Panasonic UB-T781 User manual

UB-T781
Operating Instructions
(For Basic Operations)
Electronic Board
(elite Panaboard)
Model No. UB-T781
UB-T781W
UB-T761
Installation Manual Included (for qualified service personnel)
• To assemble this unit, please refer to the Installation Manual on pages 37 through 60.
• Before operating this unit, please read these instructions completely and keep them carefully for future
reference.
• This unit is designed for installation by a qualified servicing dealer.
Installation performed by non-authorized individuals could cause safety-related problems with the operation of
this equipment.
For U.S.A. only:
• To locate the closest authorized dealer in your area, please call 1-800-449-8989.
Stand is sold separately.

Introduction
Thank you for purchasing the Panasonic Electronic Board.
For optimum performance and safety, please read these instructions carefully.
Feature Highlights
By connecting the elite Panaboard to a computer and using a projector to display the contents of the
computer’s screen on the elite Panaboard, you can do the following.
Electronic Pen Features
•Manipulate objects on the computer screen by using the electronic pen as a mouse.
•Draw and erase lines on the computer screen by using the electronic pen.
•Save images of the computer screen that were created by drawing with the electronic pen.
elite Panaboard book
Use the elite Panaboard book software that supports elite Panaboard operations, such as writing, drawing,
attaching images and computer operations. This software lets you save the contents of the screen on your
computer and retrieve it for later use.
In-built USB Speaker
The elite Panaboard has an in-built USB speaker. Sound can be heard through the USB speaker when it
is connected to a computer.
USB Hub Features
The elite Panaboard comes with a 2-port USB hub as standard. By connecting equipment such as
scanners, printers, or external USB memory sources, you can use their respective features directly with
the elite Panaboard. Also, you can incorporate the external devices smoothly using the electronic pen.
Install-Free Kit (Optional Device)
By attaching this product to an elite Panaboard and turning the power on, you can activate the elite
Panaboard software. It is not necessary to install the elite Panaboard software on your computer.
Usage Scenarios
For Education
•Create an effective learning environment by projecting a variety of educational software onto the elite
Panaboard and, with the electronic pen, directly manipulate the software and write and draw on the
screen.
•With several tools at your disposal for aiding in explanations, such as illustration and marker tools, you
can keep students’ attention through a dynamic screen display.
•Draw your students’ interest by using the screen shade feature to show questions to students while
hiding the answers, and incrementally showing the rest of the screen.
•The teacher can prepare materials before class to display on the elite Panaboard.
For Business
•Visually communicate your product’s characteristics and create an appealing presentation of your
product by displaying images and using the electronic pen to highlight key points.
•Display the contents, including what you have written using the electronic pen, of the elite Panaboard
in your company in real time on a remote computer by using TV conferencing equipment.
2 Operating Instructions (For Basic Operations)
Introduction

Things you should keep a record of
Attach your sales receipt here
For your future reference
Date of purchase
Serial number
Dealer’s name
Dealer’s address
Dealer’s tel no.
About the Operating Instructions
There are 2 separate operating manuals for the elite Panaboard.
For Basic Operations
(this document)
Instructions for connecting and operating the elite Panaboard, as
well as instructions for installation construction.
For Software
(electronic documentation)
Instructions for the included elite Panaboard software and elite
Panaboard book. The manual "Operating Instructions (For
Software)" is located on the included CD-ROM. You can view the
"Operating Instructions (For Software)" after you install the elite
Panaboard Software on your computer. For details on viewing the
manual, see "Viewing the Electronic Documentation" (page 27).
Operating Instructions (For Basic Operations) 3
1
Introduction

Abbreviations
Windows® refers to the Microsoft® Windows® operating system.
Windows® 2000 refers to the Microsoft® Windows® 2000 operating system.
Windows® XP refers to the Microsoft® Windows® XP operating system.
Windows Vista® refers to the Microsoft® Windows Vista® operating system.
DirectX® refers to the Microsoft® DirectX® application programming interface.
Trademarks
•Microsoft, Windows, Windows Vista, DirectX, and Windows Media are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
•IBM and AT are trademarks of International Business Machines Corporation in the United States, other
countries, or both.
•Intel and Pentium are trademarks or registered trademarks of Intel Corporation in the United States and
other countries.
•Adobe, Reader and Flash are either registered trademarks or trademarks of Adobe Systems Incorporated
in the United States and/or other countries.
•All other trademarks identified herein are the property of their respective owners.
Federal Communications Commission Requirements
For United States Only
Note
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC Warning
To assure continued FCC compliance, the user must use only the provided power supply cord.
Also, any unauthorized changes or modifications to this equipment would void the user’s authority
to operate this device.
4 Operating Instructions (For Basic Operations)
Introduction

Warning about saving data
When the system storage device or any of its optional storage device is adversely effected by
operational errors, static electricity, electrical noise, vibration, dust or when the power has been cut off
due to malfunction, repair or inadvertently, the memory contents may be lost or changed. Before
operating the system, make a point of reading the precautionary notes in the Operating Instructions
and the help information, and observe them during operation.
Please observe carefully the following precaution:
•Make absolutely sure that all important data is saved by back-up or the original is saved.
The manufacturer hereby declares that it cannot be held accountable for any loss or change in any
data stored on floppy disks, hard disks, optical disks, or other memory devices.
System Requirements
Computer IBM® PC/AT® or compatible with a CD-ROM drive
CPU Intel® Pentium® 4 processor or later
Operating System Windows 2000 SP4 / Windows XP SP2 / Windows Vista
(64-bit editions are not supported.)
Interface USB 2.0
Memory (RAM)
256 MB or greater (Windows 2000 SP4)
512 MB or greater (Windows XP SP2)
512 MB or greater (Windows Vista)
Hard Disk Hard disk with at least 400 MB of free space (not including the space
required for saving files)
Note
•To run the elite Panaboard software, Microsoft .NET Framework 2.0 or later and DirectX 7.0 or later
are required. When you install the elite Panaboard software on the CD-ROM, .NET Framework 2.0 will
be installed on your computer if it is not already installed.
•The system requirements above do not meet the recommended specifications of all operating systems.
•You must have Windows Media® Player 10 or later, or Adobe® Flash® Player installed to insert and play
back video.
•Inserting and playing back video is not supported in Windows 2000 SP4.
•The handwriting recognition feature is supported in Windows Vista Ultimate, Windows Vista Home
Premium, Windows Vista Business, and Windows XP Tablet PC Edition 2005.
•For users of Windows 2000 SP4 or later, or Windows XP Professional: in order to use the handwriting
recognition feature, you will have to install the Tablet PC SDK and Microsoft Windows XP Tablet PC
Edition 2005 Recognizer Pack.
•The handwriting recognition feature is not supported in Windows Vista Home Basic and Windows XP
Home Edition.
•You must have enough available hard disk space in order to record and play back video.
Operating Instructions (For Basic Operations) 5
1
Introduction

Exemption of Liability
Panasonic Communications Co., Ltd. is not responsible for accidents or injuries caused by, but not limited to,
the following:
1. Altering the device or improper installation construction.
2. Using the device for purposes beyond its intended use.
3. Earthquake, fire, flood, tidal wave, hurricane, lightning or other natural phenomena.
4. Natural aging of the building or similar phenomena.
For FRG Users (For Germany Only)
Note
Machine noise information regulation - 3.GPSGV, the maximum sound pressure level is 70 dB(A)
or less, in conformity with EN ISO 7779.
This equipment is not for use at video display work stations according to BildscharbV.
6 Operating Instructions (For Basic Operations)
Introduction

Table of Contents
