Philips Vari-lite VL3500 Wash FX Luminaries User manual

VARI❋LITE® is a trademark owned by Genlyte Thomas Group LLC and is registered in the United States and other countries.
VL500™, VL1000™,VL2000™, VL2201™, VL2202™, VL2400™ (and the individual product designations), VL3000™, VL3500™, Series 500™, Series
1000™, Series 2000™, Series 3000™, DICHRO❋TUNE™,VARI❋IMAGE™,VARI❋BRITE™, and the Vari-Lite Asterisk are also trademarks owned by
Genlyte Thomas Group LLC.
VARI❋LITE® products are protected by one or more of the following patents, and other pending patent applications worldwide:
U. S. Patents No. 6,809,869; 6,796,682; 6,769,792; 6,578,987; 6,550,939; 6,282,027; 6,123,436; 6,113,252; 6,046,861; 6,031,749; 6,011,640; 5,969,868;
5,959,768; 5,934,794; 5,882,107; 5,829,868; 5,825,548; 5,798,619; 5,774,273; 5,769,527; 5,758,956; 5,728,994; 5,640,061; 5,590,954; 5,454,477; 5,432,691;
5,367,444; 5,329,431; 5,307,295; 5,282,121; 5,278,742; 5,209,560; 5,186,536; 5,073,847; 5,010,459; 4,980,806; 4,972,306; 4,800,474; 4,779,176; 4,701,833;
4,602,321;
U. S. Design Patents No. 524,245; 457,678; 452,339; 451,890; 442,944; 439,356; 420,332; 417,300; 415,301; 414,888; 413,995; 377,338; 366,712; 359,574;
350,408; 347,113;
Australia Patents No. 693,691; 683,695; 667,109; 649,264; 646,588; 586,095; 576,400;
Australia Design Patents No. 128,796; 128,795;
Canada Patents No. 2,070,670; 2,050,375; 1,270,675; 1,259,058;
Canada Design Patents No. 81,234; 81,233; 76,046;
European (UK) Patents No. 0 652 400; 0 586 049; 0 565 218; 0 547 732; 0 534 710; 0 495 305; 0 474 202; 0 379 970; 0 253 082; 0 253 081; 0 248 974; 0 192
882;
Germany Patents No. 694 25 943.8; 693 14 122.0; 692 08 615.3; 692 07 692.1; 691 31 478.0; 691 21 029.2; 690 33 385.4; 37 89 166.9; 37 68 727.1; 37 51
804.6; 37 50 201.8; 35 87 270.5;
Germany Design Patents No. M 98 01 745.4; M 96 04 515.9; M 96 04 514.0; M 94 07 689.8; M 94 02 951.2; M 499 03 583.6; M 498 11 203.9; G 93 12 884.3;
Spain Patents No. 2 090 191; 2 084 289; 2 020 960; 0 548 328;
Spain Utility Model Patent No. 2.031.748;
Spain Design Patents No. 0.137.502; 0.137.501; 0.133.573;
Greece Patent No. 910.400.544;
Japan Patents No. 2,843,696; 2,059,669; 2,055,324; 2,002,168; 1,966,525; 1,889,481; 1,792,721; 1,770,241;
Japan Design Patents No. 985,985-1; 985,985; 947,552; 945,436-1; 945,436; 1,106,089; 1,077,598; 1,072,598; 1,060,414; 1,002,123;
Korea Patents No. 76,310; 42,639; 283,770; 181,180;
Korea Design Patents No. 209,896; 209,895;
Mexico Patent No. 180,148;
Taiwan Patents No. 78,726; 66,975; 65,380; 28,275;
United Kingdom Design Registrations No. 2082526; 2072562; 2056387; 2056386; 2042174; 2038212; 2033108; 2029499.
All other brand or product names which may be mentioned in this manual are trademarks or registered trademarks of their respective companies or
organizations.
Vari-Lite
A Philips Group Company
10911 Petal Street
Dallas, Texas 75238 USA
This manual is for informational use only and is subject to change without notice. Vari-Lite assumes no responsibility or liability for any claims resulting from
errors or inaccuracies that may appear in this manual.
Version as of: 10-June-2009
Part number: 02.9678.0018 B
VL3500™ & VL3500™Q Spot Luminaire Service Manual
©2003-2009, Vari-Lite, a Philips group company. All Rights Reserved.

