oventrop ClimaCon F Series User manual

ClimaCon F
Operating instructions
EN

Page
ClimaCon F
Contents
1. General information ............................................................................................................5
1.1 Validity of the instructions...................................................................................................................... 5
1.2 Type plate............................................................................................................................................... 5
1.3 Scope of delivery .................................................................................................................................... 5
1.4 Contact................................................................................................................................................... 5
1.5 Declaration of conformity
(ClimaCon F 210 / F 310) ......................................................................................................................... 5
1.6 Symbols used.......................................................................................................................................... 5
2. Safety-related information ..................................................................................................6
2.1 Correct use ............................................................................................................................................. 6
2.2 Warnings ................................................................................................................................................ 6
2.3 Safety notes............................................................................................................................................ 6
2.3.1 Danger to life due to electric current............................................................................................................ 6
2.3.2 Danger due to insufficient personnel qualification ...................................................................................... 6
2.3.3 Availability of the operating instructions ..................................................................................................... 6
3. Technical description ..........................................................................................................7
3.1 Installation scheme (example) ................................................................................................................ 7
3.2 Design .................................................................................................................................................... 7
3.2.1 ClimaCon F 90, F 100.................................................................................................................................... 7
3.2.2 ClimaCon F 210, F 310................................................................................................................................... 8
3.3 Functional description ............................................................................................................................ 8
3.3.1 App connection (F 210, F 310)....................................................................................................................... 8
3.3.2 Functions in detail ........................................................................................................................................ 8
3.4 Operating elements and displays............................................................................................................ 9
3.4.1 ClimaCon F 90, F 100.................................................................................................................................... 9
3.4.2 ClimaCon F 210, F 310................................................................................................................................... 9
3.5 Technical data....................................................................................................................................... 10
3.5.1 F 90, F 100....................................................................................................................................................10
3.5.2 F 210, F 310 ..................................................................................................................................................10
4. Accessories and spare parts .............................................................................................. 12
5. Transport and storage ....................................................................................................... 12
6. Installation........................................................................................................................ 12
6.1 Tools required........................................................................................................................................12
6.2 Loosening of the base plate ...................................................................................................................12
6.3 Mounting of the base plate ....................................................................................................................13
6.4 Electrical connection of the room thermostat........................................................................................13
6.4.1 Terminal assignment ...................................................................................................................................13
6.4.2 Connection of the room thermostat ...........................................................................................................15
6.4.3 Fitting of the control unit.............................................................................................................................15
6.5 App installation (F 210, F 310) ...............................................................................................................15
7. Commissioning ................................................................................................................. 16
7.1 Connection of the power supply ............................................................................................................16
7.2 ClimaCon F 210, F 310 ............................................................................................................................16
7.2.1 ClimaCon F 210, F 310 - Teach-in .............................................................................................................16
3115500983-V02.01.2022

Page
ClimaCon F
Contents
7.2.2 ClimaCon F 210, F 310 - Removal of a room thermostat .............................................................................17
7.2.3 ClimaCon F 210, F 310 - Setting of the heating profile ................................................................................17
7.2.4 ClimaCon F 210, F 310 - Configuration ........................................................................................................19
7.2.5 ClimaCon F 210, F 310 - Extended settings................................................................................................. 20
8. Operation ......................................................................................................................... 21
8.1 ClimaCon F 90, F 100 .............................................................................................................................21
8.2 ClimaCon F 210, F 310 ............................................................................................................................21
8.2.1 Auto mode...................................................................................................................................................21
8.2.2 Eco mode ....................................................................................................................................................21
8.2.3 Manual mode...............................................................................................................................................21
9. Troubleshooting................................................................................................................22
10. Maintenance .....................................................................................................................22
11. Disposal............................................................................................................................ 22
4115500983-V02.01.2022

ClimaCon F
General information
1. General information
The original operating instructions are written in German.
The operating instructions in other languages have been
translated from German.
1.1 Validity of the instructions
These instructions are valid for the Oventrop ClimaConF
room thermostats.
Product Item no.
ClimaCon F  ( V) 
ClimaCon F  ( V) 
ClimaCon F  ( V) 
ClimaCon F  ( V) 
ClimaCon F  ( V) 
ClimaCon F  ( V) 
1.2 Type plate
The type plate is located on the inside of the control unit.
1.3 Scope of delivery
• ClimaCon F room thermostat
• Safety and installation advice
1.4 Contact
OVENTROP GmbH & Co. KG
Paul-Oventrop-Straße 1
59939 Olsberg
GERMANY
www.oventrop.com
Technical service
Phone: [phone]
1.5 Declaration of conformity
(ClimaCon F 210 / F 310)
Oventrop GmbH & Co. KG hereby declares that these
products comply with the directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
www.oventrop.com
1.6 Symbols used
Highlights important information and further
additions.
fAction required
• List


