Panasonic ElitePANABOARD UB-T880W User manual

Operating Instructions
Electronic Board
(elite Panaboard)
Model No. UB-T880W
UB-T880W
Stand is sold separately.
UB-T880
Installation Manual Included (for qualified service personnel)
•To assemble this unit, please refer to the Installation Manual on pages 35 through 55.
•Before operating this unit, please read these instructions completely and keep them carefully for future
reference.
•This unit is designed for installation by a qualified servicing dealer.
Installation performed by non-authorized individuals could cause safety-related problems with the operation of
this equipment.
For U.S.A. only:
•To locate the closest authorized dealer in your area, please call 1-800-449-8989.
UB-T880-PJQXC0337ZA_mst.book 1 ページ ２０１０年５月１１日 火曜日 午後１時９分

Introduction
2Operating Instructions
Introduction
Introduction
Thank you for purchasing the Panasonic Electronic Board.
For optimum performance and safety, please read these instructions carefully.
Feature Highlights
By connecting the elite Panaboard to a computer and using a projector to display the contents of the
computer’s screen on the elite Panaboard, you can do the following.
Touch and Electronic Pen Features
•Manipulate objects on the computer screen by using your finger as a mouse.
•Use the electronic pen to draw or erase lines on the computer screen and to select line colors and other
options.
•Up to 3 people at once can draw or erase lines on the computer screen by using their fingers.
•Save what you draw on the computer screen as image files.
•Manipulate objects on the computer screen remotely by using the up and down buttons on the
electronic pen.
•Supports Windows®7 multi-touch functionality.
elite Panaboard book
Use the elite Panaboard book software that supports elite Panaboard operations, such as writing,
drawing, attaching images and computer operations. This software lets you save the contents of the
screen on your computer and retrieve it for later use.
In-built USB Speaker
The elite Panaboard has an in-built USB speaker. Sound can be heard through the USB speaker when it
is connected to a computer.
USB Hub Features
The elite Panaboard comes with a 2-port USB hub as standard. By connecting equipment such as
scanners, printers, or external USB memory sources, you can use their respective features directly with
the elite Panaboard. Input from the USB peripherals can be easily incorporated in whiteboard
presentations.
Usage Scenarios
For Education
•Create an effective learning environment by using your finger for direct control of a variety of
educational software projected onto the elite Panaboard. Write or draw on software screens with your
finger or the electronic pen.
•With several tools at your disposal for aiding in explanations, such as illustration and marker tools, you
can keep students’ attention through a dynamic screen display.
•Draw your students’ interest by using the screen shade feature to show questions to students while
hiding the answers, and incrementally showing the rest of the screen.
•The teacher can prepare materials before class to display on the elite Panaboard.
UB-T880-PJQXC0337ZA_mst.book 2 ページ ２０１０年５月１１日 火曜日 午後１時９分

Introduction
3Operating Instructions
1
For Business
•Visually convey your product’s characteristics and create an appealing product presentation by
displaying images and using your finger or the electronic pen to highlight key points.
•Information projected on the elite Panaboard at your company—including what you add, using your
finger or the electronic pen—can be displayed in real-time at remote locations using videoconferencing
equipment.
Things you should keep a record of
Abbreviations
Windows®refers to the Microsoft®Windows®operating system.
Windows®XP refers to the Microsoft®Windows®XP operating system.
Windows Vista®refers to the Microsoft®Windows Vista®operating system.
Windows®7 refers to the Microsoft®Windows®7 operating system.
DirectX®refers to the Microsoft®DirectX®application programming interface.
Trademarks
•Microsoft, Windows, Windows Vista, DirectX, Windows Media, and Internet Explorer are either registered
trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
•IBM is a trademark of International Business Machines Corporation in the United States, other countries, or
both.
•Intel and Pentium are trademarks of Intel Corporation in the U.S. and other countries.
•Adobe, Reader and Flash are either registered trademarks or trademarks of Adobe Systems Incorporated
in the United States and/or other countries.
•All other trademarks identified herein are the property of their respective owners.
For your future reference
Date of purchase
Serial number
Dealer’s name
Dealer’s address
Dealer’s tel no.
Attach your sales receipt here
UB-T880-PJQXC0337ZA_mst.book 3 ページ ２０１０年５月１１日 火曜日 午後１時９分

