Panasonic EBL512 G3 5000 Technical manual

Planning Instructions
MEW01472
Revision -
Fire Alarm System EBL512 G3
United version 2.7.x
Author: Jan Pettersson
Date of issue: 2012-04-05
Date of rev:

This page has deliberately been left blank.

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
1
Table of contents
1Introduction________________________________ 9
2Definitions / Explanations ___________________ 11
2.1 PEWN AB_______________________________________ 11
2.2 Alarm points _____________________________________ 11
2.2.1 Smoke detector _______________________________ 11
2.2.2 Sensor ______________________________________ 11
2.2.3 Analog detector_______________________________ 11
2.2.4 Analog (Sensor) Base (ASB) ____________________ 11
2.2.5 Conventional detector __________________________ 11
2.2.6 (Conventional Detector) Base (CDB) ______________ 11
2.2.7 Addressable__________________________________ 11
2.2.8 Conventional zone line input / External line_________ 12
2.3 Output unit ______________________________________ 12
2.4 Output / Control output_____________________________ 12
2.5 Short circuit isolator (ISO) __________________________ 12
2.6 Display unit (D.U.) ________________________________ 12
2.7 COM loop _______________________________________ 12
2.8 Control Unit / C.U. / C.I.E.__________________________ 12
2.9 Fire Brigade Panel (FBP) ___________________________ 12
2.10 Control panel (CP) ________________________________ 12
2.11 System__________________________________________ 12
2.12 Network / TLON®/ LonWorks®/ Echelon / Node / TLON
Conn. board / Channel / Backbone net / Router / Repeater _______ 13
2.13 LED____________________________________________ 13
2.14 External Indicator (Ext. LED)________________________ 13
2.15 Display / LCD____________________________________ 13
2.16 Door open (Door / Key switch)_______________________ 13
2.17 Site Specific Data (SSD)____________________________ 14
2.18 Software (S/W) / System program ____________________ 14
2.19 Mixed system ____________________________________ 14
3Overview _________________________________ 15
3.1 The EBL512 G3 system ____________________________ 15
3.1.1 Printer ______________________________________ 15
3.1.2 Expansion boards _____________________________ 15
3.1.3 Power supply_________________________________ 15
3.2 S/W versions _____________________________________ 16
3.3 Documents ______________________________________ 16
3.4 Applications _____________________________________ 16
3.5 PC software (S/W) ________________________________ 16
3.5.1 Win512 version 2.7.x __________________________ 16
3.5.2 WinG3 version 1.1.x___________________________ 17
3.5.3 TLON Manager_______________________________ 17

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
2
3.5.4 Web512 II Config Tool 2.7______________________ 17
4Control Unit / TLON Network _______________ 18
4.1 The TLON network________________________________ 18
4.2 Single TLON Network / Redundancy in distributed system_ 18
5Control Units 5000 and 5001 _________________ 20
5.1 Mounting plates___________________________________ 22
5.1.1 Mounting plate for 19" mounting rack, 5020 ________ 22
5.1.2 Mounting plate for inflammable wall, 5021 _________ 22
5.2 COM loops ______________________________________ 23
5.3 Programmable voltage outputs (S0-S3) ________________ 25
5.4 Programmable relay outputs (R0-R1)__________________ 25
5.5 Programmable inputs (I0-I3)_________________________ 25
5.6 Relay outputs for routing equipment (tx) _______________ 26
5.6.1 Fire alarm output______________________________ 26
5.6.2 Fault condition output __________________________ 26
6Expansion boards 458x _____________________ 27
6.1 Expansion board no. (address) setting__________________ 28
6.2 8 zones expansion board 4580 _______________________ 28
6.2.1 Type of detectors = Type of zone line input _________ 29
6.2.2 Input states __________________________________ 30
6.3 8 relays expansion board 4581 _______________________ 31
6.4 I/O Matrix board 4582 _____________________________ 31
6.4.1 Generic _____________________________________ 33
6.4.2 Fan control __________________________________ 33
6.4.3 Zone control _________________________________ 34
6.5 Inputs and outputs expansion board 4583_______________ 34
6.6 External FBP / DU interface board 1587 _______________ 34
7Printer ___________________________________ 35
8TLON connection board 1590 ________________ 36
8.1 Single TLON Network _____________________________ 36
8.2 Network programming _____________________________ 36
9Peripheral devices__________________________ 37
9.1 COM loop units___________________________________ 37
9.1.1 Input units ___________________________________ 39
9.1.2 Addressable I/O units __________________________ 46
9.1.3 Alarm devices (addressable sounders) _____________ 48
9.1.4 Short circuit isolators (addressable) _______________ 49
9.1.5 Units for Hazardous (Ex) areas___________________ 50
9.1.6 Other COM loop units__________________________ 51
9.2 Units connected to the RS485 interface ________________ 53
9.2.1 External Fire Brigade Panels_____________________ 53
9.2.2 Alert Annunciation Units _______________________ 55
9.2.3 External Presentation Units______________________ 56
9.3 Units connected to the RS232 interface J7 ______________ 57