FOREWORD
02.9678.0018 B i
How To Obtain Warranty Service
A copy of the Vari-Lite Limited Warranty was included in the shipping package for this VARI❋LITE®
product.
To obtain warranty service, please contact customer service at 1-877-VARI-LITE (1-877-827-4548),
[phone], or [email protected] and request a Return Material
Authorization (RMA) for warranty service. You will need to provide the model and serial number of
the item being returned, a description of the problem or failure and the name of the registered user or
organization. If available, you should have your sales invoice to establish the date of sale as the
beginning of the warranty period.
Once you obtain the RMA, pack the unit in a secure shipping container or in its original packing box.
Fill out the RMA form included at the end of this manual and place in shipping container along with a
copy of your invoice (if available). Write the RMA number legibly on or near the shipping address
label and return the unit, freight prepaid to:
Vari-Lite
10911 Petal Street
Dallas, Texas 75238 USA
Attention: Warranty Service
As stated in the warranty, it is required that the shipment be insured and FOB our service center.
Note: The Series 3500 Luminaires share many common assemblies and parts of the VARI❋LITE®
Series 3000 Luminaires.

VARI❋LITE®- VL3500™ SPOT LUMINAIRE SERVICE MANUAL
ii 02.9678.0018 B
Compliance Notice
This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when this equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with Vari-Lite system, service, and safety guidelines, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his/her own expense.
Declaration of Conformity
We declare, under our sole responsibility, that this product complies with the relevant clauses of the
following standards and harmonized documents:
Safety
EN 60598-1:2000 Luminaire Safety Standard, General Requirements
EN 60598-2 17:1989/A2: 1991 Specification for Luminaires for Stage and Studio Lighting
EMC
EN 61000-6-4: 2001 Radiated and Conducted Emissions
We certify that the product conforms to the protection requirements of council directives: 73/23/EEC
(LVD) and 89/336/EEC (EMC)
FCC

FOREWORD
02.9678.0018 B iii
Safety Notice
It is extremely important to read ALL safety information and instructions provided in this manual and
any accompanying documentation before installing and operating the products described herein. Heed
all cautions and warnings during installation and use of this product.
Safety symbols used throughout this manual are as follows:
GENERAL INFORMATION PERTAINING TO PROTECTION AGAINST ELECTRICAL SHOCK,
FIRE, EXPOSURE TO EXCESSIVE UV RADIATION, AND INJURY TO PERSONS CAN BE
FOUND BELOW.
WARNING:
INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST FIRE
1. VARI❋LITE® luminaires have been designed for use with specific lamp types. The VL3500 Spot
luminaires require an Osram HMI 1200 W/S metal halide lamp. Installing another type of lamp
may be hazardous.
2. Luminaires may be mounted on any type of surface as long as mounting instructions are followed.
See instructions detailed in this manual.
3. Note distance requirement from combustible materials or illuminated objects for VARI❋LITE®
luminaires.
WARNING:
INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST ELECTRICAL SHOCK
1. VARI❋LITE® luminaires are designed for dry locations only. Exposure to rain or moisture may
damage luminaire.
2. Disconnect power before servicing any VARI❋LITE® equipment.
3. Servicing to be performed by qualified personnel only.
CAUTION advising of potential damage to product.
WARNING advising of potential injury or death to persons.

VARI❋LITE®- VL3500™ SPOT LUMINAIRE SERVICE MANUAL
iv 02.9678.0018 B
WARNING:
INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST EXCESSIVE EXPOSURE
TO UV RADIATION
1. Many VARI❋LITE® luminaires use a lamp that produces UV radiation. DO NOT look directly at
lamp.
2. It is hazardous to operate luminaires without lens or shield. Shields, lenses, or ultraviolet screens
shall be changed if they have become visibly damaged to such an extent that their effectiveness is
impaired. For example, by cracks or deep scratches.
WARNING:
INSTRUCTIONS FOR PROTECTION AGAINST INJURY TO PERSONS
1. Exterior surfaces of the luminaire will be hot during operation. Use appropriate safety equipment
(gloves, eye protection, etc.) when handling and adjusting hot equipment and components.
2. Luminaires will have a hot lamp when operating. Disconnect power and allow lamp to cool before
replacing.
3. Arc lamps emit ultraviolet radiation which can cause serious skin burn and eye inflammation.
Additionally, arc lamps operate under high pressure at very high temperatures. Should the lamp
break, there can exist a danger of personal injury and/or fire from broken lamp particles being
discharged.
4. Wear eye protection when relamping.
5. Appropriate safety equipment (gloves, eye protection) should be used when handling damaged
lamps.
6. If lamp is touched with bare hands, clean lamp with denatured alcohol and wipe with lint-free
cloth before installing or powering up the luminaire.
7. The lamp shall be changed if it has become damaged or thermally deformed.
WARNING:
RF INTERFERENCE
1. This is a Class A product. In a domestic environment this product may cause radio interference, in
which case, the user may be required to take adequate measures.
ARC LAMP CHARACTERISTIC CONSIDERATIONS
1. Arc lamps require a period of time to relight after a power interruption or a severe voltage dip. In
some cases, the lamp will automatically relight after it has cooled depending on Lamp Power-Up
State configuration setting.
2. Burning position is universal.

