PCS Digital PCS digital System 24 Specification sheet

1
System 24 and System 48 Features
Account Code
Forced Verified-When enabled, you must dial an account code in order to
make an outgoing call.
Unforced/Unverified ([ Feat+71])-You may dial an account code for call
tracking purposes.
Alarm-Station Activate: ([ Feat+92 ]) Cancel: ([ Feat+*+92 ])
You may activate your own private alarm on the telephone to remind you
of a special event, appointment, etc.
Answering Machine Operation ([ Feat+64 ])
You can monitor a caller leaving you a message in your voice mail box and
retrieve the caller from voice mail by pressing a button.
Authority Code-Traveling Class of Service ([ Feat+55 ])
Allows a user with the proper class of service to override a restricted phone
to make a Long Distance call.
Automatic Line Selection ([ Feat+95 ]) Cancel: ([ Feat*95 ])
This feature allows you to access a specific outside line or intercom path
automatically when you lift your handset or press the spkr button.
Background Music ([ Feat+52 ])
When activated and your phone is in an idle condition, you can hear music
through the speaker on your phone.
Call Back [ Feat+91 ] Cancel: [ Feat+*91 ]
This feature allows you to queue a station which is busy, in Do Not Disturb,
or idle.

2
Call Forward ([ Feat+2 ])
Display ( Feat+#6 )-when any type of call forwarding is invoked, the LCD
display will Indicate the call forwarding mode at all times.
No Answer-your phone will only forward when there is no answer.
Busy-your phone will only forward when your off-hook.
Busy/No Answer-your phone will forward when you don’t answer or when
your off-hook.
Idle-your phone will forward immediately in an idle condition.
Direct (All Call)-will forward all intercom calls, regardless of busy/idle
state.
Follow Me-you can forward your station to the station you are visiting
from that station with a password.
Cancel-( Feat+2 ) any call forward mode can be canceled by one code from
your station.
Caller Identification (ICLID) ( Feat+#9 )
Name/Number Caller ID-the calling part telephone number ID will be
displayed if available on incoming caller ID calls and the user may
toggle between the number and the name while the call is ringing or after
it is answered.
Calling Number/Name SMDR-if the calling name and number is available,
the name and number will be output in the SMDR record.
Answered Call Table-up to 200 answered calls are stored in a system-wide
Answered/Unanswered Call Table for future review.
Unanswered Call Table-up to 200 unanswered calls are stored in a system-
wide Answered/Unanswered Call Table for future review.
Call Park ([ Feat+73 ])
Allows you to have calls parked at your telephone that can be retrieved
from any telephone in the system.

3
Call Pickup ([ Feat+53 ]) Group Pickup ([ Feat+54 ])
You may answer calls ringing at another station by pressing a code or a
button on your telephone.
Call Waiting ([ Feat+68 ])
You will hear a notification tone through the speaker whenever an inside
caller is waiting and this feature is enabled You may accept or reject the
call.
CO Line Queuing [ Feat+93]
Allows you to queue to a busy CO line and reserves that CO line for use when
it become available.
Conference
Supervised ([ Feat+60 ])-the system allows up to 8 four-party conferences
simultaneously. A maximum of two CO lines in a conference
Unsupervised ([ Feat+77 ])-allows the conference controller to exit a conference
while allowing the two outside CO lines in the conference to continue their
conversation.
Distinctive Ringing-Station ([ Feat+#7 ])
You may choose from four distinctive ringing tones to signal incoming calls.
Do Not Disturb (DND) ([ Feat+4 ])
Allows you to temporarily block and discontinue ringing from incoming CO
calls and intercom calls.
Directory Dial ( Feat+79 )
Enables station users to obtain a directory for up to 200 internal stations and
System Speed Dial Numbers on their Display of the phone for soft key
dialing.
Flash ([ Feat+3 ])
When flash is accessed, the system will generate a timed open loop flash
condition on any CO line.
Feature Button Inquiry ( Feat+#3 )
Allows you to review the programming for feature buttons in an idle condition
on your Display Phone.

