Panasonic VL-GM201A Operating instructions

Thank you for purchasing a Panasonic Single Monitor Station.
Please read this Installation and Operation Guide before using the unit and save for future
reference.
Single Monitor Station
Installation and Operation Guide
Model No. VL-GM201A
GM201A.book Page 1 Monday, April 4, 2005 5:10 PM

2
Table of Contents
Important Information
Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Additional safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
For best performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Introduction and Installation
Included items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Optional item information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Compatible PBXs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Location of controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Before installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installing the monitor station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Using the desktop stand (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the Unit
Turning {PBX MODE}switch ON/OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Connecting to a PBX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Answering a door call using the monitor station. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Monitoring the outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Opening a door (door opener) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Help
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
General Information
Technical data about this product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
FCC and Other Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
GM201A.book Page 2 Monday, April 4, 2005 5:10 PM

3
Important Information
Important safety instructions
1) Read these instructions.
All the safety and operating instructions should be read before the appliance is operated.
2) Keep these instructions.
The safety and operating instructions should be retained for future reference.
3) Heed all warnings.
All warnings on the appliance and in the operating instructions should be adhered to.
4) Follow all instructions.
All operating and use instructions should be followed.
5) Do not use this apparatus near water.
For example, near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement,
or near a swimming pool, and the like.
6) Clean only with dry cloth.
Do not use liquid cleaners or aerosol cleaners. Use a dry cloth for cleaning.
7) Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
Slots and Openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating. The openings should never be
blocked by placing the product on a bed, sofa, rug, or other similar surface.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
This product should not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s instructions have been
adhered to.
9) Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments / accessories specified by the manufacturer.
The lightning flash with arrow
head within a triangle is
intended to tell the user that
parts inside the product are a
risk of electric shock to persons.
The exclamation point within a
triangle is intended to tell the
user that important operating
and servicing instructions are in
the papers with the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
GM201A.book Page 3 Monday, April 4, 2005 5:10 PM

4
Important Information
12) Unplug this apparatus during lightning storms or when unused for long periods of time.
This will prevent damage to the product due to lightning and power-line surges.
13) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power- supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
SAVE THESE INSTRUCTIONS
Additional safety information
1. Use only the power source marked on the unit. If you are not sure of the type of power
supplied to your home, consult your dealer or local power company.
2. Use only the specified AC adaptor.
3. Do not tamper with the plug.
4. Make sure the plug is securely inserted.
5. Do not touch the plug with wet hands.
6. Do not place objects on the power cord. Install the unit where no one can step or trip on
the cord.
7. To reduce the risk of electric shock, do not disassemble this unit. Take the unit to an
authorized service center when service is required. Opening or removing covers may
expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric
shock when the unit is subsequently used.
8. Unplug this unit from power outlets and refer servicing to an authorized service center
when the following conditions occur:
A. If smoke rises, or an unaccustomed noise or smell is discharged from the unit.
B. If metal objects have been dropped inside the monitor station.
9. Do not put your ear(s) near the speaker, as loud sounds emitted from the speaker may
cause hearing impairment.
10. Only a qualified technician is allowed to connect a power cable to the unit.
Contact an authorized service center.
11. Do not make any wiring connections when the power supply is turned on.
12. Never install wiring during a lightning storm.
13. Do not connect a power cable other than the specified voltage.
14. Do not connect the power cable to any terminal other than the one specified.
15. When existing chime wires are used, it is possible that they contain AC voltage. Electric
shock or unit damage could result. Contact an authorized service center.
16. Never touch the inside of the monitor station. High voltage is present.
17. Make certain when mounting the unit to any wall surface that the method used will hold the
weight of the unit properly.
18. If the wiring is outdoors, use a protection tube or a surge protector.
19. If the wiring is underground, do not make any connections underground.
20. WARNING –To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This
Apparatus To Rain Or Moisture.
GM201A.book Page 4 Monday, April 4, 2005 5:10 PM