Fixed order. Steps  to X.
ZResult of action
5115500983-V02.01.2022

ClimaCon F
Safety-related information
2. Safety-related information
2.1 Correct use
Operational safety is only guaranteed if the product is
used as intended.
The ClimaCon F room thermostats are electronically
controlled operating devices for controlling surface
heating and cooling systems as well as heating and
cooling ceilings in detached houses or multiple dwellings.
Any use beyond and/or different from this is considered
improper use.
Claims of any kind against the manufacturer and/or his
authorised representatives for damage resulting from
improper use cannot be recognised.
Proper use also includes correct compliance with these
instructions.
2.2 Warnings
Each warning contains the following elements:
Warning symbo
SIGNAL WORD
Type and source of danger!
Possible consequences if the danger occurs or the
warning is ignored.
!
Ways to avoid the danger.
Signal words define the severity of the danger posed by a
situation.
WARNING
Indicates a possible danger with moderate risk. If the
situation is not avoided, death or serious bodily injuries
may result.
CAUTION
Indicates a possible danger with lower risk. If the
situation is not avoided, minor and reversible bodily
injuries will result.
NOTICE
Indicates a situation that can potentially result in damage
to property if not avoided.
2.3 Safety notes
We have developed this product in accordance with
current safety requirements.
Please observe the following notes concerning safe use.
2.3.1 Danger to life due to electric current
!
Make sure that the product can be disconnected
from the power supply at any time.
!
Do not operate the product if there is visible
damage.
!
Work on the power supply may only be carried
out by a qualified electrician.
!
Disconnect the product from the power supply at
all poles and secure it against being switched on
again.
!
Check that no voltage is present.
!
Only install the product in dry indoor areas.
!
For devices with a 24 V power supply, use a SELV
voltage source that is galvanically isolated from
the earth potential.
2.3.2 Danger due to insufficient personnel
qualification
Work on this product may only be carried out by suitably
qualified specialist tradespeople.
Due to their professional training and experience as well
as knowledge of the relevant legal regulations, qualified
specialist tradespeople are able to carry out work on the
described product in a professional manner.
Operator
The operator must be instructed in the operation by
specialist tradespeople.
2.3.3 Availability of the operating instructions
Every person who works with this product must have read
and apply this manual and all applicable instructions.
The instructions must be available at the place of use of
the product.
!
Pass on these instructions and all applicable
instructions to the operator.
6115500983-V02.01.2022

ClimaCon F
Technical description
3.2.1 ClimaCon F 90, F 100
1 2
3
45
Fig. 2: Design F 90, F 100
1Control unit
2Base plate
3Terminal strip
4Opening for the cable feed
5Release clip
3. Technical description
3.1 Installation scheme (example)
Fig. 1: Installation scheme (example)
3.2 Design
7115500983-V02.01.2022

