....................................................................................................................
Side effects4.3 14........................................................................................................................................
Further information4.4 14..............................................................................................................................
Nameplate and warning labels4.5 14..............................................................................................................
Delivery5 15...............................................................................................................................................................
Scope of delivery5.1 15................................................................................................................................
Options5.2 15.............................................................................................................................................
Storage5.3 15..............................................................................................................................................
Storage during daily use5.3.1 15......................................................................................................................
Storage during extended disuse5.3.2 15............................................................................................................
Preparing the product for use6 15.........................................................................................................................
Assembly6.1 15...........................................................................................................................................
Use7 17......................................................................................................................................................................
Further instructions for use7.1 17...................................................................................................................
Getting in and transferring7.2 17...................................................................................................................
Legrests7.3 18............................................................................................................................................
Seat cushion and back upholstery7.4 18.........................................................................................................
Removing and fastening the seat cushion7.4.1 19...............................................................................................
Removing and fastening the back support pad7.4.2 19........................................................................................
Backrest7.5 20............................................................................................................................................
Side panels7.6 20........................................................................................................................................
Adjusting the height of the forearm support7.6.1 20............................................................................................
Push handles7.7 21......................................................................................................................................
Adjusting the push handles7.7.1 21..................................................................................................................
Drive wheels7.8 21.......................................................................................................................................
Removing and mounting the drive wheels7.8.1 22...............................................................................................
Caster wheels and caster forks7.9 23.............................................................................................................
Approach in case of stiffness7.9.1 23................................................................................................................
Wheel locks7.10 23.......................................................................................................................................
Using the wheel locks7.10.1 23..........................................................................................................................
Using the wheel lock lever extension7.10.2 24......................................................................................................
Anti-tipper/tip-assist7.11 25............................................................................................................................
Activating and deactivating the anti-tipper7.11.1 25..............................................................................................
Using the tip-assist7.11.2 26..............................................................................................................................
Lap belt (seat belt)7.12 26..............................................................................................................................
Additional options7.13 27...............................................................................................................................
Disassembly and transport7.14 27...................................................................................................................
Use in vehicles for transporting persons with reduced mobility7.15 29..................................................................
Zenit, Zenit R without CLT option7.15.1 29..........................................................................................................
Required accessories7.15.1.1 29..........................................................................................................................
Installation7.15.1.2 30..........................................................................................................................................
Table of contents
3Zenit
Table of contents

Using the product in a vehicle7.15.1.3 30...............................................................................................................
Restrictions for use7.15.1.4 33.............................................................................................................................
Zenit CLT, Zenit R CLT Option7.15.2 33.............................................................................................................
Care7.16 33..................................................................................................................................................
Cleaning7.16.1 33............................................................................................................................................
Cleaning by hand7.16.1.1 33................................................................................................................................
Cleaning the seat cushion7.16.1.2 34....................................................................................................................
Cleaning belts/straps7.16.1.3 34..........................................................................................................................
Disinfection7.16.2 34........................................................................................................................................
Maintenance and repair8 35...................................................................................................................................
Maintenance8.1 35.......................................................................................................................................
Maintenance intervals8.1.1 35..........................................................................................................................
Maintenance tasks8.1.2 35..............................................................................................................................
Repair8.2 36...............................................................................................................................................
Inner tube, rim tape and tyre replacement8.2.1 36..............................................................................................
Disposal9 37.............................................................................................................................................................
Disposal information9.1 37............................................................................................................................
Legal information10 37..............................................................................................................................................
Liability10.1 37..............................................................................................................................................
Warranty10.2 37............................................................................................................................................
Service life10.3 37.........................................................................................................................................
Technical data11 38...................................................................................................................................................
Appendices12 39........................................................................................................................................................
Threshold values for wheelchairs transportable by train12.1 39...........................................................................
4 Zenit
Table of contents

