peerless-AV PLAV70-UNL-S Guide

Models: PLAV70-UNL,
PLAV70-UNL-S, PLAV70-UNLP,
PLAV70-UNLP-S
Installation and Assembly - Universal Articulating
Swivel Double-Arm for 42" - 95" Plasma Screens
ISSUED: 06-05-06 SHEET #: 202-9142-10 (2013-03-17)
2300 White Oak Circle • Aurora, Il 60502 • [phone] • Fax: [phone] • www.peerless-av.com
Max UL Load Capacity:
200 lb (91 kg)

2 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
Tools Needed for Assembly
•stud finder ("edge to edge" stud finder is recommended)
• drill
• 7/32" drill bit for wood studs
• 3/8" masonry drill bit for concrete
• 7/16" socket wrench with extension (recommended)
• level
• phillips screwdriver
• 3/4" open-end wrench
Accessories
•External Wall Plate (WSP716, WSP716-S, WSP724,
WSP724-S) (Metal Stud not evaluated by UL)
NOTE: Read entire instruction sheet before you start installation and assembly.
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US
customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact
your local distributor.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
• Never exceed the Maximum Load Capacity. See page one.
• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of
an "edge to edge" stud finder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws firmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal
injury.
• This product was designed to be installed on the following wall construction only;
WALL CONSTRUCTION HARDWARE REQUIRED
• Wood Stud Included
•Wood Beam Included
•Solid Concrete Included
•Cinder Block Included
•Metal Stud Do not attach except with Peerless Metal Stud Accessory Kit - ACC415;
(not evaluated by UL)
•Brick Contact Qualified Professional (not evaluated by UL)
•Other or unsure? Contact Qualified Professional
WARNING

3 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
B
Some parts may appear slightly different than illustrated.
A
DEF
G
H
C
I
J
KL
NOPT
Q
MR S
U
V
Parts List PLAV70-UNL
PLAV70-UNLP
Part #
PLAV70-UNL-S
PLAV70-UNLP-S
Part #
Description Qty
Awall plate 1 201-1040 201-4040
Btilt-roll assembly 1 201-1042 201-4042
Carm assembly 1 201-1044 201-4044
Dwall support arm axle 2 201-1041 201-1041
Evinyl trim 3 600-1012 600-1012
FM10 x 15mm screw bolt 8 520-9262 520-9262
G.505 x .062" nylon washer 1 540-1074 540-1074
Htilt adjustment knob 1 560-0108 560-0108
Icarriage bolt 3/8"-16 x 3.25" 1 520-1315 520-1315
J1.525 x .062" delrin washer 4 540-1070 540-1070
K#8-32 x .375" socket screw 2 520-1210 520-1210
Lplastic finishing cap 6 590-1123 590-1123
Mholding pin 2 580-1166 580-1166
Nretainer plug 2 590-1007 590-1007
O5/16 x 3" wood screw 8 520-1243 520-1243
P.250 x .068" washer 8 540-1063 540-1063
Q9/64" allen wrench 1 560-9728 560-9728
Rcable management clips 8 590-1166 590-1166
Scable tie 8 590-1168 590-1168
T36" polyester mesh sleeve 2 600-1015 600-1015
U6mm allen wrench 1 560-9716 560-9716
Vconcrete anchor 6 590-0321 590-0321

4 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
AA BB CC
Phillips Adapter Bracket Fasteners
M5 x 12 mm (4)
(520-1027)
M5 x 25 mm (4)
(520-9543)
M6 x 12 mm (4)
(520-1128)
M6 x 25 mm (4)
(520-1208)
.75" spacer (4)
(540-1059)
Multi-washer (4)
(580-1398)
M8 x 25 mm (4)
(520-1031)
M8 x 12 mm (4)
(520-9571)
M5 x 25mm (4)
(520-1122)
M5 x 12mm (4)
(520-1064) M6 x 12mm (4)
(520-1050)
M6 x 25mm (4)
(520-1211) M8 x 25mm (4)
(520-1101)
M8 x 12mm (4)
(520-1724) .75" spacer (4)
(540-1059)
Multi-washer (4)
(580-1398)
Security Adapter Bracket Fasteners
Parts List PLAV70-UNL
Part # PLAV70-UNL-S Part # PLAV70-UNLP Part # PLAV70-UNLP-S Part #Description Qty
AA adapter bracket 1 201-1110 201-4110 201-1110 201-4110
BB shallow adapter bracket 2 202-1655 202-4655 202-1656 202-4656
CC 4mm allen wrench 1 560-9646 560-9646 560-0072 560-0072

