Petsafe Comfort-Fit bark control Setup guide

21-800-732-2677
Thank you for choosing PetSafe®, the #1 selling brand of
electronic training solutions in the world. Our mission is to
ensure your pet’s safety by providing you the tools and techniques
to successfully train your pet. If you have any questions, please
contact the Customer Care Center at 1-800-732-2677 or visit
our website at www.petsafe.net.
____________________________________________________________________
Table of Contents
Components ........................................................................... 3
Features.................................................................................. 3
How the PetSafe Bark Control CollarTM Works........................... 4
Key Definitions ....................................................................... 4
Fit the Bark Control Collar...................................................... 5
To Insert and Remove the Battery............................................ 7
What to Expect During Use of the Bark Control Collar ............ 8
Regular Maintenance .............................................................. 8
Accessories ............................................................................. 9
Frequently Asked Questions .................................................... 9
Troubleshooting.................................................................... 10
Terms of Use and Limitation of Liability ................................ 10
____________________________________________________________________
“In a Tuskegee University study of adult shelter dogs wearing the
PetSafe Bark Control CollarTM for six 30-minute sessions over
two weeks, we detected no long-term adverse effects, and all dogs
dramatically reduced their barking by the second day.”
Dr. Janet Steiss and Dr. Caroline B. Schaffer
Tuskegee University

www.petsafe.net 3
Components
Operating Guide
Battery
(PetSafe® RFA-67)
Warranty
Card
Wa r ranty
PetSafe
Bark Control CollarTM
Features
• 6 levels of Static Correction, automatically adjusts to your dog’s
temperament starting at the lowest level
• Water Resistant
• Low Battery Indicator Light
• Lifetime Limited Warranty

41-800-732-2677
How the PetSafe Bark Control Collar
TM
Works
The Bark Control Collar™ has a unique patented sensor technique that
provides the most reliable bark detection available.The Bark Control Collar
uses both vibration and sound sensors to discriminate each bark from other
external noises. A Static Correction is administered through the Contact
Points only if both the vibration from the vocal cords and the sound from the
bark match the bark sampling criteria.The Bark Control Collar starts with the
lowest level of Static Correction and then increases through 6 levels each time
your dog barks within 30 seconds of the previous bark. If your dog does not bark
again within 30 seconds, the Bark Control Collar will reset itself to the lowest
level of Static Correction. As a built-in safety feature, if your dog barks 15 times
or more within a 50-second period, the Bark Control Collar will automatically
shut off for 3 minutes.
Important:
• Before playing with your dog, remove the Bark Control Collar.
The activity may cause your dog to bark, which could lead to him
associating the play with the Static Correction.
• Never leave the Bark Control Collar on your dog for more than 12
consecutive hours.
____________________________________________________________________
Key Definitions
Indicator Light: Flashes once every five seconds
during normal operation.
Sound Activated Sensor: Detects the sound
of you dog’s bark.
Sensor Probe: Detects the vibrations of your
dog’s barking. Note:The Sensor Probe is not
adjustable.
Contact Points: Deliver the safe Static
Correction. Contact Points
Battery
Sensor
Probe
Indicator Light
Sound Activated
Sensor

www.petsafe.net 5
Fit the Bark Control Collar
Important: The proper fit and placement of your Bark Control Collar is
important for effective operation. The Contact Points must have direct
contact with your dog’s skin on the underside of his neck.
To assure a proper fit, please follow these steps:
1. Make sure that the battery is not installed in the Bark
Control Collar.
2. Have your dog standing comfortably.
3. Center the Contact Points underneath your dog’s neck,
touching the skin.
YES
NO
Note: It is sometimes necessary to trim the hair
around the Contact Points to make sure that contact
is consistent.
4.The PetSafe QuickFit™
Collar is designed so you
can quickly attach and
remove the Bark Control
Collar from your dog
while maintaining the
desired fit.
a.With the Snap Buckle
fastened, thread the
collar through the
Metal Buckle.
b. Slide the excess collar through the “C” Loop on top
of the Snap Buckle.This will hold the collar in place.
c. Once the collar fit is determined, simply use the
Snap Buckle to remove and replace the collar.
5.The Bark Control Collar should fit snugly, yet loose
enough to allow one finger to fit between a Contact
Point and your dog’s neck. Allow your dog to wear the
collar for several minutes, then recheck the fit. Check the fit
again as your dog becomes more comfortable with the Bark
Control Collar.
6.Trim the collar as follows:
a. Mark the desired length of the collar with a pen. Allow for
growth if your dog is young or grows a thick winter coat.
b. Remove the Bark Control Collar from your dog and cut
off excess.
Snap Buckle “C” Loop
Metal Buckle

