Pentair BAA A390-D.03 Select User manual

created on/by 22.03.2017 Graf H.
reviewed on/by
22.03.2017
L:\documentation\08-Mitarbeiter\01_Graf_Holger\Betriebsanleitnug in Bearbeitung\ATEX\baa_a390_d_03_sel_en_v504_201703.docx
1
BAA A390-D.03 Select
Version 5.04
SVP aseptic change-over valve
DN 010 – 020
OD 0.50" – 0.75"; ISO 008 – 015
diaphragm – O-ring
pneum. operated
Operating instructions

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
2
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
1. Contents
1. Contents ...................................................................................................................................................... 2
2. Safety instructions ...................................................................................................................................... 4
2.1. General ................................................................................................................................................... 4
2.2. Maintenance ........................................................................................................................................... 4
2.3. Modification of the SVP aseptic change-over valve ................................................................................ 5
2.4. SVP aseptic change-over valves with feedback ..................................................................................... 5
2.5. Cleaning, flushing, sterilization ............................................................................................................... 5
2.6. Storage ................................................................................................................................................... 5
2.7. Place of use, Environment ...................................................................................................................... 6
2.8. Lifespan .................................................................................................................................................. 6
2.9. ATEX-usage ........................................................................................................................................... 6
2.10. Operation ................................................................................................................................................ 6
2.11. Spare parts ............................................................................................................................................. 6
2.12. Risk assessment .................................................................................................................................... 6
3. Technical data ............................................................................................................................................. 7
3.1. Dimensions ............................................................................................................................................. 7
3.1.1. Pneum. SVP aseptic change-over valves ....................................................................................... 7
3.2. Valve use ................................................................................................................................................ 8
3.3. Surfaces ................................................................................................................................................. 8
3.4. Materials ................................................................................................................................................. 8
3.5. Allowed operating media, pressures and temperatures .......................................................................... 8
3.6. CIP-Cleaning .......................................................................................................................................... 10
3.7. Control systems ...................................................................................................................................... 10
3.8. Electrical and pneumatic connections .................................................................................................... 11
3.9. Control air ............................................................................................................................................... 12
4. Valve function .............................................................................................................................................. 13
4.1. SVP aseptic change-over valve air opened – spring closed .................................................................. 13
4.2. SVP aseptic change-over valve spring opened – air closed .................................................................. 13
4.3. SVP aseptic change-over valve air opened – air closed ........................................................................ 14
4.4. Flow directions (seat area) ..................................................................................................................... 14
5. Valve connection piping ............................................................................................................................. 15
5.1. Installation position ................................................................................................................................. 15
5.1.1. SVP aseptic change-over valve with spring-return-function
(Operating mode: Air to open – Spring to close or Spring to open – Air to close) ........................... 15
5.1.2. SVP aseptic change-over valve without spring-return-function
(Operating mode: Air to open – Air to close) ................................................................................... 15
5.2. Valve connections .................................................................................................................................. 15
5.3. Installation instructions for the SVP aseptic change-over valve .............................................................. 15
6. Welding and assembly instructions .......................................................................................................... 16
6.1. General remarks ..................................................................................................................................... 16
6.2. Delivery condition of SVP aseptic change-over valve ............................................................................. 16
6.3. Installation instructions ........................................................................................................................... 16
6.3.1. Installation space ............................................................................................................................. 16
6.3.2. Installation ....................................................................................................................................... 16

