Perel PHT700 User manual

PHT700/PHT1200
PHT700
PHT1200
USER MANUAL 4
HANDLEIDING 12
MODE D'EMPLOI 20
MANUAL DEL USUARIO 28
BEDIENUNGSANLEITUNG 36
INSTRUKCJA OBSŁUGI 44
MANUAL DO UTILIZADOR 52
This product is only suitable for well-insulated spaces or occasional use.
Dit product is uitsluitend geschikt voor goed geïsoleerde plaatsen of voor incidenteel gebruik.
Ce produit ne peut être utilisé que dans des locaux bien isolés ou de manière occasionnelle.
Este producto está indicado únicamente en lugares abrigados o para una utilización puntual.
Dieses Produkt ist nur für gut isolierte Räume oder für den gelegentlichen Gebrauch geeignet.
Ten produkt jest odpowiedni tylko do sporadycznego użytku lub do stosowania w dobrze izolowanych pomieszczeniach.
Este produto é adequado apenas para espaços bem isolados espaços ou utilização ocasional.

PHT700/PHT1200
V. 02 –28/05/2021 2 ©Velleman nv
PHT700

PHT700/PHT1200
V. 02 –28/05/2021 3 ©Velleman nv
PHT1200

PHT700/PHT1200
V. 02 –28/05/2021 4 ©Velleman nv
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its
lifecycle could harm the environment. Do not dispose of the unit (or batteries) as
unsorted municipal waste; it should be taken to a specialized company for recycling.
This device should be returned to your distributor or to a local recycling service. Respect
the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Perel! Please read the manual thoroughly before bringing this
device into service. If the device was damaged in transit, do not install or use it and
contact your dealer.
2. Safety Instructions
Read and understand this manual and all safety
signs before using this appliance.
Warning: In order to avoid overheating, do not
cover the heater.
Do not touch.
WARNING –Hot surface.
This way up. Do not use upside-down.
CAUTION –Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
Take off all packaging material including
transport protection before use.
IPX4
IP class X4.

PHT700/PHT1200
V. 02 –28/05/2021 5 ©Velleman nv
•WARNING –Do not use this appliance in the
immediate surroundings of a bath, a shower
or a swimming pool.
•WARNING –Do not install or use the
appliance close to curtains and other
combustible materials.
•WARNING –Do not install this appliance
immediately below a socket.
•Children of less than 3 years should be kept
away unless continuously supervised.
Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
in its intended normal operating position and
they have been given supervision or
instruction concerning use of the appliance in
a safe way and understand the hazards
involved. Children aged from 3 years and
less than 8 years shall not plug in, regulate
and clean the appliance or perform user
maintenance.
•This device can be used by children aged
from 8 years and above, and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning the use
of the device in a safe way and understand
the hazards involved. Children shall not play
with the device. Cleaning and user
maintenance shall not be made by children
without supervision.

PHT700/PHT1200
V. 02 –28/05/2021 6 ©Velleman nv
•Do not use the heater with a programmer,
timer, separate remote-control system or
any other device that switches the heater on
automatically, since a fire risk exists if the
heater is covered or positioned incorrectly.
•If the external flexible cable or cord of this
appliance is damaged, it shall be exclusively
replaced by the manufacturer or his service
agent or a similar qualified person in order to
avoid a hazard.
•Some parts of this product can become very
hot and cause burns. Do not touch the
appliance when in use or shortly after use.
Do not rest the power cable on the appliance
when hot.
•This appliance must not be supplied through
an external switching device, such as a
timer, or connected to a circuit that is
regularly switched on and off by the utility.
•The use of an extension lead or multi-plug
adaptor is not advised when connecting this
appliance to the mains. Connection through
these devices could lead to a risk of
overloading, overheating and even fire at the
extension lead or adaptor due to inadequate
connection quality.
•The first time you use the appliance, a little
smoke and smell due to the protective
substances applied to the heating element
before transport may be given off. This is
normal and should not be considered a fault.

