PCE Instruments PCE-T 260 User manual

+ Type k Temp, Pt 1000 ohm Temp,
IRTemp adapter.
Automotive Tester
Model : PCE-T 260
Your purchase of this
TACHOMETER/
STROBOSCOPER
Strength Meter
marks a step forward for you
into the eld of
precision measurement.
Although this METER is
a complex and delicate
instrument, its durable
structure will allow
many years of use if
proper operating
techniques are
developed. Please read
the following
instructions carefully
and always keep this
manual within easy
reach.
OPERATION MANUAL

TABLE OF CONTENTS
1. FEATURES..............................................................................................................
1
2. SPECIFICATIONS..................................................................................................
2
3. FRONT PANEL DESCRIPTION.............................................................................
6
3-1 Display Reflecting mark..........................................................................................................
6
3-2 Power button..........................................................................................................
6
3-3 HOLD/ ▲
button..........................................................................................................
6
3-4 REC/DOUBLE button..........................................................................................................
6
3-5 UNIT/ ▼
button..........................................................................................................
6
3-6 Function button..........................................................................................................
6
3-7 RPM Adapter..........................................................................................................
6
3-8 Surface Speed Test Wheel..........................................................................................................
6
3-9 Funnel type rubber for RPM adapter..........................................................................................................
6
3-10 RS-232 Output Terminal..........................................................................................................
6
3-11 pt 1000 Ω
probe Terminal..........................................................................................................
6
3-12 Termocouple(type k) probe Terminal..........................................................................................................
6
3-13 Tripod Fix Nut..........................................................................................................
6
3-14 Battery Compartment/Cover..........................................................................................................
6
3-15 Reflecting Mark..........................................................................................................
6
3-16 Photo led light beam..........................................................................................................
6
3-17 Stroboscope flash light (red) indicator..........................................................................................................
6
3-18 Moniter indicator..........................................................................................................
6
3-19 IR Temp. adapter seat..........................................................................................................
6
3-20 IR Temp. adapter select switch...........................................................................................................
6
3-21 IR Temp. adapter...........................................................................................................
6
4. PHOTO TACHOMETER MEASURING PROCEDURE...........................................
7
5. CONTACT TACHOMETER MEASURING PROCEDURE......................................................................
8
6. STROBOSCOPE OPERATION PROCEDURE......................................................................
9
7. Type K Thermometer MEASURING PROCEDURE......................................................................
10
8. RTD Temperature MEASURING PROCEDURE......................................................................
11
9. Infrared Thermometer MEASURING PROCEDURE......................................................................
11
10. RECORD OPERATION PROCEDURE..................................................................................................................
12
11. BATTERY REPLACEMENT.......................................................................................................
13
12. RS232 PC SERIAL INTERFACE....................................................................
13

1. FEATURES
* Multi-functions, one instrument combine Photo Tachometer
( RPM ) & Contact Tachometer ( RPM, m/min., ft/min. ).
Strobscope , Type K Thermometer, Pt 1000 Thermometer,
IR Thermometer .
* High intensity white white light beam for photo tachometer,
safety and save the power energy.
* Wide measuring range from 0.5 to 100,000 RPM.
* 0.1 RPM resolution for the measured value < 1000
RPM.
* High precision with 0.05% accuracy.
* The last value, max., value, min. value will be stored
into the memory automatically & can be obtained by
pressing REC BUTTON.
* Large LCD display
* High visible LCD display gives RPM reading exactly
with no guessing or errors & saves battery energy.
* This tachometer used the exclusive one chip
MICRO-COMPUTER LSI circuit & crystal time base,
offer the high accurate measurement & fast sampling
time.
* The use of durable, long lasting components, including
a strong, light weight ABS plastic housing, assures
almost maintenance free performance for many years.
* The housing cabinet has been carefully shaped to fit
comfortable in either hand.
1

2. SPECIFICATIONS
2-1 General Specifications
Display 45 mm x 24 mm LCD, 5 digits.
5 digits with display unit.
Measurement 1. Photo Tachometer. 2. Contact Tachometer
3. Strobescople Tachometer. 4. Type K/J thermometer
5. p t 1000 Ωthermometer. 6. IR thermometer
Operating Humidity Max. 80% RH.
Operating 0 to 50 ℃ ( 32 to 122 ℉ )
Temperature
Over Input Indication of "- - - - "
Indicater.
Power Supply UM3-AA X 4 ( DC 6 V battery )
Power Approx. DC 5 mA
Consumption
Weight 160g (battery included)
Dimension HWD 207 x 67 x 39 mm (81.5 x 26.3 x 15.3 inch).
Time base Quartz crystal.
Circuit
Exclusive one-chip of microcomputer
LSI circuit.
Memory Last/Max./Min. value.
Accessories Hard carrying case ...................................... 1 PC.
Included Reflecting tape marks
( 600 mm )................................................... 1 PC.
RPM adapter ( CONE )........................................
1 PC.
RPM adapter ( FUNNEL )..................................
1 PC.
Surface speed test wheel................................ 1 PC.
Operation manual........................................ 1 PC.
Optional Type K Temp. probe : TP-01 , TP-02A ,TP-03 ,
Accessories TP-04 ,
IR Temp. adapter
2