4
Feature Button Programming ([ Feat+#3 ])
Allows you to program features and DSS/BLF functionality on the flexible
buttons on your phone.
Headset Mode ([ Feat+9# ])
Allows you to connect a headset to your phone and use the spkr button as the
ON and OFF switch ( toggle between headset and speakerphone modes ).
Hold
Abandon (Loop Supervision)-anytime the system detects a disconnect signal
from the Central Office, an existing Hold condition will be released, freeing
that line for future inbound traffic.
Automatic-([ Feat+94 ]) allows you to skip from line button to line button or
intercom call
to outside call and vise-versa.
Call Answer/Select-allows a user to place and retrieve calls ON and OFF of
hold by simply pressing the Hold button.
Exclusive-([ Feat+HOLD ]) allows the user to place a CO line on a private hold.
Reminder Time-the system provides a programmable timer to remind you that
a call has been left on System or Exclusive Hold.
System-allows the user to place a CO line on hold and any station user can
can take it off hold.
Last Number Redial ([ Feat+8 ])
This feature automatically dials the last number dialed from your phone.
Message
Outgoing-you may send a message waiting, a customized message, or one of
6 pre-programmed messages to other Display Phone users on the system
Executive Notify-( Feat+90 ) a message to inform intercom callers of the reason you
are away from your phone.
Night Service ([ Feat+#2 ])
The system can be programmed in Night Service to change ringing assignments
of the CO lines.

5
One Button Record ([ Feat+72 ])
If you have integrated voice mail system, this feature will allow you to record
Internal and external conversations in your mailbox for future playback.
Paging ([ Feat+50 ])
Internal-paging up to 8 groups of internal stations.
External-one-way, dedicated paging access to a paging amplifier that external
speakers are attached.
Allow/Deny-you can block one-way pages (internal, group, and all page) over
the phone speaker by dialing a code.
Meet Me-any station user paging internally may be answered for a private
meet me connection.
Pause ([ Feat+70 ])
You can insert a pause to generate an intentional delay in dialing on outgoing
calls.
Station Lock/Unlock ([ Feat+97 ])
You can prevent unauthorized outside calling from your telephone by dialing
your password.
Saved Dialed Number ([ Feat+51 ])
Allows you to dial the Save Number at a later time.
Speed Dialing
Station Save: ([ Feat+#1 ]) Dial: ([Feat+1 ])-allows each station user to store up to 20
frequently dialed numbers up to 16 digits in length at their phone.
System-the Attendant Administrator can program up to 80 frequently dialed
numbers that can be accessed form any phone in the system.
Station Feature Status Check ( Feat+#8 )
The Display Key Telephone user can quickly determine the status of all user-
controlled features.
Voice Mail Button ([ Feat+64 ])
Voice Mail button is used to retrieve voice mail messages, and will flash an

6
LED indicator when there are messages.
Voice Over Busy Allow: ( Feat+9* ) Deny: ( Feat+*9* ) [ Feat+56 ]
If your telephone is busy you may still receive a voice announcement from a
calling station allowing you to speak to the person or reject the Voice Over Busy
request.
Auxiliary Jack Port
Allows for any analog device to be connected to the auxiliary jack on the Key
Telephone utilizing the second pair of the station cabling.
Alarm-System
The system administrator may establish a system-wide alarm notifications
through system programming for various events.
Alternate Answering Position
The alternate answering position serves as a back up to the main attendant.
Attendant
One primary attendant is provided in the system for support of necessary
services like Line Recall, Forced Incoming Intercom Call Forward and
Manual Night Service operation. The attendant, with a private password,
is allowed to change the service mode (Day, Night, or Time), Time of Day
settings and System Speed Dial numbers.
Busy Lamp Field
If a button on your phone is programmed as a BLF button and the station
your monitoring for a busy condition goes off hook or is in Do Not Disturb,
the button LED will light red. This same button is used as one-button
Direct Station Selection call button for one button dialing of an internal
station.
Camp On Busy Station
Privately alerting a busy station for immediate consultation.
Class of Service (Day/Night)
The system provides eight COS for assignment of outside line dialing
privileges.
CO Line Group Assignment
The system provides four CO Line Groups for assignment of specific CO

7
lines.
CO Line Pool
The CO Line Pool allows random CO line outgoing access and becomes a
virtual Answer button, with illumination, for receiving incoming or transferred
calls.
CO Line Signaling
Incoming CO line calls are indicated by a flashing red LED and distinctive
ring tone from the key telephone speaker.
CO Line Type Assignment
Each CO line can be assigned as CO,PBX or OPEN.
Dial Pulse to DTMF Conversion
When a CO line is set to pulse (rotary) dialing, the digits following [*] will
be sent in DTMF tone mode.
Do Not Disturb Override
From a 31 Btn Display Phone, you may override a station in DND if you have
a higher class of service.
Direct Inward System Access (DISA)
This feature allows you to remotely access system features such as System
Speed Dial, CO Line Access , CO Line-to-CO Line Conferencing, and
Intercom dialing.
Drop Time-Out
When enabled, any outgoing CO line will be automatically timed and then
dropped, after the system warning tone time has expired
DSS Console
One 50 Btn. DSS console may be assigned to a station. Features and DSS/BLF
buttons assignment.
Emergency Numbers
The System 24 and 48 System Speed Dial feature provides use of emergency
number calling at a station that may be otherwise restricted from dialing. All
80 System Speed Dial bins functionally override a station COS.