FOREWORD
02.9678.0018 B v
Sicherheitshinweise
Es ist äußerst wichtig, ALLE Sicherheitsinformationen und -hinweise in diesem Handbuch und dem
beiliegenden Informationsmaterial zu lesen, bevor Sie die hierin beschriebenen Produkte installieren
bzw. bedienen. Halten Sie bei der Installation und dem Einsatz dieses Produkts alle Warnhinweise und
Vorsichtsmaßnahmen ein.
Folgende Sicherheitssymbole werden in diesem Handbuch verwendet:
NACHSTEHEND FINDEN SIE ALLGEMEINE HINWEISE ÜBER
SICHERHEITSVORKEHRUNGEN GEGEN ELEKTROSCHOCK, FEUER, ÜBERHÖHTE UV-
STRAHLUNG UND KÖRPERVERLETZUNGEN.
WARNUNG:
HINWEISE ZUM FEUERSCHUTZ
1. VARI❋LITE®-Scheinwerfer sind ausschließlich für den Einsatz mit bestimmten Lampentyps.
Achten Sie auf den Lampentyp (Osram HMI 1200 W/S metal halide lamp), bevor Sie die
jeweiligen Lampen ersetzen. Die Installation eines anderen Lampentyps kann gefährlich sein.
2. Scheinwerfer können auf jeder beliebigen Oberfläche montiert werden, solange Sie die
Montageanweisungen befolgen. Detaillierte Hinweise finden Sie in diesem Handbuch.
3. Beachten Sie die Einhaltung des erforderlichen Sicherheitsabstandes der VARI❋LITE®-
Scheinwerfer von brennbarem Material oder beleuchteten Objekten.
WARNUNG:
HINWEISE ZUM SCHUTZ GEGEN ELEKTROSCHOCK
1. VARI❋LITE®-Scheinwerfer eignen sich ausschließlich für trockene Standorte. Regen oder
Feuchtigkeit können die Scheinwerfer beschädigen.
2. Unterbrechen Sie die Stromzufuhr, bevor Sie mit der Arbeit an VARI❋LITE®-Geräten beginnen.
3. Die Geräte sollten nur von qualifiziertem Personal gewartet werden.
VORSICHT - weist auf möglichen Produktschaden hin.
WARNUNG - weist auf mögliche Körperverletzung und Lebensbedrohung hin.

VARI❋LITE®- VL3500™ SPOT LUMINAIRE SERVICE MANUAL
vi 02.9678.0018 B
WARNUNG:
HINWEISE ZUM SCHUTZ GEGEN ÜBERHÖHTE UV-STRAHLUNG
1. Viele VARI❋LITE®-Scheinwerfer verwenden die Lampentyp, der UV-Strahlen abgibt.
SCHAUEN SIE NICHT direkt in die Lampe.
2. Es ist gefährlich, Leuchten ohne Linsen oder Blenden zu bedienen. Blenden, Linsen oder
Ultraviolettschirme müssen ausgetauscht werden, sofern deren Schutzwirkung durch sichtbare
Beschädigung (z. B. Sprünge oder Schrammen) eingeschränkt ist.
WARNUNG:
HINWEISE ZUM SCHUTZ GEGEN KÖRPERVERLETZUNGEN
1. Bei Betrieb sind die Außenflächen der Scheinwerfer heiß. Verwenden Sie bei der Bedienung von
aufgeheizter Apparatur die jeweils geeignete Sicherheitsausrüstung (Handschuhe, Augenschutz
etc.).
2. Bei Betrieb der Scheinwerfer ist die Lampe heiß. Unterbrechen Sie die Stromzufuhr und lassen Sie
die Lampe abkühlen, wenn Sie diese austauschen.
3. Bogenlampen senden ultraviolette Strahlen aus, die Hautverbrennungen und Augenentzündungen
verursachen können. Der Betrieb von Bogenlampen erfolgt unter Hochdruck und bei hohen
Temperaturen. Sollte die Lampe zerbrechen, besteht die Gefahr von Körperverletzung bzw. von
Feuer, das von Lampenteilen ausgelöst werden kann.
4. Tragen Sie beim Austausch der Lampen einen Augenschutz.
5. Die geeignete Sicherheitsausrüstung (Handschuhe, Augenschutz) sollte beim Umgang mit
beschädigten Lampen verwendet werden.
6. Wenn die Lampe mit bloßen Händen berührt wird, reinigen Sie sie mit denaturiertem Alkohol und
einem flusenfreien Tuch, bevor Sie die Scheinwerfer installieren oder in Betrieb nehmen.
7. Wenn die Lampe beschädigt oder durch Hitzeeinwirkung deformiert ist, muß diese ausgetauscht
werden.
WARNUNG:
HF-INTERFERENZ
1. Es handelt sich um ein Produkt der Klasse A. In einer Wohnumgebung kann das Produkt Hochfre-
quenzstörungen verursachen. In diesem Fall müssen eventuell geeignete Maßnahmen getroffen
werden.
BESONDERHEITEN VON BOGENLAMPEN
1. Bogenlampen benötigen eine gewisse Zeitdauer, um nach einem Stromausfall oder einem
Spannungsgefälle wieder aufzuleuchten. In einigen Fällen wird die Lampe nach Abkühlung
automatisch wieder aufleuchten, je nach der Systemkonfigurationseinstellung des Lampenein-
schaltungsstatus.
2. Die Brennposition ist Universal.