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
3
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017 en
6.4. Welding instructions ............................................................................................................................... 16
6.4.1. Area of application .......................................................................................................................... 16
6.4.2. Welding technique ........................................................................................................................... 16
6.4.3. Type of welding ............................................................................................................................... 16
6.5. Weld preparation .................................................................................................................................... 16
6.6. Welding ..................................................................................................................................................16
6.7. Weld filler materials ................................................................................................................................ 17
6.8. Weld finishing ......................................................................................................................................... 17
6.8.1. Interior ............................................................................................................................................. 17
6.8.2. Exterior ............................................................................................................................................ 17
6.9. Cleaning of the valve .............................................................................................................................. 17
6.10. Valve assembly ...................................................................................................................................... 17
7. Dismantling – Assembly ............................................................................................................................. 18
7.1. Preparatory measures for dismounting - mounting ................................................................................ 18
7.2. SVP aseptic change-over valves with feedback ..................................................................................... 19
7.3. Spare parts ............................................................................................................................................. 19
7.4. Assembly of joint clamp .......................................................................................................................... 20
7.5. Mounting tools ........................................................................................................................................ 20
7.6. Replacement of product-contacted seals ............................................................................................... 21
7.6.1. Pneum. SVP aseptic change-over valve air to open - spring to close - diaphragm – O-ring ......... 21
7.6.2. Pneum. SVP aseptic change-over valve spring to open - air to close - diaphragm – O-ring ......... 23
7.6.3. Pneum. SVP aseptic change-over valve air to open - air to close - diaphragm – O-ring ............... 25
7.7. Assembly O-ring ..................................................................................................................................... 27
7.7.1. Removal .......................................................................................................................................... 27
7.7.2. Installation ....................................................................................................................................... 27
7.8. Pneum. actuator ..................................................................................................................................... 28
7.8.1. Operating mode air to open - spring to close .................................................................................. 28
7.8.2. Operating mode spring to open - air to close .................................................................................. 29
7.8.3. Mode of operation air to open - air to close ..................................................................................... 30
7.9. Retrofitting of the process control unit IntelliTop ®2.0
to the pneumatic SVP aseptic change-over valve .................................................................................. 31
8. Start-up ......................................................................................................................................................... 32
8.1. Functional test of SVP aseptic change-over valve ................................................................................. 32
8.1.1. Pneumatic version ........................................................................................................................... 32
8.2. Leak test of SVP aseptic change-over valve .......................................................................................... 32
9. Maintenance ................................................................................................................................................. 32
9.1. Preparatory maintenance measures ...................................................................................................... 32
9.2. Inspection ............................................................................................................................................... 33
9.3. Preventive maintenance ......................................................................................................................... 33
9.3.1. Process contact seals ..................................................................................................................... 33
9.3.2. Actuator seals ................................................................................................................................. 33
10. Disorder - trouble shooting ....................................................................................................................... 34
11. Disposal ........................................................................................................................................................ 34
12. List of spare parts ........................................................................................................................................ 35
12.1. SVP aseptic change-over valve .............................................................................................................. 35
12.2. Pneum. actuator ..................................................................................................................................... 36
12.2.1. Mode of operation air to open– spring to close, spring to open– air to close .................................. 36
12.2.2. Mode of operation air to open - air to close ..................................................................................... 36
13. Service adress ............................................................................................................................................. 38

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
4
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
2. Safety instructions
This symbol indicates a direct and immediate danger to the life and health
of persons!
Failure to observe these warnings may result in serious damage to health,
up to and including life-threatening injuries which may or may not be fatal.
This symbol indicates a potentially hazardous situation!
Failure to observe these warnings may result in less serious injuries, or
damage to material property.
This sign draws your attention to important information about
the proper use
of the SVP aseptic change-over valve. It is essential for this information to be
observed.
Failure to observe these instructions may cause malfunctions in the valve or
in its vicinity.
2.1. General
⇒SVP aseptic change-over valves from Pentair Südmo GmbH are manufactured in accordance with state-of-the-art standards and the recog-
nized safety rules. However, these SVP aseptic change-over valve may constitute a hazard if used by operating personnel improperly or for a
purpose other than the intended one. This may result in a risk to life and limb of the user or of third parties, or cause damage to the SVP asep-
tic change-over valve and other material propertyn.
⇒Each person concerned with installation, commissioning, operation and maintenance of this SVP aseptic change-over valve must have read
and understood the complete operating instructions, and in particular all safety instructions.
⇒In addition to these operating instructions, the following are of course also valid:
pertinent accident prevention regulations
generally recognized safety rules
national regulations of the country of use
in-house work and safety regulations.
2.2. Maintenance
⇒Any maintenance and service work on the SVP aseptic change-over valves must be carried out by specially trained, qualified personnel only.
Training or instruction in accordance with the current safety standards.
For systems with explosion protection: training or instruction or authorization to carry out work on systems
subject to explosion hazards (observe ATEX regulations).
Caution
Danger