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
3
9.3.1 Web-servers__________________________________ 57
9.4 Other units_______________________________________ 57
9.4.1 Alert Annunciation Controllers___________________ 57
9.4.2 External LED ________________________________ 58
9.4.3 Alarm devices (sounders, etc.) ___________________ 58
9.4.4 Door release magnets __________________________ 58
9.4.5 Boxes_______________________________________ 59
9.4.6 Duct detector chambers_________________________ 59
10 Programmable inputs_______________________ 60
10.1 The 3361 unit's Inputs In0 / Z & In1___________________ 60
10.1.1 Input In0 ____________________________________ 60
10.1.2 Input In1 ____________________________________ 60
11 Input programming ________________________ 61
11.1 Trigger conditions_________________________________ 61
11.2 Logic ___________________________________________ 63
12 Programmable outputs______________________ 64
12.1 Control unit outputs S0 –S3_________________________ 65
12.2 Control unit outputs R0 & R1________________________ 65
12.3 8 relays expansion board 4581 Output 0 –Output 7_______ 65
12.4 The 3361 unit's Outputs Re0 & Re1 ___________________ 66
12.5 The 3364 unit's VO0 –VO2 _________________________ 66
12.6 The 3377 unit's Output (siren)________________________ 66
12.7 The 3379 unit's Output (sounder) _____________________ 66
12.8 The 4380 unit's Output (beacon)______________________ 66
13 Output programming_______________________ 67
13.1 Type of output____________________________________ 67
13.2 Logic ___________________________________________ 68
13.3 Supervised / Not supervised _________________________ 68
13.4 Time Activation Output ____________________________ 68
13.5 Control expression ________________________________ 71
13.5.1 Trigger conditions_____________________________ 71
13.5.2 Logical operators______________________________ 75
13.5.3 Control expression examples ____________________ 75
14 Interlocking function _______________________ 79
14.1 Programming of interlocking function _________________ 79
14.1.1 Interlocking output ____________________________ 79
14.1.2 Interlocking input _____________________________ 79
14.1.3 Interlocking combination _______________________ 79
14.2 Interlocking indications_____________________________ 81
14.3 Information of interlocking combinations (H9) __________ 81
14.3.1 Display interlocking information (H9/C1) __________ 81
14.3.2 Activate interlocking output (H9/C2) ______________ 81
14.3.3 Reset interlocking output (H9/C3) ________________ 82
14.3.4 Disable interlocking output (H9/C4)_______________ 82
14.3.5 Re-enable interlocking output (H9/C5)_____________ 82

