BEAUTY GUIDE
Why is skin cleansing so important?
C◗Cleansing is the first step
Facial cleansing is a basic element of women's
beauty regime.It is a prerequisite for proper
skincare.Cleansing the face prepares the skin for
other treatments such as moisturising,deep
cleansing or nourishing.
If you do not cleanse your skin properly,the pores
may clog up,possibly causing blackheads or
blemishes,or a residue may develop which slows
down the natural process of sloughing off skin
cells.
◗The benefits of exfoliation
The purpose of exfoliating is to remove dead skin
cells to reveal a radiant,youthful skin.Exfoliation
makes room at the skin's surface to allow the
deeper layer of newer,less dry skin cells to reach
the surface of the skin.Dried-up skin cells left on
the surface of the skin too long can produce a
dull,uneven and flaky layer.
Removing these dead skin cells can make a huge
difference to the appearance of the face and
lends a fresher look to the skin.The more you
stimulate the normal process of exfoliation of skin
cells,the less cell debris can fill up and clog the
pores,the easier blackheads can be removed and
the more radiant your skin will look.
ENGLISH4

Thus,a thorough but gentle facial cleansing is
essential to preserve your skin by preventing skin
breakouts and by keeping your skin healthier.
How doesVisapure guarantee an optimal
(thorough and gentle) cleansing?
Together with the Philips Personal Care Institute
(a network of research and testing institutes
around the world) and dermatologists,we
carefully develop our Philips beauty products to
help make women's beauty routine more
effective and more enjoyable.
C◗Unique brushes
The newVisapure has specially developed soft
brushes which gently rotate to deeply cleanse
your skin.They can be used every day with your
regular cleansing product or for special intensive
cleansing.The brushes remove dirt and dead skin
cells,leaving your skin smooth and radiant.
C◗Soft Pressure Sensor
A built-in system automatically adjusts the
pressure of the brush on your face to guarantee
optimal and gentle cleansing.Two different
intensity settings are available:you can use the soft
setting (left) for a gentle treatment and the
intensive setting (right) for a deeper cleansing.
These settings also allow you to adjust the
intensity of the treatment to the sensitivity of
your skin,the soft setting being more pleasant on
a sensitive skin.
ENGLISH 5

Cleansing withVisapure
C◗This brush can be used with facial soap or
with your regular cleansing product (gel,milk,
etc).
◗The section 'Daily facial cleansing with the
cleansing brush' in this booklet details how to
obtain the best results withVisapure in your
cleansing routine.
C◗The curved surface of this brush follows
perfectly the contours of the face,providing
gentle and more effective cleansing.
Exfoliating withVisapure
C◗This brush can be used with your regular
cleanser or exfoliating product (scrub
gel/cream,etc).
◗The section 'Removing dead skin cells with
the exfoliating brush' in this booklet details
how to obtain the best exfoliating results with
Visapure.
C◗The longer filaments of the brush lift away
impurities and gently exfoliate dead skin cells.
This brush is highly suitable for effective deep
cleansing.
ENGLISH6

Important
◗Do not use theVisapure on dry,chapped skin
or when you suffer from skin diseases or skin
irritations,such as acne,sunburn,etc.
◗Please note that the condition of the skin
varies throughout the year.Facial skin can get
dryer during the winter season:in that case
you should reduce the treatment time.
◗Do not press the brush too hard onto your
face.Using theVisapure should always feel
pleasant.
◗When usingVisapure on the neckline,make
sure that you observe a shorter treatment
time than normally recommended.The
neckline area is more sensitive than the face.
◗Regular cleaning of the appliance ensures
optimal results and a longer life.
◗Keep the appliance away from children.
◗Use,for example,a headband to keep your
hair away from your face in order to prevent
the hair from getting tangled in the brush.
◗The appliance is waterproof and can be used
in the shower.
◗To achieve the best results,theVisapure
should be used as described on the following
pages.
ENGLISH 7