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
5
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017 en
⇒Obtain information on possible risks that could be caused by residues of the operating medium and take appropriate measures if necessary
(safety gloves, safety goggles, etc.), before carrying out maintenance and service work on the SVP aseptic change-over valve.
⇒Prior to carrying out any maintenance and service work, make sure that:
the work is only carried out in a depressurized state and with the media supply shut off.
the SVP aseptic change-over valve and all piping elements leading to the valve have been drained and cleaned or flushed.
the fittings have cooled down.
the system cannot be started by a third person.
the pressure build-up which may form in sealed pipelines is counteracted.
disassembly - assembly of the SVP aseptic change-over valve are carried out according to the installation instructions (see chapter 7
"Disassembly - Assembly").
the power supply has been disconnected.
the SVP aseptic change-over valve is removed from the piping section, if possible.
⇒Avoid any working method which could impair the safety and function of the SVP aseptic change-over valve.
2.3. Modification of the SVP aseptic change-over valve
⇒ Operate the SVP aseptic change-over valve according to the designated use
and safety and hazard instructions.
⇒ Operate the SVP aseptic change-over valve in perfect technical condition on-
ly.
⇒ Modifications to the SVP aseptic change-over valve are not permitted.
2.4. SVP aseptic change-over valves with feedback
2.5. Cleaning, flushing, sterilization
⇒The operator of the plant in which the SVP aseptic diaphragm valve is installed must draw up operating instructions
so that all the information required for the operation of the valve is available to the operating and maintenance per-
sonnel.
⇒The start-up and operating personnel must wear protective clothing (gloves and safety goggles) during the clean-
ing, flushing and sterilization work.
2.6. Storage
⇒Store the valve in a dry place by room temperature protected against external influences.
⇒Keep away from direct solar radiation
⇒Prior to handling (disassembly of the body / activation of the actuators) temporarily store the valves in a dry place for
at least 24 hours at a temperature ≥ 5° C.
Don’t put fingers into check-back signal.
⇒ Accident risk.
Fingers can be crushed or cut off.
Danger
Danger

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
6
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
2.7. Place of use, Environment
⇒The described SVP aseptic change-over valves are primarily used in breweries, in the food and beverage industry
as well as in the pharmaceutical and cosmetic industry.
⇒The valves have to be operated in rooms with acid and caustic proof floors.
⇒The rooms of operation have to be equipped with lights, which enables at all time to read clearly the labels and se-
curity advices.
⇒The rooms of operation have to be free of dust.
⇒Do not leave the SVP aseptic change-over valves outdoors.
⇒Permissible ambient temperature 0° C to +55° C.
⇒The atmospheric circumstanced (Air temperature, Air moisture and air movement) in the operating rooms shall not
lead to freeze over the moveable parts.
2.8. Lifespan
⇒The foreseeable lifespan of the SVP aseptic vavles are 15 years..
⇒The maximum switching cycles of the SVP aseptic change-over valves are 500.000.
2.9. ATEX-usage
The operator of the SVP aseptic change-over valves has to make sure,
⇒ that max. allowable surface temperature gets not exceeded, due to hot me-
dia treatment.
⇒ that the ignition temperature gets not exceeded, due to hot media in the
pipework.
⇒ that the plant is grounded, where the SVP-aseptic change-over valves get
used.
The SVP aseptic change-over valve complies with the EC directives 2014/34/EU.
The applied standards which are used to demonstrate compliance with the Directives are listed in the EC Declaration
of Conformity. This may be requested from Pentair Südmo.
The specifications on the respective rating plate apply to the respective SVP aseptic change-over valve.
Ignition protection type:
ATEX 0123 EX II 2GD IIB TX
2.10. Operation
⇒ Never touch the valve or piping system when hot products are in pro-
cessing or during sterilization.
⇒ Observe strictly the technical data.
⇒ We cannot be held liable for an incorrect use of the valve
2.11. Spare parts
Use original spare parts only.
⇒ For original spare parts, refer to the enclosed spare parts list (see chapter
12 "Spare parts list").
⇒ Perfect functioning of the SVP aseptic change-over valve is only guaranteed
when using original spare parts.
2.12. Risk assessment
⇒All safety instructions in these operating instructions result from the risk assessment for the SVP aseptic change-
over valve.
Danger
Caution
Danger

