Panasonic KX-TDA100AL User manual

ORDERNO. KMS0303678C3
HybridIP-PBX
KX-TDA100AL
(for Australia)
2003 PanasonicCommunicationsCo., Ltd. All rights reserved.
Unauthorizedcopying and distribution isaviolation oflaw.
IMPORTANTINFORMATION ABOUTLEAD FREE, (PbF), SOLDERING
Ifleadfree solderwas usedinthe manufacture of this productthe printedcircuitboards will be
markedPbF.
Standardleaded, (Pb), soldercanbe usedas usual on boards without the PbF mark.
Whenthis mark does appearplease readand followthe special instructions describedinthis
1

manual on the use of PbF and howitmight be permissible to use Pbsolderduring service and
repairwork.
1. ABOUTLEADFREE SOLDER(PbF:Pbfree)
Note:
Inthe information below, Pb, the symbol forleadinthe periodic table of elements, will referto
standardsolderorsolderthatcontains lead.
We will use PbF whendiscussing the leadfree solderusedinourmanufacturing process which
is made from Tin, (Sn), Silver, (Ag), and Copper, (Cu).
This model, and others like it, manufacturedusing leadfree solderwill have PbF stampedon
the PCB. Forservice and repairwork we suggestusing the same type of solderalthough, with
some precautions, standardPbsoldercanalsobe used.
Caution
-PbF solderhas amelting pointthat is50° ~70° F, (30° ~40°C)
higherthanPbsolder. Please use asoldering iron with
temperaturecontrol and adjust itto700° ±20° F, (370° ±10°C). In
case ofusing high temperaturesoldering iron, please becareful
nottoheat too long.
-PbF solderwill tend tosplashifitisheatedmuchhigherthanits
melting point, approximately1100°F, (600°C).
-Ifyou must use Pbsolderon aPCB manufacturedusing PbF
solder, removeas muchoftheoriginal PbF solderas possibleand
besurethat anyremaining ismeltedprior toapplying thePb
solder.
-Whenapplying PbF soldertodoublelayeredboards, please check
thecomponentsidefor excess whichmayflowontotheopposite
side(See figure, below).
1.1. SUGGESTEDPbF SOLDER
There are several types of PbF solderavailable commercially. While this productis
manufacturedusing Tin, Silver, and Copper,
(Sn+Ag+Cu), you canalsouse Tinand Copper, (Sn+Cu), orTin, Zinc, and Bismuth, (Sn+Zn+Bi).
2

Please check the manufac
turer’s specific instructions forthe melting points of theirproducts and anyprecautions for
using theirproductwith other
materials.
The following leadfree (PbF) solderwire sizes are recommendedforservice of this product:
0.3mm, 0.6mm and 1.0mm.
1.2. HOWTO RECOGNIZE THATPbFREE SOLDERIS USED
2. FORSERVICE TECHNICIANS
ICs and LSIs are vulnerable to static electricity.
Whenrepairing, the following precautions will helpprevent recurring malfunctions.
1. Covertheplasticparts boxes withaluminum foil.
2. Ground thesoldering irons.
3. Use aconductivemat on theworktable.
4. DonottouchICor LSI pinswithbarefingers.
3. CAUTION
3.1. NOTE
Whenyou note the serial number, write downall of the 11 digits.
The serial numbermaybe found on the label affixedto the bottom of the unit.
3.2. SAFETY PRECAUTIONS
1. Beforeservicing, unplug thepowercord topreventanelectric
shock.
2. Whenreplacing parts, use onlythemanufacturer's recommended
components for safety.
3. Check thecondition ofthepowercord. Replace ifwearor
3

damageisevident.
4. Afterservicing, besuretorestoretheleaddress, insulation
barriers, insulation papers, shields, etc.
5. Beforereturning theservicedequipmenttothecustomer, besure
toperform thefollowing insulation resistance test topreventthe
customerfrom being exposedtoshock hazards.
3.3. INSULATIONRESISTANCE TEST
1. Unplug thepowercord and shortthetwoprongsoftheplug with
ajumperwire.
2. Turn on thepowerswitch.
3. Measuretheresistance valuewithohmmeterbetweenthe
jumperedACplug and eachexposedmetal cabinet part, suchas
screwthreads, control shafts, handlebrackets, etc.
Note:
Some exposedparts maybe isolatedfrom the chassis bydesign. These will readinfinity.
4. Ifthemeasurementisoutsidethespecifiedlimits, thereisa
possibilityofshock hazard. Theequipmentshouldberepaired
and recheckedbeforeitisreturnedtothecustomer.
3.4. BATTERY CAUTION
4