Preparing the appliance for use
Charging the appliance
When you charge the appliance for the first time,
it will take approximately 16 hours before the
battery is fully charged.
C1Place theVisapure in the charging stand.
Note:To ensure that theVisapure makes proper
contact with the charging stand,it should be
pushed into the stand as deep as possible.The
appliance has been properly inserted when you
are unable to turn it round in the stand.
Make sure the charging unit does not come into
contact with water.
2Insert the plug of the charging stand into a
wall socket.
C◗As soon as you start charging the appliance,
the green pilot light will go on.
You can put theVisapure back into the charging
stand after each use.
BTip:TheVisapure can be left to charge
continuously.However,to extend the lifetime of
the battery,we recommend that you let the
Visapure run until the motor almost stops after
having charged it for the first time.Then recharge
the appliance.Repeat this procedure at least
every 6 months.
ENGLISH8

Using theVisapure
Daily facial cleansing with the
cleansing brush
C1Push the cleansing brush onto the
connection pin until it locks into position
with a click.
2Use,for example,a headband to keep your
hair away from your face in order to
prevent your hair from getting tangled in
the brush.
If you are wearing heavy make-up,we advise you
to remove most of the make-up first.
C3Choose the 'soft' setting for daily
cleansing.
BTip:For the best result,we advise you to foam up
a small portion of your favourite cleansing product
in the palm of your hand by using the brush and
lukewarm water.You can also put the cleanser
directly onto the dampened brush.
BIf you use cleansing milk,we advise you to put it
directly onto the brush.
4Place the brush onto your face.
C5Press the on/off button to switch the
Visapure on.
ENGLISH 9

C6Gently move the brush across your face
while making circular movements.
To achieve the best cleansing result,you should
use theVisapure for approximately 1 to 2
minutes,depending on the sensitivity of your skin.
Do not overdo the cleansing.Remember that
cleansing should always feel pleasant.
BTip:While cleansing,skip sensitive skin areas such
as the eye area and the lips.
Removing dead skin cells with the
exfoliating brush
C1To exchange the brush,pull it from the
connection pin and store it carefully on
the back part of the stand.
C2Attach the exfoliating brush by pushing it
onto the connection pin until it locks into
position with a click.
3Use,for example,a headband to keep your
hair away from your face in order to
prevent your hair from getting tangled in
the brush.
4To achieve the best exfoliating results,you
should first clean your face.Then moisten
your face with lukewarm water and apply
your favourite scrub cream.
ENGLISH10

BTip:If you prefer to exfoliate only with cleansing
cream,foam up a small portion in the palm of
your hand with help of the dampened brush.You
can also put the cleanser directly onto the
dampened brush.
C5Choose the 'intensive' setting,which is
ideal for effective deep cleansing and
exfoliation.
6Place the exfoliating brush onto your face.
7Press the on/off button to switch the
Visapure on.
8Gently move the brush across your face
while making circular movements.
Do not overdo the exfoliation procedure
Remember that exfoliation should always feel
pleasant.
For an effective exfoliation,you should use the
brush for approximately 1 to 2 minutes,
depending on the sensitivity of your skin (do not
exfoliate longer or more often than
recommended on the package of your scrub
cream).
Soft Pressure Sensor
The Soft Pressure Sensor will automatically adjust
the pressure of the brush on your face to
guarantee effective and gentle cleansing.
ENGLISH 11

C◗When you press the brush onto your face,it
will spring backwards.The cushioned brush
ensures that optimal brushing pressure is
maintained and that the brush accurately
follows the contours of the face.
BTip:The appliance has two intensity settings:1)
the 'soft' setting for a gentle treatment or for
more sensitive skin areas,2) the 'intensive' setting
for deeper cleansing and more thorough
exfoliation.
Cleaning and storing
Clean the appliance and the brushes after each
use.
Do not use any alcohol,acetone,petrol,abrasive
cleaning agents etc.to clean the plastic parts.
C1Rinse theVisapure and the brushes under
the tap.Use warm water (max.60cC).
C2Also rinse the inside of the brushes.
BTip:If the filaments have become deformed,you
can restore them to their original shape by rinsing
the brush in warm water.
C3Switch theVisapure on to rinse any
cleansing residues from the drive shaft.
4Dry theVisapure and brushes with a
towel.
ENGLISH12

