Parkside PDSLG 12 A1 User manual

DOUBLE BATTERY CHARGER / DOPPEL-LADEGERÄT
CHARGEUR DOUBLE PDSLG 12 A1
IAN 351902_2007
CHARGEUR DOUBLE
Traduction des instructions d’origine
DOPPEL-LADEGERÄT
Originalbetriebsanleitung
DOUBLE BATTERY CHARGER
Translation of the original instructions
DVOJITÁ NABÍJEČKA
Překlad originálního provozního návodu
DUBBELE OPLADER
Vertaling van de originele gebruiksaanwijzing
DVOJITÁ NABÍJAČKA
Preklad originálneho návodu na obsluhu
PODWÓJNA ŁADOWARKA
Tłumaczenie oryginalnej instrukcji obsługi
CARGADOR DOBLE
Traducción del manual de instrucciones original
DOBBELT OPLADER
Oversættelse af den originale driftsvejledning

GB Translation of the original instructions Page 1
DE Originalbetriebsanleitung Seite 15
FR Traduction des instructions d’origine Page 29
NL Vertaling van de originele gebruiksaanwijzing Pagina 49
CZ Překlad originálního provozního návodu Strana 63
PL Tłumaczenie oryginalnej instrukcji obsługi Strona 77
SK Preklad originálneho návodu na obsluhu Strana 93
ES Traducción del manual de instrucciones original Página 107
DK Oversættelse af den originale driftsvejledning Side 121

Ladezeiten
Charging times
Temps de
charge
Ladeströme
Charging
currents
Courants
de charge
2 Ah
Batterie
Battery pack
Batterie
PAPK 12 A1
2 Ah
Batterie
Battery pack
Batterie
PAPK 12 A2/
A3
4 Ah
Batterie
Battery pack
Batterie
PAPK 12 B1
max. 2,4 A
Ladegerät
Charger
Chargeur
PLGK 12 A1/A2
60 min
2,4 A
60 min
2,4 A
120 min
2,4 A
max. 4,5 A
Ladegerät
Charger
Chargeur
PLGK 12 B2
60 min
2,4 A
45 min
3,5 A
60 min
4,5 A
max. 4,5 A
Ladegerät
Charger
Chargeur
PDSLG 12 A1
60 min
2,4 A
45 min
3,5 A
60 min
4,5 A

Alle Parkside Geräte und die Ladegeräte
PLGK12A1/A2/B2/PDSLG 12 A1
der X12V Team Serie sind mit dem Akku-Pack
PAPK12A1/A2/A3/B1 kompatibel.
All Parkside tools and the chargers PLGK12A1/A2/
B2/PDSLG 12 A1 of the
X12V Team series are compatible with the
PAPK12A1/A2/A3/B1 battery pack.
Tous les outils Parkside et les chargeurs PLGK12A1/
A2/B2/PDSLG 12 A1
de la série X12V Team sont compatibles avec la bat-
terie PAPK12A1/A2/A3/B1.
12V max.
10,8V

PDSLG 12 A1 GB│IE │ 1 ■
Contents
Introduction........................................ 2
Intended use.................................................2
Features ....................................................2
Package contents .............................................3
Technical data ...............................................3
General safety instructions ........................... 4
Use and handling of the cordless electrical power tool ................4
Extended safety guidelines......................................5
Safety guidelines for battery chargers .............................6
Before use ......................................... 7
Charging the battery pack ......................................7
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Maintenance and storage ............................ 8
Kompernass Handels GmbH warranty ................. 8
Service ...........................................11
Importer .........................................11
Disposal..........................................12
Notes on the EC Declaration of Conformity .............13
Ordering a replacement battery......................14
Telephone ordering ......................................... 14