ClimaCon F
Technical description
3.2.2 ClimaCon F 210, F 310
1 2
3
45
Fig. 3: Design F 210, F 310
1Control unit
2Base plate
3Terminal strip
4Opening for the cable feed
5Release clip
3.3 Functional description
The ClimaCon F room thermostats are used to control the
temperature of surface heating and cooling systems as
well as heating and cooling ceilings in detached houses
and multiple dwellings.
The ClimaCon F room thermostats control electrothermal
actuators (e.g. Aktor T 2P) via a cable connection.
Valves are opened or closed via the electrothermal
actuators. If the room temperature is lower than the
setpoint temperature, the valves are opened; if the room
temperature reaches the setpoint temperature, the valves
are closed.
The setpoint temperature is adjusted at the room
thermostat .
All product variants offer the same basic functions.
3.3.1 App connection (F 210, F 310)
The ClimaCon F 210 and F 310 product variants can be
programmed via smartphone app.
Three modes are available for temperature control.
3.3.1.1 Auto mode
In Auto mode, the temperature control follows a time
profile (see par. 7.2.3.2 on page 18).
3.3.1.2 Eco mode
In Eco mode, the temperature is constantly regulated to
the “Eco setback temperature” (see par. 7.2.3.1 on page
18).
ClimaCon F 210, F 310 devices are equipped with a
setback output (master). Whenever the Eco mode is
active, a voltage is present at this output. The setback
output can be connected to the setback input (slave) of a
ClimaCon F 90, F 100 room thermostat. The voltage at the
setback input reduces the temperature at the slave room
thermostat by 4 Kelvin compared to the temperature set
at the scale (position
2 in Fig. 4 on page 9).
3.3.1.3 Manual mode
You always have the option to set the temperature
manually (see par. 8.2.3 on page 21).
3.3.2 Functions in detail
3.3.2.1 ClimaCon F 90 - Only heating / only cooling
• Rotary wheel for adjusting the setpoint temperature
• Frost protection can be activated via rotary wheel
• Slave input for connection to a master room
thermostat
3.3.2.2 ClimaCon F 100 - Heating or Cooling
• Rotary wheel for adjusting the setpoint temperature
• Frost protection can be activated via rotary wheel
• Slave input for connection to master room thermostat
• Switching between heating and cooling via change-
over signal
3.3.2.3 ClimaCon F 210 - Only heating / only cooling
• Dot-Matrix display for visualisation of the setpoint
temperature, the actual temperature, various error
codes, the display “BLu” for the teach-in mode, as well
as the OFF display when the device is switched off
• LED display heating or cooling
• LED display with touch surfaces for adjusting the
setpoint temperature via the Plus and Minus keys and
for switching between Auto and Eco mode
• Control via app (Bluetooth)
• Possible modes: Auto (daily or weekly schedule), Eco/
Setback, Manual
• Frost protection (6 °C/ 43 °F) is activated when the
room thermostat is switched off
• Temperature limitation and offset temperature
adjustable
• Master output for controlling the setback temperature
of a slave room thermostat
8115500983-V02.01.2022

ClimaCon F
Technical description
3.3.2.4 ClimaCon F 310 - Heating or cooling
• Dot-Matrix display for visualisation of the setpoint
temperature, the actual temperature, various error
codes, the display “BLu” for the teach-in mode, as well
as the OFF display when the device is switched off
• LED display heating or cooling
• LED display with touch surfaces for adjusting the
setpoint temperature via the Plus and Minus keys and
for switching between Auto and Eco mode
• Switching between heating and cooling via change-
over signal
• Control via app (Bluetooth)
• Possible modes: Auto (daily or weekly schedule), Eco/
Setback, Manual
• Frost protection (6 °C/ 43 °F) is activated when the
room thermostat is switched off
• Temperature limitation and offset temperature
adjustable
• Master output for controlling the setback temperature
of a slave room thermostat
Only ClimaCon F 310 (24 V)
• 0-10 V output for controlling e.g. Air Handling Units
(AHU)
• An external NTC temperature sensor (10 K) can be
connected for measuring the actual temperature
3.4 Operating elements and displays
3.4.1 ClimaCon F 90, F 100
1 2
Fig. 4: Operating elements F 90, F 100
1Rotary wheel
2Scale
3.4.2 ClimaCon F 210, F 310
1
4
5
6
3
2
78
Fig. 5: Operating elements F 210, F 310
1“ON/OFF” key
2Display cooling
3“-” sign, decrease of the desired temperature
4Temperature display
5Display heating
6“+” sign, increase of the desired temperature
7“Eco mode” key
8“Auto mode” key
9115500983-V02.01.2022

