Panasonic Panaboard KX-BP800U User manual

ElectronicPrintBoard
(Interactive Panaboard)
Operating Instructions
withInstallation Manual
(forqualified service personnel)
KX-BP800U/KX-BP800G/
KX-BP800A/KX-BP800C/
KX-BP800T
MODELNO.
•To assemblethisunit, pleaserefertothe Installation Manualon pages82 through 94.
•Before operating thisunit, pleaseread theseinstructions completely.
After reading them,keep themforfuturereference.
•Because of the nature of the print film,all the printed textwill remain on the film.
•Thisproductisdesigned forinstallation bya qualified servicing dealer.
Installation performed bynon-authorized individuals couldcausesafety-related problemswith
the operation of thisequipment.
Stand and wall-mounting kitare optional.

Thank you forpurchasing the PanasonicElectronicPrintBoard.
Foroptimumperformance and safety,please readthese instructions carefully.
Warning aboutsaving data
When the systemstorage device oranyofitsoptionalstorage deviceisadverselyeffected byoperational
errors,staticelectricity,electricalnoise,vibration,dustorwhen the powerhasbeen cutoff due tomalfunction,
repairorinadvertently, the memory contentsmaybe lostorchanged.Before operating the system,make a
pointofreading the precautionarynotesinthe Operating Instructionsand the helpinformation,and observe
themduring operation.
Please observe carefullythefollowing precaution:
•Make absolutely surethatall importantdatais saved byback-up orthe original is saved.
The manufacturerherebydeclaresthatitcannotbe held accountableforanyloss orchange in anydatastored
on floppydisks,hard disks,opticaldisks,orother memorydevices.
•Filmcassette (Blue gearx1,Green gears x 3) ··········· 1
•Thermaltransferfilm (20m) ······························· 1
•Markers(Black,Red,Blue-Big)················Each 1
•Eraser·································································1
•A4(Letter) papers*·······························20 sheets
•Pen holder··························································2
•Markersforinteractive
(Black,Red,Blue, Green-Small)······ Each 1
•Electroniceraser················································1
•Erasercloth(forElectroniceraser) ····················2
•Batteries(LR03)·················································6
•Powercord·························································1
•Interactivecable(5m) ········································ 1
•SoftwareCD-ROM·············································1
•Operating Instructions········································1
•Software LicenseAgreement ·····························1
•Wall-mounting template····································· 1
•Microsoft®,Windows®,WindowsNT®,NetMeeting®,PowerPoint®and CalliGrapher®are either registered
trademarks ortrademarks ofMicrosoft Corporation inthe United Statesand /orothercountries.
Windows®isMicrosoft®Windows®operating system.
WindowsNT®isMicrosoft®WindowsNT®operating system.
NetMeeting®isMicrosoft®NetMeeting®conferencing software.
PowerPoint®isMicrosoft®PowerPoint®presentation graphics program.
•IBM®isaregistered trademarkof InternationalBusiness MachinesCorporation.
•Pentium®isaregistered trademarkof Intel Corporation inthe U.S.and othercountries.
•Adobe®,Acrobat®areregistered trademarks ofAdobe SystemsIncorporated.
•All trademarks referred tointhismanualarethe propertyof their respectivecompanies.
Accessories
*KX-BP800U/G/A/T:A4
KX-BP800C:Letter
The markers(Big)and the eraserare used forotherthan the interactivefunction.
The markersforinteractive(Small)are used whileinserted inthe pen holder.
Inthismanual, the pen holderwithamarkerforinteractive(Small)is called the ElectronicPen.
The ElectronicPen and the ElectronicEraserare used withthe interactivefunction.
2