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
4
14.4 Interlocking control expressions ______________________ 82
15 Fire Door Closing __________________________ 83
16 Functions / Services / Features _______________ 84
16.1 Sensor value _____________________________________ 84
16.2 Week average sensor value__________________________ 84
16.3 Decision value____________________________________ 85
16.4 Alarm algorithms for smoke detectors / Detection levels /
Offsets85
16.4.1 Alarm algorithm / Alternative alarm algorithm ______ 86
16.4.2 Filtering algorithm ____________________________ 87
16.4.3 Smouldering smoke algorithm ___________________ 89
16.5 Performance factor ________________________________ 90
16.6 Algorithms for analog heat detectors __________________ 91
16.6.1 Class A1 algorithm ____________________________ 92
16.6.2 Class A2 S algorithm __________________________ 92
16.6.3 Class B S algorithm____________________________ 92
16.7 Self verification___________________________________ 92
16.8 Minimum / Maximum sensor values___________________ 93
16.9 2-zone / 2-address dependence (Co-incidence alarm)______ 94
16.9.1 2-zone dependence ____________________________ 94
16.9.2 2-address (-unit) dependence ____________________ 95
16.9.3 Reset of 2-zone / 2-address dependence (co-incidence
alarm 95
16.10 Delayed alarm __________________________________ 96
16.11 Alarm Verification Facility________________________ 96
16.12 Alert Annunciation ______________________________ 97
16.13 Alarm Acknowledgement Facility (AAF)_____________ 99
16.14 Quiet alarm ___________________________________ 101
16.15 Fire alarm type A and Fire alarm type B_____________ 101
16.15.1 Fire alarm type B___________________________ 102
16.15.2 Fire alarm type A __________________________ 102
16.16 Disable alarm points and outputs __________________ 102
16.16.1 Disable zone ______________________________ 103
16.16.2 Disable zone / address_______________________ 103
16.16.3 Disable control output_______________________ 103
16.16.4 Disable / Re-enable output type _______________ 103
16.16.5 Disable / Re-enable alarm devices _____________ 103
16.17 Disable interlocking output_______________________ 103
16.18 Disable outputs for routing equipment ______________ 104
16.19 Disconnect & Re-connect loop / zone line input_______ 104
16.20 External time channels __________________________ 104
16.21 Test mode ____________________________________ 104
16.22 Test alarm devices______________________________ 105
16.23 Test of routing equipment________________________ 105
16.24 Calibration of supervised outputs __________________ 105

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
5
16.25 Service signal _________________________________ 105
16.26 Fault signal (fault condition)______________________ 106
16.27 Alarm texts ___________________________________ 106
16.27.1 Creating the alarm texts via Win512 version 2.7.x_ 107
16.27.2 Downloading alarm texts to the DU:s 1728 / 1735 /
1736 and ext. FBP:s 1826 / 1828________________________ 108
16.28 Real time clock (RTC) __________________________ 108
16.28.1 Daylight saving time ________________________ 109
16.29 Loss of main power source _______________________ 109
16.29.1 Fault: Loss of main power source ______________ 109
16.29.2 LCD backlight_____________________________ 109
16.30 Evacuate _____________________________________ 109
16.31 Win512 Tools menu ____________________________ 110
17 Redundancy in distributed system ___________ 112
17.1 Master and Slaves ________________________________ 112
17.1.1 Master unit _________________________________ 112
17.1.2 Slave unit___________________________________ 113
17.2 Several control units ______________________________ 115
17.2.1 Master unit _________________________________ 115
17.2.2 Several control units (slaves) ___________________ 115
18 Special New Zealand functions ______________ 118
18.1 Alarm devices ___________________________________ 118
18.1.1 Silence alarm devices (inside switch) _____________ 118
18.1.2 New Zealand FB Silence switch (outside switch)____ 118
18.2 Battery faults____________________________________ 120
18.2.1 FAULT: Battery _____________________________ 120
18.2.2 FAULT: Low battery capacity __________________ 120
18.3 Routing equipment isolate (disable) __________________ 120
18.4 Acknowledged alarm _____________________________ 120
19 Cyber sensor functions_____________________ 122
19.1 Pulse up –down counter ___________________________ 123
19.1.1 Pulse up –down counter for smoke ______________ 123
19.1.2 Pulse up –down counter for temperature __________ 123
19.1.3 Pulse up –down counter for smoke & temperature __ 123
19.2 Fire judgement __________________________________ 123
19.3 Alarm threshold levels ____________________________ 124
19.4 Learning function / Learning conditions_______________ 124
19.4.1 Learning conditions___________________________ 124
19.5 Alarm delay time_________________________________ 126
19.6 Analog data output _______________________________ 127
19.7 Sensitivity compensation __________________________ 127
19.8 Self diagnosis of internal devices ____________________ 128
19.9 Address setting check _____________________________ 128
20 Control unit properties (settings) ____________ 129
20.1 Control unit properties ____________________________ 129