ClimaCon F
Technical description
3.5 Technical data
3.5.1 F 90, F 100
3.5.1.1 ClimaCon F 90 (230 V)
Parameter Value
Temperature adjustment
range
°C to °C, frost
protection
Protection category IP
Switching current  A
Power Max.  W
Inputs Setback input - K (slave)
Outputs Two point
Required actuator Heating
Electrothermal actuator
“normally closed”
or
Cooling
Electrothermal actuator
“normally open”
Fuse SMD (not exchangeable)
Colour White
Operating voltage  V AC / - Hz
Protection class II
Dimensions (WxHxD) mm xx
3.5.1.2 ClimaCon F 100 (230 V)
Parameter Value
Temperature adjustment
range
°C to °C, frost
protection
Protection category IP
Switching current  A
Power Max.  W
Inputs • Setback input - K
(slave)
• Change-over
Outputs Two point / PWM
Required actuator Electrothermal actuator
“normally closed”
Fuse SMD (not exchangeable)
Colour White
Operating voltage  V AC / - Hz
Protection class II
Dimensions (WxHxD) mm xx
3.5.1.3 ClimaCon F 100 (24 V)
Parameter Value
Temperature adjustment
range
°C to °C, frost
protection
Protection category IP
Switching current  A
Power Max.  W
Inputs • Setback input - K
(slave)
• Change-over
Outputs Two point / PWM
Required actuator Electrothermal actuator
“normally closed”
Fuse SMD (not exchangeable)
Colour White
Operating voltage  V AC +/- %
Protection class III
Dimensions (WxHxD) mm xx
3.5.2 F 210, F 310
3.5.2.1 ClimaCon F 210
Parameter Value
Temperature adjustment
range
°C to °C, frost
protection
Protection category IP
Switching current  A
Power Max.  W
Inputs Change-over
Outputs • Setback output (master)
• Two point / PWM
Required actuator Electrothermal actuator
“normally closed”
Fuse SMD (not exchangeable)
Colour White
Operating voltage  V AC / - Hz
Protection class II
Bluetooth BLE .
App For smartphones in
portrait format
(Android:.x; iOS:.x)
10 115500983-V02.01.2022

ClimaCon F
Technical description
App languages DE/EN/FR
Dimensions (WxHxD) mm xx
3.5.2.2 ClimaCon F 310 (230 V)
Parameter Value
Temperature adjustment
range
°C to °C, frost
protection
Protection category IP
Switching current  A
Power Max.  W
Input Change-over
Outputs • Setback output (master)
• Two point / PWM
• Potential-free contact
(max V, mA DC/
AC)
Required actuator Electrothermal actuator
“normally closed”
Fuse SMD (not exchangeable)
Colour White
Operating voltage  V AC / - Hz
Protection class II
Bluetooth BLE .
App For smartphones in
portrait format
(Android:.x; iOS:.x)
App languages DE/EN/FR
Dimensions (WxHxD) mm xx
3.5.2.3 ClimaCon F 310 (24 V)
Parameter Value
Temperature adjustment
range
°C to °C, frost
protection
Protection category IP
Switching current  A
Power Max.  W
Input • External temperature
sensor ( K NTC)
• Change-over
Outputs • Setback output (master)
• Two point / PWM
• Potential-free contact
(max V, mA DC/
AC)
• - V output
Required actuator Electrothermal actuator
“normally closed”
Fuse SMD (not exchangeable)
Colour White
Operating voltage  V AC +/- %
Protection class III
Bluetooth BLE .
App For smartphones in
portrait format
(Android:.x; iOS:.x)
App languages DE/EN/FR
Dimensions (WxHxD) mm xx
11115500983-V02.01.2022

ClimaCon F
Accessories and spare parts
4. Accessories and spare parts
You will find the current accessories and spare part list on
our website.
fCall up the search on the website
www.oventrop.com by clicking on the magnifying
glass symbol and search for .
fSelect your product.
ZHere you can find all information on your product.
5. Transport and storage
Parameter Value
Temperature range °C to +°C
Relative air humidity Max. %, non-
condensing
Particles Store in a dry and dust-
protected place
Mechanical influences Protected from
mechanical shock
Weather influences Do not store outdoors
Protect from sunlight
Chemical
influences
Do not store together with
aggressive media
6. Installation
WARNING
Danger to life due to electric current !
There is a danger to life if live components are
touched.
!
Disconnect the product from the power supply
at all poles.
!
Check that no voltage is present.
!
Secure the product against being switched on
again.
!
Only install the product in dry indoor areas.
6.1 Tools required
• Pen for marking the drill holes
• Percussion drill with masonry drill bit
• Slotted screwdriver or current tester
6.2 Loosening of the base plate
Fig. 6: Loosening of the base plate
 Press the release clip (position 5 in Fig. 2 on page
7 or position 5 in Fig. 3 on page 8) down
slightly and detach the control unit from the base
plate.
 Put the control unit to one side.
12 115500983-V02.01.2022

