Philips SmartBirght BN013C Series User guide

BN013C
Mounting Instruction
Philips Lighting Luminaires (Shanghai) Co., Ltd.
Address: 2F, Building 6, No. 1805, Huyi Highway, Malu Town,
Jiading District, Shanghai, P.R. China
Postal code: 201801
Product Type Power (W)
BN013C LED20/WW L1200 AU G2
BN013C LED20/NW L1200 AU G2
BN013C LED20/CW L1200 AU G2
BN013C LED10/WW L600 AU G2
BN013C LED10/NW L600 AU G2
BN013C LED10/CW L600 AU G2
20
20
20
10
10
10
CCT (K)
0.24
0.24
0.24
0.12
0.12
0.12
3000
4000
6500
3000
4000
6500
V1.0
FrequencyVoltage
220-240V 50/60Hz
Lumen Output (lm)Dimension (mm)
1200x30x37
1200x30x37
1200x30x37
600x30x37
600x30x37
600x30x37
IP20
Type L600 L1200
D (mm) 300-500 600-800
Installation on ceiling or wall through mounting clips.
(D: Mounting distance)
Surface Mounting
SmartBirght LED Batten
2000
2000
2000
1000
1000
1000
Unit: mm
Suspended Mounting
~
AS/NZS
60598
1200/600
37
30
L
Type L600 L1200
L (mm) 300-500 600-800
>50
Trunking method A
Click fit male plug part into female socket. Affix next system,
only after linking. Maximum amount of linking: 10pcs
Trunking method B
Use connector jack cable for linking, as required.
Maximum amount of linking: 10pcs
16.7
33.4
14.2
2-
4
16.7
33.4
14.2
2-
4

BN013C
Mounting Instruction
Philips Lighting Luminaires (Shanghai) Co., Ltd.
Address: 2F, Building 6, No. 1805, Huyi Highway, Malu Town,
Jiading District, Shanghai, P.R. China
Postal code: 201801
V1.0
SmartBirght LED Batten
This marking indicates that this product should not be disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
Please read this manual carefully before using the product.
1. For indoor use only.
2. Do not switch on before complete installation.
3. The luminaire shall be installed by a qualified electrician and wired in accordance with the latest IEE electrical
regulations or the national requirements.
4. The external flexible cable or cord of this luminaire cannot be replaced; if the cord is damaged, the luminaire shall be
destroyed.
5. The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire
shall be replaced.
6. The luminaire is complied with AS/NZS 60598.
7. Luminaire must not be used or stored in corrosive environment where hazardous materials such as Sulphur, Chlorine,
phthalates,
etc., are present.
8. This product allows maximun10 pcs trunking (via connector or end to end trunking). For your safety concern, the
connection of BN013C with any other product is prohibited. And make sure to keep the last male socket open.
9. Max current of power cable: 2A.