PHT700/PHT1200
V. 02 –28/05/2021 7 ©Velleman nv
3. General Guidelines
•Refer to the Velleman®Service and Quality Warranty on the last pages of this
manual.
•All modifications of the device are forbidden for safety reasons. Damage caused by
user modifications to the device is not covered by the warranty.
•Only use the device for its intended purpose. Using the device in an unauthorised
way will void the warranty.
•Damage caused by disregard of certain guidelines in this manual is not covered by
the warranty and the dealer will not accept responsibility for any ensuing defects or
problems.
•Nor Velleman nv nor its dealers can be held responsible for any damage
(extraordinary, incidental or indirect) –of any nature (financial, physical…) arising
from the possession, use or failure of this product.
•Keep this manual for future reference.
4. Technical Specifications
PHT700
power supply ........................................................................ 220-240 V~, 50-60 Hz
power consumption ...................................................................................... 700 W
IP rating.........................................................................................................IPX4
radiation range ......................................................................................3 m / 360°
dimensions ................................................................................... Ø 220 x 410 mm
weight ........................................................................................................ 2.3 kg
power cord ............................................................. 1.8 m - H05RN-F x 3G0.75 mm²
Information requirements for electric local space heaters
Model identifier(s):
Item
Sym
bol
Value
Unit
Item
Unit
Heat output
Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat
output
Pnom
0,7
kW
manual heat charge control, with integrated
thermostat
N.A.
Minimum
heat output
(indicative)
Pmin
0,35
kW
manual heat charge control with room and/or
outdoor temperature feedback
N.A.
Maximum
continuous
heat output
Pmax,c
0,7
kW
electronic heat charge control with room
and/or outdoor temperature feedback
N.A.

PHT700/PHT1200
V. 02 –28/05/2021 8 ©Velleman nv
Auxiliary electricity consumption
fan-assisted heat output
N.A.
At nominal
heat output
elmax
0,7
kW
Type of heat output/room temperature control
(select one)
At minimum
heat output
elmin
0,35
kW
single-stage heat output and no room
temperature control
N.A.
In standby
mode
elSB
0,0
kW
two or more manual stages, no room
temperature control
yes
with mechanic thermostat room temperature
control
N.A.
with electronic room temperature control
N.A.
electronic room temperature control plus day
timer
N.A.
electronic room temperature control plus week
timer
N.A.
Other control options (multiple selections
possible)
room temperature control, with presence
detection
N.A.
room temperature control, with open window
detection
N.A.
with distance control option
N.A.
with adaptive start control
N.A.
with working time limitation
N.A.
with black bulb sensor
N.A.
Contact
details
Velleman NV
Legen Heirweg, 33 9890 Gavere, Belgium
PHT1200
power supply ........................................................................ 220-240 V~, 50-60 Hz
power consumption .................................................................................... 1200 W
IP rating.........................................................................................................IPX4
radiation range ......................................................................................3 m / 360°
dimensions ................................................................................... Ø 220 x 560 mm
weight ........................................................................................................ 2.9 kg
power cord ............................................................. 1.8 m - H05RN-F x 3G0.75 mm²

PHT700/PHT1200
V. 02 –28/05/2021 9 ©Velleman nv
Information requirements for electric local space heaters
Model identifier(s):
Item
Sym
bol
Value
Unit
Item
Unit
Heat output
Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat
output
Pnom
1,2
kW
manual heat charge control, with integrated
thermostat
N.A.
Minimum
heat output
(indicative)
Pmin
0,6
kW
manual heat charge control with room and/or
outdoor temperature feedback
N.A.
Maximum
continuous
heat output
Pmax,c
1,2
kW
electronic heat charge control with room
and/or outdoor temperature feedback
N.A.
Auxiliary electricity consumption
fan-assisted heat output
N.A.
At nominal
heat output
elmax
1,2
kW
Type of heat output/room temperature control
(select one)
At minimum
heat output
elmin
0,6
kW
single-stage heat output and no room
temperature control
N.A.
In standby
mode
elSB
0,0
kW
two or more manual stages, no room
temperature control
yes
with mechanic thermostat room temperature
control
N.A.
with electronic room temperature control
N.A.
electronic room temperature control plus day
timer
N.A.
electronic room temperature control plus week
timer
N.A.
Other control options (multiple selections
possible)
room temperature control, with presence
detection
N.A.
room temperature control, with open window
detection
N.A.
with distance control option
N.A.
with adaptive start control
N.A.
with working time limitation
N.A.
with black bulb sensor
N.A.
Contact
details
Velleman NV
Legen Heirweg, 33 9890 Gavere, Belgium

PHT700/PHT1200
V. 02 –28/05/2021 10 ©Velleman nv
5. Overview
Refer to the illustrations on page 2 of this manual.
1
heater knob
2
rotation knob
6. Operation
1. Install the appliance on a firm and level surface, free from obstructions and at least
1 m away from any wall or combustible materials.
2. Make sure the heater knob is in the off position (0). Insert the power plug into the
mains.
3. Turn the heater knob to either low or high mode, with or without oscillation (OSC).
350 W (PHT700)
600 W (PHT1200)
700 W (PHT700)
1200 W (PHT1200)
LOW + OSC
HIGH + OSC
This appliance allows selecting the
oscillation degree. Do so by turning the
rotation knob.
4. After use, turn the selector knob back to the off position (0) and disconnect the
appliance from the mains.
This heater is equipped with a safety tilt switch, which automatically switches off the
appliance if it is not in the upright position.
