Outsider GFS20317F User manual

GRILL GAZE B O
Questions, problems, or missing parts?
Before returning to the store, call or email Customer Service.
8am - 5pm, PST Monday - Friday
[e-mail] M
Item No. 256109 0
Model No. G F S20317F
2561090 | [e-mail]1-866-238-6800
RETAIN THIS MANUAL FOR FUTURE USE.
ASSEMBLY INSTRUCTIO N S

PARTS LIST
D
A3
C1 C2
E
I
G
L
J
F
B1
B2
A1 A2
2561090 | GFS20317F [email protected]1-866-238-6800
Before beginning assembly of this product, make sure all parts are present. Compare parts with the Parts
List. If any part is missing or damaged, do not attempt to assemble the product. Contact customer
service for replacement parts.
H1 H2
A1 1 Right Rear Leg
A2 1 Right Front Leg
A3 2 Left Rear Legs
B1 2 Long-side Header Beams
B2 2 Short-side Header Beams
C1 4 Long Corner Rafters
C2 4 Short Corner Rafters
D 1 Shelf Assembly
E 1 Rafter Hub
F 3 Accessory Hook Racks
G 1 Hanger Hook
H1 1 Upper Canopy
H2 1 Lower Canopy
I 6 Philips Head Screws
J 18 Threaded Knobs
K 4 Ground Stakes
L 1 Philips Head Screwdriver
PART QTY DESCRIPTION
K

PARTS DIAGRAM
H1
H2
C2
E
G
B2
C1
B1
D
F
A2
A1
A3
A3
2561090 | GFS20317F [email protected]1-866-238-6800

ASSEMBLY
STEP 1
Requires: A1, A2, A3, B1, B2, J
BUILD THE LOWER STRUCTURE
Connect the Long-Side Header Beam (B1) to Right Rear Leg (A1) and Left Rear Leg (A3) using
Threaded Knobs (J). Next connect Short-Side Header Beams (B2) using Threaded Knobs (J). Attach
Right Front Leg (A2) and Left Front Leg (A3) to the other ends of the Short-Side Header Beams
(B2) using Threaded Knobs (J). Finish by connecting the Long-Side Header Beam (B1) to Left Front
Leg (A3) and Right Front Leg (A2) using Threaded Knobs (J).
B2 B1
JJ
A1 & A2 & A3
A3
B2 B1
B1
B2
A1
A2
2561090 | GFS20317F [email protected]1-866-238-6800
A3

ASSEMBLY
STEP 2
Requires: D, F, I
ADD HOOKS TO BOTTOM OF TABLE
Connect the three (3) Accessory Hook Racks (F) to the underside of the Shelf Assembly (D) using
Phillips Head Screws (I).
F
I
D
I
FF
F
D
2561090 | GFS20317F [email protected]1-866-238-6800

ASSEMBLY
STEP 3
Requires: A1, A2, D, J
INSTALL SHELF ASSEMBLY
Install the Shelf Assembly (D) onto Right Front Leg (A2) and Right Rear Leg (A1) by inserting the
holed tabs into the brackets, then fasten using Threaded Knobs (J).
A1&A2
D
D
A1
A2
J
2561090 | GFS20317F [email protected]1-866-238-6800

ASSEMBLY
STEP 4
Requires: C1, E, G
ROOF ASSEMBLY
Install Hanger Hook (G) into the underside of Rafter Hub (E). Then insert the ends of Long Corner
Rafters (C1) into the Rafter Hub (E) as shown. The silver push buttons on parts C1 should make an
audible click and protrude from the holes of the Rafter Hub (E) when securely connected.
C1
EC1
C1
G
C1
E
C1
C1
G
C1
C1
2561090 | GFS20317F [email protected]1-866-238-6800

ASSEMBLY
STEP 5
Requires: C1, C2, H2
ADD LOWER CANOPY AND UPPER RAFTERS
Drape the lower canopy over the assembled roof frame, aligning the short and long sides. Then
connect the Short Corner Rafters (C2) to the Long Corner Rafters (C1) as shown. The silver push
buttons on parts C2 should make an audible click and protrude from the holes on parts C1 when
securely connected.
C1
C2 H2
C1
C1
C2
C1
C1
2561090 | GFS20317F [email protected]1-866-238-6800

