Phoenix Contact FL MC 10BASE-T/FO G850 User manual

1. Description
The FL MC 10BASE-T/FO G850 medium converter
provides a high level of noise immunity and a long
transmission range in industrial applications by
converting the 10 BASE-T Ethernet interface to optical
fibers.
The device can be operated individually as well as in
modular hub stations.The supply voltage is 24V DC.
In FL hub stations, the supply voltage is supplied to all
the connected devices via a backplane integrated in
the base of the device.In individual operation, the
supply is provided using plug-in screw-clamp
terminals.
The converter has a link monitoring function, which
separately indicates/monitors the operability of the
cable connection and the connected devices for theTP
and optical fiber channels.It also automatically detects
pairs of incorrectly connected receiving cables at the
TP connection and corrects them using the auto
polarity correction function.
If long distances are to be covered or if an existing
glass fiber installation is used, the FL MC 10BASE-T/
FO G850 converter covers distances up to 2800 m
(9186.35 ft.) using multimode glass fiber.The
connection corresponds to the ST® (B-FOC) standard.
The medium converter conforms to the
specifications of standards IEEE 802.3 and ISO/IEC
68802.3.
Should you have any technical questions, please
contact us:
PSM HOTLINE: +49 - 52 35 - 31 98 90
FAX: +49 - 52 35 - 31 98 99
E-mail: [email protected]
2800 m (9186.35 ft.) glass fiber
Medium Converter
FL MC 10BASE-T/FO G850
Headquarters: © Phoenix Contact GmbH & Co. • Flachsmarktstraße 8 • 32825 Blomberg • Germany
Phone +49 - 52 35 - 3 00 • Fax +49 - 52 35 - 34 12 00 • www.phoenixcontact.com
Local Contact: www.phoenixcontact.com/salesnetwork
ST
®
is a registered trademark of AT&T.

PHOENIX CONTACT page 2 of 7
Medium Converter – FL MC 10BASE-T/FO G850
2.Technical Data
Description
Optical fiber converter ,
for converting 10 BASE-T to multimode glass fibers, (850 nm)
DIN-rail mountable, supply 24 V DC
Technical Data
Ethernet Interface
Connection
Transmission speed
TP transmission length
Signal LEDs
Optical Fiber Interface
Connection
Wavelength
Transmission length including 3 dB system reserve, minimum
Signal LEDs
General Data
Supply voltage
Nominal current consumption
Indicator
Connection
Electrical isolation
Test voltage
Housing material
Connection data for screw-clamp terminals
Ambient operating temperature range
Dimensions (W x H x D)
Electromagnetic compatibility
• Noise emission
• Noise immunity
FL MC 10BASE-T/FO G850
Housing width 22.5 mm (0.886 in.)
Type Order No.
Pcs.
Pkt.
FL MC 10BASET/FO G850 27 44 78 8 1
FL MC 10BASET/FO G850
for glass fibers
10 BASE-T in accordance with IEEE 802.3
RJ45 shielded
10 Mbps
100 m (328.08 ft.), twisted-pair, shielded
Receiving data, link status
B-FOC (ST
®
)
850 nm
• 2000 m (6561.68 ft.) glass fibers with
F-G 50/125 2.4 dB/km
• 2800 m (9186.35 ft.) glass fibers with
F-G 62.5/125 3.0 dB/km
Receiving data, link status
24 V DC ± 20%
70 mA, maximum
Green LED
Plug-in screw-clamp terminal (COMBICON)
10 BASE T//supply
1.5 kV
rms
, 1 minute
PA V0, color green
0.2-2.5 mm
2
(AWG 24-14)
0°C to +55°C (32˚F to 131˚F)
22.5 mm x 99 mm x 127 mm (0.886 in. x 3.898 in. x 5.000 in.)
c Conforms to EMC directive 89/336/EEC
EN 50 081-2
EN 61000-6-2
99
127
Figure 04
6 3 7 9 A 0 1 3
V C C
U S 1 +
G N D
2 4 V
5 V
U S 2 +
G N D
1 0
B a c k -
p l a n e
µ C
1 0 M B i t / s
1 0 B a s e - T
T D - ( 6 )
T D + ( 3 )
R D - ( 2 )
R D + ( 1 )
R D
T D
B a c k p l a n e
F O
Figure 03