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
6
20.1.1 General data ________________________________ 129
20.1.2 Type of control unit___________________________ 129
20.1.3 LED indications by inputs______________________ 130
20.1.4 Miscellaneous _______________________________ 130
20.1.5 Selective alarm presentation ____________________ 131
20.2 Log events______________________________________ 132
20.3 Log setup_______________________________________ 132
20.4 Control unit information ___________________________ 132
21 System properties (settings)_________________ 133
21.1 System data _____________________________________ 133
21.1.1 Logical name________________________________ 133
21.1.2 Alarm delay time_____________________________ 133
21.1.3 Main power loss fault delay time ________________ 133
21.1.4 Alarm reset _________________________________ 133
21.1.5 Door closing by time__________________________ 134
21.1.6 Miscellaneous _______________________________ 134
21.1.7 LCD in quiescent state ________________________ 135
21.2 Time channels ___________________________________ 135
21.3 Time activation output ____________________________ 135
21.4 Door open ______________________________________ 136
21.4.1 Indication door open affected by_________________ 136
21.4.2 Disablement of routing equipment _______________ 136
21.5 National holidays ________________________________ 137
21.6 Alarm algorithms ________________________________ 137
21.6.1 Classic smoke detectors' properties_______________ 137
21.6.2 Heat detectors' (3308, 3309, 3316 and 4300) properties138
21.6.3 Smoke detectors' (3304, 4301, 3316 and 4300) properties139
21.6.4 Multi detectors' (3316 and 4300 + decision algorithm)
properties __________________________________________ 139
21.7 System information_______________________________ 140
21.8 Alert Annunciation and Alarm Acknowledgement Facility 140
21.8.1 Alert Annunciation ___________________________ 140
21.8.2 Alarm Acknowledgement Facility _______________ 140
21.9 Two zone dependence_____________________________ 140
22 Compatibility_____________________________ 142
23 Cable types ______________________________ 143
23.1 TLON Network cables ____________________________ 143
23.2 COM loop cables_________________________________ 143
23.3 Ext. FBP / Display Units cables _____________________ 143
23.4 Conventional zone line cables_______________________ 143
23.5 Alarm device cables ______________________________ 144
23.6 Other cables_____________________________________ 144
24 COM loop cable length_____________________ 145
25 Current consumption ______________________ 148

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
7
26 Power supply_____________________________ 152
26.1 Charger functions ________________________________ 153
26.1.1 Charging ___________________________________ 153
26.1.2 Battery charging functions:_____________________ 153
26.1.3 Security functions ____________________________ 153
26.2 Current consumption calculations____________________ 154
26.3 Rectifier (main power source)_______________________ 155
26.4 Battery (second power source) ______________________ 155
26.5 Fuses __________________________________________ 156
26.6 Form / Table of current consumption _________________ 157
27 S/W versions _____________________________ 158
28 Technical data____________________________ 159
29 Limitations_______________________________ 160
29.1 User definable texts_______________________________ 160
29.2 C.i.e. / System ___________________________________ 160
30 National regulations _______________________ 162
31 Drawings / connection diagrams_____________ 163
32 Revision history___________________________ 164
Drawings according to the valid table of drawings.

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
8

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
9
1 Introduction
EBL512 G3 Planning Instructions is a document
1
intended to be used
by planning engineers as well as service / commissioning engineers.
This document should be read in conjunction with the drawings
according to the valid Table of drawings and the EBL512 G3
Operating Instructions MEW01473.
When planning a fire alarm installation the national regulations have
to be obeyed. A lot of detector types can be used. Detector coverage
area and detector placing in the room / building, etc. are matters for
the planning engineers and are not described in this document.
Due to continual development and improvement, different S/W
versions might be found. This document is valid for S/W United
version 2.7.x. On the date / revision date of the document x = 0.
EBL512 G3 S/W United version 2.7.x. is a bit special since it can be
used only for EBL512 G3 units in a TLON Network with both
EBL512 units
2
and EBL512 G3 units, i.e. a mixed network.
Since the EBL512 G3 control unit (c.i.e.) is produced for many
countries the look, the texts, the functions, etc. might vary.
Products
Consists of one or more parts (HW) according to a Product Parts
List. A product has:
a type number
5000 EBL512 G3 c.i.e. Configured for 128, 256 or 512
addresses and with or without printer depending on article
number.
5001 EBL512 G3 c.i.e. No front panel and no Plexiglas in the
door. Configured for 128, 256 or 512 addresses depending on
the article number.
an article number is often the same as the type no. but a country
code can be added (e.g. SE for Sweden). If the letters PRT also
are added in the article number the product comes with a printer.
If digits are added to the article number they are showing the
number of addresses configured (e.g. 5000PRTSE-128).
1
File name: L:\User documents\512 G3\United 2.7.x\MEW01472 (Rev -
).doc
2
The EBL512 units have to have a special S/W version (2.7.x), which makes
it possible to use EBL512 G3 units (5000 / 5001) together with EBL512 units
(1548 / 1549 / 1550), in a TLON Network, i.e. a mixed system.