ClimaCon F
Installation
6.3 Mounting of the base plate
The ClimaCon F room thermostat is designed for
surface-mounted installation.
Operate the room thermostat at a location in the
room where the room air is well distributed.
Mount the room thermostat on an interior wall or
on a pillar, at a height of  cm to  cm. Make
sure that the room thermostat is not thermally
influenced by extraneous heat (e.g. solar radiation
or nearby heating devices).
The supply line is fed into the device through the
opening for the cable feed (see position
 in Fig.
 on page  or position  in Fig.  on page
). The supply line must therefore already
protrude from the wall at the designated location.
The cross-section of the cores must be at least
. mm. .
Alternatively, the base plate can also be mounted
on a standard flush-mounted box.
For mounting and installing the actuators you
use, observe the respective operating
instructions.
Fig. 7: Mounting of the base plate
 Hold the base plate flat against the wall and align it
perpendicularly.
 Mark the drill holes with a pen.
WARNING
Danger to life due to electric current !
Damage to live lines can cause electric shocks or
fires.
!
Be careful not to drill into electrical lines.
 Drill at least two holes (opposite each other) and insert
dowels.
 Screw on the base plate.
Only use device screws for switch boxes
(countersunk screws).
If you use screws with thicker screw heads, you
will not be able to mount the control unit.
6.4 Electrical connection of the room
thermostat
6.4.1 Terminal assignment
Fig. 8: ClimaCon F - Electrical connection
6.4.1.1 ClimaCon F 90 (230 V) (item no.)
Terminal Assignment
IN (L  V) operating voltage
IN (N  V) operating voltage
OUT (L  V) two point
IN (L  V) setback input
L
N
L
L
1
2
3
4
N



13115500983-V02.01.2022

ClimaCon F
Installation
6.4.1.2 ClimaCon F 100 (230 V) (item no.)
Terminal Assignment
IN (L  V) operating voltage
IN (N  V) operating voltage
OUT (L  V) two point /PWM
IN (L  V) setback input
IN (L  V) change-over
L
L
L
1
2
3
4
5
N



CO
L
N
6.4.1.3 ClimaCon F 100 (24 V) (item no.)
Terminal Assignment
IN (L  V AC) operating voltage
IN (L  V AC) operating voltage
OUT (L  V AC) two point / PWM
IN (L  V AC) setback input
IN (L  V AC) change-over
L1
L1
L1
1
2
3
4
5
L2



CO
L1
L2
SELV
6.4.1.4 ClimaCon F 210 (230 V) (item no.)
Terminal Assignment
IN (L  V) operating voltage
IN (N  V) operating voltage
OUT (L  V) two point / PWM
OUT (L  V) setback output
L
L
1
2
3
4
N



L
N
6.4.1.5 ClimaCon F 310 (230 V) (item no.)
Terminal Assignment
IN (L  V) operating voltage
IN (N  V) operating voltage
OUT (L  V) two point / PWM
OUT (L  V) setback output
IN (L  V) change-over
OUT (NO) potential-free contact
(max V, mA DC/AC)
 OUT (COM) potential-free contact
(max V, mA DC/AC)
L
L
L
1
2
3
4
5
9
10
N



CO
NO
COM
L
N
DI
(ON/
OFF)
14 115500983-V02.01.2022

ClimaCon F
Installation
6.4.1.6 ClimaCon F 310 (24 V) (item no.)
Terminal Assignment
IN (L  V AC) operating voltage
IN (L  V AC) operating voltage
OUT (L  V AC) two point / PWM
OUT (L  V AC) setback output
IN (L  V AC) change-over
IN (A) ext. K NTC
IN (B) ext. K NTC
OUT (signal) - V
OUT (NO) potential-free contact
(max V, mA DC/AC)
 OUT (COM) potential-free contact
(max V, mA DC/AC)
L1
L1
L1
1
2
3
4
5
9
10
6
7
8
L2



