Panasonic FP Web-Server2 User manual

PROGRAMMABLE CONTROLLERS
FP Web-Server
Hardware / Configurator

Before beginning
Liability and copyright for the hardware
This manual and everything described in it are copyrighted. You may not
copy this manual, in whole or part, without written consent of Panasonic
Electric Works Europe AG (PEWEU).
PEWEU pursues a policy of continuous improvement of the design and
performance of its products. Therefore we reserve the right to change the
manual/product without notice. In no event will PEWEU be liable for direct,
special, incidental, or consequential damage resulting from any defect in
the product or its documentation, even if advised of the possibility of such
damages.
We invite your comments on this manual. Please e-mail us at:
[email protected]asonic.com.
Please direct support matters and technical questions to your local
Panasonic representative.
Limited warranty
If physical defects caused by distribution are found, PEWEU will
replace/repair the product free of charge. Exceptions include:
When physical defects are due to different usage/treatment of the
product other than described in the manual.
When physical defects are due to defective equipment other than the
distributed product.
When physical defects are due to modifications/repairs by someone
other than PEWEU.
When physical defects are due to natural disasters.

2 FP Web-Server V2.810 EN
Warnings used in this manual
One or more of the following warnings may be used in this documentation:
DANGER
Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
Indicates a hazardous situation which, if not
avoided, could result in serious or moderate injury.
CAUTION
Indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE
Indicates a property damage message.

Table of contents
FP Web-Server V2.810 EN 3
Table of contents
Getting started..........................................................................................................................81.
1.1 BEFORE YOU START........................................................................................................................8
1.2 Product numbers and versions............................................................................................................9
1.3 System requirements...........................................................................................................................9
1.4 Advantages and functions of the FP Web-Server.............................................................................10
1.5 FP Web-Server block diagram ..........................................................................................................14
1.6 System sample network ....................................................................................................................14
Hardware description .............................................................................................................152.
2.1 The FP Web-Server unit....................................................................................................................15
2.1.1 Introduction............................................................................................................................15
2.1.2 Hardware version..................................................................................................................16
2.1.3 FP Web-Server unit package................................................................................................17
2.1.4 Parts and functions................................................................................................................18
2.1.5 Technical data.......................................................................................................................19
2.1.6 Installation.............................................................................................................................20
2.1.7 Important notes .....................................................................................................................21
2.1.8 Mechanical installation..........................................................................................................23
2.1.9 Connecting the power supply................................................................................................27
2.2 FP Web expansion unit .....................................................................................................................28
2.2.1 Introduction............................................................................................................................28
2.2.2 FP Web expansion unit package ..........................................................................................28
2.2.3 Parts and functions................................................................................................................29
2.2.4 Technical data.......................................................................................................................29
2.2.5 Targeted peripheral list of the USB host port........................................................................30
2.2.6 Important notes .....................................................................................................................30
2.2.7 Mechanical installation..........................................................................................................31
First steps ...............................................................................................................................323.
3.1 Getting started...................................................................................................................................32
3.2 The Ethernet network........................................................................................................................32
3.3 Connection of the FP Web-Server ....................................................................................................32
3.4 Installation of the Configurator program............................................................................................33
3.5 Determination of the IP configuration................................................................................................33
3.6 Generate a new Configurator project................................................................................................34
3.7 Transfer a Configurator project to the FP Web-Server .....................................................................36
3.8 Test the FP Web-Server with an Internet browser............................................................................37
3.9 Further information............................................................................................................................38

