Philips EasyKey 7000 Series User manual

EasyKey
7000 series
DDL709-FVP-7HWS
Facial recognition
smart door lock
User
manual
Sign your product up and get
support at
www.philips.com/support

1
19
21
22
Contents
1. Important Information
2. Assembly
3. Get to know your
smart lock
Outside escutcheon
Inside escutcheon
Safety
Caution
Disposal of used products and
batteries
Packing list
Exploded views
Notice before assembling
Adjustable latch instructions
Assembly procedure
02
03
09
10
16
4. Settings
Instructions before setting
Master mode
User ngerprint
Settings
Network settings
Mini program binding guidance
5. Get to use your lock
Outdoor/ indoor unlock
Outdoor/ indoor lock
Inside deadlock
Mechanical key unlock
6. Other features
7. Indicators
Door lock status indicator
Low battery indicator
Outside forced lock indicator
Mute indicator
Indoor deadlock indicator
System locking indicator
8. Troubleshooting
Alert types
How to apply external power
supply
Battery replacement
Battery recharge
Indoor infrared unlock
Outside forced lock
Mute button
Default settings
Doorbell
Video intercom
Display

2
1. Important information
Safety
◆Before using the product, please read through
and fully understand all instructions. The
warranty will not cover damage caused by non-
observance to the instructions.
◆Suggest using only the manufacturer-specied
accessories / components.
◆Use only the alkaline or Li-polymer batteries
the product is equipped with or use the same
type of batteries with the same specication.
◆Do not forcibly disassemble the product
to avoid triggering the alert or damaging the
product.
◆Do not use any sharp object to scratch the
ngerprint sensor, otherwise, it might cause
permanent damage.
◆Do not expose products to places that have
water leakage or splashing.
◆Do not expose the product to corrosive
substances to prevent damaging the protective
cover.
◆Do not hang objects on the handle in case it
might aect the normal use of the lock.
◆Please clean the product with soft cloth.
◆Do not disassemble the battery during setting
up and operating.
◆Please follow the assembly instructions that
we provided to install the product and keep the
relevant sealed stickers properly.
◆Please modify the default master PIN code
immediately after installation and conguration
are done, and keep the mechanical key properly,
do not disclose the PIN codes to others.
◆Please replace all the batteries in time if there
is a low battery alert. Please make sure to match
the poles (+/-) correctly when installing the
batteries.
Caution
◆Do not place the batteries near ignition source
to avoid explosion.
◆Do not use any power supply that does not
meet the safety requirements to power up the
product.
◆Do not connect the 2 poles of the batteries
with metals to avoid short out which may lead to
explosion.
◆Please make sure any component replacement
is executed by Philips, Philips authorized service
centers or professional technicians.
◆Do not use accessories or parts that have been
produced by other manufacturers or have not
been specically recommended by Philips. The
use of such accessories and parts may void your
warranty.
Disposal of used
products and batteries
◆You can have your locks reclaimed at Philips
authorized service centers. You will receive
corresponding compensation if your products
meet our recall conditions.
◆Please familiarize with the local electronic
product collection system yourself.
◆Please follow local regulations and do not
discard used products and batteries into ordinary
household waste.
◆Please familiarize with the local regulations
on batteries classication recycling yourself.
Disposing of used products and batteries
properly can help avoid a negative impact on the
environment and human health.

3
① Outside
escutcheon with
silicon pad
② Inside
escutcheon with
silicon pad
③ Drilling
template
④ Mortise
⑤ Fixing plate ⑥ QSG ⑦ Warranty card ⑧ Certificate of
conformity
⑨ Key tag ⑩ Mechanical keys ⑪Li-Polymer
battery
⑫Strike plate
⑬Installation kit ⑭Charging cable
Warranty
Card
Easy Key
EasyKey
合格证
Quick Start
Guide
EasyKey
Packing list
This packing list is for reference only. Please refer to the actual packing items.
2 Assembly

4
1 2 3 4
5 6 7 8 9 10
11
12
13
Exploded views
1. Battery cover*1
2. Li-polymer battery*1
3. M6 anchor screw*2
4. Inside escutcheon*1
5. Compressed spring*2
6. Square shaft*2
7. M5 anchor screw*2
8. Fixing plate*1
9. Mortise*1
10. M5 screw tube*2
11. M6 screw tube*2
12. Outside escutcheon*1
13. Screw plug*1

5
Left-hand swing Right-hand swing
Left-hand inswing
Left-hand outswing
Right-hand inswing
Right-hand outswing
Loosen the screws counterclockwise
with an Allen wrench and remove the
mortise plate.
Reattach the mortise plate on the
mortise and tighten the screws with
the Allen wrench.
Pull the latch straight out of mortise,
turn the latch 180 degrees, and
reinsert it into the mortise.
1
3
2
Notice before assembling
Adjustable latch instructions
This product applies to doors with four opening directions: left-hand inswing,
left-hand outswing, right-hand inswing, and right-hand outswing.
Attention
1. Choose a proper installation kit base on the door thickness.
2. The default tool kit applies to a door thickness of 60-90mm. Please consult the local distributor for other
door thicknesses.
Mortise plate
Latch
Mortise plate
Allen wrench
Allen wrench

