SnapServer®XSD 40
Add-on/Spare DIMM Instructions
This document describes how to add an additional or remove
and replace an existing DIMM (Dual In-line Memory Module)
in a SnapServer XSD 40 from Overland Storage.
WARNING: To reduce the risk of electric shock or damage to
equipment, always remove any power cords while working
with the unit.
WARNUNG: Um das Risiko eines elektrischen Schlags oder
Schäden am Gerät zu vermeiden, ziehen Sie stets den
Netzstecker, bevor Sie an der Einheit arbeiten.
AVERTISSEMENT: Pour réduire le risque de choc électrique
ou endommagement de l'équipement, retirez toujours les
cordons électriques en travaillant avec l'appareil.
CAUTION: While working with the unit, observe standard
Electrostatic Discharge (ESD) precautions to prevent damage
to micro-circuitry or static-sensitive devices.
Register the Add-on DIMM
NOTE: If you are only replacing an existing DIMM, skip ahead to
the next section, “Prepare the Unit.”
When adding a second DIMM to your unit, you must first
register it to activate the warranty. Technical and warranty
support are not available until this is done:
1. Go to the Overland Storage website
http://www.overlandstorage.com/
2. Select
Service & Support > My Products .
3. At the Site Login, enter your e-mail address and
password, and click GO.
4. Click the Manage Products button.
5. From the Product Selector drop-down list, select the
XSD 40 in which you are installing the extra DIMM.
6. Click Add a Component.
7. Enter the DIMM information.
8. Click Save & Exit.
IMPORTANT: Your warranty certificate will be emailed to you.
Follow the instructions included in the email to complete the
registration process.
Enter
Enter
5325301507-XSD 40 s/n: 0247

10400592-001 ©2014 Overland Storage, Inc. Page 2 of 4
Add-on/Spare DIMM Instructions
Prepare the Unit
Power Off and Disconnect
1. Briefly press the Power button on the front.
2. When all front LEDs are off, disconnect the power cord.
3. Disconnect all the cables from the unit.
Remove the Right-side Panel
DIMMs are accessed through the right-side panel, when facing
the unit front.
1. On the back of the unit, remove and retain the thumb
screw securing the side panel.
2. Slide the side panel towards the back of the unit until the
anchors release and the panel is free to remove sideways.
3. Set the panel on a secure surface.
Remove the DIMM
This process applies only to replacing existing DIMMs. To
simply install an additional DIMM, proceed to “Install DIMM.”
1. Press the latches on each end of the DIMM.
2. Unseat the DIMM by pulling it straight out.
3. If desired, repeat Steps 1–2 to replace the second DIMM.
Power Button
Right-side Thumb Screw
DIMM slot

10400592-001 ©2014 Overland Storage, Inc. Page 3 of 4
Add-on/Spare DIMM Instructions
Install DIMM
Install DIMMs
NOTE: If only one DIMM is installed, it must be installed in the
lower DIMM slot.
1. In the lowest available empty DIMM slot, align the DIMM
in the slot, lining up the DIMM notch with the guide in the
slot.
2. Firmly press the DIMM down until the latches lock it in
place.
3. To install a second DIMM, repeat Steps 1–2 using the
remaining DIMM slot.
Reassemble the Unit
Reinstall the Side Panels
NOTE: The panels are interchangeable; if you are having issues,
reverse the orientation of the panel. When correctly installed, the
side panels will slightly overlap the back of the unit.
1. On the new chassis, position the side panel with no more
than one-half inch (1.25 cm) extending out over the rear
of the unit.
2. Align the tabs on the panel with the slots on the side of the
unit.
3. Push the panel sideways to be flush with the side of the
unit, then slide the panel towards the front of the unit.
Ensure that the tabs are seated securely in the slots.
4. Reinstall the thumb screw on the back of the unit to
secure the panel.
IMPORTANT: If this is a new appliance install, continue with
the SnapServer XSD 40 Quick Start Guide instructions.
Reattach Cables and Power Cord
1. Reattach all cables to the same connections as before.
2. Attach the power cord.
3. At the front, press the power button to power it ON.
DIMM slot
AC Power
Cable Ports

10400592-001 ©2014 Overland Storage, Inc. Page 4 of 4
http://support.overlandstorage.com
You can get additional technical support on the Internet at the Overland Storage Support web page, or by contacting Overland Storage using
the information found on the Contact Us page on our web site.
Add-on/Spare DIMM Instructions
Verify Memory
1. In the Web Management Interface, go to Monitor >
System Status
.
2. Verify the
Memory amount is correct.
The usual DIMM memory GB rounding variations apply.
If necessary, click Refresh to display the current settings.
3. Click
Close .
Return Old Parts to Overland
1. Place the old part in the anti-static bag and put it in the
replacement part’s box.
2. Use an RMA to return the part to Overland Storage.
For return shipping details and RMA number, go to:
http://docs.overlandstorage.com/return-instructions