5Store the dryVisapure in the stand.
C6Leave one brush attached to theVisapure.
Place the second brush onto the pin on
the back part of the stand.
◗You can clean the charging stand with a moist
cloth.
Make sure the charging stand is unplugged when
you clean it.
Maintenance and replacement
Mains cord
If the mains cord is damaged,this appliance must
be discarded.
Replacement brushes
C◗Replace the brushes every 3 to 6 months for
good cleansing and exfoliation results.
Replace the brush if the deformed filaments can
no longer be restored to their original shape.
Worn filaments will move impurities around
rather than remove them.They could also irritate
your skin.
New brushes are available from the shop in
which you have purchased your Philips beauty
Visapure.If you have problems finding
replacement brushes,see under 'Guarantee &
service'.
ENGLISH 13

Environment
Remove the batteries when you discard the
appliance.Do not throw the batteries away with
the normal household waste,but hand them in at
an official collection point.You can also take the
batteries to a Philips Service Centre,which will
dispose of them in an environmentally safe way.
1Take the appliance out of the charging unit.
2Let the appliance run until the battery is
completely empty.
C3Remove the bottom part of the appliance.
C4Disange the battery and cut the wires.
Do not try to replace the battery.
Do not put the appliance back in the charging
unit after the battery has been removed.
Guarantee & service
If you need information or if you have a problem,
please visit the PhilipsWeb site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet).If there is no Customer Care Centre in
your country,turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
ENGLISH14

PANDUAN KECANTIKAN
Mengapa mencuci badan penting?
C◗Mencuci ialah langkah pertama
Mencuci muka ialah elemen asas regim kecantikan
wanita.Ianya ialah prasyarat untuk kulit yang
sempurna.Mencuci muka menyediakan kulit untuk
rawatan lain seperti melembabkan,mencuci muka
dalaman dan pemeliharaan.
Jika anda tidak mencuci muka dengan betul,liang
roma pada muka akan tersumbat,dan
menyebabkan tahi lalat atau tanda kekal,atau
bekas tinggalan setelah sekian lama yang akan
melambatkan proces menghilangkan lapisan pada
sel kulit.
◗Kebaikan eksfoliasi
Tujuan eksfoliasi ialah untuk menanggalkan sel kulit
yang telah mati dan memperlihatkan kulit yang
berseri dan kelihatan muda. Eksfoliasi
menyediakan ruang pada lapisan muka untuk
membenarkan sel lapisan dalam yang baru dan
kurang kering untuk sampai ke permukaan muka.
Sel yang telah kering yang tertinggal pada
permukaan kulit terlalu lama boleh meninggalkan
lapisan yang buruk,tidak sama dan mengelupas.
Menanggalkan sel kulit yang mati ini boleh
meninggal kesan yang besar pada perawakan
muka dan menyebabkan muka kelihatan lebih
segar.Lagi banyak stimulasi dilakukan dengan
15BAHASA MELAYU

BAHASA MELAYU16
proses eksfoliasi biasa sel kulit,lagi kurang
tinggalan menimbun dan menutup liang roma
kulit,ini memudahkan tahi lalat dibuang dan muka
anda akan jadi lebih berseri.
Jadi,mencuci muka secara lembut tetapi
menyeluruh adalah penting untuk menjaga kulit
anda supaya ianya tidak pecah dan sentiasa sihat.
BagaimanaVisapure menjamin pencucian
muka optimum(menyeluruh dan lembut)
Bersama Institut Penjagaan Peribadi Philips (satu
rangkaian institut penyelidikan dan pengujian
seluruh dunia) dan para dermatologi,kami
bersama-sama membentuk produk kecantikan
Philips secara berhati-hati untuk membantu
membuat penjagaan kecantikan harian wanita
lebih berkesan dan menyeronokkan.
C◗Berus yang unik
Visapure telah mereka khas sejenis berus yang
dengan lembut bergerak mencuci ke bahagian
dalam kulit.Ianya boleh digunakan setiap hari
dengan produk pencuci muka harian anda atau
untuk pencucian intensif khas.Berus ini
menanggalkan kotoran dan sel kulit yang mati,
meninggalkan anda kulit yang lembut dan berseri.
C◗SensorTekanan Lembut
System yang tersedia direka secara automatik
mengawal tekanan berus pada muka anda untuk
menjamin pencucian optimum dan lembut.Dua