8
End-to-End Signaling
This feature allows digital phones to generate in-band DTMF tones on ICM
calls to an on-site voice mail system.
External Call Forward
Allows for an incoming CO call to forward to a programmed CO Line that
was programmed in Speed Bin 99.
Flexible Line Assignment
Stations may be allowed to answer or retrieve from hold, specific CO lines
assigned in system programming.
Flexible Ring Assignments
A station can be programmed to ring for any, or all incoming CO lines.
Forced Intercom Call Forward
Tone ringing intercom calls can be immediately forwarded to the attendant
by pressing the DND button.
Forced Tone Ringing
Allows you to change the station you are calling that is in the Voice Announce
mode to the Tone Ringing mode by pressing the *key.
Hour Mode Selection
Standard 12-hour time or military 24-hour time can be selected for common
display at all Display Phones.
Hunt Groups-Stations
Up to 8 hunt groups may be assigned. Hunting is always in a linear fashion.
each group can have up to 24 members.
I-Hold Indication
Allows you to easily distinguish between a call you placed on hold at your
phone and calls placed on hold at other phones by the use of red and green
LEDs.
I-Use Indication
When you are using a CO line, the associated lamp will light green at your
phone and red at other phones.

9
Intercom Call
All intercom calls are made by dialing another station number or by depressing
their DSS/BLF button.
Loud Bell Control
The system provides one dry contact closure for interface to an external Loud
Bell device which is associated with an incoming CO line ringing.
Message Waiting
A busy or unattended station may be notified of a call attempt via the Message
Waiting feature.
Music-on-Hold
Any intercom or CO line call placed on hold will hear music, if the system is
equipped with an external music source.
Mute
During a conversation, you may prevent the distant party from hearing your
voice by depressing the Mute button.
Muted Ringing
While the user is on another call, incoming ICM/CO line calls will automatically
ring at a muted lower level at that station.
Name in Display
A station user can program their name in the display of their phone that will
also appear in the display of the station they are calling.
On Hook Dialing
You may make outgoing calls without lifting the handset of your phone.
PBX Compatibility
Any CO line may be programmed as a PBX type facility.
Privacy
Provides privacy on intercom and CO line calls.
Privacy Release
You may on a system-wide basis to allow up to three users to join a conversation
on busy lines.

10
Private Line
You can program one or more CO lines for access by only one station.
Recall (Transfer Recall)
A transfer CO line call that goes unanswered for a specific time will recall back
to the originating station.
Reminder Tones
If you have Do Not Disturb or Call Forward enabled, you will hear a Reminder
Tone whenever you access intercom dial tone.
Ringing Line Priority
Automatically connects incoming calls (intercom, camped on CO, recalled CO
transferring CO, incoming CO, and incoming intercom call) based on a
predetermined priority.
Station Groups
The system provides eight station groups for partitioning the system into
separate departments or related features (Call Pickup and internal paging).
Station Numbering Plan
The System 24 has 2-digit intercom station numbers and the System 48 has
3-digit intercom station numbers.
Station Message Detail Recording (SMDR)
This allows the system administration to track all incoming and outgoing CO
Line calls on an SMDR report.
System Time
The system provides a built-in clock to track System Time for certain features
such as System Night Service Mode Change, SMDR, Alarm Clock Check, etc.
Toll Restriction
The system provides sophisticated monitoring of digits dialed on a CO lines.
If the digits dialed are allowed, the call will go through. If the digits are not
allowed the call will be denied.
Tone Detector
The system provides one tone detector which is used for certain features to
detect the call status of the CO line call in progress.

11
Tone/Inter-Digit Duration
Depending on the type of CO, and the customer specialized dialing requirements,
the DTMF ON time and INTER-DIGIT time may be modified for dialing.
Transfer
Allows you to transfer a CO call screened, unscreened, and one-button.
Voice Mail Integration
An ancillary voice mail device may be connected to the system, and you can
program a button for access to this feature with indication of voice messages.
Voice Announce (Hands-Free or Privacy)
Provides the ability to receive incoming intercom calls through the speaker of
the phone and reply back without lifting your handset in the hands-free mode.
If you are in the privacy mode, you can hear the caller, but they cannot hear you.
Volume Control
Allows you to adjust the volume levels for five functions: Background Music,
Ringing, Handset, Speaker, and Headset.
Warning Tone
A system warning tone may be heard repeatedly on specific stations that have
exceeded a preset time limit on outgoing calls.
4/10/03 REV. 3
