FILTRATION & PROCESSING SOLUTIONS QL2-OW200L FILTER INSTALLATION AND OPERATION GUIDE
The Everpure QL2-OW200L Water Filter reduces chlorine tastes and odors in drinking water and beverages made with water.
The OW200L also filters out dirt and rust, and reduces the formation of limescale which builds-up in water-using appliances
that heat or freeze water. Perhaps most important, the OW200L reduces both lead and trihalomethanes (THMs) to below
Federal limits.
PARTS LIST
Key Letter Description Part Number
AQL2 Head Assembly EV3063-32
BOW200L Cartridge EV9619-01
CMounting Screw (2 req’d) EV3061-96
DStar Washer (2 req’d) EV3062-04
EFlow Control/Quick Disconnect EV3081-32
FMounting Bracket EV3055-34
GBracket Screw (3 req’d) EV3062-03
SPECIFICATIONS
Rated Service Flow: 0.5 gpm / 1.9 Lpm
Maximum Working Temperature: 35-100°F (2-38°C)
Min/Max Operating Pressure: 10 psi (0.7 bar) / 125 psi (8.6 bar)
Capacity: 480 gallons (1816 L)
Flow Rate: 0.5 gpm (1.9 Lpm)
For cold water use only.
Not for use with water preheated over 100 °F (38 °C).
This drinking water system must be maintained in accordance with the manufacturer’s instructions, including the timely
replacement of filter cartridges.
EVERPURE®QL2OW200L WATER FILTER
A
B
C
D
E
F
G
INCOMING FITTING FROM COLD WATER
SUPPLY PROVIDED BY INSTALLER
TO
DISPENSER
WATER INLET

2 QL2OW200L FILTER INSTALLATION AND OPERATION GUIDE
INSTALLATION
The following instructions provide for installation of a
QL2-OW200L system regardless of whether or not the cooler
is already installed. The label on the OW200L cartridge
illustrates and explains the procedure for cartridge insertion
and removal into the filter head. The filter cartridge should be
placed into the head after the system has been installed.
1. Install the QL2-OW200L as close to the cooler as
possible. Do not connect this filter to any other
equipment. Connect only to the cold water line and do
not expose it to high temperatures.
2. Select a location for the filter [nominally 4 x 4 x 22 inches
long (10.1 x 10.1 x 55.8 cm) including a 2.5 inch (6.3 cm)
drop-down clearance for cartridge changes). Write the
installation date and anticipated cartridge replacement
date in the space provided on the cartridge label. The
cartridge should be replaced every 480 gallons (1816 L)
for optimum lead and THM reduction.
3. If required, shut off the incoming water supply and
relieve pressure in the water line. Cut the tubing,
allowing a 4 inch (10.1 cm) space for the filter installation
between the water supply and the cooler water inlet.
4. Note the arrow in the top of the QL2 head assembly. This
indicates the water flow, from left to right. Note that
a 3/8-inch flow control/quick disconnect fitting (E) has
been installed in the outlet (right hand) port.
5. Install a fitting (not supplied) into the inlet (left hand)
port. Do not overtighten the fitting. Use plumber tape or
food grade pipe joint sealant on fittings.
6. Cut the end of the outlet tubing with a sharp knife,
making sure the tube end is cut flat. Insert the tube end
onto the quick disconnect fitting (E) and push firmly until
the tube end bottoms out in the fitting. To remove the
tubing, push the gray ring tight against the fitting while
pulling the tubing out.
7. Position the QL2 head assembly so that the arrow shown
on top of the head corresponds to the direction of water
flow and attach the incoming cold water supply to the
inlet of the head.
8. Connect the filter outlet to the water cooler inlet line,
and secure in place by tightening the compression nuts.
9. Mount the head to the wall or the cabinet using the
screws (C) and star washers (D) provided.
10. Install the OW200L cartridge (B) into the head following
the instructions on the cartridge label.
11. Turn on the water and check for leaks.
12. Run water through the OW200L cartridge for three
minutes at maximum flow to purge the cartridge of air.
Check for compliance with state and local laws and
regulations. Do not use with water that is microbiologically
unsafe or of unknown quality without adequate disinfection
before or after the system. Systems certified for cyst
reduction may be used on disinfected waters that may contain
filterable cysts.
System Tested and Certified by NSF International against NSF/ANSI Standards 42 and 53 for
the reduction of:
Standard No. 42 — Aesthetic Effects Standard No. 53 — Health Effects
Chemical Reduction
Taste and Odor
Chlorine
Chemical Reduction
TTHM
Lead
Mechanical Filtration
Nominal Particulate Class I
Mechanical Filtration
Cyst
QUICK-CONNECT FITTING
Insertion and removal of plastic or copper tubing:
1. Simply push in tube to attach.
2. Tube is secured in position.
3. Push in collet from both sides to release tubing.
Illustration A - Right Wall Mounting
Illustration B - Rear Wall Mounting
Illustration C - Left Wall Mounting