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
10
a product name (e.g. EBL512 G3 CU, 128 alarm points, with
printer)
HW
A HW (e.g. a printed circuit board) has:
a type number (e.g. 5010)
an article number, often the same as the type no. but sometimes a
country code is added (e.g. 5010SE)
a product name (e.g. Main Board 128 alarm points)
a p.c.b. number (e.g. 9290-2B) and can also have a configuration
(e.g. CFG: 2) and a revision (e.g. REV: 1)
sometimes a S/W
S/W
A S/W has:
a version number (e.g. V2.7.x)
sometimes additional information, such as Convention (different
functions / facilities), Language, Number of addresses, etc.
PC S/W
A PC S/W is a program used for programming, commissioning, etc.
(e.g. Win512 V2.7.x). It has a version number (e.g. V2.7.x).

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
11
2 Definitions / Explanations
Definitions / explanations / abbreviations / etc. frequently used or not
explained elsewhere in the document.
2.1 PESN AB
Panasonic Eco Solutions Nordic AB
2.2 Alarm points
Units, which can generate a fire alarm (in the control unit), i.e. analog
detectors (sensors), conventional detectors, manual call points, etc.
2.2.1 Smoke detector
Analog and conventional photoelectric (optical) smoke detectors are
available.
2.2.2 Sensor
Sensor = Analog detector
2.2.3 Analog detector
Contains an A/D-converter. The Control Unit pick up the digital
values ("sensor values") for each detector individually. All
evaluations and "decisions" are then made in the c.i.e. Analog
detectors are addressable –an address setting tool is used for detector
types 430x.
An analog detector has to be plugged in an analog sensor base (ASB).
2.2.4 Analog (Sensor) Base (ASB)
An analog detector is plugged in an ASB, which is connected to a
COM loop (see below).
2.2.5 Conventional detector
Detector with only two statuses, i.e. normal and fire alarm. The
detector has a closing contact and a series alarm resistor. Normally
plugged in a conventional detector base CDB (see below) connected
to a conventional zone line input, with an end-of-line device. Some
types (e.g. water proof types) are connected directly on zone line.
2.2.6 (Conventional Detector) Base (CDB)
A conventional detector is plugged in a CDB, connected to a
conventional zone line input.
2.2.7 Addressable
A unit with a built-in address device, i.e. each unit is individually
identified, handled and indicated in the c.i.e.
(The unit can be an I/O unit with a zone line input, to which one or
more conventional "alarm points" can be connected.)

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
12
2.2.8 Conventional zone line input / External line
Input intended for one or more conventional alarm points. End-of-line
device in the last alarm point on the line.
2.3 Output unit
Addressable unit with programmable control outputs. Connected to a
COM loop (see below).
2.4 Output / Control output
Defined or programmable function. Relay output or voltage output
(supervised / monitored or not), in the c.i.e. or an output unit
connected on a COM loop.
2.5 Short circuit isolator (ISO)
Addressable unit for automatic disconnection of a part (segment) of a
COM loop (see below) in case of short circuit on the loop.
(According to EN54-2, one ISO is required per 32 alarm points.)
2.6 Display unit (D.U.)
Addressable unit for fire alarm presentation (incl. user definable alarm
text messages, if programmed).
2.7 COM loop
Loop = a cable, with two wires, to which all the addressable units can
be connected. Starts in the c.i.e. and it returns back to the c.i.e.
2.8 Control Unit / C.U. / C.I.E.
Control Unit = Control and Indicating Equipment = Unit to which the
alarm points are connected (via e.g. a COM loop). Indicates fire
alarm, fault condition, etc. Fire Brigade Panel & Control Panel, i.e.
the front, included or not included. Printer included or not included.
2.9 Fire Brigade Panel (FBP)
Unit intended for fire alarm presentation, etc. for the fire brigade
personnel. Can be a part of the control unit (a part of the front) or a
separate unit (external FBP).
In the ext. FBP, a printer can be included or not included.
2.10 Control panel (CP)
A part of the control unit (a part of the front), intended for the building
occupier, service personnel, etc., to "communicate" with the control
unit / system.
2.11 System
One control unit or several control units connected via a TLON
network (co-operating control units).

