Paxton TOUCHLOCK Compact K Series User manual

Paxton
ins-30076
TOUCHLOCK Compact K Series

Quickstart guide
Exit button
(push to make)
Electric release
12V DC power
supply
12V DC release current rating must be less than 1A.
This supplement is a brief guide to installing a TOUCHLOCK K series compact system. Further information is available
for download at: http://paxton.info/140 or call the communications team on: 01273 811011.
The reader's default indication has all the LED's on. Access granted is denoted with a single ashing Green
LED. Access Denied is a single ashing Red LED.
0V
0V
+12V
Exit
0V
0V
+12V
+12V

K75 Screw connector option
+12V DC
0V
Lock 12V
Lock 0V
Exit input
Exit 0V
12 3
456
789
0 #
*

Wiring
The unit should be mounted in conjunction with
an electrical backbox to achieve the required
clearance for the connector.
If an adaptor plate (310-750) is tted, the
mountings on the backbox can also be used.
Bell 12V
Bell 0V
Illustrations in this instruction
show the standard keypad.
The Stainless Steel version installs
and operates in exactly the same
manner.
Indoor use only

This box can be used to write down the Programming Code for future reference.
Ensure that this information is stored in a secure place.
Factory reset
1. Power down the system.
2. Power the system up whilst pressing and holding 3.
3. The LED's will ash and the unit will beep 3 times a second.
4. Go to the programming guide. - Initialising a new system.
Choose a 6 digit Programming Code and load this into the unit as follows:
DO NOT USE 123456 - The default User Code (1234) will open the door before the
Programming Code had been fully entered.
6 digit Programming Code
The default user code is now set to 1234
6 digit Programming Code
You can now set up the user codes and features using the programming chart.
Example: - Setting a user code to unlock the door under Normal conditions.
Enter user code
4-8 digits
Re-enter
user code 4
8
Enter 6 digit
Programming
Code
Hold for 3 secs Normal
The unit will beep and the LED ashes faster
Initialising a new system

X
Single or multiple codes
Silent operation
20 wrong keystrokes
= 60 second lockout
Door open time (seconds)
Change Programming Code
Exit button
Set a user
code
Data Reset (except
Programming code)
OR
One code only Multiple codes allowed
Silent
Beep on
OFF ON
Enter time in seconds (default =
07, max = 60)
Open door for time
in option 5
Toggle door open until
pressed again or toggle
code entered
Enter user code
4-8 digits
Re-enter user
code
Enter 6 digit
Programming Code
= Delete
= Normal
= Toggle
= Duress
Enter 6 digit
Programming Code
Re-enter 6 digit
Programming Code
6
OR
OR
X
OR
2
4
6
8
OR
OR
OR
Lock wire setting Fail locked Fail open
OR
2
2
2
2
2
2
1
3
4
7
5
6
9
8
6
6
6
6
START - Enter the 6 digit Programming Code and hold down a function key for 3
seconds. - The unit beeps and the LED ashes faster.
Continue the key sequence to set the option - The keypad returns to operating mode.
= Hold down for 3 secs
Function keys
9

Keypad bezels
Additional bezels are available in black, white and satin chrome. Registered installers can order these
free of charge by logging onto the secure installer extranet: http://paxton.info/1035 or if you are not a
registered installer please call us on: 01273 811011 for more information.
Fitting

Here is the list of topics about this product that receive the most technical support enquiries.
We list them here to help you speed up the installation and trouble shooting process.
1 - Can I use a fail open release (e.g. Maglock)?
QThe lock wires from a compact keypad provide 12V DC to the electric lock. By default, the compact is
Qset to operate with a fail locked release - providing 12V on the lock wires when a valid entry is made.
QTo use a fail open release, the lock wire setting needs to be changed (Program option 1)
2 - Can I put a relay across the lock wire output?
QYes - All compact systems have been designed to drive relays.
3 - Integration with an entry phone system.
QThe output from the entry phone system is used to simulate an exit button for the Paxton equipment.
QNo voltage should be applied to the exit input wires (Blue / Mauve) of a compact unit. Most phone
Qsystems will provide a powered pair to release the door lock; this voltage must be used to drive an
Qindependent relay. The relay contacts must be 'normally open going closed' to mimic a 'push to make'
Qexit button. Only a voltage free output pair can be connected directly to the exit input wires.
4 - What are the keypad code types used for?
QNormal - Releases the door for the time period set in Option 5.
QToggle - Releases the lock until the code is entered for a second time.
QDuress - Releases the lock (as in Normal) but also energizes the bell output for 30 seconds.
QDelete - Used to remove a specic code that has already been entered in Multiple mode.
5 - Connecting a compact with another control unit.
QThis cannot be done. Paxton Compact systems have the control electronics built in and no direct data
Qoutput is provided. The Switch2 and Net2 system use a dierent type of data input.
QNote: The compact system will control the door unit on its own.
6- Read in and read out on one door.
QYou cannot wire two compact systems in parallel to a common lock as this may result in damage to
Qyour system. They will both power the door lock independently and will not oer single point control.
QWe recommend using one Switch2 controller with two compatible keypads or readers.
7 - Use with External doors.
QCompact system are less secure than a system with a separate controller. It is strongly recommended
Qthat a Switch2 based system is used in place of a compact as the control electronics are secure on the
Qinside of the property.
Technical Help

11V DC 14V DC
100 mA 250 mA
1A
12V DC
1 50
4 digits 8 digits
1 sec 60 secs
- 20 °C + 55 °C
IPX7
K38 38 mm 78 mm 13 mm
K50 50 mm 100 mm 15 mm
K75 75 mm 143 mm 16 mm
Outdoor use
Yes
Yes
Yes
Yes
3 metres
No
K series compact keypad
Black and White keypad bezels or Stainless Steel bezel
Documentation
P50 fk1-059 P50 tting kit
P38 fk1-060 P38 tting kit
P75 fk1-061 P75 tting kit
Switchable current
Backlight
Features
Code length
Door open time
Silent operation
Can be used with fail OPEN locks
Can be used with fail CLOSED locks
Exit button input
Door Contact input
Alarm/bell output voltage
Number of Users
Cable length
Min Max
Voltage
Specications
Operating temperatures - all items
Electrical
Environment
Current
Waterproof - Fixed cable
Dimensions
Min
Width Height
Max
Min Max
Depth
Contents in box
Not with Stainless Steel keypad
Description
Low
Vandal resistance - Stainless steel keypad
Vandal resistance - Standard keypad
Medium
Option
Waterproof - K75 - Screw connection Indoor use

This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person.
The declaration of conformity is available http://paxton.info/3910
Contact details are provided at: http://paxton.info/596
