Test Stand for Force Gauge
PCE-MTS500
INSTRUCTION MANUAL

1.Function 1
2.Structure 1
3.Installation 2
4.Specification 2
5.Attention 3
6.Operation 3
7.Maintenance 3
8.Packing List 3
CONTENTS

1
POWER
OFF ON
UP
STOP
DOWN
MANUAL AUTO
SPEED CONTROL
LOW HIGH Power Socket
Up Button
Stop Button
Down Button
Shift Button
of Manual and
Automatic Mode
Speed Knob
Power Lamp
Power Switch
Down Slide Carriage
Up Slide Carriage
1040mm
410mm
Tighten Screw of
Up Slide Carriage
Up Limit Ring
Down Limit Ring
Limit Switch
260mm
Column
Up Limit Screw
Lower Limit Screw
Small Backboard
Force Gauge Backboard
1.Function
3&(076Electric Vertical Test Stand, applied in tension and compression test, is assembled with
(2N-5kN) Series Force Gauge. The stand adopts double-column construction
with good stability, wide application range and easy operation. Furthermore, it has advantages
of non-polar speed adjustment, manual or automatic operation, suitable for fields of rubber & plastic
products, textile, construction, complex material, wire & cables,auto accessories, engine
and scientific research,etc.
Note: When installing different force gauge, itshould equip different backboard.
2.Structure

2
Picture 1 Installation of
(Sensor Inside) ForceGauge
Picture 2 Installationof
Force Gauge
Picture 3 Installationof
Force Gauge(1kN-5kN)
3.Installation of Force Gauge
Force Gauge
M3 Screw
M6 Haxangular Nut
Force Gauge Outside Backboard Sensor
Joint Bearing
1.When installing (Sensor Inside) Force Gauge, take out 4 pieces of M3 screws from toolbox,
and through 4 deep hole of Small Backboard, tighten them into 4 installing hole on force
gauge(Picture 1);
2. When installing Force Gauge, take off 4 pieces of M6 hexangular screws of back cover, and
backboard. also take off Small Backboard on test stand;through 4 hole of Force Gauge
backboard, tighten 4 pieces of M6 screws into insalling hole of Force Gauge by nut
(Picture 2);
3. When installing (1kN-5kN) Force Gauge, it should equip the SJ-021 Outside Backboard.
Loosen the 4 pieces of M6 hexangular screws, take off the SKN Backboard, fix the SJ-021
Backboard on the position of Force Gauge Backboard by the 4 screws;Take one of the joint
axletree from sensor toolbox, and tighten the sensor through hole of
backboard as showing in picture(Picture 3).
4. Specification
Capacity
Measuring Stroke
Measuring Speed
Maximum Gap
WorkVoltage
Rate Current
Fuse of MainCircuit
Fuse of ControllingCircuit
WorkingTemperature
Store & Delivery Temperature
Relative Humidity

7.Maintenance
8.Packing List
3
5.Attention
A. Please do not take Up or Lower Limit Screw at any time to prevent screw mandrel from getting
out or damagingto other accessories.
B. When needing to move UP Slide Carriage for appropriate space, please pay attention:
1. Loosen the tighten screw at two side of Up Slide Carriage, during which it should support the
slide carriage by hands to avoid dropping down.
2. The Up Slide Carriage will not upper than the top of column, and lower than Up Limit Screw.
C. Operation
Examine Before Operation
Manual Test
A. Check Tighten Screw of Up Slide Carriage to be locked firmly;
B. Turn on thepower switch, thenthe power lamp will be light.
C. Examine the stand whether there is abnormal sound when moving without load.
Choose the Manual mode by pressing Shift Button of Manual and Automatic Mode;Press Up
or Down button all along, the test stand will work; Loosen the button, the test stand will stop
work and finish test.
Automatic Test
Choose theAutomatic mode bypressing Shift Buttonof Manual and Automatic Mode;Press
Up or Downbutton once, the test stand will work; Press Stop button, the test stand will stop
and finish test.
A. Please keep the environment clean and prevent liquid and metal scraps from entering
the engine box, otherwise electric shock may happen and driving components may be
damaged.
B. Please keep the column and lower slide carriage hole clean.
C. Add some lubricantto screw mandrel and gear after period of time.
D. Please pullout power connector, and makethe stand away from dust andmoisture if it is
not used.
Number
1
2
3
4
5
Quantity
1
1
1
1
1
Parts Name
3&(076Main Body
M10 Inner Hexagon Spanner
110/220V Power Wire
6
Manual
1
Qualification Certificate