FOREWORD
02.9678.0018 B vii
Notes de sécurité
Avant de procéder à l’installation des produits décrits dans ce guide et de les mettre en marche, il est
extrêmement important de lire TOUS les renseignements et TOUTES les directives de sécurité
contenues dans ce guide ainsi que toute documentation jointe. Tenir compte de tous les avertissements
et suivre toutes les précautions pendant l’installation et l’utilisation de cet appareil.
Les symboles de sécurité utilisés dans ce guide sont les suivants :
CETTE SECTION CONTIENT DES INFORMATIONS GÉNÉRALES POUR SE PROTÉGER
CONTRE LES DÉCHARGES ÉLECTRIQUES , LES INCENDIES, L’EXPOSITION EXCESSIVE
AUX RAYONS UV ET TOUT AUTRE ACCIDENT POUVANT ENTRAÎNER DES BLESSURES.
AVERTISSEMENT:
DIRECTIVES POUR SE PROTÉGER CONTRE LES INCENDIES
1. Les luminaires VARI❋LITE® ont été conçus pour être utilisés uniquement avec certaines type de
lampes. Vérifier le type de lampe (Osram HMI 1200 W/S metal halide lamp) avant de remplacer
les lampes. L’installation d’un autre type de lampe peut poser un danger.
2. Les luminaires peuvent être fixés sur tout type de surface tant que les directives de montage sont
respectées. Voir les explications détaillées dans ce guide.
3. Vérifier la distance à respecter entre les matériaux combustibles ou les objets illuminés et les
luminaires VARI❋LITE®.
AVERTISSEMENT:
DIRECTIVES POUR SE PROTÉGER CONTRE LES DÉCHARGES ÉLECTRIQUES
1. Les luminaires VARI❋LITE® sont conçus pour une utilisation au sec uniquement. Une
exposition à la pluie et à l’humidité risque d’endommager le luminaire.
2. Débrancher l’appareil avant de procéder à la révision de tout matériel VARI❋LITE®.
3. Les révisions doivent être effectuées uniquement par des personnes qualifiées.
ATTENTION Ce symbole annonce que l’appareil risque d’être endommagé.
AVERTISSEMENT Ce symbole annonce qu’il y a risque d’accident grave ou même fatal.

VARI❋LITE®- VL3500™ SPOT LUMINAIRE SERVICE MANUAL
viii 02.9678.0018 B
AVERTISSEMENT:
DIRECTIVES POUR SE PROTÉGER CONTRE UNE EXPOSITION EXCESSIVE AUX
RAYONS UV
1. Plusieurs luminaires VARI❋LITE® utilisent une lampe qui produit des rayons UV. NE PAS fixer
son regard sur la lampe.
2. L’utilisation des luminaires sans lentille ou blindage pose des risques. Tous blindages, lentilles ou
écrans ultraviolet visiblement endommagés au point que leur efficacité en est affectée doivent être
remplacés, par exemple s’il y a des fissures ou de profondes rayures.
AVERTISSEMENT:
DIRECTIVES POUR SE PROTÉGER CONTRE LES ACCIDENTS POUVANT ENTRAÎNER
DES BLESSURES
1. Les surfaces externes du luminaire deviennent brûlantes quand l’appareil est en marche. Pour
manœuvrer ou ajuster des appareils brûlants et leurs composants, se protéger suffisamment (gants,
protection pour les yeux, etc.).
2. La lampe du luminaire est brûlante lorqu’il est en marche. Débrancher le courant et attendre que la
lampe ait refroidi avant de la remplacer.
3. Les lampes à arc émettent des rayons ultraviolets pouvant causer de graves brûlures sur la peau et
une inflammation des yeux. De plus, les lampes à arc fonctionnent sous haute tension à de très
hautes températures. Si la lampe se casse, les particules de la lampe cassée peuvent causer
blessures et/ou incendie en s’éparpillant.
4. Se protéger les yeux pour remplacer la lampe.
5. Utiliser des appareils de protection appropriés (gants, protection des yeux) pour manier des lampes
endommagées.
6. Si la lampe a été touchée avec des mains nues, la nettoyer avec de l’alcool dénaturé et l’essuyer
avec un chiffon non-pelucheux avant d’installer ou de brancher le luminaire.
7. Si la lampe a été endommagée ou a reçu une déformation thermique, elle doit être remplacée.
AVERTISSEMENT:
INTERFÉRENCE RF
1. Cet appareil est de Classe A. Dans un environnement domestique, cet appareil peut causer des
interférences radio, et si c’est le cas, l’utilisateur peut avoir à prendre des mesures adéquates.
CONSIDÉRATIONS DES CARACTÉRISTIQUES DE LAMPES À ARC
1. Après une interruption de courant ou une baisse importante de voltage, les lampes à arc mettent du
temps avant de se rallumer. Dans certains cas, la lampe se rallumera automatiquemet après s’être
refroidie. Cela dépend de la manière dont le système est réglé pour le statut de mise en marche de
la lampe.
2. La position Brûler est Universelle.