Introduction
4Operating Instructions
Help of the Software
Instructions for elite Panaboard software and elite Panaboard book (included) are provided in the help
information accompanying the software.
For details on accessing this information, see “Viewing the Help of the Software” (page 27).
Federal Communications Commission and Industry Canada Requirements
For United States and Canada Only
This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of
this device.
Federal Communications Commission Requirements
For United States Only
Note
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Industry Canada Requirements
For Canada Only
This equipment complies with IC radiation exposure limits set forth for an uncontrolled equipment and
meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF
energy that are deemed to comply without testing of specific absorption ratio (SAR).
FCC Warning
To assure continued FCC compliance, the user must use only shielded interface cable and the
provided power supply cord. Also, any unauthorized changes or modifications to this equipment
would void the user’s authority to operate this device.
RF Exposure Warning:
This Electronic Board may be used with below referenced optional low power 2.4 GHz USB
Wireless Adaptor and Electronic Pen and may not be co-located or operated with any other
antenna or transmitter. These transmitters comply with FCC radiation exposure limits set forth for
uncontrolled environment/general population to meet the FCC radio frequency (RF) Exposure
Guidelines in FCC/OET Bulletin 65, Supplement.
This satisfies RF exposure evaluation by calculated Maximum Permission Exposure (MPE) without
the need for tested localized specific absorption rate (SAR) measurements.
UB-T880-PJQXC0337ZA_mst.book 4 ページ ２０１０年５月１１日 火曜日 午後１時９分

Introduction
5Operating Instructions
1
Warning about saving data
System Requirements
Note
•For details about the system requirements, refer to “Read Me First” (page 22) in the install menu of the
included DVD-ROM.
•Even when the system requirements are met, the elite Panaboard response may be delayed or the
electronic pen may malfunction if other applications, anti-virus software, etc. are active.
Exemption of Liability
Panasonic System Networks Co., Ltd. is not responsible for accidents or injuries caused by, but not limited to,
the following:
1. Altering the device or improper installation construction.
2. Using the device for purposes beyond its intended use.
3. Earthquake, fire, flood, tidal wave, hurricane, lightning or other natural phenomena.
4. Natural aging of the building or similar phenomena.
When the system storage device or any of its optional storage device is adversely effected by
operational errors, static electricity, electrical noise, vibration, dust or when the power has been cut off
due to malfunction, repair or inadvertently, the memory contents may be lost or changed. Before
operating the system, make a point of reading the precautionary notes in the Operating Instructions and
the help information, and observe them during operation.
Please observe carefully the following precaution:
•Make absolutely sure that all important data is saved by back-up or the original is saved.
The manufacturer hereby declares that it cannot be held accountable for any loss or change in any data
stored on floppy disks, hard disks, optical disks, or other memory devices.
Computer IBM®PC/AT compatible with a DVD-ROM drive
CPU Intel®Pentium®4 processor or later
Interface USB 2.0
UB-T880-PJQXC0337ZA_mst.book 5 ページ ２０１０年５月１１日 火曜日 午後１時９分

Introduction
6Operating Instructions
For FRG Users (For Germany Only)
Note
Machine noise information regulation - 3.GPSGV, the maximum sound pressure level is 70 dB(A)
or less, in conformity with EN ISO 7779.
This device is not intended for use in the direct field of view at visual display workplaces. To avoid
incommoding reflexions at visual display workplaces this device must not be placed in the direct field
of view.
UB-T880-PJQXC0337ZA_mst.book 6 ページ ２０１０年５月１１日 火曜日 午後１時９分