Table of contents
4 FP Web-Server V2.810 EN
Configurator Software............................................................................................................ 39
4.
4.1 General information on the FP Web-Server Configurator.................................................................39
4.2 Control buttons for administering the "Configurator Project".............................................................41
4.3 Control buttons for the remote FP Web-Server unit..........................................................................41
4.3.1 Compare................................................................................................................................42
4.4 System icon menu.............................................................................................................................43
Base configuration................................................................................................................. 445.
5.1 Main settings ("Config").....................................................................................................................44
5.1.1 Ethernet IP address...............................................................................................................45
E-mail setup............................................................................................................................ 476.
6.1 E-mail functions of the FP Web-Server.............................................................................................47
6.1.1 E-mail function used for communication tests.......................................................................48
6.1.2 E-mail server for LAN or Internet ..........................................................................................49
6.1.3 How to find out the address of the e-mail server...................................................................50
6.2 E-mail tab input fields ........................................................................................................................51
6.3 E-mail via SSL...................................................................................................................................51
FTP client and SD memory card control setup .................................................................... 527.
7.1 FTP client function of the FP Web-Server.........................................................................................52
7.2 Operation modes for FTP client and SD card storage ......................................................................53
7.3 FTP client / SD memory card settings...............................................................................................56
7.3.1 Enable FTP client and SD memory card control...................................................................56
OpenVPN client ...................................................................................................................... 588.
8.1 OpenVPN client function of the FP Web-Server ...............................................................................58
8.2 OpenVPN client settings....................................................................................................................59
8.2.1 Enable OpenVPN client.........................................................................................................59
Data logger setup................................................................................................................... 619.
9.1 Data logger function ..........................................................................................................................61
9.2 Log file and CSV file structure (default).............................................................................................63
9.3 Log file and CSV file structure (individual format).............................................................................65
9.4 Data logger tab input fields................................................................................................................66
9.5 Configure log files..............................................................................................................................67
9.5.1 Log file details .......................................................................................................................67
9.6 Logging device setup.........................................................................................................................68
FPWEB Script......................................................................................................................... 6910.
10.1 FPWEB Script settings ......................................................................................................................69
10.1.1 Enable FPWEB Script ...........................................................................................................69

Table of contents
FP Web-Server V2.810 EN 5
10.1.2 Start PPP connection............................................................................................................70
10.1.3 Start FTP transmission..........................................................................................................70
10.1.4 Start e-mail transmission.......................................................................................................71
10.2 FPWEB Script function of the FP Web-Server..................................................................................73
HTTP client..............................................................................................................................7511.
11.1 HTTP client........................................................................................................................................75
11.2 Cloud client........................................................................................................................................76
11.3 HTTP client setup..............................................................................................................................78
11.3.1 Use Dynamic Server IP/Name..............................................................................................78
11.4 HTTP Client SSL Connection............................................................................................................79
HTTP server functions/web pages.........................................................................................8112.
12.1 Details on the FP Web-Server's web page functions........................................................................81
12.1.1 Testing the FP Web-Server functions...................................................................................81
12.1.2 Internet browser settings.......................................................................................................82
12.1.3 Generalities on PLC data fields in HTML pages...................................................................83
12.1.4 HTTP address, CGI function PLC and calling parameter .....................................................84
12.1.5 Configurator settings concerning the HTTP server...............................................................85
12.1.6 Editing HTML pages..............................................................................................................86
12.1.7 Compiling and transferring HTML pages ..............................................................................88
12.1.8 Data fields for displaying PLC data on HTML pages ............................................................88
12.1.8.1 Examples to display PLC data in an HTML page.................................................91
12.1.8.2 Comments............................................................................................................94
12.1.9 Using variable names instead of absolute PLC addresses ..................................................96
12.1.10 Access protection for individual HTML pages ..........................................................99
12.1.11 Inputs for controlling PLC internal flags on HTML pages.......................................101
12.1.12 Defining input fields for PLC data on HTML pages ................................................101
12.1.12.1 Examples on PLC data entries via HTML page.................................................104
12.1.12.2 Notes on strings..................................................................................................106
12.1.12.3 Comments on defining input fields for PLC data on HTML................................107
12.1.12.4 Extended Http POST functions ..........................................................................107
12.1.13 Example on formatting display and input fields ......................................................109
12.1.14 Automatic page reload upon submitting PLC data.................................................112
12.1.15 Notes on XML files with PLC data..........................................................................114
12.1.16 ASCII character codes for strings...........................................................................115
12.2 Configurator HTTP administration and functions ............................................................................116
12.2.1 PLC access rights ...............................................................................................................118
12.2.1.1 Configuration via HTML......................................................................................118
12.2.1.2 MEWTOCOL communication via HTTP server..................................................119
12.3 Https server.....................................................................................................................................120
12.4 Improve performance of HTTP visualizations with PLC data..........................................................120