FUSE
THE SOCKET-OUTLETMUSTBE NEARTHIS EQUIPMENTAND MUSTBE EASILY ACCESSIBLE.
WARNING:
TOPREVENT FIREORSHOCKHAZARD,DONOT
EXPOSE THIS PRODUCT TORAINORANYTYPE OF
MOISTURE.
CAUTION:
TOPREVENTRISK OFELECTRICSHOCKHAZARD,DO
NOTREMOVE THECOVEROF THIS PRODUCT,REFER
SERVICINGTO QUALIFIEDSERVICE PERSONNEL.
The productshould be used onlywiththe powercordthatis supplied bythe manufacturer.
ForusersintheUnitedKingdomonly
SafetyInformation
Thisapplianceis supplied withamoulded three pinmainsplug foryoursafetyand convenience.
A5 amp. fuseisfitted inthisplug.Shouldthe fuse need tobereplaced please ensurethat the replacement
fuse hasarating of5 amps.and thatitisapproved byASTAorBSI toBS1362.Check forthe ASTAmark
orthe BSImarkon the bodyof the fuse. If the plug containsaremovablefusecoveryou mustensure
thatitisrefitted when the fuseisreplaced. If you losethe fusecoverthe plug mustnotbe used until a
replacementcoverisobtained.Areplacement fusecovercan be purchased fromyourlocalPanasonicDealer.
If the fitted moulded plug isunsuitableforthe socketoutletinyourhomethen the fuseshouldberemoved and
the plug cutoff and disposed ofsafely.
Thereisa dangerofsevere electricalshock if the cutoff plug isinserted into any13 amp.socket.
If a newplug istobefitted please observethe wiring code as shown below. If in anydoubtpleaseconsulta
qualified electrician.
WARNING:Thisappliancemustbe earthed.
IMPORTANT: The wiresinthismainslead arecoloured in accordancewiththe following code.
Green-and-Yellow:Earth
Blue :Neutral
Brown:Live
Asthe coloursof the wireinthe mainslead of thisappliancemaynotcorrespond withthe coloured markings
identifying the terminalsinyourplug,proceed asfollows.
The wirewhichis coloured Green-and-Yellowmustbe connected tothe terminal inthe plug whichismarked with
the letterEorbythe Earthsymbolorcoloured Green orGreen-and-Yellow.
The wirewhichis coloured Blue mustbe connected tothe terminal inthe plug whichismarked withthe letterN
orcoloured Black.
The wirewhichis coloured Brownmustbe connected tothe terminal inthe plug whichismarked withthe letterL
orcoloured Red.
Howtoreplace thefuse : [KX-BP800Uonly]
Open the fusecompartmentwith a screwdriverand
replacethe fuse.
3

Features
The KX-BP800 seriesisequipped withtwointeractivefunctions;Projector mode and Whiteboardmode,in
addition toaregularelectronicprintboardthatutilizesplain paper.Itispossibleto usethisproductasfollows.
•Electronicprintboard
Functions
•Allows copying up to 9 copiesperscreen
•Allowsprinting in2levelcontrast(Normal/Dark)
•Allowsprinting of2-screensat the time by compressing themintoasinglesheetofpaper
•Projector mode (Interactivefunction)
Connect the InteractivePanaboardto a computerthatis connected toaprojectorand usethe projectorto
project the image ontothe InteractivePanaboard.
Thisis called the Projector mode.
Inthismode, the following operationsare possible:
•Operating the computerusing the ElectronicPen withits cap on asamouse
•Drawing handwritten linesorerasing itusing the ElectronicPen withits cap on inthe projected image
•Saving the projected image toanimage file and printing the projected image
•Recording the operationsofdrawing and erasing handwritten lines,playing back and editing the
recorded operationslater
InProjector mode, the projected computerimage on the screen of the InteractivePanaboardcan be
operated byusing the ElectronicPen asamouse.You can executethe application and electronicallywrite
orerase notes.The electronicallyhandwritten orpartiallyerased computerimage can be stored into an
image file.Thiswill helpmakeyourpresentation moreimpressivetothe attendants.
4

Features
•Whiteboardmode (Interactivefunction)
By connecting the InteractivePanaboardtoacomputer, the information written on the Interactive
Panaboardisdisplayed on the computerinreal-time.
Thisis called the Whiteboardmode.
Inthismode, the following operationsare possible:
•The information written on the InteractivePanaboard using the ElectronicPen withits cap off will be
displayed on the computerscreen at the sametime.
•The information erased using the ElectronicEraserwill be erased inthe computeraswell.
•You can save drawingsand notesinto a filewhichcan laterbe printed.
•Allowsthe usertorecordthe information being written orerased inafilethatcan be played back asa
movie and itcan be edited ifneeded.
•PCInterface(Option)
When the optionalPCInterfaceKit(KX-BP095U)isused,you can scan monochromeimagesfromthe
KX-BP800 seriesintoacomputer running Microsoft®Windows®orWindowsNT®and printdocuments
on the computertothe printerof the KX-BP800 series.
Forthe operation using the PCInterfaceKit, pleaserefertothe Operating Instructionsof the PCInterface
Kit(KX-BP095U).
5

