Panasonic ET-DLE030 User manual

ENGLISH
Model No. ET-DLE030
TQZJ548-1
Fixed-Focus Lens
Operating Instructions
Thank you for purchasing this Panasonic product.
■To ensure correct use of this lens, please read the operating instructions supplied with the lens and the
projector carefully.
■Before using this product, be sure to read “Read this rst!” (Page 3).
■Please save this manual for future use.
Product information (for Turkey only)
EEEYönetmeliğineUygundur.
EEE Complies with Directive of Turkey.
Commercial Use

2-ENGLISH
Read this rst! ......................................................................................3
Before Use.............................................................................................4
Attaching the Lens / Detaching the Lens...........................................4
Before replacing the projection lens........................................................4
Attaching the Lens...................................................................................5
Detaching the Lens .................................................................................5
Projection relationships.......................................................................6
Lens position setup and focus adjustment .......................................8
Lenspositionsetup(Usingprojectorfunctions) ......................................8
Lenspositionsetup(Usingthesuppliedlensshiftgauge) ......................9
Focus Adjustment Function.....................................................................9
Specications .....................................................................................10
Dimensions .........................................................................................10
Dimensional relationship...................................................... Appendix
█ Contents

ENGLISH-3
Read this rst! Always follow these precautions
WARNING:
Before replacing the projection lens, be sure to turn the power off and
disconnect the power plug from the wall outlet.
zUnexpectedprojectionoflightmaycauseinjurytoeyes.
zReplacing without removing the power plug may result in electrical shock.
Do not place objects near the light projecting surface.
zThissurfaceproducesintenselight.Failuretoheedthiswarningcouldresultinre
or burn injuries.
CAUTION:
Do not use the lens with the protective lm and lens cap left on.
zIf left on, the heat generated during projection could melt them resulting in projector
deformation and damage, and personnel attempting to remove them could suffer
burn injuries.
Do not open the desiccant bag. Do not eat the contents.
(Inadvertently ingesting desiccant could be harmful.)
zIf the desiccant gets into your eyes or mouth, immediately rinse with plenty of water
and seek medical attention.
zKeep desiccant out of the reach of children.
Information for users in the European Union
Importer’snameandaddresswithintheEuropeanUnion
Panasonic Marketing Europe GmbH
Panasonic Testing Center
Winsbergring 15, 22525 Hamburg, Germany

4-ENGLISH
Before replacing the projection lens
Return the projection lens to the home position before replacing or removing it.
For details on how to return the lens to the home position, refer to the operating instructions of the projector.
Attention
zMake sure that the projector power supply is switched off before attaching or detaching the projection lens.
zAfter removing the projection lens, store it safely away from vibration or impacts.
zDonottouchtheelectriccontactpointsoftheprojectionlenswithyourngers.Dustanddirtonthecontacts
may cause contact malfunctions.
zBeforeattachingtheFixed-focuslens,removetheprotectivelmfromthelightprojectingsurfaceandthelens
cap from the lens.
Lens surface Light
projecting
surface
Lens cap
Protectivelm
zBesurenottotouchthelightprojectingsurfaceorthesurfaceofthelens.Anyngerprintsorsmudgeson
thesesurfaceswillbemagniedandlowerthequalityoftheimagedisplayedonthescreen.
zThe light projecting surface and lens are made of glass. The lens could be damaged if brought into contact
with or rubbed against hard objects. Handle the lens carefully.
zUseaclean,softanddryclothtowipeawayanydirtordustthathasadheredtothelightprojectingsurfaceor
lens.Donotuseuffyclothscontainingoil,waterordustforcleaning.
zWhentheFixed-focuslensisremovedfromtheprojector,placeitwiththelightprojectingsurfacefacing
downwards.
Attaching the Lens / Detaching the Lens
Before Use
 Supported projectors
PT-DZ870 / PT-DW830 / PT-DX100 / PT-DZ770 / PT-DW740 / PT-DX810 / PT-DZ680 / PT-DW640 / PT-DX610 /
PT-DW730 / PT-DX800 / PT-DZ6710 / PT-DZ6700 / PT-DW6300 / PT-D6000 / PT-D5000
Note
zModels other than the above may also be supported. Refer to the operating instructions of the projector you are using.
zIn this document, the alphabet letters at the end of the projector part numbers are omitted.
 Supplied Accessories
Make sure that the following has been provided. Numbers enclosed in < > show the number of accessories.
Lens cap <1> Lens shift gauge <1>
■ 付属品
Make sure that the following has been provided. Numbers enclosed in < > show the number of accessories.
Lens cap <1> Lens shift gauge <1>
(The product is
delivered with a lens
capattached.)