PDSLG 12 A1■ 2 │ GB│IE
Introduction
Congratulations on the purchase of your new appliance. You have chosen a
high-quality product. The operating instructions are part of this product. They
contain important information about safety, usage and disposal. Before using
the product, please familiarise yourself with all the operating and safety
instructions. Use the product only as described and for the range of applica-
tions specified. Please also pass these operating instructions on to any future
owner.
Intended use
This charger is designed exclusively for charging PARKSIDE PAPK 12 A1/
A2/A3/B1 series batteries. This rechargeable battery is suitable for:
This appliance is not intended for commercial applications. Any other usage
or modification of the appliance is deemed to be improper and carries a
significant risk of accidents. The manufacturer accepts no responsibility for
damage attributable to misuse.
Features
Red charge control LED
Green charge control LED
Dual high-speed charger

PDSLG 12 A1 GB│IE │ 3 ■
Package contents
1 double battery charger
1 set of operating instructions
Technical data
Dual high-speed charger PDSLG 12 A1
INPUT
Rated voltage 220–240 V ∼ (AC), 50–60 Hz
Rated power consumption 150 W
Fuse (internal) 3.15 A
T3.15A
OUTPUT 1
Rated voltage 12 V (DC)
Rated current 4.5 A
Charging time see table on fold-out page
Protection class II/ (double insulation)
OUTPUT 2
Rated voltage 12 V (DC)
Rated current 4.5 A
Charging time see table on fold-out page
Protection class II/ (double insulation)

PDSLG 12 A1■ 4 │ GB│IE
General safety instructions
WARNING!
■Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for future reference.
Use and handling of the cordless electrical power tool
a) Charge a rechargeable battery unit using only the charger recom-
mended by the manufacturer. Chargers are often designed for a particular
type of rechargeable battery unit. There is the danger of fire if other types
of rechargeable battery units are used.
b) Only the rechargeable battery units supplied are to be used with an
electrical power tool. The use of other rechargeable battery units may
lead to the danger of injury or fire.
c) When they are not being used, store rechargeable battery units away
from paperclips, coins, keys, nails, screws or other small metal objects
that could cause the contacts to be bridged. Short-circuiting the contacts
of a rechargeable battery unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable battery units if they are misused.
If this happens, avoid contact with the fluid. If contact occurs, flush the
affected area with water. Seek additional medical help if any of the
fluid gets into your eyes. Escaping battery fluid may cause skin irritation
or burns.

PDSLG 12 A1 GB│IE │ 5 ■
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable batteries.
Protect the rechargeable battery from heat;
for example, from continuous exposure to sunlight, fire, water and
moisture. There is a risk of explosion.
Extended safety guidelines
■Do not use a damaged or modified battery. Damaged or modified
batteries may behave unexpectedly and cause fires, explosions or pose
arisk of injury.
■Do not expose a battery to fire or excessively high temperatures. Fire
or temperatures in excess of 130°C (265°F) can cause an explosion.
■Follow all instructions regarding charging and never charge the
battery or the cordless tool outside the temperature range given in the
operating instructions.
Incorrect charging or charging outside of the permissible temperature
range can destroy the battery and increase the risk of fire.
WARNING!
■ Do not use any accessories that are not recommended by PARKSIDE.
Unsuitable accessories can lead to a risk of electric shock or fire.

PDSLG 12 A1■ 6 │ GB│IE
Safety guidelines for battery chargers
■ This appliance may be used by children aged 8 years
and above and by persons with limited physical, sensory
or mental capabilities or lack of experience and knowl-
edge, provided that they are under supervision or have
been told how to use the appliance safely and are
aware of the potential risks. Do not allow children to
use the appliance as a toy. Cleaning and user mainte-
nance tasks may not be carried out by children unless
they are supervised.
■ To avoid potential risks, damaged mains cables should
be replaced by the manufacturer, their customer service
department or a similarly qualified person.
The charger is suitable for indoor use only.
WARNING!
■ To avoid potential risks, damaged mains cables should be replaced
by the manufacturer, their customer service department or a similarly
qualified person.
ATTENTION!
♦ This charger can only charge the following
batteries:
PAPK12A1/PAPK 12 A2/PAPK 12 A3/ PAPK 12 B1.
♦ A current list of battery compatibility can be found at
www.lidl.de/Akku.