PHOENIX CONTACT page 3 of 7
Medium Converter – FL MC 10BASE-T/FO G850
cc
cc
Conforms to the EMC Directive 89/336/EEC and
and the LowVoltage Directive 73/23/EEC
EMC (Electromagnetic Compatibility)
Noise immunity in accordance with EN 50082-2
• Electrostatic discharge (ESD)
• Electromagnetic HF field
Amplitude modulation
Pulsed modulation
• Fast transients (burst)
Signal:
Supply voltage:
• Surge current load (surge)
Signal:
Supply voltage:
• Conducted interference
Noise emission in accordance with EN 50081-2
EN 61000 corresponds to IEC 1000/
EN 55011 corresponds to CISPR11
1)
Criterion A: Normal operating characteristics within the specified
limits.
2)
Criterion B: Temporary adverse effects on the operating
characteristics that the device corrects independently.
Class A: Industrial application, without special
installation measures
EN 61000-4-2
EN 61000-4-3
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 55011
8 kV air discharge
2)
6 kV contact discharge
2)
10 V/m
1)
10 V/m
1)
2 kV/5 kHz
2)
4 kV/5 kHz
2)
2 kV/42 Ω
2)
0.5 kV/2 Ω
2)
10 V
1)
Class A
1 2 7 ( 5 " ) 2 2 , 5
( 0 . 8 8 6 " )
9 9 ( 3 . 8 9 8 " )
6 3 7 9 A 0 1 4
6 , 5
( 0 . 2 5 6 " )
6 1 4 5 1 0 0 1
U L
F L M C 1 0 B A S E - T
/F O -G 8 5 0
O r d . - N o . 2 7 4 4 7 8 8
T D
1
R D
2
Figure 05
Dimensional diagram

PHOENIX CONTACT page 4 of 7
1. Voltage supply 2 (24 V DC)
2. Voltage supply 1 (24 V DC)
3. Functional earth connection
4. Backplane
5. LED: Ready-to-operate (green)
6. LED: Link status FO port (green)
1
2
3
4
5
6
78
9
1 0
1 1
1 2
6 3 7 9 A 0 1 5
Figure
Medium Converter – FL MC 10BASE-T/FO G850
3. Function Elements
7. LED: Receiving data FO port (yellow)
8. LED: Link status TP port (green)
9. LED: Receiving data TP port (yellow)
10. 10Base-T connection (TP port)
11. Optical fiber connection, receiver
12. Optical fiber connection, sender

PHOENIX CONTACT page 5 of 7
Medium Converter – FL MC 10BASE-T/FO G850
4. Connection Notes
6 3 7 9 A 0 1 6
Figure 07
Control cabinet mounting
6379A017
1
M o n t a g e
D e m o n t a g e
2 3
3 2 1
U L
C O L
F L H U B 1 0 B A S E - T
O r d . - N o . 2 8 3 1 0 2 8
1
2
3
4
1
2
3
4
1
2
3
4
R E E T
U L 1
F L H U B A G E N T
O r d . - N o . 2 8 3 1 0 7 3
U L 2
C O L
1
2
3
4
00A 0451BD D
6 1 4 5 1 0 0 1
U L
F L M C 1 0 B A S E - T
/F O G 8 5 0
O r d . - N o . 2 7 4 4 7 8 8
T D
1
RD
2
6 1 4 5 1 0 0 1
U L
F L M C 1 0 B A S E - T
/F O G 8 5 0
O r d . - N o . 2 7 4 4 7 8 8
T D
1
RD
2
Figure 08
Mounting/removing the
FL hub station
6. Push the second module (from the left) along the
DIN rail to the left until the pin strip/socket strip of
both modules are interlatched and the sides of both
modules lie flush with one another.
7. Now push the other modules together from right to
left as described above.
(Figure 08).
Removal:
1. To remove a FL hub station, the FL module on the
right-hand side must be pushed to the right until the
entire pin strip/socket strip is released (Figure 08).
2. Pull the locking latch down using a screwdriver,
needle-nose pliers or similar.
3. Pull the bottom edge of the module away from the
mounting surface.
4. Pull the module diagonally upwards away from the
DIN rail.
Install the FL MC 10BASE-T/FO G850 on a DIN rail
in accordance with DIN EN 50 022 (Phoenix Contact:
item NS 35).To avoid contact resistance only use
clean, corrosion-free DIN rails.End clamps should be
mounted on both sides of the module to stop the
terminals from slipping on the DIN rail.
4.1. Mounting/Removing
Mounting:
1. Fasten an end clamp next to the left-hand module to
stop the modules from slipping.
2. Place the module onto the DIN rail from above.The
upper holding keyway must be hooked onto the top
edge of the DIN rail (Figure 07).
3. Push the module from the front towards the
mounting surface.
4. Once the module has been snapped on properly,
check that it is fixed securely on the DIN rail.
5. Snap the other modules to be contacted onto the
DIN rail side by side.
Only mount and remove modules when
the power supply is disconnected.
When connecting the supply voltage for
operation in a FL hub station, please
refer to the notes.
Attention
Disregarding this warning may result in serious
damage to persons or property.Only qualified
personnel may start up and operate these devices.
According to the safety instructions in this text,
qualified personnel are persons who are authorized
to start up, to ground and to mark devices, systems,
and equipment according to the standards of safety
technology.In addition, these persons must be
familiarwithallwarninginstructionsandmaintenance
measures in this text.
The FL MC 10BASE-T/FO G850 module is designed
exclusively for SELV operation in accordance with
IEC 60950/EN 60950/VDE 0805.
Connect the DIN rail to the protective
earth ground using a grounding terminal.
The modules are grounded when they
are snapped onto the DIN rail.This
ensures that the shield is effective.
Connect the protective earth ground with
low impedance.
Only mount and remove modules when
the power supply is disconnected.
Note:The device can be operated individually as well
as in modular FL hub stations.In a FL hub station, the
order of the various module types can be freely
selected.