CO
S1
NO
COM
0
-
10
L1
L2
SELV
NTC
10 K

ϑ
DI
(ON/
OFF)
AI
(0
-
10V)
6.4.2 Connection of the room thermostat
NOTICE
Damage to the ClimaCon due to several outer
conductors (phases) in the installation
!
Use the same outer conductor (phase) for
terminals 1 (operating voltage), 4 (setback input
or setback output) and 5 (change-over).
If this is not possible on site, ensure the
separation of the phases by means of a coupling
relay.
WARNING
Only ClimaCon F 310 (24 V) (item no. 1155531)
Danger to life due to excessive voltages at the
terminals for potential-free contacts
!
Only apply extra-low voltages (SELV) to
terminals 9 and 10.
fConnect the cores to the terminal strip according to the
terminal assignment for your product variant (stripping
length 6 mm).
.. Fitting of the control unit
NOTICE
Damage to the device due to incorrect operating
voltage
Base plates and operating elements of the different
product variants are not compatible with each
other.
!
Only combine components of the same product
variant with each other.
fConnect the control unit to the base plate by first
placing the control unit on the lower edge of the base
plate and then pressing it on with a slight twisting
motion.
ZThe room thermostat is completely mounted when
the release clip is audibly engaged.
Fig. 9: Fitting of the base plate
6.5 App installation (F 210, F 310)
The ClimaCon F app is available for both Android
and iOS.
Note the minimum requirements regarding the
version of the operating system and the
Bluetooth version (see par. . on page ).
 Go to the Appstore for your operating system.
 Search for the Oventrop App “ClimaCon” and install it.
15115500983-V02.01.2022

ClimaCon F
Commissioning
7. Commissioning
7.1 Connection of the power supply
fConnect the power supply.
ZThe room thermostat is now ready for operation.
7.2 ClimaCon F 210, F 310
ZThe display shows the currently measured
temperature. After approx. 5 seconds, the display
switches off.
7.2.1 ClimaCon F 210, F 310 - Teach-in
A ClimaCon F room thermostat corresponds to a
room in the ClimaCon app.
 Switch on the room thermostat (position 1 in Fig. 5 on
page 9).
 Press the “Eco mode” and “Auto mode” keys
simultaneously for approx. 3 seconds (positions
7 and
8 in Fig. 5 on page 9).
Fig. 10: ClimaCon F - Activation of the teach-in mode
ZThe “Eco mode” and “Auto mode” key flash alternately.
The display shows “BLu”.
The teach-in mode is active.
The teach-in mode remains active for approx. 
minute. Without teach-in mode, the device
switches off and retains the previous settings.
 Start the ClimaCon F app on your smartphone.
1
2
Fig. 11: ClimaCon F app - Start screen
1General information
2“+” sign (teach-in of the room thermostat)
 Tap the “+” sign to teach in a (further) room
thermostat.
1
2
Fig. 12: ClimaCon F app - Start screen
1Room
2Symbol
 Name the room in which the room thermostat is
operated.
IBy tapping the arrow (position  in Fig. 
on page ), you have the possibility to
make the appropriate selection from a given
list.
Alternatively, you can enter a desired text
manually.
16 115500983-V02.01.2022

ClimaCon F
Commissioning
 Select a suitable symbol from the list (position  in Fig.
 on page ).
 Confirm the entry with “OK”.
ZThe overview page for this room thermostat appears.
1 2 3
2
4
5
6
7
89
Fig. 13: ClimaCon F app - Room thermostat overview
1Back to the room thermostat selection
2Room
3Call-up of the Settings menu
4Manual temperature selection
5Heating or cooling display
6Measured temperature
7Setpoint temperature
8“Eco mode”
9“Auto mode”
If the “heating” or the “cooling” symbol lights up
blue,“heating” or “cooling” is active. When the
room has reached the setpoint temperature, the
symbol turns grey.
ClimaCon F :Depending on whether heating
or cooling is signalled to the room thermostat at
the change-over connection, the corresponding
symbol is displayed here.
7.2.2 ClimaCon F 210, F 310 - Removal of a
room thermostat
Fig. 14: ClimaCon F app - Removal of a room
thermostat
fTap and hold the room thermostat that you want to
remove.
ZA selection menu opens in which you can remove the
room thermostat.
7.2.3 ClimaCon F 210, F 310 - Setting of the
heating profile
You can regulate the room temperature in three
ways.
• Auto mode
In Auto mode, the temperature control follows a
time profile.
• Eco mode
In Eco mode, the temperature is constantly
regulated to the “Eco setback temperature”.
• Manual mode
In addition, you always have the option to set
the temperature manually.
17115500983-V02.01.2022

