PCE Instruments PCE-VC 21 User manual

© PCE Instruments
PCE-VC 21Portable Shaker Vibration Calibrator
User Manual
User manuals in various languages (Deutsch,
français, italiano, español, português, nederlands,
türk, polski, русский, 中文) can be downloaded here:
www.pce-instruments.com
Last change: 23 August 2017
v1.0
English

© PCE Instruments
Contents
1Safety notes....................................................................................... 1
2Specifications.................................................................................... 2
3System description ........................................................................... 3
4Purpose ............................................................................................. 3
5Properties.......................................................................................... 3
6Operation........................................................................................... 4
6.1 Attaching the Test Object .......................................................................................................4
6.2 Calibration ...............................................................................................................................5
6.3 Settings....................................................................................................................................6
6.4 Charging the Accumulator ......................................................................................................7
6.5 Reset .......................................................................................................................................8
7Calibration......................................................................................... 8
8Contact ............................................................................................ 9
9Disposal............................................................................................. 9

© PCE Instruments
1
1 Safety notes
Please read this manual carefully and completely before you use the device for the first time.
The device may only be used by qualified personnel and repaired by PCE Instruments
personnel. Damage or injuries caused by non-observance of the manual are excluded from our
liability and not covered by our warranty.
The device must only be used as described in this instruction manual. If used
otherwise, this can cause dangerous situations for the user and damage to the meter.
The instrument may only be used if the environmental conditions (temperature,
relative humidity, …) are within the ranges stated in the technical specifications. Do
not expose the device to extreme temperatures, direct sunlight, extreme humidity or
moisture.
Do not expose the device to shocks or strong vibrations.
The case should only be opened by qualified PCE Instruments personnel.
Never use the instrument when your hands are wet.
You must not make any technical changes to the device.
The appliance should only be cleaned with a damp cloth. Use only pH-neutral
cleaner, no abrasives or solvents.
The device must only be used with accessories from PCE Instruments or equivalent.
Before each use, inspect the case for visible damage. If any damage is visible, do not
use the device.
Do not use the instrument in explosive atmospheres.
The measurement range as stated in the specifications must not be exceeded under
any circumstances.
Non-observance of the safety notes can cause damage to the device and injuries to
the user.
We do not assume liability for printing errors or any other mistakes in this manual.
We expressly point to our general guarantee terms which can be found in our general terms of
business.
If you have any questions please contact PCE Instruments. The contact details can be found at
the end of this manual.

© PCE Instruments
2
2 Specifications
Vibration
frequencies
Vibration magnitudes (RMS values)
1 m/s²
2 m/s²
5 m/s²
10 m/s²
20 m/s²
15.915 Hz
X
X
40 Hz
X
X
X
80 Hz
X
X
X
X
159.15 Hz
X
X
X
X
X
320 Hz
X
X
X
X
X
640 Hz
X
X
X
X
X
1280 Hz
X
X
X
X
X
Accuracy of magnitudes
±3 % max. at 0 to 40 °C
±5 % max. at -10 to 55 °C
Accuracy of frequencies
±0.05 % max. at -10 to 55 °C
Harmonic distortion
<1 % (15.915 Hz: <5 %)
Level indicator
Percent value display, above ±3 % beep tone
Settling time
<10 s
Maximum weight of test object for stated accuracy in grams
f [Hz]
1 m/s²
2 m/s²
5 m/s²
10 m/s²
20 m/s²
15.92
500
500
40
500
500
500
80
500
500
500
500
159.2
500
500
500
500
250
320
500
500
500
500
200
640
500
500
500
400
100
1280
500
500
500
200
50
Vibration exciter
Dynamic force
10 N
Max. torque
2 Nm
Nominal torque
1 Nm
Max. transverse force
20 Nm
Transverse vibration
(14 mm above shaker)
15.92 / 40 / 80 / 159.2 / 1280 Hz: <10 %
320 / 640 Hz: <20 %
Mounting of test object
M5 tapped hole, 90° ± 0.5°, 7 mm deep
Clamping magnet
Adhesive
Operating temperature ranges for
3% accuracy
5% accuracy
0 … 40 °C
-10 … 55 °C
Humidity
<90 % at 30 °C, no condensation
Magnetic scatter field at shaker
<0.2 mT
Power supply
Built-in NiMH accumulator;
7.2 V / 1.6 Ah
Battery operating time
approx. 5 h with m = 100 g
Automatic shut-off time
1 to 30 min
Charge time of accumulator
3 h
Charge socket
DIN 45323 (5.5 / 2.1)
Positive terminal at center pin
Charge voltage
11 … 18 V DC