FOREWORD
02.9678.0018 B ix
Aviso sobre Seguridad
Es muy importante leer TODA la información e instrucciones sobre seguridad que se indica en este
manual así como en los documentos adjuntos antes de instalar y operar los productos descritos. Se
debe prestar atención a todos los avisos y advertencias durante la instalación y uso de este producto.
Los símbolos de seguridad usados en este manual son los siguientes:
LA INFORMACIÓN GENERAL RELACIONADA A LA PROTECCIÓN CONTRAGOLPES DE
CORRIENTE ELÉCTRICA, INCENDIO, EXPOSICIÓN EXCESIVA A RADIACIÓN ULTRA
VIOLETA Y LESIONES A LAS PERSONAS SE PUEDE ENCONTRAR SEGUIDAMENTE:
ADVERTENCIA:
INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA INCENDIO
1. Las luminarias VARI❋LITE® han sido diseñadas para ser usadas solamente con algunas
lámparas. Tome nota del tipo de lámpara (Osram HMI 1200 W/S metal halide lamp) antes de
reemplazarla. Instalación de otro tipo de lámpara puede ser peligroso.
2. Las luminarias se pueden instalar en cualquier tipo de superficie siempre que se sigan las
instrucciones de instalación. Vea las instrucciones detalladas en este manual.
3. Tome nota de los requerimientos de distancia de materiales combustibles u objetos iluminados
para las luminarias VARI❋LITE®.
ADVERTENCIA:
INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA CHOQUE ELÉCTRICO
1. Las luminarias VARI❋LITE® están diseñadas solamente para lugares secos. La exposición a la
lluvia o humedad pueden dañar la luminaria.
2. Desconecte la energía antes de dar servicio a cualquier equipo de VARI❋LITE®.
3. El servicio debe ser realizado solamente por personal calificado.
CUIDADO, indica posibles daños al producto.
ADVERTENCIA, indica posibles lesiones o muerte a las personas.

VARI❋LITE®- VL3500™ SPOT LUMINAIRE SERVICE MANUAL
x 02.9678.0018 B
ADVERTENCIA:
INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA LA EXPOSICIÓN
EXCESIVA DE RADIACIÓN ULTRA VIOLETA
1. Muchas luminarias VARI❋LITE® usan un tipo de lámpara que produce radiación UV. NO mire
directamente a la lámpara.
2. Es peligroso operar luminarias sin lentes o protectores. Debe cambiar los protectores, lentes o
pantallas ultravioletas si se aprecia que han sido dañadas, y que su efectividad pudiera estar
deteriorada. Por ejemplo, si tuvieran rajaduras o raspaduras profundas.
ADVERTENCIA:
INSTRUCCIONES PARA PROTECCIÓN CONTRA LESIONES DE PERSONAS
1. Las superficies exteriores de las luminarias están calientes durante su operación. Use un equipo de
seguridad apropiado (guantes, protección para los ojos, etc.) cuando haga ajustes en el equipo y
componentes que están calientes.
2. Cuando las luminarias están en operación la lámpara estará muy caliente. Desconecte la energía y
deje que la lámpara se enfríe antes de reemplazarla.
3. Las lámparas de arco emiten radiaciones ultravioletas que pueden ocasionar serias quemaduras a la
piel e inflamación a los ojos. Además, las lámparas de arco operan a alta presión y muy alta
temperatura. Si la lámpara se rompe, puede existir el peligro de lesiones al personal o un incendio
ocasionado por las partículas de la lámpara rota que se caen.
4. Use protección para los ojos cuando vuelve a colocar una lámpara nueva.
5. Use un equipo de seguridad apropiado (guantes, protección para los ojos, etc.) cuando trabaje con
lámparas dañadas.
6. Si toca la lámpara con las manos, limpie la lámpara con alcohol desnaturalizado y con tela sin
pelusas antes de instalar o volver a conectar la luminaria.
7. Cambie la lámpara si está dañada o deformada termicamente.
ADVERTENCIA:
INTERFERENCIA RF
1. Este es un producto de Clase A. En el ambiente de la casa este producto puede ocasionar
radiointerferencia, en cuyo caso, el usuario debe tomar las medidas adecuadas.
CONSIDERACIONES SOBRE LAS CARACTERÍSTICAS DE LA LÁMPARA DE ARCO
1. Las lámparas de arco requieren un período de tiempo para volver a iluminarse después de una
interrupción de energía o de una severa caída de voltaje. En algunos casos, la lámpara se volverá a
iluminar en forma automática después que se ha enfriado dependiendo de la configuración del
sistema de energía de la lámpara.
2. La posición de encendido es universal.