1. Dangerofexplosion ifbatteryisincorrectlyreplaced. Replace
onlywiththesameor equivalenttyperecommendedbythe
manufacturer. Dispose ofusedbatteries according tothe
manufacturer’sInstructions.
2. Thelithium batteryisacritical component(typeNo.CR23541).
Please observefor theproperpolarityand theexact location
whenreplacing itand soldering thereplacementlithium batteryin.
3.5. CAUTION
The powersocketwall outletshouldbe locatednearthis equipment and be easilyaccessible.
4. SPECIFICATIONS
4.1. GENERALDESCRIPTION
Control Bus Original bus (16 bit, 8 MHz,10 megabytes persecond)
Communication Bus H.100 bus conformity(1024 time slot)
Switching Non Blocking DistributedTime Switch
PowerInput PSU-S
(KX-TDA0108) 100 VAC to 130 VAC/200 VAC to 240 VAC, 1.4 A/0.8 A,
50
PSU-M
(KX-TDA0104) 100 VAC to 130 VAC/200 VAC to 240 VAC, 2.5 A/1.4 A,
50
External Battery +36 VDC (+12 VDC x 3, batterycapacityof 28 Ahor
below
recommendedfor1 external battery)
Maximum PowerFailure Tolerance 300 ms (without using backup battery)
MemoryBackup Duration 7 years
Dialling Trunk Dial Pulse (DP)10 pps, 20 pps
Tone (DTMF) Dialling
Extension Dial Pulse (DP)10 pps, 20 pps
Tone (DTMF) Dialling
Mode Conversion DP-DTMF, DTMF-DP
Ring Frequency 20 Hz/25 Hz(selectable)
Trunk Loop Limit 1600 maximum
Operating
Environment Temperature 0 °C to 40 °C
Humidity 10%to 90%(non condensing)
Conference Call Trunk From 10 x 3-partyconference call to 4 x 8-party
conference
Music on Hold(MOH) 2 ports (Level Control:-6 dB to +6 dB in3 dB steps)
MOH1:External Music Source port
MOH2:Selectable Internal/External Music Source port
Paging Internal Level Control:-6 dB to +3 dB in3 dB steps
External 2 ports (Volume Control:-15 dB to +6 dB in3 dB steps)
5

Serial Interface Port RS-232C 1 (max 115.2 kbps)
USB 1
Extension Connection Cable SLT 1 pairwire (T, R)
DPT 1-pairwire (D1, D2)or
2-pairwire (T, R, D1,
D2)
APT 2-pairwire (T, R, D1,
D2)
DSS Consoles and Add-on Key
Module 1-pairwire (D1, D2)
Dimension KX-TDA100 334 mm (W)x 390 mm (H)x 270 mm (D)
(13 5/32 inx 15 11/32 inx 10 5/8 in)
Weight (whenfully
mounted) KX-TDA100 Under12 kg(26.5 lb)
4.2. CHARACTERISTICS
Terminal Equipment Loop Limit -PT:KX-T76xx series and KX-T7560/KX-T7565:90 ;all otherDPTs/APTs:40
-SLT:600 including set
-Doorphone:20
-CS:130
Minimum Leakage Resistance 15000 maximum
Maximum Numberof Extension
Instruments perLine 1 forPTorSLT 2 byParallel oreXtra Device Portconnection of a PTand
an
Ring Voltage 75 Vrms at20 Hz/25 Hzdepending on the Ringing Load
Trunk Loop Limit 1600 maximum
HookswitchFlash/Recall Timing
Range 24 ms to 2032 ms
BRI Cards Internal ISDN Mode SupplyVoltage:40 V
PowerSupply:4.5 Wper1 line,10 Wper4 lines (BRI4)
4.5 Wper1 line, 20 Wper4 lines (BRI8)
PowerSupplyMethod: Phantom PowerSupply
DoorOpenerCurrent Limit 24 VDC/30 VAC, 1 Amaximum
Paging Terminal Impedance 600
MOH (Music on Hold) Terminal
Impedance 10000
4.3. SYSTEMCAPACITY
4.3.1. MaximumTrunkand Extension Cards
The following numberof trunk and extension cards canbe installedinthe HybridIP-PBXfor
expansion.
6