PDSLG 12 A1 GB│IE │ 7 ■
Before use
Charging the battery pack
CAUTION!
► Always unplug the appliance before you remove the battery pack from
or connect the battery pack to the charger.
NOTE
► Never charge the battery pack if the ambient temperature is below
10°C or above 40°C. If a lithium-ion battery is to be stored for an
extended period, the charge level should be checked regularly. The
optimum charge level is between 50% and 80%. The storage climate
should be cool and dry and the ambient temperature should be
between 0°C and 50°C.
♦ Insert one or two battery packs into the dual high-speed charger .
♦ Plug the mains plug into the mains power socket. The respective charge
control LED lights up red.
♦ The respective green charge control LED indicates that charging is
complete and the battery pack is ready for use.
♦ You should always switch the dual high-speed charger off for at least
15 minutes between successive charging processes. Also disconnect the
power plug from the mains power socket.
Cleaning
CAUTION!
► Always unplug the charger before cleaning it.
► Do not clean the charger with water.
■ Clean the appliance with a dry or slightly moistened cloth.

PDSLG 12 A1■ 8 │ GB│IE
Maintenance and storage
■ If you do not intend to use the appliance for an extended period, remove
the batteries and store it in a clean, dry place away from direct sunlight.
■ If a lithium-ion battery is going to be put into storage for an extended
period, the charge level should be checked at regular intervals. The
optimum charge level is between 50% and 80%. The optimum storage
environment is cool and dry.
■Never try to repair damaged batteries.
Batteries should only be maintained by the manufacturer or an approved
customer service centre.
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase. If this
product has any faults, you, the buyer, have certain statutory rights. Your statu-
tory rights are not restricted in any way by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your receipt
in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the date of
purchase of the product, we will either repair or replace the product for you
or refund the purchase price (at our discretion). This warranty service requires
that you present the defective appliance and the proof of purchase (receipt)
within the three-year warranty period, along with a brief written description
of the fault and of when it occurred.
If the defect is covered by the warranty, your product will either be repaired
or replaced by us. The repair or replacement of a product does not signify the
beginning of a new warranty period.
X 12 V and X 20 V Team Series battery packs come with a 3-year warranty
valid from the date of purchase.

PDSLG 12 A1 GB│IE │ 9 ■
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty.
This also applies to replaced and repaired components. Any damage and
defects present at the time of purchase must be reported immediately after
unpacking. Repairs carried out after expiry of the warranty period shall be
subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality
guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does
not extend to product parts subject to normal wear and tear or to fragile parts
which could be considered as consumable parts such as switches or parts
made of glass.
The warranty does not apply if the product has been damaged, improperly
used or improperly maintained. The directions in the operating instructions for
the product regarding proper use of the product are to be strictly followed.
Uses and actions that are discouraged in the operating instructions or which
are warned against must be avoided.
This product is intended solely for private use and not for commercial
purposes. The warranty shall be deemed void in cases of misuse or improper
handling, use of force and modifications/repairs which have not been
carried out by one of our authorised Service centres.
The warranty period does not apply to
■ Normal reduction of the battery capacity overtime
■ Commercial use of the product
■ Damage to or alteration of the product by the customer
■ Non-compliance with safety and maintenance instructions, operating
errors
■ Damage caused by natural hazards

PDSLG 12 A1■ 10 │ GB│IE
Warranty claim procedure
To ensure quick processing of your case, please observe the following
instructions:
■ Please have the till receipt and the item number (e.g.IAN12345) available
as proof of purchase.
■ You will find the item number on the type plate on the product, an
engraving on the product, on the front page of the operating instructions
(below left) or on the sticker on the rear or bottom of the product.
■ If functional or other defects occur, please contact the service department
listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service
address that will be provided to you. Ensure that you enclose the proof of
purchase (till receipt) and information about what the defect is and when
it occurred.
You can download these instructions along with many
other manuals, product videos and installation software
at www.lidl-service.com.
This QR code will take you directly to the Lidl service page
(www.lidl-service.com) where you can open your operating instructions
by entering the item number (IAN) 351902_2007.