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
7
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017 en
3. Technical data
3.1. Dimensions
3.1.1. Pneum. SVP aseptic change-over valves
DN Tube A B C øD E F G L N kg
(Valve upper
part)
DN 010 ø13 x 1.50 45,0 45,0 233,0 64,5 10,0 230 40,0 223,0 13,0 1,5
DN 015 ø19 x 1.50 45,0 45,0 233,0 64,5 10,0 230 40,0 223,0 13,0 1,5
DN 020 ø23 x 1.50 45,0 45,0 233,0 64,5 10,0 230 40,0 223,0 13,0 1,5
OD 0.50" ø12.7 x 1.65 45,0 45,0 233,0 64,5 10,0 230 40,0 223,0 13,0 1,5
OD 0.75" ø19.05 x 1.65 45,0 45,0 233,0 64,5 10,0 230 40,0 223,0 13,0 1,5
ISO 008 ø13.5 x 1.60 45,0 45,0 233,0 64,5 10,0 230 40,0 223,0 13,0 1,5
ISO 010 ø17.2 x 1.60 45,0 45,0 233,0 64,5 10,0 230 40,0 223,0 13,0 1,5
ISO 015 ø21.3 x 1.60 45,0 45,0 233,0 64,5 10,0 230 40,0 223,0 13,0 1,5
Dismantling dimension

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
8
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
3.2. Valve use
Application change-over valve
For use in aseptic processes
Shut-off tightness sealing DN Shut-off
tightness Function actuator
diaphragm – O-ring DN 010 – 020
OD 0.50ʺ - 0.75ʺ
ISO 008 – 015
10 bar max. air opened – spring closed
spring opened – air closed
air opened – air closed
3.3. Surfaces
Surfaces in contact with product Ra≤0,8 µm
Optional: E-polished
Surfaces not in contact with product: bright-turned,
Ra≤1,6 µm
3.4. Materials
Stainless steel
In contact with product 1.4404 (AISI 316L)
Not in contact with product 1.4301 (AISI 304), 1.4305 (AISI 304)
Seal materials
⇒P3(diaphragm)
The application parameters and resistance depend on the applied seal
quality in the valve disc.
3.5. Allowed operating media, pressures and temperatures
Media Allowed
operating pressure Minimum allowed operating temperature Maximum allowed operating temperature
EPDM
Water, beverages, pumpable food and cosmet-
ics (liquids, emulsions, flowing suspensions) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point
+95° C (203°F) bzw.
at least 1 K below the evaporation
temperature at atmospheric pressure
Aqueous cleaning base
(based on sodium hydroxide solution, < 5 %*) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point +80° C (176°F)
Aqueous cleaning acid
(based on nitric acid, < 3 %*) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point +40° C (104°F)
Aqueous disinfectants
(based on peracetic acid, < 0.7 %*) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point +30° C (86°F)
Water vapor
< 2,7 bar abs (39,1 psi) bzw.
short-term (15 - 20 min.)
< 4,7 bar abs (68,1 psi)
----------
continuous +130° C (266°F)
short-term (15 - 20 min.) +150° C
(302°F)