1 Foreword
INFORMATION
Date of last update: 2020-03-19
►Please read this document carefully before using the product and observe the safety notices.
►Obtain instruction from the qualified personnel in the safe use of the product.
►Please contact the qualified personnel if you have questions about the product or in case of problems.
►Report each serious incident in connection with the product, in particular a worsening of the state of health, to
the manufacturer and to the relevant authority in your country.
►Please keep this document for your records.
INFORMATION
►New information regarding product safety and product recalls as well as the declaration of conformity can be
obtained at [email protected] or from the manufacturer’s service department (see inside or outside of back
cover for addresses).
►You can request this document as a PDF file at [email protected] or from the manufacturer’s service depart
ment (see inside or outside of back cover for addresses). The PDF file can also be displayed in a larger size.
You have received a product that is very versatile for everyday use at home and outdoors.
In order to exclude injuries of any type, familiarise yourself with the handling, functions and intended use of the
product before using it. These instructions for use provide you with the related necessary information.
Please note the following in particular:
• All users and/or their attendants must be trained by qualified personnel in the use of the product. In particular,
users and/or attendants must be informed of the residual risks with the aid of the safety notices in the instruc
tions for use (user).
• The product was adapted to the needs of the user. Subsequent changes may be made only by qualified per
sonnel. We recommend checking the product settings onceper year to ensure optimal treatment over the long
term. Especially for users with a changing anatomy (forexample body dimensions, weight), an adjustment at
least onceevery six months is recommended.
• Your product may differ from the models shown. In particular, not all the options described in these instruc
tions for use will be installed on your product.
• The manufacturer reserves the right to make technical changes to the model described in these instructions for
use.
5Zenit
Foreword

2 Product description
2.1 Function
The wheelchair is intended exclusively for transporting one person on the seat.
The wheelchair can be used on solid ground both indoors and outdoors.
2.2 Product overview
1
Zenit folding wheelchair
The Zenit folding wheelchair is equipped with an open frame made of aluminium, or optionally of carbon. Thanks to
the Easy-Go folding system, it can be unfolded with little effort.
1 Back support/back support upholstery 8 Caster wheel
2 Side panel 9 Drive wheel with handrim
3 Seat/seat pad 10 Adjustable side support with drive wheel
attachment device
4 Scissor wheel lock 11 Folding mechanism
5 Release button for quick-release axle 12 Frame
6 Leg support, automatically folding 13 Back support tube
7 Caster fork 14 Push handle
6
Product description
Zenit

2
Zenit CLT folding wheelchair
The Zenit CLT folding wheelchair is equipped with an open frame made of aluminium. Thanks to the Easy-Go fold
ing system, it can be unfolded with little effort. The caster fork mountings, side supports with drive wheel attach
ment devices, wheel lock mountings and back support connection are permanently welded.
1 Back support/back support upholstery 8 Caster wheel
2 Side panel 9 Drive wheel with handrim
3 Seat/seat pad 10 Welded side support with drive wheel attach
ment device
4 Scissor wheel lock 11 Folding mechanism
5 Release button for quick-release axle 12 Frame
6 Leg support, automatically folding 13 Back support tube
7 Caster fork
7Zenit
Product description

3
Zenit R rigid frame wheelchair
The Zenit R rigid frame wheelchair is equipped with a frame made of aluminium, or optionally of carbon. The rigid
frame wheelchair version with rigid axle and fixed leg support provides a frame geometry that is particularly resist
ant to warping, for sporty driving characteristics with high torsional stiffness.
1 Back support/back support upholstery 8 Caster wheel
2 Side panel 9 Drive wheel with handrim
3 Seat/seat pad 10 Adjustable side support with drive wheel
attachment device
4 Knee lever wheel lock 11 Rigid axle tube
5 Release button for quick-release axle 12 Frame
6 Leg support, fixed installation 13 Push handle
7 Caster fork
8
Product description
Zenit

