Panasonic LNJ216C8ARA User manual

SHD00577BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
Publication date: January 2009 1
Light Emitting Diodes
LNJ216C8ARA
Surface Mounting Chip LED
Microlens Type
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Power dissipation PD60 mW
Forward current IF20 mA
Pulse forward current *IFP 100 mA
Reverse voltage VR3 V
Operating ambient temperature Topr –30 to +85 °C
Storage temperature Tstg –40 to +100 °C
Note) *: The condition of IFP is duty 10%, Pulse width 1 msec.
Electro-Optical Characteristics Ta= 25°C
Parameter Symbol Conditions Min Typ Max Unit
Luminous intensity IOIF= 10 mA 4.0 10.5 mcd
Reverse current IRVR= 3 V 100 µA
Forward voltage VFIF= 10 mA 1.72 2.5 V
Peak emission wavelength λPIF= 10 mA 660 nm
Spectral half band width Δλ IF= 10 mA 20 nm
0
5
10
15
20
25
01.6 1.8 2.0 2.2 2.4 −20 20 40 60 80 100
20
040 60 80 100
10
1
3
5
10
0.3
0.1
50
0.5
3
1
5
10
30
100
30
50
100
30
50
100
300
500
1 000
0
20
40
60
80
100
550500 600 650 700
1 3 5 10 30 50 100
IOIFIFVF
IFTa
Directive characteristics
Relative luminous intensity (%) Ambient temperature Ta(°C)
Ambient temperature Ta(°C)
Forward current IF(mA)
Forward voltage VF(V)Forward current IF(mA)
Luminous intensity IO(mcd)
Relative luminous intensity (%)
Relative luminous intensity Ta
Relative luminous intensity λP
Peak emission wavelength λP(nm)
Relative luminous intensity (%)
Forward current IF(mA)
0°
10°
20°
30°
40°
50°
60°
70°
80°
90°
020 2040 4060 6080 80 0
20
40
60
80
100
100
Lighting Color
Red

SHD00577BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
LNJ216C8ARA
2
Package (Unit: mm)
KLTLTN2K1600
Pin name
1: Anode
2: Cathode