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
9
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017 en
Media Allowed
operating pressure Minimum allowed operating temperature Maximum allowed operating temperature
FKM
Water, beverages, pumpable food and cosmet-
ics (liquids, emulsions, flowing suspensions) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point +80° C (176°F)
Aqueous cleaning base
(based on sodium hydroxide solution, < 5 %*) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point +80° C (176°F)
Aqueous cleaning acid
(based on nitric acid, < 1,5 %*) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point +60° C (140°F)
Aqueous disinfectants
(based on peracetic acid, < 0.2 %*) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point +30° C (86°F)
Water vapor short-term (15 - 20 min.)
< 2,3 bar abs (33,3 psi) ----------
continuous: not recommended
short-term (15 - 20 min.) +121° C
(250°F)
HNBR
Water, beverages, pumpable food and cosmet-
ics (liquids, emulsions, flowing suspensions) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point
+95° C (203°F) bzw.
at least 1 K below the evaporation
temperature at atmospheric pressure
Aqueous cleaning base
(based on sodium hydroxide solution, < 3 %*) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point +80° C (176°F)
Aqueous cleaning acid
(based on nitric acid, < 1,5 %*) < 10,0 barÜ (145 psi) +1° C (33,8° F) or 1 K above freezing point +40° C (104°F)
Water vapor
< 1,9 bar abs (27,5 psi) bzw.
short-term (15 - 20 min.)
< 3,6 bar abs (52,2 psi)
----------
continuous +121° C (250°F)
short-term (15 - 20 min.) +140° C
(284°F)
* Indications regarding the concentration refer to the dilution of the concentrate
If the valve contains liquids, emulsions or suspensions above their re-
spective evaporation temperature at atmospheric pressure, the switching
of the valve or a leakage due to a wear of the seal may lead to a sudden
escape of the complete contents of the pipe system in the form of vapor
into the work area; this may result in a risk of injury to the persons stay-
ing in the work area.
The operator of the valves has to make sure that the ignition temperature
gets not exceeded, due to hot media in the pipework.
If application-specific cleaning agents, other aggressive media or other prod-
ucts are used, make sure they are suitable for stainless steel used and for the
sealing material used and do not damage these materials.
If in doubt please contact the valve manufacturer.
The service life of the seals depends on:
⇒Operating time per day
⇒Number of switching intervals
⇒Type of product, temperature, etc.
⇒Type of cleaning (CIP / SIP)
Danger

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
10
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
3.6. CIP-Cleaning
⇒Inner chambers of the valve must be cleaned regularly.
⇒When selecting the detergent, please observe the following:
Do not use abrasive detergents.
Use only detergents that are suitable for seals and stainless steel.
⇒Do not exceed the concentrations and temperatures recommended by the detergent
manufacturer.
⇒Observe the safety data sheets issued by the detergent manufacturers!
⇒Non-compliance with these instructions will exempt the manufacturer from any war-
ranty and liability.
Cleaning example for EPDM process valves in the food industry:
Cleaning step Description
Pre-rinse Process water
at ambient temperature
Main cleaning process I
(caustic step) Caustic in aqueous solution < 5% at 80°C (176° F)
Intermediate rinse Process water
at ambient temperature
Main cleaning process II
(acid step) Acid in aqueous solution < 3% at 40°C (104° F)
Final rinse Water (drinking water quality)
at ambient temperature
3.7. Control systems
Simple
or double
feedback
⇒Message: Valve position “Open” or/and “Closed”
⇒Inductive feedback unit - Thread M 8 according to customer order
⇒Feedback unit data - refer to data sheet of the feedback unit manufacturer
⇒Add-on kit for feedback -
Single feedback - Order No.: 2127682
Double feedback - Order No.: 2124682
Pro
cess control head
IntelliTop
®
2.0
Technical data see Operating Manual IntelliTop 2.0
Pneum. connections see Operating Manual IntelliTop 2.0
Electrical connections see Operating Manual IntelliTop 2.0
Maintenance see Operating Manual IntelliTop 2.0