4
Zenit R CLT rigid frame wheelchair
The Zenit R CLT rigid frame wheelchair is equipped with a frame made of aluminium. The rigid frame wheelchair
with rigid axle and fixed leg support provides a frame geometry that is particularly resistant to warping, for sporty
driving characteristics with high torsional stiffness. The caster fork mountings, side supports with drive wheel
attachment devices, wheel lock mountings and back support connection are permanently welded.
1 Back support/back support upholstery 8 Caster wheel
2 Side panel 9 Drive wheel with handrim
3 Seat/seat pad 10 Welded side support with drive wheel attach
ment device
4 Scissor wheel lock 11 Rigid axle tube
5 Release button for quick-release axle 12 Frame
6 Leg support, fixed installation 13 Back support tube
7 Caster fork 14 Push handle
9Zenit
Product description

3 Intended use
The safe use of the product can only be ensured in case of intended use in accordance with the information con
tained in these instructions for use. The user is ultimately responsible for accident-free operation.
3.1 Indications for use
The wheelchair is intended for everyday indoor and outdoor use, by the user or an attendant, of people with tem
porary or permanent limitations of the ability to walk, inability to walk or difficulty standing up.
The product is suitable for users with intact skin whose anatomy (suchas body dimensions and weight) permits the
intended use of the product.
The wheelchair may only be used with the options listed on the product order form.
Ottobock assumes no liability for combinations with medical devices and/or accessories from other manufacturers
outside the modular system.
Combinations based on a combination agreement that have been evaluated for effectiveness and safety are an
exception to this.
3.1.1 Special features of the CLT version
In the CLT version, the wheelchair features permanently welded side supports for mounting the drive wheel attach
ment devices, a permanently welded back support and permanently welded caster attachment devices. In this
weight-saving version, the back support height and back support angle, for example, cannot be subsequently
adjusted. Furthermore, installation of certain options is not possible with this version.
For these reasons, this wheelchair version is intended only for experienced users with sporting ambitions who,
thanks to their physiological capabilities, are able to handle the wheelchair proficiently. Before fitting with this ver
sion, the user should be examined intensively for suitability (adequate physiological capabilities).
3.2 Indications
• Minor to pronounced or complete restrictions of mobility
3.3 Contraindications
3.3.1 Absolute Contraindications
• None known
3.3.2 Relative Contraindications
• Failure to meet physical or mental requirements
4 Safety
4.1 Explanation of warning symbols
WARNING Warning regarding possible serious risks of accident or injury.
CAUTION Warning regarding possible risks of accident or injury.
NOTICE Warning regarding possible technical damage.
4.2 Safety instructions for use
Hazards during preparation for use
WARNING
Independent modification of settings
Serious injuries to the user due to improper changes to the product
►Do not modify the settings established by the qualified personnel. Only the settings described in the section
“Use” in these instructions for use may be adjusted independently.
►In case of problems with the settings, please contact the qualified personnel who adjusted your product.
10
Intended use
Zenit