BAHASA MELAYU 17
aturan tekanan berlainan tersedia:anda boleh
gunakan aturan lembut (kiri) untuk rawatan enak
dan aturan intensif (kanan) untuk rawatan yang
dalam. Aturan-aturan ini juga membenarkan anda
untuk mengawal tekanan rawatan untuk kulit anda
yang sensitif,aturan lembut adalah lebih enak pada
kulit yang sensitif.
Mencuci muka denganVisapure
C◗Berus ini boleh digunakan dengan sabun muka
atau dengan produk pencuci muka anda yang
lain (gel,susu,etc)
◗Bahagian "Pencucian muka harian dengan
berus pencuci muka' dalam buku panduan ini
memberi maklumat secara terperinci
bagaimana untuk mendapatkan keputusan yang
lebih baik denganVisapure dalam penjagaan
muka harian anda.
C◗Permukaan lentur berus ini mengikut dengan
teliti bentuk muka anda,memberikan
pencucian muka yang lebih lembut dan
berkesan.
Eksfoliasi denganVisapure
C◗Berus ini boleh digunakan dengan pencuci
muka biasa atau produk eksfoliasi (penggosok
gel/krim.dll)
◗Bahagian 'Menanggalkan sel kulit mati dengan
berus eksfoliasi' dalam buku panduan ini
menerangkan secara terperinci bagaimana
mendapatkan kesan eksfoliasi terbaik dengan
Visapure.

BAHASA MELAYU18
C◗Bulu yang panjang pada berus menanggalkan
bekas dan tanda dan mengeksfoliasi dengan
lembut sel kulit yang mati.Berus ini sangat
sesuai untuk pencucian muka yang mendalam.
Penting
◗Jangan gunaVisapure pada kulit yang kering
dan mengelupas atau apabila anda ada penyakit
kulit atau gatal-gatal kulit seperti kesakitan
atau kesan cahaya matahari,dll.
◗Perlu diingat bahawa keadaan kulit berbeza
sepanjang tahun.Kulit muka boleh menjadi
kering semasa musim sejuk:jika begini
keadaannya anda boleh kurangkan masa
rawatannya.
◗Jangan tekan berus terlalu kuat pada muka
anda.MenggunakanVisapure anda sepatutnya
berasa selesa selalu.
◗Apabila menggunakanVisapure pada tengkok,
pastikan masa rawatan anda pendek daripada
yang selalu dinasihatkan.Bahagian tengkok
adalah lebih sensitif daripada bahagian muka.
◗Kekerapan mencuci alatan menjamin kesan
yang optimum dan tahan lama.
◗Jauhkan alatan daripada kanak-kanak.
◗Guna,contohnya pengikat rambut untuk
menjauhi rambut mengena muka dan tidak
terbelit pada berus.
◗Alatan ini mempunyai ketahanan air dan boleh
digunakan dalam bilik mandi.