Precautions···········································································8
PartNames and Functions·················································12
•The controlpanel·····························································13
Installing ThermalTransferFilm······································14
Loading CopyPaper··························································16
Making Copies ····································································18
•Copytypesand procedures···········································19
Replacing ThermalTransferFilm·····································20
PaperJams·········································································21
BeforeUsing theInteractive Function ·····························24
•Setting the ElectronicPen ····························································· 24
•Setting the ElectronicEraser·························································25
•Replacing the erasercloth·····························································25
•System requirements·····································································26
•Connecting tothe PC···································································· 26
•Installing the software····································································27
•Uninstalling the software························································· 27
Using theInteractive PanaboardSoftware····················· 29
•Startup the InteractivePanaboardSoftware································ 29
•Pop-up menu configuration of
the InteractivePanaboardSoftware······················30
•Switching the mode ········································································30
•Settingsof the InteractivePanaboardSoftware····························31
•Referencethe help·········································································33
•Displaythe information about
the InteractivePanaboardSoftware······················33
•Exiting the InteractivePanaboardSoftware·································· 33
ProjectorMode···································································34
•Precautionswhen using a projector·············································· 34
•Basicoperation flow inProjector mode ·········································35
•AboutDesktop Drawing Tool·························································39
•Desktop Drawing Tooloperation ··················································· 40
•About On-Screen Keyboard··························································47
•On-Screen Keyboard operation ···················································· 47
•AboutView window········································································50
Pages
TableofContents
6

Installation
WhiteboardMode·······························································51
•Basicoperation flow inWhiteboardmode ·····································51
•AboutWhiteboardwindow·····························································53
ViewWindoworWhiteboardWindow Operation ··········· 54
•Differencesbetween the View windowand
the Whiteboardwindow············54
•Menu configuration ········································································ 54
•Toolbars························································································57
•Create an IPB document(Whiteboardwindowonly)···················· 58
•Open an IPB document ································································· 58
•Savethe IPB document ·································································58
•Savethe IPB documentin anotherfileformat ······························ 59
•Change displaymethod ·································································62
•Switch a page of the IPB document ··············································62
•Edita page of the IPB document ·················································· 63
•Playback the IPB document ·························································· 66
•Recognizing Handwriting inthe IPB document ···························· 66
•Print the IPB document ································································· 68
•Settings·························································································· 69
RemoteConferencing using Microsoft®NetMeeting®····73
•AboutNetMeeting®········································································73
•Example ofusing NetMeeting®····················································· 73
DailyCare and Maintenance ·············································75
Troubleshooting ·································································77
•Meaningsofvariousdisplays ························································ 79
Specifications·····································································80
•Consumable and accessories························································81
Installation Manual ·····························································82
The IPB documentisaInteractivePanaboardformat file(extension ".ipb").
Pages
TableofContents
7

Locking the casters
(Pushthis side)
Never removethe cover,ortake apartor modifythe
product. Thiswill voidthe warranty.Do notposition the electronicprintboardin a location whereitisnotstable.
Do notputdrinks orotherliquidson the tray.Afterinstalling or moving the electronicprintboard,
lock the castersand set the fall-prevention extension
legs.
Do notusethe electronicprintboardin an
excessivelyhumid ordustylocation.If the electronicprintboardisnotgoing to be used foran extended period of time(e.g., during extended
holidays), turn off the powerand removethe plug
fromthe wall outlet.
Precautions
8