WARNING
Settings outside the safety limits
Tipping over, falling due to adjustment errors because of failure to observe the physical/psychological require
ments of the user
►In certain versions and with certain settings, the product tends to tip backwards due to its design. This is an
intentional feature designed to enable users with the corresponding physical prerequisites to manoeuvre
quickly and nimbly.
►Users with the necessary physical and psychological preconditions can be supplied with such versions/set
tings. If the physical/psychological preconditions change, the product may no longer be used with these set
tings. Inform the responsible qualified personnel immediately in this case.
WARNING
Improper handling of packaging materials
Risk of suffocation due to neglect of the duty to supervise
►Packaging materials must be kept out of the reach of children.
Risk of hand injuries
CAUTION
Pinching on components
Pinching, crushing due to lack of caution in danger areas
►Do not reach between the drive wheel and wheel lock or drive wheel and side panel when driving the wheel
chair.
►Do not reach into the spokes of the rotating drive wheel.
►Pay attention not to pinch parts of your body at the wheel lock lever or between the side or frame parts.
CAUTION
Heat development when braking with handrims
Burns due to insufficient hand protection
►Wear wheelchair gloves when travelling at high speeds.
Hazards while driving
WARNING
Improper use of the wheel lock
Falling due to abrupt braking, rolling away of the wheelchair, damage to the wheel lock
►Do not use the wheel lock as a driving brake.
►Apply the wheel lock to prevent the wheelchair from moving on uneven ground or during transfers (e.g.into a
car).
CAUTION
Lack of driving experience
Tipping over, falling due to errors in handling the product
►Practise on level, open ground first.
►Learn with the support of an assistant how the product reacts to changes in centre of gravity, e.g.downward
or upward slopes, inclines or when overcoming obstacles.
CAUTION
Leaning forward in the wheelchair
Tipping over, overturning due to incorrect centre of gravity
►Do not lean too far out of the wheelchair when trying to pick up objects.
►Lean well forward with your upper body when climbing gradients, overcoming obstacles on gradients or on
ramps. If users cannot lean their upper body forward, accompanying persons must support the wheelchair
from behind.
11Zenit
Safety

CAUTION
Risky operation
Falling, tipping over backwards due to approaching obstacles incorrectly
►Push slowly when crossing obstacles (e.g. steps, curbs) and negotiating uphill or downhill slopes and
inclines.
►Never cross obstacles at an angle. Always approach obstacles head on (at an angle of 90°).
►Raise the front wheels before crossing obstacles.
►Avoid collisions with obstacles and dropping off curbs/ledges.
►Avoid riding cross-country.
CAUTION
Lack of tipping resistance on public transport
Tipping over, user falls, damage to the product due to incorrect positioning
►When using public transit, always observe the currently applicable legal requirements and the safety notices
of the public transit operator.
►Use the permanently installed seats in the vehicle. If you depend on using your wheelchair as a seat, please
use the designated wheelchair spaces and safety securing equipment provided. Always ensure that you are
held in place securely.
CAUTION
Incorrect handling at level crossings
User may fall or tip over due to driving error
►Only cross railway systems and railway tracks in the designated areas.
►Negotiate level crossings so the caster wheels of the product cannot get caught in the gap between the rail
and the road surface.
CAUTION
Driving in the dark
Risk of collisions with other traffic participants due to lack of lighting
►Wear bright clothing or clothing with reflectors.
►Install active lighting on your product.
►Ensure that the reflectors on the product are clearly visible.
Hazards when overcoming obstacles
WARNING
Overcoming steps and obstacles without assistance
Tipping over, falling of the user due to failure to observe transportation instructions
►Always have accompanying persons help you negotiate steps and other obstacles.
►Use available facilities (e.g. access ramps or lifts).
►If such facilities are not available, have 2 assistants carry you over the obstacle.
WARNING
Improper lifting by attendants
Tipping over, falling of the user due to lifting by removable components
►Only lift the product by firmly mounted components (e.g. main frame, push handles).
►Be sure that the clamping levers of the height-adjustable push handles are firmly tightened.
12
Safety
Zenit