© PCE Instruments
3
Charge current
<1 A
Protection grade
IP30
Dimensions
100 x 100 x 120 mm
Weight
2.2 kg
3 System description
4 Purpose
Easy and simple calibration of vibration metering, recording and control equipment.
Regular checks of such devices and installations.
Fault finding.
5 Properties
Handy and robust battery device for laboratory and filed use.
7 selectable vibration frequencies from 15.915 to 1280 Hz1.
Up to 5 selectable vibration magnitudes from 1 to 20 m/s2.
Load-independent vibration magnitude.
Suitable for test objects weighing up to 500g.

© PCE Instruments
4
The vibration calibrator PCE-VC21 generates mechanical vibration with quartz stabilized
frequency and precisely controlled magnitude. Vibration sensors, including connected cables,
signal conditioners and readout instruments can be calibrated in acceleration, velocity or
displacement units.
Thanks to its lowest frequency of 15.915 Hz, the PCE-VC21 can also calibrate whole-body
vibration meters to ISO 2631 / ISO 8041 or building vibration meters to DIN 4150.
A reference accelerometer inside the shaker head and a control circuit keep the vibration level
constant and independent of the weight of the attached measuring object. A display indicates
the error in percent. There is an acoustical warning when he error limit is exceeded.
Because of its internal rechargeable battery, the PCE-VC21 is well suited for mobile
applications. The instrument features an automatic switch-off function preventing accidental
discharging. The display indicates the battery charging condition. The unit comes with an
external mains supply for charging.
The supplied plastic carrying case allows convenient handling and safe transport.
6 Operation
6.1 Attaching the Test Object
The vibration exciter of the PCE-VC21 has a tapped M5 hole with 7mm depth for the attachment
of the device under test. The supplied stud bolts and stud adapters or a climbing magnet can be
used for mounting.
The surface of the vibration exciter has been made extremely resistant by plasma nitride
coating.
For light transducers, adhesive wax or double sided adhesive tape can be used for mounting. A
flat surface for adhesive mounting can be obtained by using the M5 insulating flange Model 029
which is available from Metra.
Magnetic and adhesive attachments are only allowable for roughly estimated calibrations.
Accuracy is only guaranteed for screw attachment.
When mounting the specimen, pay attention to the symmetrical distribution of the object weight.
Otherwise, the vibrating system may be deflected from its main axis. When using coupling
structures for calibration of transducers, symmetrical attachment becomes especially important,
for instance, at the calibration of the x and y axis of a triaxial accelerometer. In the case, using a
balance weight as shown in the following illustration is recommended.
Figure 1: Load balancing

© PCE Instruments
5
Please note that heavy connecting cables should be supported close to the test object.
However, an application of force via the cable must be avoided.
The maximum torque rating of 1 to 2 Nm at the vibration exciter must not be exceeded since
this may damage the instrument.
The PCE-VC21 should be placed on a rigid surface. Hand-held operation is not recommended
because of possible errors.
The supplied disk-shaped steel test piece is screwed onto the shaker head. It is made of
2CrMo4 which is the reference steel for sensitivity statements in the data sheets of proximity
probes. The sensor under test is screwed into the thread adapter and inserted into hole in the
slider. A fastening screw is provided for the thread adapter. Heavy or stiff cables are to be
supported so that no transverse forces act on the clamping device. After loosening two
fastening screws on the side, the slider can be shifted vertically to adjust the air gap between
the probe tip and the steel disk. The optimum air gap is reached when the DC output of the
sensor (or its oscillator) is approximately half its full-scale value (typically 10 to 12 V). A
thickness gauge can be useful to adjust the right gap. Now you can switch the PCE-VC21D on
to calibrate the proximity probe dynamically.
The calibration of proximity probes is performed at 159.2 Hz (radian frequency 1000 s-1). This is
the frequency where the magnitude value of acceleration in m/s2 are the same as the
displacement value in μm Hence the PCE-VC21D provides displacement magnitudes of 1, 2, 5,
10 and 20 μm RMS. Calibration at other frequencies is not recommended because the damping
elements of the clamping device have been optimized only for 159.2 Hz.
The clock output of Model PCE-VC21d is described in section.
6.2 Calibration
After attaching the device under test, switch the PCE-VC21 on by depressing the “On/Off”
button until the display lights up. Device information, such as hardware and software version
and the date of the last calibration, is displayed for a few seconds (Figure 3).
Figure 3: Version and calibration date
After short time the vibration signal becomes stable. The display shows the values of vibration
frequency and magnitude (Figure 4). Please note that these are not measuring values but only
nominal values.