Table of contents
6 FP Web-Server V2.810 EN
Ethernet and serial (RS232C, RS485, USB) ports .............................................................. 123
13.
13.1 General information on the Ethernet and serial ports .....................................................................123
13.1.1 Server..................................................................................................................................123
13.1.2 Client ...................................................................................................................................125
13.1.3 FP Web-Server and PLC timeouts......................................................................................127
Dial-in setup for PPP server ................................................................................................ 13014.
14.1 Dial-in networking setup for computer/FP Web-Server...................................................................130
14.1.1 TCP/IP network installation of a Windows client.................................................................131
14.1.2 Modem and dial-up networking installation of a Windows client.........................................131
14.1.3 Setup of the modem connected to the FP Web-Server for PPP-communication...............138
14.1.4 FP Web-Server PPP gateway functions .............................................................................139
14.1.5 FPWIN Pro setup to use the remote dialup network...........................................................141
14.1.6 PPP communication via null modem cable.........................................................................142
14.2 Dial-in inputs and parameters for PPP server.................................................................................145
Dial-out setup for PPP client ............................................................................................... 14615.
15.1 The Internet dial-out function...........................................................................................................146
15.1.1 Internet e-mail settings........................................................................................................146
15.1.2 Notes for advanced users ...................................................................................................149
15.1.3 When using a cellular phone (GSM) modem......................................................................152
15.1.4 GPRS Internet connections.................................................................................................152
15.2 Internet dial-out settings..................................................................................................................154
NTP server for PLC clock synchronization ........................................................................ 15516.
16.1 (S)NTP servers................................................................................................................................155
Modbus functions ................................................................................................................ 15717.
17.1 Overview over Modbus-TCP functions of the FP Web-Server........................................................157
17.2 Modbus-TCP server of the FP Web-Server in general....................................................................158
17.3 Modbus-TCP client of the FP Web-Servers in general ...................................................................160
17.4 Appendix for Modbus functions.......................................................................................................162
IEC 60870 functions of the FP Web-Server......................................................................... 16318.
18.1 IEC 60870 general functions...........................................................................................................163
18.1.1 Details of the IEC 60870 configuration: modem and multipoint settings.............................164
18.2 Parameters for IEC 60870...............................................................................................................167
18.3 IEC 60870 library for control FPWIN Pro ........................................................................................167
SNMP functions.................................................................................................................... 16919.
19.1 Overview of SNMP on the FP Web-Server.....................................................................................169
19.2 Parameters for SNMP .....................................................................................................................171

Table of contents
FP Web-Server V2.810 EN 7
19.2.1 SNMP Version.....................................................................................................................171
Additional information..........................................................................................................17320.
20.1 Contents of the CD and auxiliary programs ....................................................................................173
20.2 Description of the HTML examples.................................................................................................173
20.3 PLC connection, cable drawings, modem.......................................................................................174
20.3.1 PLC connection...................................................................................................................174
20.3.2 Cable drawings and modem ...............................................................................................175
20.3.3 DIP switches........................................................................................................................176
20.3.4 LEDs....................................................................................................................................178
20.3.5 Clearing passwords.............................................................................................................178
20.4 IP and TCP/IP..................................................................................................................................179
20.5 Setup of an individual Ethernet LAN ...............................................................................................181
20.6 Preinstalled passwords and safety instructions ..............................................................................184
20.7 Troubleshooting...............................................................................................................................186
20.7.1 Network communication problems......................................................................................186
20.7.2 Problems finding an FP Web-Server unit or unable to send configuration.........................188

Getting started
8 FP Web-Server V2.810 EN
Chapter 1
Getting started
1.1 BEFORE YOU START
Please read the following notes on HTML. It will make working with the FP
Web-Server easier for you:
Make sure that you have worked through the First Steps (see p. 32) before
you try out the HTML functions of the FP Web-Server.
In order to use HTML you do not have to be able to tag or program HTML.
Various software is at your disposal:
Word, Frontpage (delivered with MS Office) et.al. can serve as editors
for creating HTML files.
The created HTML file will be saved on the FP Web-Server with the help
of the Configurator.
A browser (e.g. Internet Explorer) is used to display the .htm file.
These software tools provide the logical markup (i.e. text parts are
automatically adjusted to any screen format without using a lot of
memory) and easy linking that define HTML.
Please refer to the respective software company for questions on software
not provided by Panasonic mentioned in this manual (or on the software
you chose to work with HTML).
There are two ways to create HTML files:
Simple: You use editors that translate data into HTML automatically.
When using these editors, you need no special knowledge about HTML.
Advanced: You create HTML files directly. You need to have knowledge
about HTML.
For the FP Web-Server you need to have basic knowledge on how to use
HTML.