Installation •Do notinstall the unitwhereitmaybe exposed to directsunlight, near
heating equipment, ornearair-conditioning ventsasthismay cause
stretching and /ordiscoloration of the screen.
•Do notinstall the unitinlocationshaving a temperature of10°Corloweror
wherethe temperaturemay change suddenlyasthismaydisablethe unit's
abilitytomakecopies.
Screenfilm•Makethick and darklinesinside the copying
area.Notethatanywriting inside the
shaded area on the right figurecannot
be copied.
•Use a commerciallyavailablewhite boardcleanerforhard-to-erasestains.
(SANFORD®EXPO®white boardcleaneretc.)
•Do noterasewith an overlydirtyeraser.(See pages75 and 77.)
•Do notallow writing toremainonthe screen foran extended period of time
asitwill become harderto erase.
•Periodicallywipe the screen filmgentlywith a water-dampened cloththat
hasbeen thoroughlywrung.(See page 75.)
•Do not touchthe screen,writewithmarkers,orerasewhilethe screen is
moving asthismayresultin damage tothe unit.
Markers,
Erasers and
Thermal
transferfilm
•Use onlythe included ordesignated markers,erasersand thermaltransfer
film.(See page 81.)
Use ofaccessories otherthanthose included ordesignated(suchas oil-
basedmarkers)may damagethe screen or resultin hard-to-erase markings.
•Copyqualityincreaseswiththe thickness of the drawnline.To ensure
quality copies,please usethe markers(Big).
•The markersforinteractive(Small)drawthinlines.The qualityof the copies
maybe reduced when thesemarkersare used.
•Do notstorethe thermaltransferfilminalocation subject to extreme
changesintemperature(such asnearairconditioning orheating equipment)
asthismay causecondensation on the thermaltransferfilmand resultin
poorprintqualityand /orpaperjams.
•Storemarkershorizontallyas verticalstorage may stop the inkfromcoming
out.
•The length ofone roll ofdesignated thermaltransferfilm (Replacement film:
KX-BP081 orKX-BP082)isapproximately100 meters. One roll of thermal
transferfilmcan make approximately300 sheetsofcopies.
Notethat thetotalnumberofcopies may differdepending on theoperating
conditions.
Also notethat thelength of thethermaltransferfilmsuppliedwiththeunitis
shorterthanthereplacement film roll and isonly approximately20meters.
copying area
25mm
25mm
35mm 35mm
SANFORD®and EXPO®areregistered trademarks ofSanfordcorporation.
Precautions
9

NG OK
Transmitter
Powercord
and Interactive
cable
•Beforemoving the unit, disconnect the powercordfromthe electricalpower
socketand AC inlet, and disconnect the interactivecablefromthe
interactiveconnectorand a PC.Then coil themfortransportation.Failureto
do thesecausethe cord and cableto be damaged if theyarestepped on or
if they catch on something whilethe unitisbeing moved.
Replacing the
Thermal
transferfilm
•Dispose of the used thermaltransferfilminatrashreceptacleforburnable
trash.
•Anegative of the copied image will remain on the thermaltransferfilm.
(To protect the securityofyourinformation,werecommend cutting up used
thermaltransferfilmwithscissorsorshredderbefore disposing ofit.)
Electronic
Penand
Electronic
Eraser
•Do notcoverthe transmitterwithyourhand while using an interactive
function asthismay causethe position of the ElectronicPen orthe
ElectronicErasernot to be normallydetected.
•Press downfirmlywiththe pointof the ElectronicPen orthe erasercloth of
the ElectronicEraseron the screen filmuntil you heara buzzing sound,and
then moveitslowly.
However,do notpress downthe pointof the ElectronicPen too much
stronglyasthismaymake a dentinthe screen back panel.
•Do notusetwo or morethe ElectronicPensorthe ElectronicEraserat the
sametime asthismay causethe position of the ElectronicPen orthe
ElectronicErasernot to be normallydetected.
•Forprecise positioning,keep the ElectronicPen and ElectronicEraser
perpendicularlytothe screen during use.
•Since ultrasonicisused to detect the position of the ElectronicPen and
ElectronicEraserwhen theyare being used,you mayheara buzzing
sound,but thisisnotharmfultothe human bodyorperipheralhardware.
It will also notresultin an electric shock.
Precautions
10