6
1 2
34
Assembly procedure
The following assembly procedure applies to the right-hand swing doors. For
left-hand swing doors, please read through the [Notice before assembling] and
complete the adjustable latch instructions.
To drill holes in the door according
to the drilling template, mount the
mortise into the jamb, and tighten the
four anchor screws.
Pass the connecting cable through
the hole, align and insert the square
shaft of the outside escutcheon into
the rotary hole, so that the outside
escutcheon is tight against the outside
of the door.
Fasten the xing plate to the inner
surface of the door and use two M5
connecting screws to secure it tightly.
Attach the connecting screw tube on
the outside escutcheon and put the
compressed spring and square shaft in
the square shaft hole accordingly.
Attention Attention
Please make sure the assistant bolt, dead bolt, and
lock-out bolt are retracted during assembly.
Please choose the appropriate length of the
square shaft and screw tube according to the door
thickness.
M6 connecting
screw tube
M6 connecting
screw tube
Connecting cable
Mortise
connecting cable
Escutcheon
connecting cable
Antenna
M5 connecting
screw tube
Antenna

7
5 6
7 8 9
Put the compressed spring and
square shaft on the inside escutcheon
accordingly.
Open the upper
decorative cover and the
battery cover, mount,
and tighten the M6
anchor screws to secure
the inside escutcheon.
Check the rotary knob,
the mechanical key, and
whether each part is
connected and assembly
in good condition.
Install the battery and
put the battery cover
back, then mount the
upper decorative cover
and install the strike
plate to nish the
assembly.
Insert the escutcheon connecting cables
and mortise connecting cables into the
corresponding socket of the inside escutcheon,
then connect the antenna, and align the
square shaft hole on the inside escutcheon
against the rotary hole on the mortise, so that
the inside escutcheon is closely attached to the
inner surface of the door.
Mortise
connecting
cable Socket of mortise
connecting cable
Socket of
escutcheon
connecting cable
Connecting
cable of outside
escutcheon
Antenna
Attention
Attention
Be sure to put the escutcheon connecting cables
and the mortise connecting cables into the slot on
both sides of the square shaft, and hide the extra
cables in the door hole or inside escutcheon.
After installing the strike plate, please test to see if the door opens and closes smoothly.

8
①Camera
②Indicator
③Fingerprint sensor
④Keypad
⑤Mute button
⑥PIR sensor
⑦Facial recognition
module
⑧Push-pull handle
⑨Doorbell button
⑩Card reader
⑪Low battery indicator
⑫Infrared sensor
⑬Reset and external power
supply interface
⑭Mechanical key hole
①Display
②Battery compartment
③Application
programming interface
④Reset button
⑤OPEN/CLOSE button
⑥Rotary knob
⑦Push-pull handle
7
4
3
1
6
2
5
4
5
13
9
6
8
7
14
10
11
12
1
2
3
This packing list is for reference only. Please refer to the actual packing items.
3 Get to know your smart lock
Outside escutcheon
Inside escutcheon

9
User
code Name Fingerprint PIN code Key tag Face ID
00
01
02
03
04
05
06
07
08
Key tag
[#] key [*] key
Instructions before setting
◆The system mode is divided into general mode and dual-verication mode.
4 Settings
General mode Any enrolled access methods can unlock the door
Any two enrolled access methods among PIN code, key tag,
ngerprint, and face ID can unlock the door
Dual verication mode
◆ User code
You can delete a user's information by its user code without having to delete everything.
You can record the user information in the following table for future queries.
Master
PIN code
One-time
PIN code
Face ID User PIN
code
User code
00-99
Fingerprint
enrollment
Master
ngerprint
◆Icon annotation
Attention
1. Press [*] key to return to the previous menu.
2. The default master PIN code is 12345678.