© PCE Instruments
6
Press the keys ”f+“ or “f-” to choose between the seven available frequencies. The magnitude
can be selected by the “a+” and “a-” keys. Depending on the frequency, up to five magnitudes
can be selected.
Note: At 159.2 Hz (radian frequency 1000 s-1) the unit of the magnitude alternates between
m/s2for acceleration, mm/s for velocity and μm for displacement. This is the frequency where
the magnitude values of acceleration in m/s-2 are the same as the velocity values in mm/s and
the displacement values in μm.
Example: 10 m/s2are 10mm/s and 10 μm.
In the upper right hand corner you will see the actual accuracy of the vibration magnitude in
percent. After short period of time the percent value should converge on zero.
If the absolute error exceeds 3%, the percent value will change to inverse characters and a
beep sound will be generated. In the case no calibration can be performed.
When the maximum weight of the test object is exceeded, instead of the percent value, an error
message “OVERL” will appear and the shaker will be switched off. To proceed with calibration,
first switch the calibrator off. Then reduce the weight of the test object and switch the calibrator
back on. The admissible weight is up to 500 grams, depending on the selected frequency. The
overload message can be eliminated by lowering the vibration magnitude.
The PCE-VC21 can be switched off by depressing the “ON/OFF” key for least one second.
Should this be omitted, a timer is provided which switches the calibrator off after a preselected
time from 1 to 30 minutes.
Caution: The vibration calibrator is not to be used in dirty and dusty environments. Particular
care should be taken that no ferromagnetic particles get inside of the instrument. They may
damage it within short time. Defects due to dirt and dust are not covered by the warranty.
6.3 Settings
Press the “Menu” key to enter the setup menu (Figure 5).
Figure 5: Setup menu
Select “1/2 Shut-off timer” by pressing the “On/Off” key. The time for automatic shut-off can be
entered between 1 and 30 minutes by means of the “a+” and “a-” keys.
Menu item “2/2: Calibration” is intended for factory calibration only. It is protected from
manipulation by a password.

© PCE Instruments
7
6.4 Charging the Accumulator
The battery indicator is located in the upper left hand corner of the display. A full bargraph is
displayed when the battery is fully charged. Even if the bargraph is empty the instrument can
still be used within its specifications for a certain period of time. When the battery voltage drops
under a critical value, the PCE-VC21 is switched off automatically.
The instrument is equipped with a NiMH accumulator providing power for approximately 5 hours
of operation.
To charge the battery, connect the supplied mains plug adapter (15 VDC) to the DIN socket at
the side of the case. The unit should preferably be switched off during charging. Charging will
take about 3 hours. During the charging process the battery indicator will be continuously
moving (Figure 6).
Figure 6: Charging indication
During the charging process the PCE-VC21 can be used for calibration. However, this will
extend the necessary charging time.
The accumulator should be charged at room temperature. At higher temperatures charging can
be stopped before recharging the full capacity because of the build-in temperature sensor.
The battery has no memory effect. Partial charging is permissible.
Permanent connection of the main adapter is not recommended. This may lead to premature
wear of the battery. In order to avoid overcharging the battery, it is not recommended that you
disconnect and connect the main adapter immediately after charging is finished.
When the unit is not in use, the battery should be charged at least once a year.
The built-in battery is maintenance-free. Like all accumulators it has a limited number of
charging cycles. If the operating time with a fully charged battery becomes insufficient, the
battery should be replaced. In this case, the calibrator should then be returned to the
manufacturer. In addition to replacing the battery, the manufacturer will also test the accuracy of
the calibrator.