2-2 Electrical Specification ( 23 ±5 ℃
℃℃
℃ )
Photo Tachometer
Measurement Photo Tachometer :
& Range 5 to 99,999 RPM.
Resolution RPM:
0.1 RPM ( < 1,000 RPM ).
1 RPM ( ≧ 1,000 RPM ).
Accuracy ±( 0.05% + 1 digit ).
Photo 50 to 150 mm/2 to 6 inch. (typical
Tachometer max. 300 mm/12 inch, depending
detecting upon ambient light).
distance * Spec. of detecting distance are that
under the size of reflecting tape is
10 mm square & the measuring
RPM value is 1,800 RPM. The max.
& min. detecting distance may
change under different
environment, different reflecting
tape or the measuring RPM
beyond 1800 RPM.
Contact Tachometer
Measurement Contact Tachometer :
& Range 0.5 to 19,999 RPM.
Resolution m/min.:
0.01 m/min. ( < 100 m/min. ).
0.1 m/min. (
≧ 100 m/min. ).
ft/min.:
0.1 ft/min. ( < 1,000 ft/mn. ).
1 ft/min. ( ≧ 1,000 ft/mn. ).
in./min. :
0.1 in./min. ( < 1000 in./min.).
1 in//min. (
≧ 1,000 in./min.).
Accuracy ±( 0.05% + 1 digit ).
3

Strobescople Tachometer
Flash adjust 60 to 30,000 RPM/FPM.
range * RPM : round per minute.
* FPM : flash per minute.
Resolution 0.1 RPM :
< 1,000 RPM.
1 RPM :
≧ 1,000 RPM
Function Digital rotate knob,
buttons x 2 button, ÷ 2 button,
+ button, - button,
Accuracy ±(0.05 % + 1d)
* Spec. tested under the environment
RF Field Strength less than 3 V/M &
frequency less than the 30 MHz only.
* Spec. tested under the environment
RF Field Strength less than 3 V/M &
frequency less than the 30 MHz only.
4

Type K/J thermometer
Sensor Resolution Range Accuracy
Type
Type K 0.1 ℃ -50.0 to 1300.0 ℃ ± ( 0.4 % + 0.5 ℃ )
-50.1 to -100.0 ℃ ± ( 0.4 % + 1 ℃ )
0.1 ℉ -58.0 to 2372.0 ℉ ± ( 0.4 % + 1 ℉ )
-58.1 to -148.0 ℉ ± ( 0.4 % + 1.8 ℉ )
p t 1000 Ω
ΩΩ
Ω thermometer
Unit Range Resolution Accuracy
℃ -10 to 70 ℃ 0.1 ℃ ± 1.2 ℃
℉ 14 to 158 ℉ 0.1 ℉ ± 2.5 ℉
IR thermometer
Emissivity 0.95 fixed value
Spectral response 6 to 14 µm (wavelength)
Field of View D/S D/S =Approx. 6:1 ratio (D = distance, S =spot)
Unit Range Resolution Accuracy
℃ -30 to 305 ℃ 0.1 ℃ ± 1.2 ℃
℉ -22 to 581 ℉ 0.1 ℉ ± 2.5 ℉
5

3. FRONT PANEL DESCRIPTION
Fig. 1
3-1 Display Reflecting mark 3-14 Battery Compartment/Cover
3-2 Power button 3-15 Reflecting Mark
3-3 HOLD/ ▲ button 3-16 Photo led light beam
3-4 REC/DOUBLE button 3-17 Stroboscope flash light (red) indicator
3-5 UNIT/ ▼ button 3-18 Moniter indicator
3-6 Function button 3-19 IR Temp. adapter seat
3-7 RPM Adapter 3-20 IR Temp. adapter select switch.
3-8 Surface Speed Test Wheel 3-21 IR Temp. adapter.
3-9 Funnel type rubber for RPM adapter
3-10 RS-232 Output Terminal
3-11 pt 1000
Ω probe Terminal
3-12 Termocouple(type k) probe Terminal
3-13 Tripod Fix Nut
6