FOREWORD
02.9678.0018 B xi

VARI❋LITE®- VL3500™ SPOT LUMINAIRE SERVICE MANUAL
xii 02.9678.0018 B

02.9678.0018 B 43
CHAPTER 3.
Illustrated Parts Breakdown
This chapter contains illustrated parts breakdowns for all VL3500™ Spot Luminaire assemblies.
Note: The VL3500 Series Luminaires share many common assemblies and parts
of the VARI❋LITE®Series 3000 Luminaires.
• Drawing Trees
• Top Assembly
• Head Assembly
• Yoke Assembly
• Head/Yoke PCB Assemblies
• Enclosure Assembly
• Cable Assemblies

VARI❋LITE®- VL3500™ SPOT LUMINAIRE SERVICE MANUAL
44 02.9678 . 00 1 8 B
Drawing Trees
VL3500 Spot Luminaire
Figure 3-1: VL3500 Spot Luminaire Subassembly Drawing Tree Part 1
continued next page
continued next page
continued next page
continued next page
continued on page 46
Generic Luminaire Assembly
21.9678.0010.02 Rev H (VL3500
Only)
Yoke Assembly
21.9678.0700 Rev J (VL3500)
Head Structure Assembly
21.9678.0600 Rev C (VL3500
Only)
Backcap Assembly
21.9678.0615 Rev T (VL3500
Only)
Tilt Motor Assembly
21.9678.0765 Rev E
Yoke Fan Assembly
22.9661.0609 Rev C (VL3500)
Ignitor to Relay Cable Assembly
25.9661.1526 Rev C
Yoke Fan and Relay (Standard)
Cable Assembly
25.9678.0681 Rev C (VL3500
Only)
Yoke Fan (Standard) Cable
Assembly
25.9678.0758 Rev A (VL3500
Only)
Upper Enclosure Assembly
21.9678.0800.02 Rev NN
(VL3500 Only)
Head Cover Assembly
21.9678.8611 Rev -
Hot Box Assembly
21.9678.8698.01 Rev F
Dual Fan Tray Duct (Standard)
Assembly
21.9678.0660.03 Rev B (VL3500
Only)
Shutter Cable Interconnect
Assembly
21.9678.1246 Rev A
Spot Optic Assembly
22.9678.0103 Rev S
Gobo Clamp Assembly
22.9678.0693 Rev A
Edge Lead Screw Assembly
22.9678.1126 Rev B
VL3500 Controller PCB Assembly
24.9678.4730 Rev F
Color Clamp Assembly
22.9678.0694 Rev A
Relay to Gobo Fan Interlock Cable
Assembly
25.9678.0675 Rev B
Front Head Fans Cable Assembly
25.9678.0677 Rev B
Chassis To Yoke Ground Cable
Assembly
25.9661.1520 Rev C
Head Controller Cable Assembly
25.9678.1715 Rev A
Included Items Kit, Spot
28.9678.0020 Rev E
VL3500 Spot Luminaire
20.9678.0019 Rev H (VL3500 Only)
Gobo/Shutter Assembly
21.9678.1200 Rev G
Color/Dimmer/Strobe Assembly
22.9678.0402 Rev N (VL3500)
Transfer Fan Assembly
21.9678.1263 Rev 0
Rod Clamp Assembly
22.9678.0149 Rev B
Head Front Fan (Standard)
Assembly
23.9678.0684 Rev 0 (VL3500
Only)