Hazard in case of broken skin
CAUTION
Skin damage
Skin damage or pressure points due to overloading
►Check your skin for intactness before and during use of the product.
►Pay attention to diligent skin care and pressure redistribution during interruptions in using the product.
►If skin damage or other problems occur during use, stop using the product. Consult the qualified personnel.
Hazards due to fire, heat and cold
CAUTION
Extreme temperatures
Hypothermia or burns due to contact with components, failure of components
►Do not expose the product to any extreme temperatures (e.g.direct sunlight, sauna, extreme cold).
►Do not leave the product in the immediate vicinity of heaters.
Hazards due to improper use of the product
WARNING
Overloading
Severe injuries if the product tips over due to overloading, damage to the product
►Do not exceed the maximum load capacity (see the nameplate and section "Technical data").
►Please note that certain accessories and add-on components will reduce the remaining load capacity.
WARNING
Exceeding the service life
Serious injuries due to failure to observe the manufacturer’s requirements
►Using the product beyond the specified expected service life leads to increased residual risk.
►Observe the specified service life.
WARNING
Incorrect pushing or pulling of the wheelchair
Risk of falling, tipping over due to user error
►Only the push handles may be used for pushing or overcoming obstacles. The tip-assist should be used in
addition.
►If a stabiliser bar is installed, it must not be used for pulling or pushing.
►The attendant should make sure that he/she has a secure stance and firm grip (on both sides).
►In case of damage, have the push handles repaired promptly.
CAUTION
Use of the product during diagnostic examinations and therapeutic treatment
Impairment of the examination results or the effectiveness of treatment due to interactions of the product with
devices that are used
►Make sure that examinations and treatments are carried out exclusively under the prescribed conditions.
CAUTION
Uncontrolled driving behaviour, unexpected sounds or odours
Falling, tipping, collision with persons or nearby objects due to defects
►If any faults, defects or other hazards that can lead to personal injury are detected, the product must be taken
out of service immediately. This includes uncontrolled movements as well as sounds that are unexpected or
previously not noted or odours that deviate significantly from the state of the product at the time of delivery.
►Contact the qualified personnel.
13Zenit
Safety

NOTICE
Use under incorrect environmental conditions
Damage to product due to corrosion or abrasion
►Do not use the product in salt water.
►Make sure that the wheel bearings are not damaged by sand or other particles.
4.3 Side effects
The following side effects may occur during use of the product:
• Neck, muscle and joint pain
• Circulatory disorders, risk of pressure sores
Contact a doctor or therapist in case of problems.
4.4 Further information
INFORMATION
Even in the event of compliance with all applicable guidelines and standards, alarm systems (e.g. in department
stores) may respond to your product. Should this happen, remove your product from the area where the alarm
was triggered.
INFORMATION
The serial number required for enquiries and orders can be found on the nameplate. For explanations of the
nameplate, see the section "Nameplate" (Nameplate).
4.5 Nameplate and warning labels
The nameplates are found on the frame.
Label Meaning
AManufacturer’s product name
BCE marking
CMaximum load (see section “Technical data”)
DManufacturer information/address
ESerial number1)
FManufacturing date2)
GSymbol for medical device
HWARNING! Read the instructions for use before using the
product. Observe important safety-related information
(e.g.warnings, precautions).
IManufacturer’s reference number for the product variant
JSerial number (PI)3),1)
KGlobal Trade Item Number (DI)4)
1)YYYY = year of manufacture; WW = week of manufacture; PP = production site; XXXX = sequential production
number
2)YYYY = year of manufacture; MM = month of manufacture; DD = day of manufacture
3)UDI-PI to GS1 standard; UDI = Unique Device Identifier, PI = Product Identifier
4)UDI-DI to GS1 standard; UDI = Unique Device Identifier, DI = Device Identifier
Label Meaning
Fixation point to attach the product in vehicles for transporting
persons with reduced mobility
14
Safety
Zenit