5 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
Wall plate (A) can be mounted to two studs that are 16" apart. Use a stud finder to locate the edges of the studs.
Use of an edge-to-edge stud finder is highly recommended. Based on their edges, draw a vertical line down each
stud’s center. Place wall plate on wall as a template. The top mounting slots should be located .43" below the
desired screen center. Level plate, and mark the center of the eight mounting holes. Make sure that the mounting
holes are on the stud centerlines. Drill eight 7/32" dia. holes 3" deep. Make sure that the wall plate is level, secure it
using eight 5/16 x 3" wood screws (O) and washers (P).
Skip to step 2 on page 7.
1
Installation to Wood Stud Wall
P
A
O
• Installer must verify that the supporting surface will safely support the combined load of the equipment and all
attached hardware and components.
• Tighten wood screws so that wall plate is firmly attached, but do not overtighten. Overtightening can damage the
screws, greatly reducing their holding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Make sure that mounting screws are anchored into the center of the stud. The use of an "edge to edge" stud finder
is highly recommended.
• Hardware provided is for attachment of mount through standard thickness drywall or plaster into wood studs. Install-
ers are responsible to provide hardware for other types of mounting situations (not evaluated by UL).
WARNING

6 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
Use wall plate (A), making sure that it is level, as
a template to mark holes. The top mounting slots
should be located .43" below the desired screen
center. Use the masonry bit to drill 3/8" (10mm)
dia. holes to a minimum depth of 3" (76 mm). Insert
anchors (V) in holes flush with wall as shown (right).
Place wall plate (A) over anchors (V) and secure
with 5/16 x 3" wood screws (O) and washers (P).
1
Installation to Solid Concrete or Cinder Block Wall
A
O
P
V
• When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" of actual concrete
thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a
solid part of the block, generally 1" minimum from the side of the block. Cinder block must meet ASTM C-90
specifications. It is suggested that a standard electric drill on slow setting is used to drill the hole instead of a
hammer drill to avoid breaking out the back of the hole when entering a void or cavity.
• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
WARNING
• Tighten wood screws so that wall plate is firmly at-
tached, but do not overtighten. Overtightening can
damage screws, greatly reducing their holding power.
• Never tighten in excess of 80 in • lb (9 N.M.).
WARNING
• Always attach concrete expansion anchors directly
to load-bearing concrete.
• Never attach concrete expansion anchors to con-
crete covered with plaster, drywall, or other finishing
material. If mounting to concrete surfaces covered
with a finishing surface is unavoidable (not evaluated
by UL), the finishing surface must be counterbored
as shown below. If plaster/drywall is thicker than
5/8", custom fasteners must be supplied by installer
(not evaluated by UL).
WARNING
1
3
2
V
Drill holes and insert anchors (V).
Place plate (A) over anchors (V) and secure with screws (Q).
Tighten all fasteners.
A
V
Q
concrete
surface
CUTAWAY VIEW
INCORRECT CORRECT
wall
plate wall
plate
plaster/
drywall plaster/
drywall
concrete concrete

7 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
To route cables through cord management
channels: Slide one mesh sleeve (T) over
each cable. Use cable ties (S) to tighten mesh
sleeves to cables.
Pull cords through cord management
channels, leaving enough slack to allow full
range of movement for swing arm assembly
(C) as shown if figure 3.1.
3
3-1
T
fig 3.1
To route cables using cable management clips:
Snap eight cable management clips(R) into both
swing arms (C) as shown in figure 3.2.Cable ties
(S) are used with clips for cord management.
Slide one mesh sleeve (T) over each cable. Use
cable ties (S) to tighten mesh sleeves to cables.
3
CORD
MANAGEMENT
CHANNEL C
3-1
Note: There are three mounting positions.
The center position is shown right. Arm
assemblies must be mounted with one
mounting hole separating them. Slide washers
(J) over wall support arm axles (D). Next, insert
plastic caps (N) into axles. Then, insert holding
pins (M) into axles. See detail 1.
Note: Fit of axles (D) into wall plate (A) and arm
assembly (C) will be tight. Gently tap into place
with a hammer if necessary.
Insert socket cap screws (K) into hole at bottom
of wall support arm axles (D) as shown in detail 3.
Tighten screw using 9/64" allen wrench (Q).
Place arm assembly (C) with washers (J) into
wall plate (A). Insert axle assemblies shown in
detail 1 through wall plate (A), arm assembly (C),
and washers (J). Lock axles in place by aligning
holding pins (M) with notches shown in detail 2.
2
2-1
2-2
N
J
D
M
A
J
C
DETAIL 3
NOTCH
DETAIL 2
DETAIL 1
R
S
C
fig 3.2
• If you are uncertain that product is properly installed, call customer care.
WARNING
KD