Apso uso aspilhas/baterias contidasneste
produto poderoserdispostasemlixo domstico.
Brasil
BatteryIf batteriesare used improperly,batteriesmayleak,causing corrosion of the
product, ortheymayburst. To prevent this,always followthe precautions
given below.
•Always remove batteriesfromthe ElectronicPen and ElectronicEraserif
theyare not to be used foran extended period of time.
•Usethe sametype ofbatteries.Do notmixdifferent types.
•Do notmixold and newbatteries.
•Always insertbatterieswiththeirpolarityproperlyoriented asindicated on
the ElectronicPen orElectronicEraser.
•If the ElectronicPen orElectronicEraserceasestofunction because
batterieshaverun out, removethemimmediatelyand dispose of them
according tolocalregulations.
Leaving drained batteriesinthe ElectronicPen orElectronicEraser may
resultinleakage.
•Do notdisassemble batteriesorplacethemin a fire.
•Do notshortbatteries.
•Alkaline batteries cannotbe recharged.Neverattempt torecharge alkaline
batteries.
Projector•Light fromthe projector mayenterthe eyewhen using a projectorto project
imagesforthe purpose ofmaking presentationsand so on.Bevery careful
asdirectprojectorlightmayhurt the eyes.
Precautions
11

ElectronicPen/Electronic
EraserPosition Receiver
On
Off
PowerSwitch
OutputPort
Outputs copypaperthat
hasbeen copied.Can hold
up to20sheets.
PaperCover
Open this coverwhen loading
copypaper.
PrinterDoor
Open the printerdoorwhen loading
transferfilmorwhen removing
paperjams.
(See pages14,20 and 21.)
Screen Film
AC Inlet
Tray
Interactive Connector
PowerCord
PrinterOpen Lever
Push downthislever
to open the printerdoor.
ControlPanel
ElectronicEraser(See page 25)
When using the projector mode to operatethe
computerscreen on the printboardscreen and
operating the pen while holding downthe pen
button achievesthe samefunction aspressing
the rightmouse button.
EraserCloth
EraserCover
ElectronicPen(See page 24)
PenHolderLever
PenButton
ContrastKey
2-ScreenCopyKey Multi-Copy/Stop Key
CopyKey
Contrast/Remaining Film
Indicator
Multi-Copy/ErrorIndicator
Advance Key
ElectronicPen/Electronic
EraserPosition Receiver
PartNames and Functions
12

1 2
NamePanelDescription
Contrast/
Remaining
Film
Indicator
Thislampindicatornotifiesthe userwhen the timetoreplacethe
thermaltransferfilmisapproaching (estimated)and of the printing
contrastused during copying.
Indicatoroff : Normalprinting contrast.
Indicatoron :Darkerthan normalprinting contrast.
Indicatorflashing :*Almost timetoreplacethe thermaltransferfilm.
(Notethatonly about15 more sheetsmay be copiedwhen
thisindicatorstartsflashing.)
Replacement film(KX-BP081 orKX-BP082)is separately
availablefromthe dealerwhereyou purchased yourunit.
*Theflashing indicatorwill go outafterthepoweristurned off and theprinter
has been openedand closed.(Whencopying isperformed,thisindicatorwill
beginflashing again.)
Contrast
Key Eachtimethis keyispressed, the unitwill alternate between normal
and dark contrastmodes(Normal/Dark).
2-Screen
CopyKey This key causesthe frontand back of the screen to be copied on a
singlesheetofpaper.
CopyKey This keyprintsacopyof the screen.
Multi-
Copy/
Error
Indicator
Thisindicatordisplays the numberofcopiestobemade.The display
changeseachtimethe multi-copy/stop keyispressed.
Example 1 2 ... 9 1 ...
When an erroroccurs,aflashing symbol will appearinthisdisplaytoindicatethe
errorstatus.(See page 79.)
Multi-
Copy/
Stop Key
When making multiplecopies,press this keyuntil the desired
numberofcopiesisdisplayed on the multi-copy/errorindicator.
This key can also be pressed whilemultiplecopiesare being made
tostop the copying process.The displayindication changeswhile
multiplecopiesare being made as shown below.After reaching 0,
the displaywill reset to 1.
Example:5 4 3 2 1 0 1 (countdown displayduring
copying)
Advance
Key This keyadvancesthe screen from right toleft.
PartNames and Functions
The controlpanel
13