Getting started
FP Web-Server V2.810 EN 9
In case you lack knowledge about HTML, Panasonic provides you with a
brief introduction in the section First HTML Page Including PLC Data. In
addition, we have inserted examples on HTML (see "Description of the
HTML examples" on p. 173) on the CD (supplied with the FP Web-Server).
You can install and modify them easily without knowledge of HTML.
1.2 Product numbers and versions
Item
Product name
Part number
FP Web-Server (Hardware)
FP WEB-SERVER UNIT
FP-WEB
(Japan: AFP0610)
FP WEB-SERVER2 UNIT
FP-WEB2
(Japan: AFP0611)
FP Web Expansion
(Hardware)
FP Web Expansion Unit
FPWEBEXP
Configurator Software
FP Web Configurator Tool
Ver.2.810
FPWEBTOOL2
(Japan:
AFPS30520-D)
FP Web Configurator Tool
Ver.2.810 Upgrade
FPWEBTOOLR2
(Japan:
AFPS35520-D)
Software for creating HTML
visualization for FP-WEB2
FP Web Designer
AFPS36510
You can retrieve information on the following components by clicking on
the system icon (see p. 42) in the upper, left-hand corner and selecting
"About Configurator...":
Control FP Web Configurator Tool
Serial number
Name of owner and organization
The hardware version (see p. 16) is printed on the type plate of the FP
Web-Server.
1.3 System requirements
The FP Web Configurator Tool has the following system requirements:
Windows® 7, Windows® 8.x or Windows® 10
Hard disk with at least 27MB free disk space
Color or monochrome monitor

Getting started
10 FP Web-Server V2.810 EN
Standard Internet browser (e.g. Microsoft Internet Explorer, Mozilla
Firefox, Google Chrome, Apple Safari, Opera) to display HTML pages
The user needs administrator rights on his computer to perform the
following actions:
Install or update the FP Web Configurator Tool
Define a default editor.
1.4 Advantages and functions of the FP Web-Server
The multifunctional FP Web-Server unit allows you to access FP Series PLCs
via Ethernet networks (Intranet and Internet) for data exchange.
Access can be carried out by a computer and a standard browser, such as
MS Internet Explorer Mozilla Firefox, Google Chrome, Apple Safari or
Opera, by specifying the target unit's IP address, which can be changed.
The HTML page can be generated with standard tools, such as Frontpage,
Dreamviewer or MS Word (not supplied with the Configurator). Panasonic
offers the FP Web Designer (Product Number: AFPS36510) for easily
designing HTML pages without any knowledge of programming languages
for HTML, PHP, Java or Javascript.
FP Web-Server advantages:
Use standard browser, save Scada software
Use existing Intranet, save wiring
Representation of PLC data in HTML pages
Value input and change of values in the PLC (set value, outputs,
internal flags) via HTML pages.
Password protection for access
E-mail send function (alternatively via Internet dialup), e.g. for the
alarm function (optionally with PLC data attachments)
Remote programming: remote access via modem (via Dial-up
Networking)
Data transfer: process control system, PLC programming, telemetry,
remote maintenance, monitored state function
Interfacing RS232C serial data via Ethernet, i.e. two FP Web-Servers
are used to send RS232C data via Ethernet

Getting started
FP Web-Server V2.810 EN 11
Modem gateway functions to other PLCs equipped with an FP
Web-Server
FP Web-Server functions:
The FP Web-Server works as an interface between a LAN or a WAN network
(Internet/ Intranet) and all PLCs of the FP series. The following main
features are supported:
RS232C/ Ethernet interface: (see p. 123)
RS232C to Ethernet redirection/ conversion
Programming and visualization tools access via Ethernet
Optional: password protection and IP lock security
Optional: second, full transparent port
Web-Server: (see p. 81)
PLC data presented as HTML pages
Access via standard Internet browser
HTML entry field for PLC data exchange
Optional: password protection
Optional: PLC data display using Java applets
PLC data delivery as XML files
E-mail: (see p. 47)
PLC can send out an e-mail
PLC defined or pre-stored e-mail text