8 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
Insert and tape carriage bolt (I) into top hole of tilt-roll assembly (B). Attach tilt-roll assembly to adapter bracket
(AA) with four M10 socket screws (F). Tighten screws using 6 mm allen wrench (U).
• Do not overtighten screws! Overtightening may hin-
der roll option.
CAUTION
BI
F
A
L
E
5
Attach two pieces of vinyl trim (E) to wall plate (A). Next, attach one piece of vinyl trim to bottom of swivel box on
arm assembly (C).
Insert one finishing cap (L) into each unused hole of wall plate (A).
4-1
SWIVEL BOX
C
AA
4

9 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
Insert two M10 screws (F) into swivel box on arm assembly (C) as shown. Leave approx. 1/4" of exposed thread.
C
.25" F
• After tilt is adjusted, all fasteners must be tightened.
Failure to do so will result in damage to the mount.
CAUTION
SWIVEL BOX
6
Hook tilt-roll assembly (B) onto M10 screws (F).
Insert carriage bolt (I) into slot of swivel box as
shown in figure 6.1. Install nylon washer (G) and tilt
adjustment knob (H).
Install remaining two M10 screws (F) as shown in
figure 6.2. HAND TIGHTEN all four M10 screws to
allow for tilt adjustment. Remove tape from carriage
bolt (I). For tilt adjustment, gently push back on the
top of plasma to relieve pressure on knob. Adjust tilt
to desired position and tighten tilt adjustment knob
(H), then securely tighten all four M10 screws (F)
using 6 mm allen wrench (U).
6-1
6-2
Adapter bracket not shown for clarity. Adapter bracket not shown for clarity.
I
B
F
I
B
F
H
SWIVEL BOX fig 6.1 fig 6.2
G
• Use an assistant or mechanical lifting equipment to safely lift and position the plasma TV.
WARNING

10 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
Note: "X" dimensions should be equal.
• Tighten screws so adapter brackets are firmly attached. Do not tighten with excessive force. Overtightening can
cause stress damage to screws, greatly reducing their holding power and possibly causing screw heads to become
detached. Tighten to 40 in. • lb (4.5 N.M.) maximum torque.
• If screws don't get three complete turns in the screen inserts or if screws bottom out and bracket is still not tightly
secured, damage may occur to screen or product may fail.
WARNING
Installing Adapter Brackets
To prevent scratching the screen, set a cloth on a flat, level surface that will support the weight of the screen. Place
screen face side down. Refer to screen manufacturers instructions or customer service, for removing any knobs,
base, cover, or screw(s) on the back of the screen to prepare mounting. These need to be removed to allow the
adapter brackets to be attached. Select the small, medium, large or extra large screws from the baffled fastener
pack then attach adapter brackets (BB) to screen following figure 7.1 or 7.2.
NOTE: Top and bottom mounting holes on screen must be used for attaching brackets. Verify that all holes are
properly aligned, and then tighten screws using a phillips screwdriver.
BB CENTER
BRACKETS
VERTICALLY
ON BACK OF
SCREEN
X
X
NOTE: For flat back screens proceed to step 7-1. For bump-out or recessed back screen skip to step 7-2.
MEDIUM HOLE FOR M5 SCREWS
LARGE HOLE FOR M6 SCREWS
Notes:
• The number of fasteners used will vary, depending upon
the type of screen.
• Multi-washers and spacers may not be used, depending
upon the type of screen.
• Use the corresponding hole in the multi-washer that
matches your screw size as shown.
MULTI-WASHER
7