61-800-732-2677
ID Tag Ring
Use the ID Tag Ring to attach your
dog’s ID tags to the collar. Simply
place the ID Tag Ring through one
of the holes on your collar. Make
sure to place the Ring far enough
from receiver housing so that tags
will not hit the Receiver or the
Contact Points.
Important: Do not attach a leash to the collar. This can
result in pulling the Contact Points too tightly against
your pet’s neck. Attach a leash to a separate, non-metallic
collar or harness, making sure the extra collar does not
put pressure on the Contact Points.
Important: For comfort, safety and effectiveness of product, please
ensure the following:
• Check the fit to prevent excessive pressure by being able to insert one
finger between the Contact Point and your pet’s skin.
• Your pet must be carefully examined daily for any signs of a rash or
sore.
• If a rash or sore is observed, discontinue the use of the Bark Control
Collar for a few days.
• If the condition persists beyond 48 hours, see your veterinarian.
• Your pet’s neck and the Contact Points must be washed weekly with a
wash cloth and mild hand soap, then rinsed thoroughly.
A condition called Pressure Necrosis, which is a devitalization of
the skin due to excessive and prolonged contact against the Contact
Points, may occur if the steps above are not followed.

www.petsafe.net 7
To Insert and Remove the Battery
Note: Do not install the battery while the Bark Control Collar is on your dog.
This Bark Control Collar utilizes a replaceable PetSafe®battery (RFA-67).This
unique battery is designed to make battery replacement easier and increase
water protection.
To insert the battery, align the symbols
on the battery (arrow) and Bark
Control Collar (triangle). Use a large
coin to turn the battery clockwise until
the arrow lines up with the lock symbol
on the housing.
To remove the battery, turn the
battery counter-clockwise using a large
coin. DO NOT attempt to cut into
or pry open the battery. Be sure to
discard the used battery properly.
A replacement PetSafe®battery (RFA-67) can be found at many retailers.
Contact the Customer Care Center at 1-800-732-2677 or visit our web site at
www.petsafe.net to locate a retailer near you.
Battery Life
Average battery life is 3 to 6 months, depending on how often your dog barks.
However, due to greater use during your dog’s training, your first battery may
not last as long as replacement batteries.To conserve battery life, remove the
battery when the Bark Control Collar is not in use.
Indicator Light
During normal operation, the Indicator Light flashes once every 5 seconds.
As the product is used, the battery will be drained to a weakened state. At this
point, the Indicator Light will stop flashing to indicate it is time to change the
battery.

81-800-732-2677
What to Expect During Use of the
Bark Control Collar
Important: Do not leave your dog alone the first few times he receives
a Static Correction.
Place the Bark Control Collar properly on your dog and wait nearby until he
barks. Most dogs will understand very quickly that the Bark Control Collar
is disrupting their urge to bark and will relax and stop barking. Because the
Static Correction from the Bark Control Collar may be surprising or startling
at first, some dogs may bark more at the initial correction.
On rare occasions, a dog may get into a bark-correction-bark-correction cycle.
If this happens, reassure your dog with calm, soothing tones. As your dog
relaxes, he will understand that if he becomes quiet, he will not receive any
more Static Corrections.The small minority of dogs that have this reaction
will only have it the first time they wear the Bark Control Collar.
You should notice a reduction in your dog’s barking within the first couple
of days that he wears the Bark Control Collar. At this point, it is important
to remember the learning process is still not complete. Dogs will “test” this
new learning experience and will increase their attempts to bark.This usually
occurs during the second week a dog wears the Bark Control Collar. If this
does occur, remain consistent and do not alter your use of the Bark Control
Collar.You must place the Bark Control Collar on your dog in every situation
when you expect him to be quiet. If your dog is not wearing the Bark Control
Collar, he may resume barking and his learning would suffer a setback.
____________________________________________________________________
Regular Maintenance
• Check Contact Points for tightness weekly
Note: Do not adjust the factory preset Sensor Probe.
• Clean Contact Points with alcohol weekly.
Note: Remove the battery before touching the Contact Points.
• Check your dog’s neck for irritation and wash neck
weekly.