BAHASA MELAYU 19
◗Untuk mendapatkan keputusan terbaik,
Visapure perlu digunakan seperti diterangkan
di halaman seterusnya.
Menyediakan alat
Mengecas peralatan
Apabila anda mengecas peralatan untuk kali
pertama,ia akan mengambil masa kira-kira 16 jam
sebelum bateri benar-benar dicas penuh.
C1LetakkanVisapure pada penegak cas.
Nota:Untuk memastikan bahawaVisapure
mempunyai hubungan sesuai dengan tapak cas,ia
sepatut ditolak kepada penegak cas sedalam
mungkin.Peralatan telah dimasukkan betul-betul
apabila anda tidak boleh memusingkannya pusing
mengelilingi penegak.
Pastikan unit pengecas tidak terkena air.
2Masukkan plag penegak cas ke dinding
soket.
C◗Sejurus sahaja anda mula mengecas peralatan,
lampu penanda hijau akan menyala.
Anda boleh letakkanVisapure balik ke penegak
cas selepas setiap kali digunakan.
BPanduan:Visapure boleh ditinggalkan cas
berterusan,Walau bagaimanapun,untuk

BAHASA MELAYU20
panjangkan hayat bateri,kami cadangkan anda
biarkanVisapure berfungsi sehingga motor hampir
berhenti selepas mengecasnya untuk kali
pertama.Kemudian caskan semula peralatan.
Ulang prosedur ini sekurang-kurangnya setiap 6
bulan.
MenggunakanVisapure
Pencucian muka setiap hari dengan
berus pencuci muka
C1Masukkan berus pencuci muka pad pin
penyambung sehingga ia terkunci pada
kedudukannya dengan bunyi klik
2Guna,contohnya,pengikat rambut untuk
menjauhkan rambut anda daripada terbelit
pada berus.
Jika anda memakai alat penjagaan muka,kami
nasihatkan anda membuang sebahagian besar
daripadanya.
C3Pilih penyediaan 'lembut' untuk pencucian
muka harian.
BPanduan:Untuk kesan yang terbaik,kami
nasihatkan anda buihkan sedikit produk
kegemaran anda pada tapak tangan
menggunakan berus atau air suam.Anda boleh
letakkan pencuci muka terus ke berus yang
lembab.
BJika anda menggunakan susu pencuci muka,kami
nasihatkan anda meletakkan terus pada berus.

BAHASA MELAYU 21
4Letakkan berus pada muka anda.
C5Tekan butang suis untuk mengaktifkan
Visapure.
C6Dengan lembut gerakkan berus merintasi
muka anda dalam pergerakan membulat.
Untuk mendapat kesan pencucian muka yang
terbaik,anda patut gunaVisapure lebih kurang 1
atau 2 minit,bergantung pada sensitiviti kulit anda
Jangan terlebih lakukan rawatan menggunakan
pencuci muka ini.Ingatan bahawa pencucian
haruslah sentiasa rasa selesa.
BPanduan:Sewaktu mencuci muka,tinggalkan
bahagian kulit yang sensitif seperti bahagian mata
atau bibir.
Menanggalkan sel kulit yang mati
dengan berus eksfoliasi
C1Untuk menukar berus,tarikkannya
daripada sambungan pin dan simpan
dengan baik pada bahagian belakang
penegak.

BAHASA MELAYU22
C2Masukkan berus eksfoliasi dengan menolak
nya pada sambungan pin sehingga terkunci
pada kedudukannya dengan bunyi klik.
3Guna,contohnya,pengikat rambut untuk
menjauhkan rambut anda daripada terbelit
pada berus.
4Untuk mendapat kesan eksfoliasi terbaik,
anda mesti terlebih dahulu mencuci muka.
Kemudian lembabkan muka anda dengan
air suam dan sapukan krim penggosok
kegemaran anda.
BPanduan:Jika anda pilih mengeksfoliasi dengan
krim pencuci muka,buihkan sedikit pada tapak
tangan dengan menggunakan berus yang lembab.
Anda juga boleh meletakkan pencuci muka
secara terus pada berus yang lembab.
C5Pilih aturan 'intensif',yang lebih baik untuk
pencucian muka dalam yang berkesan dan
eksfoliasi
6Letakkan berus eksfoliating pada muka
anda.
7Tekan butang suis untuk mengaktifkan
Visapure.
8Dengan lembut gerakkan berus merintasi
muka anda dalam pergerakan membulat.