CardType KX-TDA100
Trunk Card*1 4
Extension Card 4
Total 5
*1 One T1, E1, PRI30 and PRI23 cardcounts as 2 cards.
Note:
-For eachcard, amaximum numberthat canbeinstalledinthe
HybridIP-PBX islistedin"Installation Manual".
-Anycard that exceedsthecapacityoftheHybridIP-PBX will be
ignored.
-WhentheHybridIP-PBX starts up withaninvalidconfiguration
mode, somecardswill beignored.
4.3.2. MaximumTerminal Equipment
The following numberof terminal equipment canbe supportedbythe HybridIP-PBX.
Terminal Equipment Type KX-TDA100
Telephone *1 64
CS 16
PS 128
Voice Mail 2
Doorphone 8
DoorOpener 8
*1 WhenonlyT76xx series and T7560, T7565 DPTs and SLTs are connected. IfotherDPTs or
APTs are connected, the maximum numberwill decrease as eachof these units is countedas 4
sets of SLTs orDPTs (T76xx series and T7560, T7565).
4.3.3. Power SupplyUnitSelection
HybridIP-PBXneeds anoptional powersupplyunit(PSU)suitable forits configuration.
Calculate the amount of "loadfigures"from the type and numberof equipment to be connected,
and determine the type of PSU thatwill be required.
LoadFigure Calculation
7

Equipment Type Load
Figure
PT DPT(T76xx series and
T7560, T7565) 1
OtherDPT/APT/DSS Console 4
Extension Card*1 DHLC8 8
SLC8 8
SLC16 16
MSLC16 16
CS 4
ISDN Extension 2
Voice Mail 1
*1 Onlythe extension cards thatcansupportSLTs count forthe loadfigures.
PSU Capability
EachPSU supports a different amount of loadfigures.
PSU Type Maximum LoadFigures
PSU-S 64
PSU-M*2 128
*2 Available forthe KX-TDA100 and KX-TDA200.
5. SYSTEMOVERVIEW
5.1. SYSTEMCONFIGURATIONS
8

5.2. SYSTEMCOMPONENTS
9

Model CardName Description
Shelves KX-
TDA100AL Basic Shelf
MainProcessing
Card MPR MainProcessing Card
MPR Option Card KX-
TDA0196XJ RMT Remote Card
COLine Cards KX-
TDA0180AL
KX-
TDA0181AL
KX-
TDA0184AL
KX-
TDA0188XJ
KX-
TDA0189XJ
KX-
TDA0193XJ
KX-
TDA0284XJ
KX-
TDA0288XJ
KX-
TDA0290CJ
KX-
TDA0480X
LCO8
LCOT16
E&M8
E1
CID/PAY8
CID8
BRI4
BRI8
PRI30
IP-GW4
8-PortAnalogue Trunk Card
16-PortAnalogue Trunk Card
8-PortE&MTrunk Card
E-1 Trunk Card
8-PortCallerID/PayTone Card
8-PortCallerID Card
4-PortBRI Card
8-PortBRI Card
PRI Card
4-Channel VoIPGatewayCard
Extension Cards KX-
TDA0144XJ
KX-
TDA0170XJ
KX-
TDA0171XJ
KX-
TDA0172XJ
KX-
TDA0173XJ
KX-
TDA0174XJ
KX-
TDA0175XJ
CSIF8
DHLC8
DLC8
DLC16
SLC8
SLC16
MSLC16
8 Cell Station Interface Card
8-PortDigital HybridExtension Card
8-PortDigital Extension Card
16-PortDigital Extension Card
8-PortSingle Line Telephone Extension Card
16-PortSingle Line Telephone Extension Card
16-PortSingle Line Telephone Extension with
Message
Lamp Card
10