5
Important Information
21. WARNING –Unplug this unit from power outlets if it emits smoke, an abnormal smell or
makes unusual noise. These conditions can cause fire or electric shock. Confirm that
smoke has stopped and contact an authorized service center.
For best performance
LIf a power failure occurs, the unit will not function.
LDo not place any objects within 20 cm (8 inches) of the monitor station. This may cause
communication errors or malfunction.
Note:
LThis product has a fluorescent lamp that contains a small amount of mercury. It also
contains lead in some components. Disposal of these materials may be regulated in your
community due to environmental considerations. For disposal or recycling information
please contact your local authorities, or the Electronics Industries Alliance:
<http://www.eiae.org.>
20 cm
(8 inches)
20 cm
(8 inches)
20 cm
(8 inches)
20 cm
(8 inches)
GM201A.book Page 5 Monday, April 4, 2005 5:10 PM

6
Introduction and Installation
Included items
1234
567
No. Item Quantity Notes
1Monitor station 1 ------
2Mounting bracket 1 Attached to rear of the monitor station.
3Wood screws 2 For the monitor station.
(4 mm x 16 mm, 3/16" x 5/8")
4Power cable 1 ------
5AC adaptor 1 Enclosed in the AC adaptor case.
6Wood screws 2 For the AC adaptor case.
(4 mm x 16 mm, 3/16" x 5/8")
7Power cord 1 ------
GM201A.book Page 6 Monday, April 4, 2005 5:10 PM

7
Introduction and Installation
Optional item information
Available optional items
– Door station*1 (VL-GC001A, VL-GC002A)
– Desktop stand (VL-GT001A)
*1 The door station figures shown in this installation and operation guide are based on a VL-
GC001A.
Compatible PBXs
This unit is compatible with the following Panasonic PBXs*1:
– KX-TA308
– KX-TA624
– KX-TA824
– KX-TA1232
– KX-TAW848 (From Ver2.0)
– KX-TD308
– KX-TD816
– KX-TD1232
– KX-TDA50 (From Ver2.0)
– KX-TDA100 (From Ver2.01)
– KX-TDA200 (From Ver2.01)
*1 As of March, 2005. Consult your dealer for a current list of compatible PBXs.
GM201A.book Page 7 Monday, April 4, 2005 5:10 PM

8
Introduction and Installation
Location of controls
Front view Side view
Rear view
MONITOR
BRIGHT
DOOR
TALK
VOLUME
RINGER
VOLUME
RINGER
ANSWER
AUTO
PUSH
HOLD
HIGH
LOW
OFF
ANSWER
AUTO
PUSH
HOLD
HIGH
LOW
OFF
B
I
D
E
FJ
G
A
H
C
OFF
PBX MODE
ON
K
GM201A.book Page 8 Monday, April 4, 2005 5:10 PM

9
Introduction and Installation
AMicrophone
BDisplay
CMONITOR button
LAllows you to monitor the sound and camera image from the door station (page 26).
DBRIGHT button
LAllows you to adjust the display brightness. 5 levels are available.
EDOOR button
LAllows you to open the door (page 27).
FSpeaker
GTALK button
LTo answer a door call and/or speak to the visitor (page 23).
HTalk indicator
LLights while you are talking.
IRINGER VOLUME switch
LTo adjust the ringer volume. 3 levels (high/low/off) are available.
JANSWER switch
LTo change the answering mode (page 23).
KPBX MODE switch
LTo connect the unit to a PBX, turn on this switch (page 20).
GM201A.book Page 9 Monday, April 4, 2005 5:10 PM

10
Introduction and Installation
Before installation
To avoid a malfunction or communication disturbance, do not install the monitor station in the
following locations:
– Places where vibration or any other kind of impact occurs.
– Places where echoing is frequent.
– Places where a high concentration of dust, hydrogen sulfide, phosphorus, ammonia, sulfur,
carbon, acid, or noxious fumes occur.
– Within 2 m (6'7") of a TV, microwave, personal computer, air conditioner or any other
electrical device.
Standard installation position of the monitor station
Place the monitor station in a location so that your eyes are the same height as the center of
the display.
Note:
LIn areas surrounded by high electrical field, disturbance may occur in the monitor station’s
image or sound.
LBe sure to install the monitor station more than 5 m (16'5") away from the door station.
LDo not place any objects within 20 cm (8 inches) of the monitor station. This may cause
communication errors or malfunction.
LDo not install the monitor station inside a wall.
GM201A.book Page 10 Monday, April 4, 2005 5:10 PM