10
1
Add a user PIN code: Enter a new user
PIN code, and press【#】to conrm, then
re-enter the user PIN code and conrm
with【#】again. After the voice prompt
of “succeeded”, press [*] to back to the
previous menu until exit the master mode.
Add a user ngerprint: Place the nger on
the ngerprint sensor, and you will hear a
voice prompt of “please remove your nger
and place it on the sensor again”, take your
nger o and put it back again, repeat
several times until you hear a voice prompt
of “succeeded”, then press【*】to return to
the previous menu until you exit the master
mode.
Add a user key tag: Enroll a new key
tag, when you hear a voice prompt of
“succeeded”, press【*】to back to the
previous menu until you exit the master
mode.
1
Master mode User settings
Master PIN code
Add a user PIN code
Master ngerprint
After lighting up the keypad, press [*] twice
before entering other numbers, then enter
the master PIN code and conrm with [#],
then you are in master mode.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [1] to enter user settings, and then
press [1] to add a user, the door lock will
automatically recognize the corresponding
access method and add PIN codes,
ngerprints, and key tags directly.
After lighting up the keypad, press [*] twice
before entering other numbers, then place
your enrolled master ngerprint on the
ngerprint sensor to enter master mode.
Attention
Attention
If the master PIN code is the initial PIN code, you
will need to enter [1] and then [5] in the master
mode to modify the master PIN code before you
can perform other operations.
1. Please enroll a master ngerprint before using
the product.
2. Please do not set the master ngerprint and user
ngerprint with the same nger.

11
2
11
1
1
Add a one-time PIN code Add or change a master ngerprint
Modify master PIN code
Add a Face ID
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [1] to enter user settings, then press
[4] to add or change a master ngerprint.
Press [1] to enter user settings, then press
[2] to add a one-time PIN code.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [1] to enter user settings, then press
[5] to modify master PIN code.
Press [1] to enter user settings, then press
[3] to add a Face ID.
Position your face in front of the camera
and gently move your head in dierent
angles by following the voice prompt. After
hearing a voice prompt of “succeeded',
press [*] until you nally exit the master
mode.
Enter a 6-12 digits one-time PIN code, and
press [#] to conrm; enter the one-time PIN
code again, and conrm with [#]. After the
voice prompts"added succeeded", press [*]
to return to the previous menu until you
exit the master mode.
With no enrolled master ngerprint:
Enroll a new user ngerprint, and the
new ngerprint will be set as the master
ngerprint. After a voice prompt of
“succeeded”, press [*] to back to the
previous menu until you exit the master
mode.
With existed master ngerprint : Enter
a new user ngerprint, and the new
ngerprint will cover the old master
ngerprint. After a voice prompt of
“succeeded”, press [*] to back to the
previous menu until you exit the master
mode.

12
1
Enter a new master PIN code and conrm
with [#]. Enter the new master PIN code
again and conrm with [#]. Once heard a
voice prompt of "succeeded", press [*] until
you exit master mode.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [2] to enter system settings, then press
[1] to enter language settings.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [2] to enter system settings, then press
[2] to enter volume settings.
Select the volume needed: press [1] for
higher volume; press [2] for lower volume;
press [3] for mute mode. After the setting is
done, press [*] to back to the previous menu
until you exit the master mode.
Select the language needed: for Chinese,
please press [1]; for English, please press
[2]. After the voice prompts "setting
succeeded", press [*] to return to the
previous menu until you exit the master
mode.
Press [1] to enter user settings, then press
[6] to delete user’s information.
Delete a user
Select the access methods that need to
delete: to delete a PIN code, please press [1];
to delete a ngerprint, please press [2]; to
delete a key tag, please press [3]; to delete a
Face ID, please press [4]; to delete all user's
information, please press [5], for the specic
access methods that need to delete, please
follow the voice prompt to operate. After
the voice prompts deletion succeeded,
press [*] to return to the previous menu
until you exit the master mode.
or or or or
or or
or
Settings
Language settings
Volume settings
Attention
Attention
The default language is English.
The default volume is higher volume.

13
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [4] to enter network conguration
and it will exit the master mode
automatically once the conguration is
done.
Press [2] to enter system settings, then press
[5] to enable/disable the infrared handle.
After the voice prompts the operation is
done, press [*] until you exit the master
mode.
Press [2] to enter system settings, then press
[3] to enter Eco settings.
Press [*] twice, enter the master PIN code,
and then press [#] to conrm.
Press [2] to enter system settings, then
press [4] to enable/disable dual-verication
mode. After the voice prompts the
operation is done, press [*] until you exit
the master mode.
Press [1] to turn on/o video; press [2] to
turn on/o facial recognition; press [3] for
sensor settings. After the voice prompts the
operation is done, press [*] until you exit
the master mode.
or or
Network conguration
Eco settings Infrared handle
Dual-verication mode Join a network
Attention
Attention
Attention
The Eco mode is disabled by default.
The infrared handle is enabled by default.
The default verication mode is general mode.

