Parrot CK3100 LCD User manual

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
GOLF 6
Schéma d’installation :
Gamme Parrot MKi +
Parrot CK3100
The VOLKSWAGEN GOLF marque and VOLKSWAGEN logo are the property of the VOLKSWAGEN France Group s.a or VOLKSWAGEN AG.
This document is only valid for the vehicle model GOLF® 6 year 2008 –2012, excluding all other models in the same range and excluding later
modifications made to the vehicle by the manufacturer.
The Parrot brand name and logos are the exclusive property of Parrot SA.

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Disassembly
30 min
Kit installation
30 min
Refitting
30 min
Testing
15 min
Total
1 hour 45 minutes
NO
ACC wire
NO
ISO
YES
UNIKA
FRONT SPEAKER
TEL mode
ALL
MUSIC mode
Fitting time / Main features
Tools
-TORX screwdriver
- Cutting pliers
- Crimping pliers
- Multimeter or Test lamp
- Pull through cord
- Electrical/amalgamation tape
- Soldering Iron
Plastic Trim Removal tools
FACOM / BOJO
Accessories required
Updating
Kram ref.
Dealer ref.
CK range
86 200
YY 138 CABL 1
MKi range
84 942
YY 138 CABL 2
Photos for illustration purposes
CK range MKi range
To get the most out of your hands-free kit we recommend that you update your
software regularly. The update procedure can be found at
www.parrot.com/usa/support/downloads
“Quick Connect harness references available at
http://certified.parrot.com/faisceaux_US.php"

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Disassembly

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
5 6
Using the plastic trim tools,
unclip the car stereo and air
conditioning surround.
Unplug the connector for the
airbag warning light.
1 2
3
4
4
5
1
3
2
4
Disassembly 1 / 3
Release the panel by inserting the
plastic trim tools underneath. Remove screws 1 and 2.
Unclip the cabin light and
disconnect it.
Using the plastic trim tools,
unclip the vanity light from the
left-hand side.
Remove screws 3, 4, 5 and 6
around the car stereo.
Disconnect the connector and
the aerial cables.

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
7
9
8
10
11 12
7 8
109
Disassembly 2 / 3
Remove screws 7, 8, 9 and 10
around the air conditioning
control unit, then remove it
without disconnecting it.
Open the storage compartment
under the steering wheel.
Press down on the tabs inside to
release the box. Pull up to unclip it.
Using the plastic trim tools,
unclip the side panel of the
dashboard on the driver's side.
Unclip the cover plate running
up on the side of the door.

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Démontage 3 / 3
13
9 10
Remove the ‘A’ Pillar trim.

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Using the pull-through cord,
thread a blue wire under the
steering wheel and towards the
the air conditioning control unit.
Feed the wire to the left into the
fuse box housing.
Attach a 1.5-mm lug and insert it
into one of the slots at the top of
the fuse box. (Using the
multimeter, check that the +12 v is
connected to the ignition.)
1
3
2
Finding an ACC wire
Route the 12volt ignition supply
to the adaptor loom which links
to the Parrot fused (orange)
ignition wire, Solder and heat
shrink. Note this wire should not
be linked to the vehicle stereo.

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
4
5 6
1
3
2
Microphone feeding 1 / 2
Using a guide, feed the cable from
the windscreen to the cabin light.
Using a guide, feed the cable
from the cabin light to the vanity
light.
Using a guide, feed the cable
from the vanity light to the
driver's side door.
Pass the cable through the fuse
box.
After cleaning the centre of the panel
where the rain sensor is connected,
attach the cradle supplied.
Slide the cable along the driver's
side door whilst re-fitting the
door seal.

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Passage micro 2 / 2
7
Using a guide, feed the cable under
the steering wheel towards the car
stereo housing.

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Passage du câble accessoire
1 2
Using a guide, feed the cable in
the top part of the glove
compartment through to the air
conditioning control unit housing.
Make sure that the cable is long
enough.

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Montage du système mains-libres 1 / 2
1
Connect the adaptor to the original connector.
Connect all of the wires to the blue box as
shown in the diagram below. Test the assembly
before completing fitting and then slide
everything behind the air conditioning control
unit.
Direct adaptor cable

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Montage du système mains-libres 2 / 2
Feed the cable up along the side
of the car stereo, behind the
clip’s.
WARNING: Be careful not to cut
the wire at the clips during
reassembly.
Glue on the (included) joint,
after cleaning the left-hand side
of the car stereo surround.
2
4
3
12
!

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Test
Before refitting the system, switch the kit on using the
ignition (or by starting the car). By pushing the central knob
of the remote control, check:
1 - That the menu is displayed on the screen. (Language or
iPod etc.)
2 - That the radio system is muted when the kit is in use.
3 - That there is sound through all speakers for music.
4 - That there is sound through the front speakers for spoken
menus and handsfree calls.
5 - Pair a telephone with the kit and make a call. (Check that
both the microphone and the kit are working.)
6 - Then turn off the ignition, check that the kit switches off
and that the "goodbye" message appears on the screen. (If
this fails, reverse the fuses on the kit's wiring harness)

GOLF VI
This sheet is designed to help you with the installation of a Parrot product and is purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without the
authorisation of Parrot SA. Pictures for information only.
Remontage
Faire le montage inverse en respectant l'ordre suivant:
1 –Re-fit the panel next to the dashboard.
2 –Re-fit the panel on the left-hand side of the dashboard.
3 –Re-fit the storage compartment under the steering wheel.
4 –Re-connect and refit the cabin light. (screws 1 and 2.)
5 –Re-fit the cabin light panel.
6 –Re-fit the vanity light.
7 –Re-fit the 4 screws (7, 8, 9 and 10) for the air conditioning control unit.
8 - Put the air condition control unit panel back in to place.
9 –Re-connect the adaptor and the aerials behind the car stereo and slip them
inside the housing. (Make sure that you do not trap and cut any screen wires.)
10 –Re-fit the 4 screws (3, 4, 5 and 6) for the car stereo.
11 - Put the stereo surround back into place.
12 –Re-test to check that the system is working correctly.