ClimaCon F
Commissioning
7.2.3.1 Setting of the “Eco setback temperature”
 Tap the key “Call-up of the Settings menu” on the
overview screen of the room thermostat for which you
want to make the settings (position 3 in Fig. 13 on
page 17).
ZThe “Time profile” submenu opens in the “Settings”
menu for the selected room thermostat.
1
Fig. 15: ClimaCon F app - Weekly profile
1Selection of the weekly profile
 Set the desired “Eco setback temperature” by moving
the blue dot to the desired value with your finger or a
pen.
7.2.3.2 Setting of a time profile
 Select the weekly profile
You can choose from three weekly profiles.
• “Mo - Su”: With this weekly profile,you
configure identical temperature curves for each
day of the week.
• “Mo - Fr, Sa, Su”: With this weekly profile,you
configure uniform values for the working days
and individual different values for Saturday and
Sunday.
• “Mo,Tu, We, Thu, Fr, Sa, Su”: With this weekly
profile, you configure individual values for each
day of the week.
 Tap the “+” sign below the day of the week.
ZA time profile with default values is created for this
entry.
Up to three time periods per day can be
configured.
You can set the desired start and end of the
respective time period as well as the setpoint
temperature by moving the blue dots to the
corresponding values.
Time periods in the daily routine that you do not
configure here are interpreted by the system as
times during which the Eco setback temperature
should apply.
 Set the desired time periods and the desired
temperatures.
18 115500983-V02.01.2022

ClimaCon F
Commissioning
Numerical time entry
Alternatively, you can enter the times numerically.
You can call up the input menu by tapping on the
pen symbol (position
 in Fig.  on page ).
Here you can also delete the respective time
profile (Fig.  on page ).
1
Fig. 16: ClimaCon F app - Time profile
1Manual time entry
Fig. 17: ClimaCon F app - Manual time entry
7.2.4 ClimaCon F 210, F 310 - Configuration
fTap “Configuration” in the “Settings” menu.
7.2.4.1 Temperature limitation
The maximum adjustable temperature range is
between °C and °C.
The adjustable temperature range can be limited
here.
Example:
If the room temperature is to be at least °C
and at most °C, set the values here accordingly.
With this basic setting, the room temperature can
then only be controlled in the range between
°C and °C in the app and on the room
thermostat.
7.2.4.2 Operating mode
The currently set operating mode “Heating” or “Cooling” is
displayed here.
The corresponding setting can be changed in the
“Extended settings” menu (Fig.  on page ).
7.2.4.3 Correction offset
In unfavourable installation conditions, the
temperature measured on the room thermostat
can deviate greatly from the actual room
temperature.
In these cases, you can define a correction offset
to compensate for the deviation.
 Determine the temperature deviation.
 Set the correction offset accordingly.
7.2.4.4 Designation
fHere you can change the name of the currently selected
room thermostat.
7.2.4.5 Symbol
fHere you can change the symbol for the currently
selected room thermostat.
7.2.4.6 Automatic summer time
fSelect whether the app should automatically switch
between standard time and summer time.
7.2.4.7 Removal of a room thermostat
fHere you can remove the currently selected room
thermostat.
ZAfter the room thermostat has been removed, the app
switches to the start screen (Fig. 11 on page 16).
19115500983-V02.01.2022

ClimaCon F
Commissioning
7.2.4.8 Firmware room thermostat
1
Fig. 18: ClimaCon F app - Firmware update
1Call-up of the firmware update
7.2.4.9 Extended settings
1
Fig. 19: ClimaCon F app - Call-up of the extended
settings
1Call-up of the extended settings
Fig. 20: ClimaCon F App - Entering the installer code
fTo call up the extended settings, enter the installer code
2962 and confirm the entry with “OK”.
7.2.5 ClimaCon F 210, F 310 - Extended
settings
NOTICE
Malfunctions due to improper configuration
Improperly configured extended settings can cause
unexpected room temperatures and damage parts
of the system.
!
Extended settings may only be carried out by
specialist tradespeople who are sufficiently
qualified.
7.2.5.1 Unit
Here you can choose between the units °Celsius
and °Fahrenheit.
This setting affects all temperature settings in the
app and at the room thermostat.
7.2.5.2 Operating mode
Here you can switch between the operating
modes.
• ClimaCon F : Heating / Cooling
• ClimaCon F : Heating / Cooling / Heating or
cooling
7.2.5.3 Sensor (F 310 24 V)
The room temperature can be measured via the
internal sensor or optionally via an external
sensor.
Here you select which sensor is to be used.
7.2.5.4 External limitation (F 310 24 V)
If a temperature sensor is connected to measure
the surface temperature, the maximum/minimum
permissible temperatures can be set here.
If these temperatures are exceeded or undercut,
the connected actuator is closed.
This can only be selected if the internal sensor is
used for temperature measurement.
20 115500983-V02.01.2022