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
11
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017 en
3.8. Electrical and pneumatic connections
Electrical connections
Connect up the electrical and pneumatic systems after installing the valve.
Electrical installation must be carried out by skilled personnel.
⇒Observe VDE, IEE, IEC power utility and other locally applicable regulations.
⇒Before connecting it up, check to see whether operating voltage and current match specifications.
Pneumatic connections
⇒Angular screw-in connection
Standard G 1/8, air hose PE ø6/4
USA G 1/8, air hose PE ¼“ (ø6,35)
⇒Air hose specification - Recommendation
Air hose, black hose 6/4 Order No. 0490227
hose 8/6 Order No. 0735563
Material: Polyamide 12
Linear coefficient of expansion: 15x10-5
Version according to DIN 73378 soft
Max. operating pressure: AD 6/ ID 4 = 27 bar
AD 8/ ID 6 = 19 bar
all pressure indications at 20°C, higher temperatures have a negative effect on the
max. operating pressure
⇒
Use only calibrated hose pipes with an external diameter of 6 mm or 1/4" as well as 8 mm or
5/16" (tolerance +0.05/-0.1).
⇒Cut the hose pipe only with a special hose cutter.
⇒The length of the hose must be dimensioned in a way that prevents buckling of the hose.
Even single buckling of the hose damages it permanently.
⇒Insert the air hose into the connector and fasten it. Avoid diagonal pull on connector.
⇒
The drive chamber of pneumatic actuators
with spring-return-function needs to be venti-
lated in order to avoid any undesirable pres-
sure build-up during the switching process.
⇒System Operators must ensure that no flu-
ids, e.g. external cleaning and disinfection
chemicals, condensate water or product me-
dia can enter into/thru the actuator’s ventila-
tion plug.
Any fluid ingress into the actuator can
cause potential functionality
interference.
This could lead to the fact that the safety
position of the valve (spring to close or
spring to open) can no longer be reached
in case of a pressure drop.
Caution
Danger

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
12
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
3.9. Control air
Control air pressure
SVP actuator min. 6 bar – max. 8 bar
Process control head IntelliTop®2.0 see Operating Manual IntelliTop 2.0
Only use clean and dry compressed air!
Control air quality
As possible oil-free and dry air, neutral gases
Quality classes in accordance with DIN ISO 8573-1(5 μm filter recommended)
Dust content
Quality class 5: max. particle size 40 μm, max. particle density 10 mg/m3
Water content
Quality class 3: max. pressure dew point -20 °C or min. 10 °C below the lowest ambient temperature
Oil content
Quality class 5: max. 25 mg/m3
Temperature range of compressed air
-10 to +50 °C

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
13
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017 en
4. Valve function
4.1. SVP aseptic change-over valve air opened – spring closed
Product path A ⇔D opened
⇒Connection U with elastic force closed
⇒Control air pressure 0 bar on connection L1
⇒Safety postion
⇒Locking pressure against product pressure 10 bar
Product path U ⇔D opened
⇒Connection A closed
⇒Control air pressure 6 bar on air connection L1
⇒Locking pressure against product pressure 10 bar
4.2. SVP aseptic change-over valve spring opened – air closed
Product path A ⇔D opened
⇒Connection U closed
⇒Control air pressure 6 bar on air connection L2
⇒Locking pressure against product pressure 10 bar
Product path U ⇔D opened
⇒Connection A with elastic force closed
⇒Control air pressure 0 bar on connection L2
⇒Safety postion
⇒Locking pressure against product pressure 10 bar

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
14
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
4.3. SVP aseptic change-over valve air opened – air closed
Product path A ⇔Dopened
⇒Connection U closed
⇒Control air pressure 0 bar on connection L3
⇒Control air pressure 6 bar on connection L4
⇒Safety postion
⇒Locking pressure against product pressure 10 bar
Product path U ⇔D opened
⇒Connection A closed
⇒Control air pressure 6 bar on connection L3
⇒Control air pressure 0 bar on connection L4
⇒Valve open
4.4. Flow directions (seat area)
Recommended flow direction in open position
Danger of pressure shocks while closing the valve.
Closing of the valve only permitted under static pressure (flow = 0).
Pressure shocks (pressure > 10bar) are beyond the permitted operation
parameters and following a case of not intended purpose of use. Result-
ing damage to the valve or process related components, if it occurs, is
not covered under warranty.

