Philips HP4649/01 User manual

Satin styles aquacondition
HP4649/01

2

3
1234
5678
910 11 12

4

ENGLISH 6
POLSKI 11
ROMÂNĂ 17
РУССКИЙ 22
ČESKY 28
MAGYAR 33
SLOVENSKY 38
УКРАЇНСЬКА 43
HRVATSKI 49
EESTI 54
LATVISKI 59
LIETUVIŠKAI 64
SLOVENŠČINA 69
БЪЛГАРСКИ 74
SRPSKI 80
HP4649

Introduction
This new Philips Aqua Satin Pro Style has been specially designed to
give beautiful styling results in a quick and easy way.The 2 exchangeable
attachments - the round brush and the shaping brush - allow you to
make healthy and shiny curls or waves.
Important
Read these instructions for use carefully before using the appliance and
save them for future reference.
◗Check if the voltage indicated on the appliance corresponds to
the local mains voltage before you connect the appliance.
◗Keep this appliance away from water! Do not use this product
near or over water contained in baths, washbasins, sinks etc.
When used in a bathroom, unplug the appliance after use since
the proximity of water presents a risk, even when the appliance is
switched off.
◗For additional protection, we advise you to install a residual
current device (RCD) with a rated residual operating current not
exceeding 30mA in the electrical circuit supplying the bathroom.
Ask your installer for advice.
◗Only use the appliance on dry or damp hair.
◗The barrel will become hot during use. Prevent contact with the
skin.
◗Never block the air inlet grille.
◗If the appliance overheats, it will switch off automatically. Unplug
the appliance and let it cool down for a few minutes. Before you
switch the appliance on again, check the grille to make sure it is
not blocked by fluff, hair, etc.
◗Keep the appliance out of the reach of children.
◗Always unplug the appliance after use. Because the slide on this
appliance has no 'off' position, the only way to switch the
appliance off is by unplugging it!
◗Wait until the appliance has cooled down before storing it.
◗If the mains cord is damaged, it must be replaced by Philips, a
service centre authorised by Philips or similarly qualified persons
in order to avoid a hazard.
ENGLISH6

◗Noise level: L= 71 dB(A) re 1pW
Preparing for use
Filling the reservoir
1Detach the water reservoir from the appliance (fig. 1).
2Fill the reservoir with water under a gently running tap (fig. 2).
◗Always make sure that the reservoir is full before you start
styling.
Keep the appliance itself away from water!
3Close the reservoir. First insert the narrow end of the reservoir
into the appliance and then push the broader end of the
reservoir home.You will hear a click.
Preparing for styling
◗If you want to create curls with the round brush, we advise you
to perform a curl test to determine how long the brush should
be held in your hair to achieve a good result.
◗Start with 8 to 10 seconds.You may have to hold the brush in
your hair longer for tighter curls. Less tight curls will require less
than 8 seconds.
1Put the plug in the wall socket.
2Make sure that the slide is in the mposition (heat only) (fig. 3).
3While the appliance is heating up, comb or brush the hair so that
it is disentangled and smooth. Use a comb to divide the hair into
locks. Do not put too much hair in one lock.
BThe appliance is ready for use after approx. 2 minutes.
◗To ensure optimal performance, do not activate the steam
function more than twice in 10 seconds.
Make sure the slide is in the mposition (heat only).
ENGLISH 7

Using the appliance
Styling with the round brush
1Take a lock of hair and wind it round the brush. Make sure the
end of the lock is wound in the required direction (fig. 4).
- Do not wind too much hair round the brush at a time.
- The thinner the lock of hair, the tighter the curl will be.
- Do not wind a lock of hair more than twice round the brush.
- Make sure the lock of hair is in contact with the barrel of the brush.
1If you wind the hair at right angles to the scalp, you will give your
hair optimum lift and volume.
2Activate the steam function by pushing the button on the
reservoir (fig. 5).
One push will suffice to set one curl or wave.
If the steam function does not work, the reservoir may be empty.
Refill the reservoir.
3Set the appliance to the desired setting (fig. 6).
◗m: normal heat, no airflow.
◗~: a gentle, warm airflow for easy styling.
◗6: a stronger and warmer airflow for fast styling.
4Hold the brush in place as long as required (normally 8 to 10
seconds).
5Remove the brush from your hair by carefully unwinding the lock
of hair.
Make sure you keep the brush away from the underlying hair when
you remove it.
6Let the curls cool down before combing, brushing or finger-
combing the hair to finish your style (fig. 7).
ENGLISH8

Styling with the shaping brush
The special design of the shaping brush ensures that the warm air is
directed at the scalp, creating maximum root lift. It adds optimum body
to your hair and allows you to easily shape the desired style.
The shaping brush can be used to create large curls and waves and also
to curl the hair ends inwards or outwards.
7Disconnect the round brush (fig. 8).
8Attach the shaping brush (fig. 9).
Volume & waves
1Place the shaping brush in the hair in such a way that the pins
touch your scalp.
2Brush against the direction of hair growth (fig. 10).
3Then move the brush away from the head while turning the
brush (fig. 11).
This will cause the hair to be lifted and to fall lightly back onto the head,
creating maximum volume.
◗If the hair is damp, you can hold the shaping brush still for a
moment before moving it away from the head while turning the
brush.
4Let the curls cool down before combing, brushing or finger-
combing the hair to finish your style (fig. 12).
Storage
1Unplug the appliance.
2Do not wind the mains cord round the appliance.
3Put the appliance in a safe place and let it cool down.
Cleaning
◗Clean the appliance with a small brush or a dry cloth.
ENGLISH 9

◗Clean the attachments with a moist cloth or by rinsing them
under the tap.
Remove the attachments from the appliance before cleaning them.
Make sure the attachments are dry before using or storing them.
◗Because you are using tap water, scale will develop in the
reservoir.To remove the scale, you should clean the reservoir
every 2 months. Remove the reservoir, add 3-4 drops of vinegar,
top it up with water and put it back into the appliance. Put the
plug in the wall socket and wait at least 2 minutes. Hold the
appliance with the barrel pointing downwards and activate the
steam function for 3 seconds. Keep activating the steam function
at brief intervals until the reservoir is empty.Then unplug the
appliance and rinse the reservoir with water.
Replacement
◗If the mains cord is damaged, it must be replaced by Philips, a
service centre authorised by Philips or similarly qualified persons
in order to avoid a hazard.
◗Always return the appliance to a service centre authorised by
Philips for examination or repair, as special tools and/or parts are
required.
Guarantee & service
If you need information or if you have a problem, please visit the Philips
Web site at www.philips.com or contact the Philips Customer Care
Centre in your country (you will find its phone number in the
worldwide guarantee leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and Personal Care BV.
ENGLISH10