ASSEMBLY
STEP 6
Requires: C2, H1
INSTALL UPPER CANOPY
Install the Upper Canopy (H1) to the Short Corner Rafters (C2) as shown.
H1
H1
C2
H1
2561090 | GFS20317F [email protected]1-866-238-6800

ASSEMBLY
STEP 7
Requires: A1, A2, A3, C1
INSTALL ROOF ASSEMBLY
With two people, lift the roof assembly on top of the frame assembly and join them by inserting
the post at each Long Corner Rafter (C1) into the receiving posts on the top of each Leg (A1, A2, &
A3 x 2). The silver push buttons on parts C1 should make an audible click and protrude from the
holes on the receiving posts when securely connected.
C1
C1
C1
C1
A1
A2
A3
A3
A1 & A2 & A3
2561090 | GFS20317F [email protected]1-866-238-6800

ASSEMBLY
STEP 8
Requires: A1, A2, A3, C1, H2, K
FINAL ASSEMBLY
Finish installing the Lower Canopy (H2) by pulling down and out on the D-loops at each corner
and inserting the ends of the Long Corner Rafters into the fabric pockets on the Lower Canopy.
For the easiest assembly it is recommended to start with the Right Front Leg (A2), then move to
Left Rear Leg (A3), then Left Front Leg (A3), and finish with Right Rear Leg (A1). If installing on the
ground, insert Ground Stake (K) through one hole on each Leg (A1, A2, & A3). Be sure to use the
appropriate fasteners (not provided) to secure the Grill Gazebo if installing on a wood or
composite deck, or onto a concrete or paver patio. Your local store can help you find the
appropriate fastener for your application.
H2
H2
A1
A2
A3
A3
K
A1 & A2 & A3
H2
C1
2561090 | GFS20317F [email protected]1-866-238-6800

CLEANING & MAINTENANCE
IMPORTANT
If you have any problems with this product (missing or damaged parts, assembly issues, etc.),
PLEASE DO NOT RETURN TO THE RETAILER/STORE
from where you purchased the product.
To expedite any future warranty claims, please retain the instruction sheet,
warranty card and receipt for future use.
CARE AND MAINTENANCE
Be careful to never allow water to build up in frames as this will cause corrosion and freeze
damage in cold climates. Wash all frames with a solution of mild soap and water. Rinse with
clean water and dry with a soft absorbent cloth towel. Frames can be treated with a liquid wax
for maximum protection against UV rays and/or salty, damp air. Canopy may be cleaned by hand
with a solution of soap and water with a clean water rinse. Never machine wash the canopy as
this will result in shrinkage or damage. Never use a commercial or home dryer to tumble dry
fabric goods.
Do not use bleach or solvents to clean any product! This will void the warranty.
2561090 | GFS20317F [email protected]1-866-238-6800
Before returning to the store, call or email Customer Service.
18662386800
8am - 5pm, PST Monday - Friday
[email protected]
STAPLE RECEIPT HERE