4. PHOTO TACHOMETER
MEASURING PROCEDURE
1) Power On the meter by pressing and hold the " Power
button " ( 3-2, Fig. 1 ) >1.5 second , the LCD will light.
2) Press the " Function button " ( 3-5, Fig. 1 ) once in
sequence until to the " Photo RPM " function be
selected, in the same time the " Photo light beam " (
3-16, Fig. 1 ) will be generated.
3) Apply a " Reflecting mark " ( 3-15, Fig. 1 ) to the
object being measured. and align the " Photo light
beam " ( 3-16, Fig. 1 ) with the applied target. Verify
that the " Monitor Indicator " ( 3-18, Fig. 1 ) lights
when the target pass through the light beam.
4) when test value stable ,press hold buttom " ( 3-3, Fig. 1 )"
he test value will be keep in didplay .
Release the "Measuring Button" when the reading
Measuring consideration :
stabilizes (about 2 seconds).
If the measured RPM values is very low ( for
example less than 50 RPM ), recommend to
attach more " Reflecting Marks " average to
the object. It will get the real RPM with high
resolution, precisely & fast sampling time
when divided the reading values by the no.
of the " Marks ".
7

5. CONTACT TACHOMETER
MEASURING PROCEDURE
5-1 RPM measurement
1) Power On the meter by pressing and hold the " Power
button " ( 3-2, Fig. 1 ) >1.5 sencnds, the LCD will light.
2) Press the " Function button " ( 3-6, Fig. 1 ) once in
sequence until to the " Contact RPM " function be
selected.
3) Lightly pressing the " RPM Adapter " ( 3-9, Fig. 1 )
against the center hole on the hole of the measured
rotating axis.
4) when test value stable ( approx. 2 sec. ) ,press hold buttom
" ( 3-3, Fig. 1 )" the test value will be keep in didplay .
Measuring consideration :
Making the contact RPM measurement due to
different kind measured rotating axis, it may
changed the rubber for RPM adapter from "
CONE " type to " FUNNEL" type ( 3-9, Fig. 1 )
.
5-2 Surface Speed Measurement
1) Power On the meter by pressing the " Power
button " ( 3-2, Fig. 1 ) once, the LCD will light.
2) Press the " Function button " ( 3-5, Fig. 1 ) again and again in
sequence until to the " Surface speed " function be
selected. The Display will show the indicator of the
" m/min ", " ft/min " or " in.min. ".
2) Change the " RPM Adapter " instead of the " Surface
Speed Test Wheel " ( 3-8, Fig. 1 )
3) Simply attaching the surface speed test wheel to the
detector. Release the "Measuring Button" when the
reading stabilizes ( approx. 2 sec. ).
8

6 STROBOSCOPE OPERATION
PROCEDURES
6-1 STROBOSCOPE OPERATION
1) Power On the meter by pressing and hold the " Power
button " ( 3-2, Fig. 1 ) >1.5 second , the LCD will light.
2) Press the " Function button " ( 3-5, Fig. 1 ) once in
sequence until to the " SCOPPE RPM " function be
selected, in the same time the " Stroboscope flash light (red)
indicator " (3-17, Fig. 1 ) will be Light.
3) The display will show " 100.0 " RPM ( FPM ), it is the
default value.
Use the " x 2 button " or " x 2 button " to adjust the
display value near the estimate setting signal's RPM
approximately..
* Press and hold the " DOUBLE button " then Press "
▲ button "
once will double the display value.
For example, the display is " 100.0 " , Press and hold the
" DOUBLE button " then Press " ▲ button " once, the display will
change to " 200.0 ". Operation again, the display will change to "
400.0 ".....
* Press and hold the " DOUBLE button " then Press "
▼ button "
once will divide the display value by two.
For example, the display is " 400.0 ", Press and hold the
" DOUBLE button " then Press " ▼ button " once , the display
will change to " 200.0 ". Operation again, the display will change
to " 100.0 ".....
6-2 Checking Speed (RPM/FPM)
1) Use the "
▲ + button " ( 3-3, Fig. 1 ) , " - button " ( 3-5,
Fig. 1 ) to adjust the exact display value.
* Press the " ▲+ button " once ( continuously ) will
increase the display value.
* Press the "▼- button " once ( continuously ) will
decrease the display value.
9

* If press the button once, the display value will
change with high resolution ( change just with 1
digit ).
* If press the button continuously, the display value will
change with low resolution ( change with more
digits ).
When checking the speed, care must be taken
to ensure that the strobe is flashing in unison
(one to one) with the object being monitored.
2) The Stroboscope will also stop motion at 2:1, 3:1, 4:1 et.,
this is normally referred to as harmonics. To ensure
unison, turn the dial until two images appear - this will
double the actual speed. Then lower the flashing rate
until a single and stationary image appears - this is the
actual true speed.
6-3 Checking Motion
For motion analysis, simply locate the actual speed as
mentioned above and then turn the dial slowly up or down.
This will give a slow motion effect allowing complete
inspection.
7. Type K Thermometer
MEASURING PROCEDURE
1) Power On the meter by pressing and hold the " Power
button " ( 3-2, Fig. 1 ) >1.5 sencnds, the LCD will light.
2) Press the " Function button " ( 3-6, Fig. 1 ) once in
sequence until to the " TYPE k " function be
selected.
3) type k probe inserted into the thermocouple probe terminal
" thermocouple probe terminal " ( 3-12, Fig. 1 ).
4) The display will show type k probe sensing temperture value.
10