DRAWING TREES : VL3500 SPOT LUMINAIRE
02.9678.0018 B 45
3
VL3500 Spot Luminaire (continued)
Figure 3-2: VL3500 Spot Luminaire Subassembly Drawing Tree Part 2
Shutter Motor Disk Assembly
21.9678.1515 Rev E
continued from previous page
Zoom Cam Assembly
22.9678.1106 Rev B
Zoom Motor Tensioning Assembly
22.9678.1113 Rev B
Interconnect Light Shield
Assembly
22.9678.1115 Rev D
Group 4 Lens Assembly
22.9678.0199 Rev 0
Spot Optic Assembly
22.9678.0103 Rev S
continued from previous page
Left Edge Bearing Assembly
22.9678.1105 Rev C
Right Edge Bearing Assembly
22.9678.1103 Rev C
continued from previous page
Gobo/Shutter Assembly
21.9678.1200 Rev G
Long Shaft Motor Assembly
21.9678.0243 Rev 0
Rotating Gobo Wheel Assembly,
Shutter
21.9678.1205 Rev B
Shutter Assembly
21.9678.1510 Rev J
Roller Pivot Rotate Assembly
21.9678.1555 Rev 0
Shutter Rotate Roller Assembly
22.9678.1550 Rev B
Gobo/Rotate Interconnect Cable
Assembly
25.9678.1209 Rev A
Rotating Gobo Wheel Assembly
21.9678.1210 Rev 0
Fixed Gobo Wheel Assembly
21.9678.1410 Rev B
Color/Dimmer/Strobe
Assembly
22.9678.0402 Rev N (VL3500)
Fixed Color Wheel Assembly
21.9678.0334 Rev D
Strobe Assembly
22.9678.0403 Rev F (VL3500
Only)
Dimmer Wheel Assembly
22.9678.0435 Rev D
Motor/Adapter Plate Assembly
21.9678.0331 Rev 0
Dimmer Wheel Assembly
22.9678.0435 Rev D
Color Sensor PCB #1 Mount
Assembly
22.9678.0481 Rev B
Color Sensor PCB #2 Mount
Assembly
22.9678.0489 Rev B
Color Interconnect PCB/Cable
Assembly
25.9678.1409 Rev B (VL3500
Only)
Right Strobe Blade Assembly
22.9678.0467 Rev C
Left Strobe Blade Assembly
22.9678.0468 Rev C
Backcap Assembly
21.9678.0615 Rev T (VL3500
Only)
80mm Fan Assembly
21.9678.0619 Rev B (VL3500
and VL3500 Quiet)
UV Filter Bulkhead Assembly
22.9678.0639 Rev G (VL3500)
Yoke to AC Fan Cable Assembly
25.9678.0012 Rev A
Backcap Interlock to Gobo Fan
Interlock Cable Assembly
25.9678.0014 Rev B
Air Duct OT Switch Cable
Assembly
25.9678.0691 Rev 0
continued from previous page

VARI❋LITE®- VL3500™ SPOT LUMINAIRE SERVICE MANUAL
46 02.9678 . 00 1 8 B
VL3500 Spot Luminaire (continued)
Figure 3-3: VL3500 Spot Luminaire Subassembly Drawing Tree Part 3
continued from page 44
Ventilation Cover Assembly -
Standard
21.9678.1254 Rev 0
Pan Pulley Assembly
21.9678.0807 Rev E
Pan Motor Assembly
21.9678.0864 Rev E
Pan Tube Assembly
21.9678.0881 Rev 0
Upper Enclosure Fan Assembly
23.9678.0686 Rev 0
Upper Enclosure Assembly
21.9678.0800.02 Rev NN (VL3500
Only)
Panel Assembly
21.9678.0805 Rev N
DMX Input PCB
24.9663.3895
AC Input Pigtail Cable Assembly
21.9678.0807 Rev E
Pan EOT Sensor Electrical
Assembly
23.9678.0687 Rev A
LVS Chassis Ground Cable
Assembly
25.9661.1514 Rev A
Chassis To Yoke Ground Cable
Assembly
25.9661.1520 Rev C
EMI Filter to Power Switch Cable
Assembly
25.9678.0811 Rev C
AC Input Splitter Cable
Assembly
25.9678.0812 Rev E
Data I/O Link Cable Assembly
25.9678.0813 Rev A
Ballast to Controller Cable
Assembly
25.9678.0816 Rev A
Pan/Tilt Control Cable Assembly
25.9678.0818 Rev B
DC Output Cable Assembly
25.9678.0821 Rev E
Display Cable Assembly
25.9678.1825 Rev C
Lamp Supply to Relay Cable
Assembly
25.9678.0829 Rev A
Gobo/Rotate Interconnect Cable
Assembly
25.9678.0843 Rev A
LVS Chassis Ground Cable
Assembly
25.9678.1716 Rev A