Label Meaning
Risk of pinching. Do not reach into the danger area.
5 Delivery
5.1 Scope of delivery
• Wheelchair ready for use
• Instructions for use (user)
• Instructions for use for accessories (depending on equipment)
5.2 Options
The standard model can be fitted to the user's personal requirements thanks to a large range of options. For use of
these options: see Page17 ff.
5.3 Storage
5.3.1 Storage during daily use
The product should always be stored so it is protected against external influences.
5.3.2 Storage during extended disuse
The product must be stored in a dry place. Specific information for extended storage: see Page38.
It is not necessary to disassemble the product.
Maintain sufficient clearance from sources of heat. If the product is parked for an extended period of time or the
tyres overheat (e.g.in the vicinity of radiators or in case of exposure to strong sunlight behind glass), the tyres may
become permanently deformed.
During extended storage, the knee lever wheel lock on wheelchairs with PU tyres (=tubeless tyres) must be
released since tyre deformation may otherwise result.
6 Preparing the product for use
6.1 Assembly
CAUTION
Exposed pinch points
Crushing, pinching due to incorrect handling
►When folding the wheelchair out or together, only grip by the specified components.
CAUTION
Failure to verify readiness for use before putting into operation
Tipping, falling due to incorrect adjustment or installation
►Before you start using the wheelchair for the first time, check the chosen wheelchair settings with the support
of qualified personnel.
►After every assembly, check for proper mounting of the drive wheels. The quick-release axles must be
securely locked in the receiver bushings.
►Pay particular attention to the stability against tipping, free running of the drive wheels and correct function of
the wheel locks.
►Check the tyre pressure. The correct tyre pressure is printed on the sidewall. Ensure that the pressure is the
same in both tyres.
INFORMATION
The assembly described below may also be carried out the same way on the CLT model (not illustrated). The
"Folding back support" option is not offered for the Zenit CLT.
15Zenit
Delivery

INFORMATION
On the topic of disassembly/transport: see Page27.
It only takes a few simple steps to prepare the wheelchair (see fig.5) for use:
Zenit; Zenit CLT – folding version
1) Only if necessary: Attach the drive wheels to the quick-release axle mounting (see fig.6). The quick-release
axles must not be removable after releasing the push-button.
2) Unfold the wheelchair by pulling the drive wheel to the side (see fig.7).
Ensure that the folding mechanism is fully unfolded. Hearing the folding mechanism engage audibly indicates
that the folding process is complete.
3) Only with “Folding back support” option: Pull the release strap for the folding mechanism of the back sup
port in the direction of travel of the wheelchair and fold the back support up (see fig.8). In doing so, ensure
that both back support tubes engage in the upright position (see fig.9).
Only with “Leg support with unlocking” option: Firmly press down the foot plate until the locking mechan
ism engages (see Page18).
4) If necessary, fold the push handles up (see fig.10).
5) Fit the seat cushion. The seat cushion is secured against sliding by being pressed onto the hook-and-loop clos
ure.
5 6
7 8
16
Preparing the product for use
Zenit

9 10
Zenit R; Zenit R CLT – rigid frame version
1) Only if necessary: Attach the drive wheels to the quick-release axle mounting (see illustration above). The
quick-release axles must not be removable after releasing the push-button.
2) Only with “Folding back support” option: Pull the release strap for the folding mechanism of the back sup
port in the direction of travel of the wheelchair and fold the back support up (see illustration above). In doing
so, ensure that both back support tubes engage in the upright position (see illustration above).
3) If necessary, fold the push handles up (see illustration above).
4) Fit the seat cushion. The seat cushion is secured against sliding by being pressed onto the hook-and-loop clos
ure.
7 Use
7.1 Further instructions for use
• Attaching loads (e.g.backpacks) can adversely affect stability. Therefore, suspending additional loads on the
wheelchair is not permitted.
• The recommended overall width for manual wheelchairs in an operational state is 700mm. This specification
should ensure unhindered use of escape routes,for example. Please note that the product dimensions can
exceed the recommended value in versions with very large seat widths (for more information see see Page38
ff.).
• The wheelchairs in this series fully satisfy the minimum technical requirements for wheelchairs transportable by
train. However, please note that it is possible that not every individual wheelchair will fulfil the minimum require
ments due to the variation in designs (please see see Page39 for further details).
7.2 Getting in and transferring
CAUTION
Incorrect handling when getting in
Risk of falling, tipping or rolling away due to incorrect handling
►Activate the wheel lock each time before you get into or out of or transfer to or from the wheelchair.
►Always get into the wheelchair from the side, where possible.
►Never step on the foot plates when getting in and out.
►Do not support yourself on the wheel lock when getting in/out.
Users can choose the method for getting into and out of the wheelchair which is most suitable for them. The
respective procedure should be discussed and practised with a therapist.
As a rule, the frame tubes, seat bottom or side panels can be used as supports for getting into the wheelchair.
If getting in independently is not possible, transferring or getting in always has to be performed with the help of an
assistant. The manufacturer also offers transfer aids for getting in, such as transfer boards.
17Zenit
Use