PHOENIX CONTACT page 6 of 7
Medium Converter – FL MC 10BASE-T/FO G850
5. Connecting the SupplyVoltage
U 1 + G N D U 2 +
r e d u n d a n t e V e r s o r g u n g
( o p t i o n a l )
G N D
6 3 7 9 A 0 1 8
6 1 4 5 1 0 0 1
U L
F L M C 1 0 B A S E - T
/ F O G 8 5 0
O r d . - N o . 2 7 4 4 7 8 8
T D
1
RD
2
Figure 09
Connecting the supply
Figure 10
Pin assignment in RJ45 format
P i n 1
P i n 2
P i n 3
P i n 4
P i n 5
P i n 6
P i n 7
P i n 8
R D +
R D -
T D +
T D -
n . c .
n . c .
n . c .
n . c .
R J 4 5
6.3. Diagnostic Indicators
Link ControlTP Path (RJ45):
The line monitoring checks the connected cable
segment for a short circuit or interrupt.To do this, the
partner must send link or data signals.The LED
(green) lights up if no error has occurred.An interface
that is not being used or a terminal device that is
switched off is indicated as an error and the LED goes
out.
Data ControlTP Path (RJ45):
The data LED (yellow) flashes depending on the
amount of data that is received by the 10Base-T
interface.
The module is operated using a +24 V DC SELV.
5.1. Operation as an Individual Device:
Provide the supply voltage for the module via
terminals US1 and GND.
As an option, an additional power supply unit can be
connected to terminals US2 and GND to provide a
redundant voltage supply.
Both US1/US2 voltages are forwarded on the
backplane (Figure 03).
5.2. Operation in a FL Hub Station:
6.Twisted-Pair Interface (TP Port)
6.1. 10Base-T Interface
The FL MC 10BASE-T/FO G850 has an Ethernet
interface on the front in RJ45 format, to which only
twisted-pair cables with an impedance of 100 Ω can be
connected.The data transmission rate is 10 Mbps.The
interface can detect a pair of incorrectly connected
receivingcables(RD+/RD-) and correct them usingthe
auto polarity correction function.
.
6.2. Connection
Push the Ethernet cable with the
crimped RJ45 connector into interface 1 until it
engages with a click.Observe the encoding of the
connector.
The sum of the nominal currents in a FL
station must not exceed 2 A. Please refer
to the nominal currents specified in the
data sheets for the selected FL modules.
The supply voltage US1, and if applicable
US2, may only be supplied to one of the
modules and never to several modules.
If a hub or hub agent is present in the
station, the supply must be provided to
one of these modules.
Only use shielded twisted-pair cables
and corresponding shielded RJ45
connectors.

PHOENIX CONTACT page 7 of 7
Medium Converter – FL MC 10BASE-T/FO G850
6 3 7 9 A 0 2 0
Figure 11
B-FOC (ST) connection
61451001
U L
F L M C 1 0 B A S E - T
/F O G 8 5 0
O rd.-N o.2744788
T D
1
R D
2
6 1 4 5 1 0 0 1
6379A019
61451001
U L
F L M C 1 0 B A S E - T
/F O G 8 5 0
O rd.-N o.2744788
T D
1
R D
2
Figure 12
Signal direction for the fiber
7. Optical Fiber Interface (FO Port)
7.1. Optical Fiber (FO) Connection
1. Connect the optical fiber cable to the B-FOC (ST

)
connector for the send and receive channel and
push the connector clamp mechanism downwards.
2. Secure the connection with a quarter turn to the
right (Figure 11).
General Notes
Follow the cable manufacturer's technical data when
handlingthevariousopticalfiber cables.Inorderfor the
communication path to be protected against
interference, the permissible values for the bending
radii, strain, and pressure strengths must not be
exceeded.
ST® is a registered trademark of AT&T.
7.2. Diagnostic Indicators
Link Control Optical Fiber Path (FO):
The line monitoring checks the connected cable
segment for an interrupt.To do this, the partner must
send link or data signals.The LED (green) lights up if
no error has occurred. An interface that is not being
used or a terminal device that is switched off is
indicated as an error and the LED goes out.
Data Control Optical Fiber Path (FO):
The data LED (yellow) flashes depending on the
amount of data that is received by the optical fiber
interface.
Protective caps should only be removed
just before the connectors are
connected.They protect the send and
receive elements.The same applies to
the protective caps for the connectors.
During operation, do not look directly
into send diodes, or use visual aids to
look into the glass fibers.The infrared
light is not visible.
Be aware of the optical fiber cable signal
direction when coupling two medium
converters:
Module 1 fiber connection "TD" (sender)
to module 2 fiber connection "RD"
(receiver).

PHOENIX CONTACT March 15, 2001TNR: 5106077-00 http://www.phoenixcontact.com