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
15
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017 en
5. Valve connection piping
5.1. Installation position
5.1.1. SVP aseptic change-over valve with spring-return-function
(Operating mode: Air to open – Spring to close or Spring to open – Air to close)
⇒Any installation position
⇒Ensure that product can drain from valve and piping.
System Operators must ensure that no fluids can enter into/thru the
actuator’sventilation plug.
5.1.2. SVP aseptic change-over valve without spring-return-function
(Operating mode: Air to open – Air to close)
⇒Any installation position
⇒Ensure that product can drain from valve and piping.
5.2. Valve connections
Connection A, B, C, E and U: - welding end
- union connection
- clamp connection
- small flange connection
Welding instructions see chapter 6 “Welding and assembly instructions“.
5.3. Installation instructions for the SVP aseptic change-over valve
Dismantle valve see chapter 7 “Dismantling – Assembly”.
⇒ Remove seals before welding.
⇒ Valve housing must be free from stress and distortions when welded.
⇒ Welding works have to be effected only by approved qualified personnel
(DIN EN ISO 9606-1 W8).
⇒ Do not allow any foreign bodies to enter the piping.
Caution
Caution

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
16
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
6. Welding and assembly instructions
6.1. General remarks
Welding works have to be effected only by approved qualified personnel
(DIN EN ISO 9606-1 W8)
Pentair Südmo cannot be held liable for any damage resulting from incorrect installation.
6.2. Delivery condition of SVP aseptic change-over valve
⇒Factory-tested and adjusted.
⇒Ready for installation or for welding into the piping
6.3. Installation instructions
6.3.1. Installation space
Determine and define the connection axes before starting installation work. Observe the installation dimensions specified
in the dimensional drawings.
Ensure that there is sufficient space available for both operation and maintenance, which may include removal.
6.3.2. Installation
Make sure that the fittings and piping are not subjected to tensile or compressive stresses.
6.4. Welding instructions
6.4.1. Area of application
Welding of fittings into pipes according to DIN 11850 Reihe 1, 2; OD-Tube; DIN EN ISO 1127
6.4.2. Welding technique
TIG (tungsten inert-gas welding)
6.4.3. Type of welding
⇒Preparation of the welding seam according to DIN 2559 (groove shape I / for I-groove)
⇒Welding seams corresponding to DIN EN ISO 5817 evaluation group B (high)
6.5. Weld preparation
⇒Saw off the pipe ends evenly and at right angles, and debur them (pipe saw M882).
⇒Align the welding ends of the valve body and piping radially and axially, ensuring they are fitted flush together (cen-
tering device).
⇒Avoid too large a gap at the flush-fitting welding ends.
⇒Make sure that enough forming gas arrives at the welding seam.
6.6. Welding
⇒Connect the forming gas.
⇒Tack at 3 or 4 points.
⇒Weld valve type of welding TIG manual or orbital (automatic welding).
Caution

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
17
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017 en
6.7. Weld filler materials
Material allocation
Material of parts to
be welded Suitable weld filler materials
1.4430 1.4440 1.4519
1.4404 X
1.4435 X X X
1.4571 X X
6.8. Weld finishing
6.8.1. Interior
Depending on requirements, for example
⇒untreated.
⇒abrasive surface finishing (at accessible points).
6.8.2. Exterior
Weld finishing methods
⇒pickling - dispose pickling paste correctly
⇒brushing
⇒grinding
⇒polishing
6.9. Cleaning of the valve
Clean throughly before assembly.
6.10. Valve assembly
Perform assembly according to the assembly instructions (see chapter 7 "Disassembly - Assembly").

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
18
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
7. Dismantling – Assembly
Assemble the SVP valve in general after heaving read the safety instructions (see chapter 7.1. "Preparatory measures
for dismounting - mounting").
7.1. Preparatory measures for dismounting - mounting
Please always take the following steps before loosening the valve connections and clamp connection on the valve hous-
ing:
⇒ Fitting of the SVP aseptic change-over valves may only be carried out by
specially trained, qualified personnel.
Training or instruction in accordance with the current safety standards.
For systems with explosion protection:
training or instruction or authorization to carry out work on systems subject
to explosion hazards (observe ATEX regulations).
⇒ Obtain information on possible risks that could be caused by residues of the
operating media and take appropriate measures if necessary (safety gloves,
safety goggles, etc.), before carrying out maintenance and service work on
the SVP aseptic change-over valve.
⇒ Before disconnecting the valve connections and the flange connection of the
valve housings, make sure that
this work is only carried out in a depressurized state and with the media
supply shut off.
the SVP aseptic change-over valve and all piping elements leading to the
valve have been drained and cleaned or flushed.
the fittings have cooled down.
the system cannot be started by a third person.
the pressure build-up which may form in sealed pipelines is counteracted.
disassembly - assembly of the SVP aseptic change-over valve are carried
out according to the assembly instructions.
when dismantling the control unit, the closing spring is preloaded with auxil-
iary assembly air. To actuate the valves in the manual mode, the supply
voltage and/or electrical signal must be applied.
when dismounting the control unit, the closing spring is to be preloaded. In
case of non-compliance there is a risk of injury when removing the clamp
connection, due to the released spring tension of the actuator.
Secure SVP aseptic change-over valves against signaling, voltage and sig-
nal cut-off, operation and actuation.
the power supply has been disconnected.
the SVP aseptic change-over valve is removed from the piping section, if
possible.
Note
⇒ Cordon off assembly area.
⇒ Ensure that the assembly area remains cordoned off while work is being per-
formed.
Danger
Danger