ON
OFF
PowerSwitch
GreenGear
GreenGear
Thermal
TransferFilm
GearTabs
Tabs
GreenGears
BlueGear
BlueGear
Grooves
(Blue)
Grooves
PrinterDoor
PrinterOpen
Lever
1
Set the powerswitchto on ( ).
•" " will flashonthemulti-copy/error
indicatorwhenthethermaltransferfilmhas
run out.
3
Insert the fourgearsintothe newthermal
transferfilm.
•Securely align thegeartabswiththegrooves
inthethermaltransferfilmand insert them
as faras they will go.
•Thereisabluegearand three green gears
which needto be attachedas showninthe
figureon theright.
2
Push downthe printeropen leverand open
the printerdoor.
Note
Installing ThermalTransferFilm
Load the thermaltransferfilmintothe filmcassette and install inthe printer.
14

English
BlueLabel
BlueGear
Thermal
TransferFilm
FilmCassette
Loadthermaltransfer
filminthisdirection
PrinterDoor
Thermal
TransferFilm
Slack Prohibited
Label
6
Install the filmcassette.
•Insert thefilmcassetteintotheprinterso
that thebluegearon the cassette alignswith
thebluelabelon theprinterand theninsert
thegearshaftson bothsides of the cassette
intothegrooves insidetheprinter.
•If thefilmis slack afterloading thefilm
cassette,take up the slack inthe same
mannerdescribedinstep5whilethe
cassetteremainsloaded.
Note
4
Load the thermaltransferfilmintothe film
cassette.
•Loadthethermaltransferfilmintothefilm
cassette sothat thebluegearinsertedinthe
thermaltransferfilmislocated on theblue
labelsideof thefilmcassette.Pushinthe
direction of the arrowuntil you hearall four
gearshafts click in place.
5
If the thermaltransferfilmis slack, take up
the slack bywinding the gearson the label
side of the cassetteinthe direction of the
arrows.
•Themulti-copy/errorindicator may flash
" " if thethermaltransferfilmis slack. In
addition,thethermaltransferfilm may
wrinkle,and blank(unprinted)spotsorblack
streaks may appearon the copypaper.
7
Closethe printerdoor.
•Securely close theprinterdoorbyusing both
handsuntil a click isheard.
•The" " flashing on themulti-copy/error
indicatorwill go out.
•If theflashing " " does notgo outeven
though theprinterdoorhas beenclosed,this
indicates that thefilmcassettehas notbeen
installed properlyorthat thereis slack inthe
thermaltransferfilm.Check the condition of
thefilmcassette and forslack inthethermal
transferfilm.
Installing ThermalTransferFilm
15
Grooves
BlueLabel
Grooves

ON
OFF
PowerSwitch
Notes on Loading CopyPaper
Note
1
Set the powerswitchto on ( ).
•" " will flashonthemulti-copy/error
indicatorwhencopypaperhas run out.
•Be absolutely suretocheck that thepoweris
on whenloading copypaperas itwill not
load properlyotherwise.
Loading CopyPaper
It ispossibletoload up to80sheetsofA4(Letter) sizecopypaper (assuming a paperweightof80g /m2).
NotethatonlyA4(Letter) paper maybe used.
When the unitisfirstused orwhen " " flasheson the multi-copy/errorindicatortoindicatethat the unitisoutof
paper,load copypaperasdescribed below.
Followthe guidelinesbelowto ensuresmooth and accurate printing bythe unit.
•OnlyuseA4(Letter)) sizecopying paperhavingaweightof60 to 90g /m2asthe copypaperforthis
unit.
•Do notsimultaneouslyload paperofvarying type and thickness asthismayresultin paperjams.
•Before adding copypaper,be suretoremove all copypaper remaining inside the unit'spapercover.
(Note:Thatcopypaperwill slightlyresistbeing removed,butmaybe pulled outwithoutproblems.)
After removing the copypaper,stack the removed papertogetherwiththe newpaper, fan it
thoroughly,squareitand reload.
DONOTUSE THEFOLLOWINGTYPES OFPAPER
•Extremely smooth orglossy paper
•Coated paper
•Thermalpaper
•Paperthatisprinted on one side
•Wrinkled paper,creased paper,etc.
16

