Patton electronics 537 User manual

USER

MANUAL

MODEL 537

Token Ring Surge Protector

SALES OFFICE

(301) 975-1000

TECHNICAL SUPPORT

(301) 975-1007

http://www.patton.com

Part# 07M537-A

Doc# 074180U,

Rev. B

Revised 1/22/08

CERTIFIED

An ISO-9001

Certified Company

1.0 WARRANTY

Patton Electronics warrants all Model 537 components to be free

from defects, and will—at our option—repair or replace the product

should it fail within one year from the first date of shipment. This

warranty is limited to defects in workmanship or materials, and does not

cover customer damage, abuse or unauthorized modification. If this

product fails or does not perform as warranted, your sole recourse shall

be repair or replacement as described above. Under no condition shall

Patton Electronics be liable for any damages incurred by the use of

this product. These damages include, but are not limited to, the

following: lost profits, lost savings and incidental or consequential

damages arising from the use of or inability to use this product. Patton

Electronics specifically disclaims all other warranties, expressed or

implied, and the installation or use of this product shall be deemed an

acceptance of these terms by the user.

1.2 SERVICE

All warranty and nonwarranty repairs must be returned freight

prepaid and insured to Patton Electronics. All returns must have a

Return Materials Authorization number on the outside of the shipping

container. This number may be obtained from Patton Electronics

Technical Support: (301) 975-1007; http://www.patton.com; or,

[email protected].

Notice: Packages received without an RMA number will not be

accepted.

Patton Electronics' technical staff is also available to answer any

questions that might arise concerning the installation or use of your

Patton Model 537 Surge Protector. Technical Service hours: 8AM to

5PM EST, Monday through Friday.

1.3 CE NOTICE

The CE symbol on your Patton Electronics equipment indicates

that it is in compliance with the Electromagnetic Compatibility (EMC)

directive and the Low Voltage Directive (LVD) of the Union European

(EU). A Certificate of Compliance is available by contacting Technical

Support.

APPENDIX A

PATTON MODEL 537 SPECIFICATIONS

Surge Capacity: 1500 Watts for 1msec

400A with a 8/20μS pulse

Connectors: Two IBM data style connectors

Lines Protected: All four on the IBM data connector

Compliance: CE marked for EMC directive 89\336\EEC

(ESD.EFT)

Clamping Voltage: 9.0 Volts in 500nsec

Protection Mode: All lines common mode to connector shield.

All lines differential.

Patton Electronics Company

5.0 INSTALLATION

The Patton Model 537 is simple to install and requires no user

configuration. Follow these installation steps.

1. Disconnect the data cable from the device you are protecting in

a manner consistent with the manufacturer’s installation

instructions.

2. Be sure the connector shield on the device you are protecting

is connected to frame ground. If not, contact Patton Technical

Support for further instructions.

3. Plug the connector of the Model 537 directly into the Token

Ring port of the device you are protecting.

4. Re-attach the cable to the available connector on the Model

537. The Model 537 is now inserted between the

data port and the data cable, and will provide up to 1500 Watts

of protection to the data port.

Note: We recommend that a Patton surge protector be

connected to the other end of the data cable as well. To order,

please contact us at: (301) 975-1000; http://www.patton.com;

or, [email protected]

2.0 GENERAL INFORMATION

Thank you for your purchase of this Patton Electronics product.

This product has been thoroughly inspected and tested and is

warranted for One Year parts and labor. If any questions arise during

installation or use of the unit, contact Patton Electronics Technical

Support: (301) 975-1007; http://www.patton.com; or,

[email protected].

3.0 PRODUCT DESCRIPTION

The Patton Model 537 Surge Protector uses a solid state hybrid

network to guard token ring ports against data loss and hardware

damage due to transient surges. The Model 537 inserts between the

data cable and a token ring port. It intercepts data line transients and

sends them directly to chassis ground through the connector shield.

Warning: This product will not provide complete protection should your

equipment or building be subject to a direct lightening hit.

4.0 SURGE PROTECTION BENEFITS

The method of surge protection used in the Model 537 adds four

benefits to your system:

High Surge Capacity

The Model 537 handles up to 1500 Watts

of surge energy without failure.

Quick Response

The Model 537 has fast response times (1 pS

at the component level; 0.5 μS installed). Transient surges are

clamped at 9 volts.

Low Impedance

The Model 537 adds minimal load to your

system. It is about the same as a gender changer.

Open Failure

The Model 537 fails “open” if your system

experiences a severe transient or power fault above the rated voltage

of the protector. This means that data and surge energy is shunted

directly to chassis ground, rather than being allowed to flow throughout

the system.

5.0 INSTALLATION

The Patton Model 537 is simple to install and requires no user

configuration. Follow these installation steps.

1. Disconnect the data cable from the device you are protecting in

a manner consistent with the manufacturer’s installation

instructions.

2. Be sure the connector shield on the device you are protecting

is connected to frame ground. If not, contact Patton Technical

Support for further instructions.

3. Plug the connector of the Model 537 directly into the Token

Ring port of the device you are protecting.

4. Re-attach the cable to the available connector on the Model

537. The Model 537 is now inserted between the

data port and the data cable, and will provide up to 1500 Watts

of protection to the data port.

Note: We recommend that a Patton surge protector be

connected to the other end of the data cable as well. To order,

please contact us at: (301) 975-1000; http://www.patton.com;

or, [email protected]

2.0 GENERAL INFORMATION

Thank you for your purchase of this Patton Electronics product.

This product has been thoroughly inspected and tested and is

warranted for One Year parts and labor. If any questions arise during

installation or use of the unit, contact Patton Electronics Technical

Support: (301) 975-1007; http://www.patton.com; or,

[email protected].

3.0 PRODUCT DESCRIPTION

The Patton Model 537 Surge Protector uses a solid state hybrid

network to guard token ring ports against data loss and hardware

damage due to transient surges. The Model 537 inserts between the

data cable and a token ring port. It intercepts data line transients and

sends them directly to chassis ground through the connector shield.

Warning: This product will not provide complete protection should your

equipment or building be subject to a direct lightening hit.

4.0 SURGE PROTECTION BENEFITS

The method of surge protection used in the Model 537 adds four

benefits to your system:

High Surge Capacity

The Model 537 handles up to 1500 Watts

of surge energy without failure.

Quick Response

The Model 537 has fast response times (1 pS

at the component level; 0.5 μS installed). Transient surges are

clamped at 9 volts.

Low Impedance

The Model 537 adds minimal load to your

system. It is about the same as a gender changer.

Open Failure

The Model 537 fails “open” if your system

experiences a severe transient or power fault above the rated voltage

of the protector. This means that data and surge energy is shunted

directly to chassis ground, rather than being allowed to flow throughout

the system.