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
19
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017 en
Before assembly, clean and grease the sliding surfaces and lubricate the sealing elements.
Seal materials Grease type
EPDM PARALIQ GTE 703
HNBR PARALIQ GTE 703
FKM PARALIQ GTE 703
P
3
PARALIQ GTE 703
NBR RENOLIT SI 410 M
⇒ if a different grease is used
→ it may attack seals.
⇒ please do not use mineral or animal greases.
⇒ Don't use grease based on petroleum.
7.2. SVP aseptic change-over valves with feedback
7.3. Spare parts
Use original spare parts only.
⇒ For original spare parts, refer to the enclosed spare parts list (see chapter
12 "Spare parts list").
⇒ Perfect functioning of the SVP aseptic change-over valve is only guaranteed
when using original spare parts.
Don’t put fingers into check-back signal.
⇒ Accident risk.
Fingers can be crushed or cut off.
Danger
Caution
Caution

Operating instructions
SVP aseptic change-over valve, pneum. operated
diaphragm – O-ring
DN 010 – 020, OD 0.50" – 0.75"; ISO 008 – 015
20
Copy of original operating instructions
BAA A390-D.03Select
Version 5.04
created on/by 22.03.2017 Graf H.
reviewed on/by 22.03.2017
en
7.4. Assembly of joint clamp
Fig.. 1 Fig. 2
⇒Mounting of the clamp only in faultless condition (Fig. 1).
⇒Pay attention to gap X and to the parallel position of the side piece (Fig. 1).
⇒It is not allowed to mount clamps with deformed side pieces (Fig. 2).
Fig. 3
⇒Lubricating of the screw thread before assembly → Type of the grease IBF PW 119
⇒Put the clamp on the clamp connection.
⇒Put the screw with the hexagon nut (S) in the groove of the holding bracket.
⇒Tighten the hexagon nut (S) with torque spanner
→ Locked torque 5 – 8 Nm.
It is not allowed to exceed the peak value of max. 8 Nm.
7.5. Mounting tools
Tool for Order no. Use
Punch 155 mm DN 010 – 020
OD 0.50ʺ - 0.75ʺ
ISO 008 – 015
0098525 Pneum. SVP aseptic change-over
valve
Piercer ø5 DN 010 – 020
OD 0.50ʺ - 0.75ʺ
ISO 008 – 015
2311691 Pneum. SVP aseptic change-over
valve
Combination wrench (wrench size)12 DN 010 – 020
OD 0.50ʺ - 0.75ʺ
ISO 008 – 015
forked open jaw wrench SW 17 – 19 DN 010 – 020
OD 0.50ʺ - 0.75ʺ
ISO 008 – 015
0098558 Pneum. SVP aseptic change-over
valve
calliper face spanner DN 010 – 020
OD 0.50ʺ - 0.75ʺ
ISO 008 – 015
2117744 Pneum. SVP aseptic change-over
valve
Torque spanner with bit SW 17 DN 010 – 020
OD 0.50ʺ - 0.75ʺ
ISO 008 – 015
Pneum. SVP aseptic change-over
valve
Hexagonal screwdriver 3,0 mm DN 010 – 020
OD 0.50ʺ - 0.75ʺ
ISO 008 – 015
2127637 Pneum. SVP aseptic change-over
valve