7.3 Legrests
CAUTION
Improper use of the legrests
Tipping over, falling due to errors in handling the product
►Fold up the footplates before getting in.
The purpose of the leg supports is to support the legs of the user (Zenit folding wheelchair: see fig.11; Zenit CLT
folding wheelchair: see fig.12).
One version of the leg support is equipped with an unlocking and locking mechanism (see fig.13). The foot plate
can be folded up after the release button is pressed (see fig.14). To lock it, firmly press down the foot plate until
the locking mechanism engages again.
The height of the leg support has been adjusted by qualified personnel to the length of the user's lower legs.
The angle of the foot support has been set by the qualified personnel so that it allows the ankles to rest in a com
fortable position.
The depth of the foot plate is 140mm.
11 12
13 14
7.4 Seat cushion and back upholstery
WARNING
Seat cushions and back support pads may ignite
Burns due to user error
►The seat and back support upholstery as well as seat cushions, padding and covers fulfil the normative
requirements for flame resistance. However, they may still ignite if fire is handled improperly or negligently.
►Keep away from all ignition sources, especially lit cigarettes.
CAUTION
Wear of the seat and back upholstery
Loss of functionality due to prohibited continued use
►Have the seat and back upholstery replaced immediately in case of damage.
18
Use
Zenit

The product is equipped with seat and back upholstery. Hook-and-loop fasteners on the seat upholstery are used
to attach the seat cushion. The seat cushion ensures pressure relief during use of the wheelchair. It was chosen by
qualified personnel according to the needs of the user.
7.4.1 Removing and fastening the seat cushion
The seat cushion can be removed from the wheelchair for cleaning.
1) Lay the seat cushion onto the seat upholstery and secure it against sliding by pressing it onto the hook-and-
loop fastener (see fig.15).
2) To remove, detach the seat cushion from the hook-and-loop closure on the seat upholstery.
15
7.4.2 Removing and fastening the back support pad
The back padding can be removed from the wheelchair for cleaning.
Removing the back support pad
1) Remove the seat cushion.
2) Pull the back support pad off the seat upholstery towards the rear (see fig.16).
3) Pull the back support pad off the hook-and-loop straps of the back support upholstery (see fig.17).
Fastening the back support pad
1) From the rear, apply the edge of the back support pad to the upper hook-and-loop strap (see fig.18).
2) Fold down the back support pad and secure it to the upholstery straps with the hook-and-loop fasteners (see
fig.19).
3) Pull the part of the flap that can be fastened forward and attach it to the seat upholstery with the hook-and-loop
fastener.
16 17
19Zenit
Use

18 19
7.5 Backrest
The product can be equipped with a fixed or optionally an angle-adjustable backrest.
“Angle-adjustable back support, folding” option
With this option, the back support angle is adjustable and the back support can be laid down onto the seat bottom.
1) Pull the strap of the back support release mechanism until the adjustment mechanism is released (see fig.20).
2) Move the back support to the desired position.
3) Release the strap.
20
7.6 Side panels
CAUTION
Pinching at the side panels
Pinching, crushing due to lack of caution in danger areas
►Pay attention not to pinch parts of your body between the side panel or frame parts.
The side panels protect the user and his/her clothing from getting dirty.
If armrests have been installed on the wheelchair, they offer the user additional support for the forearms.
7.6.1 Adjusting the height of the forearm support
With the “Side panel with arm pad” option, the height of the forearm support can be set to various positions
without the use of tools.
1) Press in the push-button on the inner side of the side panel (see fig.21, item1).
2) Bring the forearm support to the desired position.
3) Release the push-button. The forearm support locks into place automatically.
20
Use
Zenit