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
13
2.12 Network / TLON®/ LonWorks®/ Echelon /
Node / TLON Conn. board / Channel /
Backbone net / Router / Repeater
Brief explanations to the words/expressions to be found in connection
with a "network". See also separate TLON Technical description.
TLON®= TeleLarm Local Operating Network = a LonWorks®- based
network
3
for communication between several units/nodes. The
protocol is called LonTalk and the transmission works with doubly-
terminated bus topology (Echelon FTT-10). To connect a control unit
to the network, a TLON connection board has to be plugged in the
control unit. EBL512 G3 also supports redundant TLON system
communication. In this case two TLON connection boards have to be
plugged in each control unit.
A network can be one channel (FTT-10) or several channels,
connected via routers. (In the TLON Network a sub net = a channel.)
Routers are also used to increase the maximum cable length, node to
node, in a network.
Router or Repeater is the same type of unit (different configuration).
All network programming (configuration) are made with the PC
program "TLON Manager".
2.13 LED
LED (Light Emitting Diode) = Yellow, green or red optical indicator
("lamp").
2.14 External Indicator (Ext. LED)
A unit with an LED. Connected to an ASB, CDB or any detector with
an output for an ext. LED. (In old installations also an ADB.)
Lit when the built-in LED in the detector / base is lit.
2.15 Display / LCD
LCD (Liquid Crystal Display) = Display (in the c.i.e. or Display unit)
for presentation of fire alarms, fault messages, etc. In EBL512 G3 it
is a graphical monochrome LCD (320 x 240 dots) with backlight.
2.16 Door open (Door / Key switch)
In EBL512 G3 there is a door switch, which is activated when the
control unit's door is open. In the ext. FBP 1828 this door switch is
replaced with a key switch.
An open door is indicated in the LCD (i.e. an "open door" icon).
3
LonWorks®= A "summing-up-name" for the market of Echelon
Corporation Inc. technology.

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
14
2.17 Site Specific Data (SSD)
The SSD is unique for each installation. All alarm points,
presentation numbers, user definable alarm text messages,
programmable outputs, etc. are created in the PC program Win512
V2.7.x and also downloaded in EBL512 G3 united version 2.7.x with
Win512 V2.7.x.
2.18 Software (S/W) / System program
The S/W (firmware) makes the control unit (the microprocessor)
work. It is factory downloaded but a new version can, via the PC
program WinG3 version 1.1.x, be downloaded in EBL512 G3 united
version 2.7.x on site.
2.19 Mixed system
EBL512 units (1548 / 1549 / 1550) with software EBL512 version
2.7.x together with EBL512 G3 units (5000 / 5001) with software
United version 2.7.x in a TLON Network, i.e. a mixed system.
EBL512 G3 united version 2.7.x can only be used in a mixed system.

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
15
3 Overview
3.1 The EBL512 G3 system
EBL512 G3 is a microprocessor controlled intelligent fire alarm
system, intended for analog addressable smoke detectors, as well as
conventional detectors and manual call points. Programmable control
outputs and output units are available. In EBL512 G3 United version
2.7.x, up to 512 addresses can be connected to each control unit (c.i.e.)
- according to EN54-2.
EBL512 G3 is available in several types, versions and configurations.
It can be connected to a TLON network, i.e. in a "system" with up to
30 control units. Each control unit has access to all information.
Product type no.
Product name
5000
EBL512 G3 c.i.e. With or without a printer.
With front and display.
5001
EBL512 G3 c.i.e.
Without front, display and printer. No door.
EBL512 G3 is designed according to the European standard EN54,
part 2 and 4. The Swedish front conforms to SS3654.
3.1.1 Printer
The control unit EBL512 G3 type 5000 can be delivered with a printer
("PRN" included in the article number) or without a printer.
4
In Ext. Fire Brigade Panel 1826 it is possible to mount an optional
Printer 1835.
3.1.2 Expansion boards
In the control unit (c.i.e.) it is possible to mount up to six expansion
boards. The following types are available:
Product type no.
Product name
Note
4580
8 zones expansion board
4581
8 relay outputs expansion board
Regarding the expansion boards, see also chapter "Expansion boards
458x, page 27 and EBL512 G3 drawings.
3.1.3 Power supply
The main power source is a built-in switched power supply (rectifier)
5037. 230 V AC, 1.6 A / 24 V DC, 6.5 A.
The second power source is a backup battery (2 x 12 V). In the c.i.e.
4
Printer 5058 is a spare part for the c.i.e. type 5000 with a printer, i.e. it
comes without a mounting frame etc.