PDSLG 12 A1 GB│IE │ 11 ■
WARNING!
►Have your appliances repaired by the Service Centre or a trained
electrician, and use only original spare parts. This will ensure that the
safety of the appliance is maintained.
►Always ensure that the power plug or the mains cable is replaced
only by the manufacturer of the appliance or by an approved
customer service provider. This will ensure that the safety of the appli-
ance is maintained.
Service
Service Great Britain
Tel.: [phone]
E-Mail: kom[email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kom[email protected]
IAN 351902_2007
Importer
Please note that the following address is not the service address.
Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

PDSLG 12 A1■ 12 │ GB│IE
Disposal
The packaging protects the appliance from damage during
transport. The packaging materials have been selected for their
environmental friendliness and disposal attributes, and are
therefore recyclable.
Returning the packaging to the material cycle conserves raw materials
and reduces the amount of waste that is generated. Dispose of packaging
materials that are no longer needed in accordance with applicable local
regulations.
Do not dispose of power tools in your normal domestic
waste!
European Directive 2012/19/EU requires that worn-out power
tools be collected separately and recycled in an environmentally
compatible manner.
Do not dispose of batteries in your normal household
waste!
Defective or worn-out rechargeable batteries must be recycled
according to Directive 2006/66/EC. Take the battery pack and/
or tool to a nearby collection facility.
Please consult your local authorities regarding suitable disposal of worn-out
power tools/battery packs.
Dispose of the packaging in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging
material components for disposal if necessary. The packaging
material is labelled with abbreviations (a) and numbers (b) with
the following meanings: 1–7: plastics, 20–22: paper and cardboard,
80–98: composites.

PDSLG 12 A1 GB│IE │ 13 ■
Your local community or municipal authorities can provide
information on how to dispose of the worn-out product.
The product is recyclable, subject to extended producer
responsibility and is collected separately.
Notes on the EC Declaration of Conformity
This appliance complies with the basic requirements and other relevant
provisions of the Electromagnetic Compatibility Directive 2014/30/EU
and the Low-Voltage Directive 2014/35/EU.
The complete original Declaration of Conformity is available from the
importer.
RoHS Directive (2011/65/EU)*
* The manufacturer bears the full responsibility for compliance with this conformity
declaration. The object of the declaration described above complies with the require-
ments of the Directive 2011/65/EU of the European Parliament and Council of
8June 2011 on the limitations of use of certain dangerous substances in electrical
and electronic appliances.

PDSLG 12 A1■ 14 │ GB│IE
Ordering a replacement battery
If you want to order a replacement battery for your
appliance, you can do so easily via the Internet on
www.kompernass.com or by telephone.
Due to limited stocks, this item may sell out in a
relatively short time.
NOTE
► Online ordering of replacement parts might not be possible in some
countries. If this is the case, please contact the Service hotline.
Telephone ordering
Service Great Britain Tel.: [phone]
Service Ireland Tel.: [phone]
0,08 EUR/Min., peak · 0,06 EUR/Min., off peak
To ensure fast processing of your order, have the article number of your
appliance to hand (e.g. IAN 351902) in case of questions. The article
number can be found on the type plate or the title page of these instructions.

PDSLG 12 A1 DE│AT│CH │ 15 ■
Inhaltsverzeichnis
Einleitung.........................................16
Bestimmungsgemäßer Gebrauch ............................... 16
Ausstattung................................................ 16
Lieferumfang............................................... 17
Technische Daten ........................................... 17
Allgemeine Sicherheitshinweise ...................... 18
Verwendung und Behandlung des Akkuwerkzeugs ................. 18
Erweiterte Sicherheitshinweise ................................. 19
Sicherheitshinweise für Ladegeräte ............................. 20
Vor der Inbetriebnahme ............................21
Akku-Pack laden ............................................ 21
Reinigung ........................................21
Wartung und Lagerung ............................. 22
Garantie der Kompernaß Handels GmbH ..............22
Service ...........................................25
Importeur ........................................25
Entsorgung .......................................26
Hinweise zur EG-Konformitätserklärung ............... 27
Ersatz-Akku Bestellung ............................. 28
Telefonische Bestellung....................................... 28