14
③Go back to the APP and follow the
prompt to finish the binding process.
APP binding guidance
Download
Add a door lock
Scan QR code
Manually adding the device
①
②
Please scan the QR code below to
download Philips EasyKey Plus APP on
your phone.
1. After powering up the door lock, nd
the QR code on the back of the battery
cover.
2. Open the "Philips EasyKey Plus" APP,
and click [Add a Device] on the home
page.
3. After scanning the QR code on the
battery cover, follow the instructions of
the APP to complete the binding process.
1. Enter the "Philips EasyKey Plus" APP,
and click [Add a device] on the home
page.
2. Search for the current door lock model
and enter the binding process.
3. Press [*] twice on the lock, enter
the master PIN code, and press [#]
to conrm, then the door lock will
be in master mode. Press [4] to "Join
a network", and the voice prompts
"binding, please wait".
Attention
The door lock only supports 2.4G band Wi-Fi
routers (5G band is not supported). Please ensure
the distance between the router and the door lock
is less than 10 meters, otherwise the Wi-Fi signal
might be weak.

15
1
① Touch to wake up
the keypad, enter
the enrolled PIN
code and conrm
with [#].
② After the voice
prompts " door
opened”, push or
pull the handle to
unlock the door.
①Place the enrolled
nger on the
ngerprint sensor.
②After the voice
prompts “door
opened”, push or
pull the handle to
unlock the door.
①Place the enrolled
key tag on the card
reader.
②After the voice
prompts “ door
opened”, push or
pull the handle to
unlock the door.
①Face the camera
with the enrolled
face ID.
②After the voice
prompts “ door
opened”, push or
pull the handle to
unlock the door.
Use the rotary knob to
unlock.
Double press the [OPEN]
button within one second,
and then push or pull the
door to unlock the door.
With the infrared sensor
on, once the sensor
detects the hand from the
handle's front and rear side,
touching the handle could
unlock the door.
Rotary knob OPEN button Infrared handle
PIN code Fingerprint Key tag Face ID
11
1
2
22 2
Outdoor/ indoor unlock
5 Get to use your lock
Outdoor unlock
Indoor unlock
Keypad
Push/
pull to
unlock Fingerprint
sensor
Card
reader
Push/pull
to unlock
Push/pull
to unlock
Push/pull
to unlock
Facial
recogni-
tion
module

16
Push knob
Outside/Inside locking
Inside deadlock
Mechanical key
After closing the door, the latch bolt will automatically pop up to lock, and there
will be a voice prompts "Door closed".
After the door is locked, long press the
[CLOSE] button, and there will be a voice
prompt of "Inside deadlock enabled".
1. In inside deadlock mode, all functionalities from the
outside escutcheon will be disabled. With any enrolled
access method input from the outside escutcheon,
the keypad will display the combination of “15937(X)”
followed by a voice prompt of “Inside deadlock
enabled” to remind you that the door has locked from
inside.
2. In the inside deadlocked mode, unlocking from the
outside can only be achieved by entering the master PIN
code or using the mechanical key.
Attention
① Cut the mechanical key
box and take out the key
shell. Push the knob aside
and reveal the key itself.
② Insert the key into the
key hole and keep the key
and key shell vertical to
each other. Rotate the key
shell towards the handle for
90° until it becomes close to
the door surface.
③ Rotate the key cell 180°
downward so it can be
parallel to the ground，then
rotate it horizontally
toward the lever to unlock
the lock.
Attention
Please use the mechanical key to unlock the door for emergencies only, i.e. when the battery is dead, when
you forgot the PIN code, or the lock fails to work.

17
Infrared sensor
Touch sensor
Function：
When this function is enabled, you
could unlock the door from inside.
How to use：
When the touch sensor and infrared
sensor are on, touching the touch
sensor and infrared sensor on the
handle can unlock the door.
Infrared handle:
When the infrared handle is o, long
pressing the [OPEN] and [CLOSE]
buttons for 10 seconds can enable the
infrared handle.
When the infrared handle is on, long
pressing the [OPEN] and [CLOSE]
buttons for 10 seconds can disable the
infrared handle.
Function:
Unlocking from inside will trigger
an alert.
How to use:
After the door is locked, press [8] to
enter the outside forced lock mode.
Functional button
Attention
Attention
When the infrared handle is o, you will not be
able to unlock the door from inside. When your
hand touches the touch sensor and the infrared
sensor, the red light will light up to remind you
that the infrared handle is o.
The outside forced lock mode will not aect the
normal unlocking from outside.
6 Other features
Indoor infrared unlock
Outside forced lock

18
Mute button
Default settings
Function:
Press [0] to enable mute mode
when before unlocking the door,
this function applies to scenarios
in which you don’t want to disturb
your family.
How to use:
Mute: when the outside escutcheon
is light up, press the [mute button]
for 2 seconds to enter mute mode,
it will follow by a voice prompt of
"mute mode enabled".
Unmute: when the outside
escutcheon is light up, press the
[mute button] for 2 seconds to
restore to voice guide, it will follow
by a voice prompt of "voice prompt
enabled".
Function:
To empty all user information and
restore to default settings.
How to use:
Double press the [RES] button with
a sharp object, and all the user
information will be emptied. The
lock will restore to default settings.
Mute button