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
16
is space for two 28 Ah batteries. Larger batteries (up to 65 Ah) have
to be placed outside the c.i.e.
The batteries and the power supply are connected to the Main board
(5010), which handles the charging of the batteries, etc. See chapter
"Power supply", page 152 for more information.
3.2 S/W versions
Due to continual development and improvement, different S/W
versions can be found. When installing a new control unit in a system
with "older" control units, you might have to update the S/W in the
old control units (or download an older version in the new control
unit). The same S/W version is required in all control units in a
TLON network. In a mixed system must only be used the S/W
EBL512 version 2.7.x and EBL512 G3 United version 2.7.x
respectively.
3.3 Documents
The following documents are available:
Planning Instructions (this doc.)
Operating Instructions MEW01473
Drawings
Normally, information found in one of the documents is not found in
another document, i.e. the documents complement each other.
3.4 Applications
The mixed system is intended for small, medium and large
installations. The intelligent control units offer the system designer
and end user a technically sophisticated range of facilities and
functions. Programming and commissioning of the control units /
system is very easy. (PC software Win512 version 2.7.x and TLON
Manager.)
Start with one control unit and then later when it is required, add more
units. The TLON network makes it possible to install the control units
in one building or in many buildings.
3.5 PC software (S/W)
The following PC software is used together with the EBL512 G3
system.
3.5.1 Win512 version 2.7.x
Win512 version 2.7.x is used for programming and commissioning of
one or more EBL512 control units (version 2.7.x) but in a mixed
system (see chapter "Mixed system", page 14) it is also used for the
EBL512 G3 control units (United version 2.7.x), i.e. to:
create / download / backup (upload) the site specific data (SSD)
program convention / configurations / C.U. & system data / etc.

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
17
create and download the user definable text messages (alarm
texts) shown in the display in the C.U. / ext. FBP and other
Display units (AAU / EPU).
download S/W & EBL512 settings in an EBL512 C.U.
NOTE! For the EBL512 G3 control units in a mixed system,
Win512 version 2.7.x has to be used to download S/W.
Old SSD files can be opened in a newer (higher) version of Win512,
saved, edited and thereafter downloaded to an EBL512 G3 / EBL512
control unit with the corresponding version.
3.5.2 WinG3 version 1.1.x
In a mixed system, WinG3 version 1.1.x is used to download new
software and change max. number of addresses in an EBL512 G3
control unit.
3.5.3 TLON Manager
TLON Manager is used for the TLON Network programming, i.e
data / addresses / etc.
3.5.4 Web512 II Config Tool 2.7
A PC tool, Web512 II Config tool version 2.7.x is used for
configuration of the Web-server II (1598).

Panasonic Eco Solutions Nordic AB
MEW01472 Rev: - Planning Instructions Fire alarm system EBL512 G3, United version 2.7.x
18
4 Control Unit / TLON Network
4.1 The TLON network
In a mixed system, up to 30 control units (EBL512 G3 United
version 2.7.x and EBL512 version 2.7.x) can be connected in a TLON
Network. At least one has to be an EBL512 control unit.
In a TLON Network each control unit works independent but has
nevertheless total access to all information in the system.
NOTE!
In a system with two or more control units in a TLON Network, pay
attention to the following:
A zone must not be distributed over the system, i.e. all alarm
points in a zone have to be connected to one c.i.e.
When the "Fire door closing" function is used, the alarm points
and their "belonging" output must be connected to the same c.i.e.
When the interlocking function is used, the input, the output and
the Interlocking Combination (area-point) must be in / connected
to one c.i.e. An input and an output can only be used in one
Interlocking combination.
When the AAF function is used, all devices within the same AAF
zone must be connected to the same c.i.e.
4.2 Single TLON Network / Redundancy in
distributed system
The EBL system can be build up as a single TLON Network system or
a Redundancy in distributed system.
In the single TLON Network, one TLON connection board
(1590/5090) has to be plugged in each control unit.
A fault in a TLON Network generates the following fault:
FAULT: Control unit xx has no contact
with control unit xx
NOTE!
For highest security in a mixed system the function Redundancy in
distributed system can be used in a system with a TLON Network.
One EBL512 control unit has to be the "master" unit and the other
control units in the system are "slave" units that are connected to the