www.petsafe.net 9
Accessories
To purchase additional accessories for your PetSafe Bark Control CollarTM,
contact the Customer Care Center at 1-800-732-2677 or visit our website at
www.petsafe.net to locate a retailer near you.
Component Part Number
Battery - two pack RFA-67D-11
If the collar breaks, you do not have to replace the whole unit. The collar is
replaceable; however under normal circumstances there is no need to separate the
collar and receiver. Please contact the Customer Care Center for replacement
collar and instructions.
Frequently Asked Questions
Will my dog stop
barking completely?
• The Bark Control Collar effectively and humanely
stops all barking when it is worn. It should only be
worn during periods of unwanted barking.
My dog has a sensitive
nature. Can I lower
the Static Correction
level?
•You can obtain a resistor to reduce the Static
Correction level by contacting the Customer Care
Center at 1-800-732-2677.
Will another dog’s
bark set off the Bark
Control Collar?
• No.
Is the Bark Control
Collar safe and
humane?
•Yes.The Bark Control Collar is designed to get your
dog’s attention, not to punish him. However, the
initial Static Correction may startle your dog.
Will the Bark Control
Collar work for my
dog?
• The Bark Control Collar is safe and effective for all
breeds and sizes of dogs, though it may be too large
for dogs under 8 pounds to wear comfortably.
Can I attach a leash
to the Bark Control
Collar?
• No.This can result in pulling the Contact Points
too tightly against your dog’s neck. Attach a leash to
a separate, non-metallic collar or a harness, making
sure the extra collar does not put pressure on the
Contact Points.

10 1-800-732-2677
Troubleshooting
My dog keeps
barking (does not
respond to the Static
Correction).
• Tighten the Bark Control Collar and/or trim your
dog’s hair where the Contact Points touch his neck
to ensure good skin contact.
• Replace the battery.
• If your dog still does not respond, contact the
Customer Care Center at 1-800-732-2677.
The Indicator
Light stopped
flashing.
• Ensure that the battery is properly installed.
• Replace the battery.
• If the Indicator Light still does not flash, contact the
Customer Care Center at
1-800-732-2677.
Terms of Use and Limitation of Liability
1. Terms of Use
This Product is offered to you conditioned upon your acceptance without
modification of the terms, conditions and notices contained herein. Usage
of this Product implies acceptance of all such terms, conditions, and
notices.
2. Proper Use
This Product is designed for use with pets where training is desired. The
specific temperament of your pet may not work with this Product.We
recommend that you not use this Product if your pet is less than 8 pounds
or if your pet is aggressive. If you are unsure whether this is appropriate
for your pet please consult your veterinarian or certified trainer.
Proper use includes reviewing the entire Guide provided with your Product
and any specific Caution statements.
3. No Unlawful or Prohibited Use
This Product is designed for use with pets only. This pet training device is
not intended to harm, injure or provoke. Using this Product in a way that is
not intended could result in violation of Federal, State or local laws.

www.petsafe.net 11
4. Limitation of Liability
In no event shall Radio Systems Corporation be liable for any direct,
indirect, punitive, incidental, special or consequential damages, or any
damages whatsoever arising out of or connected with the use or misuse
of this Product. Buyer assumes all risks and liability from the use of this
Product.
5. Modification of Terms and Conditions
Radio Systems Corporation reserves the right to change the terms,
conditions and notices under which this Product is offered.

300-414
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
Radio Systems Corporation
10427 Electric Avenue
Knoxville, TN 37932
1-800-732-2677
www.petsafe.net
400-714
©Copyright 2005, Radio Systems Corporation
