Split System Submittal Data
Indoor: CS-MKS9NB4U
Multi System Indoor Units - Ceiling Recessed
Approval:
Date:
Construction:
Unit#:
Drawing#:
Job Name:
Location:
Engineer:
Submitted to:
Submitted by:
Reference:
General Data
Power (V/P/Hz) 208 - 230/1/60
Circuit Ampacity (A) N/A
Fuse Size, Max.(A) 15
Running Amps (A) COOL .11 / .1
Power Input (W) COOL 15 / 16
Indoor Unit Cool/Heat
Fan type Turbo
Dia & Length (in.) - No. Speeds D12-5/8 L5-3/4 -1
No. Speeds 3 & Auto
No. Poles (RPM, High) 8 - 440
No. Motors (W) 1-(23)
CFM (HI) 221
Operation Sound (HI/Med/Lo) 33/32/31
Coil Type Aluminum Plate Fin & Copper
Tube
Fin Type - Pipe Type Slit Plate - Inner Rifled
Rows - F.P.I. 2 - 18.1
Face Area (sq.ft.) 2.94
Tube Size (in) N/A
Drain Connection Size 3/4
Refrigerant R410A
Line Size (in. O.D. Discharge) 1/4” (Flare)
Line Size (in. O.D. Suction) 3/8” (Flare)
Dimensions (HxWxD)
Indoor Unit (Crated) (in.) 11-13/32 x 24-13/16 x 28-1/8
Indoor Unit (Uncrated) (in.) 12-5/16 x 24-19/32 x 24-19/32
Weight (lbs.)
Net 35.3
Shipping 41.9
Shipping Volume (cu.ft.) 4.59
Performance Data @ ARI Standard Conditions (230V)
Cooling
Total Capacity (BTU/H) 9000
Moisture Removal (HI, Pint/H) 3.4
Features
Controls Microprocessor
Remote Control LCD Wireless Type, Built-in Temp
Sensor
Temperature Control IC Thermostat
Timer 24 Hr. Program, 1 Hr. Off
Night Setback Built-In
Air Louver Automatic
Power Failure Automatic Restart Built-In
Self-Diagnosis Built-In
Quiet Operation Built-In
Air Filter Washable, Anti-Mold
Option
Refrigerant Line Set Available
Fresh Air Intake Knock-out
Airduct Extension N/A
Condensate Drain Pump Standard
Hard Wired Remote Controller Available
Non-Removeable Remo-con
Bracket
Available
Operating Range Indoor Air Intake Temp Outdoor Air Intake Temp
Cooling (Max) 95F DB/71F WB 115F DB
Cooling (Min) 67F DB/57F WB 14F DB

Panasonic North America
Air Conditioning Division
1690 Roberts Blvd., NW, Suite 110
Kennesaw, GA 30144
us.panasonic.com/aircon
Indoor Dimensions
3. DIMENSIONAL DATA Indoor Unit CS-KS12NB41 & CZ-18BT1U CS-KS18NB4UW & CZ-18BT1U
6-5/16 6-11/16
1-3/16 (30)
4-19/32 1-25/32
1-25/32
2-3/32
8-15/32
22-5/8 (575)
11-5/32 (283)
3
6
5
Less than 31/32Less than 31/32
3-5/8
22-5/8 (575)
12-7/8
Suspension bolt pitch
Suspension bolt pitch
21-1/32 (534)
21-1/32
(534)
12-7/16
23-5/8 (600)
Ceiling opening dimensions
23-5/8 (600)
Ceiling opening dimensions
7
Center of
panel
24-19/32 (625)
24-19/32 (625)
13-5/32 (334)
14-3/32 (358)
1
2
2
2
2
7-11/16
4-29/32
A View
8
1-3/16
21/32
3-1/8
The length of the suspension
bolts should be selected so that
there is a gap of 1-3/16" or
the ceiling (21/32" or more
below the lower surface of the
main unit), as shown in the
figure at right. If the suspension
bolts is too long, it will contact
the ceiling panel and the unit
cannot be installed.
AA
Air intake
Discharge outlet
Refrigerant tubing
(liquid tube) dia.
1/4" (flared)
Refrigerant tubing (gas tube)
dia. 1/2"
(flared)
Drain tube connection port VP20 (outer dia. 1")
Power supply port
Suspension bolt hole (4 - 1/2" x 1-1/8" hole)
Fresh air intake duct connection port (dia. 3-7/8")
1
2
3
4
5
6
7
8
7-23/32
1-27/32 1-3/32
2-3/32
2-3/4 1-9/32
5-9/16
25/32
Unit : inch (mm)