ENGLISH-5
Guide groove Lens mount cover
Positioning guide
Fixed-focuslens
1) With the lens mount cover that
came with your projector attached,
align the positioning guide on the
lens with the guide groove on the
projector, and insert the lens fully.
zThere is a red dot at the bottom right end of the
positioning guide.
2) Rotate the lens clockwise until you
hear a “click”.
Attention
zGently turn the projection lens counterclockwise
to check that it will not fall out.
B
A
Lens mount cover
A
C
B
Lens release
button
1) Turn the lens mount cover
counterclockwise to detach it from
the lens and slide it towards the
front end of the lens.
2) Hold down the lens release
button while turning the lens
counterclockwise to release it.
3) Turn the lens mount cover
clockwise to reattach it.
Attention
zAttach the supplied lens cap before storing the lens.
Detaching the Lens
Attaching the Lens
Attaching the Lens / Detaching the Lens (continued)
*Unlessspeciedotherwise,theillustrationsintheseoperatinginstructionsshowthelensusedwiththe
PT-DZ870 projector.

6-ENGLISH
The dimensional relationship between the screen and the projector is shown below.
 Dimensional relationship diagram
SH
SW
SD
SH
A1
L3
L4
A2
L1
L2
Projected image
Screen
Note
zThe indications of this illustration are premised on aligning the projected image size and position to the full screen.
zThis illustration is not drawn to scale.
SH Projected image height L3 Screen to projector front end
SW Projected image width L4 Screen to projector rear end
SD Diagonal length of the projected image A1 Bottom edge of the screen to the top of the
projector
L1 Projection distance
(fromscreentomirrorreective surface*) A2 Bottom edge of the screen to the bottom of the
projector
L2 Screen to lens front end
*Themirrorreectivesurfaceisinsidethexed-focuslens,andisnotvisiblefromtheoutside.
Note
zTheillustrationsofprojectorsinthismanualareforinformationalpurposesonlyanddonotrepresentaspecic
projectormodel.Congurationsmayvarywiththemodel.
zDimension L4 is the distance from the projector rear panel to the screen.
zDimension A2 is the distance from the bottom edge of the screen to the bottom of the adjustable projector legs
(withthelegsfullyscrewedin).
Attention
zDimension L4 is not the distance from the projector rear panel to a wall, but the distance from the projector
rearpaneltothescreen.Provideatleast500mm(19-11/16")ofventilationspacebetweentheprojectorrear
panel and a wall or other object.
 Whenplacingtheprojectorinaconnedspace,aventilationand/orairconditioningsystemisrequired.
 Exhaustheatmayaccumulatewhentheventilationisnotsufcienttriggeringtheprotectioncircuitofthe
projector.
Projection relationships

ENGLISH-7
Projection relationships (continued)
α
Screen
(Sideview)
zWhen using one of PT-DW830 / PT-DX100 / PT-DZ770 / PT-DZ680 / PT-DZ6710 / PT-DZ6700 /
PT-DW740 / PT-DW730 / PT-DW640 / PT-DW6300 / PT-DX810 / PT-DX800 / PT-DX610 /
PT-D6000 / PT-D5000
If keystone distortion in vertical direction or horizontal direction is corrected, the projected image overall will no
longer be in focus. Set up the projector so that the projected image is rectangular and the back of the projector
and the screen are parallel.
zWhen using a projector other than one listed above
Please see "Setting up" in the operating instructions for the projector you are using.
 Dimensional relationship
zWhen using one of PT-DZ870 / PT-DW830 / PT-DX100 / PT-DZ770 / PT-DZ680 / PT-DZ6710 /
PT-DZ6700 / PT-DW740 / PT-DW730 / PT-DW640 / PT-DW6300 / PT-DX810 / PT-DX800 /
PT-DX610 / PT-D6000 / PT-D5000
Fordetailsonprojectiondistance(L1),andA1,A2,L2,L3andL4values,referto"Projectedimagesizeand
Projectiondistance"or"Projectiondistanceformulas"intheAppendix.
zWhen using a projector other than one listed above
Please see "Setting up" in the operating instructions for the projector you are using.
 Keystone distortion correction
When attaching this lens for use, regardless of the projector model, set up the projector so that the projected
image is rectangular and the back of the projector and the screen are parallel.
In addition, depending on the projector used, keystone distortion correction may be feasible after setup.
zWhen using PT-DZ870
Forkeystonedistortionintheverticaldirectiongeneratedwithintheanglerangebelow,select[MAINMENU]→
[POSITION]→[GEOMETRY(2D)]→[KEYSTONE]→[VERTICALKEYSTONE]toperformcorrection.
Keystone distortion in the vertical direction greater than this angle and keystone distortion in the horizontal
direction can be corrected but the projected image overall will no longer be in focus.
Correctionfeasibleangle(α):0-5°