WARRANTY
1-YEAR LIMITED WARRANTY PROGRAM
CONTACT CUSTOMER SERVICE AT 1-866-238-6800
For a period of one (1) year after date of purchase, the Manufacturer will either repair or replace defective
components in accordance with this Limited Warranty. This warranty is between the Manufacturer and the
original purchaser and is valid only when accompanied by the original purchaser’s sales receipt showing
original date of purchase and location of purchase. Replacements under this warranty revert back to the
date of original purchase for future warranty.
The Manufacturer or its authorized dealer can accept or reject warranty claims based on its findings. This
warranty applies in normal residential use only and is not intended for commercial use. The Manufacturer can
make substitutions as required of materials, components, and sub-components of comparable value and
utility. This warranty is limited to product repair or replacement (to be determined solely by the
Manufacturer). Warranty return is limited to only the single affected component.
This limited warranty covers only manufacturing defects and does not cover normal wear and tear, damage
due to acts of nature (such as, but not limited to freezing or high winds), abuse or misuse, including chemical
damage from suntan oil or other chemicals, exposure to extreme heat or cold, abrasion or excessive weight.
This product is intended to be used in standard installations only. This warranty is void
if the product is not used for its intended purpose. The Manufacturer disclaims liability for any aspect of
installation and any inconvenience caused by a defective part of a component.
Certain items are not covered by this warranty. These include, but are not limited to the following:
1. Components subjected to abuse, including abuse intended to simulate failure.
2. Damages caused by retailer, shipper or installation crew (such as scratches, dents, tears, chips, etc.).
3. Any part which merely exhibits normal wear yet functions essentially as new, including chips, scratches or
stretching of materials and stitching.
4. Tears, punctures, scratches or any damage caused by improper installation or use.
5. Damage to frames/welds resulting from improper assembly or exposure to water and/or sub-freezing
temperatures is not covered. General frame rusting is not covered.
6. Fading and/or discoloration of fabrics/cushions/straps/wicker resulting from exposure to the elements,
chemicals, oils, fluids or any other cause are not covered.
7. Umbrella bases are not covered under any circumstances.
8. Items sold “as is” or floor models.
To make a claim, call the toll-free number below. Please have available a copy of the original sales receipt
along with a brief description of the problem. Please also provide your email address and daytime telephone
or cell phone number. All items may be charged actual freight costs plus $15 for handling. Repairs or
replacement will be made at the Manufacturer’s option. Sales and use taxes, plus shipping and handling
charges are the responsibility of the consumer.
THIS IS THE ENTIRE EXCLUSIVE EXPRESS LIMITED LIABILITY. THE MANUFACTURER NEITHER MAKES NOR IS
RESPONSIBLE FOR ANY OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING THOSE OF RETAILING
DEALERS. THIS EXCLUSIVE REMEDY IS LIMITED TO RECEIPT OF A CREDIT IN CONNECTION WITH THE REPAIR
OR REPLACEMENT OF ANY PRODUCT OR COMPONENT DEEMED TO BE DEFECTIVE UNDER THE TERMS AND
CONDITIONS AS STATED IN THIS WARRANTY. NEITHER THE PRODUCT MANUFACTURER NOR ITS AGENTS
SHALL BE LIABLE IN ANY CASE FOR INCIDENTAL, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY OR
NEGLIGENCE EVEN IF IT HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, EXCEPT AS OTHERWISE
MAY BE REQUIRED BY LAW, THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE
WARRANTY DESCRIBED HEREIN, AND ALL OTHER WARRANTIES, INCLUDING IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED.
2561090 | GFS20317F [email protected]1-866-238-6800

SAFETY INSTRUCTIONS
2561090 | GFS20317F [email protected]1-866-238-6800
WARNING
To reduce the risk of serious injury, read the following
safety instructions before assembling and using the gazebo.
CAUTION
Always keep children under close supervision
while they are using or around this product.
Never leave children unattended.
• Two people are required for this assembly.
• Some parts may contain sharp edges. Wear protective gloves if necessary.
• When assembling and using this product, basic safety precautions should always be followed to reduce the risk of
personal injury and damage to equipment. Please read all instructions before assembly and usage.
• This product is intended for domestic, outdoor use only.
• The product should be placed on flat, horizontal ground.
• Ensure enough clearance around the product. Before assembling the product, find level ground not less than
6' (1.8 m) away from any structures or obstructions such as fences, garages, houses, overhanging branches,
laundry lines, or electrical wires.
• The gazebo must be anchored with stakes onto the ground for added safety. It cannot be permanently attached to a
concrete floor or platform. Do not assemble the gazebo on sandy, muddy or loose soil as stakes do not have enough
anchorage in these types of soil.
• In case you set up more than one gazebo, keep a minimum distance of 10' (3 m) between the gazebos.
• Any assembly or maintenance of the product must be carried out by adults only.
• Arrange necessary manpower when assembling or moving the product.
• Keep children and pets away while setting up the gazebo.
• Check all nuts and bolts periodically for tightness. When required, tighten them again.
• Reparing and replacing parts should be done by a qualified technician.
• This gazebo is intended for decorative and sunshade purposes only, and it is not designed to withstand harsh weather,
including high winds, rain, and snow.
• Always remove the canopy in heavy wind conditions; otherwise, might tip over and cause damage to the
product or injuries to passersby.
• Always ensure that the roof canvas is tensioned to avoid water accumulation on the roof.
• Remove accumulated water on the roof immediately, or disassemble the gazebo in order to avoid damages.
• If the product will not be used for a longer period (e.g., winter time), it should be stored in a clean, dry
environment.
• Do not light any fires inside or near the product!
• Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before firemen allow you to do
so.
• Do not hang any weights on the roof frame.
• Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
• Retain the original packaging to store the gazebo.
CAUTION
Do not climb on top of the gazebo. Falling off
the gazebo can result in serious injury, possibly
even death.
DANGER
This unit is heavy! Do not
assemble this item alone.
WARNING
Keep all flame and heat sources away from this gazebo fabric. This gazebo is made with fabric that
meets CPAI-84 specifications for flame resistance. It is not fire proof. The fabric will burn if left in
contact with any flame source. The application of any foreign substance to the gazebo fabric may
render the flame-resistant properties ineffective.

