Advanced Hybrid System
KX-TA624-4
Manual Addendum
for the
Caller ID Feature
This Manual Addendum provides the additional information on Caller ID for the Panasonic
Advanced Hybrid System, KX-TA624.

2
[913] Caller ID Call Waiting Assignment
Description
Enables or disables the Caller ID Call Waiting feature for outside (CO) lines which have
contracted Caller ID Service with a Central Office.
Selection
• Outside (CO) line number: 1 –6,( = all outside (CO) lines)
•Enable / Disable
Default
All outside (CO) lines — Enable
Programming
1. Enter 913.
Display: C.W CID Assign
2. Press NEXT.
Display: CO NO?
3. Enter an outside (CO) line number.
Pressing NEXT also can enter outside (CO) line number 1.
Display example: CO 1:Enable
4. Keep pressing SELECT until the desired selection is displayed.
5. Press STORE.
6. To program another outside (CO) line, press NEXT or PREV, or SELECT and enter
the desired outside (CO) line number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions
• To assign alloutside(CO) lines to thesame selection, press the keyin step 3. In this case,
the display will show: CO :Mixed.
• When “Disable” is assigned in program [900] “Caller ID Assignment”, the Caller ID Call
Waiting feature does not perform even if “Enable” is assigned in this program.
Feature References — in the Installation Manual
Caller ID Call Waiting
System Programming

3
[914] Caller ID Call Waiting CAS Receive Time
Description
The telephone company calls the system "Customer Premise Equipment (CPE)". If you have
a Caller ID Call Waiting during a conversation, the telephone company will send to the CPE a
CAS (CPE Alerting Signal). If the CAS duration is too long or too short, the CAS is ignored.
If the CAS is accepted, then the system will respond and the Caller ID Call Waiting feature will
be performed.
This program assigns the allowable CAS duration. Normally, it should not be necessary to
change the default setting.
Selection
•Mode 1 (40 ms through 120 ms) / Mode 2 (64 ms through 96 ms) /
Mode 3 (72 ms through 96 ms)
Default
Mode 3
Programming
1. Enter 914.
Display: C.W CID Receive
2. Press NEXT.
Display example: Mode 3
3. Keep pressing SELECT until the desired selection is displayed.
4. Press STORE.
5. Press END.
Conditions
• This program is available when “Enable” is assigned in programs [900] “Caller ID
Assignment” and [913] “Caller ID Call Waiting Assignment”.
Feature References — in the Installation Manual
Caller ID Call Waiting
System Programming

[915] Caller ID Checksum
Description
Enables or disables to select the checksum mode. Normally, it should not be necessary to
change the default setting.
For further details on the checksum, consult your dealer.
Selection
•Enable / Disable
Default
Enable
Programming
1. Enter 915.
Display: CID Check Sum
2. Press NEXT.
Display example: Enable
3. Keep pressing SELECT until the desired selection is displayed.
4. Press STORE.
5. Press END.
Conditions
None
Feature References — in the Installation Manual
Caller ID
Caller ID Call Waiting
System Programming