Getting started
12 FP Web-Server V2.810 EN
E-mail sending via LAN or Internet dialup
Optionally with PLC data attachments
Modem/ Ethernet gateway: (see "Dial-in networking setup for computer/FP Web-Server" on p.
130)
FP Web-Server can be dialed-up via modem for local or network access
One remote gateway for multiple FP Web-Servers provided in a local
Ethernet network
Remote password handling
IEC60870 protocol (optional): (see p. 163)
IEC60870-5-101 standard telecontrol communication protocol via serial
interfaces
IEC60870-5-104 standard telecontrol communication protocol via
Ethernet
Optionally with modem support
Network Time Server: (see p. 155)
PLC real-time clock can be synchronized via NTP server
Modbus RTU/TCP functions: (see p. 157)
Modbus RTU master/slave functionality
Modbus-TCP client/server functionality
Modbus RTU/TCP gateway
MEWTOCOL/Modbus gateway
SNMPv1 agent: (see p. 169)
The SNMP agent (see p. 169) feature allows any SNMP management
system to exchange data with FP Web-Server devices via the Ethernet
using SNMP version 1 protocol.
FTP client: (see p. 52)
The FP Web-Server unit can be configured as an FTP client (see p. 52)
for sending user-defined, current PLC data or logged data to a remote
FTP server.

Getting started
FP Web-Server V2.810 EN 13
Data logger: (see p. 61)
The FP Web-Server unit can log PLC data (see p. 61) and store it on the
optional SD memory card or send it via FTP (see p. 52).
Secure data transmission and authentication: (see p. 58)
The FP Web-Server unit can communicate via OpenVPN (see p. 58) to
get an encrypted and secure data transmission and authentication.
The FP Web-Server comes in an FP0 housing and has the following interfaces: (see "Hardware
description" on p. 15)
RS232C interface which can be connected to the PLC (MEWTOCOL
protocol)
Ethernet 10/100BaseT interface for network connections using the TCP/
IP protocol
2nd RS232C interface for an optional modem or for full transparent
Ethernet/ RS232C communication
The optional FP Web Expansion unit has the following functions:
USB 1.1 host port
RS485 port
Digital output
SD memory card slot
Configurator software (see p. 39)
A Windows program is supplied to make the configuration and the setup of
the FP Web-Server easy. This configuration program is called "Control FP
Web Configurator Tool". It helps the user to quickly set up and change the
following items, e.g.:
Automatic integration of PLC data into HTML pages
Preparation of pre-stored mail addresses and texts
TCP/ IP address and parameter configuration (DHCP is also possible)
Password and security setup

Getting started
14 FP Web-Server V2.810 EN
1.5 FP Web-Server block diagram
1.6 System sample network
Any combinations of the LAN and the dial-up functions are possible, e.g. an
Ethernet network connecting several FP Web-Servers with one FP
Web-Server set up as a gateway for the dial-up connections.

Hardware description
FP Web-Server V2.810 EN 15
Chapter 2
Hardware description
2.1 The FP Web-Server unit
2.1.1 Introduction
Please read the safety instructions in important notes (see p. 21) and also
the section on mechanical installation (see p. 23) carefully.
The FP Web-Server allows you to connect the Panasonic FP Series PLCs to
an Ethernet Network (LAN).
The FP Web-Server works as an Interface between a LAN or a WAN
network (Internet/ Intranet) and all PLCs of the FP Series.
The following main features are supported:
RS232C/ Ethernet Interface (remote programming monitoring and
visualization)
Web-Server (http/https server supplies HTML pages with PLC data (see
comments))
E-mail (SMTP protocol)
Modem/Ethernet gateway (PPP Server function)
Modbus-TCP/RTU functions
NTP time synchronization
Optional: IEC60870
SNMPv1 agent
FTP client, FTP server
Data logger (requires FP Web expansion unit)
A Windows program is supplied to make the configuration of the FP
Web-Server easy (see comments).
Note

Hardware description
16 FP Web-Server V2.810 EN
See above for a more detailed overview (see p. 8) of the FP Web-Server
functions. There you can also find a block diagram, a list of features and a
brief description.
A data sheet can be found below which also lists the supported standards
and protocols.
Comments:
A standard HTML editor (not supplied with the FP Web-Server
Configurator Tool) is needed to design HTML Web pages. HTML pages
can easily be created with the FP Web Designer (product number:
AFPS36510) without knowledge of HTML or any other programming
language.
A standard Internet browser, e.g. Microsoft Internet Explorer, Mozilla
Firefox, Google Chrome, Apple Safari, Opera, is recommended for
displaying the HTML pages.
2.1.2 Hardware version
The unit hardware model and version is printed on the type plate. Two
different hardware models are available:
Model 1: "FP Web-Server" unit (FP-WEB)
The hardware version 1.2 (available since 2003) is identical to hardware
version 1.1 except that the pin assignment of the 9-pin RS232C connector
was optimized and the UL approval sign is printed on the unit label.
Hardware version 1.3 (available since the beginning of 2006) is identical to
hardware version 1.2 but with the Panasonic logo and RoHS conformity.
Model 2: "FP Web-Server2" unit (FP-WEB2)
Version 1.0 of this new hardware model has been available since December
2006.
The following table presents a brief comparison of the two models.
FP-WEB2
FP-WEB
Ethernet interface
100Mbps
10Mbps
Application memory
8MB Flash
0.5MB Flash
CPU speed
24 bits at 25MHz
16 bits at 20MHz