© PCE Instruments
8
6.5 Reset
In the unlikely event that your PCE-VC21 cannot be switched on by the “On/Off” key, it may be
necessary to press the Reset button. This button is found on the bottom side of the case near
the key pad. Use a thin non-metallic object, such as a toothpick, to press the button inside the
hole. This will start the instrument. Pressing the Reset button has no effect on accuracy.
7 Calibration
The vibration characteristics of the PCE-VC21 are very stable even after intensive use. Typical
changes are below 1% per year. We recommend annual re-calibration. In case of shock load,
dropping the instrument, etc. immediate recalibration is advised.

© PCE Instruments
9
8 Contact
If you have any questions, suggestions or technical problems, please do not hesitate to contact
us. You will find the relevant contact information at the end of this user manual.
9 Disposal
For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament
applies. Due to the contained pollutants, batteries must not be disposed of as household waste.
They must be given to collection points designed for that purpose.
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use
them or give them to a recycling company which disposes of the devices in line with law.
For countries outside the EU, batteries and devices should be disposed of in accordance with
your local waste regulations.
If you have any questions, please contact PCE Instruments.

© PCE Instruments
10
PCE Instruments contact information
Germany France Spain
PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L.
Im Langel 4 23, rue de Strasbourg Calle Mayor, 53
D-59872 Meschede 67250 SOULTZ-SOUS-FORETS 02500 Tobarra (Albacete)
Deutschland France España
Tel.: [phone] Téléphone: [phone] Tel. : [phone]
Fax: [phone] Numéro de fax: [phone] Fax: [phone]
[e-mail] [e-mail] [e-mail]
www.pce-instruments.com/deutsch www.pce-instruments.com/french www.pce-instruments.com/espanol
United States of America United Kingdom Italy
PCE Americas Inc. PCE Instruments UK Ltd PCE Italia s.r.l.
711 Commerce Way suite 8 Units 12/13 Southpoint Business Park Via Pesciatina 878 / B-Interno 6
Jupiter / Palm Beach Ensign Way, Southampton 55010 LOC. GRAGNANO
33458 FL Hampshire CAPANNORI (LUCCA)
USA United Kingdom, SO31 4RF Italia
Tel: [phone] Tel: [phone] Telefono: [phone]
Fax: [phone] Fax: [phone] Fax: [phone]
[e-mail] [e-mail] [email protected]
www.pce-instruments.com/us www.pce-instruments.com/english www.pce-instruments.com/italiano
The Netherlands Chile Hong Kong
PCE Brookhuis B.V. PCE Instruments Chile S.A. PCE Instruments HK Ltd.
Institutenweg 15 RUT: 76.154.057-2 Unit J, 21/F., COS Centre
7521 PH Enschede Santos Dumont 738, local 4 56 Tsun Yip Street
Nederland Comuna de Recoleta, Santiago, Chile Kwun Tong
Telefoon: [phone] Tel. : [phone] Kowloon, Hong Kong
Fax: [phone] Fax: [phone] Tel: [phone]
[e-mail] [e-mail] [e-mail]
www.pce-instruments.com/dutch www.pce-instruments.com/chile www.pce-instruments.cn
China Turkey
PCE (Beijing) Technology Co.,Ltd PCE Teknik Cihazları Ltd.Şti.
1519 Room, 4 Building Halkalı Merkez Mah.
Men Tou Gou Xin Cheng, Pehlivan Sok. No.6/C
Men Tou Gou District 34303 Küçükçekmece - İstanbul
102300 Beijing Türkiye
China Tel: [phone]
Tel: [phone] Faks: 0212 705 53 93
[e-mail] [email protected]m.tr
www.pce-instruments.cn www.pce-instruments.com/turkish