8. RTD Temperature
MEASURING PROCEDURE
1) Power On the meter by pressing and hold the " Power
button " ( 3-2, Fig. 1 ) >1.5 sencnds, the LCD will light.
2) Press the " Function button " ( 3-6, Fig. 1 ) once in
sequence until to the " P t " function be
selected.
3) pt 1000
Ω probes are connected to the pt 1000 Ωprobe terminal
" ( 3-11, Fig. 1 ).
4) The display will show type k probe sensing temperture value.
9. Infrared Thermometer
MEASURING PROCEDURE
NON-CONTACT TEMPERATURE MEASUREMENTS
(* IR Temp. adapter is optional )
1) Please IR Temp. adapter Seat cover leave, IR Temp. adapter
"( 3-21, Fig. 1 )", Lock into the seat "( 3-19, Fig. 1 )"
2) IR Temp. function select slide switch"( 3-20, Fig. 1 )", please slide
to IR place.
3) Power On the meter by pressing and hold the "power
button " ( 3-2, Fig. 1 ) >1.5 secnds, the LCD will light.
4) Press the " Function button " ( 3-6, Fig. 1 ) once in
sequence until to the " I r " function be selected.
5) Press and hold the IR thermometer test button
( " Power button " ( 3-2, Fig. 1 ).
6) Use the led light pointer to identify the exact spot to be measured.
7) The area of the surface to be measured must be larger than the spot
size as determined by the distance to spot size specification.
8) when test value stable then reless the IR thermometer test button
( " Power button " ( 3-2, Fig. 1 ) .
9) The display will show and hold the IR sensing temperture value.
11

10. RECORD OPERATION PROCEDURE
Data Record ( Max., Min. reading )
Remark : the function strobscope is except.
1) The data record function records the maximum and minimum readings.
Press the " REC Button " ( 3-4, Fig.1 ) once to start the Data Record
function and there will be a " REC "Symbol indicator "
will be light.
2) With the " REC " Symbol is light on the display :
a) Press the " REC Button " ( 3-4, Fig. 1 ) once, the "
REC and MAX Symbol indicator will be light ,
and the maximum value will appear on the display.
b) Press the " REC Button " ( 3-4, Fig. 1 ) again, the
" REC and MIN " Symbol indicator will be light ,
and the minimum value will appear on the display.
c) To exit the memory record function, just press the
" REC " button for 1.5 seconds at least. The display will
revert to the current reading, Symbol indicator will be quenched
12

11. BATTERY REPLACEMENT
1) When the left corner of " Lobattery text " indicator
is light, it is necessary to replace the battery. However, in-spec.
measurement may still be made for several hours after
low battery indicator appears before the instrument
become inaccurate.
2) take away the " Battery Cover " ( 3-14, Fig. 1 )
from the instrument and remove the battery.
3) Replace with DC 1.5 V battery ( UM3, AA,
Alkaline/heavy duty ) x 4 PCs, and reinstate the cover.
4) Make sure the battery cover is secured after changing
the battery.
12. RS232 PC SERIAL INTERFACE
The instrument has RS232 PC serial interface via a 3.5
mm terminal ( 3-10, Fig. 1 ).
The data output is a 16 digit stream which can be
utilized for user's specific application.
A RS232 lead with the following connection will be
required to link the instrument with the PC serial port.
Meter PC
(9W 'D" Connector)
Center Pin............................................
Pin 4
(3.5 mm jack plug)
Ground/shield...........................................
Pin 2
2.2 K
resistor
Pin 5
13

The 16 digits data stream will be displayed in the
following format :
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Each digit indicates the following status :
D15 Start Word
D14 4
D13
D12, D11 Annunciator for Display
ft/min = 11 inch/min = 28 m/min = 60
RPM = 27
℃ = 01 ℉ = 02
D10 Polarity
0 = Positive 1 = Negative
D9 Decimal Point(DP), position from right to the
left
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D8 to D1 Display reading, D1 = LSD, D8 = MSD
For example :
If the display reading is 1234, then D8 to
D1 is : 00001234
D0 End Word
RS232 FORMAT : 9600, N, 8, 1
Baud rate 9600
Parity No parity
Data bit no. 8 Data bits
Stop bit 1 Stop bit
14