Hardware description
FP Web-Server V2.810 EN 17
Hardware version 1.01 has improved PLL circuitry on the CPU for a better
start-up behavior.
Hardware version 1.1 contains an additional right-side expansion connector
to support the FP Web expansion unit .
Comment:
The FP Web Configurator Tool (Ver.2.3 and higher) can configure all
available hardware types and versions.
2.1.3 FP Web-Server unit package
The FP Web-Server unit package of Panasonic contains:
one FP Web-Server unit
a 24V DC power cable
a leaflet providing installation instructions
Phoenix 3-pin screw terminal
Comments:
The FP Web-Server network will be configured via the Control FP Web
Configurator Tool.
The Control FP Web Configurator Tool can be purchased separately.
For creating HTML pages a standard HTML editor (not supplied with the
Configurator) is required.

Hardware description
18 FP Web-Server V2.810 EN
2.1.4 Parts and functions
Below are two illustrations of the FP Web-Server's parts and their
functions:
Q
Ethernet (RJ45)
(Ethernet 10-Base-T / 100-Base-Tx) use Standard Ethernet CAT.5
W
RS232C (without handshake)
Screw terminal. Connects to the PLC.
E
2nd RS232C (SUB-D 9 male)
Compatible to IBM PC serial port.
Use standard serial computer cables.
–Connects to modem (PPP), or
–Transparent communication with 2nd PLC, computer, panel, etc.
R
24V DC, use Panasonic power cable
brown = +24V DC
blue = GND
green = framing ground
T
Connector for FP Web expansion unit
16-pin expansion connector

Hardware description
FP Web-Server V2.810 EN 19
LEDs (see p. 177).
The expansion connector is for the FP Web expansion unit only.
FP0 expansion units are not supported and may damage the FP-WEB2
unit.
Only FP-WEB2 units with hardware version greater than 1.1 are
equipped with the connector for the FP Web expansion unit.
2.1.5 Technical data
Feature
Description: Type 1
Type 2
Product number
FP Web-Server
PN Hardware: FP-WEB
PN Hardware: FP-WEB2
PN Configurator: FPWEBTOOL2
PLC connection
PLC COM: RS232C via 3-pin screw terminal port Plug:
Phoenix product: MC1,5/3-ST-3,5 Order Number: 18 40
37 9
Modem / 2nd
RS232C
Modem COM: RS232C via 9-pin SUB-D port, with RTS,
CTS Plug: 9-pin SUB-D female
Power supply
24V DC Molex 35 plug on the bottom side of the unit
Ethernet connection
Ethernet-COM: 10BASE-T
via RJ45 female connector
10BASE-T / 100BASE-TX
autoneg via RJ45 female
connector
LEDs (see p. 177)
Power, Ethernet, PLC data
exchange
Power, Ethernet, Ethernet
data, PLC data
Protocols and
standards
TCP/IP, UDP/IP, DHCP, FTP, TELNET, http, https, SMTP,
ESMTP-Auth, POP3, PPP, IEC60870, NTP, Modbus,
DynDNS, SNMPv1
Flash memory
512KBytes
8MBytes
For further information, refer to Available Memory
Calculation in the online help.
RAM
512KBytes
8MBytes
Operating voltage
24V DC (10.8 –26.4V DC supplied by class 2 circuit
only)
Current consumption
Approx. 75mA at 24V DC
Approx. 65mA at 24V DC
Degree of protection
IP20
Ambient temperature
0°C to +55°C
Storage temperature
-20°C to +70°C
Humidity
Max. 30% to 85% (non-condensing)
Vibration resistance
10Hz to 55Hz, 1 cycle per minute with a double
amplitude of 0.75mm; 10 minutes every X-, Y-, and
Z-axis
Shock resistance
Min. 10g; 4 times every X-, Y-, and Z-axis
Dimensions
Height 90mm, Width 25mm, Depth 64mm
Note