DRAWING TREES : VL3500Q SPOT LUMINAIRE
02.9678.0018 B 47
3
VL3500Q Spot Luminaire
Figure 3-4: VL3500Q Spot Luminaire Subassembly Drawing Tree Part 1
continued next page
continued next page
continued next page
continued next page
continued on page 46
Generic Luminaire Assembly
21.9678.0011.02 Rev C (VL3500Q
Only)
Yoke Assembly
21.9678.0701 Rev B (VL3500Q)
Head Structure Assembly
21.9678.0601 Rev 0 (VL3500Q
Only)
Backcap Assembly
21.9678.0616 Rev H (VL3500Q
Only)
Tilt Motor Assembly
21.9678.0765 Rev E
Yoke Fan Assembly
22.9678.0609 Rev A (VL3500Q)
Ignitor to Relay Cable Assembly
25.9661.1526 Rev C
Yoke Fan and Relay (Quiet) Cable
Assembly
25.9678.0781 Rev A (VL3500Q
Only)
Yoke Fan (Quiet) Cable Assembly
25.9678.0759 Rev A (VL3500Q
Only)
Upper Enclosure Assembly
21.9678.0801.02 Rev Z
(VL3500Q Only)
Head Cover Assembly
21.9678.8611 Rev -
Hot Box Assembly
21.9678.8698.01 Rev F
Dual Fan Tray Duct (Quiet)
Assembly
21.9678.0659.03 Rev D
(VL3500Q Only)
Shutter Cable Interconnect
Assembly
21.9678.1246 Rev A
Spot Optic Assembly
22.9678.0103 Rev S
Gobo Clamp Assembly
22.9678.0693 Rev A
Edge Lead Screw Assembly
22.9678.1126 Rev B
VL3500 Controller PCB Assembly
24.9678.4730 Rev F
Color Clamp Assembly
22.9678.0694 Rev A
Relay to Gobo Fan Interlock Cable
Assembly
25.9678.0675 Rev B
Front Head Fans Cable Assembly
25.9678.0677 Rev B
Chassis To Yoke Ground Cable
Assembly
25.9661.1520 Rev C
Head Controller Cable Assembly
25.9678.1715 Rev A
Included Items Kit, Spot
28.9678.0020 Rev E
VL3500Q Spot Luminaire
20.9678.0020 Rev I (VL3500Q Only)
Gobo/Shutter Assembly
21.9678.1200 Rev G
Color/Dimmer/Strobe Assembly
22.9678.0462 Rev E (VL3500Q)
Transfer Fan Assembly
21.9678.1263 Rev 0
Rod Clamp Assembly
22.9678.0149 Rev B
Head Front Fan (Quiet)
Assembly
23.9678.0699 Rev A
(VL3500Q Only)

VARI❋LITE®- VL3500™ SPOT LUMINAIRE SERVICE MANUAL
48 02.9678 . 00 1 8 B
VL3500Q Spot Luminaire (continued)
Figure 3-5: VL3500Q Spot Luminaire Subassembly Drawing Tree Part 2
Shutter Motor Disk Assembly
21.9678.1515 Rev E
continued from previous page
Zoom Cam Assembly
22.9678.1106 Rev B
Zoom Motor Tensioning Assembly
22.9678.1113 Rev B
Interconnect Light Shield
Assembly
22.9678.1115 Rev D
Group 4 Lens Assembly
22.9678.0199 Rev 0
Spot Optic Assembly
22.9678.0103 Rev S
continued from previous page
Left Edge Bearing Assembly
22.9678.1105 Rev C
Right Edge Bearing Assembly
22.9678.1103 Rev C
continued from previous page
Gobo/Shutter Assembly
21.9678.1200 Rev G
Long Shaft Motor Assembly
21.9678.0243 Rev 0
Rotating Gobo Wheel Assembly,
Shutter
21.9678.1205 Rev B
Shutter Assembly
21.9678.1510 Rev J
Roller Pivot Rotate Assembly
21.9678.1555 Rev 0
Shutter Rotate Roller Assembly
22.9678.1550 Rev B
Gobo/Rotate Interconnect Cable
Assembly
25.9678.1209 Rev A
Rotating Gobo Wheel Assembly
21.9678.1210 Rev 0
Fixed Gobo Wheel Assembly
21.9678.1410 Rev B
Color/Dimmer/Strobe
Assembly
22.9678.0462 Rev E (VL3500Q)
Fixed Color Wheel Assembly
21.9678.0334 Rev D
Strobe (Quiet) Assembly
22.9678.0463 Rev B (VL3500Q
Only)
Dimmer Wheel Assembly
22.9678.0435 Rev D
Motor/Adapter Plate Assembly
21.9678.0331 Rev 0
Dimmer Wheel Assembly
22.9678.0435 Rev D
Color Sensor PCB #1 Mount
Assembly
22.9678.0481 Rev B
Color Sensor PCB #2 Mount
Assembly
22.9678.0489 Rev B
Color Interconnect (Quiet)
PCB/Cable Assembly
25.9678.1419 Rev A
(VL3500Q Only)
Right Strobe Blade Assembly
22.9678.0467 Rev C
Left Strobe Blade Assembly
22.9678.0468 Rev C
Backcap Assembly
21.9678.0616 Rev H (VL3500Q
Only)
80mm Fan Assembly
21.9678.0619 Rev B (VL3500
and VL3500 Quiet)
UV Filter Bulkhead Assembly
22.9678.0617 Rev D (VL3500
Q)
Yoke to AC Fan Cable Assembly
25.9678.0012 Rev A
Backcap Interlock to Gobo Fan
Interlock Cable Assembly
25.9678.0014 Rev B
Air Duct OT Switch Cable
Assembly
25.9678.0690 Rev 0 (VL3500Q)
continued from previous page