Model CardName Description
OtherCards KX-
TDA0161XJ
KX-
TDA0166XJ
KX-
TDA0190XJ
KX-
TDA0191XJ
KX-
TDA0410XJ
DHP4
ECHO16
OPB3
MSG4
CTI-LINK
4-PortDoorphone Card
16-Channel Echo CancellerCard
Optional 3-Slot Base Card
4-Channel Message Card
CTI Link Card
PowerSupply
Units (PSUs) KX- TDA0104XJ
KX-
TDA0108XJ
PSU-M
PSU-S M-Type PowerSupplyUnit S-Type PowerSupplyUnit
Cell Stations
(CS’s) KX- TDA0142CE 4-Channel Cell Station UnitforDECTPortable
Station
Proprietary
Equipment KX-A228XJ
KX-A229XJ S/M-type Back-up BatteryCable L-type Back-up BatteryCable
KX-A258XJ Blank Slot Cover
KX-T30865X Doorphone
Available Telephones
The HybridIP-PBXsupports all of the Panasonic X-T7xxx and KX-TD7xxx series:
-Digital/Analog proprietarytelephones (e.g., KX-T7625, KX-T7630,
KX-T7633, KX-T7636)
-Portablestations(e.g., KX-TD7590)
-DSS consoles (e.g., KX-T7640)
-Singlelinetelephones (e.g., KX-T7710)
The HybridIP-PBXdoes not supportthe following telephones:
-KX-T308xx series ProprietaryTelephones and DSS consoles
-KX-T616xx series ProprietaryTelephones and DSS consoles
-KX-T1232xx series ProprietaryTelephones and DSS consoles
-KX-T7500 Digital PortableStation
-KX-TD7500 DECTPortableStation
Forthe equipment (e.g., Add-on KeyModule, USB Module, Headset) thatcanbe connectedto a
particulartelephone, referto the telephone’s manual.
Abbreviations inthis manual
Proprietarytelephone:PT
Digital proprietarytelephone:DPT
Analog proprietarytelephone:APT
11

Portable station: PS
Single line telephone:SLT
Note:
-Therearesomeoptional service cardsand features that arenot
availablefor certaincountries/areas. Consultyour authorized
Panasonicdealerfor detailedinstructions.
-ThepowersupplycapacityoftheHybridIP-PBX maydifferfrom
thevalues describedinthismanual depending on themodel
number.Please consultyour dealerfor detailedinformation.
5.3. SYSTEMCONNECTIONDIAGRAM
12

13

*Only1 ServerPC canbe connectedto the HybridIP-PBX.Twoormore ServerPCs cannot be
usedsimultaneously.
6. NAME AND LOCATIONS
14

-Null slot:
Null slotisnotavailablefor anyoptional service card.
-RUN Indicator :
15

Showsthesystemnormallyworking bygreenlight.
-ALARM Indicator :
Showsthesystemdetectedsomeobstacles.
-RS-232C Port:
Theyworkas systemprograming/administration interface port,
SMDR information outputport, computertelephonyintegration
port.
Note:
-Linecapacityofthiscabinet isup to108 ports.
-These limitation oflinecapacityischeckedat installation ofslot
assignment.
-Linecapacityissum ofeachcard portnumberexceptDHLCcard.
Incase ofDHLCcard, theyareregardedas 8PITS ports and 8SLT
ports.
7. DISASSEMBLY INSTRUCTIONS
7.1. DISASSEMBLY INSTRUCTION(MPRCARD)
16

1. Remove the Libbysliding itinthe direction of the
arrow1.
2. This will be removedifthe userattaches the Pad
Lock as shownina Fig.1.
3. Loosenthe Screw.
4. Front Coveris removedinthe direction of an
arrow2.
17

5. Loosenthe twoScrews.
6. Remove the MPR Card.
7.2. DISASSEMBLY INSTRUCTION(BACK BOARD)
1. Remove fourScrews (A).
2. Remove the Left Side Coverand the Right Side
Cover.
18

3. Remove the Hook. And remove the Top Cover.
4. Remove nine Screws (B).
5. Remove the Back Cover.
19

6. Remove the RS-232C Connectorand LED
Connectorfrom the Back Board1.
7. Remove eight Screws (C).
8. Remove the Back Board1.
9. Remove the LED Connectorfrom the Back Board2.
10. Remove the Screw(C).
11. Remove the Back Board2.
8. OUTLINE
8.1. GENERALDESCRIPTION
The control systemof this unitis composedof the maincontrol section (MPR)controlling the
entire system, exchanging voice data, the circuitcontrol section (LPR)controlling various
telephone lines and the powersupplysection (POWER).
MPR, LPR and POWER are connectedeachotherthrough the SystemBUS(ADDRESS BUS,
DATABUSand CONTROL BUS). MPR LPR are underI/Ocontrol (I/ORead/Write)byMPR.
MPR controls LPR whichhas a microprocessorbythe lnter-MicroprocessorCommunication
SystemsupportedbyASIC. Thatis, MPR and LPR exchange controlling messages through bi-
directional bufferand CPU controls LPR sothatitcanmanage multiple telephone lines.
I/Oaddress forLPR access is fixedpereachfree slot. CPU discriminates the sortof LPR
20