GLORIETA PARA ASADOR
¿Preguntas, problemas o piezas faltantes?
Antes de regresar a la tienda, llama o envía un correo electrónico a Servicio al Cliente.
Llama al 1-866-238-6800 de lunes a viernes, entre 8:00 a.m. - 5:00 p.m. (hora del Pacífico)
[email protected]
Artículo Núm. 256109 0
Modelo Núm. G F S20317F
2561090 | [e-mail]1-866-238-6800
CONSERVA ESTE MANUAL PARA USO FUTURO.
INSTRUCCIONES DE ENSAMBLAJE

LISTA DE PIEZAS
D
A3
C1 C2
E
I
G
L
J
F
B1
B2
A1 A2
2561090| [e-mail]1-866-238-6800
Antes de comenzar el ensamblaje de este producto, asegúrate de que no falta ninguna pieza. Compara las
piezas con la lista de piezas. Si alguna pieza falta o está dañada, no intentes ensamblar el producto.
Comunícate con servicio al cliente para piezas de repuesto.
H1 H2
A1 1 Pata trasera derecha
A2 1 Pata frontal derecha
A3 2 Pata trasera izquierda
B1 2 Vigas de cabecera del lado largo
B2 2 Vigas de cabecera del lado corto
C1 4 Vigas de esquina largas
C2 4 Vigas de esquina cortas
D 1 Ensamblaje de la repisa
E 1 Núcleo para vigas
F 3 Colgaderos con ganchos para accesorios
G 1 Gancho de suspensión
H1 1 Cubierta superior
H2 1 Cubierta inferior
I 6 Tornillos de cabeza Philips
J 18 Perillas roscadas
K 4 Estacas para tierra
L 1 Destornillador de cabeza Phillips
PIEZA CANT. DESCRIPCIÓN
K

DIAGRAMA DE PIEZAS
H1
H2
C2
E
G
B2
C1
B1
D
F
A2
A1
A3
A3
2561090 | GFS20317F [e-mail]1-866-238-6800

ENSAMBLAJE
PASO 1
Requiere: A1, A2, A3, B1, B2, J
CONSTRUYE LA ESTRUCTURA INFERIOR
Conecta la viga de cabecera del lado largo (B1) a la pata trasera derecha (A1) y la pata trasera
izquierda (A3) usando perillas roscadas (J). A continuación, conecta las vigas de cabecera del lado
corto (B2) utilizando las perillas roscadas (J). Conecta la pata delantera derecha (A2) y la pata
delantera izquierda (A3) a los otros extremos de las vigas de cabecera del lado corto (B2) usando
perillas roscadas (J). Termina conectando la viga de cabecera del lado largo (B1) a la pata delantera
izquierda (A3) y la pata delantera derecha (A2) usando perillas roscadas (J).
B2 B1
JJ
A1 & A2 & A3
A3
B2 B1
B1
B2
A1
A2
2561090 | [e-mail]1-866-238-6800
A3

ENSAMBLAJE
PASO 2
Requiere: D, F, I
AGREGA LOS GANCHOS AL INFERIOR DE LA REPISA
Sujeta los tres (3) colgaderos con ganchos para accesorios (F) a la parte inferior de ensamblaje de
la repisa (D) con tornillos de cabeza Phillips (I).
F
I
D
I
FF
F
D
2561090 | [e-mail]1-866-238-6800

ENSAMBLAJE
PASO 3
Requiere: A1, A2, D, J
INSTALA EL ENSAMBLAJE DE LA REPISA
Instala el ensamblaje de la repisa (D) en la pata delantera derecha (A2) y la pata trasera derecha (A1)
insertando las pestañas perforadas en los soportes y luego fíjalas con perillas roscadas (J).
A1&A2
D
D
A1
A2
J
2561090 | [e-mail]1-866-238-6800