8-ENGLISH
Lens position setup (Using projector functions)
Automatically return the lens to base position using the projector.
*Themenuscreensshownintheseoperatinginstructionsareonlyprovidedasexamples.Actualmenuscreens
mayvarywiththespecicmodel.
Lens position setup and focus adjustment
1) Turn on the projector to start the
projection.
2) Press the <MENU> button to open
the [MAIN MENU] screen. Then
select [PROJECTOR SETUP] and
press the <ENTER> button.
3) Select [SERVICE PASSWORD] in
the [PROJECTOR SETUP] menu
and press the <ENTER> button.
4) In the [SERVICE PASSWORD]
entry screen, press the numeric
button <0> and <3> on the remote
control to enter "030" and press
the <ENTER> button.
zThe[DLE030POSITION]screenappears.
5) Press the <ENTER> button in the
[DLE030 POSITION] screen.
z[PROGRESS]isdisplayedonthe[DLE030
POSITION]screenandlenspositionmoves
to the standard projection position for the ET-
DLE030.
Note
zThis method of adjustment does not work with the PT-DZ770, PT-DW740, PT-DX810, PT-DZ680, PT-DW640,
PT-DX610,PT-DW730,PT-DX800,PT-DZ6710,PT-DZ6700,PT-DW6300,PT-D6000andPT-D5000.Usethe
supplied lens shift gauge for adjustments.
zLens position adjustments made from the projector may deviate slightly from adjustments made using the lens
shift gauge.
zAfter returning the lens to the standard projection position, lens shift adjustments are possible within the range
where the projector will not interfere with the edges of the projected image.
zIf the rear of the projector blocks the bottom edge of the projected image, it may also obscure the view of an
On-screendisplay(OSD)thatispositionedattheloweredgeofthescreen.Ifthishappens,openthe[DISPLAY
OPTIONS]menuandselect[ON-SCREENDISPLAY]→[OSDPOSITION]tochangedisplaylocationsothat
the whole OSD menu can be seen.
LAST USED
SW1234567
ET-LAD120
DISABLE
DEFAULT
1.00
1.00
ACTIVATED
2/2
PROJECTOR SETUP
STARTUP INPUT SELECT
RS-232C
STATUS
NO SIGNAL SHUT-OFF
REMOTE2 MODE
FUNCTION BUTTON
DATE AND TIME
LENS CALIBRATION
SAVE ALL USER DATA
LOAD ALL USER DATA
INITIALIZE
SERVICE PASSWORD
LENS
DLE030 POSITION
OK
CANCEL
MENU
ENTER
MAIN MENU
POSITION
ADVANCED MENU
DISPLAY LANGUAGE
DISPLAY OPTION
3D SETTINGS
PROJECTOR SETUP
TEST PATTERN
SIGNAL LIST
SECURITY
NETWORK
MENU SELECT
SUB MENU
P IN P
ENTER

ENGLISH-9
Lens position setup (Using the supplied lens shift gauge)
Usethesuppliedlensshiftgaugetoadjustverticallensposition.
* This illustration shows the lens used with the PT-DZ770 projector.
1) As shown in the gure, fold the
lens shift gauge at right angles
along the dotted line.
zAdjust so that the gauge plane of the lens shift
gauge and the front panel of the projector are
roughly in the same plane.
2) Move the lens to the home position.
zFor details on how to return the lens to the
home position, refer to the operating instructions
of the projector.
3) Adjust lens shift on the projector
so that the bottom edge of the
projected image aligns with the
line for the specic projector
model on the lens shift gauge.
zUsetheprojectoraftermakingtheadjustments
and lens position settings described here.
Lens shift gauge
Bottom edge of
projected image
Projected light
Focus Adjustment Function
After setting the lens position, adjust the focus.
The focal balance between the center and periphery of the projected image changes depending on the size of the
projectedimage.Thelensisequippedwithafocusbalanceadjustmentfunctionforthescreenperiphery.
 Adjusting the Focus
Periphery focus adjustment ring
1) Focus the center of the screen by
operating the projector unit.
2) Turn the periphery focus ring by
hand as shown in the gure to
adjust the focus in the periphery
of the screen.
3) Again check focus at the center of
the screen and use the projector
controls to make ne adjustments.
Note
zTheprojectedimagesizesandscaleshownontheperipheryfocusadjustmentringareanapproximateguide.
Note
zAfter adjusting the lens position using the lens shift gauge, lens shift adjustments are possible within the range
where the projector will not interfere with the edges of the projected image.
Lens position setup and focus adjustment (continued)

10-ENGLISH
Dimensions
132 (5-3/16")
102 (4-1/32")
311 (12-1/4")
(Unit:mm)
Specications
F value 2.0
FocalLength(f) 5.3mm(7/32")
Dimensions
Width
Height
Depth
132mm(5-3/16")
102mm(4-1/32")
311mm(12-1/4")
Net Weight Approx.1.3k](2.9lb)