3QL2OW200L FILTER INSTALLATION AND OPERATION GUIDE

FILTRATION & PROCESSING SOLUTIONS
EVERPURE-SHURFLO WORLD HEADQUARTERS, 1040 MUIRFIELD DRIVE, HANOVER PARK, IL 60133 USA • WWW.EVERPURE.COM
800.942.1153 MAIN (US ONLY) • 800.942.1153 (US ONLY) • 630.307.3000 MAIN • 630.307.3030 FAX • [e-mail] EMAIL
PENTAIR AUSTALIA/NEW ZEALAND, 1-21 MONASH DRIVE, DANDENONG SOUTH, VIC 3175, AUSTRALIA
1300.576.190 TEL • [e-mail] EMAIL
EVERPURE-SHURFLO CHINA, 21F CLOUD 9 PLAZA, NO 1118, SHANGHAI, 200052, CHINA
86.21.3211.4588 TEL • 86.21.3211.4580 FAX • [email protected] EMAIL
EVERPURE-SHURFLO INDIA, GREEN BOULEVARD, B-9/A, 7TH FLOOR - TOWER B SECTOR 62, NOIDA - 201301
91.120.419.9444 TEL • 91.120.419.9400 FAX • [e-mail] EMAIL
EVERPURE-SHURFLO EUROPE, PENTAIR WATER BELGIUM BVBA, INDUSTRIEPARK WOLFSTEE, TOEKOMSTLAAN, 30 B-2200 HERENTALS, BELGIUM
+32.(0).14.283.500 TEL • +32.(0).14.283.505 FAX • [e-mail] EMAIL
EVERPURE-SHURFLO JAPAN INC., HASHIMOTO MN BLDG. 7F, 3-25-1 HASHIMOTO, MIDORI-KU, SAGAMIHARA-SHI KANAGAWA 252-0143, JAPAN
81.(0)42.775.3011 TEL • 81.(0)42.775.3015 FAX • [e-mail] EMAIL
EVERPURE-SHURFLO SOUTHEAST ASIA, 390 HAVELOCK ROAD, #04-01, KING’S CENTRE, SINGAPORE 169662
65.6795.2213 TEL • FAX: [phone] FAX • CSEVERPUR[email protected] EMAIL
All Pentair trademarks and logos are owned by Pentair, Inc. or its affiliates. All other registered and unregistered trademarks and logos are the property of their
respective owners. Because we are continuously improving our products and services, Pentair reserves the right to change specifications without prior notice.
Pentair is an equal opportunity employer.
© 2014 Pentair Filtration Solutions, LLC. All Rights Reserved. EV3063-31 Rev M MY14
EPA Est. No. 002623-IL-002
LIMITED WARRANTY
COMMERCIAL WATER TREATMENT EQUIPMENT
You have just purchased one of the finest water treatment units made. As an expression of confidence in this product, Pentair Filtration
Solutions, LLC (“PFS”) offers the following product warranty. This product is warranted against material defects in materials and
workmanship to the original end-user when installed in accordance with the PFS specifications. The warranty period commences on the
date of purchase and is administered as follows:
For a period of ONE YEAR Replaceable elements (i.e., filter & water treatment cartridges)*
For a period of FIVE YEARS The entire system (excluding replaceable elements)
The unit must be used in operating conditions that conform to PFS’s recommended guidelines. This warranty will not apply if the unit
has been modified, repaired or altered by someone not authorized by PFS.
If a part described above is found to have a material defect in materials or workmanship within the specified warranty period, you
should notify Pentair®Everpure technical service at the phone number listed below. Any part found materially defective within the terms
of this warranty will be repaired or replaced (at PFS’s discretion) by your local dealer or Pentair Everpure technical service. You pay only
freight from our factory and local dealer charges. Any item repaired or replaced pursuant to this warranty will be covered under the
original warranty terms of the system.
PFS is not responsible for damage caused by accident, fire, flood, freezing, Act of God, misuse, misapplication, neglect, oxidizing agents
(such as chlorine, ozone, chloramines and other related components), alteration, installation or operation contrary to our printed
instructions, or by the use of accessories or components which do not meet PFS’s specifications. Refer to the specifications section in
the Installation and Operating manual for approved application parameters.
Our product performance specifications are furnished with each water treatment unit. TO THE EXTENT PERMITTED BY LAW,
EVERPURE DISCLAIMS ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR PARTICULAR PURPOSE; TO THE EXTENT REQUIRED BY LAW, ANY SUCH IMPLIED WARRANTIES ARE LIMITED IN
DURATION TO THE PERIOD SPECIFIED ABOVE FOR THE ENTIRE WATER TREATMENT UNIT.
As a manufacturer, we do not know the characteristics of your water supply or the purpose for which you are purchasing this product.
The quality of water supplies may vary seasonally or over a period of time, and your water usage rate may vary as well. Water
characteristics can also differ considerably if this product is moved to a new location. For these reasons, we assume no liability for
the determination of the proper equipment necessary to meet your requirements, and we do not authorize others to assume such
obligations for us. Further, we assume no liability and extend no warranties, express or implied, for the use of this product with a non-
potable water source or a water source which does not meet the conditions for use described in the owner’s guide or performance data
sheet for this product.
OUR OBLIGATIONS UNDER THIS WARRANTY ARE LIMITED TO THE REPAIR OR REPLACEMENT (AT PFS’S DISCRETION) OF THE
FAILED PARTS OF THE WATER TREATMENT UNIT, AND WE ASSUME NO LIABILITY WHATSOEVER FOR DIRECT, INDIRECT, INCIDENTAL,
CONSEQUENTIAL, SPECIAL, GENERAL OR OTHER DAMAGES.
Some states do not allow the exclusion of implied warranties or limitations on how long an implied warranty lasts, so the above
limitation may not apply to you. Similarly, some states do not allow the exclusion of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
*Warranty applies to material defects in materials & workmanship only.