11 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
Begin with the shortest length screw, hand thread through multi-washer and adapter bracket into display as
shown below. Screw must make at least three full turns into the mounting hole and fit snug into place. Do not
over tighten. If screw cannot make three full turns into the display, select a longer length screw from the baffled
fastener pack. Repeat for remaining mounting holes, level brackets and tighten screws.
NOTE: Spacers may not be used, depending upon the type of display.
Begin with longer length screw, hand thread through multi-washer, adapter bracket and spacer in that order into
display as shown below. Screw must make at least three full turns into the mounting hole and fit snug into place.
Do not over tighten. If screw cannot make three full turns into the display, select a longer length screw from the
baffled fastener pack. Repeat for remaining mounting holes, level brackets and tighten screws.
For Flat Back Display
For Bump-out or Recessed Back Display
7-1
7-2
If you have any questions, please call Peerless customer care at 1-800-865-2112.
If you have any questions, please call Peerless customer care at 1-800-865-2112.
DISPLAY
MULTI-WASHER
SCREW
ADAPTER
BRACKET
(BB)
fig. 7.2
SPACER
fig. 7.1
ADAPTER
BRACKET
(BB)
DISPLAY
MULTI-WASHER
SCREW

12 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
Mounting and Removing Flat Panel Screen
Refer to mount instruction sheet for attachment of adapter bracket to mount.
Hook adapter brackets (BB) onto adapter bracket (AA), then slowly swing screen in as shown. Turn screws
clockwise at least six times to prevent screen from being removed as shown in detail 4. Tighten using allen wrench
(CC).
Screen can be adjusted horizontally if desired.
Note: To lock the screen down, tighten screws to adapter bracket as shown in detail 4.
To remove screen from mount, loosen screws, swing screen away from mount, and lift screen off of mount.
8
• Always use an assistant or mechanical lifting equipment to safely lift and position the plasma television.
WARNING
AA
BB
DETAIL 4
SAFETY/SECURITY
SCREWS
AA
BB

13 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
Position of screen may be adjusted vertically up to .79" in each direction by doing the following:
• To raise screen, turn hex nut shown in figure 10.1 clockwise with 3/4" open-end wrench (not provided).
• To lower screen, turn hex nut shown in figure 10.1 counterclockwise with 3/4" open-end wrench (not provided).
If it is too difficult to adjust roll of plasma, loosen
screws shown in figure 9.1 using a phillips
screwdriver.
IMPORTANT! Do not loosen or tighten screws
more than 1/8 turn.
Depending on the specific size & weight of the plas-
ma, articulating swing arm may be angled at different
positions, causing plasma to appear to lean sideways
at different articulating positions. Tilt-roll assembly (B)
allows plasma to be manually adjusted, so plasma
can be horizontal at all positions. To adjust, gently
rotate plasma by hand to desired position.
99-1
ARTICULATING
ARM
PLASMA
10
fig 9.1
HEX
NUT
fig 10.1
© 2013, Peerless Industries, Inc. All rights reserved.
All other brand and product names are trademarks or registered trademarks of their respective owners.
ROLL
ADJUSTMENT
SCREWS

14 of 14 ISSUED: 06-05-06 SHEET #: 202-9142-10 (2014-03-17)
© 2014 Peerless Industries, Inc.
Peerless Industries, Inc. (“Peerless”) warrants to original end-users of Peerless® products will be free from defects in material and workmanship, under normal
use, for a period of five years from the date of purchase by the original end-user (but in no case longer than six years after the date of the product’s manufacture).
At its option, Peerless will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty.
In no event shall the duration of any implied warranty of merchantability or fitness for a particular purpose be longer than the period of the applicable
express warranty set forth above. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
This warranty does not cover damage caused by (a) service or repairs by the customer or a person who is not authorized for such service or repairs by Peerless,
(b) the failure to utilize proper packing when returning the product, (c) incorrect installation or the failure to follow Peerless’ instructions or warnings when installing,
using or storing the product, or (d) misuse or accident, in transit or otherwise, including in cases of third party actions and force majeure.
In no event shall Peerless be liable for incidental or consequential damages or damages arising from the theft of any product, whether or not secured
by a security device which may be included with the Peerless® product. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
This warranty is in lieu of all other warranties, expressed or implied, and is the sole remedy with respect to product defects. No dealer, distributor, installer or other
person is authorized to modify or extend this Limited Warranty or impose any obligation on Peerless in connection with the sale of any Peerless® product.
This warranty gives specific legal rights, and you may also have other rights which vary from state to state.
LIMITED FIVE-YEAR WARRANTY
www.peerless-av.com
Patented. Utiltiy Patent No. 7,487,943; 8,348,212; 8,517,322.