MaximumPaperLimit
Guide
PaperCover
English
PaperCover
Magnets
2
Pull the papercoverforward as showninthe
right figure.
•Themagnets areusedas fastenersto holdthe
papercoverclosed.
4
Closethe papercover.
3
To preventpaperjams such asthose
caused bymultiplesheetsfeeding,oncefan
the paperthoroughly,squareit, align itwith
the guide inside,and insertasfarasitwill
go.
•Onlyuse A4(Letter)size copying paper
having aweightof60 to90g/m2as the
copypaperforthisunit.
•Do notstack more copypaperintheunit
thanthemaximumpaperlimitindicated by
theguide(see figuretotheright) as thismay
resultin paperjams.(Theunitcan hold
about80 sheetsofpaperhaving aweightof
80g/m2.)
Note
Notes
Loading CopyPaper
17

ON
OFF
PowerSwitch
OutputPaper
CopyKey
12
1
Set the powerswitchto on ( ).
•"1"will lighton themulti-copy/error
indicatortoindicatethat theunitisreadyto
copy.
Notes
2
Press the copy key.
•Textand illustrationson the screenwill be
copiedand copies emergefromtheoutput
port.
•Theoutputportcan hold up to20 sheetsof
copypaper.(Notethatexceeding theoutput
port's capacitymay resultin paperjams.)
•Fordetailson making multiple copies,
2-screencopies and so on,see page 19.
•Do notuse paperthathas beencopied on
one sidebythisprinteras copypaperinthis
unitorinanyothercopiersorprinters as
thismay resultin dirtyrollers,degradation of
printing quality,paperjams,and streaks and
smudges on outputpaper.
•Copyqualityincreases withthethickness of
thedrawnline.To ensurequality copies,
please use themarkers(Big).
•Themarkersforinteractive (Small)drawthin
lines.Thequalityof the copies may be
reducedwhenthese markers areused.
Making Copies
This section describeshowtocopytextand illustrationsdrawnonthe screen.
18

CopyTypeProcedure
Copying the
frontof the
screenPress .
Copying the
back of the
screen
Press tomovethe screen tobecopied tothe front.
Press .
Making multiple
copies
(up to9)
Select the numberofcopies(1to 9)bypressing asnecessary.
Press .
•Press tostop copying inmid-operation.
Making 2-screen
copies
•Copying the front
and back of the
screen on a single
sheetofpaper
Press .
Copying chart
paperChartpapercan be attached tothe screen as showninthe figure and
copied.(Besuretotakethe chartoff the screen soon aftercopying is
finished.)
•Wrinkles,slackness orfoldsinthe chartwhen attached tothe screen will showup in
copiesasdark shadows.
•Affixit tothe screen with drafting tape made by3M®orothersimilartape with
mediumadhesive.
Attach both
sides with
tape
1 2
Making Copies
Copytypes and procedures
3M®isaregistered trademarkof3MCorporation.
19
FrontBack
2-ScreenCopy
1 2

Direction for
Removing
Thermal
TransferFilm
ThermalTransferFilm
GreenGear
GreenGears
FilmCassette
Thermal
TransferFilm
BlueGear
PrinterOpen
Lever
Film
Cassette
Notes on Replacing ThermalTransferFilm
1
Push downthe printeropen leverto open
the printerdoor,and removethe film
cassettewith both hands.
2
Removethe used thermaltransferfilmfrom
the filmcassette and removethe fourgears.
3
Next, perform steps3to 7 inthe section
entitled "Installing ThermalTransferFilm"
thatcan be found on pages14 and 15.
Replacing ThermalTransferFilm
The unitis capable ofproducing about15 morecopieswhen the contrast/remaining filmindicatorbeginsto
flash.The unithasrun outof thermaltransferfilmand can no longer makecopieswhen the multi-copy/error
indicatorflashes" ".Separatelyavailablereplacement film (KX-BP081 orKX-BP082) maybe purchased from
the dealerwhereyou purchased the unit. Thermaltransferfilmisreplaced asfollows.
•Onlyusethe designated product(KX-BP081 orKX-BP082)fromPanasonicasthe replacement film.
(Notethatusing anothertype ofreplacement film mayresultin degraded printing qualityordamage to
the unit.)
•Thermaltransferfilmisdisposable.Dispose ofused thermaltransferfilmas"burnable"or"non-
recyclable"rubbish.
•Anegative of the copied image will remainonthe thermaltransferfilm.To protect the securityofyour
information,werecommend cutting up used thermaltransferfilmwithscissorsorshredderbefore
disposing ofit.
20
