Panasonic MA3S1330G User manual

Switching Diodes
1
Publication date: October 2007 SKF00086AED
This product complies with the RoHS Directive (EU 2002/95/EC).
MA3S1330G
Silicon epitaxial planar type
For switching circuits
■Features
•Two isolated elements contained in one package, allowing high-
density mounting
•Two diodes are connected in series in the package
■Absolute Maximum Ratings Ta=25°C
Parameter Symbol Conditions Min Typ Max Unit
Forward voltage VFIF=100 mA 1.2 V
Reverse voltage VRIR=100 µA80V
Reverse current IRVR=75 V 100 nA
Terminal capacitance Ct*1VR=0 V, f =1 MHz 5.5 pF
Ct*23.0
Reverse recovery time *3trr *1IF=10 mA, VR=6 V 150 ns
trr *2Irr =0.1 IR , RL=100 Ω9
■Electrical Characteristics Ta=25°C ±3°C
1
3
2
Bias Application Unit (N-50BU)
90%
Pulse Generator
(PG-10N)
Rs= 50 Ω
Wave Form Analyzer
(SAS-8130)
Ri= 50 Ω
tp= 2 µs
tr= 0.35 ns
δ = 0.05
IF= 10 mA
VR= 6 V
RL= 100 Ω
10%
Input Pulse Output Pulse
Irr = 0.1 IR
trtp
trr
VR
IF
t
t
A
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.
2. Absolute frequency of input and output is 100 MHz.
3. *1: Between pins 2 and 3
*2: Between pins 1 and 3
*3: trr measurement circuit
Parameter Symbol Rating Unit
Reverse voltage VR80 V
Maximum peak reverse voltage VRM 80 V
Forward current Single IF100 mA
Series 65
Peak forward Single IFM 200 mA
current Series 130
Junction temperature Tj150 °C
Storage temperature Tstg −55 to +150 °C
■Package
•Code
SSMini3-F3
•Pin Name
1: Anode 1
2: Cathode 2
3: Cathode 1
Anode 2
■Marking Symbol: MP
■Internal Connection

2
MA3S1330G
SKF00086AED
This product complies with the RoHS Directive (EU 2002/95/EC).
IFVFIFVFIRVR
VFTaVFTaIRTa
CtVRIF(surge) tW
10 −2
0 0.2 0.4 0.6 0.8 1.0 1.2
10 −1
1
10
102
103
Forward voltage VF(V)
Forward current IF(mA)
Between pins 1 and 3
Ta= 150°C
100°C
25°C
−20°C
0 0.2 0.4 0.6 0.8 1.0 1.2
Forward voltage VF(V)
Forward current I
F
(mA)
10 −2
10 −1
1
10
10
2
10
3
Between pins 2 and 3
T
a = 150°C
100°C
25°C
−20°C
10 −2
0 20 40 60 80 100 120
10 −1
1
10
102
103
Reverse voltage VR(V)
Reverse current IR(nA)
Ta= 150°C
Ta= 150°C
100°C
100°C
25°C
25°C
Between pins 2 and 3
Between pins 1 and 3
0
0.4
0.8
1.2
1.6
−40 0 40 80 120 160 200
Ambient temperature T
a
(°C)
Forward voltage V
F
(V)
I
F = 100 mA
Between pins 1 and 3
10 mA
3 mA
0
0.4
0.8
1.2
1.6
−40 0 40 80 120 160 200
Ambient temperature T
a
(°C)
Forward voltage V
F
(V)
I
F = 100 mA
Between pins 2 and 3
10 mA
3 mA
10 −2
−40 0 40 80 120 160 200
10
−1
1
10
10
2
10
3
Ambient temperature Ta(°C)
Reverse current IR(nA)
V
R = 75 V
35 V
6 V
V
R
= 75 V
35 V
6 V
Between pins 2 and 3
Between pins 1 and 3
0
6.0
5.0
4.0
3.0
2.0
1.0
0 20406080100120
Reverse voltage VR(V)
Terminal capacitance Ct(pF)
f = 1 MHz
Ta= 25°C
Between pins 2 and 3
Between pins 1 and 3
10 −1
1
10
102
103
10110 −1
Pulse width tW(ms)
Forward surge current IF(surge) (A)
tW
Non repetitive
IF(surge)
Ta= 25°C
Between pins 1 and 3
Between pins 2 and 3

MA3S1330G
3
SKF00086AED
This product complies with the RoHS Directive (EU 2002/95/EC).
SSMini3-F3 Unit: mm
1.00 ±0.05
(0.50) (0.50)
1.60
+0.05
−0.03
0.26
+0.05
−0.02
12
3
0.85
+0.05
−0.03
1.60
±0.05
0.70
+0.05
−0.03
0 to 0.10
(5°)
(0.45)
0.13
+0.05
−0.02
0.375
±0.05
(5°)
